Blaupunkt ACD 9850 User Manual

Operating instructions

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

ESPAÑOL

ACD 9850

PORTUGUÊS

1

ENGLISH

1

2 43 5

12

11 10

9

FRANÇAIS

ITALIANO

NEDERLANDS

78

6

SVENSKA

ESPAÑOL

PORTUGUÊS

3

Table of contents

Short instructions ........................ 16

Important notes ............................ 19

What you really have to read ................ 19

Traffic safety ......................................... 19

Installation/Connection.......................... 19

Anti-theft coding........................... 19

Entry of a wrong code number.............. 19

Switching the code system on .............. 20

Restart following an interruption of the

power supply ......................................... 20

Switching the code system off .............. 20

Switching the code-LED on/off.............. 20

Radio operation with RDS ........... 21

AF - Alternative frequency .................... 21

REG - regional program ........................ 21

Selecting a station................................. 22

Selecting stations automatically ........ 22

Selecting stations manually ............... 22

Selecting the station search sensitivity . 22
Separate adjustment of the sensitivity

levels for local and distant reception..... 22

Switching from stereo to mono ............. 22

Changing the memory bank .................. 23

Storing stations ..................................... 23

Automatically storing the strongest

stations with Travelstore ....................... 23

Recalling stored stations ....................... 23

Receiving traffic information

stations with RDS-EON ................ 24

Traffic announcement priority on/off ..... 24

Warning beep........................................ 24

Switching the warning beep off.......... 24

Automatic seek tuning start................... 24

Adjusting the volume for traffic announce-

ments and the warning beep................. 24

CD operation................................. 25

Inserting the disc................................... 25

Ejecting the disc .................................... 25

Selecting a track ................................... 25

The Mix function.................................... 25

Changing the audio source with SRC ... 25

The Loudness function.......................... 25

Summary of default settings made at the

factory ................................................... 26

Appendix....................................... 26

Specification.......................................... 26

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

15

ESPAÑOL

PORTUGUÊS

Short instructions

1 On/Off

Turn button.
On
Off

To adjust the volume:

Turn button.

2 LD / AUD

LD - Loudness

When listening at a low level, the Loud­ness function will create a more natural
sound by boosting the bass frequen­cies.

To switch the Loudness on/off: Press
AUD until “LOUD ON” or “LOUD OFF”

is displayed.
Extra function:

To adjust the bass boost level.
AUD – Audio

To adjust the

BASS
TREBLE
BALANCE (left/right volume)
FADER (front/rear volume).

To alter a setting:

Press AUD briefly until the abbreviation
of the desired mode and the correspon­ding value appear in the display.

Use the buttons to alter the selec­ted setting (will be indicated in the dis­play). The last adjustment will be stored
automatically.
If the setting remains unchanged within
8 seconds, the display will switch back
to the previous condition.

3 MIX / lo

MIX - If “MIX” lights up in the display,

the CD titles will be played at random.

To switch on/off: Press button briefly.
lo (local) - seek tuning sensitivity during

radio operation.
“lo” lights up in the display - normal
seek tuning sensitivity. The system will
only pick up powerful nearby stations.
“lo” does not light up in the display ­high seek tuning sensitivity. The system
will also pick up weaker stations.
To switch over: Press MIX/lo briefly
during radio operation.

Extra function:

To adjust the seek tuning sensitivity
separately for local and distant re­ception.

Stereo/mono switching:

Keep button depressed until “MONO
OFF” or “MONO ON” appears in the
display.

4 CD slot

Insert the disc with the label side facing
up. The system will automatically
switch from radio to CD operation.

/ SRC

5

To eject the disc:

Hold button depressed until the disc is
ejected.

To switch between radio and CD
operation:

Press button briefly while a CD is being
played.

Extra function:

To switch the code-LED on/off.

16

6 1, 2, 3, 4, 5, 6 - preset buttons

You can store six stations on each FM
memory bank (I, II, T).
To store a station: Press button du­ring radio operation and hold down until
the radio resumes play.
To recall a station: Select the desired
memory bank pressing the FM

T button

and press the relevant preset button
briefly.

Extra function:
Coding: Read chapter “Anti-theft co­ding” first.
Buttons 1, 2, 3, 4 - To enter the four-
digit code.
Press each of the buttons as many
times as required until the code num­ber given in the car radio passport
stands in the display.

