English
General Power Tool Safety Warnings
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges and moving parts. Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
English | 3
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.
Use of the power tool for operations different from those intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
|
Bosch Power Tools |
|
|
1 609 92A 41A | (7.12.17) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 4 Thursday, December 7, 2017 10:52 AM
4 | English
Safety Warnings for Jigsaws
Hold power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
Additional Safety and Working
Instructions
Keep hands away from the sawing range. Do not reach under the workpiece. Contact with the saw blade can lead to injuries.
Apply the machine to the workpiece only when switched on. Otherwise there is danger of kickback when the cutting tool jams in the workpiece.
Pay attention that the base plate rests securely on the material while sawing. A jammed saw blade can break or lead to kickback.
When the cut is completed, switch off the machine and then pull the saw blade out of the cut only after it has come to a standstill. In this manner you can avoid kickback and can place down the machine securely.
Use only undamaged saw blades that are in perfect condition. Bent or dull saw blades can break, negatively influence the cut, or lead to kickback.
Do not brake the saw blade to a stop by applying side pressure after switching off. The saw blade can be damaged, break or cause kickback.
Use suitable detectors to determine if utility lines are hidden in the work area or call the local utility company for assistance. Contact with electric lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes property damage or may cause an electric shock.
Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure than by hand.
Always wait until the machine has come to a complete stop before placing it down. The tool insert can jam and lead to loss of control over the power tool.
Before any work on the machine itself, pull the mains plug.
The saw blade should not be longer than required for the intended cut. Use a narrow saw blade when sawing tight curves.
Check the tight seating of the saw blade. A loose saw blade can fall out and lead to injuries.
When ejecting the saw blade, hold the machine in such a manner that no persons or animals can be injured by the ejected saw blade.
Dust from materials such as lead-containing coatings, some wood types, minerals and metal can be harmful to one’s health and cause allergic reactions, lead to respiratory infections and/or cancer. Materials containing asbestos may only be worked by specialists.
–As far as possible, use a dust extraction system suitable for the material.
–Provide for good ventilation of the working place.
–It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the materials to be worked.
Prevent dust accumulation at the workplace. Dust can easily ignite.
Observe correct mains voltage! The voltage of the power source must agree with the voltage specified on the nameplate of the machine. Power tools marked with 230 V can also be operated with 220 V.
The contact protector attached to the casing (see figure 15, page 52) prevents accidental touching of the saw blade during the working procedure and may not be removed.
Before sawing in wood, particle boards, building materials etc., check for foreign objects, such as nails, screws, etc. and remove them as required.
Plunge cuts may only be applied to soft materials, such as wood, gypsum board, etc. For plunge cuts, use only short saw blades.
The sliding shoe can prevent the surface from being scratched. The splinter guard can prevent fraying of the surface while sawing wood. Do not use the splinter guard for mitre cuts.
Adapt the settings of your power tool to the respective application. For example, reduce the stroke rate and orbital action when cutting metal or for tight curved cuts.
When working small or thin work pieces, always use a sturdy support or a saw table (accessory).
In extreme conditions, always use dust extraction as far as possible. Blow out ventilation slots frequently and install a portable residual current device (PRCD).
When working metals, conductive dust can settle in the interior of the power tool. The total insulation of the power tool can be impaired.
Products sold in GB only: Your product is fitted with a BS 1363/A approved electric plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place by an authorised customer service agent. The replacement plug should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible shock hazard and should never be inserted into a mains socket elsewhere.
Products sold in AUS and NZ only: Use a residual current device (RCD) with a rated residual current of 30 mA or less.
|
1 609 92A 41A | (7.12.17) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 5 Thursday, December 7, 2017 10:52 AM
Symbols
The following symbols are important for reading and understanding the operating instructions. Please take note of the symbols and their meaning. The correct interpretation of the symbols will help you to use the machine in a better and safer manner.
