Bosch VDN-5085-V321 Specsheet

960H

Video | FLEXIDOME AN outdoor 5000

FLEXIDOME AN outdoor 5000

www.boschsecurity.com

u Ultra high resolution 960H sensor

u High Dynamic Range to see bright and dark details

simultaneously

The FLEXIDOME 5000 camera is the ultimate solution
for virtually any indoor or outdoor surveillance
application. This vandal-resistant dome camera uses a
high performance 960H 1/3-inch CCD sensor with a
resolution of 720TVL. The sensor, the high dynamic
range engine and the advanced image processing
technology combine to provide a detailed image with
outstanding accuracy in color reproduction even under
harsh lighting conditions. True day/night performance
ensures the highest image quality possible at any time,
day or night. The camera is easy to install and ready to
use, and offers the best solution for demanding scene
conditions.

System overview

The cast-aluminum housing, polycarbonate dome, and
hardened inner liner can withstand the equivalent of
55 kg (120 lbs) of force. The enclosure contains the
full-featured camera and integral varifocal lens. Ideal
for outdoor use, the cameras are protected against
water and dust to IP66 and NEMA Type 4X standards.
The camera enclosure provides the extra protection
necessary for applications such as schools, banks,
prisons, parking garages, retail and industrial
buildings.

u High impact, vandal-resistant, weatherproof housing

u Bilinx communication for remote set-up and control

u Easy to install

Installation is quick and easy, as the camera comes
completely assembled and ready to use. Using the
proprietary pan/tilt/rotation mechanism, installers can
select the exact field of view. Mounting options are
numerous, including surface, 4S (USA), wall, corner
and suspended ceiling. The compact, sleek design and
virtually flush-mount appearance complements any
decor.
The camera is supplied ready to operate. Six distinct
pre-programmed operational modes are stored in the
camera. Recall the mode that suits your application for
optimized performance.

Functions

Detail in extreme lighting

In harsh lighting, the difference between the brightest
and the darkest parts of a scene can be extreme. To
produce a clear picture in these conditions, the CCD
sensor in the camera generates two images; one long
exposure to resolve details in the scene’s darkest
areas, and one short exposure to resolve details in the
scene’s brightest areas. The advanced image
processing technology in the camera combines these
dual shutter images, mixing pixels from each exposure

2 | FLEXIDOME AN outdoor 5000

to produce the most detailed image possible. The
superior wide dynamic range for all lighting conditions
reveals details previously unseen.

Day/Night mode

The day/night mode provides enhanced night viewing
by increasing the IR sensitivity. The IR filter can switch
from color to monochrome automatically by either
sensing the illumination level or via the alarm input.
The filter can be switched manually via the alarm
input, through the camera menu or via the Bilinx
coaxial control interface. An internal through-the-lens
IR detector enhances the monochrome mode stability,
as it prevents reverting to the color mode when IR
illumination is dominant. IR contrast is also measured
and used to handle reflected IR light in outdoor
scenes.

Ease of installation

The lens wizard helps focus the lens at the maximum
opening to ensure proper back-focus is maintained
throughout the 24-hour cycle. No special tools or
filters are required.
Six independent, pre-programmed operating modes
support typical applications, but are fully
programmable for individual situations. Switching
between modes is easy via Bilinx or the external alarm
input.
Several other features are available that make
installation easy:

• Video BNC and power connectors on flying leads.

• A built-in test pattern generator produces signals to
test and fault-find cables.

• A multi-language On-Screen Display (OSD).

• A high efficiency power supply improves maximum
operating temperature

Cable compensation is used to avoid the need for
amplifiers in long distance coaxial connections up to
1000 m (3000 ft). It can prevent the image quality
degradation caused by signal losses from long cable
lengths.

Bilinx technology

Bilinx is a bidirectional communication capability
embedded in the video signal of this camera. Installers
can check status, change camera settings and even
update firmware from virtually anywhere along the
video cable. Bilinx reduces service and installation
time, provides for more accurate set-up and
adjustment, and improves overall performance. In
addition, Bilinx uses the standard video cable to
transmit alarm and status messages, providing
superior performance without additional installation
steps.

