Fridge-freezer
KIF82...
[en] User manual
Register your
new device on
MyBosch now and
get free benefits:
bosch-home.com/
welcome
en
Table of contents
Safety...............................................4
General information..........................4
Intended use.....................................4
Restriction on user group.................4
Safe transport...................................5
Safe installation ................................5
Safe use ...........................................6
Damaged appliance .........................8
Preventing material damage ........10
Environmental protection and
saving energy................................10
Disposing of packaging .................10
Saving energy.................................10
Installation and connection..........11
Scope of delivery............................11
Installing and connecting the ap-
pliance ............................................11
Criteria for the installation loca-
tion..................................................12
Preparing the appliance for the
first time..........................................12
Connecting the appliance to the
electricity supply.............................12
Familiarising yourself with
your appliance...............................13
Appliance .......................................13
Controls ..........................................14
Features.........................................14
Shelf................................................15
Variable shelf..................................15
Extendable shelf .............................15
Fruit and vegetable container ........15
Cool-fresh container .......................16
Butter and cheese compartment ...16
Door racks......................................16
Accessories....................................16
Basic operation .............................16
Switching on the appliance ............16
Operating tips.................................16
Switching off the appliance ............17
Setting the temperature..................17
Additional functions .....................17
Super function ................................17
Alarm..............................................18
Door alarm .....................................18
Refrigerator compartment ............18
Tips for storing food in the refri-
gerator compartment .....................18
Chill zones in the refrigerator
compartment ..................................18
Cool-fresh compartment...............19
Storage times in the cool-fresh
compartment at 0°C .....................19
Freezer compartment....................19
Freezer compartment door ............19
Freezing capacity ...........................20
Tips for buying frozen food ............20
Tips for storing food in the
freezer compartment ......................20
Tips for freezing fresh food ............20
Shelf life of frozen food at
−18°C............................................21
Defrosting methods for frozen
food ................................................21
Defrosting......................................22
Defrosting in the refrigerator
compartment ..................................22
Defrosting in the cool-fresh com-
partment .........................................22
Defrosting in the freezer com-
partment .........................................22
Cleaning and servicing.................22
Preparing the appliance for
cleaning ..........................................22
Cleaning the appliance ..................23
Removing the fittings......................23
2
Removing appliance compon-
ents.................................................24
Troubleshooting............................27
Malfunctions ...................................27
Information on display panel..........28
Temperature problem.....................28
Noise ..............................................28
Odours............................................29
Conducting an appliance self-
test..................................................30
Storage and disposal....................30
Switching off the appliance ............30
Disposing of old appliance ............30
Customer Service..........................31
Product number (E-Nr.) and pro-
duction number (FD) ......................31
Technical data ...............................31
en
3
en Safety
Safety
Please read the safety information to ensure that you use the appliance safely.
General information
You can find general information for this instruction manual here.
¡ Read this instruction manual carefully. Only this will ensure you
use the appliance safely and efficiently.
¡ This manual is intended for the user of the appliance.
¡ Follow the safety instructions and warnings.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Check the appliance after unpacking it. Do not connect the ap-
pliance if it has been damaged in transit.
Intended use
Read the information on intended use to ensure that you use the
appliance correctly and safely.
This appliance is only intended to be fully fitted in a kitchen.
Only use this appliance:
¡ As specified in this instruction manual.
¡ For chilling and freezing food and making ice.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of max. 2000m above sea level.
Restriction on user group
Avoid risks to children and vulnerable persons.
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Children must not play with the appliance.
4
Safety en
Cleaning and user maintenance must not be performed by children unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Children above the age of three years old and younger than eight
years old may load and unload the the fridge-freezer.
Safe transport
Follow these safety instructions when transporting the appliance.
WARNING‒Risk of injury!
The high weight of the appliance may result in injury when lifted.
▶
Do not lift the appliance on your own.
Safe installation
Follow these safety instructions when installing the appliance.
WARNING‒Risk of electric shock!
¡ Improper installation is dangerous.
▶
Connect and operate the appliance only in accordance with
the specifications on the rating plate.
▶
Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.
▶
The protective conductor system of the domestic electrical
installation must be properly installed.
▶
Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶
When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.
▶
When installing the appliance, check that the power cable is
not trapped or damaged.
5
en Safety
¡ If the insulation of the power cord is damaged, this is danger-
ous.
▶
Never let the power cord come into contact with heat
sources.
▶
Never let the power cord come into contact with sharp
points or edges.
▶
Never kink, crush or modify the power cord.
WARNING‒Risk of explosion!
If the appliance's ventilation openings are sealed, a leak in the
refrigeration circuit may result in a flammable mixture of gas
and air.
▶
Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING‒Risk of fire!
¡ It is dangerous to use an extended power cord and non-ap-
proved adapters.
▶
Do not use extension cables or multiple socket strips.
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer.
¡ Portable multiple socket strips or portable power supply units
may overheat and cause a fire.
▶
Do not place portable multiple socket strips or power supply units on the back of the appliance.
Safe use
Follow these safety instructions when using the appliance.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat or humidity.