7 TA (priority for traffic announcements)

When “TA” is displayed, the system will
only tune into stations offering traffic
information.
To switch TA on/off: Press the TA but­ton.

Extra function:

To adjust the traffic message and
warning beep volume.

T

8 FM

To switch between the FM memory
banks:

Press button until the desired memory
bank (I, II, T) is displayed.

T - Travelstore

To store and recall the six most power­ful stations of your current reception
area.

To store with Travelstore:
Press FM

T until the search starts in the

display. The system will store the found
stations automatically.

To recall a station stored with Tra­velstore:
Press FM

T until “T” is displayed. Then

briefly press one of the presets 1-6.

9 AF

(Alternative Frequency during RDS
operation)
When “AF” lights up in the display, the
radio will automatically search for a
frequency offering better reception of
the same RDS program.
To switch AF on/off: Press AF briefly.

Extra functions:
REG ON / REG OFF - With REG ON
the system will only switch to an alter-

native frequency if the latter belongs to
a linked station offering the same regio­nal program (see “REG - regional pro­gram).

Manual station tuning:

When AF is switched off, the system
will automatically switch to manual sta­tion tuning.
Use the

buttons to alter the fre-

quency in steps of 50 kHz.

17

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

ESPAÑOL

PORTUGUÊS

: Display

Radio operation

; Code-LED

May flash for additional theft protection
when the car radio is switched off.

a

c jd e

g

f h

i k

l

CD operation

b

m

n

a) NDR2 - Station name
b) 1 : 52 - Playback time
c) FM - Waveband
d) 6 - Preset button (1-6)
e) I, II, T - Memory bank I, II, or T
f) CD-IN - A CD is inserted
g) - Stereo reception
h) lo - Seek tuning sensitivity
i) AF - Alternative RDS frequency
j) TA - Priority for traffic information

k) TP - The system receives a traffic

l) LD - Loudness 2 extra AUD

m) MIX - Playback of CD tracks in

n) T5 - Track number

stations

program

function

random order

<

Station tuning – automatically, if “AF”

lights up in the dis­play.

– manually, if “AF” is

off.

Switch with AF,

9 AF.

18

Important notes

Anti-theft coding

What you really have to read

Before you operate your new car radio, plea­se read the information on “Traffic safety”
and “Anti-theft coding” carefully.

Traffic safety

As the driver of a motor vehicle, it is your
responsibility to pay attention to the traffic
situation at all times. Never use your car radio
in a way that could distract you.
Please keep in mind that you travel a di­stance of 14 m per second at a speed of only
50 km/h.
Should the traffic situation become particu­larly demanding, we advise you not to use the
radio.
Always make sure that you are still able to
hear any warning signals coming from outsi­de of the vehicle, such as police or fire engine
sirens, so that you can react accordingly.
Always select a moderate volume for playing
your car radio while you are driving.

Installation/Connection

If you would like to install this equipment
yourself or add any new components, then
please read the enclosed installation and
connection instructions carefully.
Do not connect the loudspeaker outputs to
ground!
Use only the accessory and replacement
parts approved by Blaupunkt.

This car radio is supplied with inactive code
protection. In order to switch the anti-theft
coding system on, proceed as described in
the following.
If the code protection system is active while
the power supply to the system is interrupted
(e.g. theft, disconnection of the car battery),
the set will be electronically blocked. In such
a case it can only be made operable again by
entering the correct code number given in the
car radio passport.

Entry of a wrong code number

It should not be possible for a thief to find out
the correct code number by a simple trial­and-error operation. This is why the set will
be blocked for a certain period of time after a
wrong code number was entered. The dis­play will then show “- - - -”.
The waiting time is 10 seconds after the first
three attempts and one hour following subse­quent trials.
After 19 unsuccessful attempts the display
will show “OFF”, making it impossible for you
to restart the unit.

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

19

ESPAÑOL

PORTUGUÊS

Note:

Keep your car radio passport including the
code number in a safe place in order to avoid
“unauthorised access” to your car radio.
If the power supply to the unit is interrupted
while the code system is switched on, you
need to know the right code number.
The radio will function again as soon as you
have entered the correct code.
If you have lost your radio passport and
forgotten the code number, your radio can
only be made operable again by one of our
authorised customer service workshops,
which is subject to payment.