Ideal picture performance

There are many settings available to help fine-tune the
picture performance to match your installation
environment. These include:

• Smart BLC – automatically and dynamically
compensates for strong backlight

• Peak White Invert – reduces glare from highlight
areas

• Contrast and sharpness – enhance details in bright or
misty scenes

• SensUp – sensitivity is dramatically enhanced by a
factor of 10

• Default shutter – improves the motion performance in
auto exposure mode

• Dynamic noise reduction – dynamically reduces noise
in the picture

Privacy masking

Fifteen different privacy zones allow specific parts of a
scene to be blocked. Pre-program any part of the
scene to be masked.

Video Motion Detection

The built-in video motion detector allows you to select
four programmable areas with sensitivity thresholds.
When motion is detected, alarms can be displayed in
the video signal or an alarm message can be
transmitted via Bilinx.

Lens Options

With this dome camera, there is no compromise
between scene coverage and aesthetics of the camera.
The camera brings the widest choice of lens selection.
Choose lenses between 2.8 to 10.5 mm for wide
coverage, 9 to 22 mm VF lens for standard coverage,
or 18 to 50 mm for long-rang coverage.

Typical applications

• Entrance foyer/lobby with glass

• Warehouses and loading bays

• Prisons and correctional facilities

• Airport locations including:

– baggage handling
– fuel and equipment storage

• Stadium

Certifications and approvals

Electro Magnetic Compatibility

Emission EN 55022 class B, FCC part 15 class B,

EN61000-3-2, EN61000-3-3
EN50121-4

Immunity EN 50130-4, EN 50121-4

Vibration IEC 60068-2-6

Safety

EN60950-1, UL60950-1 (2ND edition), CSA C22.2 No. 60950-1-07
(2ND edition)

Region Certification

Europe CE

USA UL

FCC

Canada CSA

158

6.22

39.5

1.56

85

3.35

95

3.7

130.5

5.14

158

6.22

14

0.55

32

1.26

23.6

0.93

15

0.59

VDA-455UTP

Video Transceive r

205 (8.07)

mm (in)

247 (9.71)

46 (1.81)

83 (3.27)

Ø133 (5.24)

Ø4.8 (0.19)

Ø158 (6.23)

113 (4.43)

113 (4.43)

3 | FLEXIDOME AN outdoor 5000

Installation/configuration notes

FLEXIDOME 5000 model overview

Model Standard Lens

VDN-5085-V311 PAL 2.8 to 10.5 mm F1.2

VDN-5085-V321 NTSC 2.8 to 10.5 mm F1.2

VDN-5085-V911 PAL 9 to 22 mm F1.4

VDN-5085-V921 NTSC 9 to 22 mm F1.4

VDN-5085-VA11 PAL 18 to 50 mm F1.5

VDN-5085-VA21 NTSC 18 to 50 mm F1.5

Flush Mounting

Accessories (not included)

BNC to UTP Transceiver

Dimensions in mm (in.)

VDA-WMT-DOME –Pendant Wall Mount

Dimensions in mm (in.)

VDA-455SMB–Surface Mount Box

Dimensions in mm (in.) for surface mounting

656 (25.82) mm (in)

Ø158 (6.23)

88 (3.47)

88 (3.47)

Ø11 (0.43)

90°

90 (3.54)

81 (3.21)

mm (in)

25 (0.98)

107 (4.19)

146 (5.75)

180 (7.09)

3-3/4"NPT

M8 Thread

Typ 4 Places

6-32 Thread

Typ 4 Places

139.1
(5.48)

53.3

(2.10)

66.5

(2.62)

(1.81)

49.4

(1.95)

49.4

45.8

(1.95)

(6.00)

82.9

(3.27)

152.4

38.4

(1.51)

Hole

mm
(in.)