▶
Do not use steam- or high-pressure cleaners to clean the
appliance.
6
Safety en
WARNING‒Risk of suffocation!
¡ Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
¡ Children may breathe in or swallow small parts, causing them
to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
WARNING‒Risk of explosion!
¡ Mechanical devices or other devices may damage the refri-
geration circuit; flammable refrigerant may escape and explode.
▶
To accelerate the defrosting process, do not use any other
mechanical devices or devices other than those recommended by the manufacturer.
¡ Products which contain flammable propellants and explosive
substances may explode, e.g. spray cans.
▶
Do not store products which contain flammable propellants
(e.g. spray cans) or explosive substances in the appliance.
WARNING‒Risk of fire!
Electrical devices within the appliance may cause a fire, e.g.
heaters or electric ice makers.
▶
Do not operate electrical devices within the appliance.
WARNING‒Risk of injury!
¡ Containers that contain carbonated drinks may burst.
▶
Do not store containers that contain carbonated drinks in
the cool-fresh compartment.
▶
Do not store containers that contain carbonated drinks in
the freezer compartment.
¡ Injury to the eyes caused by escaping flammable refrigerant
and hazardous gases.
▶
Do not damage the tubes of the refrigerant circuit or the insulation.
7
en Safety
WARNING‒Risk of cold burns!
Contact with frozen food and cold surfaces may cause burns
by refrigeration.
▶
Never put frozen food straight from the freezer compartment
into your mouth.
▶
Avoid prolonged contact of skin with frozen food, ice and
the tubes in the freezer compartment.
CAUTION‒Risk of harm to health!
¡ To prevent food from being contaminated, you must observe
the following instructions.
▶
If the door is open for an extended period of time, this may
lead to a considerable temperature increase in the compartments of the appliance.
▶
Regularly clean the surfaces that may come into contact
with food and accessible drain systems.
▶
Store raw meat and fish in suitable containers in the refrigerator so that they do not touch or drip on other food.
▶
If the fridge/freezer is empty for an extended period of time,
switch off the appliance, defrost it, clean it and leave the
door open to prevent the formation of mould.
¡ If acidic food comes into contact with aluminium in the appli-
ance, aluminium foil ions may pass into the food.
▶
Do not consume soiled food.
Damaged appliance
Follow the safety instructions if your appliance is damaged.
WARNING‒Risk of electric shock!
¡ If the appliance or the power cord is damaged, this is danger-
ous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked or fractured surface.
▶
Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains.
8
Safety en
▶
If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box.
▶
"Call Customer Service." →Page31
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
¡ Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be
replaced by the manufacturer, the manufacturer's Customer
Service or a similarly qualified person in order to prevent
any risk.
WARNING‒Risk of fire!
If the tubes are damaged, flammable refrigerant and harmful
gases may escape and ignite.
▶
Keep naked flames and ignition sources away from the appliance.
▶
Ventilate the room.
▶
"Switch off the appliance." →Page17
▶
Unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
▶
"Call after-sales service." →Page31
9
en Preventing material damage
Preventing material damage
Preventing material damage
Preventing material damage
Follow these instructions to prevent
material damage to your appliance,
accessories or other objects in your
kitchen.
ATTENTION!
¡ Using the base, runners or appli-
ance doors as a seat surface or
climbing surface may damage the
appliance.
▶
Do not stand or support yourself
on the base, runners or doors.
¡ Contamination with oil or fat may
cause plastic parts and door seals
to become porous.
▶
Keep plastic parts and door
seals free of oil and grease.
¡ Metal or metal-style parts in the ap-
pliance may contain aluminium.
Aluminium reacts when it comes
into contact with acidic foods.
▶
Do not store unpackaged food
in the appliance.
Environmental protection and saving energy
Environmental protection
and saving energy
Environmental protection and saving energy
Help protect the environment by using your appliance in a way that conserves resources and by disposing of
reusable materials properly.
Information about current disposal
methods are available from your
specialist dealer or local authority.
Saving energy
If you follow these instructions, your
appliance will use less power.
Selecting the installation location
Follow these instructions when installing your appliance.
¡ Keep the appliance out of direct
sunlight.
¡ Install the appliance as far away
as possible from heating elements, cookers and other heat
sources:
– Maintain a 30mm clearance to
electric or gas cookers.
– Maintain a 30cm clearance to
oil or solid-fuel cookers.
The appliance needs to cool less
frequently at low ambient temperatures.
¡ Use a niche depth of 560mm.
¡ Do not cover or block ventilation
openings.
The air on the back wall of the ap-
pliance can escape more easily
and the appliance does not warm
up so intensely.
The appliance must cool less frequently.
Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
▶
Sort the individual components by
type and dispose of them separately.
10
Saving energy during use
Follow these instructions when using
your appliance.
Note:The arrangement of the fittings
does not affect the energy consumption of the appliance.
Installation and connection en
¡ Do not cover or block ventilation
openings.
The air on the back wall of the ap-
pliance can escape more easily
and the appliance does not warm
up so intensely.
¡ Open the appliance door only
briefly.