Switching the code system on

To activate the code system:

• Turn off the radio.

• Press preset buttons 1 and 4 simulta­neously, hold down and

• turn the set back on again.
The display briefly shows “CODE” befo-

re the set is switched on.

• Release presets 1 and 4.

Now the code system is activated.
In future, “CODE” will always be briefly dis­played each time the radio is turned on.

Restart following an interruption
of the power supply

(code system is activated)

• Turn on the radio.
The display shows “CODE”.

• Briefly press preset button 1, the dis­play shows “0000”.

• Enter the code number given in the car
radio passport:

Example: The code number is 2521.

- Press preset button 1 twice; the dis-

play shows “2000”.

- Press preset button 2 five times; the

display shows “2500”.

- Press preset button 3 twice; the dis-

play shows “2420”.

- Press preset button 4 once; the dis-

play shows “2521”.

• To confirm the code number:
Press the rocker button

Now your car radio is ready for operation.
However, if the display again shows four

dashes, you have made a mistake. In this
case go ahead entering the correct code
number after the waiting period has elapsed
(“CODE” in the display).

.

When turning the radio off during the waiting
time, this period is reset and will start anew as
soon as the unit is switched on again.

Switching the code system off

• Turn off the radio.

• Press preset buttons 1 and 4 simulta­neously, hold down and

• turn the set back on again.
The display shows “CODE”.

• Now enter the code number of the car
radio passport and confirm (see ex­ample under “Restart ...”.

The code system is switched off.

Switching the code-LED on/off

When the car is stationary, you may let the
LED below the display flash for additional
theft protection.
Condition: The function is switched on (“LED
ON”)
To switch on/off (radio turned on, no CD
inserted):

• Press
OFF” is displayed.

• Use the
desired mode.

/ SRC until “LED ON” / “LED

buttons to activate the

20

Radio operation with RDS (Radio Data System)

The last adjustment will be stored automati­cally.
If the setting remains unchanged within 8
seconds, the display will switch back to the
previous condition.

On FM, the Radio Data System offers you
more convenience when listening to the ra­dio.
More and more radio stations have begun to
broadcast RDS information alongside their
programs.
As soon as a program has been identified,
the station name including a regional identi­fier, if applicable, will appear in the display,
for example, NDR1 NDS (regional program
in Lower Saxony, Germany).
When RDS is activated, the station buttons
become program buttons. You now know
exactly which program you have tuned into,
making it easy to find the desired station
quickly.
But RDS offers you further advantages:

AF - Alternative frequency

The AF (Alternative Frequency) function
makes sure that the strongest frequency of
the currently selected program is always
tuned in automatically.
This function is activated when “AF” appears
in the display.
In order to switch this function on or off,

• press the AF button briefly.
While the radio is searching for the strongest

reception signal, it will switch to mute briefly.
When “SEARCH” appears in the display after

the radio has been switched on or one of the
stored frequencies recalled, the radio is auto­matically searching for an alternative fre­quency.
“SEARCH” will disappear from the display
when the alternative frequency has been
found or the complete frequency range has
been run through.
If the reception quality of the selected pro­gram becomes too bad,

• tune into another station.

REG - regional program

Certain radio programs are split up at times
into regional programs offering local informa­tion. The 1st program broadcast by NDR, for
example, offers programs with different con­tents in the northern states of Germany
Schleswig-Holstein, Hamburg and Lower
Saxony at certain times of the day. If you are
listening to one program and move to an area
where another linked regional program beco­mes stronger, the unit will switch to that
program.
If you wish to continue listening to the first
station,

• press the AF button for approximately 2
seconds. “REG ON” appears in the
display.

21

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

ESPAÑOL

PORTUGUÊS

If you leave the service area of the regional
program tuned into, or if you would like to take
advantage of the full RDS service, then
switch to “REG OFF”.

• Press the AF button for approximately
2 seconds until “REG OFF” appears.

If REG ON is activated, “REG ON” will appear
in the display briefly each time the radio is
switched on.

Selecting a station

With this car radio you can receive FM stati­ons between 87.5 and 108 MHz.

