Braun 8986 User Manual
8990
8986
8985
off
on
fix
trim
100
cutter
80
60
foil+
40
replace
0...20
reset
8990
www.braun.com/register
clean
eco
normal
auto select
intensive
g
n
i
n
a
cartridge
full
empty
Type 5647, 5649
Modèle 5647, 5649
Modelo 5647, 5649
5-647-446/00/III-06
English 4
Français 15
Español 25
Thank you for purchasing a Braun product.
We hope you are completely satisfied with
your new Braun shaver.
If you have any questions, please call:
US residents 1-800-BRAUN-11
1-800-272-8611
Canadian residents 1-800-387-6657
Merci d’avoir fait l’achat d’un produit Braun.
Nous espérons que vous serez pleinement
satisfaite de votre nouveau rasoir Braun.
Si vous avez des questions, veuillez appeler
Braun Canada : 1-800-387-6657
Gracias por haber comprado un producto
Braun.
Esperamos que Ud. quede completamente
satisfecha con su nueva afeitadora Braun.
Si Ud. tiene alguna duda, por favor llame al:
01(800) 508-5800
USA/CDN/MEX
Printed in Germany
Imprimé en Allemagne
Impreso en Alemania
8000
Series
1
2
start
clea
ning
8
34
clean
eco
normal
auto select
intensive
full
cartridge
empty
16
17
18
19
20
5
6
7
12
off
on
fix
trim
+cutter
foil
charge
lace
rep
empty
reset
8985
8985
18 19 20
off
on
fix
trim
reset
8986
8986
8987
replace foil+ cutter
360°Complete
off
on
fix
trim
100
80
60
40
0 20
8990
8990
foil+cutter
replace
reset
8000
Series
11
10
9
10
11
12
13
14
15
16
17
18
19
20
21
English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for an appliance that has fallen into water.
Unplug immediately.
2. Do not use while bathing or in a shower when the appliance is connected to an
electrical outlet.
3. Do not place, store or charge the appliance where it can fall or be pulled
into a tub or sink. Do not place in or drop into water or other liquid.
4. When not using for an extended period of time, unplug this appliance from the
electrical outlet.
5. Unplug this appliance before cleaning.
6. This appliance comes provided with a special cord set with integrated Safety
Extra Low Voltage power supply. Do not exchange or manipulate any part of it.
FOR HOUSEHOLD USE
SAVE THESE INSTRUCTIONS
4
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is used by, on, or near
children or individuals with disabilities.
2. Use this appliance only for its intended use as described in this manual.
Do not use attachments that are not recommended by the manufacturer.
3. The appliance should never be exposed to temperatures of less than
32 º F / 0 ºC and more than 105 ºF/+40ºC for longer than a few hours.
Be sure to completely dry appliance after use. Keep cord and adapter dry at
all times. Do not store in a damp environment. To avoid damage do not wind
the cord around the appliance. It is important to check the cord for damage
periodically particularly at each end where the cord enters the plug.
4. Never operate this appliance if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped into water.
Return the appliance to a service center for examination and repair.
5. Keep the cord away from heated surfaces.
6. Never drop or insert any object into any opening.
7. Do not use outdoors or operate where aerosol (spray) products are being
used or where oxygen is being administered.
8. Do not use this appliance with a damaged or broken foil, as serious facial
injuries may occur.
9. Always attach plug to appliance first, then to outlet.
To disconnect, turn all controls to «off», then remove plug from outlet.
5
Your 360° Complete (shaver with Clean&Renew™ station)
is a system equipped with highly advanced electronic
processors. It ensures unsurpassed closeness and
comfort for you and optimum care for your shaver:
• The system automatically adapts to any voltage
worldwide.
• The system recognizes when cleaning of your shaver is
required, and automatically recognizes which of the
three cleaning programs is appropriate.
• While the shaver is connected to an electrical outlet,
the system automatically takes care of charging and
discharging in a way that is optimized for the shaver’s
battery capacity and life span.
• The system takes care of lubrication of the shaver’s
cutting parts.
• The system tells you when to replace the shaving foil
and cutter block.
Important
In order to avoid any leakage of the cleaning fluid,
place the Clean&Renew™ station on a flat, stable
surface.
Do not tip, move suddenly or transport the station in
any way if a cleaning cartridge is installed.
Do not place the station in a mirror cabinet, store it
over radiators, or place it on polished or laquered
surfaces. Do not expose to direct sunlight.
The station contains highly flammable liquid. Keep it
away from sources of ignition.
No smoking.
Keep out of reach of children.
Do not refill cartridge.
