Bosch NPC-20012-F2 Specsheet

Video | IP micro 2000

IP micro 2000

www.boschsecurity.com

u Compact and stylish indoor IP microbox

u 720p or VGA resolutions at 30 images per second

u MicroSD card slot for edge recording

The 720p and VGA indoor microbox cameras from
Bosch are ready-to-use, complete network video
surveillance systems inside a compact and stylish
housing. These cameras bring Bosch’s high­performance technology into the realm of homes,
small office and retail businesses by offering a cost­effective solution for a broad range of applications.

System overview

iDNR reduces bandwidth and storage requirements

The camera uses intelligent Dynamic Noise Reduction
(iDNR) which actively analyzes the contents of a scene
and reduces noise artifacts accordingly.
The low-noise image and the efficient H.264
compression technology provide clear images while
reducing bandwidth and storage by up to 30%
compared to other H.264 cameras. This results in
reduced-bandwidth streams that still retain a high
image quality and smooth motion. The camera
provides the most usable image possible by cleverly
optimizing the detail-to-bandwidth ratio.
Area-based encoding is another feature which reduces
bandwidth. Compression parameters for up to eight
user-definable regions can be set. This allows
uninteresting regions to be highly compressed, leaving
more bandwidth for important parts of the scene.

u Motion and audio detection

u FTP, Dropbox and e-mail applications

The average typical optimized bandwidth (for firmware

5.8) in kbits/s for various image rates is shown in the
table:

IPS 720p VGA

30 1200 600

15 955 478

5 568 284

2 245 122

Compact and stylish design

Ideal for indoor use, the compact aesthetic design is
suitable for installations where housing size and
appearance are important. The camera is supplied
with a versatile mounting bracket, allowing it to be
easily positioned for best coverage.

720p or VGA resolutions with multiple streams

The camera is available in 720p or VGA resolutions at
30 images per second (ips). The innovative multi­streaming feature delivers various H.264 streams
together with an M‑JPEG stream. These streams
facilitate bandwidth-efficient viewing and recording as
well as integration with third-party video management
systems.

2 | IP micro 2000

Edge recording

The internal MicroSD card slot supports up to 2 TB of
storage capacity. A microSD card can be used for local
alarm recording. Pre-alarm recording in RAM reduces
recording bandwidth on the network, or — if microSD
card recording is used — extends the effective life of
the storage medium.

Two-way audio

The 720p version has a built-in microphone and
loudspeaker that allows remote users to listen in on an
area and communicate messages to visitors or
intruders via the loudspeaker. Audio detection can be
used to generate an alarm if needed.

Tamper and motion detection

A wide range of configuration options is available for
alarms signaling camera tampering. A built-in algorithm
for detecting movement in the video can also be used
for alarm signaling.

Cloud-based facilities

The camera supports time-based or alarm-based JPEG
posting to four different accounts. These accounts can
address FTP servers or cloud-based storage facilities
(for example, Dropbox). Video clips or JPEG images
can also be exported to these accounts.
Alarms can be set up to trigger an e-mail or SMS
notification so you are always aware of abnormal
events.

Easy installation

The power supply adapters delivered with the cameras
provide the 5 VDC power supply required. The 720p
version can be supplied via a Power-over-Ethernet
(IEEE 802.3af) compliant network cable connection.
With this configuration, only a single cable connection
is required to view, power, and control the camera. To
increase system reliability, the 720p version camera
can be simultaneously connected to both PoE and 5
VDC supplies.
Additionally, uninterruptible power supplies (UPS) can
be used, which will allow continuous operation, even
during a power failure. For trouble free network
cabling, the cameras support Auto-MDIX.

Access Security

Password protection with three levels and 802.1x
authentication is supported. To secure Web browser
access, use HTTPS with a SSL certificate stored in the
camera. The video and audio communication channels
can be independently AES encrypted with 128-bit keys
by installing the optional encryption site license.

Complete viewing software

There are many ways to access the camera’s video
features: using a web browser, with the supplied
Bosch Video Client, or with the video security mobile
App.

The Bosch Video Client PC surveillance software offers
a user-friendly interface to support easy installation
and configuration, and is supplied completely free-of­charge. It provides easy live viewing of multiple
cameras, playback, forensic search and export.

Video security App

The Bosch video security mobile App has been
developed to enable Anywhere access to HD
surveillance images allowing you to view live images
from any location. The App is designed to give you
complete control of all your cameras, from panning
and tilting to zoom and focus functions. It’s like taking
your control room with you.
This App, together with the separately available Bosch
transcoder, will allow you to fully utilize our dynamic
transcoding features so you can play back images even
over low-bandwidth connections.

System integration

Bosch IP standard- and high-definition cameras,
encoders and analytics work seamlessly with a wide
range of security software and recording solutions
from Bosch and other industry providers. Through
ONVIF conformance, the open availability of Bosch
video software development kits and a team dedicated
to special integration and support projects, it is easy
to manage Bosch video products within your system
design (for details on the Bosch Integration Partner
Program, visit ipp.boschsecurity.com).

