Bosch WTW84560GB User Manual

1 2 3 4 5

6

The programme has ended when \ lights up in the display panel.

Interrupt programme to load/unload laundry.

The drying operation can be interrupted briefly to load or unload laundry. The programme selected
must then be resumed and completed.

Never switch the dryer off before
the drying process has ended.

1. Open door, the drying process is interrupted.

2. Load or remove laundry and close door.

3. If required, select a new programme and additional functions.

4. Press the  Start/Stop button.

Emptying condensation

Empty container after each drying operation, and not when drying is in
progress!

1. Pull out condensation container keeping it horizontal.

2. Pour out condensation.

3. Always push container in fully until it clicks into place.

If ā flashes in the display panel -> Page 6/10.

Cleaning the fluff filter

Clean the fluff filter after each drying operation.

1. Open the door, then pull out and fold open the fluff filter.

2. Remove the fluff (by wiping the filter with your hand).

If the fluff filter is very dirty or blocked, rinse with warm water and dry
thoroughly.

3. Close and reinsert the fluff filter.

4. Remove fluff from door/door area.

Switching off the dryer

Turn the programme selector to Off.
Do not leave laundry in the dryer.

Removing the laundry

Your dryer is equipped with an automatic anti-crease function. The drum is moved at specific time intervals
for 30 minutes once the programme has ended. The laundry stays loose and fluffy (60 or 120 minutes if

the additional Reduced Ironing c function is selected).

... and adapt to individual requirements

Never start the dryer if it is damaged!
Inform your after-sales service.

Inspecting the

dryer

Sorting and loading laundry

Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.

Your new dryer

Congratulations - You have chosen a modern, high-quality Bosch
domestic appliance.

The condensation dryer with heat exchanger and automatic cleaning
function is outstanding in terms of efficient energy consumption and
low maintenance requirements.

Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased
to help.

Disposal in an environmentally-responsible manner

Dispose of packaging in an environmentally-responsible manner.
This appliance is labelled in accordance with the European

guideline

2002/96/EC on waste electrical and electronic

equipment - WEEE.
The guideline provides an EU-wide framework for the return and

recycling of old appliances.

Intended use

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋSetting the programmes . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5

ʋMaintenance and cleaning . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8

ʋFrost protection/transport . . . . . . . . . . . . 8

ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . . . 9

ʋWhat to do if... . . . . . . . . . . . . . . . . . . . .10

ʋSafety instructions . . . . . . . . . . . . . . . . 11

Preparing for installation, see Page 8

Selecting and adjusting the programme

Additional

functions

Drying

Condensation container

with filter

Control panel

ʋfor domestic use only,

ʋonly to be used for drying fabrics that have been

washed with water.

Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.

Care and cleaning

Heat exchanger

The heat exchanger of the dryer is cleaned automatically when drying is in progress,
Cln appears in the display panel. Do not pull the condensation container out during the
cleaning process.

Dryer housing, control panel, air inlet

– Wipe off with a soft, damp cloth.
– Do not use caustic cleaning agents and solvents.
– Remove detergent and cleaning agent residue immediately.
– Water may occasionally accumulate between the window and the seal.

This does not impair the functions of your dryer in any way.

Filter in condensation container

The filter is cleaned automatically when the condensation container is emptied. Cleaning is

only required if the symbol ā flashes again in the display panel once the condensation

container has been emptied.

1. Pull out the condensation container.

2. Twist the filter to release it from the catch.

3. Clean the filter under a continuously-running stream of water.

4. Insert the filter and turn it until the limit stop is reached.

5. Slide in the condensation container until it clicks into place.

Only operate the dryer with the filter inserted!

Moisture sensors

The dryer is equipped with stainless steel moisture sensors. Moisture sensors measure the
moisture level of the laundry. After sustained, repeated operation, a fine layer of scale may
form on the moisture sensors.

1. Open the door.

2. Clean the moisture sensors with a damp scouring sponge.

.
Do not use steel wool or or abrasive materials!

Select the drying programme ...

Press the Start/Stop button

1

2

3

Make sure your hands are dry.
Hold the plug only.