Use only original Braun refill cartridge.
6
Description
el
2
c
le
a
n
e
c
o
n
o
rm
a
l
in
te
n
s
ive
full
cartridge
auto select
em
pty
1
c
le
a
n
e
c
o
n
o
rm
a
l
in
te
n
s
iv
e
full
cartridge
auto s
elect
em
pty
c
le
a
n
e
c
o
n
o
rm
a
l
in
te
n
s
iv
e
full
cartridge
auto select
em
pty
1 Special cord set
2 «start cleaning» button
3 Station-to-shaver connecting contacts
4 Station lift button for cartridge exchange
5 Display for cleaning programs
6 Display for cleaning fluid status
7 Station mains socket
8 Cleaning cartridge
9 Shaver foil protection cap
10 Shaver foil
11 Cutter block
12 Foil release buttons
13 Long hair trimmer
14 Shaver-to-station connecting contacts
(shaver backside)
15 Switch
16 Shaver charging lights (green)
17 Shaver low-charge light (red)
18 Replacement light for shaving parts
19 Reset button
20 Pilot light
21 Shaver mains socket
Before shaving
If you wish, you may start shaving right away (if the shaver
is charged, see section «The shaver indicator lights»).
However, we recommend to follow the procedure
described here:
• Using the special cord set (1), connect the socket of the
Clean&Renew™ station (7) to an electrical outlet.
eco
normal
auto s
intensive
full
cartridge
empty
• Press the station lift button (4) to open the housing.
• Hold the cleaning cartridge (8) down on a flat, stable
surface (e.g. table).
• Carefully remove the lid from the cartridge.
• Slide the cartridge into the base of the station as far as
it will go.
• Slowly close the housing by pushing it down until it
locks.
7
a
trim
fix
on
off
cartridge
empty
The display for cleaning fluid (6) will show how much
cleaning fluid is in the cartridge:
a) cleaning solution sufficiently available
b) up to 7 cleanings left
c) new cartridge required
empty
c
full
cartridge
empty
full
b
full
cartridge
trim
fix
o
n
off
auto select
clean
eco
norm
al
auto select
s
intensive
t
a
r
g
t
n
c
i
l
n
e
a
full
cartridge
em
pty
clean
eco
normal
intensive
a
b
c
d
Make sure the foil protection cap (9) is removed from the
shaver. Insert the shaver head down into the station (the
contacts (14) on the back of the shaver will correspond to
the contacts (3) in the station). If necessary, the system
will now charge the shaver.
Also, the cleaning status will be automatically analyzed
and one of the four diodes of the cleaning program display
(5) will light up:
a) the shaver is clean
b) eco(nomic), i.e. short cleaning required
c) normal cleaning required
d) intensive cleaning required
8990
reset
0..20
foil replacel+cutter
40
60
80
100
clean
eco
select
normal
to
au
intensive
g
n
i
s
n
t
a
a
r
e
l
t
c
full
cartridge
empty
auto select
intensive
clean
eco
normal
If the system has selected one of the three cleaning
programs, it will not start until you push down the «start
cleaning» button (2). This locks the shaver into the station
and starts the cleaning process.
We recommend cleaning after each shave.
While the cleaning is in progress, the respective cleaning
program light will flash. Each cleaning consists of several
cycles (where the cleaning fluid is flushed through the
shaver head) and a heat drying period. The total cleaning
time is 33 to 50 minutes.
Cleaning processes in the Clean&Renew™ should not
be interrupted. While the shaver is drying, the metal
parts of the shaver may be hot. Also, if the shaver is
taken out prematurely and is not dry, its electronics
could be harmed.
When the program is finished, the blue «clean» light will
shine. You can release the shaver by pushing the «start
cleaning» button.
Your shaver is now clean and ready for use.
auto select
intensive
clean
eco
normal
8
Shaving
fix
on
fix
on
trim
fix
on
8990
trim
fix
on
off
If the shaver is locked into the Clean&Renew™ station,
push the «start cleaning» button (2) to release the shaver
and take it out.
Switch positions
off = (switch is locked)
Press and push up the switch to operate the shaver.
on = Shaving with the pivoting head
(the pivoting cutting system automatically adjusts to
every contour of your face).
fix = Shaving with the pivoting head locked at an angle
(to permit shaving in difficult areas, e.g. under the
nose).
trim=The long hair trimmer is activated
(for trimming sideburns, moustache and beard).
Tips for the perfect shave
• It can take up to 14-21 days for your beard to adjust
to the new shaving system.
• Shave before washing your face or taking a shower,
as skin tends to swell after washing.
