Boss Audio BV7464B User Manual

To ensure safety while driving

and to comply with laws,

drivers should not watch video or

operate the video device while driving.

Content

Precaution..... ..... ..... .......................

Safety Informatio n.... ..... ................

Disc Note........ ..... ..... .....................

Installation .... ..... ..... ......................

Electric Connecti on .... ..... .............

Remote Control .... ..... ..... ..............

Basic Operation ... ..... ..... ...............

Main Menu Operation..... ..... ............

Setting animation..... ..... .................

Setting disc..... ..... ..... .....................

Setting radio.... ..... ..... .....................

Setting BT............... ..... ..................

Setting wallpaper...... ..... . ................

Version about.......... ..... ...................

Setting time..... ..... . ..... ...................

Setting audio mode...... ..... ..............

Setting video mode...... ..... ..............

Setting OSD language.... ..... ...........

Setting illumination col or... ..... .........

TFT dis play calibration. ......... ..... ....

Rear Vi ew Camera ................. ..... ..

Control Panel ..... ..... ..... .................

Unit keys ......... ..... ..... .....................

Radio Operation.. ..... ..... ................

Listening to the radio ..... ..... ............

Storing and Listening to a mem ory

station ......... ..... ..... .................. ...

Automatic Memory St oring &

2

Program Scanning...... ..... ............

3

RDS function..... ..... ..... ...................

4

Media Operation....... ..... .................

5

Basic Operation ... ..... ..... .................

8

Selecting Play Mode ...... ..... .............

9

On-Screen Display Functi on .... .........

11

Digital Video Special Function.... ....

11

Multi-Subtitle Languag e funct ion.. .....

11

Multi-audio language Fun ction ..... .....

12

Multi-angle Function.. ..... .................

12

Tit le menu f uncti on .... .................. ....

12

BT Operation.. ........................... ...

12

AUX Operation ..... ..... ..... ................

12

AV Opera tion................... ..... ..........

12

USB Operation ..... ..... ..... ................

12

Card Operation .... ..... ..... ................

13

SWC Operation.... ..... ..... ................

13

Parental Control. ..... ..... ................

13

Region Code...... ..... ..... ..................

13

Specification ... ..... ..... ....................

13

Troubleshooting. ..... ..... ..................

14

14

16

16

16

17

17

19

20

20

21

22

22

22

22

22

23

26

27

28

28

29

30

31

32

33

-1-

Precaution

THANK YOU F OR PURCHASING PLAYER .

Before oper ating the unit, read this manual thor oughly and ke ep it handy
for future re ference .
To av oid injury or accident , read the follo wing precau tions before
installin g and operati ng the unit .

ON INSTALLATION

DO NOT inst all any receiver in locations where ;

- it may obstru ct the steering wheel and gearshift lever operat ions, as this
may result in a t raffic accident.

- it may obstru ct the operation of safety devices su ch as air bags, a s this
may result in a f atal accident.

- it may obstru ct visibili ty.
DO NOT oper ate any receiver while manipulati ng the steering wheel, as
this may resu lt in a traffic accide nt.
The driver mu st not watch the monitor while driving.
IF THE DRIV ER watches the monitor while drivin g, it may lead to
carelessness and cause a n accident.
IF YOU NEED t o operate the receive while driving , be sure to look ahead
carefully o r you may be invo lved in a traffic acci dent.
IF THE PARKING BRAKE is not engage d.“ ParkingBrake” flashes on the
monitor, and n o playback pi cture will be shown.

- This warn ing appears only when the parking brake wire is conn ected to
the parking brake system b uilt in the car ( refer to the e lectric connection)

Do not pr ess h ard on the LCD panel. Do ing s o can distort

A BOSS AUDIO M ULTIMEDIA

ABOUT THE LIQ UID CRYSTAL DI SPLAY (LCD) PAN EL

the picture o r

Do not press hard on the LCD pan el. Doing so can distort
cause a malfunction . The picture may become unclear , or the LCD
panel may be damaged .

NOTES ON CLEA NING

-Clean the LC D panel with a sl ightly damp soft cloth.

-Do not use sol vents such as benzine, thinner, commercially av ailable
cleaners or antistatic spray .

- Do not use alcohol to clean the scr een .

If your car was p arked in a cold o r hot place, the picture may not be clear .
The monit or is not damaged . The pi cture will become clear the temper­ ature in your c ar becomes no rmal .

-2-

Safety Information

CAUTION:

THIS DI GITAL VIDEO PLAYER IS A CLASS I L ASER PRODUCT. HOWEVER

THIS DIGITAL VIDEO PLAYER USES A VISIBLE/INVISIBLE LA SER BEA M
WHICH COULD CAUSE .

HAZARDOUS RADIATION EXPOSURE IF DIREC TED. BE S URE TO OPERATE
THE DIG ITAL VIDEO PLAYE R CORRE CTLY AS INSTRUCTED.
USE OF CONTROLS OR ADJUS TMENT S OR PERF ORMANCE OF
PROCEDURES OTHER THAN TH OSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT
REPAIR YOUR SELF. REF ER SERVICI NG TO QUALIFIED PERSONNEL.

WARNING:

TO RE DUCE THE RISK OF FIRE O R ELECT RIC SHO CK, DO NOT EXP OSE THI S
EQUIPMENT TO RAIN OR MOI STURE .

TO RE DUCE THE RISK OF FIRE O R ELECT RIC SHO CK, AND ANNOY ING
INTERFERENCE, USE O NLY THE REC OMMEN DED ACCES SORIE S.

THIS DE VICE IS INTENDED FOR CONTINUOUS O PERATION.

This pr oduct incorporates copyright prote ction t echno logy that is protected
by method claims of cer tain U. S. Pate nts and o ther intellectual property ri ghts
owned by Macrovision Corpo ratio n and oth er rights owners.Use of this
copyright protect ion tec hnolo gy must b e authorized by Macro vision Corporati on,
and is intended for home and oth er limi ted vie wing uses only unless
otherwise authori zed by Ma crovi sion Co rporation. Reverse engineering or
disassembly is prohibite d.

REGION MANA GEMENT INFORMATIO N:

This Di gital Vide o Playe r is designed and manufactured to respon d to the Re gion
Management Inform ation t hat is re corde d on a Digital Video di sc. If the Region

number described on the Digi tal Video disc does n ot corr espon d to the Region
number of this Digita l Video Player, this Digita l Video Player cann ot play t his dis c.

