Appendix A - CR2 Specifications
C001538_04_CR2 User Manual_Appendix A - 1
CR2 - Physical Characteristics
Reader Dimensions: 1.3” H x 4.3” D x 1.8” W (3.3cm H x 10.9cm L x 4.6cm W)
Handle Dimensions: 3.8” H x 1.4” D x 1.2” W (9.65cm H x 3.6cm D x 3cm W)
Reader Weight: 2.5 oz (71.5 gm)
Battery Weight: 2.1 oz (59.5 gm)
Battery Blank Weight: .5 oz (13.6 gm)
Handle Weight: 2.1 oz (58.9 gm)
CR2 - Performance Characteristics
Field of View: Near: 21.5º horizontal by 16.2º vertical
Far: 22.9º horizontal by 11.6º vertical
Focal Point: Near: approximately 4”
Far: approximately 9”
Sensor: Progressive Scan CMOS 1.33 MP (1024x1280) 256 level gray scale
Optical Resolution: Near Field: 1024 x 640
Far Field: 1024 x 640
Pitch: ± 60 ° (from front to back)
Skew: ± 60 ° from plane parallel to symbol (side-to-side)
Rotational Tolerance: ± 180 °
Print Contrast Res.: 25% (1-D symbologies) or 35% (PDF417) absolute dark/light reflectance
differential, measured at 650 nm
Target Beam: Class IIa Visible Laser Diode at 630nm
Ambient Light Immunity: Sunlight: Up to 9,000ft-candles/96,890 lux
Shock: Withstands multiple drops of 6.56 feet (2 Meters) concrete
Power Requirements: Reader @ 5vdc (mA) - Typical = 140; Peak = 310; Idle = n/a;
Sleep = 3; Bluetooth Radio @ 90m away (mA) Typical = 280
Peak = 350; Idle = 96; Sleep = 3
1400 mAH Battery with radio will support 4000 read/transmits
per charge including 8 hours of standby interval.
Optional Cable Interfaces: USB (Full Speed), RS232 & PS/2
Code Quality: Code Readability Index
C001538_04_CR2 User Manual_Appendix A - 2
CR2 - User Environment
Operating Temperature: 0 ° to 40 ° C/32 ° to 104 ° F
Storage Temperature: -20 ° to 60 ° C/-4 ° to 140 ° F
Humidity: 5% to 95% non condensing
Decode Capability: MaxiCode, PDF417 (including Macro support), Data
Matrix, QR Code, MicroPDF417, GoCode, Composite,
Code 11, Aztec, Code 39, Code 128, Pharmacode,
UPC/EAN/JAN, Int 2 of 5, Codabar, Codablock F,
Code 93, RSS, Posnet, Planet, Japanese Post,
Australian Post, Royal Mail, KIX, MSI Plessy
Image Output Options: Formats: JPEG, Raw (Uncompressed)
Field Selection: Near or Far
Resolution Selection: 1024 x 640 (Multiple Window Options)
Grayscale: 256 Level
Time Stamp: Interval Logging
Data Editing: CodeXML® Ready
C001538_04_CR2 User Manual_Appendix A - 3
