Blodgett BCS-8E Operator’s Manual

THE BLODGETT COMBI CONVECTION STEAMER
OWNER/OPERATOR MANUAL
MODEL: BCSĆ8E
C
U
L
A Division of G. S. Blodgett Corporation
U
L
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INĆ STALLATION, OPERATING AND MAINTENANCE INĆ STRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
The information contained in this manual is important for the proper installation, use, and maintenance of this oven. Adherence to these procedures and instructions will result in satisfactory baking results and long, trouble free service. Please read this manual carefully and retain it for future reference.
Errors: Descriptive, typographic or pictorial errors are subject to correcĆ
tion. Specifications are subject to change without notice.
A PERSONAL WORD
FROM BLODGETT COMBI
Congratulations on your purchase of the BLODGETT Combi Convection Steamer. We firmly believe that your choice has been a wise one, and trust you will receive many years of excellent service from your new steamer.
The Convection Steamer concept offers completely new potential for cooking which minimizes shrinkage, while maintaining food's essential vitamins and valuable nutrients. In addition, you will find that cooking with the Convection Steamer will save time, labor and extensive cleaning of both the kitchen and the appliance.
With the Convection Steamer the quality, taste, consistency, and look of the food are improved, thus endorsing the policy to which we've always adhered: For Better Cooking!"
Once you've had a chance to use your steamer, please tell us, your dealĆ er and colleagues about any creative and interesting applications you have discovered; exchange ideas with other users. Be sure to advise us or your dealer immediately should any mechanical or technical problems be encountered (...we're here to help!) and above all Enjoy Cooking the BLODGETT Combi Convection Steamer Way!
Your Service Agency's Address:
Model:
Serial Number:
Your oven was installed by:
Your oven's installation was checked by:
Table of Contents
Introduction
The Blodgett Combi Convection Steamer 2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Description of the Combi Convection Steamer 3. . . . . . . . . . . . . . . . . . . . . . .
Convection Steamer Features 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
Instructions 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convection Steamer Location and Ventilation 6. . . . . . . . . . . . . . . . . . . . . . . .
Installation and Connection 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leg Attachment 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stacking Ć Double Section Assembly 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Final Check and Adjustments 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation
Steamer StartĆUp and ShutĆDown 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Panel 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mode Selection and Operation 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance
Spray Bottle Operating Procedure 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning and Preventive Maintenance 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Decalcification 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steaming Guide
General Tips and Procedures 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSERT BLANK PAGE
FOR
INSIDE BACK COVER
Original Equipment Limited Warranty
Blodgett COMBI warrants to the original purchaser its Combi Convection Steamers to be free from defects in material and workmanship for which it is responsible. Blodgett COMBI's obligation under this warranty shall be limited to repairing or replacing without charge any part which is found to be defective within the earlier of one (1) year from the date of installation or 13 months from the date of shipment from our factory, together with the labor costs incurred in each repair or replacement, provided equipment has been unaltered, and has been properly installed, maintained, and operated in accordance with the Blodgett COMBI Ownership Manuals. This warranty is valid for continental United States, Hawaii, Alaska, Canada and Mexico.
Blodgett Combi agrees to pay our factory authorized service agent for any labor required to repair or replace at our option any part which proves to be defective due to defects in material or workmanship during the warranty period. This warranty includes actual mileage not to exceed fifty (50) miles (100 miles round trip) or travel time not to exceed two (2) hours. Mileage or travel time exceeding the limits will not be covered unless previously authorized by factory.
This warranty does not cover any defect due to or resulting from handling, abuse, misuse, or harsh chemical, nor shall it extend to any unit from which the serial number has been removed or altered, or modifications made by unauthorized service personnel or damage by flood, fire or other acts of God.
Adjustments such as calibrations to the thermostats, leveling, tightening of fasteners or plumbĆ ing connections normally associated with the original installation are the responsibility of the dealer or installer and are not covered by Blodgett COMBI under the terms of this warranty.
Proper installation is the responsibility of the dealer, the ownerĆuser, or installing contractor, and is not covered by this warranty. Many local codes exist, and it is the responsibility of the owner
and installer to comply with these codes.
