Boss Audio 825CA User Manual

10 R - 02 1397

1. BUTTONS LOCATION AND FUNCTIONS

9 6

15 16

1. Panel ReleaseButton

2. Power /Mute Button

3. CD EjectButton

4. Audio Button

5. Display Button/ ID3 InformationButton

6. Local /Distant Button

7. Preset MemoryButtons

8. iX-BassButton

9. Source Button

10. Volume Knob

11. AutomaticallyStore / PresetScan Button

12. Band/LoudnessButton / MP3Enter Button

13. TuningUp/Down &Track Up / DownButtons

14. RemoteControl Receiver

15. PresetEqualizer Button

16. AuxIn Jack

1. Entriegel-Taste Bedienteil

2. Stumm-Taste /Einschalt-Taste

3. CD-Auswurftaste

4. Audio-Taste

5. Display-/ID3-Taste

6. Local/ Distant-Taste

7. Senderspeichertasten

iX-Bass-Taste

9. Source-Taste

10. Lautstärkenregler

11. AMSTaste /MP3 Suchlauf Taste

12. Frequenzband-Taste /MP3 Eingabe-Taste

13.TitelAUF/AB-Taste

14. Fernbedienungs-Taste

15. PEQ-Taste

16. Front-Audio-Anschluss

13 7 11 5

1.Teclapara removero painelfrontal

2.TeclaLigar/desligar &TeclaMute

3.Teclapara ejetaro disco

4.Teclade ajustede audio

5.TeclaDisplay /informação MP3-iD3

6.TeclaLocal/Distante

7.Teclasde memóriade estações

FunçãoIX-BASS

9.TeclaSource

10.Controle devolume

11.Memorização automática(As) /PresetScan (Ps)

12.TeclaBanda /Loudness /MP3Enter

13.Teclasde sintonizaçãode estações/

14.TeclaEqualizador pré-programado

15.Sensor docontrole remoto

16.Entrada Auxiliar

1. Extraccióndel panel frontal

2. Silenciamientorápido / Encendido/Apagado

3. Aperturadel panel motorizadoy expulsióndel disco

4. Tecla Audio

5. Seleccióninformación Display/ID3 TAGmuestra

6. BotónDistancia/Local

7. Botonesde estaciones memorizadas

8. BotóniX-Bass

9. Selecciónmodos Radio/CD/Entrada auxiliar

10. BotónDe Volumen

11. MemorizaciónAutomática de emisoras / selecciónde memorias

12. SelectorBandas / Bajos/MP3

13. Botónde selección deemisoras &banda de música

14. Receptorde control remoto

15. Tecla de ecualización

16. Entradade auxiliar

mudançade faixasde música

1. BoutonDe DéclenchementDu Panneau

2. BoutonD'assourdissement /Bouton D'alimentation

3. BoutonÉjection D'unCd

4. BoutonDe SélectionAudio /Entrée DeMP3

5. BoutonD'écran /Affichage D'informationSur LesDisques MP3

6. BoutonLocal/distant

7. BoutonsDes StationsPréréglées (m1~m6)

BoutonDeiX-Bass

9. BoutonDe Régime

10.BoutonDeVolume

11.BoutonDeStockageDesStationsDansLa Mémoire

12.BoutonDeBande /Entrée DeMP3

13.BoutonDeRechercheDesStations/pistes:EnAvant/EnArrière

14.RécepteurDeLaCommandeÀDistance

15.BoutonDePEQ

16.AuxAJack

1. Tasto Rilascio Frontalino

2. Tasto Mute /Tasto Power

3. Tasto Eject

4. AudioControlla

5. Tasto Display/ID3 (informazioni)

6. BottoneDistante Locale

7. Tasti Stazioni MemoriePreimpostate

Bottone Bassi

9. Tasto Mode

10. Tasto Volume

11. Tasto Menu &AS/PS

12. Tasto Banda/Forte & EnterMP3

13. Tasto sintonizzazione su/gui& traccia su/gui

14. Destinatariodi controllo remoto

15. Bottonedi equilizzatore preprogrammato

16. EntradaAux

This radio is equipped with the most advanced "TOUCH SENSE PANEL", so that it is easy and convenient to use while driving.

Here are some tips to show you how easy it is to use this touch sense panel:

Tips

Using a very light touch on the radio panel will activate that feature. You will not need to "PRESS" hard onthe panelto make thisradio change features.

The power button along with some of the buttons that have dual functions, will need to be "TOUCHED" from 2to 3 secondsto makethe change.

The best areato "TOUCH"on the panelto make itactivate isthe illuminated orlighted area.For example, just touchfor 2to 3 secondsthe illuminatedpower symbol and the unitwill turn on or off.

