WARRANTY
Terms and conditions
BOS MTB offers warranty on its products on the following terms :
BOS MTB guarantees to the original purchaser that the BOS product for which they
received this warranty is free from defects in material and workmanship for one year
from the date of original retail purchase. A proof a purchase will be asked for any
warranty claim. This warranty is not transferable to a subsequent purchaser.
Wear and tear parts such as dust seals, Oring, bushings, rear shock mouting
hardwares, stanchions, threaded parts and bolts are not covered under this warranty.
Terms
This warranty is subject to legal jurisdictional or warranty rights of the country where it
has been originally purchased, which will prevail if different from the terms herein
listed.
Limits
BOS MTB cannot be liable for any loss, inconvenience damages, whether direct,
incidental, consequential, resulting from the use of its products, local legislation
prevailing.
Warranty exclusions
This warranty does not cover the following cases:
• Damage to products resulting from improper assembly other than listed below
• Products that have been modified by the owner or a third party
• Improper use
• Damages resulting from an accident, crash under any circumstances
• Invalid servicing procedures and servicing time frame not respected
• Replacement of the original parts by parts from others manufacturers
• Products whose serial numbers has been altered, defaced or removed.
Warranty procedure
The owner should always refer to an approved BOS center for any warranty claim. A
proof a purchase is compulsory for any warranty claim. Otherwise the warranty claim
will not be considered. Always contact BOS MTB warranty department before returning
any products that may fall under this warranty. If “the faulty parts” do not fall under
warranty, the customer will be charged for any costs in respect with warranty such as
transport and package back and forth.
1. INTRODUCTION
Thank you for purchasing a Bos KIRK shock. Your shock has been assembled specifically for one bike - obviously
yours ! - which means that the internal valving and the air chamber volume are settled for your bike. The adequate
mounting kit is also provided with the shock.
CAUTION
Never try to disassemble your shock. Limit yourself to the instructions given in this manual.
This shock is pressurized, for your own safety, do not try to open it.
Contact an authorized service center for any maintenance operation.
2. ASSEMBLY
Your KIRK shock features adequate mounting kits for the bike mentionned while ordering.
Check the mounting way
by refering to the compatibility table, available on bos mtb website : http://www.bosmtb.com.
Refer to the bike manual
to follow the specific shock mounting procedures of your bike.
3. SETTINGS
3.1. AIR PRESSURE
Before using the shock, you must set up the air pressure, depending on your weight.
The air pressure is not only related to your weight but also to your bike’s rear suspension geometry.
Refer to the compatibility table on Bos mtb’s website, in the download area :
http://www.bosmtb.com to check the correct air pressure, related to your body weight and your bike..
Connect a pump equipped with a precise manometer to the Schrader valve located on the side of the upper part of
the body, and inflate at the right pressure.
air valve
