About This Document
4
Document Conventions
Document Conventions
The following conventions are used throughout this document to convey certain information.
Alternate Color (online only) Cross-references contain hot links to other sections in this
guide. If you are viewing this guide online in .p df format, you can click the cross-reference
(blue text) to jump directly to its location.
LCD Display Examples Text from a printer’s Liquid Crystal Display (LCD) appears in
Bubbledot ICG font.
Command Line Examples Command line examples appear in Courier New font. For
example, type
Files and Directories File names and directories appear in Courier New font. For
example, the
Icons Used
ZTools to get to the Post-Install scripts in the bin directory.
Brady<version number>.tar file and the /root directory.
Caution • Warns you of the potential for electrostatic discharge.
Caution • Warns you of a potential electric shock situation.
Caution • Warns you of a situation where excessive heat could cause a burn.
Caution • Advises you that failure to take or avoid a specific action could result in physical
harm to you.
Caution • (No icon) Advises you that failure to take or avoid a specific action could result in
physical harm to the hardware.
Important • Advises you of informatio n that is essential to complete a task.
Note • Indicates neutral or positive information that emphasizes or supplements important
points of the main text.
Example • Provides an example, often a scenario, to better clarify a section of text.
14070L-001 Rev. AMVPplus User Guide1/12/07
About This Document
PAUSE
Document Conventions
Illustration Callouts Callouts are used when an illustration contains information that needs
to be labeled and described. A table that contains the labels and descriptions follows the
graphic. Figure 1 provides an example.
The control panel LCD shows the printer’s operating status and allows you to change settings
as needed to work with your media and label formats.
The control panel buttons and lights are sho wn in Figure 3. Descriptions for each are located in
Ta ble 1 and Table 2.
Figure 3 • Control Panel
1234
5
Introduction
Control Panel
9
12
11
10
9
Power LED
1
Pause LED
2
Error LED
3
Data LED
4
LCD
5
PLUS (+) button
6
SETUP/EXIT button
7
CANCEL button
8
PAUSE button
9
FEED button
10
SELECT button
11
MINUS (–) button
12
6
7
8
1/12/07MVPplus User Guide14070L-001 Rev. A
Introduction
10
Control Panel
Control Panel Buttons
ButtonFunction
Table 1 • Control Panel Buttons
FEED
PAUSE
CANCEL
SETUP/EXIT
SELECT
PLUS (+)
(scroll mode)
PLUS (+)
(change mode)
Forces the printer to feed one blank label each time the button is pressed.
• Printer not printing: one blank label immediately feeds.
• Printing: one blank label feeds after the current batch of labels is complete.
Starts and stops the printing process.
• Printer not printing: no printing occurs. (Press
PAUSE again to resume printing.)
• Printing: printing stops after the current label is complete.
Cancels print jobs when in the pause mode.
• Printer not printing: the next stored label format does not print.
• Printing: current label completes printing, and the next label format is cancelled.
Press and hold for several seconds to cancel all print jobs in memory.
Enters and exits the configuration mode.
Toggles the function of PLUS (+) and MINUS (–) between the Scroll and Change
Modes.
• Press once to use
PLUS (+) and MINUS (–) to change the values of the selection.
• Press again to use PLUS (+) and MINUS (–) to scroll through the menu items.
Scrolls to the next selection.
• Increases the value.
• Answers yes.
• Prints a label (when applicable).
MINUS (–)
Scrolls to the previous selection.
(scroll mode)
MINUS (–)
(change mode)
• Decreases the value.
• Selects the digit you wish to change.
• Answers no.
14070L-001 Rev. AMVPplus User Guide1/12/07
Control Panel Lights
Table 2 • Control Panel Lights
LightStatusIndication
POWEROffThe printer is off, or no power is applied.
OnThe printer is on.
PAUSEOffNormal printer operation.
OnThe printer has stopped all printing operati ons.
FlashingThe Pause light flashes when initializing FLASH or PCMCIA
memory and in Peel-Off Mode when the label is available.
ERROROffNormal printer operation (no errors).
Introduction
Control Panel
11
Slow flashing
Fast flashing
On
DATAOffNormal printer operation (no data being received or processed).
One flash
Slow flashingThe printer cannot accept more data from the host.
Fast flashingThe printer is receiving data.
OnA partial format has been received and no subsequent data activity.
RIBBON IN warning, HEAD UNDER TEMP warning, or HEAD
OVER TEMP
error.
HEAD OPEN error.
MEDIA OUT, or RIBBON OUT, or CUTTER JAM errors.
CANCEL was pressed and a format is successfully cancelled.