-3-

Disc Note

Disc format s supported by this
player

Digit al
Video

VCD

CD

MP3

Audio and Video
Disc size 12 cm

Audio and Video
Disc size 12 cm

Audio
Disc size 12 cm

Audio
Disc size 12 cm

Discs which c annot be played
with this pla yer

Digital Video-RAM
CDV
CDG

Handling an d Cleaning

Dirt, dust, scratch es and wa rping d isc
will cause misoperation.
Do not place stickers o r make
scratches on discs.
Do not warp discs.
A disc should always be kept in its
case when not in use to pre vent fr om
damaging.
Do not place discs in the f ollow ing
places:

1.Direct sunlight

2.Dirty, dusty and damp areas

3.Near car heaters

4.On the seats or dashbo ard

Disc Cleani ng

Use a dry soft cloth to wip e the sur face.
If the disc is quite dirt y, use a soft cloth
slightly moistured with is oprop yl (rub bing)
alcohol. Never use solvent s such as
benzine, thinner or conven tiona l recor d
cleaners as they may mar the sur face of
the disc.

Note:

A disc may become somewhat scra tched
(although not enough to make i t

-4-

unusable) depending on you r handl e it
and conditions in the usage en viron ment.
Note these scratche s are not a n
indication of any problem wi th the pl ayer.

Lab el si de
up

Do no t tou ch
the
und ers ide
of th e dis c

Do no t
ben d

Wip e the disc fr om
center
tow ard t he out side
edg e

Preparing N ew Discs with Rough
Spots

A new disc ma y h av e r oug h e dg es on
its in side and ou ts ide ed ge s. If a d isc
with rou gh edges is us ed , t he prope r
setting w ill not be per fo rme d and th e
player will not p lay th e disc. Therefore,
remove the ro u gh edg e s i n ad v anc e
by using a ball point pen or penci l as
shown on the right. To rem o ve t he
rough edges, press the sid e o f th e pen
or pencil against the inside a nd outs ide
edges of the disc.

Rou gh spot s
on
out side ed ge

Bal l point p en
or pe ncil

Rou gh spot s
on in side
edg e

Installation

NOTES:

1. Choose the mounting locat ion whe re the un it will not interfere with the normal
driving function of the driv er.

2. Before finally installi ng the un it, con nect the wiring temporarily and make sur e
it is all connected up properl y and the u nit and t he system work properly.

3. Use only the parts included w ith the u nit to en sure proper installation. The use
of unauthorized parts can ca use mal funct ions.

4. Consult with your nearest d ealer i f insta llation requires the drilling of holes o r
other modifications of the v ehicl e.

5. Install the unit whe re it doe s not get i n the dri ver s way and cannot injure the
passenger if there is a sudden s top, li ke an eme rgency stop.
6

. Avoid in stalling the unit where it would be subjec t to high t emper ature , such
as from direct sunlight, or fr om hot ai r, from th e heater, or where it would be
subject to dust, dirt o r exces sive vi brati on.

7. If installation angle exc eeds 30 f rom hor izontal, the unit might not give its
optimum performance.

DIN FRONT/R EAR-MOUNT

This unit can be properly inst alled e ither f rom "Front"(conventional DIN
Front-mount) or "Re ar"(D IN Rear -moun t installation, utilizing threaded
screw holes at the sides of the un it chas sis). F or details, refer to the followin g
illustrated installati on meth ods.

'

30

Removing the unit

1. Press the REL butt on to rel ease th e front panel .

2. Remove the control panel .

-5-

Installation

Installation the unit

3. Remove the PLASTIC COVER of the both sides away

PLASTIC COVER

4. Insert the two KEY PLAT into the grooves at both sides
of the unit as shown in figure until they click .

KEY PLATE

5. Pulling the levers makes it possible to remove
the unit from the dashboard .

SPRIN G WASH ER

PLAIN WA SHE R

TAPPING SCREW

DASH BO ARD

HEX NUT

METAL MOU NTING
STRAP

CONSO LE

SLIDE B RAC KET
HOUSI NG

HEX BOLT

-6-

Installation

How To Remove And Install The Front Panel

When detaching or attachin g the con trol pa nel, be careful not to damage the
connectors on the back of the co ntrol p anel an d on the panel holder.

Detaching C ontrol Panel

Before deta ching the control panel, be sure to turn off the power.

1). Press the “REL” release button and the left han d side of f ront pa nel will release.

RELEA SE BU TTON

2). Pull-off the front panel and keep the front pan el into t he case .

PROTE CTI VE CA SE

Attaching C ontrol Panel

1). First insert the ri ght han d side of t he fron t panel into the hollow of the unit .
(NOTE : the “bulge” poi nt on the p anel mu st be att ached into the hollow of the unit .)

2). Gently push the lef t hand si de of the f ront pa nel until you feel a “ Click” .

Hollow

Bulge

-7-

Electric Connection

WI RING CONNECTION

RADIO ANTENNA JACK

KEY 1 INPU T BRO WN

KEY 2 INPU T WHI TE

KEY GROU ND BL ACK

RCH IN RED
VIDEO IN YE LLOW

REAR RCA AU DIO OU TPU T RED

LCH IN WHI TE

REAR RCA AU DIO OU TPU T WHIT E

REAR CAM ERA IN PUT YELLO W

SUBWOOFER G RAY

PARKING BRAKE INPUT: LIGHT GREEN

REAR CAMERA SWITCH: VIOLET/WHITE

FRONT RCA AUDIO OUT SOCKET

FRONT RCA AUDIO OUT SOCKET

VIDEO OUTPUT SOCKET

VIDEO OUTPUT SOCKET

IS O CONNE CTO R

AV IN

B

A

FUS E

8 6 4 2

7 5 3 1

4

5

Whit e Yello w

Red

Yello w

2

8 6 4 2

B

7 5 3 1

24

5

A

ISO CONNECTOR

1 BLACK. .... ....... .... .... ... ..GR OUND

2 RED... .... ....... .... .... ... IGNI TION (+)

4 BLUE/W HITE .....AU TO ANTE NNA

5 YEL LOW..... .... .... ..C ONSTA NT(+ )

1 GREEN/ BLAC K...... .... ......L EFT RE AR(-)

2 GREEN. .... ....... .... ....... .... LEFT R EAR (+)

3 WHITE/ BLAC K...... .... .....LE FT FRO NT(-)

4 WHITE. .... ....... .... .... ... ...L EFT FR ONT (+)

5 GRAY/BLAC K... ....... .... RIGHT FRO NT(- )

6 GRAY....... .... .... ... .... .... RIG HT FRO NT(+ )

7 VIOLET /BLA CK..... .... ....RIG HT REA R(-)

8 VIOLET.. .... ....... .... .... ... .RIG HT REA R(+ )

-8-

Remote Control

1. MODE BUTTO N

2. POWER BUTTON

3. BUTTON

4. AS/

5. >II BUTTON

6. I<< BUTTON

7. BUTTON

8. TITLE BUTT ON

9. RPT/2 BUTTON

10. DISP/1 BUTTO N

11. AUDIO/5 BUT TON S

BUTTON

12. MENU/4 BUTTO N

13. VOL - BU TTON

14. SEL BU TTON

15. MUTE BUTTON

16. BAND/ BUTTON

17. >>I BUTTO N

18. EQ BUTTON

19. RDM/3 BUTTON

20. SUB-T/6 BUTTON

21. VOL + BU TTON

-9-

Remote ControlRemote Control

Preparing the Remote Control

Inserting t he Battery

1.First push to insid e as the di recti on indi cated by the arrow (See )And then

Remove the battery ho lder as t he dire ction i ndicated by the arrow (See ).

