Thank You!
Thanks for purchasing a Blue Tiger Pro Bluetooth headset.
Please double check the contents of your package to
verify that you have received all of the included items.
Please read the user guide in its entirety before operating
your headset. Your Blue Tiger headset can be paired with
any device that is Bluetooth enabled.
Getting Started – Battery Care
Please fully charge your new headset before attempting
to pair your headset for the first time. Your headset
should be charged for a minimum of four hours and no
more than eight hours to achieve a full charge. The LED
will remain solid red while charging, and will turn off
when fully charged.
Specifications
Bluetooth Type
V 2.1, Class 2
Frequency Band
2.4GHz-2.8435GHz, ISM Band
Talk/Standby Time
20 hours/350 hours
Data Encryption
128 bit
Battery Type
High Capacity Li-Polymer
Charging Type
USB
Weight
75g (includes battery)
Size
150*140*65mm
FIRST TIME USAGE INSTRUCTIONS
Adjusting the Headband: We recommend that you
extend the headband slightly on both sides to reduce
tension and increase the headband’s flexibility.
Pairing the Headset: Before your headset can be used
with your phone, it must first be connected, or paired, to
your phone. This process should only need to be
completed one time with each new device.
Instructions for Single Device Pairing:
1. Make sure that your Blue Tiger headset is in the "Off"
position (no light flashing on the side of the headset),
press and hold the MFB for about 10 seconds, until the
LED light begins alternating between red and blue flashes.
2. On your phone or other Bluetooth device, go to your
Bluetooth menu (sometimes located under Settings,
Wireless, Connectivity, or another submenu), and select
"Add New" or "Search for New Devices."
3. On your phone or other Bluetooth device, select your
headset on the list. Your device may ask for a passcode.
If so, input "0000."
4. On your phone or other Bluetooth device, select
"Connect" or "Automatically Connect."
Having Trouble?: If your phone does not “see” your
headset, check to make sure the LED light on the headset
is flashing blue and red. Once you have verified that it is
flashing and your phone is not recognizing the headset, try
rebooting your phone and attempt pairing again.
Instructions for Pairing to a Second Device (Multi-point):
1. Pair the headset as normal with the first phone.
2. Turn the Bluetooth function off on the first phone.
3. Turn the headset off and then pair the headset with the
second phone.
4. Turn the Bluetooth function back on the first phone.
At this time, both phones should be paired with the
headset. For functions such as voice dial and redial, the
headset will automatically connect to whichever phone it
had the most recent active connection with.
General Functions
Turn On: Press and hold the MFB button for 5 seconds
until the indicator light flashes blue 3 times.
NOTE: For the first 5 cycles of turning on the headset, the
headset will beep twice, flash blue 5 times, and then two more times.
Turn Off: Press and hold the MFB for 5 seconds. The
headset will beep three times and then the indicator light
will flash red three times.
Voice Dialing: Press and hold the MFB for about one
second. Your phone should then activate its voice dialing
function. This process may vary slightly based on your
particular phone model.
Redialing: Press the MFB twice quickly.
Answering/Ending a Call: Press the MFB once.
Mute On/Off: Press and hold the Down Volume (-)
button for 2-3 seconds.
NOTE: Some functions may or may not work with certain phone models.
See your phone’s manual for more information.
Bluetooth Tips
Most Bluetooth headsets, including Blue Tiger headsets,
have a range of about 10 meters (about 30 feet).
However, there are factors that can increase or decrease
your range and signal strength.
Like most radio transmissions, line of sight plays an
important role. If your headset has a clear line of sight to
your phone, you may be able to go beyond the 30 meter
mark. On the other hand, if you do not have good line of
sight or have something like a wall between the headset
and phone, you may only get a few feet of range.
Additionally, other factors may interfere with Bluetooth
signal transmission. Other devices emitting radio waves,
minor non-harmful radiation from every day electronic
devices, or even the magnetic field around one's body
may at times cause interference. The best way to avoid
this is to remove your phone or other Bluetooth device
from contact or close proximity to the source of the
interference.
Troubleshooting Tips
*Ensure that your headset has enough power, is turned
on, and has been successfully paired with your device.
(Follow the pairing instructions located in this manual)
*If you are having trouble getting the headset paired, try
rebooting your phone.
*Ensure that you have enabled your Bluetooth function
on your phone or device.
*Be sure that you are within 10 meters (about 30 feet) of
your phone or Bluetooth enabled device with good line of
sight and with no other electromagnetic interferences
obstructing your wireless link.
*If the indicator light on your headset is flashing red, your
battery is running low.
*If indicator light goes off during charging, do not be
alarmed, headset is still receiving a charge.
Headset Storage
*Only use included accessories with your Blue Tiger Pro.
Using unauthorized chargers could damage your battery.
*Store headset away from dust, heat, and water.
*Do not store headset or chargers in extreme
environments.
Additional Support
If you have any other questions or for information about
your headset warranty, please contact our Customer
Service department at 1-800-935-1165, see our technical
support page on our website, bluetigerusa.com/technicalsupport.