Connecting the

mains plug

Drying

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

(cDrying at normal temperature.

'cDrying at low temperature -> also select  Low Heat.

)cDo not machine dry.

Observe safety instructions without fail -> Page 11!
Do not tumble-dry the following fabrics for example:
– Impermeable fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk or curtains made from synthetic material) -> they may crease
– Laundry contaminated with oil.

Drying tips

– To ensure a consistent result, sort the laundry by fabric type and drying programme.
– Always dry very small items (e.g. baby socks) together with large items of laundry (e.g.

hand towel).
– Fold up large items of laundry (bed sheets) before drying.
– Close zips, hooks and eyelets, and button up covers.

Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-care laundry -> risk of creasing!

Allow laundry to finish drying in the air.
– Do not dry woolens in the dryer, only use to freshen them up -> Page 7, Woollens Finish

Programme.

– Do not iron laundry immediately after drying, fold items up and leave for a while -> the

remaining moisture will then be distributed evenly.
– Machine-knitted fabrics (e.g. T-shirts or jerseys) often shrink the first time they are dried ->

do not use the Extra Dry programme.
– Starched laundry is not always suitable for dryers -> starch leaves behind a coating that

adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the manufacturer's instructions when

washing the laundry to be dried.
– Use the timer programme for small loads -> this improves the drying result.

Environmental protection/energy-saving tips

– Before drying, spin the laundry thoroughly in the washing machine -> the higher the spin

speed the shorter the drying time will be (consumes less energy), also spin easy-care

laundry.
– Put in, but do not exceed, the maximum recommended quantity of laundry ->

programme overview -> Page 7.
– Make sure the room is well ventilated during drying.
– Do obstruct or seal up the air inlet.

Only when switched off!

Drum

Display panel

Programme selector

All buttons are sensitive and only
need to be touched lightly.

Do not pull out/empty the condensation container
when drying is in progress!

Only operate the dryer with
the fluff filter inserted!

Air inlet

Fluff filter

Display of max.
loading capacity for
programme selected

Drum interior light

See programme overview -> Page 7

Reduces creasing and extends the anti-creasing phase once the

program has ended; two settings available.

ˎReduced

Ironing cc

Reduced temperature for delicate fabrics ' that require a longer drying

time; e.g. for polyacrylics, polyamide, elastane or acetate.

ˎLow Heat 

Programme sequence displays:

drying, iron dry, cupboard dry, slackening/ready.

Status indicators

Ic+c\

Clean fluff filter.

Empty the condensation container.

Service displays

Fluff filter 4

Container ā

ˎMenu For selecting the settings.

ˎ-/+ (Change) To change all settings in the display panel.

 Electronic start

timer

End of the programme following... (depending on the programme selected,
e.g. duration 1:54h -> 2h; the nearest whole hour is always selected).

1 -24 hrs

3Signal Signal volume selectable in four stages: 0 (off), 1 (quiet), 2 (normal), 3 (loud). 0, 1, 2, 3

# Appliance lock Protection against accidental adjustment of functions that have been set (hold menu button down for

5 seconds).

On-Off

9 Degree of dryness Fine adjustment of degree of dryness, selectable in four stages for Cottons, Easy-Care, Mix and Super

Quick 40: 0 (low) - 3 (very high).

0, 1, 2, 3

 Spin speed Speed at which the washing machine was spun;

only used if the anticipated drying time needs to be displayed more accurately.

600­1800

7

Programme overview also see Page 5

After drying: laundry is to be ...

T-shirt

Shirts

Trousers

Skirts/dresses

Sportswear

Work clothing

Anoraks

Towelling

dressing gowns

Underwear

Socks

Bed linen

Table linen

Terry towels

Tea towels/

towels

cironed

 lightly ironed dry

@cnot ironed

cpassed through a mangle

 Cottons

max. 7 kg

For whites and coloureds/cotton or linen.

Iron Dry  ø@

è**è*è*è*è*è*è*è*

Cupboard Dry @

***è*è*è**è*è*

Very Dry @

*è*è*è**è*è*

Extra Dry @

è*è*è**

 Easy-Care

max. 3.5 kg For non-iron laundry made of synthetic fibres and blended fabric, cotton.