¡ Transport purchased food in a
cool bag and place in the appliance quickly.
¡ Allow warm food and drinks to
cool down before placing them in
the appliance.
¡ Thaw frozen food in the refriger-
ator compartment to utilise the low
temperature of the food.
The air in the appliance does not
warm up so intensely.
The appliance must cool less frequently.
¡ Always leave some space
between the food and to the back
panel.
¡ Pack the food airtight.
The air can circulate and the air
humidity remains constant.
¡ Defrost the freezer compartment
regularly.
A frost-free freezer compartment is
power-saving and cools the frozen
food optimally.
¡ Only open the freezer compart-
ment door briefly and then carefully close it.
A closed freezer compartment
door protects the freezer compartment against severe icing.
Installation and connection
Installation and connection
Installation and connection
You can find out where and how best
to install your appliance here. You
will also learn how to connect your
appliance to the power supply.
Scope of delivery
After unpacking all parts, check for
any transport damage and for completeness of delivery.
If you have any complaints, contact
your dealer or our "after-sales service" →Page31.
The delivery consists of the following:
¡ Built-in appliance
¡ Equipment and accessories
¡ Installation material
¡ Installation instructions
¡ User manual
¡ Customer service booklet
¡ Warranty enclosure
2
¡ Energy label
¡ Information on energy consump-
tion and noises
Installing and connecting the appliance
Requirement:"The scope of delivery
of the appliance is checked."
→Page11
1. "Observe the criteria for the appli-
ance's installation location."
→Page12
2. Install the appliance according to
the enclosed installation instructions.
3. "Prepare the appliance for first
use." →Page12
1
1
Depending on the appliance specifications
2
Not in all countries
11
en Installation and connection
7
4. "Electrically connect the appli-
ance." →Page12
Criteria for the installation location
Follow these instructions when installing your appliance.
WARNING
Risk of explosion!
If the appliance is in a space that is
too small, a leak in the refrigeration
circuit may result in a flammable mixture of gas and air.
▶
Only install the appliance in a
space with a volume of at least
1m3 per 8g refrigerant. The
volume of refrigerant is indicated
on the rating plate. →"Appliance",
Fig. 1 /7, Page14
The weight of the appliance ex works
may be up to 75kg depending on
the model.
The subfloor must be of sufficient stability to bear the weight of the appliance.
Permitted room temperature
The permitted room temperature depends on the appliance's climate
class.
The climate class can be found on
the rating plate. →"Appliance", Fig.
1 /
, Page14
Climate class Permitted room temperat-
ure
SN 10°C to 32°C
N 16°C to 32°C
ST 16°C to 38°C
T 16°C to 43°C
The appliance is fully functional within
the permitted room temperature.
If an appliance with climate class SN
is operated at colder room temperatures, the appliance will not be damaged up to a room temperature of
5°C.
Niche dimensions
Observe the niche dimensions if you
install your appliance in the niche. If
this is not the case, problems may
occur when installing the appliance.
Niche depth
Install the appliance in the recommended niche depth of 560mm.
If the niche depth is smaller, the energy consumption increases slightly.
The niche depth must be a minimum
550mm.
Niche width
An inside niche width of at least
560mm is required for the appliance.
Preparing the appliance for the first time
1. Remove the informative material.
2. Remove the protective foil and
transit bolts, e.g. remove the adhesive strips and carton.
3. "Clean the appliance for the first
time." →Page23
Connecting the appliance to the electricity supply
1. Insert the mains plug of the appli-
ance's power cable in a socket
nearby.
The connection data of the appliance can be found on the rating
plate. →"Appliance", Fig. 1 /7,
Page14
2. Check the mains plug is inserted
properly.
a The appliance is now ready for
use.
12
Familiarising yourself with your appliance en
1
2
3
4
5
6
7
8
9
A
B
C
A
B
C
1
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Familiarise yourself with the parts of your appliance.
Appliance
You can find an overview of the parts of your appliance here.
1
Freezer compartment
Refrigerator compartment
Cool-fresh compartment
Controls
13
en Features
2
3
4
5
6
7
8
9
1 2 3 4 5 6
1
2
3
4
5
6
"Variable shelf" →Page15
"Extendable shelf" →Page15
Partition with humidity controller
"Fruit and vegetable container"
→Page15
"Cool-fresh container" →Page16
Note:Deviations between your appliance and the diagrams may differ
with regard to their features and size.
Rating plate
"Butter and cheese compartment"
→Page16
Door storage compartment for large
bottles
Controls
The controls are used to configure all functions of your appliance and to obtain
information about the operating status.
2
lights up when the appliance is
operating.
switches the warning signal off.
/ sets the temperature of the refri-
gerator compartment.
Displays the set temperature for the
refrigerator compartment in°C.
switches Super cooling on or
off.
switches the appliance on or off.
Features
Features
Features
Here you can see an overview of the
features of your appliance and their
use.
The features of your appliance depend on the model.
14
Shelf
To vary the shelf as required, you
can remove the shelf and re-insert it
elsewhere.
