IMPORTANT SAFETY INSTRUCTIONS
3
WARNING – To reduce the risk of a
range top grease fire:
a) Never leave surface units unattended at
high settings. Boilovers cause smoking
and greasy spillovers that may ignite.
Heat oils slowly on low or medium
settings.
b) Always turn hood ON when cooking at
high or when flambéing food (i.e. Crepes
Suzette, Cherries Jubilee, Peppercorn
Beef Flambé).
c) Clean ventilating fans frequently. Grease
should not be allowed to accumulate on
fan or filter.
d) Use proper pan size. Always use
cookware appropriate for the size of the
surface element.
e) Do not place any objets on the snorkel.
They could fall down when the snorkel is
raised.
Caution: Grease left on filters can remelt
and move into the vent.
When children become old enough to
use the appliance, it is the legal
responsibility of the parents or legal
guardians to ensure that they are
instructed in safe practices by qualified
persons.
WARNING – To reduce the risk of in-
jury to persons in the event of a cooktop
grease fire, observe the following:
a) Smother flames with a close-fitting lid,
cookie sheet, or metal tray, then turn off
the burner. Be careful to prevent burns. If
the flames do not go out immediately,
Evacuate and call the fire department.
b) Never pick up a flaming pan.
You may be burned.
c) Do not use water, including wet dish
cloths or towels. A violent steam
explosion will result.
d) Use an extinguisher only if:
1) Yo u know you have a Class ABC
extinguisher, and you already know
how to operate it.
2) The fire is small and contained in the
area where it started.
3) The fire department is being called.
4) Yo u can fight the fire with your back
to an exit.
WARNING: Whenever possible, do
not operate blower during a cooktop fire.
However, do not reach through fire to turn
off blower.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
READ AND SAVE THESE INSTRUCTIONS
4
FEATURES OPERATION
For Best Results
❑ Turn the blower on before starting to
cook.
❑ A higher heat setting may be needed
when the downdraft is in operation.
❑ Use a rear burner when browning or pan
frying meat.
❑ Open a window or inside door slightly.
❑ Clean the filters and the wall behind the
filters frequently.
❑ For Gas Cooktops, a lower blower
speed should be used if:
•the gas flame is being distorted by
the air movement.
•the burner continually sparks (clicks).
•the burner flame repeatedly blows
out.
To Raise the Intake
❑ Press the control push-button once to
raise the intake.
❑ The intake will stop automatically at its
maximum height.
❑ The blower will automatically turn on to
the previously set blower speed.
To Set or Adjust Blower Speed
❑ Vary the blower speed as needed for the
food or the cooking method being used.
For example: greasy or pungent foods
require greater ventilation power than
boiling pasta. Turn the button clockwise
to adjust the speed.
Intake
The intake, when raised, captures and
channels the cooking odors, steam and
grease. The filters are located within the
intake.
UP/DOWN Button
The UP/DOWN Button is located on the top
right of the intake. Press the Button once to
raise or lower the intake. It is not necessary
to hold the Button.
Blower
The blower is the fan that draws the
cooking odors out of the house.
Blower Speed Control Switch
The blower speed control switch is located
on the right front of the intake. The intake
must be raised in order to use the control
switch. There are four blower speed
settings: Off, Low, Medium, and High. Slide
the switch to the desired setting.
Filters
The filters are located on the front of the
intake. They condense and trap the grease
in the air.
Filter Release Levers
The filter release levers are used to remove
the filters. Pull out on the lever then pull up
and out on the filter.
Intake To p Cap
UP/DOWN Button
Blower Speed Control Switch
The Thermador Universal Cook’n’Vent
®
takes the place of an overhead hood and
can be conveniently hidden away (lowered)
when not in use.
Filters (behind front panel)
Filter Release Lever
Blower (not shown)
There are five primary parts of the
downdraft system: the intake, the
UP/DOWN button, the blower, the blower
speed control switch, the filter and the filter
release lever.
