Bosch PKF375FP1E Product spec sheet

Dual rings, tough and easy-to-clean glass
surfaces and good looks make ceramic
hobs a smart addition to your home.

●

DirectSelect: Direct, simple selection of the desired cooking
zone, power and additional functions.

●

The 18 cm cooking zone - extendable cooking zone.

●

ComfortProfil: Elegant, appealing design with bevelled front
and metal strips on the side.

●

30 cm width: suitable for combining with other Domino and
ComfortProfile hobs.

●

PowerBoost: selectable boost in power output for a 20%
shorter time to boiling.

Technical Data

Product name/family : Vario/Domino cooking zone cera
Construction type : Built-in
Energy input : Electric
Total number of positions that can be used at the same time : 2
Required niche size for installation (HxWxD) : 38 x x
Width of the appliance : 306
Dimensions : 38 x 306 x 527
Dimensions of the packed product (HxWxD) (mm) :

120 x 375 x 590
Net weight (kg) : 4.806
Gross weight (kg) : 5.5
Basic surface material : Ceramic
Color of surface : Alu, brushed, Black
Approval certificates : AENOR, CE
Length of electrical supply cord (cm) : 100
EAN code : 4242002938141
Electrical connection rating (W) : 3500
Current (A) : 16
Voltage (V) : 220-240
Frequency (Hz) : 60; 50

'!2E20AC-jdibeb!

Serie | 6, Domino electric hob, 30 cm,
Black
PKF375FP1E

Optional accessories

HEZ394301 : Connecting strip
HEZ9LP160 : Pot Ø 14 (bottom) / 16 cm (top)
HEZ9LP200 : Pot Ø 18 (bottom) / 20 cm (top)

1/4

Serie | 6, Domino electric hob, 30 cm, Black
PKF375FP1E

Dual rings, tough and easy-to-clean glass
surfaces and good looks make ceramic hobs
a smart addition to your home.

Design

306 mm

-

Profile trim (front facette with side trim)

-

Special features

2 zone Quick-Therm hob

-

Standard zone, Dual-circuit cooking zone

-

DirectSelect touch control

-

Variable 17-stage power settings for each zone

-

Digital display, red

-

Timer for all zones

-

Timer - shows how long the cooktop is in use

-

ReStart function

-

Safety Features

Main on/off switch

-

Power on indicator light

-

2 stage residual heat indicator for each zone

-

Control panel lock

-

Automatic safety shut off

-

Individual energy consumption display

-

Power and size

Connected load: 3.5 KW

-

Cooking zones

-

front: Ø 180 mm, 120 mm, 2 KW, 1 KW (max. power level 2.3
KW);
rear: Ø 145 mm, 1.2 KW;

Quickness

PowerBoost function

-

Technical information

Appliance dimensions: (W/D) 306 mm x 527 mm

-

Installation dimensions: (ID/W/D) 38 mm x 270 mm x 490 mm

-

Min. worktop thickness: 16 mm

-

Total connected load: 3500 W

-

2/4

Serie | 6, Domino electric hob, 30 cm, Black
PKF375FP1E

3/4

Serie | 6, Domino electric hob, 30 cm, Black
PKF375FP1E

4/4
