Replaces BN-RCUTB, November 2015
REMOTE INDOOR COMPRESSOR UNITS
Model SRN | ZRN
Technical Guide
BNRCUTB
July 2016
heatcraftrpd.com
TABLE OF CONTENTS
Nomenclature ..............................................................................................................................................................................................................................2
SRN Models ...............................................................................................................................................................................................................................3-8
Features & Benets ....................................................................................................................................................................................................................3
Options ..........................................................................................................................................................................................................................................4
Performance Data
Medium Temperature
R-404A/R-507 ..................................................................................................................................................................................................................5
R-407A ...............................................................................................................................................................................................................................5
R-407C ...............................................................................................................................................................................................................................5
R-448A/449A ....................................................................................................................................................................................................................5
Low Temperature
R-404A/R-507...................................................................................................................................................................................................................6
R-407A ...............................................................................................................................................................................................................................6
R-407C ...............................................................................................................................................................................................................................7
R-407F ................................................................................................................................................................................................................................7
R-448A/449A ...................................................................................................................................................................................................................7
Electrical Data ..............................................................................................................................................................................................................................8
Medium Temperature (R-404A/R-507) ...................................................................................................................................................................... 6
Low Temperature (R-404A/R-507)...............................................................................................................................................................................9
Physical Data ............................................................................................................................................................................................................................ 10
ZRN Models ............................................................................................................................................................................................................................... 10
Features & Benets ................................................................................................................................................................................................................. 11
Options ....................................................................................................................................................................................................................................... 12
Performance Data .............................................................................................................................................................................................................13-15
Extended Temperature
R-404A/R-507 ............................................................................................................................................................................................................... 13
R-407A ............................................................................................................................................................................................................................ 13
R-407C ............................................................................................................................................................................................................................ 13
R-448A/449A ................................................................................................................................................................................................................. 13
Medium Temperature
R-404A/R-507................................................................................................................................................................................................................ 14