2.Replace the battery Set a ne w batte ry prop erty with (+)side up as illustrated

(See ).

3.Insert the batter y holde r. Push in t he hold er to the original position(See ).

3

1

2

4

Using the Rem ote Control

Face the remote contr ol towa rds the p layer f ront face IR mark (remote control s ignal

receiver).

Operation angle: About 30 deg ree in ea ch the di rection of the front of the IR mark.

Note :

The lithium cell in the batter y compa rtmen t of remote control has been secured for

transport with a plastic . Bef ore ini tial us e please remove this plastic so that the

remote control is ready for op erati on .

-10-

Basic Operation

Main Menu Operation

In many modes, touch th e icon
or touch the range to ent er the
main menu, the message like fo llowi ng
as below.

10: 00 AM10: 00 AM

(1)

(2)

(4)

1. POWER icon
In any modes, touch the P OWER ic on
to switch the unit off .

2. EJECT icon
Tou ch to all ow for in serting or ejecting
disc.

3. When the unit is power on, tap to t urn
off the display and the unit still work,
tap anywhere of the dis play to t urn on
the display again.

4. SETUP icon
Tou ch to ent er the SE TTING mode,
the message will disp lay as fo llow :

Touch the “ ” section on the
setting menu, touch t he “ / ”
ranges to select the adjustm ent ite m,
Touch the “ ” icon to return to t he
previous playback .

(3)

ILLU MINATIO N COLOR

Setup interface 2

ADJUSTABLE ITEMS:

GENE RAL

ANIM ATION 2 MI NUTE

KEY BE EP ON

DISC . ..DISC . ..

RADI O ...

General se tup i nte rfa ce1

GENE RAL

BLUE TOOTH O N

WALLPA PER ...

ABOU T ...

General se tup i nte rfa ce2

ANIMATI ON

In RADIO mode, you can change th e
playing time of animation am ong of
“OFF, 10S, 30S, 1M,90S, 2 M, 3M and 4 M ”.

Note:

Please set the playing time of t he
animation to “ 10S ” for the first , when
you turn the unit on .

KEY BEE P : ON or OFF.

Disc setup as f ollow:

Setup interf ace 1

DISC

FORM AT AUTO

TV TYP E 16:9

RATIN G ADULT

-11-

Basic Operation

FORMAT

This player is capable of play ing dis cs
recorded in either PAL or NTSC for mats.
Make the selection based on wh ether
you are connecting the unit to a PAL TV
or an NTSC TV. You can also set the unit
to AUTO (a uto select). The di sadvantage
to autoselect is that e ach tim e you tur n
the unit on it checks to se e what ki nd of
monitor is connected, whic h cause s a
small delay and some flicker ing of th e
display image which you may fi nd
unpleasant.

TV TYPE

16: 9

4:3 Pan Scan

4:3 L etter B ox

This is to select the app ropri ate TV
aspect (4:3 or 16:9) ac cordi ng to the
connected TV set.

Normal/PS (For 4:3 TV )

Played back in the PAN & SCAN style.
(If connected to wide -scre en TV, the
left and right edges are cut off.)

Key in “1234” and then turn to rating
then you can setting as follow :
KID SAFE -> G -> PG -> PG-13

-> PG R -> R ->NC-17 -> ADU LT

RADIO

ST/MONO: touch to sel ect ste reo or mo no.

LOCAL: touch to selec t local o r dista nt.

REGION: touch to sele ct radi o frequ ency.

BT

Touch to select BT fu nction on or off.

WALLPAP ER

Touch to select wallpaper .

ABOUT

Touch to show the version inform ation .

CLOCK SETUP

Touch the CLOCK to adjust the time a nd
time format.

Normal/LB (For 4:3 TV )

Played back in LETTER BOX styl e.
(If connected to wide -scre en TV, black
bands appear at top and bottom o f the
screen.)

Wide (F or 16:9 T V)

Select when a wide-screen TV set is
connected.

RATING

Select to turn Parent al Cont rol on or o ff.
The factory default p asswo rd is 123 4.
(The password must be used to ma ke
changes to the Parental Cont rol
menu below .)

clock setup interface

AUDIO SETUP

Touch the audio to turn to audio qua lity
adjustment.

audio setup interface2audio setup interface1

-12-

Basic Operation

TREBLE: -7 to +7
Adjust treble level .

BASS: -7 to +7
Adjust bass level .

SUBWOOFER: touch to a djust s ubwoo fer
volume and frequency.

EQ: touch to select aud io mode a s follo w:

USER -> J AZZ -> CLASS IC -> POP -> ROCK

LOUDNESS: touch to se lect lo udnes s
effec t as :OFF -> LOW -> MID -> HIGH

FADER/BALANCE:
BALANCE: R 0-10 to L 0- 10

Adjust sound balance betwe en left
and right speakers .

FADE: F 0-10 to R 0-10
Adjust sound balance betwe en fron t
and rear speakers .

VIDEO SETUP

20

20

20

20

-Adjustable when “NTSC “ is se lecte d
for “NTSC/PAL “ .

LANGUAGE

Touch to select OSD language.

ILLUMINATION COLOR

Touch to select the backlight fo r all
buttons. Tap auto i con the backlight
change automatically.

CALIBRATION

Touch the arrow as show to calibra tion
the display.

Reset Factory Settings

RESET bu tton is p laced on the housing
and must be activated with eit her a
ballpoint pen or thin metal ob ject.
The RESET button is to be activated for
the following reasons:

A. Initial installation of t he unit w hen
all wiring is completed.
B. All the function buttons do no t opera te.
C. Error symbol on the di splay.

Video s etup interface

COLOR: 0 to 40

Adjust the color for th e pictu re-li ghter
or darker.

BRIGHTNESS: 0 to 40

Adjust if the picture i s too bri ght or
too dark.

CONTRAST: 0 to 40

Adjust the contrast o f the bri ght and
dark portion.

TINT: 0 to 40

Adjust the tint if the hu man ski n color
is unnatural.

NOTE:

If RESET is selected, all memory data
will deleted, please re-ad just .