• The drier the skin, the closer the shaving results will
be.
• Hold the shaver at right angles (90°) to the skin.
Stretch the skin and shave against the direction of
beard growth.
• To maintain 100% shaving performance, replace
your foil and cutter block at least every 18 months or
when worn.
Shaving with the cord
If the shaver is completely discharged and you do not
have the time to recharge in the Clean&Renew™ station,
you may also shave with the shaver connected to an
electrical outlet.
After shaving
Automatic cleaning
After each shave, return the shaver to the Clean&Renew™
station and proceed as described above in the section
«Before shaving». All charging and cleaning needs are
then taken care of. With daily use, a cleaning cartridge
should be sufficient for about 30 cleaning cycles.
The hygienic cleaning solution cartridge contains alcohol
which, once opened, will naturally evaporate slowly into
the surrounding air. Each cartridge, if not used daily,
should be replaced after approximately 8 weeks.
8990
re
s
et
0..2
0
4
foil rep
0
6
0
8
la
0
c
1
e
0
l+
0
cu
tte
r
n
lea
c
t
o
c
e
lec
l
a
m
r
o
n
to se
au
e
iv
s
n
te
in
g
n
i
s
n
t
a
a
r
e
l
t
c
ll
fu
cartridge
y
t
p
m
e
9
fix
on
off
on
off
new
e
t
t
t
Quick cleaning
Press the foil release buttons (12) to lift the shaver foil
(do not remove the foil completely). Switch on the shaver
for approx. 5–10 seconds so that the shaved stubbles can
fall out.
Thorough manual cleaning
Manual cleaning is recommended only when the
Clean&Renew™ station is not available, e.g. when travelling.
Never use water to clean the shaver.
Remove the shaver foil and tap it out on a flat surface.
Using the brush, clean the inner area of the pivoting head.
However, do not clean the shaver foil nor the cutter block
with the brush as this may damage them.
If you do not use the Clean&Renew™ station for a longer
period of time, you should apply a drop of light machine
oil onto the shaver foil.
Cleaning the housing
Clean the housing of shaver and station from time to time
with a damp cloth, especially inside the opening of the
station where the shaver rests.
Replacing the cartridge
After having pressed the lift button (4) to open the housing,
wait for a few seconds before removing the used cartridge.
Before discarding the used cartridge, make sure to close
old
the openings using the lid of the new cartridge, since the
used cartridge will contain contaminated cleaning solution.
The shaver indicator lights
60
replac
40
0..20
reset
8990
Pilot light (20): the shaver is connected to an electrical
outlet.
10
100
charge
replace foil+cut
empty
80
60
40
0...20
replace foil+cut
replace foil+cut
The red low-charge light (17) flashes when the battery
capacity has dropped below 20%, provided the shaver is
switched on. The remaining capacity will then be sufficient
for 2 to 3 shaves.
Model 8990:
e
t
tt
empty
charge
8000
Series
360°Complete
When the shaver is fully charged, all five
charging lights (16) will light up (20% per light), provided
the shaver is plugged in or switched on.
Model 8986: When the shaver is fully charged, all three
charging lights (16) will light up, provided the shaver is
plugged in or switched on.
Model 8985: The green single charging light (16) shows
that the shaver is being charged. When fully charged, the
charging light flashes or turns off. If later on, the charging
light turns on again, this indicates that the shaver is being
recharged to maintain its full capacity.
Charging information
A full charge will give up to 50 minutes of cordless shaving
time, depending on your beard growth.
Best environmental temperature range for charging is
60°F to 75°F/15 °C to 35 °C.
For battery maintenance, the system will automatically
initiate full discharging and then recharging of the
batteries. This will take place every six months at the
most, and only if necessary.
Replacement light for shaving parts/Reset
To maintain 100% shaving performance, replace your foil
and cutter block, when the replacement light for shaving
parts (18) comes on (after about 18 months) or when worn.
Change both parts at the same time for a closer shave with
less skin irritation.
(Shaver foil (10) and cutter block (11): 8000 series)
The replacement light will remind you during the next
7 shaves to replace the shaving parts. Then the shaver
will automatically reset the display.
After you have replaced the shaving parts (foil and cutter
block), use a ball-pen to push the «reset» button (19) for at
least 3 seconds to reset the counter.
While doing so, the replacement light blinks and goes off
when the reset is complete. The manual reset can be done
at any time.
100
80
60
40
0...20
replace foil+cutt
replace foil+ cu
80
60
40
0...20
replace foil+cut
replace foil
t
11
Loading...