R-407C ............................................................................................................................................................................................................................14
R-448A/449A ................................................................................................................................................................................................................ 14
Low Temperature
R-404A/R-507................................................................................................................................................................................................................ 15
R-407A ............................................................................................................................................................................................................................ 15
R-407C ............................................................................................................................................................................................................................15
R-448A/449A ................................................................................................................................................................................................................ 15
Electrical Data .....................................................................................................................................................................................................................16-17
Low Temperature (R-404A/R-507)............................................................................................................................................................................ 17
Medium & Extended Temperature (R-404A/R-507) ...........................................................................................................................................18
Physical Data ............................................................................................................................................................................................................................ 18
Dimensional Drawing (Figures A. & Figures B.) ............................................................................................................................................................. 19
NOMENCLATURE - SRN MODELS
S R N 0090 M 6 C
Compressor Model Application Model Size Temp. Refrigerant Voltage
S = SemiHermetic
Reciprocating
R = Remote N = Indoor 0090 - 2200 L = Low
M = Medium
6 = R–404A/507
(R-407A/407C/407F,
R-448A/449A
available on select
models)
B = 208/230/1/60
G = 230/1/60
C = 208/230/3/60
D = 460/3/60
E = 575/3/60
NOMENCLATURE - ZRN MODELS
Z R N 020 M 6 C
Compressor
Z = Scroll R = Remote N = Indoor 020 - 060
2
Model Application Model Size Temp. Refrigerant Voltage
or
0650-1500
X = Extended
L = Low
M = Medium
6 = R–404A/507
(R-407A/407C/407F,
R-448A/449A
available on select
models)
© 2016 Heatcraft Refrigeration Products, LLC
B = 208/230/1/60
C = 208/230/3/60
D = 460/3/60
FEATURES & BENEFITS -SRN
The indoor remote compressor unit is specically designed for use in supermarket, restaurant, warehouse and other
commercial and industrial applications. The design focuses on ease of installation and maintenance along with the
exibility to t most application requirements.
Construction
• Spacious, pre-painted electrical box
• Fixed low pressure switch (adjustable on low temp models)
• Fixed high pressure switch
• Pump down switch
• 230V control circuit transformer on 460V units
• Sealed liquid line lter drier and sight glass
Serviceability
• Easy access refrigerant piping
• Captive door fasteners
• Single electrical connection location
• Removable electrical box provides convenient front access to the oil pump
and compressor
Quality
• Pre-bent tubing reduces the possibility of leaks
• Shipped with dry nitrogen charge
• Heavy duty base plate
• Non-metallic conduit on all wiring runs
Components
• Semi-hermetic reciprocating compressors
• Compressor contractor and control circuit fusing
• Oil pressure switch (when required)
• Rigid mounted compressors (models 0090-0400)
• Spring mounted compressors with suction and discharge vibration
eliminators (models 0499 and above)
• Compressor head cooling fan (when required)
• Compressor solid state protection model (on units with 4D compressors)
NOTES: SRN pictured with optional suction accumulator,
liquid solenoid valve, sealed suction lter and
head pressure valve
N.Y. MEA
3
OPTIONS - SRN Models
Factory-Installed Options
• Dual pressure switch
• Oil separator with discharge check valve and oil return hand valve
• Compressor and control circuit breaker
• Two tier rack
• Suction accumulator
• Sealed suction lter
• Replaceable core suction lter (0300-2200)
• Replaceable core liquid lter (0300-2200)
• Liquid line solenoid valve
• Spring mounted compressors with suction and discharge vibration eliminators (models 0090 to 0400)
• Crankcase heater
• Air defrost timer
• Electric defrost kit. Kit includes timer, evaporator fan contactor, defrost heater contactor(s), lockout relay
and terminal block
• Remote load fusing for electric defrost kit. Includes evaporator fan motor and defrost heater fuses
• Fixed head pressure control valve
• Beacon II™ compatible (contact factory)
• Demand cooling for low temperature (contact factory)
4
PERFORMANCE DATA - SRN Models
R-404A/R-507 Models - Medium Temperature
Capacity BTUH
Model Compressor
15°F 20°F 25°F 30°F 35°F 40°F
SRN0090M6 KARA-010E 6,910 7,780 8,880 - - -
SRN0199M6 KAKA-020E 11,450 12,850 14,150 - - -
SRN0200M6 ERCA-021E 14,470 16,310 18,480 - - -
SRN0310M6 ERFA-031E 21,380 24,080 27,080 - - -
SRN0500M6 2DC3R53KE 33,050 37,370 42,030 47,090 52,600 58,540
120°F Condensing Temperature, 8°F Subcooling
Suction Temperature
R-407A/R-407F Models - Medium Temperature
Capacity BTUH
Model Compressor
15°F 20°F 25°F 30°F 35°F 40°F
SRN0500M6 2DC3R53KE 31,640 36,160 41,240 46,900 53,140 59,990
Suction Temperature
120°F Condensing Temperature, 8°F Subcooling
R-407C Models - Medium Temperature
Capacity BTUH
Model Compressor