Symbol |
Meaning |
|
GST 150 CE: Jigsaw with constant |
|
electronic control |
|
Grey-marked area: Handle |
|
(insulated gripping surface) |
|
GST 150 BCE: Jigsaw with constant |
|
electronic and bow handle |
|
Grey-marked area: Handle |
|
(insulated gripping surface) |
|
Read all safety warnings and all |
|
instructions |
|
Before any work on the machine |
|
itself, pull the mains plug from the |
|
socket outlet |
|
Wear protective gloves |
|
Additional information |
|
Movement direction |
|
Reaction direction |
|
Next step of action |
|
Sawdust blower device |
|
Extraction |
|
Mitre/Bevel Angle |
English | 5
Symbol |
Meaning |
|
Low stroke rate/speed |
|
High stroke rate/speed |
|
Switching On |
|
Switching Off |
|
On/Off switch lock-on |
|
Prohibited action |
|
Correct result |
|
Saw with moderate pressure in |
|
order to achieve optimal and precise |
|
cutting results. |
|
When sawing metal, apply coolant/ |
|
lubricant alongside the cutting line |
|
Article number (10-digit) |
P1 |
Rated power input |
n0 |
Stroke rate at no-load |
|
Cutting depth, max. |
|
Wood |
|
Aluminium |
|
Metal |
|
Weight according to |
|
EPTA-Procedure 01:2014 |
/ II |
Symbol for protection class II |
|
(completely insulated) |
Delivery Scope
Jigsaw, splinter guard and extraction kit.
Parallel guide, sliding shoe, application tools and other accessories shown or described are not part of the standard delivery scope.
A complete overview of accessories can be found in our accessories program.
|
Bosch Power Tools |
|
|
1 609 92A 41A | (7.12.17) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 6 Thursday, December 7, 2017 10:52 AM
6 | English
Intended Use
The machine is intended for making separating cuts and cutouts in wood, plastic, metal, ceramic plates and rubber while resting firmly on the workpiece. It is suitable for straight and curved cuts with mitre angles to 45°. The saw blade recommendations are to be observed.
Technical Data
The technical data of the machine are listed in the table on page 42.
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Mounting and Operation
The following table indicates the action objectives for mounting and operation of the power tool. The instructions for each action objective are shown aside. Depending on the type of application, various instruction combinations are required. Observe the safety instructions.
Action |
Figure |
Please observe |
Page |
Inserting the Saw Blade |
1 |
|
43 |
Ejecting the Saw Blade |
2 |
|
43 |
Switching on the sawdust blower |
3 |
|
43 |
device |
|
|
|
Connecting the dust extraction |
4 |
|
44 – 45 |
Adjusting the Cutting Angle |
5 |
|
45 – 46 |
Mounting the sliding shoe |
6 |
|
47 |
Mounting the splinter guard |
7 |
|
47 |
Orbital Action Settings |
8 |
|
48 |
Adjusting the stroke rate preselec- |
9 |
|
48 |
tion |
|
|
|
1 609 92A 41A | (7.12.17) |
|
|
Bosch Power Tools |
OBJ_BUCH-1088-004.book Page 7 Thursday, December 7, 2017 10:52 AM
|
|
|
English | 7 |
|
|
|
|
Action |
Figure |
Please observe |
Page |
Switching On and Off |
10 |
|
49 |
|
|
|
|
Guide the power tool toward the |
11 |
50 |
workpiece only when switched on |
|
|
Lubrication when cutting metal |
12 |
50 |
Plunge Cutting |
13 |
50 – 51 |
Mounting and use of the parallel |
14 |
51 – 52 |
guide |
|
|
Selecting Accessories |
– |
54 – 55 |
Maintenance and Cleaning
For safe and proper working, always keep the machine and the ventilation slots as well as the tool holder clean.
If the replacement of the supply cord is necessary, this has to be done by Bosch or an authorized Bosch service agent in order to avoid a safety hazard.
Clean the saw blade holder regularly. For this, remove the saw blade from the machine and lightly tap out the machine on a level surface.
Regularly spray penetrating oil onto the saw blade holder (see figure 16, page 53).
Check the guide roller regularly. If worn, it must be replaced through an authorised Bosch after-sales service agent.
Lubricate the guide roller occasionally with a drop of oil (see figure 17, page 53).
After-sales Service and Application
Service
Our after-sales service responds to your questions concerning maintenance and repair of your product as well as spare parts. Exploded views and information on spare parts can also be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions concerning our products and their accessories.
In all correspondence and spare parts orders, please always include the 10-digit article number given on the nameplate of the product.
Cambodia
Robert Bosch (Cambodia) Co., Ltd
Unit 8BC, GT Tower, 08th Floor, Street 169, Czechoslovakia Blvd, Sangkat Veal Vong Khan 7 Makara, Phnom Penh
VAT TIN: 100 169 511
Tel.: +855 23 900 685
Tel.: +855 23 900 660 www.bosch.com.kh
People’s Republic of China China Mainland
Bosch Power Tools (China) Co., Ltd. 567, Bin Kang Road
Bin Jiang District 310052 Hangzhou, P. R. China Tel.: 4008268484
Fax: (0571) 87774502
E-Mail: contact.ptcn@cn.bosch.com www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Co. Ltd.