Iron Dry cø@c

*è*è*è*è*è*è**

Cupboard Dry @*è*è*****

Very Dry @è*è*è*

! MIx

max. 3 kg

For mixed items of laundry made of cotton and easy-care fabrics.

Cupboard Dry/Iron Dry

 Freshen up

max. 3 kg

For cotton or linen fabrics that are still damp and easy-care fabrics. Creasing in fabrics is reduced. Fabrics are not dried

completely. Hang up fabrics!

$ Sportswear

max. 1.5 kg

For fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with

removable internal lining separately).

Woollens

Finish

max. 3 kg

For woollen fabrics suitable for machine-washing. Fabrics become fluffier but not dry.

Remove fabrics once the programme has ended and allow to dry.

Super Quick 40 

max. 2 kg

For laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may

differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric

and loading capacity.

 Timed Programme warm

max. 3 kg

For pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.Also for subsequent

drying.

 Timed Programme cold

max. 3 kg

For all types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.

Further information: http://www.bosch-hausgeraete.de

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

D-81739 Munich/Germany

WTW84560GB

0509 en

9000 415833

8

Installation

– Delivery specification: dryer, instructions for installation and use.
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g. the door) as they may break off.
– Do not set up in a room that is susceptible to frost.

Freezing water may cause damage.

– If in doubt, have the appliance connected by an expert.

Setting up the dryer

– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level

and solid surface.

– Keep the cooling grille at the front of the dryer

unobstructed.
– Keep the area around the dryer clean.
– Make the dryer level using the threaded feet

and a spirit level.
– Do not unscrew the threaded feet further than 20 mm.

Do not remove the threaded feet under any

circumstances.

Mains connection see safety instructions -> Page 11.

– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.
– The mains voltage and the voltage shown on the rating plate (-> Page 9) must correspond.
– The connected load and necessary fuse protection are specified on the rating plate.

Frost protection

Preparation

1. Empty the condensation container -> Page 4.

2. Turn the programme selector to any programme.

3. Press the Start/Stop button -> condensation is pumped into the container.

4. Wait 5 mins., empty the condensation container again.

5. Turn the programme selector to Off.

Transport

– Preparation of dryer -> see Frost protection.
– Transport the dryer in a vertical upright position.
– Following transportation, leave the dryer to stand for one hour.

The dryer contains residual water;
this can flow out if the dryer is tilted.

1.

Take all accessory parts
out of the drum.
The drum must be empty.

Make sure that the air

inlet remains unobstructed

Clean and level

2.

Do not operate the dryer if
there is a danger of frost.

Do not set up the dryer behind a door or sliding
door as this may obstruct or prevent the dryer door
from opening. This will prevent a potentially fatal
danger to children from locking themselves in.

9

Technical data

ʠ

Dimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)

Weight approximately 53 kg
Max. capacity 7 kg
Condensation container 4.0 l
Connection voltage 220-240 V
Connected load max. 1500 W
Fuse protection 10 A
Ambient temperature 5 - 35 °C
Product number/

Production number

Inside of door

You can find the rating plate on the back of the dryer.

ʠ

Consumption rates

These are guide values determined under standard
conditions.

Spin speed in rpm
(residual moisture)

Drying time**

in min.

Energy

consumption**

in kWh

 Cottons 7 kg

Cupboard Dry* 1400 (approx. 50 %) 106 1.61

1000 (approx. 60 %) 124 1.90

800 (approx. 70 %) 143 2.19

Iron Dry* 1400 (approx. 50 %) 73 1.11

1000 (approx. 60 %) 91 1.40

800 (approx. 70 %) 110 1.70

 Easy-Care 3.5 kg

Cupboard Dry* 800 (approx. 40 %) 48 0.64

600 (approx. 50 %) 59 0.79

*Test program according to DIN EN 61121
**The values may differ from the those specified depending on the type of fabric, mixture of

laundry to be dried, residual moisture in the fabric and loading capacity.

ʠ

Drum interior light (bulb E14, 15 W)

The drum is illuminated after the door is opened or closed, and also after the programme is
started. It goes out automatically. Replacing the bulb -> Page 10.