15°F 20°F 25°F 30°F 35°F 40°F
SRN0500M6 2DC3R53KE 30,270 34,850 40,040 45,850 52,320 59,450
120°F Condensing Temperature, 8°F Subcooling
Suction Temperature
R-448A/R-449A Models - Medium Temperature
Capacity BTUH
Model Compressor
15°F 20°F 25°F 30°F 35°F 40°F
SRN0500M6 2DC3R53KE 32,750 37,320 42,410 48,030 54,190 60,880
120°F Condensing Temperature, 8°F Subcooling
Suction Temperature
For additional capacity sizes and options, please contact the factory at 800-537-7775
5
R-404A/R-507 Models - Low Temperature
Capacity BTUH
Model Compressor
-40°F -30°F -25°F -20°F -10°F 0°F
SRN0150L6 KALA-016E 2,790 4,620 5,510 6,470 8,480 11,020
SRN0200L6 EADA-020E 3,240 5,130 6,150 7,310 9,960 13,250
SRN0210L6 EAVA-021E 3,720 5,610 6,890 8,270 11,550 15,370
SRN0310L6 LAHA-032E 5,300 8,790 10,920 13,250 18,660 24,910
SRN0310E6 LACA-032E 7,930 11,960 14,310 17,070 - -
SRN0311L6 2DF3F16KE 9,250 13,760 16,320 19,080 25,330 32,860
SRN0400L6 2DL3F20KE 11,670 16,890 19,820 23,110 30,530 39,330
SRN0599L6 2DA3F23KE 13,860 19,840 23,110 26,710 34,870 44,630
SRN0600L6 2DB3F25KE 14,580 21,030 24,700 28,620 37,520 48,120
SRN0601L6 3DA3F28KE 17,190 24,080 27,980 32,330 42,080 53,640
SRN0750L6 3DB3F33KE 20,490 28,810 33,390 38,370 49,710 63,280
SRN0900L6 3DF3F40KE 25,140 35,020 40,700 46,850 60,950 77,800
SRN1000L6 3DS3F46KE 28,520 39,690 46,000 52,890 68,260 86,180
SRN1500L6 4DHNF63KE 39,900 55,780 64,020 72,720 92,330 116,390
SRN2200L6 4DJNF76KE 45,370 65,300 75,790 86,710 110,880 138,750
Suction Temperature
110°F Condensing Temperature, 6°F Subcooling
R-407A Models - Low Temperature
Capacity BTUH
Model Compressor
-40°F -30°F -25°F -20°F -10°F 0°F
SRN0311L6 2DF3F16KE 6,350 10,500 12,740 15,220 21,210 29,180
SRN0400L6 2DL3F20KE 7,850 12,520 15,330 18,460 25,730 34,370
SRN0599L6 2DA3F23KE 9,320 14,700 17,910 21,500 29,890 40,040
SRN0600L6 2DB3F25KE 10,600 16,300 19,560 23,170 31,720 42,410
SRN0601L6 3DA3F28KE 10,750 18,130 22,120 26,430 36,460 49,010
SRN0750L6 3DB3F33KE 13,890 22,970 27,720 32,790 44,390 58,830
SRN0900L6 3DF3F40KE 16,470 26,880 32,790 39,250 54,000 71,540
SRN1000L6 3DS3F46KE 18,040 29,630 35,930 42,740 58,350 77,450
SRN1500L6 4DHNF63KE 28,450 43,070 51,460 60,600 81,260 105,290
SRN2200L6 4DJNF76KE 40,290 53,630 63,060 74,260 101,740 135,580
110°F Condensing Temperature, 6°F Subcooling
Demand Cooling is REQUIRED
Suction Temperature
For additional capacity sizes and options, please contact the factory at 800-537-7775
6
R-407C Models - Low Temperature
Capacity BTUH
Model Compressor
Suction Temperature
-40°F -30°F -25°F -20°F -10°F 0°F
SRN0311L6 2DF3F16KE 5,590 9,760 11,950 14,300 19,820 26,920
SRN0400L6 2DL3F20KE 6,900 11,630 14,360 17,350 24,040 31,710
SRN0599L6 2DA3F23KE 8,180 13,640 16,770 20,190 27,930 36,930
SRN0600L6 2DB3F25KE 9,300 15,090 18,300 21,760 29,650 39,120
SRN0601L6 3DA3F28KE 9,490 16,140 19,990 24,240 34,060 45,810
SRN0750L6 3DB3F33KE 12,260 20,350 24,930 29,930 41,340 54,900
SRN0900L6 3DF3F40KE 14,550 23,900 29,630 36,000 50,440 66,870
SRN1000L6 3DS3F46KE 15,920 26,350 32,470 39,190 54,510 72,390
SRN1500L6 4DHNF63KE 24,210 37,800 45,660 54,340 74,550 99,190
SRN2200L6 4DJNF76KE 30,550 46,820 55,410 64,780 87,200 116,830
110°F Condensing Temperature, 6°F Subcooling. Demand Cooling is REQUIRED
R-407F Models - Low Temperature
Capacity BTUH
Model Compressor
-40°F -30°F -25°F -20°F -10°F 0°F
SRN0311L6 2DF3F16KE 6,350 10,500 12,740 15,220 21,210 29,180
SRN0400L6 2DL3F20KE 7,850 12,520 15,330 18,460 25,730 34,370
SRN0599L6 2DA3F23KE 9,320 14,700 17,910 21,500 29,890 40,040
SRN0600L6 2DB3F25KE 10,600 16,300 19,560 23,170 31,720 42,410
SRN0601L6 3DA3F28KE 10,750 18,130 22,120 26,430 36,460 49,010
SRN0750L6 3DB3F33KE 13,890 22,970 27,720 32,790 44,390 58,830
SRN0900L6 3DF3F40KE 16,470 26,880 32,790 39,250 54,000 71,540
SRN1000L6 3DS3F46KE 18,040 29,630 35,930 42,740 58,350 77,450
SRN1500L6 4DHNF63KE 28,450 43,070 51,460 60,600 81,260 105,290
SRN2200L6 4DJNF76KE 40,290 53,630 63,060 74,260 101,740 135,580
110°F Condensing Temperature, 6°F Subcooling. Demand Cooling is REQUIRED
Suction Temperature
R-448A/R-449A Models - Low Temperature
Capacity BTUH
Model Compressor
-40°F -30°F -25°F -20°F -10°F 0°F
SRN0311L6 2DF3F16KE 7,030 11,040 13,300 15,830 22,040 30,280
SRN0400L6 2DL3F20KE 8,700 13,180 16,010 19,210 26,740 35,700
SRN0599L6 2DA3F23KE 9,580 15,350 18,700 22,410 31,020 41,470
SRN0600L6 2DB3F25KE 10,360 16,930 20,420 24,180 32,880 43,850
SRN0601L6 3DA3F28KE 12,990 19,250 23,090 27,450 37,930 50,990
SRN0750L6 3DB3F33KE 15,370 24,180 28,950 34,120 46,090 61,010
SRN0900L6 3DF3F40KE 17,650 28,320 34,290 40,840 56,230 75,480
SRN1000L6 3DS3F46KE 19,370 31,060 37,610 44,810 61,690 82,800
SRN1500L6 4DHNF63KE 22,760 37,230 44,780 52,690 70,130 90,530
SRN2200L6 4DJNF76KE 33,120 54,660 65,850 77,770 10,5070 139,180
110°F Condensing Temperature, 6°F Subcooling. Demand Cooling is REQUIRED
For additional capacity sizes and options, please contact the factory at 800-537-7775
Suction Temperature
7
ELECTRICAL DATA - SRN MODELS
Medium Temperature
Low Amps High Amps
Model
Number
SRN0090M6B KARB-010E 208-230 1 60 6.4 40.0 15.0 15 15.0 15 10 (1) 3 - - - SRN0090M6C KARA-010E 208-230 3 60 3.8 27.0 15.0 15 15.0 15 10 (1) 3 - - - SRN0199M6B KAKB-021E 208-230 1 60 9.1 55.0 15.0 20 25.0 25 20 (1) 6 50.0 50 40 (1) 12
SRN0199M6C KAKA-020E 208-230 3 60 5.8 50.0 15.0 15 25.0 25 20 (1) 6 - - - SRN0200M6C ERCA-021E 208-230 3 60 7.9 46.0 15.0 15 25.0 25 20 (1) 6 - - - SRN0310M6G ERFB-031E 230 1 60 15.3 86.0 20.0 30 25.1 40 20 (1) 6 50.0 50 40 (1) 12
SRN0310M6C ERFA-031E 208-230 3 60 11.2 82.0 15.0 25 25.0 30 20 (1) 6 50.0 50 40 (1) 12
SRN0310M6D ERFA-031E 460 3 60 5.2 41.0 15.0 15 15.0 15 10 (1) 3 25.0 25 20 (1) 6
SRN0310M6E ERFA-031E 575 3 60 4.5 30.0 15.0 15 15.0 15 8 (1) 3 20.0 20 16 (1) 5
SRN0500M6C 2DC3R53KE 208-230 3 60 20.0 120.0 25.0 45 31.0 50 20 (1) 6 50.0 50 40 (1) 12
SRN0500M6D 2DC3R53KE 460 3 60 9.4 60.0 15.0 20 15.0 20 10 (1) 3 25.0 25 20 (1) 6
SRN0500M6E 2DC3R53KE 575 3 60 6.9 49.0 15.0 15 15.0 15 8 (1) 3 20.0 20 16 (1) 5
*Number of defrost heater contactors in parentheses
RLA - Rated Load Amps MCA - Minimum Circuit Ampacity
LRA - Locked Rotor Amps MOPD - Maximum Overcurrent Protection Device
For additional capacity sizes and options, please contact the factory at 800-537-7775