Steam Generator maintenance is the responsibility of the ownerĆuser, and is not covered by the warranty. The use of good quality feed water (see owner/operator manual) is the responsibility of
the ownerĆuser. Decalcification of the steam generator should be carried out by the recommended preĆ ventive maintenance schedule. Steam Generator or steam generator component failure due to imĆ
proper preventive maintenance, the use of poor quality water or scale buildup is not covered unĆ der the warranty.
The foregoing is exclusive and in lieu of all other warranties, whether written, oral, or implied, includĆ ing any warranty of performance, merchantability, or fitness for any particular purpose, and supersedes and excludes any oral warranties or representations, or written warranties or representations, not exĆ pressly designated in writing as a warranty" or guarantee" of Blodgett COMBI made or implied in any manual, literature, advertising brochure or other materials. This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
In no event shall Blodgett COMBI be liable, directly or indirectly, for special consequential or inciĆ dental damages, including but not limited to: (i) any loss of business or profits, and (ii) labor, materials or other charges, claims, losses or damages incurred or suffered from, in connection with or in circumĆ stances of the working upon, alteration, or repair of any such defective products or parts by persons or firms other than that of Blodgett COMBI.
Spray bottles and hose assemblies shall be warranted for a period not to exceed the first thirty (30) days after installation.
55 Boyer Circle, P.O. Box 1440, Williston, Vermont 05495Ć1440 USA
Telephone (802) 860Ć4598, (888) 992Ć6624ĂĂFAX (802) 860Ć3784
A Division of G. S. Blodgett Corporation
PN R5377 (8/95)
Introduction
The Blodgett Combi Convection Steamer
Steaming āis āa wellĆknown cooking process freĆ quently used in restaurant and institutional kitchens. With the Blodgett Combi Convection Steamer, it is now possible to enjoy the many adĆ vantages of steaming, some of which are:
D Simplified Work Process
The work process is simplified since products are prepared on or in steam table āpans āand trays. Food can be cooked, stored, and transĆ ported with āthe āsame āāpans. āSmall āamounts of product can be processed efficiently; preĆ cooked and convenience foods can be reĆ thermalized within minutes. āMany frozen foods can be processed without preĆthawing. This flexibility in preparation reduces the need for kettles and steam tables since there is no need for large amounts of food to be kept warm for long periods of time.
D High Quality Foods
Today the improvement of food quality is more important than ever. With ātheā useāāāofā steam,ā valuable taste and aroma are preĆ served since steamed foods retain their own natural taste. During the steaming process foods retain the nutrients and vitamins which are lost in water during boiling. Therefore, when compared, steamed foods have much better color than foods that have been boiled. āAlso,ā by using shallow containers the product is not layered as deeply and mushing is avoided.
D Vitamin Retention
In āthe āBlodgettā āCombi Convection Steamerā viĆ tamins are not destroyed. This is due to the shorter cooking times, the use of less or little water and the use of a low temperature; slightĆ ly less than 212F/100C.
D Firmness
With the use of steam, overcooking āisā notā a problem and firmness can be individually controlled.
D Simultaneously Steaming Different Foods
There is no flavor transfer when cookingā āwithā ātheā āConvection Steamer. For this reason, variĆ ous types of food with different cooking times can be loaded or removed at any point during the steaming process.
HOW STEAMING WORKS
The Blodgett Combi Convection Steamer gently cooks food using nonĆpressurized steam. Fresh steam is directed into the unit from the generaĆ tor. It is not necessary to add water to foods durĆ ing the steaming process.
WHAT CAN BE STEAMED
Vegetables, side dishes, fish, meat, poultry, diet foods, garnishes, dumplings, casseroles, meat loaf, fruits, desserts and eggs.
In the Steam mode you can:
steam thawstew preserveblanch reconstitutepoach simmerrethermalize
2
Introduction
Description of the Combi Convection Steamer
ABOUT THE CONVECTION STEAMER
Blodgett Combi Convection Steamers are qualiĆ ty produced using highĆgrade stainless steel with first class workmanship.