Optional accessories

Order no.:

Washer-dryer stack connection set

The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space.
This connection set must always be used to secure the dryer to the washing machine.

Same as WTZ 11310, but with pull-out worktop.

Installation underneath the worktop

Risk of electric shock!

Instead of the appliance covering plate, you must have a metal cover fitted by an expert.

Platform

Facilitates loading and unloading the appliance.
The basket contained in the drawer can be used to carry the laundry.

WTZ
11310

WTZ
11300

WTZ
10290

WMZ
20460

10

What to do if ...

Repairs must only be carried out by the aftersales service or an authorised expert.
Before you contact the after-sales service, please make sure that you are unable to resolve

the problem yourself. You will be charged for advice if a technician is called out, even during
the warranty period. You can find your nearest customer services in the enclosed list. When
contacting the after-sales service, please specify the product number (E-Nr.) and production
number (FD) of your appliance (see inside of door).

ʠ

The Start/Stop indicator lamp
does not light up.

Mains plug plugged in?
Programme selected?
Check the socket fuse.

ʠ

The ā symbol and Start/Stop

indicator lamp flash.

Empty the condensation container.
Clean the condensation container filter if necessary ->Page 6.

ʠ

The 4 symbol and Start/Stop

indicator lamp flash.

Clean the fluff filter -> Page 4.

ʠ

Dryer does not start. Start/Stop button selected?

Door closed?
Programme set?
Ambient temperature greater than 5 °C?

ʠ

Water is leaking out. Make sure the dryer is level.

ʠ

The door opens by itself. Push the door closed until you hear it engage.

ʠ

The required degree of
dryness was not achieved or
the drying time was too long.

Clean the fluff filter -> Page 4.
Empty condensation container -> Page 4.
Ambient temperature higher than 35 °C -> airing.
Air inlet may be blocked -> keep unobstructed.
Was an unsuitable programme selected? -> Page 7.
Laundry too dry? The laundry in a dryer with a heat

exchanger requires sufficient residual moisture.
Has the dryer been installed with sufficient space on all

sides? Ensure that air can circulate.
Mains failure -> Restart the dryer.
Fine layer of scale on the moisture sensors -> Clean the

moisture sensors -> page 6.

ʠ

Laundry damp. Use the next drying programme up or use the timer

programme as a supplement -> Page 7.
Warm laundry feels damper than it really is!

ʠ

The moisture content of the room
has increased significantly.

Make sure the room is sufficiently ventilated.
Air inlet blocked? -> keep unobstructed.

ʠ

Cln appears in the display
panel.

Not an error! Automatic cleaning of heat exchanger.
Do not empty the condensation container.

ʠ

Mains failure. Remove laundry from the dryer immediately and spread out.

This allows the heat to dissipate.

ʠThe interior light is not working. Pull out the appliance plug, remove the cover cap in the

interior above the door (use Torx 20 screw driver) and
replace the bulb. Close the cover cap.
Never operate the dryer without a cover cap.

ʠ

Other intermittent noises and
vibrations.

Not an error!
Automatic cleaning of the heat exchanger.

ʠ

Loud humming noise for
several seconds.

Has the condensation container been properly reinserted?

-> slide the condensation container in fully.

ʠ

If you cannot rectify a fault yourself or a repair is necessary:
– Turn the programme selector to Off.
– Remove the appliance plug from the socket.
– Call the after-sales service -> see the after-sales service directory.

11

Safety instructions

Emergency

– Pull the appliance plug out of the socket immediately or disconnect the fuse.

ONLY use the
dryer...

– In rooms inside the house.
– To dry fabrics.

The dryer must
NEVER...

– Be used for other purposes than those described above.
– Be modified in terms of its technology or attributes.

Dangers

– The dryer must not be used by children or persons who have not been

instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets.

Make especially sure that cigarette lighters are removed as they constitute an

-> explosion hazard.

– Do not lean or sit on the door -> risk of tipping.

Installation

– Secure loose cables -> tripping hazard.
– Do not operate the dryer if there is a risk of frost.