→"Removing the shelf", Page23
Variable shelf
Use the variable shelf to the store tall
items, e.g. cans or bottles, on the
shelf below.
You can remove the front section of
the variable shelf and slide it below
the rear part of the shelf.
Extendable shelf
In order to achieve an improved overview and to remove food more
quickly, remove the shelf.
Fruit and vegetable container
Store fresh fruit and vegetables in the
fruit and vegetable container.
You can adjust the humidity in the
fruit and vegetable container via the
humidity controller on the partition
and a special seal.
Features en
The air humidity in the fruit and
vegetable container can be set
according to the type and amount of
food to be stored by turning the
humidity control:
¡ Low humidity required when
primarily storing fruit or if the appliance is very full.
¡ Medium humidity required for
a mixed load.
¡ High humidity required when
primarily storing vegetables or
when the appliance is not very full.
Condensation may form in the fruit
and vegetable container depending
on the food and quantity stored.
Remove the condensation with a dry
cloth and adjust the air humidity using the humidity controller.
To ensure that the quality and aroma
are retained, store fruit and vegetables that are sensitive to cold outside of the appliance at temperatures
of approx. 8°C to 12°C.
Fruit that is sensitive
to cold
Vegetables that are
sensitive to cold
¡ Pineapples
¡ Bananas
¡ Mangoes
¡ Papayas
¡ Citrus fruits
¡ Aubergines
¡ Gherkins
¡ Courgettes
¡ Peppers
¡ Tomatoes
15
en Basic operation
¡ Potatoes
Cool-fresh container
Use the lower temperatures in the
cool-fresh container to store perishable food, e.g. fish, meat and sausages.
Butter and cheese compartment
Store butter and hard cheese in the
butter and cheese compartment.
Door racks
To adjust the door racks as required,
you can remove the door rack and
re-insert elsewhere.
→"Removing door racks", Page24
Accessories
Only use original accessories. These
have been made especially for your
appliance. Here you can find an overview of your appliance's accessories
and how to use them.
The accessories for your appliance
depend on the model.
Egg tray
Store eggs safely on the egg tray.
Bottle holder
The bottle holder prevents bottles
from falling over when the appliance
door is opened and closed.
Ice cube tray
Use the ice cube tray to make ice
cubes.
Making ice cubes
1. Fill the ice cube tray with water up
to ¾ and place in the freezer compartment.
If the ice cube tray is stuck to the
freezer compartment, loosen it with
a blunt implement only (e.g. spoon
handle).
2. To loosen the ice cubes, twist the
ice cube tray slightly or hold it
briefly under flowing water.
Basic operation
Basic operation
Basic operation
You can find out everything you need
to know about operating your appliance here.
Switching on the appliance
1. Press .
a The appliance begins to cool.
2. "Set the required temperature."
→Page17
16
Operating tips
¡ Once you have switched on the
appliance, the set temperature is
only reached after several hours.
Additional functions en
Do not put any food in the appliance until the temperature has
been reached.
¡ The housing to the left, the right
and beneath the cool-fresh compartment may heat up slightly temporarily. This prevents condensation in the area of the door seal.
¡ When you close the door, a va-
cuum may be created. The door is
then difficult to open again. Wait a
moment until the vacuum is offset.
Switching off the appliance
▶
Press .
a The appliance stops cooling.
Setting the temperature
After you have switched on the appliance, you can set the temperature.
Setting the refrigerator compartment temperature
▶
Press / repeatedly until the temperature display shows the required temperature.
The recommended temperature in
the refrigerator compartment is
4°C.
Setting the cool-fresh compartment temperature
Note:The temperature in the cool-
fresh compartment is kept at around
0°C.
▶
"If frost forms on the food items in
the cool-fresh compartment, set a
higher cool-fresh temperature."
→Page28
Setting the freezer compartment temperature
▶
In order to set the freezer compartment temperature, "change the refrigerator compartment temperature" →Page17.
The refrigerator compartment temperature influences freezer compartment temperature. Refrigerator
compartment temperatures that
are set to warm generate warmer
freezer compartment temperatures.
Additional functions
Additional functions
Additional functions
Find out which additional functions
which can be used for your appliance.
Super function
With the Super function, the refrigerator compartment and the freezer
compartment cool more intensively.
This refrigerates or freezes food
quickly right through to the centre.
Switch on the Super function 4 to
6hours before placing food weighing
2kg or more.
In order to utilise the freezer capacity,
use the Super function.
→"Freezing capacity", Page20
Note:When the Super function is
switched on, increased noise may
occur.
Switching on Super function
▶
Press .
a lights up.
Note:After approx. 36hours, the appliance switches to normal operation.
17
en Alarm
Switching off Super function
▶
Press .
a The previously set temperature is
displayed.
Alarm
Alarm
Alarm
Your appliance is equipped with
alarm functions.
Door alarm
If the appliance door is open for a
longer period, the door alarm
switches on.
Switching off the warning tone (door alarm)
▶
Close the appliance door or press
.
a The warning tone is switched off.
Refrigerator compartment
Refrigerator compartment
Refrigerator compartment
You can keep dairy products, eggs,
prepared meals, pastries, open preserves and hard cheese in the refrigerator compartment.