The high performance fresh steam generator with its control system makes it possible to enjoy all of the advantages of a high quality steamer at the flick of a switch. Fresh steam enters the oven cavity without pressure and is circulated at high speed. This process enables quick and gentle cooking and ensures high quality food while providing convenient working methods. The steam generator is completely automatic and protected from running dry.
A patented quench system keeps the air in the steamer clean. Fumes are extracted from the appliance, quenched, and directed out through the condenser drain. This exhaust system reĆ sults in better quality foods and no flavor transĆ fer. The fan, which is guarded against accidenĆ tal finger contact, is driven by a quiet and powerful motor. The condenser draws out exĆ cess steam from the appliance. Condensation and waste water, which result during steaming and cleaning, are continuously drained.
The use of high quality insulation impedes exĆ cessive heat radiation and saves energy.
The Convection Steamer has optional adjustĆ able legs which adapt easily to slightly uneven surfaces and optional floor stands which are deĆ signed for use with all of the table models.
STEAMER OPERATION
The practical door, with a viewing window, has a wide swing radius and handle which can be operated easily, even with wet or greasy hands.
Ease of operation is guaranteed through the simple arrangement of the controls. Graphic symbols make the appliance easy for even inexĆ perienced kitchen staff to operate. Steam can be selected with one switch.
Cleaning is kept to a minimum. The interior is sprayed with a selfĆacting cleaning solution which interacts with steam to easily remove crusts and stains. The steamer is designed for easy care and is welded water tight so that the internal cooking cavity may be rinsed with a hose after the steam cleaning process.
3
Introduction
Convection Steamer Features
10
Standard Features
6
1
12
1
Mode Selector Switch
2 3
11
5
4
7
8
9
7
DripĂCollectorĂ(self draining)
Timer Dial
2
3
Flush/Drain Switch
4
Indicator Lamp (Red) Low Water"
5
Power ON" Indicator (Green)
6
Steamer Door
Door Handle
8
9
Door Contact Switch
10
VentĂ(not shown)
11
Decalcifying Inlet & Funnel Assembly
12
Decalcifying Valve Lever
4
THE INSTALLATION INSTRUCTIONS CONĆ TAINED HEREIN ARE FOR THE USE OF QUALIĆ FIED INSTALLATION AND SERVICE PERSONĆ NEL ONLY. INSTALLATION OR SERVICE BY OTHĆ ER THAN QUALIFIED PERSONNEL MAY REĆ SULT IN DAMAGE TO THE OVEN AND/OR INJUĆ RY TO THE OPERATOR.
Qualified installation personnel are individuals, a firm, a corporation, or a company which either in person or through a representative are engaged in, and are responsible for:
The installation of electrical wiring from the elecĆ tric meter, main control box or service outlet to the electric appliance. Qualified installation personĆ nel must be experienced in such work, be familiar with all precautions required and have complied with all requirements of state or local authorities having jurisdiction. Reference: National Electrical Code, ANSI/NFPA 70-Latest Edition and/or CaĆ nadian Electrical Code CSA C22.1 as applicable.
This equipment is to be installed in compliance with the Basic Plumbing Code of the Building OffiĆ cials and Code Administrators International Inc. (BOCA) and the Food Service Sanitation Manual of the Food and Drug Administration (FDA).
C
Installation
Instructions
U
L
U
L
5
Installation
Convection Steamer Location and Ventilation
The well planned and proper placement of the convection steamer will result in long term operĆ ator convenience and satisfactory performance. It is, therefore, urged that adequate thought be given to the location of the steamer prior to its delivery for installation.
Place the steamer in an area which is free of drafts and accessible for proper operation and servicing. The unit requires a minimum clearĆ ance of six (6) inches between the steamer body's right and left side and back and any comĆ bustible or nonĆcombustible construction. It is recommended that at least twelve (12) inches of space be provided around the entire unit for servicing.
Keep the steamer area free and clear of all comĆ bustibles such as paper, cardboard, and flamĆ
mable liquids and solvents. DO NOT place the steamer on a curb base or seal to the wall; either condition will restrict the flow of air to the comĆ bustion compartment and prevent proper ventiĆ lation to the blower motors. Slight unevenness can be corrected with the adjustable legs.