2. HANDLING COMPACT DISCS

MOISTURE CONDENSATION

On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit. Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for about an houruntil the moisturehas evaporated.

NOTES ON CDs

A dirty or defective disc may cause sound dropouts while playing. To enjoy optimum sound, handle the disc as follows. Handle the disc by its edge. To keep the disc clean, do not touch the surface (P.1).

P. 1

Do not stickpaper or tapeon thedisc (P.2).

P. 2

Do not expose the discs to direct sunlight or

heat sources such as hot air-ducts, or leave them in a car parked in direct sunlight where there can be a considerable rise in temperature inside the car (P.3).

Before playing, clean the discs with an

optional cleaning cloth. Wipe each disc from the centre out (P.4).

Do not use solvents such as benzine,

thinner,commercially available cleaners, or antistatic spray intended for analog discs.

P. 3

P. 4

NOTES ON DISCS

If you use the discs explained below, the sticky residue can cause the CD to stop spinning and may cause malfunction or ruin your discs.

Do not use second-hand or rental CDs that have a sticky residue on the surface (for example, from peeled-off stickers or from ink, or glue leaking from under the stickers).

There are paste residue. Inkissticky(P.5).

P. 5

Do not use rental CDs with old labels that are beginning to peel off.

Stickers that are beginning to peel away, leaving a sticky residue (P.6).

P. 6

Do not use your CDs with labels or stickers attached.

Labels are attached (P.7).

P. 7

Do Not Use Special Shape CDs

Be sure to use round shape CDs only for this unit and do not use any special shape CDs. Use of special shape CDs may cause the unit to malfunction.(P.8).

P. 8

Be sure to use CDs with disc mark CD-Rs and CD-RWs which have not

undergone finalization processing cannot be played. (For more information on finalization processing, refer to the manual for your CD-R/CD-RW writing software or CD-R/CD-RW recorder.) Additionally, depending on the recording status, it may prove impossible to play certain CDs record on CD-R or CD-RW.

****

*******

**************

*******

E - 1

3. INSTALLATION

Before finally installingthe unit,connect the wiringtemporarily and make sureit isall connected up properly andthe unit andsystem workproperly. Use onlythe parts included withthe unit to ensureproper installation. The useof unauthorized parts can causemalfunctions. Consult with your nearest dealer if installation requires the drilling of holes or other modifications of thevehicle. Install the unitwhere it doesnot getin the driver'sway and cannotinjure the passenger ifthere is a sudden stop,like an emergencystop. If installation angle exceeds 30° from horizontal, the unit might not give its optimum performance.

Avoid installing the unit where it would be subject to high temperature, such as from direct sunlight, or from hot air, from heater, or where it would be subject to dust dirt or excessive vibration. Be sure toremove the frontpanel beforeinstalling the unit.

DIN FRONT/REAR-MOUNT

This unit canbe property installedeither from“Front”(conventional DINFront-mount) or“Rear”(DIN Rear-mount installation, utilizing threaded screw holesat thesides ofthe unit chassis). For details, refer to thefollowing illustrated installationmethods Aand B.

DIN FRONT-MOUNT (Method A)

Installation the unit

182

30°

1. Dashboard

2. Holder After inserting the half sleeve into the dashboard, select the appropriate tab according to the thickness of the dashboard material and bend them inwards to secure the holder in place.

3. Screw

1. Dashboard

2. Nut (5mm)

3. Spring washer

4. Screw (4x12mm)

5. Screw

6. Support Strap

Be sure to use the support strap to secure

the back of the unit in place. The strap can be bent by hand to the desired angle.

7. Plain washer

E - 2

Removing the unit

a. Frame b. Insert fingers into the groove in the

front of frame and pull out to remove the frame. (When re-attaching the

Trim Plate Installation:

Push the trim plate against the chassis until it is fitted. You must do this before you install the front panel, otherwise it can't be attached.

DIN REAR-MOUNT (METHOD B)

Installation using thescrew holes onthe sidesof the unit. Fasteningthe unitto the factoryradio mounting bracket.

frame, point the side with a groove down wards and attach it.)

c. Insert the levers supplied with the

unit into the grooves at both sides of the unit as shown in figure until they click. Pulling the levers makes it possible to remove the unit from the dashboard.

1. Select a position where the screw holes of the bracket and the screw holes of the main unit become aligned (are fitted) and tighten the screws at 2 places on each side.

2. Screw

3. Factory radiomounting bracket.

4. Dashboard orConsole

5. Hook (Removethis part)

Note: the mounting box, outer trim ring, and half-sleeve are not used for method B installation.

E - 3