Rear View Camera

When connecting the rear vie w camer a
the mirror image of the rear vie w is auto ­matically displayed on the m onito r
when you change the gear to the ba ck
position.
(Note: additional monito r can not d ispla y

the image.)

-13-

Control Panel

UNIT KEYS

14

4

8

6

11

6

7 109

15

16

19
1

213 5312

Control Panel

1718

Sliding Pl ate d iag ram a fte r remo ving C ontrol Panel

1. AUXILIARY INPUT JACK

Insert an external de vice to t his AUX jac k in orde r to have a udio output of the
device through the un it.

2. SEL BUTTON

Press the SEL

switch between BASS,TREB LE,BA LANCE , FADE,SWF VOL

and SWF FRE.

After switching on the d esire d mode ab ove, ro tate VOL knob to se t it.

3. VOL KNOB

In normal mode, knob is used to increase or decr ease th e volum e.

the VOL

4. /SRC BUTTON

In power off mode, press it to turn on the unit.

In power on mode, short p ress it r epeat edly to select one mode of the RADIO,
DISC, USB, CARD, BT, AUX and AV; long p to turn off the unit.ress it

-14-

Control Panel

5/6. >>| and |< < BUTTONS

In radio mode,
or up for an available st ation b eginn ing fro m the current frequency; Briefly
pressing |<< or >>| but ton can m anual ly sear ch down or up for a your desired
station beginning f rom the c urren t frequ ency.

In media mode, pressi ng |<< or > >| butt on can pl ay the previous or next track;
continuously and lo ng pres sing |< < or >>| bu tton can fast backwards or
forwards at the follo wing mu ltipl e of norm al speed: x2, x4, x8, x20.

. MUTE BUTTON

7

Press it button to swit ch of the l oudsp eakers for a short period. Th e word MU TE
flashes in the displa y. Press it again to can cel the m ute fun ction . Thi s funct ion
can also be cancelled by rotat ing the V OL multifunction button.

8-13. PRESE T STATION MEMORY AND >II, IN T, RPT, RDM BUTTON
A)In RADIO mode

Go to any preset statio n by pres sing on e of the 6p reset station(1-6) ,if one of
these buttons is pres sed for m ore tha n 2 secon ds, the stations currently bein g
listened to will be mem orize d into th e selec ted preset button.

B) In DISC/USB/SD mod e
During playing, pre ss 1/>I I butto n to paus e the current playback, press aga in to
continue play;

During playing, pre ss 2/RP T button to se lect re peat fu nctio n;

long pressing |<< or >>| butto n can aut omati cally search down

During playing, pre ss 3/RD M butto n to sele ct random function;

During DVD/VCD/CD d isc pla ying, p ress 4/ STO P button to stop play ing and t urn
to home mode, during MP 3/USB /SD mod e, pres s this button to turn to previous
mode, press again to tu rn to hom e mode;

14. REL BUTTON

Press it to detachabl e the fro nt pane l.

15.

(EJECT) BUT TON

Insert the disc, labe l side fa cing up , until t he mechanism senses its presenc e
and draws the disc in. Pr ess it to e ject th e disc.

6 USB PORT

1 .

For information about conn ectin g a USB dev ice, please see USB operation.

17.

SD CARD SLOT

18.

RESET BUTTON

Press this button to re turn to f actor y settings.

19. MICROPH ONE

-15-

Touch Screen Operation

RADIO OPERATION

Listening to Radio

Touch the RADIO ICON in hom e menu
to enter the RADIO mode . In radi o mode,
tap icon to adjust the br ightn ess for
the display .

10:00 AM10:00 AM

Briefly touch “ ” to decr ease fr equen cy
by one step of channel spacing .

Automatic Search

During Radio mode, touch and h old
(for more than 2 seconds ) eithe r “ / ”
ICONS to start search f or a radi o stati on
automatically.

To tune in strong-signal FM
Station onl y (LO/DX function)

In radio mode, LOC
remote control to select
select LOC/DX
Long-distance traffic news.

Press button on the

or tap icon

mode of Local and

Storing and Listening to a
Memory Station

Setting Mem ory

87.5087.50 101.70101.70

98.1098.10

87.5087.50

107.9107.9 100.8100 .8

Selecting T he Frequency Band

Touch the screen of “ BAND ” section
repeatedly to select the ban d , the
message will show in turn :

FM1 FM2 FM3

AM2(MW2)

AM1(MW1)

When an FM ster eo broadcast
is hard to rece ive

Press ST/MO button on t he remo te
control to select the M ONO or ST EREO
mode .

Start Searc hing For a Station

Manual Search

During Radio mode, briefly t ouch “ ”
to increase frequency by one s tep of
channel spacing.

With this system, a tot al of 30 st ation s
can be stored in the memory of six
buttons. Each band stores up t o six
preset stations. The stations might be
FM1, FM2, FM3, AM1(MW1), and
AM2(MW2) band.
The operation is as below :

- Store in Memory
>S elect t he frequency band

>S elect t he station
>Press and the statio n until i t show

the frequency band your sele ct.

- Retrieve a preset station
Touch the 1-6 ranges briefly to re triev e

a station which had been store d in the
memory in advance the chose nu mber
is shown on display .

-16-

Touch Screen Operation

Automatic Memory Storing &
Program Scanning

Automatic P reset Setup

In Radio Mode, touch and keep (f or more
than 2 ’ S) the sc reen of “ ” r ange to
active automatic st ation s torag e.
The radio searches within th e curre nt
frequency band, e.g. Fm , for the
stronger signal level unti l the sea rch cyc le
has finished . Th e six strongest stations
are then allocated to the corr espon ding
storage locations .
Then the station of the f irst st orage
location is set .

Scan Functi on

In Radio mode, briefly touch t he “ ”
section on the touch screen , th e radio
briefly plays all the preset s tatio ns of the
frequency band .

3

REG FUNCTION

at certain times some s tatio ns divi de up
their programs into region al prog rams
with varying content .
REG ON : the message “REG O N” will
appears in the display for a few s econd s .
Note :

- the display capacity is limi ted . It is
possible that in the double di splay m ode
some segments of the di splay a re dele ted .

- the function REG ON pre vents t he

radio from switching to alte rnati ve
frequency which have a different regional
program content .

REG OFF : the program ide ntifi catio n(PI)
of the regional program is ign ored du ring
the search for an alter nativ e frequ ency
(AF) or a program ident ifica tion (P I) .

RADI O

RDS PI M UTE

RDS TA OFF

RDS AF OF F

Select RDS REGIONAL to turn RDS

function on or off.

RDS FUNCTION

In home menu, then touch the “ ”
ICON to enter the set mod e, the
message in the display :

RADI O

ST/M ONO STE REO

LOCA L DX

REGI ON USA

RDS RE GIONA L ON

ADJUSTAB LE ITEMS:

REGION SET

Tou ch to swi tch the r egion area as:
EUROPE, USA, AMERICAN 1,
AMERICAN 2 and OIRT .