On all models, tripping the blower motor's therĆ mal overload device indicates an excessive amĆ bient temperature at the back of the unit. This must be corrected to prevent permanent damĆ age to the convection steamer. All motor bearĆ ings are permanently lubricated by the manĆ ufacturer; there is no need for additional lubrication during the operational lifetime of the motors.
6
Installation
Installation and Connection
HOT AND COLD WATER CONNECTION
Connect the appliance to quality hot and cold water via a pressure hose with 3/4" couplings. A shut off valve is to be provided adjacent to the unit.
Regulator
1/2" Appliance Hose With 3/4" Hose Fittings
NOTE: Operating the steamer without the
water regulator installed will invaliĆ date your warranty.
Water must meet the following minimum reĆ quirements:
Total Dissolved Solids (TDS) content will
not exceed 30 parts per million.
Water PH must be 7.0 or higher
NOTE: The use of poor quality water will inĆ
validate your warranty.
DRAIN CONNECTION
The Drain Vent assembly, included with the unit, and a 2 pipe with standard drain pitch, should be run to an open drain or connected to a standĆ pipe equipped with a vent. The waste water can also be directed to a nearby floor drain.
Please use the drain vent assembly and a 2" pipe for drain connection. Flexible hose which allows trapped water to accumulate in sagged runs must be avoided.
Steamer Drain
To Drain
2" Drain Customer Supplied
A 24" long standpipe must be connected to the DWV. This allows the escaping water vapor to exit above the inlet louvers on the back panel.
Breather Vent
Plumber Installed
Connection
Tee, Hose
and Clamps
Plumber Installed
Connection To Drain
7
Installation
Installation and Connection
ELECTRICAL CONNECTIONS
Before making any electrical connections to these units, check that the power supply is adeĆ quate for the voltage, amperage, and phase reĆ quirements stated on the rating name plate mounted on the unit.
All steamers, when installed, must be electrically grounded in accordance with local codes or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70-Latest Edition and/or Canadian Electrical Code CSA C22.1 as applicable.
Wiring diagrams are located on the inside of the louvered side panel.
NOTE: DISCONNECT THE POWER SUPPLY
TO THE UNIT BEFORE SERVICING!
CAUTION! After connecting the appliance, the
fan āshould ābe checked to āensure the proper roĆ tation (see diagram). If the fan turns in the wrong direction, the appliance will not function properĆ ly and damage to the unit can occur. Improper connection of the appliance renders the Blodgett Combi warranty invalid.
Direction Of Fan Rotation
NOTE: ALL MANUAL RESETS SHOULD BE
RESTORED BEFORE CONNECTING POWER TO THE APPLIANCE.
WARNING!
IMPROPER INSTALLATION WILL
INVALIDATE YOUR WARRANTY
8
Installation
Leg Attachment
LEG VARIATIONS
Legs are available in 4(101mm), 6 (152mm) āor ā25ā(635mm) ālengths āāor āālow profile casters. The 6" legs are used on the lower section of a double stacked unit. The 4" legs may be used with the optional stands if additional height is reĆ quired or when mounting on a counter. The 25 legs are used for a single unit located on the floor.
NOTE: For safety reasons, casters must not
be used with the 25" legs.
25 Adjustable Leg
LEG ATTACHMENT
1. Align the threaded stud on one of the front legs to the bolt āholeā locatedāāā ināā ātheā āāunit'sā botĆ tom ācorner. Turn the leg clockwise and tightĆ en to the nearest full turn.
2. Align the leg plate holes with the bolt holes. Secure with the two 1/2" bolts provided.
3. Repeat the above steps with the other front leg. If low profile casters are used, install
them with the locking casters in the front of the oven. The rear casters do not lock. EnĆ
sure that the locks are set on the front casters.
4. Tip the unit up on the newly installed front legs. If ācastersā are āused, checkā thatā the locksā areā setā on ātheā front casters. āRepeat āthe above steps for the rear legs.
5. Except for units with casters, level the steamer by screwing the adjustable feet in or out as necessary.
6 Adjustable Leg
4 Leg
Low Profile Casters
9
Installation
Stacking Ć Double Section Assembly
STACKING
1. Install 6" legs or casters on the bottom unit, using three .50Ć13 UNC bolts provided per leg or caster. If casters are used, ensure that the casters with brakes are located on the front of the steamer. See STEP 1.