Mains
connection

– Connect the dryer according to specifications to an AC earthed socket, as

otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.

– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not hold the appliance plug with wet hands -> risk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead -> risk of electric shock.

Operation

– Only load the drum with laundry.

Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,

grease or paint (e.g. hair setting spray, nail polish remover, stain remover,

cleaning solvent, etc.) -> fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer

->explosion hazard.

– Do not put laundry containing foamed material/rubber in the dryer -> elastic

material may be destroyed and the dryer may be damaged due to possible

deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with fluff.

Defect

– Do not use the dryer if it is defective or if you suspect it is.

Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only

have the defective mains cable replaced by the after-sales service.
– Always pull the mains plug out of the socket before changing the bulb for the

interior light -> risk of electric shock.

Spare parts

– Only use genuine spare parts and accessories for safety reasons.

Disposal

– Dryer: pull out the appliance plug, then cut off the mains cable from the

appliance.

Dispose of at municipal waste disposal facility.
– Packaging: do not leave children alone with packing parts

-> risk of suffocation.

– The heat exchanger contains coolant -> Dispose of it in the proper manner.
– All materials are environmentally sound and can be reused. Dispose of in an

environmentally-responsible manner.

Instructions for
installation and use

Tumble dryer

Read these instructions before operating the dryer.

en

Observe the safety instructions on page 11.

1 2

... and adapt to individual requirements

Never start the dryer if it is damaged!
Inform your after-sales service.

Inspecting the

Sorting and loading laundry

Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.

Your new dryer

Congratulations - You have chosen a modern, high-quality Bosch
domestic appliance.

The condensation dryer with heat exchanger and automatic cleaning
function is outstanding in terms of efficient energy consumption and
low maintenance requirements.

Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased
to help.

Disposal in an environmentally-responsible manner

Dispose of packaging in an environmentally-responsible manner.
This appliance is labelled in accordance with the European

guideline 2002/96/EC on waste electrical and electronic

equipment - WEEE.
The guideline provides an EU-wide framework for the return and

recycling of old appliances.

Intended use

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋSetting the programmes . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5

ʋMaintenance and cleaning . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8

ʋFrost protection/transport . . . . . . . . . . . . 8

ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . . . 9

ʋWhat to do if... . . . . . . . . . . . . . . . . . . . .10

ʋSafety instructions . . . . . . . . . . . . . . . . 11

Preparing for installation, see Page 8

Selecting and adjusting the programme

Additional

functions

ʋfor domestic use only,

ʋonly to be used for drying fabrics that have been

washed with water.

Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.

Select the drying programme ...

Press the Start/Stop button

Make sure your hands are dry.
Hold the plug only.

Connecting the

Display panel

Programme selector

All buttons are sensitive and only
need to be touched lightly.

Only operate the dryer with
the fluff filter inserted!

Display of max.
loading capacity for
programme selected

See programme overview -> Page 7

Reduces creasing and extends the anti-creasing phase once the

program has ended; two settings available.

ˎReduced

Ironing cc

Reduced temperature for delicate fabrics ' that require a longer drying

time; e.g. for polyacrylics, polyamide, elastane or acetate.

ˎLow Heat 

Programme sequence displays:

drying, iron dry, cupboard dry, slackening/ready.

Status indicators

Ic+c\

Clean fluff filter.

Empty the condensation container.

Service displays

Fluff filter 4

Container ā

ˎMenu For selecting the settings.

ˎ-/+ (Change) To change all settings in the display panel.

 Electronic start

timer

End of the programme following... (depending on the programme selected,
e.g. duration 1:54h -> 2h; the nearest whole hour is always selected).

3Signal Signal volume selectable in four stages: 0 (off), 1 (quiet), 2 (normal), 3 (loud).

# Appliance lock Protection against accidental adjustment of functions that have been set (hold menu button down for

5 seconds).

9 Degree of dryness Fine adjustment of degree of dryness, selectable in four stages for Cottons, Easy-Care, Mix

Quick 40: 0 (low) - 3 (very high).

 Spin speed Speed at which the washing machine was spun;

only used if the anticipated drying time needs to be displayed more accurately.