4 | FLEXIDOME AN outdoor 5000

VDA-PMT-DOME –Pendant Pipe Mount

VDA-CMT-DOME –Corner Mount

VDN-5085-V321,

12 VDC / 24 VAC 60 Hz
VDN-5085-V921,
VDN-5085-VA21

Power Consumption 360 mA (12 VDC), 700 mA with heater on

330 mA (24 VAC), 650 mA with heater on

Image Sensor 960H, 1/3" DS CCD, sensor resolution

720TVL, WDR dual shutter

System PAL or NTSC

Total pixels (H x V) 1020 x 596 (PAL)

1020 x 508 (NTSC)

Effective pixels (H x V) 976 x 582 (PAL)

976 x 494 (NTSC)

Sensitivity Lens 2.8 to 10.5 mm (3200K, scene reflectivity 89%,
transmission 68%, F1.2)”

Full video

(100 IRE)

Color 0.7 lx

(0.0651 fc)

Color
+ SensUp 10x

0.07 lx
(0.00651 fc

Usable picture
(50 IRE)

0.13 lx
(0.0121 fc)

0.013 lx
(0.00121 fc)

Usable picture
(30 IRE)

0.06 lx
(0.00558 fc)

0.006 lx
(0.000558 fc)

)

LTC 9213/01 Pole Mount Adapter

Technical specifications

Electrical

Model No. Rated Voltage Rated Frequency

VDN-5085-V311,
VDN-5085-V911,
VDN-5085-VA11

12 VDC / 24 VAC 50 Hz

Monochrome 0.3 lx

(0.0279 fc)

Monochrome
SensUp 10x

0.03 lx
(0.00279 fc

0.06 lx
(0.00558 fc)

0.006 lx
(0.000558 fc)

0.03 lx
(0.00279 fc)

0.003 lx
(0.000279 fc)

)

Sensitivity Lens 9 to 22 mm (3200K, scene reflectivity 89%,
transmission 68%, F1.4)”

Full video

(100 IRE)

Color 1 lx

(0.0930 fc)

Color
+ SensUp 10x

0.1 lx
(0.00930 fc

Usable picture
(50 IRE)

0.17 lx
(0.0158 fc)

0.017 lx
(0.00158 fc)

Usable picture
(30 IRE)

0.08 lx
(0.00744 fc)

0.008 lx
(0.000744 fc)

)

Monochrome 0.4 lx

(0.0372 fc)

Monochrome
SensUp 10x

0.04 lx
(0.00372 fc

0.08 lx
(0.00744 fc)

0.008 lx
(0.000744 fc)

0.04 lx
(0.00372 fc)

0.004 lx
(0.000372 fc)

)

Sensitivity Lens 18 to 50 mm (3200K, scene reflectivity 89%,
transmission 68%, F1.5)”

Full video

(100 IRE)

Color 1.1 lx

(0.102 fc)

Color
+ SensUp 10x

0.11 lx
(0.0102 fc)

Usable picture
(50 IRE)

0.2 lx
(0.0186 fc)

0.02 lx
(0.00186 fc)

Usable picture
(30 IRE)

0.09 lx
(0.00836 fc)

0.009 lx
(0.000836 fc)

5 | FLEXIDOME AN outdoor 5000

Monochrome 0.5 lx

Monochrome
SensUp 10x

Signal-to-Noise Ratio >54 dB

Video Output Composite video 1 Vpp, 75 ohm

Synchronization Internal, Line Lock

Shutter Auto (1/50 [1/60] to 1/100000)

Sensitivity Up Adjustable from Off up to 10x

Day/Night Color, Mono, Auto

Dynamic Engine XF-Dynamic, HDR, Smart BLC

Dynamic Range 94 dB (WDR)