Do Not Remove Body Top
Caster with Brakes
STEP 1
2. Lift and mount the upper unit onto the lower unit. Flush the edges on all four sides. ReĆ move the louvered panel and body back of both units. Remove the lower body back from the top unit. See STEP 2.
Remove
Body Back
Remove
Lower
Body Back
Remove
Body Back
Remove Louvered Panel and Save Screws
STEP 2
3. Bolt the upper and lower units together with the .50Ć13 UNC bolts provided. See STEP 3.
PLUMBING
1. Attach copper Tee, gray hose and clamps to the drain outlet of both units.
NOTE: The installation plumber is reĆ
sponsible for connections beĆ tween units and connection to drain. Use a 24" section on top unit Tee to raise breather vent. See STEP 4.
Breather Vent
Plumber Installed
Connection
24.00" Long
Tee, Hose
and Clamps
Plumber Installed
Connection
Tee, Hose
and Clamps
Plumber Installed
Connection To Drain
STEP 4
WARNING!
Improper installation, adjustment, alĆ teration service or maintenance can cause property damage, injury or death. Read the installation, operaĆ tion and maintenance instruction thoroughly before installing or servĆ icing this equipment.
Bolt Through
Holes Closest to
Oven Center
STEP 3 (Rear of Units)
10
Installation
Final Check and Adjustments
BEFORE SWITCHING THE APPLIANCE ON
Before applying power to the unit for the first time, check for the following conditions:
1. All āelectricalā safety provisions have been adĆ hered to and the electrical connections are correct.
2. Water is connected, turned on and all of the connections are water tight.
NOTE: The first time the unit is turned on, or
after the unit has been OFF for 5 hours and then turned on, āit āwill autoĆ matically flush the steam generator for a period of 75 seconds. The steam generator will then fill to the proper water level. The unit is now ready for operation.
DOOR ADJUSTMENT
The door catch may be adjusted in two direcĆ tions, in and out, and up and down, using the folĆ lowing procedure:
1. Adjust catch up and down by loosening the two boltsā holdingā theā catch to the face of the unit (A).
2. Make āadjustmentsā soā thatā theā leadingā face of the catch is centered in the opening of the handle assembly.
3. Tighten the bolts so that there is no further movement.
4. Adjust catch in and out by loosening the bolt on the top of the catch (B).
5. The āāadjustment āāface āāis āstepped āso āthat movement is limited with the bolt tightened properly.
6. The āadjustment āis ācorrect āwhen āthe ādoor closes firmly and no steam leaks from the gasket.
The hinges can also be adjusted as follows:
1. Be certain the catch is adjusted properly.
2. Adjustā hinges āso āthatā the door back and the unit face are parallel (C).
3. The adjustment is correct when no steam leaks through the gasket.
Steamer
B
A
Door
Door Adjustment
11
C
Operation
Steamer StartĆUp and ShutĆDown
STEAMER STARTĆUP
Turn the mode switch to STEAM.
STEAM MODE
Turn the mode switch selector knob to the
Steam Position.
The green POWER" Indicator lamp illumiĆ
nates on the front control panel.
The steam generator will flush and drain
automatically for 75 seconds if the unit has been off for at least 5 hours.
The steam generator begins to fill. The
FILL" indicator lamp on the front control panel begins to blink with a frequency of 1 second ON/1 second OFF. The convection blowers shut off.
When the steam generator is filled to the
proper level, the convection blower and POWER" indicator lamp turn on.
Steam soon fills the cavity and is controlled
by a nonĆaccessible internal thermostat.
STEAMER SHUTĆDOWN
Turn the mode selector switch to the off poĆ
sition.
12
1. Indicator Light: LOW WATER, FILL
This light flashes when the water level in the steam generator is too low. The appliance shuts off automatically in order to avoid damage. In this case, turn on the water tap or check to see if the flow of water is stopped (See the sections Adjustments" and Decalcifying").
2. Indicator Light: POWER ON
Lights up when the appliance is in operation.
3. Mode Selection
To turn the appliance on, simply turn the Mode selector switch to STEAM.