You can set the temperature in the
refrigerator compartment from 3°C
to 8°C.
The recommended temperature in
the refrigerator compartment is 4°C.
The refrigerator compartment can
also be used to store highly perishable foods in the short to medium
term. The lower the selected temperature, the longer the food remains
fresh.
Tips for storing food in the refrigerator compartment
Follow the tips if you store food in
your refrigerator compartment.
¡ To ensure that the freshness and
quality of the food is retained for
longer, only store fresh and unspoiled food.
¡ In the case of ready-made
products and bottled goods, do
not exceed the best-before date or
use-by date specified by the manufacturer.
¡ To retain aroma, colour and fresh-
ness or to prevent taste transfer
and discolouration of the plastic
parts, store food well wrapped or
covered.
¡ Leave warm food and beverages
to cool down before placing them
in the refrigerator compartment.
Chill zones in the refrigerator compartment
The air circulation in the refrigerator
compartment creates different chill
zones.
Coldest zone
The coldest zone is on the partition
and in the door rack for large bottles.
Warmest zone
The warmest zone is at the very top
of the door.
Tips
¡ Store food that does not spoil eas-
ily in the warmest zone, e.g. hard
cheese and butter. Cheese can
then continue to release its aroma
and the butter will still be easy to
spread.
18
Cool-fresh compartment en
¡ Store perishable food such as fish,
sausages and meat in the coolfresh compartment.
→"Cool-fresh compartment",
Page19
Cool-fresh compartment
Cool-fresh compartment
Cool-fresh compartment
In the cool-fresh compartment, you
can keep fresh food fresh three times
longer than in the refrigerator compartment.
The temperature in the cool-fresh
compartment is kept at around 0°C.
Storing food in the fresh compartment retains the quality of the food
better. The low temperature and the
optimum moisture provide ideal storage conditions for fresh food.
Storage times in the coolfresh compartment at 0°C
The storage times are dependent on
the original quality of your food.
Food Storage
time
Fresh fish, seafood up to 3days
Poultry, meat (boiled/fried) up to 5 days
Beef, pork, lamb, sausage (cold
meat)
Smoked fish, broccoli up to 14
Salad greens, fennel, apricots,
plums
Soft cheese, yoghurt, quark,
buttermilk, cauliflower
up to 7 days
days
up to 21
days
up to 30
days
Freezer compartment
Freezer compartment
Freezer compartment
You can store frozen food, freeze
food and make ice cubes in the
freezer compartment.
The temperature in the freezer compartment depends on the temperature in the refrigerator compartment.
Long-term storage of food should be
at –18°C or lower.
The freezer compartment can be
used to store perishable food longterm. The low temperatures slow
down or stop the spoilage.
The time between putting fresh food in
the freezer compartment and it freezing
solid depends on various factors:
¡ Set temperature
¡ Food (size and type)
¡ Quantity and type of storage
¡ Quantity and type of food already
stored
Freezer compartment door
To ensure that the frozen food that is
stored does not thaw and the freezer
compartment is not covered in too
much ice, always close the freezer
compartment door.
The position of the handle on the
freezer compartment door indicates
whether or not the freezer compartment is correctly closed.
Note:When you close the freezer
compartment door, you can hear it
engaging.
19
en Freezer compartment
Freezing capacity
The maximum freezing capacity indicates the quantity of food that can be
frozen right through to the centre
within a specific period of time.
Information on the maximum freezing
capacity can be found on the rating
plate. →"Appliance", Fig. 1 /7,
Page14
Prerequisites for freezing capacity
1. Approx. 6hours before placing
fresh food in the appliance, switch
on Super function.
→"Switching on Super function",
Page17
2. Store larger quantities of fresh
food store at the bottom, close to
the back panel. This is where food
will freeze most quickly.
Tips for buying frozen food
Follow the tips when you are buying
frozen food.
¡ Check the packaging is not dam-
aged.
¡ Check the best-before date.
¡ The temperature in the supermar-
ket freezer must be –18°C or
lower.
¡ Do not interrupt the deep-freeze
chain. If possible, transport frozen
food in a cool bag and quickly
place it in the freezer compartment.
Tips for storing food in the freezer compartment
Follow the tips if you are storing food
in the freezer compartment.
¡ Spread out the food over a wide
area in the freezer compartment.
¡ Do not bring food which is to be
frozen into contact with frozen
food.
If necessary, redistribute frozen
food in the freezer compartment.
Tips for freezing fresh food
Follow the tips when you freeze fresh
food.
¡ Freeze fresh and undamaged food
only.
¡ Cooked food is more suitable than
food that can be eaten raw.
¡ In order to retain the nutritional
value, flavour and colour, you
should prepare certain food for
freezing.
– Vegetables: Wash, chop up,
blanch.
– Fruit: Wash, pit and perhaps
peel, possibly add sugar or
ascorbic acid solution.
Additional information on how to do
this can be found in the relevant literature.