Compressor
Number
Power Supply Compressor
Volts Ph Hz RLA LRA MCA MOPD MCA MOPD Amps Amps
Beacon II™ or
Air Defrost
Electric
Defrost
Def.
Htr*
Evap.
Fan
Electric
Defrost
MCA MOPD
Def.
Htr*
Amps
Evap.
Fan
Amps
8
ELECTRICAL DATA - SRN MODELS
Low Temperature
Low Amps High Amps
Model
Number
SRN0150L6B KALB-015E 208-230 1 60 8.9 55.0 15.0 20 25.0 25 20 (1) 6 - - - SRN0150L6C KALA-016E 208-230 3 60 5.0 50.0 15.0 15 25.0 25 20 (1) 6 - - - SRN0150L6D KALA-016E 460 3 60 3.1 25.0 15.0 15 15.0 15 10 (1) 3 - - - SRN0200L6G EADB-021E 230 1 60 9.0 58.0 15.0 20 25.0 25 20 (1) 6 - - - SRN0200L6C EADA-020E 208-230 3 60 6.1 46.0 15.0 15 25.0 25 20 (1) 6 - - - SRN0210L6B EAVB-021E 208-230 1 60 13.2 102.0 20.0 25 25.0 35 20 (1) 6 - - - SRN0210L6C EAVA-021E 208-230 3 60 6.6 50.0 15.0 15 25.0 25 20 (1) 6 - - - SRN0210L6D EAVA-021E 460 3 60 2.9 26.6 15.0 15 15.0 15 10 (1) 3 - - - SRN0210L6E EAVA-021E 575 3 60 2.8 20.0 15.0 15 15.0 15 8 (1) 3 - - - SRN0310L6G LAHB-032E 230 1 60 15.0 105.0 20.0 30 25.0 35 20 (1) 6 50.0 50 40 (1) 12
SRN0310L6C LAHA-032E 208-230 3 60 11.5 112.0 15.0 25 25.0 30 20 (1) 6 50.0 50 40 (1) 12
SRN0310L6D LAHA-032E 460 3 60 5.4 56.0 15.0 15 15.0 15 10 (1) 3 25.0 25 20 (1) 6
SRN0310L6E LAHA-032E 575 3 60 3.7 30.0 15.0 15 15.0 15 8 (1) 3 20.0 20 16 (1) 5
SRN0310E6G LACB-032E 230 1 60 13.9 105.0 20.0 30 25.0 35 20 (1) 6 50.0 50 40 (1) 12
SRN0310E6C LACA-032E 208-230 3 60 11.5 112.0 15.0 25 25.0 30 20 (1) 6 50.0 50 40 (1) 12
SRN0310E6D LACA-032E 460 3 60 5.4 56.0 15.0 15 15.0 15 10 (1) 3 25.0 25 20 (1) 6
SRN0311L6G 2DF3F16KE 230 1 60 22.9 125.0 28.7 50 34.7 50 20 (1) 6 50.0 60 40 (1) 12
SRN0311L6C 2DF3F16KE 208-230 3 60 14.4 102.0 20.0 30 25.0 35 20 (1) 6 50.0 50 40 (1) 12
SRN0311L6D 2DF3F16KE 460 3 60 7.1 52.0 15.0 15 15.0 15 10 (1) 3 25.0 25 20 (1) 6
SRN0311L6E 2DF3F16KE 575 3 60 6.0 41.0 15.0 15 15.0 15 8 (1) 3 20.0 20 16 (1) 5
SRN0400L6C 2DL3F20KE 208-230 3 60 23.6 161.0 29.5 50 35.5 50 20 (1) 6 50.0 60 40 (1) 12
SRN0400L6D 2DL3F20KE 460 3 60 9.2 60.0 15.0 20 15.0 20 10 (1) 3 25.0 25 20 (1) 6
SRN0400L6E 2DL3F20KE 575 3 60 6.9 49.0 15.0 15 15.0 15 8 (1) 3 20.0 20 16 (1) 5
SRN0599L6C 2DA3F23KE 208-230 3 60 25.8 161.0 32.3 50 38.3 60 20 (1) 6 50.0 70 40 (1) 12
SRN0599L6D 2DA3F23KE 460 3 60 9.2 60.0 15.0 20 15.0 20 10 (1) 3 25.0 25 20 (1) 6
SRN0599L6E 2DA3F23KE 575 3 60 8.1 49.0 15.0 15 15.0 20 8 (1) 3 20.0 20 16 (1) 5
SRN0600L6C 2DB3F25KE 208-230 3 60 25.3 161.0 31.7 50 37.7 60 20 (1) 6 50.0 60 40 (1) 12
SRN0600L6D 2DB3F25KE 460 3 60 11.9 80.0 15.0 25 20.0 25 10 (1) 3 25.0 30 20 (1) 6
SRN0600L6E 2DB3F25KE 575 3 60 8.6 63.0 15.0 15 15.0 20 8 (1) 3 20.0 20 16 (1) 5
SRN0601L6C 3DA3F28KE 208-230 3 60 24.0 150.0 30.1 50 36.1 60 20 (1) 6 50.0 60 40 (1) 12
SRN0601L6D 3DA3F28KE 460 3 60 10.8 77.0 15.0 20 20.0 25 10 (1) 3 25.0 30 20 (1) 6
SRN0601L6E 3DA3F28KE 575 3 60 9.4 62.0 15.0 20 15.0 20 8 (1) 3 20.0 25 16 (1) 5
SRN0750L6C 3DB3F33KE 208-230 3 60 27.6 161.0 34.5 60 50.0 70 40 (1) 12 87.5 90 70 (2) 16
SRN0750L6D 3DB3F33KE 460 3 60 14.1 83.0 20.0 30 25.0 35 20 (1) 6 50.0 50 40 (1) 12
SRN0750L6E 3DB3F33KE 575 3 60 9.9 67.0 15.0 20 20.0 25 16 (1) 5 40.0 40 32 (1) 10
SRN0900L6C 3DF3F40KE 208-230 3 60 33.2 215.0 41.5 70 53.5 80 40 (1) 12 87.5 90 70 (2) 16
SRN0900L6D 3DF3F40KE 460 3 60 15.0 106.0 20.0 30 25.0 35 20 (1) 6 50.0 50 40 (1) 12
SRN0900L6E 3DF3F40KE 575 3 60 14.1 84.0 20.0 30 22.6 35 16 (1) 5 40.0 40 32 (1) 10
SRN1000L6C SDS3F46KE 208-230 3 60 37.2 215.0 46.5 80 58.5 90 40 (1) 12 87.5 90 70 (2) 16
SRN1000L6D SDS3F46KE 460 3 60 16.7 106.0 20.8 35 26.8 40 20 (1) 6 50.0 50 40 (1) 12
SRN1000L6E SDS3F46KE 575 3 60 14.6 84.0 20.0 30 23.2 35 16 (1) 5 40.0 40 32 (1) 10
SRN1500L6C 4DL3F63KE 208-230 3 60 47.2 278.0 59.0 100 87.5 110 70 (2) 16 120.0 125 96 (2) 25
SRN1500L6D 4DL3F63KE 460 3 60 23.6 139.0 29.5 50 50.0 60 40 (1) 12 87.5 90 70 (2) 16
SRN1500L6E 4DL3F63KE 575 3 60 18.8 113.0 23.5 40 40.0 50 32 (1) 10 70.0 70 56 (2) 12
SRN2200L6C 4DT3F76KE 208-230 3 60 59.2 374.0 74.0 125 90.0 125 70 (2) 16 120.0 150 96 (2) 25
SRN2200L6D 4DT3F76KE 460 3 60 29.6 187.0 37.0 60 50.0 70 40 (1) 12 87.5 90 70 (2) 16
SRN2200L6E 4DT3F76KE 575 3 60 21.7 135.0 27.1 45 40.0 50 32 (1) 10 70.0 70 56 (2) 12
Compressor
Number
Power Supply Compressor
Volt Ph Hz RLA LRA MCA MOPD MCA MOPD Amps Amps MCA MOPD
Beacon II™ or
Air Defrost
Electric
Defrost
Def.
Htr.*
Evap.
Fan
Electric
Defrost
Def.
Htr.*
Amps
Evap.
Fan
Amps
*Number of defrost heater contactors in parentheses
RLA - Rated Load Amps MCA - Minimum Circuit Ampacity
LRA - Locked Rotor Amps MOPD - Maximum Overcurrent Protection Device
For additional capacity sizes and options, please contact the factory at 800-537-7775
9
PHYSICAL DATA - SRN MODELS
Medium Temperature
Connections (in.)
Model Compressor
SRN0090M6 KARA-010E 7/8 1/2 3/8 1/2 26 A 36-3/8 23-3/4 35 160
SRN0199M6 KAKA-020E 7/8 1/2 3/8 1/2 26 A 36-3/8 23-3/4 35 200
SRN0200M6 ERCA-021E 7/8 1/2 3/8 1/2 26 A 36-3/8 23-3/4 35 245
SRN0310M6 ERFA-031E 1-1/8 5/8 1/2 5/8 57 A 39-1/4 26-3/4 40 305
SRN0500M6 2DC3R53KE 1-3/8 7/8 5/8 5/8 57 A 39-1/4 30-3/8 42 375
Suction Discharge
Liquid
Line
Condenser
Return
90% Rec.
Capacity
(Lbs.)
Dimensions (in.)
FIG. # H W D
Approx.
Low Temperature
Connections (in.)
Model Compressor
SRN0150L6 KALA-016E 7/8 1/2 3/8 3/8 26 A 36-3/8 23-3/4 35 175
SRN0200L6 EADA-020E 7/8 1/2 3/8 1/2 26 A 36-3/8 23-3/4 35 305
SRN0210L6 EAVA-021E 7/8 1/2 3/8 1/2 26 A 36-3/8 23-3/4 35 305
SRN0310L6 LAHA-032E 1-1/8 5/8 1/2 5/8 26 A 39-1/4 26-3/4 40 305
SRN0310E6 LACA-032E 1-1/8 5/8 1/2 5/8 26 A 39-1/4 26-3/4 40 305
SRN0311L6 2DF3F16KE 1-3/8 7/8 1/2 5/8 57 A 39-1/4 26-3/4 40 320
SRN0400L6 2DL3F20KE 1-3/8 7/8 1/2 5/8 57 A 39-1/4 26-3/4 40 360
SRN0599L6 2DA3F23KE 1-3/8 7/8 5/8 5/8 57 A 39-1/4 30-3/8 42 390
SRN0600L6 2DB3F25KE 1-3/8 7/8 5/8 5/8 57 A 39-1/4 30-3/8 42 390
SRN0601L6 3DA3F28KE 1-3/8 1-1/8 5/8 5/8 57 A 39-1/4 30-3/8 42 405
SRN0750L6 3DB3F33KE 1-5/8 1-1/8 5/8 7/8 106 A 43-1/2 35-3/8 47 385
SRN0900L6 3DF3F40KE 1-5/8 1-1/8 5/8 7/8 106 A 43-1/2 35-3/8 47 465
SRN1000L6 3DS3F46KE 1-5/8 1-1/8 7/8 7/8 106 A 43-1/2 35-3/8 47 595
SRN1500L6 4DL3F63KE 2-1/8 1-1/8 7/8 7/8 106 A 43-1/2 35-3/8 47 655
SRN2200L6 4DT3F76KE 2-1/8 1-1/8 7/8 7/8 106 A 43-1/2 35-3/8 47 725
Suction Discharge
Liquid
Line
Condenser
Return
90% Rec.