Operation
Control Panel
1
2
STEAM
4. TIMER 0Ć120 minutes and ON
5. Steam Generator DRAIN/FLUSH Switch
Preheating for the STEAM function
Before the first use of the appliance, daily or after the unit has been idle for 5 hours, preheat with the STEAM function 1Ć2 minutes until the winĆ dow is misted over. The appliance can then be loaded. Otherwise, there is no need to preheat for the STEAM function.
3
4
5
13
Operation
Mode Selection and Operation
1. Toāāāturnāā the āāappliance āāāon,ā āsimply āāāturn āāthe āāMode āāSelector Switch (1) to STEAM:
STEAM
2. Theāā POWER ONāā Indicatorāā Lightā (2)āā will āālightā āup.
3. Set āthe āTIMER ā(3)ā āfor ātheā desiredāā steaming ātimeā or set āit toā āON. āThe āāābuzzer āāwill sound āand ātheā unitā will āāshutā off when the time has expired.
4. At āthe āend āof āthe āspecified time period, the buzzer sounds andā theā appliance āāāwillā āshutā off āāautomatically.āā Moving āāthe Timer āswitchā to ātheā ONā positionāā stops the buzzer and reĆ starts the unit.
5. Theā Mode Selector Switch is also the Main Power Switch. In the OFF position the appliance is not operational.
NOTE: Always disconnect the power supply
before servicing the unit.
1
2
3
14
4
5
Maintenance
Spray Bottle Operating Procedure
1. Unscrewāā ātheā āāsprayerāāā āhead āāāāandāāā āfillā āāāthe conĆ tainer to the MAX mark. Screw the head asĆ sembly āon āfirmlyā toā āensureā āan āāairtight seal. The liquid must be clean and free from forĆ eign matter. Do not overfill Ć space must be left for compressing air.
2. To build up pressure, pump approximately 20 full strokes when the container is filled with liquid. The higher the pressure, the finer the spray. If the container is only partially filled,ā then āmoreā pumping āāis āārequired āto compress the additional air space.
3. To spray, depress the trigger with your thumb.
4. After a period of spraying, the pressure will drop. Restore the pressure by operating the air pump.
Spray Head
Pressure Pump
5. Release pressure after use by inverting the spray head and depressing the trigger or byā slowly āunscrewing ā theā spray āhead assemĆ bly āwhichā willā allow āairā toā escape āfrom around āāāthe filling aperture.
6. Afterā use,ā rinse āthe āsprayā bottleā withā clean water and check that the hole in the nozzle is āperfectly āclean āand clear. Warm water (notā hot)ā usedā withā aā household ādetergent is a useful cleaning agent for this purpose.
NOTE: Further information can be found in
the instruction leaflet supplied with your spray bottle.
Spray Trigger
Pump
Pressure Vessel
NOTE: Clean the pump 2 or 3 times
per week with warm water
PROTECTIVE CLOTHING AND EYEWEAR SHOULD BE WORN
WHILE USING CLEANING AGENTS
MAX
WARNING!
15
Maintenance
Cleaning and Preventive Maintenance
CLEANING THE STEAMER'S INTERIOR
Daily cleaning of the appliance is essential for sanitation, and to ensure against operational difĆ ficulties. Use an oven cleaning detergent in conĆ junction with the supplied spray bottle.
For difficult cleaning, allow the sprayĆon oven cleaner to work longer before rinsing.
1. Cool āāthe āsteamer down to 140F/60C or,
if the āāunitāā has āābeenā āidle, āāturnā the steam modeā onā foār 3 āto ā4ā minutesā inā order āāāto warm the steamer surfaces.
2. Fill āāāāātheāāā āsprayāāā ābottleā āāandāāā pump āāāairā āāintoāā āthe container with the pressure pump.
3. Spray āāthe āinteriorā of āātheāā unitā with a cleaning solution.
4. Let āthe ācleanerā āworkāā for āā10ā toā 20 minutes withāāāāā the āāāāunit āāāāoff.āāā āForā āādifficult cleaning allow to work over night.
