1 6-Channel interpreter desk
with loudspeaker (LBB 3222/04)
1.1 Introduction
The LBB 3222/04 6-channel interpreter desk provides listening and speaking facilities for interpreters using the CCS 800, CCS 400 or non-BOSCH discussion systems. Up to 12 desks can be connected to an Integrus transmitter using the Integrus audio input and interpreters module (LBB 3422/20). It can distribute up to 6 outgoing languages. An ‘auto-floor’-feature is incorporated for relay interpretation. This allows a less well-known floor language to be translated by one interpreter into a language familiar to all other inter­preters and relayed as the auto-floor.
The LBB 3222/04 has an integral loudspeaker and is supplied with a microphone incorporating an illuminat­ed status ring to warn everyone in the booth that the microphone is active. Two outgoing channels are pro­vided, A and B, switchable by means of a channel select key.
1.2 Front panel controls
The desk has the following front-panel controls and indicators (see figure 1.1):
Figure 1.1:
1. Microphone activating key - 2-position toggle
switch for activating the microphone. An interlock facility can be enabled (using the under-panel con­trols) that prevents the microphone being activated if the desk’s outgoing language distribution channel is occupied by another desk.
2. Microphone status indicators - Two red LEDs to
indicate that the microphone is active.
3. Microphone mute key - A non-locking push-but-
ton to temporarily mute the microphone. When pressed, the status indicators and status ring are ‘off’, but the outgoing language distribution channel remains occupied by the desk.
4. Microphone - Gooseneck microphone with inte-
gral status indicator ring.
Figure 1.1 LBB 3222/04 6-channel interpreter desk
Note: Flashing indicators warn that the
language channel occupied by this desk
is also being used by one or more other
desks.
INTEGRUS | Installation and User Instructions | 6-Channel interpreter desk with loudspeaker en | 2
Bosch Security Systems | 2005-04 | 9922 141 70164en
5. Call-channel key - Non-locking push-button to
route the microphone to the call channel for one­way communication with the operator (with priority over the A/B channel). The microphone status indi­cators and status ring are ‘on’ when the call-channel key is pressed. The outgoing language distribution channel remains occupied by the desk. Not applica­ble for use with CCS 800 discussion systems.
6. Outgoing message key - Non-locking push-button
to be used for signalling purposes. When pressed, contacts are closed. This switch is connected to the 6-pole DIN connector for custom wiring.
7. Incoming message indicator - A yellow LED with
1 k W series resistor connected to the 6-pole DIN connector. To be used for custom signalling purpos­es.
8. Tone/volume controls - Rotary volume, bass and
treble controls for the headphone.
9. Volume control - Rotary volume control for built-
in loudspeaker.
10. Monitor loudspeaker - Built-in loudspeaker for
monitoring without headphones. The speaker is only active when the microphone is off.
11. Incoming channel selector - 8-position rotary
switch to select either OR, OR2 or channels 1 to 6 for monitoring as incoming language. This switch is only active if the incoming channel pre-selector key is in the ‘up’-position.
12. Incoming channel pre-selector key - 2-position
toggle switch to select either OR when in the ‘down’-position, or the channel selected by the incoming channel selector knob when in the ‘up’­position. If OR is selected and OR2 is activated using the auto-floor-feature, the desk automatically receives OR2 for monitoring.
13. Incoming channel OR2 indicator - Green LED to
indicate that OR2 is active instead of OR during relay interpretation.
14. A-B channel selector key - 2-position toggle
switch for selecting either A or B. If use of channel B is inhibited, the outgoing channel will be the one pre-set for the desk by the under-panel A select control. If channel B is enabled, the outgoing chan­nel can be selected with the channel-B select keys.
15. Outgoing channel-A indicators - 6 green LEDs to
indicate which outgoing channel is assigned to the desk for channel A using the under-panel controls.
16. Outgoing channel-B indicators - 6 green LEDs to
indicate which outgoing channel is assigned to the desk for channel B using the outgoing channel-B select keys.
17. Outgoing channel-B select keys - 6-way interlock-
ing push-button array to select the outgoing channel when channel B is selected.
18. A-B channel select indicators - 2 red LEDs to
indicate which channel, A or B, is selected.
19. Outgoing OR2 indicator - Green LED to indicate
that the desk is enabled for relaying OR2 to other desks (using under-panel controls).
20.Engaged channel indicators - 2 yellow LEDs, one
each for A and B, to indicate that the outgoing channel selected is occupied by one or more desks. A flashing LED indicates that the outgoing channel occupied by the desk is also being used by one or more other desks.
Note: For a full explanation of terms
OR and OR2, see section 1.6.
