Boxlight S25 Product Sheet

Phoenix S25

Phoenix S25

BRIGHTNESS

3000 Lumens (Boost)
2600 Lumens (Standard)
2400 Lumens ( Eco)

RESOLUTION

800 x 600 SVGA True
1280 x 1024 SXGA Compressed

DISPLAY TYPE

0.55" x 1, 12º DDR DLP

CONTRAST RATIO

2000 :1

LAMP

200 watt OSRAM VIP

LAMP LIFE

2000 Boost
3000 Standard
4000 Eco

DIAGONAL IMAGE SIZE

22” - 260” Inches

ASPECT RATIO

4:3 Compatible 16:9

OPTIONAL ACCESSORIES:

Extended Warranty
Mac Adaptor / DVI Adaptor Cable / Audio / VGA / Component / Composite Video
Universal Ceiling Mount / Suspension Pole
Round Flush Kit
Security Cable / Spare Lamp Module

Special features of the Phoenix S25 include:

Three lamp modes—Change your lamp output for varying light
conditions and save on lamp life.

Password security—Protect use from multiple users or theft.
Fan speed options—Enables better control of the projector’s

temperature and cooling process.
Custom Splash Screen—Customize the start-up screen on the
projector.

Laser Remote Control (with batteries)

User Manual CD ROM / Quick Start Guide

Power Cord / USB Cable

SHIPS WITH:

Computer Cable

PROJECTION LENS

Manual Zoom / Focus

THROW DISTANCE

3.2 ’- 32’ Feet
1 - 10 Meters

THROW RATIO

1.89 ~ 2.18 ( x screen width)

ZOOM RATIO

1.15:1

INPUTS

VGA-in / Component
Composite
Audio (R/L) RCA
S-Video
Audio (Mini jack)

OUTPUTS

Audio (Mini jack)
VGA (Out)

COMPATIBILITY

VGA,SVGA,XGA,SXGA, Mac

PROJECTOR CONTROLS

USB

19462 Powder Hill Place, Suite 101
Poulsbo, WA 98370

© 2008 BOXLIGHT Corporation. All rights reserved. Specifications are subject to change without notice.

KEYSTONE

+/- 15º

EDTV / SDTV / HDTV

480i/p / 720p / 1080i

DIMENSIONS (WxDxH)

12” x 9.6” x 3.4” Inches
30 x 24.4 x 8.8cm

WEIGHT

7.3 Lbs / 3.3 kg

VIDEO COMPATIBILITY

NTSC / NTSC 4.43, PAL B/G/H/I/M/N 60 / SECAM

DECIBEL RATING

36dB (boost) / 33dB (standard) / 31dB (eco)

AUDIO

1 x 3w Mono Speaker

WARRANTY

3 year parts & labor / 90 day lamp

FCC CERTIFICATION

FCC-B,UL,C-UL,TUV.CB,CCC

H-REFRESH RATE

Horizontal—15—90 kHz

V-REFRESH RATE

Vertical—50—85 kHz

POWER SUPPLY

AC input 110 ~ 240
Voltage (auto ranging)

POWER CONSUMPTION

290W (boost)
255W (standard)
230W (eco)

www.boxlight.com

Direct 800.762.5757

International 360.779.7901

Partners 866.688.3636

2.13.08