21st Floor, 625 King’s Road North Point, Hong Kong
Customer Service Hotline: +852 2101 0235 Fax: +852 2590 9762
E-Mail: info@hk.bosch.com www.bosch-pt.com.hk
Bosch Power Tools |
1 609 92A 41A | (7.12.17) |
OBJ_BUCH-1088-004.book Page 8 Thursday, December 7, 2017 10:52 AM
8 | English
India
Bosch Service Center
69, Habibullah Road, (Next to PSBB School), T. Nagar Chennai – 600077
Phone: (044) 64561816
Bosch Service Center Rishyamook
85A, Panchkuin Road
New Delhi – 110001
Phone: (011) 43166190
Bosch Service Center
79, Crystal Bldg., Dr. Annie Besant Road, Worli Mumbai – 400018
Phone: (022) 39569936 / (022 )39569959 / (022) 39569967 / (022) 24952071
Indonesia
PT Robert Bosch
Palma Tower 10th Floor
Jalan RA Kartini II-S Kaveling 6
Pondok Pinang, Kebayoran Lama
Jakarta Selatan 12310
Tel.: (21) 3005-5800
www.bosch-pt.co.id
Malaysia
Robert Bosch Sdn. Bhd.(220975-V) PT/SMY No. 8A, Jalan 13/6
46200 Petaling Jaya Selangor
Tel.: (03) 79663194 Toll-Free: 1800 880188 Fax: (03) 79583838
E-Mail: kiathoe.chong@my.bosch.com www.bosch-pt.com.my
Pakistan
Robert Bosch Middle East FZE – Pakistan Liaison Office 2nd Floor Plaza # 10, CCA Block, DHA Phase 5 Lahore, 54810
Phone: +92(303)4444311 Email: Faisal.Khan@bosch.com
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers, 3rd Avenue corner 31st Street, Fort Bonifacio, Global City, 1634 Taguig City
Tel.: (632) 8703871
Fax: (632) 8703870 www.bosch-pt.com.ph
Singapore
Powerwell Service Centre Ptd Ltd
Bosch Authorised Service Centre (Power Tools) 4012 Ang Mo Kio Ave 10, #01-02 TECHplace Singapore 569628
Tel.: 6452 1770
Fax: 6452 1760
E-Mail: ask@powerwellsc.com www.powerwellsc.com www.bosch-pt.com.sg
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: 02 6393111
Fax: 02 2384783
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501
www.bosch.co.th
Bosch Service – Training Centre
La Salle Tower Ground Floor Unit No.2
10/11 La Salle Moo 16
Srinakharin Road
Bangkaew, Bang Plee
Samutprakarn 10540
Tel.: 02 7587555
Fax: 02 7587525
Vietnam
Branch of Bosch Vietnam Co., Ltd in HCMC Floor 10, 194 Golden Building
473 Dien Bien Phu Street
Ward 25, Binh Thanh District, Ho Chi Minh City Tel.: (08) 6258 3690
Fax: (08) 6258 3692 Hotline: (08) 6250 8555 www.bosch-pt.com.vn
Armenia, Azerbaijan, Georgia, Kyrgyzstan, Mongolia, Tajikistan, Turkmenistan, Uzbekistan
TOO “Robert Bosch” Power Tools, After Sales Service Rayimbek Ave., 169/1
050050, Almaty, Kazakhstan
Service Email: service.pt.ka@bosch.com
Official Website: www.bosch.com, www.bosch-pt.com
Bahrain
Hatem Al Juffali Technical Equipment Establishment. Kingdom of Bahrain, Setra Highway, Al Aker Area Phone: +966126971777-311
Fax: +97317704257
Email: h.berjas@eajb.com.sa
Egypt
Unimar
20 Markaz kadmat
El tagmoa EL Aoul – New Cairo Phone: +20 2224 76091-95 Phone: +20 2224 78072-73 Fax: +20 2224 78075
Email: adelzaki@unimaregypt.com
Iran
Robert Bosch Iran
3rd Floor, No 3, Maadiran Building Aftab St., Khodami St., Vanak Sq. Tehran 1994834571
Phone: +982186092057
|
1 609 92A 41A | (7.12.17) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 9 Thursday, December 7, 2017 10:52 AM
Iraq
Sahba Technology Group
Al Muthana airport road
Baghdad
Phone: +9647901906953
Phone Dubai: +97143973851
Email: bosch@sahbatechnology.com
Jordan
Roots Arabia – Jordan
Nasser Bin Jameel street, Building 37 Al Rabiah 11194 Amman
Phone: +962 6 5545778 Email: bosch@rootsjordan.com
Kuwait
Al Qurain Automotive Trading Company
Shuwaikh Industrial Area, Block 1, Plot 16, Street 3rd P.O. Box 164 – Safat 13002
Phone: 24810844 Fax: 24810879
E-mail: josephkr@aaalmutawa.com
Lebanon
Tehini Hana & Co. S.A.R.L.