5. Set the timer for 15 to 20 minutes.
6. Set āātheā āmodeā āāselector switch to Steam. This will soften all residue.
7. Rinseāā āātheāāā āunit'sāāāāā interiorā āāāwithāāāāā waterāā. A hose mayāā ābeāā āused,āā ābut āāātakeāā careā thatā only āātheā āsteamer'sā interior cavity is sprayed with waĆ ter.
8. Setā āāātheā āāāmode āāāselectorāāā toā āāSteam āāāforā anotherā five minutes to flush out the steamer interior and remove all detergent residue.
NOTE: The āsteamer ācavity ā should ā never ā be
scoured or scraped.
On stainless interiors deposits āmay ābe āremoved āwith āany of the following elements: Grade FFF Italian Pumice, Liquid Nu Steel, Permapass, SaĆ mea or Cameo Paste, Nu Steel or DuBois Temp. Heat tint or heavy discolorations may be reĆ moved with any of the following: PennyĆBrite, CopperĆBrite, DuBois Temp., Paste NuĆSteel, 5% to 15% nitric acid āor ā5% āto 15% phosphoric acid. Apply cleaners when the steamer is cold and always rub with the grain of the metal. The interior of the Blodgett Combi Convection Steamer can easily be cleaned with oven cleanĆ ers such as DuBois Chemical's Oven āCleaner And Degreaser, Economics Laboratories' GreaĆ secutter or Greasestrip or Malone Chemical's MaloneĆ34. The racks and rack supports may be cleaned in the steamer or by removing them from the āunit āand āsoaking āthem in a solution of ammonia and water.
NOTE: DO NOT use corrosive cleaners on
the Steamer.
CLEANING THE STEAMER'S EXTERIOR
The Convection Steamer's exterior may be cleaned and kept in good condition with a light oil. Saturate a cloth and wipe the unit when it is cold; wipe dry with a clean cloth.
NOTE: The outside of the appliance is not to
be sprayed with water.
PREVENTIVE MAINTENANCE
The best preventive maintenance measures are the āāāproper āāinitial āāinstallation āāof āāthe equipment and a program for cleaning the unit routinely. The Steamer requires no lubrication. However, the venting system should be checked annually for possible deterioration resulting from moisĆ ture and corrosive flue products. Contact the factory, the factory representative or a local Blodgett Combi service company to perform maintenence and repairs should they be reĆ quired.
WARNING!
DISCONNECT APPLIANCE FROM POWER SUPPLY BEFORE SERVICING OR CLEANING
16
Maintenance
Decalcification
1. Turn the Mode Selection Switch (1) to the STEAM mode. Wait until steam is produced. This will ensure that the water in the steam generator is hot.
2. Turn the Mode Selection Switch (1) to the COOL DOWN mode and leave the door open. Let the oven compartment cool to 150F (66C). This ensures that the Drain/ Flush switch will function in STEP 8.
3. Turn the Mode Selection Switch (1) to OFF.
4. In a suitable size container, mix together the deliming solution and hot tap water. Refer to the following chart for the proper mixture:
Deliming
Model
COSĆ6 12 oz. 3 quarts
COSĆ101 18 oz. 1Ć1/4 gallons
COSĆ101S 18 oz. 1Ć1/4 gallons
COSĆ8E 30 oz. 2Ć1/2 gallons
BCSĆ8E 30 oz. 2Ć1/2 gallons
COSĆ8G 24 oz. 2 gallons
Solution Hot Tap Water
5. Remove the Deliming Port Cap. Attach the supplied Funnel and Hose Assembly (3) to the deliming inlet.
6. Open the Deliming Port Valve (2) and pour in the deliming mixture. Stop pouring when the funnel stops draining. This is the correct amount for your site.
7. Shut the Deliming Port Valve (2). Screw on the Deliming Port Cap. Let the mixture stand for 20 minutes. In areas of the country with hard water, allow the mixture to stand for 1 hour.
8. Depress and hold the Drain/Flush Switch (4) in the FLUSH position for 90 seconds. This completes the deliming procedure.