Food suitable for freezing
¡ Baked goods
¡ Fish and seafood
¡ Meat
¡ Poultry and game
¡ Vegetables, fruit and herbs
¡ Eggs without shells
20
Freezer compartment en
¡ Dairy products, e.g. cheese, butter
and quark
¡ Ready meals and leftovers, e.g.
soups, stews, cooked meat and
fish, potato dishes, bakes and
desserts
Food that is unsuitable for freezing
¡ Types of vegetables that are usu-
ally eaten raw, e.g. lettuce or
radishes
¡ Unpeeled or hard-boiled eggs
¡ Grapes
¡ Whole apples, pears and peaches
¡ Yoghurt, soured milk, sour cream,
crème fraîche and mayonnaise
Packing frozen food
If you select suitable packaging material and the correct type of packaging, you can determine the product
quality and prevent freezer burn.
1. Place the food in the packaging.
Suitable packaging:
– Plastic film made of polyethyl-
ene
– Tubular film made of polyethyl-
ene
– Freezer bags made from poly-
ethylene
– Freezer containers
Unsuitable packaging:
– Wrapping paper
– Greaseproof paper
– Cellophane
– Aluminium foil
– Rubbish bags and used shop-
ping bags
2. Squeeze out the air.
3. Pack food airtight to prevent it
from losing flavour and drying out.
Suitable seals:
– Rubber bands
– Plastic clips
– Cold-resistant adhesive tape
4. Label the packaging with the con-
tents and the date of freezing.
Shelf life of frozen food at
−18°C
Observe the storage times when you
freeze food.
Food Storage time
Fish, sausages, prepared
Up to 6months
meals and baked goods
Poultry, meat Up to 8months
Vegetables, fruit Up to 12months
Defrosting methods for frozen food
To retain the best-possible product
quality, the defrosting method must
be adjusted to the food and application.
CAUTION
Risk of harm to health!
During the thawing process, bacteria
may multiply and spoil the frozen
food.
▶
Do not refreeze food after it has
been defrosted or started to defrost.
▶
Refreeze food only after cooking.
▶
These items should no longer be
stored for the maximum storage
period.
Defrosting
method
Refrigerator compartment
Room temperature Bread
Microwave Food for immediate con-
Oven or cooker Food for immediate con-
Food
Animal-based food such
as fish, meat, cheese,
quark
sumption or immediate
preparation
sumption or immediate
preparation
21
en Defrosting
Defrosting
Defrosting
Defrosting
Observe the information when you
want to defrost your appliance.
Defrosting in the refrigerator compartment
The refrigerator compartment in your
appliance defrosts automatically.
Defrosting in the cool-fresh compartment
The cool-fresh compartment in your
appliance defrosts automatically.
Defrosting in the freezer compartment
As the frozen food must not start
thawing, the freezer compartment
does not defrost automatically. A
layer of hoarfrost in the freezer compartment impairs refrigeration of the
frozen food and increases power
consumption.
Defrosting the freezer compartment
Regularly defrost the freezer compartment.
1. Switch on the Super function ap-
prox. fourhours before defrosting.
→"Switching on Super function",
Page17
This means that the food reaches
very low temperatures and it can
be stored for longer at room temperature.
2. Remove the frozen food and tem-
porarily place it in a cool location.
Place ice packs (if available) on
the frozen food.
3. "Switch off the appliance."
→Page17
4. Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
5. To accelerate the defrosting pro-
cess, place a pan of hot water on
a trivet in the freezer compartment.
6. Wipe up the condensation water
with a soft cloth or sponge.
7. Rub the freezer compartment dry
with a soft, dry cloth.
8. Electrically connect the appliance.
9. "Switch on the appliance."
→Page16
10."Put the frozen food in the appli-
ance." →Page20
Cleaning and servicing
Cleaning and servicing
Cleaning and servicing
To keep your appliance working efficiently for a long time, it is important
to clean and maintain it carefully.
Customer Service must clean inaccessible points. Cleaning by customer service can give rise to costs.
Preparing the appliance for cleaning
Find out how to prepare your appliance for cleaning.
1. "Switch off the appliance."
→Page17
2. Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
3. Take out all of the food and store it
in a cool place.
Place ice packs (if available) onto
the food.
4. If there is a layer of hoarfrost, allow
this to defrost.
5. "Remove all fittings from the appli-
ance." →Page23
22
Cleaning and servicing en
6. Remove the following components
from the appliance:
– →"Partition and cover of the
fruit and vegetable container",
Page24
– →"Telescopic rails", Page25
– Door ventilation cover
Cleaning the appliance
Clean the appliance as specified to
ensure that it is not damaged by incorrect cleaning or unsuitable cleaning products.
WARNING
Risk of electric shock!
¡ An ingress of moisture can cause
an electric shock.
▶
Do not use steam- or high-pressure cleaners to clean the appliance.
¡ Liquid in the lighting can be dan-
gerous.
▶
The rinsing water must not run
into the light.
ATTENTION!
¡ Unsuitable cleaning products may
damage the surfaces of the appliance.
▶
Do not use hard scouring pads
or cleaning sponges.