Dynamic Noise
Reduction

AGC AGC On or Off (0 – 40 dB) selectable

Smart BLC On/Off

Peak White Invert On/Off

White Balance ATW Indoor, ATW Outdoor, ATW hold and

Contrast Enhancement Low, Medium, High

Sharpness Sharpness enhancement level selectable

Alarm Output VMD or Bilinx

Cable Compensation Up to 1000 m (3000 ft) coax without

Camera ID 17 character editable string, position

Test Pattern Generator Color bar, Raster, Impulse, Cross Impulse,

Modes 6 preset programmable modes

Remote Control Bilinx coaxial bi-directional

Video Motion Detection 4 areas, fully programmable

Privacy Masking 15 independent areas, fully programmable

E-Zoom Up to 16x

Digital Image Stabilizer On/Off

Controls OSD with soft-key operation

OSD Language English, French, German, Spanish,

(0.0465 fc)

0.05 lx
(0.00465 fc
)

0.09 lx
(0.00836 fc)

0.009 lx
(0.000836 fc)

selectable, fixed, flickerless, default

2D-NR, 3D-NR

Manual

external amplifiers (automatic set-up in
combination with Bilinx coaxial
communication)

selectable

Cross hatch,

communication

Portuguese, Simplified Chinese, Russian

0.05 lx
(0.00465 fc)

0.005 lx
(0.000465 fc)

Optical

Varifocal Manual zoom and focus adjustment

Iris control Automatic iris control

Viewing angle

2.8 to 10.5 mm Wide 101.8 x 73.7º (H x V)

Tele 27.4º x 20.6º (H x V)

9 to 22 mm Wide: 32.1º x 23.3º (H x V)

Tele: 13.1º x 9.8º (H x V )

18 to 50 mm Wide: 14.6º x 10.9º (H x V)

Tele: 5.6º x 4.2º (H x V )

Mechanical

Dimensions See drawings

Weight 750 g (1.65 lb)

Mounting Flush on hollow surface with three (3)

Color White (RAL9010) trim ring with black inner

Adjustment range 360º pan, 90º tilt, ±90º azimuth

Dome bubble Polycarbonate, clear with UV blocking anti-

Trim ring Aluminum

screws in a 4S electrical box

liner

scratch coating

Environmental

Operating temperature
default (with heater off)

Operating temperature
(with heater on)

Storage temperature -55 ºC to +70 ºC (-67 ºF to +158 ºF)

Operating humidity 5% to 93% relative humidity

Storage humidity Up to 98% relative humidity

Impact protection IEC 60068-2-75 test Eh, 50 J

EN 50102, exceeding IK 10

Water/dust protection IP66 and NEMA Type‑4X

-30 ºC to +55 ºC (-22 ºF to +131 ºF)

-50 ºC to +55 ºC (-58 ºF to +131 ºF)

Ordering information

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 2.8 to 10.5 mm lens; 50 Hz; PAL

Order number VDN-5085-V311

6 | FLEXIDOME AN outdoor 5000

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 2.8 to 10.5 mm lens; 60 Hz; NTSC

Order number VDN-5085-V321

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 9 to 22 mm lens; 50 Hz; PAL

Order number VDN-5085-V911

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 9 to 22 mm lens; 60 Hz; NTSC

Order number VDN-5085-V921

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 18 to 55 mm lens; 50 Hz; PAL

Order number VDN-5085-VA11

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 18 to 55 mm lens; 60 Hz; NTSC

Order number VDN-5085-VA21

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 2.8 to 10.5 mm lens; surface mount;
50 Hz; PAL

Order number VDN-5085-V311S

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 2.8 to 10.5 mm lens; surface mount;
60 Hz; NTSC

Order number VDN-5085-V321S

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 9 to 22 mm lens; surface mount; 50 Hz;
PAL

Order number VDN-5085-V911S

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 9 to 22 mm lens; surface mount; 60 Hz;
NTSC

Order number VDN-5085-V921S

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 18 to 50 mm lens; surface mount;
50 Hz; PAL

Order number VDN-5085-VA11S

FLEXIDOME AN outdoor 5000

960H analog outdoor WDR dome camera. IP66; IK10;
12VDC/24VAC; true day/night; 720 TVL; 3-axis
adjustment; 4-zone motion detect; 15-zone privacy
mask; varifocal 18 to 50 mm lens; surface mount;
60 Hz; NTSC