•
0
•
1
•
2
•
3
Raised Intake
• 0
• 1
• 2
• 3
Snorkel Up/Down
Pushing the Snorkel
Up/Down moves the
intake up or down.
Pushing this button
while snorkel is raising or
lowering will stop
motion.
Pushing again will
reverse motion.
0Blower Off
1Low Blower Speed
2Medium Blower
Speed
3High Blower Speed
Pressing the High,
Medium, or Low Blower
Speed buttons will turn
on or change the
ventilator speed to the
corresponding button
selected.
5
CARE AND CLEANING
To Remove Filters
1. Pull out on lever.
2. Lift filter up and out.
3. Clean filters in the dishwasher or in
warm, sudsy water. See Care and
Cleaning Chart, next page, for further
details.
To Replace Filters
1. Place bottom of filter in grease trough.
2. Pull out on lever.
3. Press top of filter into place.
4. Release Lever.
To Clean the Intake and Grease
Troughs
Intake must be in the raised position to
clean.
1. Turn off the blower.
2. Remove filters.
3. Clean intake and grease troughs with
general household degreaser spray or
cleaner.
4. Rinse and dry.
5. Replace filters.
❑ Always use the mildest cleaner that will do the job. Use clean, soft cloths, sponges or
paper towels.
❑ Rub stainless steel finishes in the direction of the grain. Wipe area dry to avoid water
marks.
❑ After cleaning, place all parts in their proper positions before using.
The cleaners recommended below indicate a type and do not constitute an endorsement. Use all products according to package directions.
A Anodized Top cap is not removable. Wash top and underside with hot sudsy
Aluminum water. Rinse and wipe dry or apply Fantastic®or Formula 409®first to
Top Caps for a clean sponge or paper towel and wipe clean.
Stainless DO NOT USE powdered cleansers or steel wool pads.
B Aluminum Clean filters in the dishwasher or by agitating in sudsy water. Ensure
Mesh Filters that there is no soil trapped in the fine mesh. Dry the filters before
reinstalling them.
C Plastic DO NOT REMOVE push-button or control knob. Wipe with a moist
Controls soapy sponge. Rinse and dry.
D Painted Wash top and underside with hot sudsy water. Rinse and wipe dry or
Top Cap for apply Fantastic®or Formula 409®first to a clean sponge or paper
Black/White towel and wipe clean.
DO NOT USE powdered cleansers or steel wool pads.
E StainlessWipe grease accumulation with a paper towel or sponge. Scrape
Steel Parts heavy buildup with a plastic spatula. Clean with a soapy sponge;
rinse and dry.
Always wipe or rub with grain. Wipe with Fantastic®or Formula 409
®
sprayed onto a paper towel. If grease buildup is heavy, several
appliacations may be necessary.
Polish with Stainless Steel Magic®and a soft cloth. Remove water
spots with a cloth dampened with white vinegar. Use Cameo
Aluminum and Stainless Steel Cleaner®to remove heat discoloration.
Carbon Filter
A carbon filter is used only with a
recirculation unit. Carbon filters are
disposable; They cannot be cleaned or
reused. With normal use (1 to 2hours per
day), the carbon filter should be replaced
once per year.
The replacement active carbon filters are
available by calling Thermador Customer
Service or by ordering online at
Thermador.com. Use Thermador-supplied
filters only. Filters are priced and shipped in
sets of 2 to allow replacement of both filters
at the same time.
OPERATION
To Lower the Intake
❑ Press the control push-button once.
Note: The blower will turn off when the
intake is lowered if operating when the
control push-button is pressed.
If Intake Stops
❑ Locate and remove obstruction.
❑ Press control button to raise intake.
❑ Press control button again to lower
intake.
CARE AND CLEANING
The efficiency of the downdraft ventilation
system depends on the cleanliness of the
intake and filters. The frequency of cleaning
depends on the amount and type of
cooking.
❑ Do not use the ventilating system
without the filters in place or with greaseladen filters or surfaces.
WARNING To avoid risk of fire
and explosion do not use flammable
liquids or solvents.
Always unplug or disconnect the appliance from the power supply before servicing.