PI SET

Touch to change between PI MUTE an d
PI SOUND .

PI MUTE / PI SOUND

(only f or ra dio o peration)

I

f you are in an area where two progr am

identifications (PI) ove rlap, y ou can
select the option PI SO UND and
PI MUTE for playback of t he soun d.
Alternate switching of the pr ogram
identification sh ould be a voide d .

PI SOUND :

I

f switching nevert heles s occur s the

sound of another station is he ard for

less than one second .

-17-

Touch Screen Operation

PI MUTE :

the sound of another station i s
suppressed .

TA Traffic Announcement
(Priority For Traffic Information)

In Radio mode, touch the curso r butto n
to switch the TA functi on ON and O FF .
When the TA function is ac tivat ed, the
TA symbol a ppears in the display .
During radio operation in on e FM
frequency band the search fo r a traffic
announcement station is st arted
automatically (TA SEEK) .
If an FM station is being r eceiv ed whic h
transmits the lates t traffic announce­ments from time to time , the TP display
lights up.

When the TA function is sw itche d on ,
the FM traffic automatically interrupt
CD operation (the word TRAFF IC
appears in the display).

The volume level is increase d to the
minimum value for the transm issio n of
traff ic announcements.
After the traffic announcements has
finished, the program that w as
previously running is resu med.

Touch the AF s ection on touch screen or

swing and keep the SEL knob in t he
TA/AF di rection for about 2 seconds ,
the AF function is activated. The AF
symbol appears in the displa y .

When the AF function has been swi tched
on, the radio continuously t ests th e
signal strength of the AF frequ ency .
The test interval for e ach AF freq uency

depends on the signal streng th of the
current station and varies f rom a few

minutes in the case of weak sign als.
Whenever the new AF frequency i s
stronger than the sta tion th at is cur rentl y
tuned in , the radio switched to t his
frequency for a short time for a s hort
time and the message
“NEW FREQUENCY “ is displayed for
one or two seconds.

PTY FUNCTION

In Radio mode, touch screen of “ PTY”
range to select the Pro gram ty pe .

PTY Sel ection of the program type
besides the stations name, s ome FM
stations also trans mit inf ormat ion on th e
type of program. This information can
be displayed by your car radio .

Interruption of the TA Fu nctio n:

If you would like to interrupt t he curr ent
traff ic announcement, touch the TA
section on screen briefly . This does
switch off the TA mode .

AF FUNCTION

(Alternative Frequenci es)

In Radio mode, touch the curso r butto n
to switch the AF functio n ON and OF F .

AF is a function that wor ks with t he help
of RDS (Radio Data System) and c an
only be used with FM stations. The radio
searches in the background f or the be st
frequency reception of the s tatio n that
has been tuned into .

Examples of such type s of prog ram are :

SPORT NEWS POP WEATHE R ..... .

With PTY function you can specifically
select stations tra nsmit ting a pa rticu lar
type of program. Touch the PTY on s creen
repeatedly to call up the PTY selection
menu. Th e messa ge “PTY SEEK ” then
appears briefly in the displ ay .
When PTY has been selected the radio
start searching for c orres pondi ng PTY
information and stops when t he PTY
information has been found , “NO PTY ”
appears in the display. If the PTY
information being search ed for no l onger
exists, the PTY function automatical ly
switches to normal mo de .

-18-

Touch Screen Operation

Media Operation

In audio play mode, the message will
display as below :

Mute function

To select the Equalizer mode

Fast forward

Fast backward

Intro Function

To decrease the volume level

To increase the volume level

Loudness Function

Subwoofer Function

Tur ning pr e-swi tchin g for tra ffi c
announcements on and off

To skip the next track

To skip the previous track

Repeat Function

Random Function

Previous menu

Tap to turn to BT PHONE mode.

(afte r pairing an d connecti ng a
mobil e phone with B T function ).

In audio play mode, tap icon to
adjust the brightness for th e displ ay .

The icons for other mod e

(The same icon have the same function
in each mode)

In PHOTO playing ,tap to change
the photo direction.

ZOOM IN and OUT.

For page turning.

For page turning.

For page turning.

For page turning.

For page turning.

Switching on and off an
Alternative frequency

Play/Pause the playing

-19-

Touch Screen Operation

BASIC OPERATION

Pause (stil l picture)

Touch the “ ” section on touc h
screen during playback wil l stop
play temporary, touch it again to
return the normal playback .

Rapid Forwa rd/Rapid Reverse

During DISC playback, touc h the
screen of “ / ” range the
speed of rapid forward/rev erse
changes according to the dis c as
follow:

Digital Video/VCD/CD/MP3:

Normal P lay back 2 x 4x 8x 2 0x

Skipping Tra ck

During DISC playback, Touch the
/ section on the touch sc reen
to skip to next/back on e track .

Note :

For some VCD2.0 disc (P BC-pl aybac k
control), above these butt ons may b e
unavailable .

Zoom Functi on

Touch the button repeatedly,
the displayshow as “zoom 2,

zoom 3, zoom 4 , zoo m ½,
zoom 1/3, zoom 1 /4 , zoom off . ”

Use the keys ( / / / on
remote control to move the enl arged
picture .

SELECTING PLAY MODES

During the Disc playback, se lect th e
“RPT, RDM ” to select your fa vour
play mode.

1). REPEAT FUNCTION

FOR Digital Video :
Tap the icon or press the RPT button
on the remote control to selec t REPEAT
mode as follows :

CHAPTE R REPEAT ON TI TLE R EPEAT ON

REP EAT OFF

FOR VCD/CD :
Tap the icon or press the RPT button
on the remote control to selec t REPEAT
mode as follows :

REPEAT ONE REPEAT ALL

FOR MP3 :
Tap the icon or press the RPT button
on the remote control) to sele ct REPE AT
mode as follows :

REP EAT ONE R EPEAT FO LDER(or DI R)

REP EAT OFF

2). RDM(RAN DOM) FUNCTION

During DISC playback, touc h scree n
of “ ” section ( press the
RDM button on the remote contr ol to
play in random. Each play mode t he
order is different . (Depend on the
disc used for VCD).
Touch it again to cancel this func tion .
Note : in random mode, th e butto n
is not available .

REP EAT ALL

REPEAT OFF

REP EAT ALL

-20-

Touch Screen Operation

ON-SCREEN D ISPLAY FUNCTION

screen or press the DIS P on the
remote control, it wi ll disp lay
the following as belo w :

Note: touch the scree n or pres s the DIS P
on the remote control again to c ancel
the OSD information .