▶
Do not use harsh or abrasive
detergents.
▶
Do not use cleaning products
with a high alcohol content.
¡ If you clean fittings and accessor-
ies in the dishwasher, this may
cause them to become deformed
or discolour.
▶
Never clean fittings and accessory in the dishwasher.
2. Clean the appliance, the fittings,
the components and the door
seals with a dish cloth, lukewarm
water and a little pH-neutral washing-up liquid.
3. Dry thoroughly with a soft, dry
cloth.
4. Refit the fittings and the compon-
ents.
5. Electrically connect the appliance.
6. "Switch on the appliance."
→Page16
7. Putting the food into the appliance.
Removing the fittings
If you want to clean the fittings thoroughly, remove these from your appliance.
Removing the shelf
▶
Pull out and remove the shelf.
Removing the extendable shelf
1. Pull out the extendable shelf until
the locking catch is released.
1. "Prepare the appliance for clean-
ing." →Page22
23
en Cleaning and servicing
2. Lower the shelf and swing it out to
the side.
Removing door racks
▶
Lift the door rack upwards and remove it.
Removing the fruit and vegetable container
▶
Tilt the fruit and vegetable container forwards and remove it .
Removing the cool-fresh container
▶
Tilt the cool-fresh container forwards and remove it .
Removing appliance components
If you want to clean your appliance
thoroughly, you can remove certain
components from your appliance.
Partition and cover of the fruit and vegetable container
You can remove the partition and the
cover of the fruit and vegetable container in order to clean it thoroughly.
Removing the partition
1. Remove the glass plate from the
partition.
24
2. Remove the fruit and vegetable
container.
3. Press the lever on the underside
on both sides and pull the partition forwards .
4. Lift the partition and swivel it out to
the side.
Removing the cover
▶
Lift the cover of the fruit and vegetable container, pull it forwards and
swivel it out to the side.
Fitting the partition and cover
1. Insert the cover for the fruit and ve-
getable container.
2. Insert the partition.
Cleaning and servicing en
2. Move the lock in the direction of
the arrow and loosen the pin
from the rear .
3. Push in the telescopic rail.
4. Push the telescopic rail backwards
above the rear pin and disengage .
3. Place the glass plate on the parti-
tion.
Telescopic rails
You can remove the telescopic rails
in order to clean them thoroughly.
Removing telescopic rails
1. Pull out the telescopic rail.
Installing telescopic rails
1. Place the extended telescopic rail
on the front pin and pull it forwards slightly to lock in place .
25
en Cleaning and servicing
2. Place the telescopic rail on the
rear pin and push the locking
mechanism back .
26
Troubleshooting en
Troubleshooting
Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-sales service. This will avoid unnecessary costs.
WARNING
Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained specialist
staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced by the
manufacturer, the manufacturer's Customer Service or a similarly qualified
person in order to prevent any risk.
Malfunctions
Fault Cause troubleshooting
The appliance is not working.
No displays light up.
The appliance is not cooling,
the displays and lighting
light up.
The LED lighting does not
work.
Do not remove the lamp
cover.
The refrigeration unit is
switching on more frequently and for longer.
The mains plug has not been
inserted properly.
Fuse has been tripped.
The power has failed. 1. Check whether the power is on.
Showroom mode is switched
on.
Different causes are possible.
The appliance door was
opened frequently.
The ventilation openings are
covered up.
▶
Check whether the mains plug for
the power cord is fully inserted into
the socket.
▶
Check the fuses.
2. Place ice packs (if available) on the
frozen food.
▶
"Carry out the appliance self-test."
→Page30
a Once the appliance self-test has
ended, the appliance switches to
normal operation.
▶
Call the after-sales service.
→"Customer Service", Page31
▶
Do not open appliance door unnecessarily.
▶
Remove any obstructions from in
front of the ventilation openings.
27
en Troubleshooting
Information on display panel
Fault Cause troubleshooting
or appears in the tem-
perature display.
The electronics have detected a fault.
▶
Call the after-sales service.
→"Customer Service", Page31
Temperature problem
Fault Cause troubleshooting
The temperature differs
greatly from the setting.
Cool-fresh compartment is
too warm or cold.
Different causes are possible.
Standard setting is too high
or too low, e.g. frost in coolfresh compartment.
1. "Switch off the appliance."
→Page17
2. "Switch the appliance back on after
fiveminutes." →Page16
‒ If the temperature is too
warm, check the temperature
again after a couple of hours.
‒ If the temperature is too cold,
check the temperature again
on the following day.
Note:The standard setting of the coolfresh compartment is preset at 0. Setting 0 corresponds to a temperature of
around 0°C. You can set the temperature in the cool-fresh compartment to
3settings warmer or colder.
A change in the standard setting will
affect the temperature in the refrigerator compartment and the freezer
compartment.
1. Press until the temperature
display flashes.
2. To change the setting, press / .
– Setting –3 corresponds to the
coldest setting.
– Setting +3 corresponds to the
warmest setting.
a The selected setting is saved after
one minute.
Noise
Fault Cause troubleshooting
Appliance has a humming
sound.