Order number VDN-5085-VA21S

Accessories

VDA‑455SMB

High impact surface mount box for dome cameras

Order number VDA-455SMB

VDA‑455UTP

Adaptor for UTP twisted pair output

Order number VDA-455UTP

S1460 Service/Monitor Cable

2.5 mm jack to BNC video connector cable. 1 m

Order number S1460

VDA-WMT-DOME Wall Pendant Mount Bracket

Wall pendant mount bracket for FlexiDome cameras

Order number VDA-WMT-DOME

VDA-CMT-DOME Corner Mount Bracket

Corner mount bracket for FlexiDome cameras

Order number VDA-CMT-DOME

VDA-PMT-DOME Pendant Pipe Mount Bracket

Pendant pipe mount bracket for FlexiDome cameras

Order number VDA-PMT-DOME

LTC 9213/01 Pole Mount Adapter

Flexible pole mount adapter for camera mounts. Max.
9 kg (20 lb); 3 to 15 inch diameter pole; stainless steel
straps

Order number LTC 9213/01

UPA-2420-50 Power Supply

Power supply for cameras. 220 VAC, 50 Hz In; 24 VAC,
20 VA Out

Order number UPA-2420-50

7 | FLEXIDOME AN outdoor 5000

Represented by:

Americas: Europe, Middle East, Africa: Asia-Pacific: China: America Latina:

Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.us

Bosch Security Systems B.V.
P.O. Box 80002
5617 BA Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: [phone]
[e-mail]
www.boschsecurity.com

Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.asia

Bosch (Shanghai) Security Systems Ltd.
201 Building, No. 333 Fuquan Road
North IBP
Changning District, Shanghai
200335 China
Phone [phone]
Fax: [phone]
www.boschsecurity.com.cn

Robert Bosch Ltda Security Systems Division
Via Anhanguera, Km 98
CEP 13065-900
Campinas, Sao Paulo, Brazil
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.com

© Bosch Security Systems 2014 | Data subject to change without notice
10382714251 | en, V7, 29. Apr 2014

UPA-2430-60 Power Supply

Power supply for camera. 120 VAC, 60 Hz; 24 VAC,
30 VA Out

Order number UPA-2430-60

UPA-2450-50 Power Supply, 220 V, 50 Hz

Indoor power supply for camera. 220 VAC, 50 Hz In;
24 VAC, 50 VA Out

Order number UPA-2450-50

UPA-2450-60 Power Supply, 120 V, 60 Hz

Indoor power supply for camera. 120 VAC, 60 Hz In;
24 VAC, 50 VA Out

Order number UPA-2450-60

VDA-455TBL Tinted bubble

Tinted bubble for FlexiDome series

Order number VDA-455TBL

VDA-455CBL Clear bubble

Clear Bubble for FlexiDome series

Order number VDA-455CBL

EX12LED‑3BD‑8M Infrared Illuminator

Mini IR 850 nm illuminator. LED array; 3D Diffuser;
black; 17 m HFOV; 30º beam pattern

Order number EX12LED-3BD-8M

EX12LED‑3BD‑8W Infrared Illuminator

Mini IR 850 nm illuminator. LED array; 3D Diffuser;
black; 16 m HFOV; 60º beam pattern

Order number EX12LED-3BD-8W

EX12LED‑3BD‑9M Infrared Illuminator

Mini IR 940 nm illuminator. LED array; 3D Diffuser;
black; 17 m HFOV; 30º beam pattern

Order number EX12LED-3BD-9M

EX12LED‑3BD‑9W Infrared Illuminator

Mini IR 940 nm illuminator. LED array; 3D Diffuser;
black; 16 m HFOV; 60º beam pattern

Order number EX12LED-3BD-9W

TC8235GIT Ground Loop Isolation Transformer

Order number TC8235GIT

Software Options

VP‑CFGSFT Configuration Software

Configuration software for cameras using Bilinx. VP­USB adaptor

Order number VP-CFGSFT