Capacity
(Lbs.)
Dimensions (in.)
FIG. # H W D
Approx.
Net Wt.
(Lbs.)
Net Wt.
(Lbs.)
NOTES: Receiver refrigerant holding capacity refers to the weight of the type of refrigerant indicated by the model number
(i.e. M6, L6, E6 = R-404A/R-507)
Figures are located on page 15 of this technical bulletin.
Dimensions are maximum dimensions with options. Please refer to submittal drawings for specic model dimensions
For additional capacity sizes and options, please contact the factory at 800-537-7775
10
FEATURES & BENEFITS -ZRN MODELS
The indoor ZRN remote compressor unit is designed for use in supermarket, restaurant, warehouse, commercial
and industrial refrigeration applications. When space is at a premium, and exibility of installation matters, the ZRN
product line provides ease of installation with required components factory installed on remote compressor units.
Construction
• Large, pre-painted electrical enclosure
• Factory installed xed high and low pressure switches
• Adjustable low pressure switch available on low temperature models
• Pump down switch for ease of troubleshooting and service
• 230V control transformer on 460V models for simplied control circuits
• Liquid line lter drier and sight glass to verify system operation (optional on ZWN style)
Serviceability
• Easily accessible refrigerant piping and access ports
• Removable electrical panel door with captive fasteners
Quality
• Formed tubing minimizes brazed joints and reduces the potential for leaks
• Shipped with a holding charge of dry nitrogen to ensure the system is leak free
• Assembled on a heavy duty base plate to provide years of trouble free service
• Non-metallic conduit on all wiring outside of the electrical enclosure to protect wiring integrity
Components
• Scroll compressors
• Vibration isolation mounts on all scroll compressors
• Integrated discharge check valve
• Discharge high pressure safety switch
11
OPTIONS - ZRN MODELS
Features & Options Small Large Notes
Controls
High Pressure Standard Standard Fixed
Low Pressure Standard Standard Fixed (HT/MT), Adjustable (LT)
Dual Pressure Control - Option
Control Transformer Standard Standard Available on 460V and 575V Models only
Liquid Line
Receiver Standard Standard
Filter Drier & Sight Glass Option Standard
Replaceable Core Filter & Sight Glass - Option
Solenoid Valve Option Option
Pumpdown Switch Standard Standard
Suction Line
Filter Option Option
Replaceable Core Filter - Option
Accumulator Option Option
Discharge Line
Oil Seperator - Option
Fixed Head Pressure Control Option Option
Defrost
Timer, O-Cycle (Air) Option Option
Timer, Electric Option Timer, Electric w/ Contactor Option Option
Remote Load Fusing - Option
Beacon II Option -
Miscellaneous
Crankcase Heater Option Option
Compressor Circuit Breaker - Option Includes Circuit Breaker in control circuit
Two-high Rack Option Option
12
PERFORMANCE DATA - ZRN MODELS
R-404A/R-507, Models - Extended Temperature
Capacity BTUH
Model Compressor
Suction Temperature
-20°F -10°F 0°F 10°F 20°F 30°F 40°F
ZRN020X6 ZS15KAE 6,990 8,820 11,020 13,500 16,520 19,980 23,980
ZRN025X6 ZS19KAE 8,620 10,910 13,500 16,630 20,300 24,620 29,590
ZRN030X6 ZS21KAE 9,830 12,200 15,120 18,470 22,460 27,220 32,830
ZRN035X6 ZS26KAE 12,200 15,230 18,790 23,110 28,190 34,020 40,930
ZRN045X6 ZS29KAE 13,720 17,280 21,490 26,570 32,400 39,200 47,090
ZRN055X6 ZS38K4E 17,170 21,380 26,460 32,510 39,740 48,170 58,320
ZRN060X6 ZS45K4E 20,950 25,920 31,970 39,100 47,630 57,780 69,660
120°F Condensing Temperature, 8°F Subcooling
Max 40°F Superheat Limit
R-407A Models - Extended Temperature
Capacity BTUH
Model Compressor
-20°F -10°F 0°F 10°F 20°F 30°F 40°F
ZRN020X6 ZS15KAE — 8,310 10,540 13,100 16,170 19,910 24,500
ZRN025X6 ZS19KAE — 9,370 11,900 14,790 18,240 22,460 27,640
ZRN030X6 ZS21KAE — 11,300 15,080 19,340 24,240 29,970 36,710
ZRN035X6 ZS26KAE — 12,550 16,740 21,460 26,900 33,270 40,750
ZRN045X6 ZS29KAE — 14,060 18,760 24,040 30,140 37,270 45,660
Suction Temperature
120°F Condensing Temperature, 8°F Subcooling
Max 20°F Superheat Limit
R-407C Models - Extended Temperature
Capacity BTUH
Model Compressor
Suction Temperature
-20°F -10°F 0°F 10°F 20°F 30°F 40°F
ZRN020X6 ZS15KAE — 6,030 9,120 12,340 15,770 19,520 23,690
ZRN025X6 ZS19KAE — 6,800 10,300 13,920 17,790 22,030 26,730
ZRN030X6 ZS21KAE — 9,140 13,830 18,690 23,900 29,580 35,900
ZRN035X6 ZS26KAE — 10,140 15,340 20,740 26,510 32,820 39,830
ZRN045X6 ZS29KAE — 11,360 17,190 23,250 29,710 36,780 44,650
120°F Condensing Temperature, 8°F Subcooling
Max 20°F Superheat Limit
R-448A/R-449A Models - Extended Temperature
Capacity BTUH
Model Compressor
-20°F -10°F 0°F 10°F 20°F 30°F 40°F