28
Not a fault. A motor is running, e.g. refrigerating unit,
fan.
No action required.
Fault Cause troubleshooting
The appliance bubbles,
buzzes or gargles.
The appliance clicks. Not a fault. Motor, switches
Not a fault. Refrigerant flows
through the pipes.
No action required.
No action required.
or solenoid valves are
switching on or off.
The appliance makes
noises.
Fittings wobble or stick.
Bottles or containers are
touching.
Super function is switched
▶
Check the removable fittings and, if
required, replace these.
▶
Move the bottles or containers
away from each other.
No action required.
on.
Odours
Fault Cause troubleshooting
The appliance has an unpleasant smell.
Different causes are possible.
1. "Prepare the appliance for clean-
ing." →Page22
2. "Clean the appliance." →Page23
3. Clean all food packaging.
4. To prevent odours from forming,
store strong smelling food in airtight containers.
5. After 24hours, check whether
odours are still forming.
Troubleshooting en
29
en Storage and disposal
Conducting an appliance selftest
1. "Switch off the appliance."
→Page17
2. "Switch the appliance back on
after approx. fiveminutes."
→Page16
3. Within the first 10seconds after
switching on, press and hold
3 to 5seconds.
a The appliance self-test starts.
a While the appliance self-test is run-
ning, a long audible signal sounds.
a If, at the end of the appliance self-
test, two audible signals sound
and the temperature display indicates the set temperature, your appliance is OK. The appliance then
switches to normal operation.
a If, at the end of the appliance self-
test, five audible signals sound
and flashes for 10seconds,
inform the after-sales service.
Storage and disposal
Storage and disposal
Storage and disposal
You can find out here how to prepare
your appliance for storage. You will
also find out how to dispose of old
appliances.
Switching off the appliance
1. "Switch off the appliance."
→Page17
2. Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
3.
"Defrost the appliance." →Page22
4.
"Clean the appliance." →Page23
5. To ensure the ventilation inside the
appliance, leave the appliance
open.
Disposing of old appliance
Valuable raw materials can be reused by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
▶
Leave shelves and containers inside the appliance to prevent children from climbing in.
▶
Keep children away from the redundant appliance.
WARNING
Risk of fire!
If the tubes are damaged, flammable
refrigerant and harmful gases may
escape and ignite.
▶
Do not damage the tubes of the refrigerant circuit or the insulation.
1. Unplug the appliance from the
mains.
2. Cut through the power cord.
3. Dispose of the appliance in an en-
vironmentally friendly manner.
This appliance is labelled in accordance with European Directive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and recycling of used appliances as
applicable throughout the EU.
30
Customer Service en
Customer Service
Customer Service
Customer Service
If you have any queries, are unable to
rectify faults on the appliance yourself or if your appliance needs to be
repaired, contact Customer Service.
You can solve many problems yourself by consulting the information on
troubleshooting in these instructions
or on our website. If this is not the
case, contact our after-sales service.
We will always find an appropriate
solution and try to avoid unnecessary
visits being made by a Customer Service technician.
With any warranty claims, we will
make sure that your appliance is repaired by trained after-sales technicians using genuine spare parts, including after the manufacturer's warranty has expired.
For safety reasons repairs to the appliance should only be carried out by
trained specialist staff. The warranty
claim becomes void if repairs or interventions have been carried out by
persons not authorised by us for that
purpose or if our appliances have
been fitted with spare, supplementary
or accessory parts that were not
genuine parts and then resulted in a
defect.
Function-relevant genuine spare parts
according to the corresponding Ecodesign Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty applicable to the
location, the use of Customer Service
is free of charge. The minimum duration of the warranty (manufacturer's
warranty for private consumers) in
the European Economic Area is 2
years according to the terms of warranty applicable to the location. The
terms of warranty do not affect other
rights or claims held by yourself under local legislation.
Detailed information on the warranty
period and terms of warranty in your
country is available from our aftersales service, your retailer or on our
website.
If you contact Customer Service, you
will require the product number (ENr.) and the production number (FD)
of your appliance.
The contact details for Customer Service can be found in the enclosed
Customer Service directory or on our
website.
Product number (E-Nr.) and production number (FD)
You can find the product number (ENr.) and the production number (FD)
on the appliance's rating plate.
→"Appliance", Fig. 1 /7, Page14
Make a note of your appliance's details and the Customer Service telephone number to find them again
quickly.
Technical data
Technical data
Technical data
Refrigerant, cubic capacity and further technical specifications can be
found on the rating plate.
→"Appliance", Fig. 1 /7, Page14
More information about your model
can be found online at https://energylabel.bsh-group.com1. This web
address is linked to the official EU
EPREL product database. At the time
1
Only applies to countries in the European Economic Area
31
en Technical data
of printing its web address had not
yet been published. Please then follow the instructions on searching for
models. The model identifier is made
up of the characters before the slash
in the product number (E-Nr.) on the
rating plate. Alternatively you can
also find the model identifier in the
first line of the EU energy label.
32
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
*9001535911*
9001535911 (000508)
en
Loading...