Certifications and approvals

Standards

Standards EN 60950-1

UL 60950-1

CAN/CSA-C22.2 NO. 60950-1-07

EN 50130-4; EN 50130-5

FCC Part15 Subpart B, Class B

EMC directive 2004/108/EC

EN 55022 class B

EN 61000-3-2

EN 61000-3-3

EN 55024

VCCI J55022 V2/V3

AS/NZS CISPR 22 (equal to CISPR 22)

ICES-003 Class B

EN 50132-5-2; IEC 62676-2-3

Product
certifications

CE, FCC, UL, cUL, C-tick, CB, VCCI

3 | IP micro 2000

Region Certification

Europe CE

USA UL

Technical specifications

Power

Input voltage +5 VDC via supplied power adapter

PoE (720p version only) Power-over-Ethernet (48 VDC

Power consumption
(720p version)

Power consumption
(VGA version)

Power supply 100–240 VAC to +5 VDC power

nominal)
IEEE 802.3af (802.3at Type 1)
Power level: Class 2

2.65 W max (+5 VDC)

4.66 W max. (PoE)

1.95 W max.

supply unit included

Video

Sensor type 1/4-inch CMOS

Effective pixels 1280 x 720 (720p version)

Sensitivity (3200 K,
reflectivity 89%, F2.8,
30IRE)

Dynamic range 69 dB

Electronic Day/Night Auto, Color, Monochrome

Shutter speed Automatic Electronic Shutter (AES)

Video resolution 720p, 480p, 432p, 240p, 288p,

Video compression H.264 MP (Main Profile); M-JPEG

Max. frame rate 30 ips

Video Settings Video watermarking, Alarm mode

640 x 480 (VGA version)

1.0 lx

Fixed (1/30 [1/25] to 1/15000)

144p (NPC-20012)
480p, 240p (NPC-20002)

(M-JPEG frame rate can vary
depending on system loading)

stamping, Image mirror, Image flip,
Contrast, Saturation, Brightness,
White balance, Backlight
Compensation, Privacy Mask, Motion
detection, Tamper alarm, Pixel counter

Audio (720p version only)

Audio input Built-in microphone

Audio output Built-in loudspeaker

Audio compression AAC, G.711, L16 (live and recording)

Local Storage

Internal RAM 10 s pre-alarm recording

Memory card slot Supports up to 32 GB microSDHC /

2 TB microSDXC card
(An SD card of Class 6 or higher is
recommended for HD recording)

Recording Continuous recording, ring recording.

alarm/events/schedule recording

Software Control

Unit configuration Via web browser or PC surveillance

software

Network

Protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS,

RTP/RTCP, IGMP V2/V3, ICMP,
ICMPv6, RTSP, FTP, Telnet, ARP,
DHCP, SNTP, SNMP (V1, MIB‑II),

802.1x, DNS, DNSv6, DDNS, SMTP,
iSCSI, UPnP (SSDP), DiffServ (QoS),
LLDP, SOAP, Dropbox, CHAP, Digest
Authentication.

Encryption TLS 1.0, SSL, DES, 3DES, AES

(optional)

Ethernet 10/100 Base-T, auto-sensing, half/full

duplex

Ethernet connector RJ45

Connectivity ONVIF Profile S, Auto-MDIX

Mechanical

Mounting bracket 3-axis adjustment

Dimensions (L x W x H) 109 x 65 x 47 mm

(4.29 x 2.56 x 1.85 in)

Weight (720p version) 143 g (5.04 oz) approx.

Weight (VGA version) 89 g (3.14 oz) approx.

Color RAL 9017

Environmental

Lens

Lens type 2.5 mm fixed, F2.8

Lens mount Board mounted

View angle (H x V)

89° x 50° (NPC-20012)
75° x 56° (NPC-20002)

Operating temperature
(720p version)

Operating temperature
(VGA version)

Storage temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF)

Humidity 0% to 95% relative humidity (non

-10 ºC to +50 ºC (14 ºF to +122 ºF)

-10 ºC to +45 ºC (14 ºF to +113 ºF)

condensing)

4 | IP micro 2000

Represented by:

Americas: Europe, Middle East, Africa: Asia-Pacific: China: America Latina:

Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.us

Bosch Security Systems B.V.
P.O. Box 80002
5617 BA Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: [phone]
[e-mail]
www.boschsecurity.com

Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.asia

Bosch (Shanghai) Security Systems Ltd.
201 Building, No. 333 Fuquan Road
North IBP
Changning District, Shanghai
200335 China
Phone [phone]
Fax: [phone]
www.boschsecurity.com.cn

Robert Bosch Ltda Security Systems Division
Via Anhanguera, Km 98
CEP 13065-900
Campinas, Sao Paulo, Brazil
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.com

© Bosch Security Systems 2013 | Data subject to change without notice
11391170571 | en, V7, 13. Dec 2013

Ordering information

IP micro 2000 HD

Cost-effective, ready-to-use, IP microbox camera for
indoor surveillance. MicroSD card slot; 2.5 mm lens;
+5 VDC PSU; 30 images/sec; motion/audio detection;
cloud services; free viewing Apps; iDNR; 720p

Order number NPC-20012-F2

IP micro 2000

Cost-effective, ready-to-use, IP microbox camera for
indoor surveillance. MicroSD card slot; 2.5 mm lens;
+5 VDC PSU; 30 images/sec; motion/audio detection;
cloud services; free viewing Apps; iDNR; VGA

Order number NPC-20002-F2