ZRN020X6 ZS15KAE - 8,160 10,100 12,350 15,200 18,950 23,890
ZRN025X6 ZS19KAE - 9,170 11,350 13,880 17,090 21,300 26,850
ZRN030X6 ZS21KAE - 11,170 15,270 19,870 25,100 31,080 37,930
ZRN035X6 ZS26KAE - 12,550 16,020 20,630 26,410 33,440 41,770
ZRN045X6 ZS29KAE - 14,180 19,370 25,210 31,850 39,440 48,140
120°F Condensing Temperature, 8°F Subcooling
Max 20°F Superheat Limit
Suction Temperature
13
PERFORMANCE DATA - ZRN MODELS
R-404A/R-507 Models - Medium Temperature
Capacity BTUH
Model Compressor
Suction Temperature
10°F 20°F 30°F 40°F
ZRN0650M6 ZB50KCE 44,500 56,380 69,010 83,380
ZRN0700M6 ZB58KCE 50,110 62,320 76,030 92,020
ZRN0750M6 ZB66KCE 57,240 70,200 85,320 102,600
ZRN0860M6 ZB76KCE 68,360 83,380 101,200 122,040
ZRN1000M6 ZS92K4E 82,620 100,440 122,040 145,800
ZRN1400M6 ZS11M4E 95,040 115,560 139,320 166,320
120°F Condensing Temperature, 8°F Subcooling
R-407C Models - Medium Temperature
Capacity BTUH
Model Compressor
10°F 20°F 30°F 40°F
ZRN0650M6 ZB50KCE 38,460 49,950 63,100 78,280
ZRN0700M6 ZB58KCE 43,580 56,780 72,010 89,660
ZRN0750M6 ZB66KCE 50,540 64,440 81,010 100,630
ZRN0860M6 ZB76KCE 61,370 77,210 96,230 118,850
Suction Temperature
120°F Condensing Temperature, 8°F Subcooling
R-448A/R-449A Models - Medium Temperature
Capacity BTUH
Model Compressor
10°F 20°F 30°F 40°F
ZRN0650M6 ZB48KCE 42,060 53,200 66,140 81,400
ZRN0700M6 ZB58K5E 48,350 62,370 77,800 95,470
ZRN0750M6 ZB66K5E 56,050 71,270 88,250 107,670
ZRN0860M6 ZB76K5E 65,480 82,880 102,540 125,300
ZRN1000M6 ZB95K5E 75,790 98,890 125,810 159,020
ZRN1400M6 ZB114K5E 90,330 118,250 150,930 191,100
120°F Condensing Temperature, 8°F Subcooling
Suction Temperature
For additional capacity sizes and options, please contact the factory at 800-537-7775
14
PERFORMANCE DATA - ZRN MODELS
R-404A/R-507 Models - Low Temperature
Capacity BTUH
Model Compressor
Suction Temperature
-40°F -30°F -20°F -10°F 0°F
ZRN020L6 ZF06K4E 4,450 5,900 7,520 9,380 11,550
ZRN025L6 ZF08K4E 5,770 7,480 9,510 11,870 14,730
ZRN030L6 ZF09K4E 6,440 8,360 10,580 13,140 16,320
ZRN035L6 ZF11K4E 8,020 10,390 13,140 16,430 20,350
ZRN045L6 ZF13K4E 8,950 11,660 14,840 18,760 23,430
ZRN055L6 ZF15K4E 11,340 14,630 18,550 23,210 28,730
ZRN060L6 ZF18K4E 13,670 17,810 22,470 27,980 34,560
ZRN0750L6 ZF24K4E 16,320 21,310 27,240 34,130 42,190
110°F Condensing Temperature, 6°F Subcooling
R-407A Models - Low Temperature
Capacity BTUH
Model Compressor
-40°F -30°F -20°F -10°F 0°F
ZRN020L6 ZF06K4E 3,760 5,050 6,640 8,550 10,810
ZRN025L6 ZF08K4E 4,650 6,240 8,200 10,560 13,340
ZRN030L6 ZF09K4E 5,380 6,940 9,210 11,890 14,690
ZRN035L6 ZF11K4E 6,680 8,610 11,450 14,840 18,390
ZRN045L6 ZF13K4E 7,740 9,700 12,810 16,820 21,500
ZRN055L6 ZF15K4E 9,770 12,180 15,880 20,700 26,450
ZRN060L6 ZF18K4E 11,780 14,800 19,290 25,030 31,780
110°F Condensing Temperature, 6°F Subcooling
Suction Temperature
R-407C Models - Low Temperature
Capacity BTUH
Model Compressor
Suction Temperature
-40°F -30°F -20°F -10°F 0°F
ZRN020L6 ZF06K4E 3,510 4,760 6,230 8,030 10,250
ZRN030L6 ZF09K4E 5,030 6,580 8,710 11,250 14,030
ZRN035L6 ZF11K4E 6,300 8,090 10,790 14,040 17,480
ZRN045L6 ZF13K4E 7,170 8,950 11,890 15,710 20,150
ZRN055L6 ZF15K4E 9,050 11,250 14,800 19,390 24,740
ZRN060L6 ZF18K4E 10,990 13,720 17,970 23,410 29,730
110°F Condensing Temperature, 6°F Subcooling
R-448A/R-449A Models - Low Temperature
Capacity BTUH
Model Compressor
-40°F -30°F -20°F -10°F 0°F
ZRN020L6 ZF06K4E 3,860 5,240 6,850 8,740 10,980
ZRN025L6 ZF08K4E 5,020 6,660 8,660 11,080 13,990
ZRN030L6 ZF09K4E 5,660 7,470 9,650 12,290 15,470
ZRN035L6 ZF11K4E 7,060 9,280 12,010 15,340 19,340
ZRN045L6 ZF13K4E 8,160 10,590 13,840 17,900 22,780
ZRN055L6 ZF15K4E 103,10 13,320 17,230 22,100 27,980
ZRN060L6 ZF18K4E 125,30 16,230 20,910 26,660 33,600
ZRN0750L6 ZF25K4E 155,80 19,890 25,790 33,300 42,430
110°F Condensing Temperature, 6°F Subcooling
Suction Temperature
15
ELECTRICAL DATA - ZRN MODELS
Medium & Extended Temperature
Low Amps High Amps
Model
Number
ZRN020X6B ZS15KAE 208-230 1 60 14.1 68.0 20.0 30 37.5 40 30 (1) 12 — — — —
ZRN020X6C ZS15KAE 208-230 3 60 9.6 58.0 15.0 20 37.5 40 30 (1) 12 — — — —
ZRN020X6D ZS15KAE 460 3 60 4.8 29.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN025X6B ZS19KAE 208-230 1 60 16.2 75.0 20.2 35 37.5 45 30 (1) 12 — — — —
ZRN025X6C ZS19KAE 208-230 3 60 12.3 73.0 20.0 25 37.5 40 30 (1) 12 — — — —
ZRN025X6D ZS19KAE 460 3 60 5.8 38.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN030X6B ZS21KAE 208-230 1 60 20.8 112.0 26.0 45 38.0 45 30 (1) 12 — — — —
ZRN030X6C ZS21KAE 208-230 3 60 13.7 93.0 20.0 30 37.5 40 30 (1) 12 — — — —
ZRN030X6D ZS21KAE 460 3 60 6.2 48.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN035X6B ZS26KAE 208-230 1 60 21.2 104.0 26.4 45 38.4 50 30 (1) 12 — — — —