P.O. Box 90-449
Jdeideh
Dora-Beirut
Phone: +9611255211
Email: service-pt@tehini-hana.com
Libya
El Naser for Workshop Tools
Swanee Road, Alfalah Area
Tripoli
Phone: +218 21 4811184
Oman
Malatan Trading & Contracting LLC
P.O. Box 131
Ruwi, 112 Sultanate of Oman
Phone: +968 99886794
Email: malatanpowertools@malatan.net
Qatar
International Construction Solutions W L L P. O. Box 51, Doha
Phone: +974 40065458 Fax: +974 4453 8585 Email: csd@icsdoha.com
Saudi Arabia
Juffali Technical Equipment Co. (JTECO) Kilo 14, Madinah Road, Al Bawadi District Jeddah 21431
Phone: +966 2 6672222 Ext. 1528 Fax: +966 2 6676308
Email: roland@eajb.com.sa
English | 9
Syria
Dallal Establishment for Power Tools
P.O. Box 1030
Aleppo
Phone: +963212116083
Email: rita.dallal@hotmail.com
United Arab Emirates
Central Motors & Equipment LLC, P.O. Box 1984 Al-Wahda Street – Old Sana Building
Sharjah
Phone: +971 6 593 2777 Fax: +971 6 533 2269
Email: powertools@centralmotors.ae
Yemen
Abualrejal Trading Corporation
Sana’a Zubiery St. Front to new Parliament Building Phone: +967-1-202010
Fax: +967-1-279029
Email: tech-tools@abualrejal.com
Ethiopia
Forever plc
Kebele 2,754, BP 4806,
Addis Ababa
Phone: +251 111 560 600
Email: foreverplc@ethionet.et
Ghana
C.WOERMANN LTD.
Nsawam Road/Avenor Junction, P.O. Box 1779
Accra
Phone: +233 302 225 141
Kenya
Robert Bosch East Africa Ltd
Mpaka Road P.O. Box 856
00606 Nairobi
Nigeria
Robert Bosch Nigeria Ltd.
52 – 54 Isaac John Street P.O. Box
GRA Ikeja – Lagos
Republic of South Africa
Customer service
Hotline: (011) 6519600
Gauteng – BSC Service Centre
35 Roper Street, New Centre Johannesburg
Tel.: (011) 4939375
Fax: (011) 4930126 E-Mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street Pinetown
Tel.: (031) 7012120
Fax: (031) 7012446
E-Mail: bsc.dur@za.bosch.com
|
Bosch Power Tools |
|
|
1 609 92A 41A | (7.12.17) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 10 Thursday, December 7, 2017 10:52 AM
10 |
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: (021) 5512577
Fax: (021) 5513223
E-Mail: bsc@zsd.co.za
Bosch Headquarters
Midrand, Gauteng
Tel.: (011) 6519600
Fax: (011) 6519880
E-Mail: rbsa-hq.pts@za.bosch.com
Tanzania
Diesel & Autoelectric Service Ltd.
117 Nyerere Rd., P.O. Box 70839
Vingunguti 12109, Dar Es Salaam
Phone: +255 222 861 793/794
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch-pt.com.au
www.bosch-pt.co.nz
Disposal
The machine, accessories and packaging should be sorted for environmental-friendly recycling.
Do not dispose of power tools into household waste!
Subject to change without notice.
!