1/12/07MVPplus User Guide14070L-001 Rev. A
Introduction
12
Printer Media Compartment
Printer Media Compartment
Figure 4 shows the components inside the media compartment of your printer. Depending on
installed options, your printer may look slightly different.
Figure 4 • Printer Components
3
4
2
1
5
6
7
Printhead assembly
1
Control panel
2
Media door
3
Media supply spindle
4
8
Ribbon take-up spindle
5
Ribbon supply spindle
6
Dancer assembly
7
Printhead release latch
8
14070L-001 Rev. AMVPplus User Guide1/12/07
2
Printer Setup
This section provides the tasks that you must complete and the issues that you must consider
before you load and configure your printer.
Review this checklist, and resolve any issues before you set up or use your printer.
Unpack and Inspect the Printer Have you unpacked the printer and inspected it for
Select a Site Have you selected an appropriate location for the printer? If y ou have no t,
Connect to a Data Source Have you determined how the printer will connect to a
Attach a Power Cord Do you have the correct power cord for your printer? If you are
Select Media Do you have the correct media for your application? If you are unsure,
Select Ribbon Do you need to use ribbon, and is the appropriate ribbon available, if
damage? If you have not, see Unpack and Inspect the Printer on page 15.
see Select a Site for the Printer on page 16.
data source (usually a computer)? For more information, see Select a Communication
Interface on page 17.
unsure, see Power Cord Specifications on page 22. To attach the power cord and connect
the printer to a power source, see Connect the Printer to a Power Source on page 21.
see Types of Media on page 23.
needed? If you are unsure, see Ribbon Overview on page 25.
14070L-001 Rev. AMVPplus User Guide1/12/07
Handling the Printer
This section describes how to handle your printer.
Unpack and Inspect the Printer
When you receive the printer, immediately unpack it and inspect for shipping damage.
• Save all packing materials.
• Check all exterior surfaces for damage.
• Raise the media door, and inspect the media compartment for damage to components.
If you discover shipping damage upon inspection:
• Immediately notify the shipping company and file a damage report.
• Keep all packaging material for shipping company inspection.
• Notify your authorized Brady distributor.
Important • Brady Corporation is not responsible for any damage incurred during the
shipment of the equipment and will not repair this damage under warranty.
Printer Setup
Handling the Printer
15
Store the Printer
If you are not placing the printer into immediate operation, repackage it using the original
packing materials. You may store the printer under the conditions shown in Table 3.
TemperatureRelative Humidity
–40°F to 140°F (–40° to 60°C)5% to 85% non-condensing
Ship the Printer
If you must ship the printer:
• Remove any media or ribbon from the printer to avoid damaging the printer.
• Carefully pack the printer into the original container or a suitable alternate container to
avoid damage during transit. A shipping container can be purchased from Br ady if the
original packaging has been lost or destroyed.
Recycle the Printer
Table 3 • Storage Temperature and Humidity
This printer is recyclable. If you must dispose of the printer, do not do so in
unsorted municipal waste. Please recycle according to your local standards.
1/12/07MVPplus User Guide14070L-001 Rev. A
Printer Setup
16
Select a Site for the Printer
Select a Site for the Printer
Consider the following whe n selecting an appropriate location for your printer.
Select a Surface
Select a solid, level surface of sufficient size and strength to accommodate the printer and
other equipment (such as a computer), if necessary. The choices include a table, countertop,
desk, or cart. For the printer’s weight and dimensions, see General Specifications on page 130.
Provide Proper Operating Conditions
This printer is designed to function in a wide range of environmental and electrical conditions,
including a warehouse or factory floor. For more information on the required conditions, see
General Specifications on page 130.
Ta ble 4 shows the temperature and relative humidity requirements for the printer when it is
operating.
Table 4 • Operating Temperature and Humidity
ModeTemperatureRelative Humidity
Thermal Transfer41° to 104°F (5° to 40°C)20 to 85% non-condensing
Direct Thermal32° to 104°F (0° to 40°C)20 to 85% non-condensing
Allow Proper Space
The printer should have enough space around it for you to be able to open the media door. To
allow for proper ventilation and cooling, leave open space on all sides of the printer.
Caution • Do not place any padding or cushioning material behind or under the printer
because this restricts air flow and could cause the printer to overheat.
Provide a Data Source
If the printer will be located away from the data source (such as a computer), the selected site
must provide the appropriate connections to that data source. For more information on the
types of communication interfaces and their limitations, see Select a Communication Interfa ce
on page 17.
Provide a Power Source
Place the printer within a short distance of a power outlet that is easily accessible.