1. Digital Video , when it is on, it will
display the informa tion su ch as:

2. Example for VCD/SV CD, whe n it is on,
it will display the informat ion suc h as:

3. Example for Movie or P HOTO .
When it is on, it will disp lay the
information such as :

During playback, touch the

OS D

T 001/ 004

C 001/ 001

the screen will display the fo llowi ng
message :

Touch to select the adjus tment
item, then select the i tem you r favou r
by touching the numberic but tons ,
then touch the OK to conf irm .

FOR VCD (With PBC OFF) :
Touch the screen as show:

the screen will display the fo llowi ng
message :

Touch to select the adjus tment
item, then select the i tem you r favou r
by touching the numberic but tons ,
then touch the OK to conf irm .

For Movie/Photo:
Touch the screen as show :

DISC Search (GOTO)

FOR Digital Video :
Touch the screen as show :

the screen will display the fo llowi ng
message :

Touch to select the adjus tment
item, then select the i tem you r favou r
by touching the numberic but tons ,
then touch the OK to conf irm .

-21-

Touch Screen Operation

Digital Video Special Function

1. Multi-su btitle Language
Function (f or Digital Video Only)

During Digital Video playback.
Touch the icon on touch
screen(or press the S UBT on
the remote) .

Each time the button is p resse d or touc h,
number of the subtitl e langu age cha nges
in sequential order.

Notes:

- The lan guage number is different
according to the disc .

- Some discs only contain one su btitl e
language.

- When no different subtitle language
are recorded, “ INVALID KEY ” will be
displayed at screen left top c orner.

2. Multi-Au dio Language Functio n

D

I

O

U

For Digital Video:

A

During Digital Video playback ,

on the remote .) Each tim e the but ton is
pressed or touch , number of the a udio
soundtrack language chan ges on
sequential order.

Notes:

- The lan guage number is different
according to the disc .

- Some disc only contain one lan guage
soundtrack

- When no different language soundtra­ ck are recorded will be
display at screen left top cor ner.

touch the icon on touch
screen (or press the LA NG

“ INVALID KEY ”

For VCD/CD:

during playback, touch the A UDIO
section of the touch sc reen or P ress
AUDIO on the remote . It is p ossib le to
switch the sound between mon aural
and stereo sound.

MON O LEF T MONO R IGHT

STE REO

MIX -MO NO

3. Multi-An gle Function
(for Digita l Video Only)

During Digital Video playback, touch the
icon on the touch scree n .

Each time the button is p resse d , the
number of the angel changes in s equen ­tial order .

Notes:

- The ang le number is differ ent
according to the disc .

- The fun ction only work for disc having
scenes recorded at di fferent angles.

- When no different angle are recorded,
wil l be disp layed a t

“ INVALID KEY ”

screen left top corne r.

4. Title Menu Function

For Digital Video:

If the Digital Video has multiple titles
recorded on the disc. It can sel ect
preferred title fro m the tit le menu t o start
playback.

- During Digital Video playback, press

TITLE button on the rem ote .Th e title
menu is display.

- Select preferred ti tle by th e curso r
button and confirme d by pres s the
ENTER button .

For VCD:

Press TITLE/PBC but ton on th e remot e
control while the disc is play ing, yo u can
switch between "PBC ON"and " PBC off"
mode.

-22-

Touch Screen Operation

1. Pairing and Connec ting
Prior to using the BT device named Boss Audio BV7464 B as a hand s-fre e

system for a BT-enabl ed mobi le phon e for the f irst time, you must
connect them

Press the BT hands-free icon or press the
pair button on the remo te cont rol to tu rn to
BT stan dby mode as right:

as follows:

pair and

* During the use of the BT de vice na med Bos s Au dio BV7 464B” as a hands-free
system for a BT- enable d mobil e phone ;Swit ch on the BT mod e of your m obile

phone; then s BT devi ce and enter it;
of the A/V system, the name will be

BT devi ce car Boss Audio BV7464B
displayed
a password, input 000 0 and ent er it; th en i with the BT
device Boss Audio BV74 64B of th e car A/V sys tem, Co nfirm i t,then the frame

of the BT lo go will l ight all the time.

When connect , the au dio of th e mobil e phone t ransfers

* f inishing pairing and ing

to the car audio system w henev er a call i s made or r eceived

or the mobile phone
plays music

2. BT PHONE

In power off mode, a incoming call or call out to wake up t his uni t and tur n to BT
hands-free mode, when the ph one cal l ended t he unit back to power off mode.

1) Make a call

(1) Dial with mobile phone dir ectly ;

Dial with BT Phone, remote contro l, or on touch screen;

(2)

a. Touch th e HANDSFREE icon in home menu or touch the ico n durin g playi ng
to turn to BT PHONE interface as follows:

elect the item to find a When it finds the

, select it and enter it; t hen it wi ll show a n inter face that asks to input

.

“

t will pair and connect

: Same as MUTE button.

& : Same as VOL+ and V OL- or
VOL knob.

: Tap t o do disc onnection.

-23-

Touch Screen Operation

b. Use the number icons or butto ns to inp ut your d esired phone number;

* When inputting a wrong digit , use ico n or < button to delete it.

c. After finishing in putti ng, tou ch icon or press button on control panel
to dial out.

2) Redial last dialed p hone nu mber

Touch icon or long press re dial bu tton on r emote c ontrol to dial out the last
dialed phone number.

3) Answer a call

During an incoming call, the i ncomi ng tele phone number displays in the the BT
PHONE interface. If y ou want t o recei ve it, touch icon or press button
on remote control; if y ou want t o rejec t it, touch icon or press button
on remote control.

4) Ending a call

When ending a call, tou ch icon o r use but ton.

5) Switch the audio bet ween th e unit an d your device

During phone BT hand s-free system of the car A/V system,
touch icon or press but ton on re mote co ntrol to switch the audio
between the unit and yo ur devi ce.

talking using the

Adj ustin g the vol ume during a call

6)

talking, use VOL knob or VO L+ and VO L-

During phone + and - icon or

buttons to adjust vol ume lev el .

; use icon or MUTE button t o mute so und

* * / # icons and buttons

they perform as * / # butto ns on mob ile pho ne.

.

3 BT MUSIC

)

1 Touch ST REAMING in home menu or pressing SOURCE bu tton ca n pop up BT
MUSIC interface as fo llows :

USE R SWFUSE R SWF

USE R SWFUSE R SWF

BT

BT

BT

BT

MUS IC

MUS IC

MUS IC

MUS IC

-24-

Touch Screen Operation

Mute function

To select the Equalizer mode

To decrease the volume level

To increase the volume level

Loudness Function

Subwoofer Function

Tur ning pr e-swi tchin g for traffi c annou ncements on and off

Switching on and off an Alternative frequency

Play/Pause the playing

To skip the next track

To skip the previous track

Tap to turn t o BT PH ONE mod e.(after p airing and c onnectin g a mobile pho ne

with BT func tion).

