Bos DEVILLE AM User Manual

Model year 2014

USER MANUAL

WARRANTY

Terms and conditions
BOS MTB offers warranty on its products on the following terms:
BOS MTB guarantees to the original purchaser that the BOS product for which
they received this warranty is free from defects in material and workmanship
for one year from the date of original retail purchase. A proof a purchase will
be asked for any warranty claim. This warranty is not transferable to a
subsequent purchaser.
Wear and tear parts such as dust seals, Oring, bushings, rear shock mouting
hardwares, stanchions, threaded parts and bolts are not covered under this
warranty.

Terms
This warranty is subject to legal jurisdictional or warranty rights of the country
where it has been originally purchased, which will prevail if different from the
terms herein listed.

Limits
BOS MTB cannot be liable for any loss, inconvenience damages, whether
direct, incidental, consequential, resulting from the use of its products, local
legislation prevailing.

Warranty exclusions
This warranty does not cover the following cases:

• Damage to products resulting from improper assembly other than listed

below

• Products that have been modified by the owner or a third party

• Improper use

• Damages resulting from an accident, crash under any circumstances

• Invalid servicing procedures and servicing time frame not respected

• Replacement of the original parts by parts from others manufacturers

• Products whose serial numbers has been altered, defaced or removed.

Warranty procedure
The owner should always refer to an approved BOS center for any warranty
claim. A proof a purchase is compulsory for any warranty claim. Otherwise the
warranty claim will not be considered. Always contact BOS MTB warranty
department before returning any products that may fall under this warranty.

If “the faulty parts” do not fall under warranty, the customer will be charged

for any costs in respect with warranty such as transport and package back and
forth.

Settings & Maintenance

> > >

1. Assembly

Caution :

Never attempt to remove or replace the steerer or upper tubes independently from the crown. Modifying the integrated
crown, steerer or upper tubes can cause an assembly failure, resulting in a loss of control of the bicycle and serious injury.

Important :

The torque of the QR screw (A) is originally set between 4 and 4.5N.m. It may be useful to check it regularly.

(1)

(2)

(3)

(1)

(A)

Fitting your Deville AM onto your bike requires care and attention. For your safety, please follow these instructions.

1.1 The steerer tube

Before cutting the steerer tube, first take some measurements: height of the headset, length of the headtube of the frame, height
of the stem and then add 5 to 10mm.

Calculate the length as below:
Add the length of the headtube of the frame to the height of the headset and to the height of the stem plus to 5 to 10mm.

1.2 Installing the front wheel: 20mm or 15mm axle

To assemble the front wheel, follow this procedure:

1. Open the quick release on right side of the fork (1).

2. Open the folding lever (2)

3. Unscrew the axle and remove it (3).

4. Install the wheel.

5. Insert the axle and screw it completely. Fold the lever. Close the quick release.

To disassemble the wheel, proceed in the opposite way.

1.3. Mounting the 15mm axle adapter sleeve

The transition from the 20mm to the 15mm axle requires the mounting of an adapter sleeve on the left leg.
To assemble the adapter, proceed as follows:

1. Hand-tighten the 15mm adapter (1).

2. Tighten up to the torque 12N.m.

3. Refer to section 1.2 for the 15mm axle wheel mounting.