ZRN035X6C ZS26KAE 208-230 3 60 13.9 93.0 20.0 30 37.5 40 30 (1) 12 — — — —
ZRN035X6D ZS26KAE 460 3 60 6.2 48.0 15.0 15 23.8 25 19 (1) 9 — — — —
ZRN045X6B ZS29KAE 208-230 1 60 23.4 137.0 29.2 50 58.8 60 47 (1) 11 — — — —
ZRN045X6C ZS29KAE 208-230 3 60 18.4 114.0 23.0 40 43.8 45 35 (1) 12 — — — —
ZRN045X6D ZS29KAE 460 3 60 8.4 58.0 15.0 15 28.8 30 23 (1) 11 — — — —
ZRN055X6B ZS38K4E 208-230 1 60 28.5 169.0 35.7 60 58.8 70 47 (1) 12 — — — —
ZRN055X6C ZS38K4E 208-230 3 60 19.2 123.0 24.0 40 43.8 50 35 (1) 12 — — — —
ZRN055X6D ZS38K4E 460 3 60 8.7 62.0 15.0 15 28.8 30 23 (1) 10 — — — —
ZRN060X6C ZS45K4E 208-230 3 60 22.8 156.0 28.4 50 40.4 60 30 (1) 12 — — — —
ZRN060X6D ZS45K4E 460 3 60 8.3 70.0 15.0 15 28.8 30 23 (1) 10.6 — — — —
ZRN0650M6C ZB50KCE 208-230 3 60 25.6 196.0 32.1 50 50.0 60 40 (1) 12 70 (2) 16 87.5 90
ZRN0650M6D ZB50KCE 460 3 60 13.5 100.0 20.0 30 25.0 35 20 (1) 6 40 (1) 12 50.0 50
ZRN0700M6C ZB58KCE 208-230 3 60 27.6 195.0 34.5 60 50.0 70 40 (1) 12 70 (2) 16 87.5 90
ZRN0700M6D ZB58KCE 460 3 60 14.7 95.0 20.0 30 25.0 35 20 (1) 6 40 (1) 12 50.0 50
ZRN0750M6C ZB66KCE 208-230 3 60 26.9 225.0 33.7 60 50.0 70 40 (1) 12 70 (2) 16 87.5 90
ZRN0750M6D ZB66KCE 460 3 60 15.7 114.0 20.0 35 25.6 40 20 (1) 6 40 (1) 12 50.0 50
ZRN0860M6C ZB76KCE 208-230 3 60 37.2 239.0 46.5 80 58.5 90 40 (1) 12 70 (2) 16 87.5 90
ZRN0860M6D ZB76KCE 460 3 60 17.9 125.0 22.4 40 28.4 45 20 (1) 6 40 (1) 12 50.0 50
ZRN1000M6C ZS92K4E 208-230 3 60 47.4 350.0 59.3 100 87.5 110 70 (2) 16 96 (2) 25 120.0 125
ZRN1000M6D ZS92K4E 460 3 60 22.4 158.0 28.0 50 50.0 60 40 (1) 12 70 (2) 16 87.5 90
ZRN1400M6C ZS11M4E 208-230 3 60 53.8 425.0 67.3 110 87.5 125 70 (2) 16 96 (2) 25 120.0 125
ZRN1400M6D ZS11M4E 460 3 60 25.3 187.0 31.7 50 50.0 60 40 (1) 12 70 (2) 16 87.5 90
Compressor
Number
Power Supply Compressor
Volt Ph Hz RLA LRA MCA MOPD MCA MOPD Amps Amps MCA MOPD
Beacon II™ or
Air Defrost
Electric
Defrost
Def.
Htr.*
Evap.
Fan
Electric
Defrost
Def.
Htr.*
Amps
Evap.
Fan
Amps
*Number of defrost heater contactors in parentheses
RLA - Rated Load Amps MCA - Minimum Circuit Ampacity
LRA - Locked Rotor Amps MOPD - Maximum Overcurrent Protection Device
For additional capacity sizes and options, please contact the factory at 800-537-7775
16
ELECTRICAL DATA - ZRN MODELS
Low Temperature
Low Amps High Amps
Model
Number
ZRN020L6B ZF06K4E 208-230 1 60 12.2 61.0 20.0 25 37.5 40 30 (1) 12 — — — —
ZRN020L6C ZF06K4E 208-230 3 60 8.3 55.0 15.0 15 23.8 25 19 (1) 6 — — — —
ZRN020L6D ZF06K4E 460 3 60 3.8 27.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN025L6B ZF08K4E 208-230 1 60 14.7 73.0 20.0 30 37.5 45 30 (1) 12 — — — —
ZRN025L6C ZF08K4E 208-230 3 60 8.7 63.0 15.0 15 23.8 25 19 (1) 6 — — — —
ZRN025L6D ZF08K4E 460 3 60 4.5 31.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN030L6B ZF09K4E 208-230 1 60 12.8 88.0 20.0 25 37.5 40 30 (1) 12 — — — —
ZRN030L6C ZF09K4E 208-230 3 60 8.7 77.0 15.0 15 23.8 25 19 (1) 6 — — — —
ZRN030L6D ZF09K4E 460 3 60 4.5 39.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN035L6B ZF11K4E 208-230 1 60 18.6 109.0 23.2 40 37.5 50 30 (1) 12 — — — —
ZRN035L6C ZF11K4E 208-230 3 60 10.9 88.0 15.0 20 28.8 30 23 (1) 6 — — — —
ZRN035L6D ZF11K4E 460 3 60 5.8 44.0 15.0 15 23.8 25 19 (1) 10 — — — —
ZRN045L6B ZF13K4E 208-230 1 60 22.4 129.0 28.0 50 39.0 60 30 (1) 11 — — — —
ZRN045L6C ZF13K4E 208-230 3 60 11.9 99.0 15.0 25 37.5 40 30 (1) 11 — — — —
ZRN045L6D ZF13K4E 460 3 60 6.4 49.5 15.0 15 23.8 25 19 (1) 9 — — — —
ZRN055L6B ZF15K4E 208-230 1 60 24.7 169.0 30.8 50 40.8 60 30 (1) 10 — — — —
ZRN055L6C ZF15K4E 208-230 3 60 17.0 123.0 21.2 35 37.5 45 30 (1) 10 — — — —
ZRN055L6D ZF15K4E 460 3 60 8.0 62.0 15.0 15 23.8 25 19 (1) 8 — — — —
ZRN060L6C ZF18K4E 208-230 3 60 19.6 156.0 24.4 40 43.8 50 35 (1) 12 — — — —
ZRN060L6D ZF18K4E 460 3 60 8.0 70.0 15.0 15 28.8 30 23 (1) 11 — — — —
ZRN0750L6C ZF24K4E 208-230 3 60 23.4 189.0 29.2 50 35.2 50 20 (1) 6 40 (1) 12 50 60
ZRN0750L6D ZF24K4E 460 3 60 11.9 99.0 15.0 25 20.0 25 10 (1) 3 20 (1) 6 25 30
ZRN1000L6C ZF33K4E 208-230 3 60 31.4 278.0 39.3 70 51.3 80 40 (1) 12 40 (1) 12 51.3 80
ZRN1000L6D ZF33K4E 460 3 60 17.3 127.0 21.6 35 27.6 40 20 (1) 6 20 (1) 6 27.6 40
ZRN1300L6C ZF40K4E 208-230 3 60 40.4 350.0 50.5 90 62.5 100 40 (1) 12 40 (1) 12 62.5 100
ZRN1300L6D ZF40K4E 460 3 60 19.9 158.0 24.8 40 30.8 50 20 (1) 6 20 (1) 6 30.8 50
ZRN1500L6C ZF48K4E 208-230 3 60 49.4 425.0 61.7 110 73.7 110 40 (1) 12 70 (2) 16 87.5 125
ZRN1500L6D ZF48K4E 460 3 60 21.8 187.0 27.2 50 33.2 50 20 (1) 6 40 (1) 12 50 60
Compressor
Number
Power Supply Compressor
Volt Ph Hz RLA LRA MCA MOPD MCA MOPD Amps Amps MCA MOPD
Beacon II™ or
Air Defrost
Electric
Defrost
Def.