In BT mus ic mode, tap icon to adjust the brigh tness f or the di splay .

2 When the play ,

) using your mobile phone with BT function to audio/video if it

is paired and connected to the u nit,

the audio of the mobile phone wi ll chan ge
into .

The Boss Audio BV7464B suppor ts A2DP, which enables t he user t o strea m

audio from their devi ce.

3 he T device of supports AVRCP,

BT Musi c interface except BT Music and their buttons on control
panel or on remote cont rol are a vaila ble for a udio/video playback of your mobile
phone during playback. But n for / icon and
/ buttons, and the func tion of r esume p layback after pausing or stopping
is available only for some mob ile pho ne

the car A/V system

) T B the c ar A/V system so t hese ic ons on the

corresponding

o fast forward/back ward fu nctio ns

.

-25-

Touch Screen Operation

AUX Operation

On the front panel of thi s unit, t here is a n
AUX IN jack, follow the d iagra m below t o
connect analogue replay de vices (only
for the Audio connect, if you want to
connect the Video, please plug the
<Vide o input > on the back of the unit .) .
Use this jack to replay sound of o ther
replay equipment such as Dig ital Video
players, computers, etc. Via the loud­speakers.

1). Please connect the exter nal dev ice
with stereo jack (3.5mm)pl ug the Aux i n
socket .

AUX IN JACK FRONT PANEL

AUX IN

AUX IN

AUX INTERFACE 1

AUX INTERFACE 2

Gro und

Rig ht

Lef t

2). In radio mode, touc h the scr een
of “ ” ICON to enter the main m enu,
touch the “ AUX ” ICON to ente r the
AUX IN mode.

In AUX mode, tap to adjust t he
brightness for the display .

10:00 AM10:0 0 AM

3). You now hear the sound from the
external device played bac k throu gh
the loudspeakers .

The function of the ico ns as fol low:

Tap t o mute th e sound .

Tap t o selec t EQ as the same on the
remote control.

Tap t o turn LO UD on or off.

Tap t o selec t subwo ofer frequency.

Tap t o adjus t audio volume.

Tur ning pr e-swi tchin g for traffi c
announcements on an d off

Switching on and off an
Alternative frequency

Tap to turn to BT PHONE mode.
(afte r pairing an d connecti ng a mobile

phone w ith BT function ).

-26-

Touch Screen Operation

AV Operation

Please plug the <Video input >
on the back of the unit .

Touch the AV IN ic on to ent er the AV IN
mode.

In AV mode, t ap icon to adjust the
brightness for the display .

10:00 AM10:0 0 AM

As the interface show, h ere is on ly the
audio output, now tap the icon ,
the picture of the auxi liary i nput vi deo
show on the display and tap the di splay
again to turn to audio mode.

Now you can watch the video from y our
External video equipment s uch as
Digital Video players, computers, etc.

Tap t o mute th e sound .

Tap t o selec t EQ as the same on the
remote control.

Tap t o turn LO UD on or off.

Tap t o selec t subwo ofer frequency.

Tap t o adjus t audio volume.

Tur ning pr e-swi tchin g for traffi c
announcements on an d off

Switching on and off an
Alternative frequency

Tap to turn to BT PHONE mode.
(afte r pairing an d connecti ng a mobile

phone w ith BT function ).

AV INTER FACE 1

AV INTER FACE 2

Note: To ens ure saf ety while driving and
to comply with lows, dr ivers s hould
not watch video or oper ate the
video device while dr iving .

-27-

Touch Screen Operation

USB OPERATION

Following the diagram belo w, conne ct
your USB device to the fr ont pan el
USB port . If it is properl y conne cted,
the device will be mounted and s tart
playing automatically.

U

SB

10:00 AM10:0 0 AM

5

Card OPERATION

The unit can support playbac k MP3/W MA/
JPEG/MP4 format whi ch are st ored on
SD memory cards .
Please read the following in struc tions
before you start usin g a memor y card .
Inserting the card as follow :

Lab el side
fac ing upw ard

Insert a card, push in till heard
a “CLICK”, then attach the
control panel again to play.

10:00 AM10:0 0 AM

10:00 AM10:0 0 AM

5

10: 00AM

SON G

1

2 3 4

001

00200 2

003

004

005

1 Current type (highl ighte d bar) .

2 Audio play mode select.

3 Picture play mode sel ect.

4 Movie play mode select,

5 Current play track .

10: 00AM

WED DING MOV 03247 .MPG

1

CIM G3080 .MOV

2 3 4

1 Current type (highl ighte d bar) .

2 Audio play mode select.

3 Picture play mode sel ect.

4 Movie play mode select,

5 Current play track .

-28-

Touch Screen Operation

STEERING WHEEL CONTROL

Touch the SWC icon as follow to turn t o
steering wheel control .

10:00 AM10:0 0 AM

10:00A M

During setting, touch the ic on to
turn to home menu.

Before operation, press th e icon
to cancel the original input t hat to
set your favour.

Tou ch this i con to cancel the
input and resume load .

When electric resis tance i s too
low, touch this icon to in creas e.

When electric resis tance i s too
high, touch this icon t o reduc e.

There are 2 KEY for total 12 buttons to
save, first, tap Assig n to open f uncti on
save, then select button 1 in KE Y 1 on
steering wheel and tap the ico n, the
icon show in button 1 position t hen tou ch
Confirm, final exit the SWC mo de ,
the function will sav e in butt on 1 of
KEY 1.

The function of the ico ns as fol low:

Tou ch to beg in function save.

After selection touc h to conf irm
operation.

-29-

Parental Control

* Parental Control

Q: After inserting a Dig ital Video disc into the dis c slot,

and asks you to input a password , what sh ould yo u do

?

A: The pl aying disc is locked by a rating level of pare ntal co ntrol . If the current

rating level of paren tal con trol of t he Digi tal Video pl ayer is l ower than the one
of current disc, you mu st inpu t the cor rect password of parental control to
unlock the parental c ontro l and ent er a rati ng level one

of the current disc in order to pl ay the di sc.

* For factory preset pa sswor d of pare ntal co ntrol of Digital Vi deo player,

see the .

part of Media Setup Menu

Appendix: Parenta l Contr ol

Parental Control fu nctio n of a Digi tal Video pl ayer ca n contr ol playback of

movie ratings on a disc . You can set t he Digi tal Video pl ayer to b e a certa in
rating level of paren tal con trol us ing the M edia Setup Menu. If the rating level
of parental control o f a disc is h igher t han the o ne of the Digital Vid eo player,
the Digital Video player cannot play the disc.