" "
事故。
气体。
会使操作者失去对工具的控制。
果你身体接地会增加电击危险。
动工具将增加电击危险。
件。
软线。
用剩余电流动作保护器RCD RCD
疏忽会导致严重人身伤害。
如适当条件下使用防尘面具、防滑安全鞋、安全帽、 听力防护等装置能减少人身伤害。
/
留在电动工具旋转零件上的扳手或钥匙会导致人身伤 害。
样在意外情况下能很好地控制电动工具。
会卷入运动部件中。
引起的危险。
|
1 609 92A 41A | (7.12.17) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 11 Thursday, December 7, 2017 10:52 AM
选用适当设计的电动工具会使你工作更有效、更安 全。
须进行修理。
须从电源上拔掉插头和/
的。
护不良的电动工具引发。
的刀具不易卡住而且容易控制。
些与其用途不符的操作可能会导致危险。
进行修理。
电导线会使工具外露的金属零件带电从而使操作者受 到电击。
| 11
用手持握工件更牢固。
具。
出插头。
害您。
刀伤害旁人或动物。
和/
–P2
标示的电压一致。
15 52
|
|
|
|
|
|
|
||
|
||
|
||
|
|
|
|
PRCD |
||||||
|
|
|
|
|
|||||
|
|
|
|
||||||
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
Bosch Power Tools |
|
1 609 92A 41A | (7.12.17) |
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 12 Thursday, December 7, 2017 10:52 AM
12 |
GST 150 CE:
GST 150 BCE:
|
|
|
/ |
/
有理想和精确的锯割效果。
10 )
P1
n0
|
|
|
|
|
|
|
|
|
|
|
EPTA-Procedure 01:2014 |
/II |
II |
|
|
中。
|
1 609 92A 41A | (7.12.17) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 13 Thursday, December 7, 2017 10:52 AM
|
| 13 |
|
|
|
42 |
|
230 V |
|
|
45 |
|
|
|
|
|
所以会有不同的提示组合。请留心安全规章。
|
|
|
|
|
1 |
|
43 |
|
2 |
|
43 |
|
3 |
|
43 |
|
4 |
|
44 – 45 |
|
5 |
|
45 – 46 |
|
6 |
47 |
|
7 |
47 |
|
8 |
48 |
|
9 |
48 |
|
Bosch Power Tools |
|
|
1 609 92A 41A | (7.12.17) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 14 Thursday, December 7, 2017 10:52 AM
14 |
|
|
|
|
/ |
10 |
|
49 |
|
11 |
|
50 |
|
|
|
|
|
12 |
|
50 |
|
13 |
|
50 – 51 |
|
14 |
|
51 – 52 |
|
– |
|
54 – 55 |
确保能够有把握且安全地操作电动工具。
安全性能。
垢。
1653
导引轮。
1753
维护和备件的问题。以下的网页中有爆炸图和备件的 资料:
www.bosch-pt.com
10
滨江区滨康路567
3100524008268484(0571) 87774502contact.ptcn@cn.bosch.com www.bosch-pt.com.cn
· 625 21
+852 2101 0235+852 2590 9762info@hk.bosch.comwww.bosch-pt.com.hk
Robert Bosch Power Tools GmbH
·
70538 Stuttgart / GERMANY
70538 /
和废弃的包装材料。
!
询。
1 609 92A 41A | (7.12.17) |
Bosch Power Tools |
OBJ_BUCH-1088-004.book Page 15 Thursday, December 7, 2017 10:52 AM
| 15
" "
事故。
樣在意外情況下能很好地控制電動工具。
髮可能會捲入運動部件中。
引起的危險。
會使你失去對工具的控制。
未經改裝的插頭和相配的插座將減少電擊危險。
果你身體接地會增加電擊危險。
動工具將增加電擊危險。
件。
,
用剩餘電流動作保護器RCD RCD
須進行修理。
種防護性措施將減少工具意外起動的危險。
的。
護不良的電動工具引發。
的刀具不易卡住而且容易控制。
些與其用途不符的操作可能會導致危險。
疏忽會導致嚴重人身傷害。
如適當條件下使用防塵面具、防滑安全鞋、安全帽、 聽力防護等裝置能減少人身傷害。
/
性。
操作者觸電。
|
Bosch Power Tools |
|
|
1 609 92A 41A | (7.12.17) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 16 Thursday, December 7, 2017 10:52 AM
16 |
果不小心碰觸了鋸片可能被割傷。
用手持握工件更牢固。
具。
出插頭。
害您。
刀傷害旁人或動物。
和/
–P2
標示的電壓一致。
15 52
等。潛鋸時只能使用短的鋸刀。
不可以使用防毛邊壓板。
的次數。
在前側加設漏電斷路器PRCD
GST 150 CE:
:
GST 150 BCE:
:
|
1 609 92A 41A | (7.12.17) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1088-004.book Page 17 Thursday, December 7, 2017 10:52 AM
|
|
|
|
|
|
|
|
/
/
有理想和精確的鋸割效果。
| 17
|
|
|
10 |
P1
n0
|
|
|
|
|
|
|
|
|
|
|
EPTA-Procedure 01:2014 |
/II |
II |
|
|
中。
45
42
230
|
Bosch Power Tools |
|
|
1 609 92A 41A | (7.12.17) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Loading...