Htr.*
Evap.
Fan
Electric
Defrost
Def.
Htr.*
Amps
Evap.
Fan
Amps
*Number of defrost heater contactors in parentheses
RLA - Rated Load Amps MCA - Minimum Circuit Ampacity
LRA - Locked Rotor Amps MOPD - Maximum Overcurrent Protection Device
For additional capacity sizes and options, please contact the factory at 800-537-7775
17
PHYSICAL DATA - ZRN MODELS
Medium & Extended Temperature
Connections (in.)
Model Compressor
ZRN020X6 ZS15KAE 7/8 3/8 1/2 1/2 20 B 28 25 29 163
ZRN025X6 ZS19KAE 7/8 3/8 1/2 1/2 20 B 28 25 29 169
ZRN030X6 ZS21KAE 7/8 3/8 1/2 1/2 20 B 28 25 29 171
ZRN035X6 ZS26KAE 7/8 1/2 1/2 1/2 20 B 28 25 29 186
ZRN045X6 ZS29KAE 7/8 1/2 1/2 1/2 20 B 28 25 29 207
ZRN055X6 ZS38K4E 7/8 1/2 1/2 1/2 20 B 28 25 29 226
ZRN060X6 ZS45K4E 7/8 1/2 1/2 1/2 20 B 28 25 29 241
ZRN0650M6 ZB50KCE 1 3/8 7/8 5/8 5/8 106 A 43 1/2 35 3/8 47 192
ZRN0700M6 ZB58KCE 1 3/8 1 1/8 5/8 5/8 106 A 43 1/2 35 3/8 47 194
ZRN0750M6 ZB66KCE 1 3/8 1 1/8 5/8 5/8 106 A 43 1/2 35 3/8 47 195
ZRN0860M6 ZB76KCE 1 5/8 1 1/8 7/8 7/8 106 A 43 1/2 35 3/8 47 354
ZRN1000M6 ZS92K4E 1 5/8 1 1/8 7/8 7/8 149 A 43 1/2 35 3/8 47 442
ZRN1400M6 ZS11M4E 1 5/8 1 1/8 7/8 7/8 149 A 43 1/2 35 3/8 47 465
Suction Discharge
Liquid
Line
Condenser
Return
90% Rec.
Capacity
(Lbs.)
FIG. # H W D
Dimensions (in.)
Approx.
Net Wt.
Low Temperature
Connections (in.)
Model Compressor
ZRN020L6 ZF06K4E 7/8 3/8 1/2 1/2 20 B 28 22 27 155
ZRN025L6 ZF08K4E 7/8 3/8 1/2 1/2 20 B 28 22 27 159
ZRN030L6 ZF09K4E 7/8 3/8 1/2 1/2 20 B 28 22 27 159
ZRN035L6 ZF11K4E 7/8 1/2 1/2 1/2 20 B 28 22 27 165
ZRN045L6 ZF13K4E 7/8 1/2 1/2 1/2 20 B 28 22 27 185
ZRN055L6 ZF15K4E 7/8 1/2 1/2 1/2 20 B 28 22 27 201
ZRN060L6 ZF18K4E 7/8 1/2 1/2 1/2 20 B 28 25 29 201
ZRN0750L6 ZF24K4E 1 3/8 7/8 5/8 5/8 57 A 39 1/4 30 3/8 42 1/2 286
ZRN1000L6 ZF33K4E 1 5/8 1 1/8 5/8 5/8 106 A 43 1/2 35 3/8 47 221
ZRN1300L6 ZF40K4E 1 5/8 1 1/8 5/8 5/8 106 A 43 1/2 35 3/8 47 292
ZRN1500L6 ZF48K4E 1 5/8 1 1/8 7/8 7/8 106 A 43 1/2 35 3/8 47 335
NOTES: Receiver refrigerant holding capacity refers to the weight of the type of refrigerant indicated by the model number
(i.e. M6, L6, E6 = R-404A/R-507)
Figures are located on page 15 of this technical bulletin.
Dimensions are maximum dimensions with options. Please refer to submittal drawings for specic model dimensions
For additional capacity sizes and options, please contact the factory at 800-537-7775
Suction Discharge
Liquid
Line
Condenser
Return
90% Rec.
Capacity
(Lbs.)
FIG. # H W D
Dimensions (in.)
Approx.
Net Wt.
(Lbs.)
(Lbs.)
18
DIMENSIONAL DATA
Figure A
Maximum Dimensions with Options
Horsepower A B C D E
3/4 to 2 35" 23-3/4" 36-3/8" 13-1/2" 12"
3 to 4 40" 26-3/4" 39-1/4" 13-1/2" 12"
5 to 6 42-1/2" 30-3/8" 39-1/4" 13-1/2" 12"
7-1/2 to 22 47" 35-3/8" 43-1/2" 24" 12"
NOTES: Please refer to submittal drawings for exact model dimensions
Figure B
19
For more information on Bohn refrigeration products, contact
your Sales Representative or visit us at heatcraftrpd.com.
A Brand of Heatcraft Refrigeration Products, LLC
2175 West Park Place Blvd. • Stone Mountain, GA • 30087
(800) 537-7775
heatcraftrpd.com
Since product improvement is a continuing eort, we reserve the right to
make changes in specications without notice.
BN-RCUTB-0716 | Version 000
Loading...