The Dig ital Video m ovie ca n be designed so that the Digital Video player can
play different versions of content of a pa rticu lar mov ie acco rding to the differ ent
rating levels of pare ntal co ntrol . Depen ding on igital Video , the
scenes that are not sui table f or chil dren wi ll be cleared or replaced by suitable
scenes automatica lly.

if a dialogue box pops up

equal to or higher than

please

the D features

The rat ing levels of Parental Control are as foll ows:

Unlock
1 Kid Safe
2 G
3 PG
4 PG 13
5 PG R
6 R
7 NC 17
8 Adult

-30-

Region Code

* Regio n Code

If you insert a disc into t he disc s lot and R EGION E RROR is displayed, the car
multi-media syste m can not p lay the d isc. The rea son is th at the re gion codes
of the car multi-medi a syste m and the u sed dis c do not match each other.

Appen dix: Regio n code of D

Motio n Picture Ass ociation o f Am erica (MPAA) div ided the wor ld into 6 regions, and
gave ev ery region a r egion code f or locking a nd unlocki ng D play back.

Basic ally, a coded D playe r can play onl y the discs if i ts region co de is the
same D player. Ot herwise, i t cannot pla y the disc.

as the co de of the igital Video

Pleas e

impos e this restr iction. igital
Video igital Video -

The proble ms caused by a rea code inc onsisten cy produ ction of
unloc ked versio n D playe rs and recod able D players .

Regio n codes and th e countrie s or areas rep resented b y region codes are as follows :

Regio n 1: America, C anada, Eas t-Pacifi c Inlands;
Regio n 2: Japan, West Eu rope, Nort h Europe, Eg ypt, South Africa, Middle Ea st;
Regio n 3: Taiwan, H ong Kong, So uth Korea,
Thailand , indonesi a, etc.;
Regio n 4: Australi a, New Zeala nd, Centra l South Ameri ca, South Pacific Inlands ;
Regio n 5: Russia, M ongolia, I ndian Peni nsula, Mid dle Asia, East Europe, North
Korea , North Afric a, North-w est Asia etc.;
Regio n 6: China mai nland.

The 8 bigges t film making compan ies of Americ a are as follo ws:

note th at only the D discs and D players produced by

the 8 big gest film- making com panies of Ame rica The D

discs a nd D p layers not produced by the 8 bi ggest film maki ng
compa nies of Ameri ca are not res tricted by t he rule of reg ion code. Generally, they
are cal led Free Reg ion Code or Fu ll Region Co de.

South -east Asian c ountries i nclude

igital Video

igital Video igital Video

-

igital Video

igital Video

igital Video igital Video

has mot ivated the

1. Wa rnerBros ;

2. Colu mbia;

3. 20th CenturyF OX;

4. Para mount;

5. Univ ersal;

6. UA(U nitedArt ist);

7. MGM( MetroDog wynMayer );

8. Wa ltDisney

-31-

Specification

Specification

General

Power Supply Requi rement...... ............ ............................. ...DC 12V

Current consumpt ion......... ............................. ............ ......10A MAX.

Maximum Power Outpu t.... ............ ............................. ........... 4 x 80 W

Audio

Signal Output................ ..... ...........Fron t, Rear, and Subwoofer Outpu t

Frequency Respon se.... ..... .................. ..... ...................20 Hz - 20 KHz

S/N Ratio ..... ..... .................. ..... ....................... ..... ..............90 dB (JIS)

Wow and Flutter. ....................... ..... ............... Below measurab le limits

TFT Monitor

Monitor Screen Siz e.... ....................... ..... .................. ....4 .6 Inch W ide

Color System............ ..... .................. ..... ....................... ..... .NTSC/PAL

Disc/US B/Card

Compatible Forma t...............Digital Video/VCD/IMAGE/MP3/WMA/CD

Radio
FM

Frequency range. ............................. .......EUR (87 .5 MHz - 108 Mhz)

USA (87.5 MHz - 1 07.9MHz)
American 1 (87.5 MHz - 108MHz)
American 2 (87.5 MHz - 108MHz)
OIRT(88.1 MHz - 107.9MH z)

Usable sensitivi ty......... ............ ............................. ............ ...15dBu

I.F Frequ ency.. ............................. ............ ........................10.7 MHz

AM(MW)

Frequency.... ............................. ............ ..EUR (522 KHz - 1620 Khz)

USA (530 KHz - 17 10 Khz)
American 1(530 KHz - 1710 Khz)
American 2(520 KHz - 1600 Khz)
OITR (531 KHz - 1602 Khz)

Usable sensitivi ty......... ............ ............................. ............ ...40dBu

I.F Frequ ency.. ............................. ............ .........................450 Khz

BT:

BT specif ication....................... ..... .................. ..... ...........V1.2 Class 2

BT Supported Pro files.......... ... HSP, HFP and A2DP & AVRCP pr ofiles

Range of frequency..... .................. ..... .................. ...2.4G Hz Spectrum

NOTE:

Specification an d design are subject to modif ication, without notice ,
due to improvement s in technology.

-32-

Troubleshooting

Before going through the che ck list , check w iring connection. If any of the problems
persist after check l ist has b een mad e, cons ult your nearest service dealer.

SYMPTOM CAUSE SOLUTION

If the power supply is properl y
connected to the car accesso ry
terminal,switch the igni tion ke y
to "ACC"

Replace the fuse

Remove the disc in the player,
then put a new one

Insert the compact di sc with
the label facing upward

Clean the disc or try to pl ay a
new one

Cool off or until the ambient
temperature return to norm al

Please switch to correct col or
system from menu

Make proper connection
according to wire connection “ ”

For safety reasons no v ideo/
images are displayed while t he
vehicle is moving.
Engaging the parking brake w ill
cause images to be displayed .

Please choose a proper color

system.

Change the disc

Change the disc Record JPEG
files using a compliant
application

Press the RESET button.
Front panel is not properly fi xed
into its place

Insert the antenna ca ble fir mly

Select a station manually

No power

Disc can not be
loaded or ejected

Video /image
appears
black-white

No video/image
appears

No color in picture

JPEG disc can
not be played
back

Unit has become
unresponsive

The radio does not
work

The car ignition switch is
not on

The fuse is blown

Presence of disc inside the
player.

Inserting the disc in revers e
direction

The disc is extremely dirty
or defective

Temperature inside the car
is too high

The color system is
set incorrectly

The unit is not connected
to the parking brake
detection switch

The parking brake is not
engaged

The dis c format is not
according to the TV-set
used (PAL /NTSC )

No JPEG files are recorded
on the disc.

JPEG files are not reco rded
in a compliant format

Unit has frozen up

The antenna cable is not
connected

The signals are too weak

Made in China

BV7464B

-33-