3
open
2
BCSĆ8G 24 oz. 2 gallons
COSĆ20G 33 oz. 2Ć3/4 gallons
BCSĆ20G 33 oz. 2Ć3/4 gallons
COSĆ20E 27 oz. 2Ć1/4 gallons
BCSĆ20E 27 oz. 2Ć1/4 gallons
NOTE: These volumes are approximate.
You may need slightly more or less hot water depending on your site.
close
1
4
17
Steaming Guide
General Tips and Procedures
CONTAINERS
Both solid and perforated steam table pans of varying sizes (full, half, and oneĆthird size) may be used in the Blodgett Combi Steamer. Small pans may be placed on wire racks. This flexibility makes the Combi Steamer an ideal tool for a wide variety of cooking needs, from full course meals to à la carte preparation.
STEAMING TIMES
The length of the steaming process depends on the quality, weight and thickness of the food product.
TEMPERATURES
Typically, the longer the steaming process, the lower the temperature.
LOADING THE STEAMER
Place the food in the appropriate pans/trays or distribute it on the racks. Insert racks and trays into the pan rack. It is recommended that the pan rack be loaded outside of the steamer when processing large amounts of product. The pan rack for table models āis āwell āsuited āfor this purĆ pose; it allows āfor a higher hourly production and an efficient work sequence.
REMOVING THE PRODUCT
Turn the Mode Selector Switch to OFF before opening the appliance door.
NOTE: Open the door slowly after steaming!
Hot Steam Will Be Present!
18
Steaming Guide
General Tips and Procedures
TIPS AND PROCEDURES
Stocks for Sauces
When trays are used for steaming there is usualĆ ly enough stock collected for making sauces. When using perforated pans, insert a solid pan in the bottom rack to collect the stock.
Seasoning
Since there is no liquid added during the steamĆ ing process, season using one of the following methods:
D Seasoning before cooking:
Sprinkle the spice mixture evenly over the food prior to cooking.
D Oil seasoning after cooking:
Stir the oil mixture into the product. Seasoned oil mixes easily and gives many foods an apĆ petizing taste and aroma. Steam again for two minutes in some cases.
Blanching and Prep Work
Large amounts of product can be blanched in a short amount of time. Trays should not be filled higher than 3 inches.
The STEAM mode is excellent for preparing vegĆ etables for peeling.
Canning and Preserving
The diameter of the containers must not exceed 4Ć5 inches when canning.
Thawing
Thawing time is much shorter when using steam and produces higher quality food.
Rethermalizing
The use of steam creates an even distribution of heat, which gives food better taste and retention of nutrients.
Foods are rethermalized in the trays in which they were cooked. Rethermalizing times vary according to the height and content of the conĆ tainers.
SAMPLE DISHES
Vegetables
Fresh and frozen vegetables may be steamed together. Frozen vegetables should be loosely scattered on the trays. Perforated trays shorten steaming time, although solid trays may be used.
Steaming times will vary depending on the qualiĆ ty of the vegetables. When āsteaming āfresh āvegeĆ tables, āācheck the product 3/4 of the way through the āācooking āāperiod.
Vegetables tend to soften after steaming. āāāSinceāāāthereāāāāisāāāāaāāāādelay between cooking and servĆ ing, it is best not to steam āvegetables too āsoft.ā Thisā āis āāespecially important for foods prepared for transport.
Rice and Potatoes
Rice requires the addition of water for steaming. Remember that the rice continues to swell after steaming; plan your quantities accordingly.
Always steam potatoes in perforated pans. Steam can permeate the potatoes better if they are quartered through the width and not the length.
Eggs
Eggs are inserted onto wire racks, either in the cardboard container or placed into perforated trays (there is no need to puncture them). This saves work and results in less waste since steamed eggs do not break. Also, the degree of hardness ācan ābe ācontrolled āexactly. Begin timĆ ing when the oven window is misted over.
Fish
Fish ācan ābe steamed āin āātrays āāwithout using extra stock. Use a 1 inch pan for fresh fish (Fillets). For larger or frozen pieces, use a 2 inch pan.
Poached fish can be prepared with aromatic herbs āand āvegetables āin āeither āsolid āor perfoĆ rated pans. Steam without stock.
Shell fish can be steamed in perforated pans. Use a solid pan to catch drippings for stock.
19
Notes
20
Loading...