14070L-001 Rev. AMVPplus User Guide1/12/07
Select a Communication Interface
The way that you connect your pri nter to a data source depend s on th e communic ation op tions
installed in the printer. You may use any available connection to send commands and label
formats from a host computer to the printer.
Caution • Ensure that the printer power is off (O) before connecting data communications
cables. Connecting a data communications cable while the power is on (
printer.
Note • You must supply all interface cables or wireless cards for your application. Refer to
Data Cable Requirements on page 20 for specific cable requirements.
Connector Locations
Refer to Figure 5. The printer comes standard with both an Electronics Industries Association
(EIA) RS-232 serial interface (DB-9 connector) and an IEEE 1284 bidirectional parallel
interface. You may use either of these interface methods to send commands and label formats
from a computer to the printer.
Printer Setup
Select a Communication Interface
I) may damage the
17
Figure 5 • Cable Connections
Parallel interface connector
1
DB-9 serial interface connector
2
1
2
1/12/07MVPplus User Guide14070L-001 Rev. A
Printer Setup
18
Select a Communication Interface
Types of Connections
The method of connecting the printer to a data source depends on the communication options
installed in the printer and the host computer. This section provides basic information about
common interfaces.
When communicating via the serial data port (RS-232), the baud rate, number of data and stop
bits, the parity, and the XON/XOFF or DTR control should be set to match those of the host
computer. See Table 10, Printer Parameters on page 72 to configure these parameters. When
communicating via the parallel port, the previously mentioned parameters do not apply.
RS-232 Serial A serial communication method consisting of data and control signals;
available as a standard feature on most personal computers and other hosts.
• Advantages: Cables and connectors are readily available from computer equipment stores
and suppliers; easy to connect; two-way communication between the computer and the
printer; relatively long cable length.
• Disadvantages: Slower than the parallel connection; limited to 50 feet (15.24 m) o f cable;
may need to change printer parameters to match host computer; need to use a null-modem
adaptor to connect to the printer if using a standard modem cable.
Figure 6 • Connecting the Printer through the Serial Data Port
9-Pin Female Connector
and Standard Modem Cable
PrinterComputerPrinterComputer
1
2
3
Null-modem adaptor (if using a standard modem cable)
1
9-pin male connector, connected to printer or null-modem adaptor
2
9-pin female connector, connected to computer
3
25-pin female connector, connected to computer
4
Maximum cable length = 50 ft. (15 m)
5
25-Pin Female Connector
and Null Modem Cable
2
4
5
14070L-001 Rev. AMVPplus User Guide1/12/07
Printer Setup
Select a Communication Interface
IEEE 1284 Bidirectional Parallel A common communication method available on most
personal computers and other hosts.
• Advantages: Faster than the serial connection; cables and connectors are readily available
from computer equipment stores and suppliers; easy to connect; two-way communication
between the computer and the printer; no printer parameter ch anges re quired to match the
host computer.
• Disadvantages: Recommended cable length of only 6 feet (1.83 m) with a maximum
length of 10 ft (3 m); many computers are equipped with only one parallel port, allowing
only one IEEE 1284 bidirectional device to be connected at a time; an Ethernet print
server takes up or covers this port on the printer.
Figure 7 • Connecting the Printer through the Parallel Port
PrinterComputer
1
19
3
36-pin male connector, attaching to printer
1
25-pin male connector, attaching t o computer
2
Maximum cable length = 10 ft. (3 m)
3
2
Optional Ethernet Print Servers Ethernet-based print servers also are available to
connect your printer to a data source. Manuals are available on the user CD that came with
your printer.
Note • The parallel connection on your printer is not operational when one of these print
server is installed. Wireless and external wired print server s plug directly into the printer’s
parallel port. Internal print servers include a mounting bracket that covers the parallel port.
With the BradyConnect PrintServer II (PSII), the printer can communicate with a 10BaseT
network. For more information on PSII, see the PrintServer II User and Reference Guide.
1/12/07MVPplus User Guide14070L-001 Rev. A
Printer Setup
20
Select a Communication Interface
Data Cable Requirements
Ethernet cables do not require shielding, but all other data cables must be fully shielded and
fitted with metal or metallized connector shel ls. Unshie lde d data cables may increase ra dia ted
emissions above the regulated limits.
To minimize electrical noise pickup in the cable:
Note • Brady printers comply with FCC Rules and Regulations, Part 15 for Class B
Equipment using fully shielded, 6.5 ft. (2 m) data cables. Use of unshielded cables may
increase radiation above the Class B limits.
• Keep data cables as short as possible.
• Do not bundle the data cables tightly with the power cords.
• Do not tie the data cables to power wire conduits.
14070L-001 Rev. AMVPplus User Guide1/12/07
Loading...
+ 124 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