Selecting stations automatically

Condition: AF is switched on!

• Press
cally search for the next receivable sta­tion.

When keeping the
sed, seek tuning will speed up in upwards or
downwards direction.

Selecting stations manually

Condition: AF is switched off!

• Press
small steps in downwards or upwards
direction.

; the car radio will automati-

or the button depres-

; the frequency will change in

When holding the
down, the frequency scan is speeded up.

or the button pressed

Selecting the station search
sensitivity

You can alter the sensitivity of the automatic
station search.
For this purpose:

• Press the lo button briefly.
If “lo” is displayed, the radio will only pick up

strong nearby stations (low sensitivity).
If “lo” does not light up, the radio will also pick
up less powerful stations (higher sensitivity)

Separate adjustment of the sensitivity
levels for local and distant reception

The sensitivity levels for local and distant
reception can be adjusted separately:

a) Local reception

• Press the MIX / lo button to switch
to “lo” (lights up in the display).

• Keep MIX / lo depressed until “S-
LO” and the adjusted value are dis­played (follows after “MONO OFF”
or “MONO ON”).

Use the buttons to alter the sensitivity
value (“1” corresponds to high sensitivity, “3”
corresponds to low sensitivity).
The last adjustment will be stored automati­cally.
If the setting remains unchanged within 8
seconds, the display will switch back to the
previous condition.
Press MIX / lo to switch back immediately.

b) Distant reception

• Press the MIX / lo button to switch
to “dx” (“lo” disappears from the
display).

• Keep MIX / lo depressed until “S-
DX” appears in the display. The
adjustment is made as described
under “a) Local reception”.

Switching from stereo to mono

If reception is poor, you may get better sound
quality by switching to mono:

• Hold down the MIX / lo button until
“MONO OFF” or “MONO ON” appears
in the display.
The stereo symbol
mono playback.

Each time the radio is switched on, stereo
playback is activated.
The unit will automatically switch to mono
playback under poor reception conditions.

will disappear for

22

Changing the memory bank

You can shift between the memory banks I, II
and T in order to store stations and recall
them later.
The currently selected memory bank is indi­cated in the display.

• Press the FM

T button until the desired

memory bank lights up in the display
(press repeatedly if necessary).

Storing stations

You can store six stations on the preset
buttons 1 to 6 for each of the memory banks
I, II, and T.

• Use the FM
mory bank.

• Select a station with the rocker buttons

• Press the desired preset button until
the radio resumes play after the muting
or until you hear a BEEP.

Now the station has been stored.
The activated preset button is indicated in the
display.

T button to select the me-

(either automatically or manually).

Automatically storing the stron­gest stations with Travelstore

You can automatically store the six most
powerful stations of your current reception
area sorted according to their signal
strength.
This function is particularly convenient on
longer trips.

• Press the FM

T button for at least 2 se-

conds.

The radio will search for the receivable FM
stations and store them on the memory bank
T (Travelstore). When this process has been
completed, the radio will tune into the stron­gest station.
If desired, stations can also be stored manu­ally on the Travelstore bank (see “Storing
stations”).

Recalling stored stations

You can recall any stored station at the touch
of a button.

• Select the desired memory bank by
pressing FM
indicated in the display.

• Press the corresponding preset button
briefly to recall the station.

T until the desired bank is

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

ESPAÑOL

23

PORTUGUÊS

Receiving traffic information stations with RDS-EON

Many FM broadcasters provide their service
area with traffic messages at regular inter­vals.
All traffic program stations transmit a special
telegram signal alongside their programs,
which your car radio can evaluate. If this
signal is identified, “TP” will appear in the
display (Traffic Program).
In addition to these, there are also stations
which do not actually transmit traffic informa­tion themselves, such as NDR3, but by using
RDS-EON they make it possible to receive
the traffic messages broadcast by another
traffic information station in the same radio
network. If you listen to one of these stations,
“TP” will appear in the display as soon as the
priority for traffic information stations is acti­vated, i.e. “TA” lights up.
If a traffic announcement is broadcast, the
radio will automatically switch to the linked
traffic information station (in this case,
NDR2) for the duration of the message and
return to the original program (NDR3) after­wards.

Traffic announcement priority
on/off

If the priority for traffic announcements is
activated, “TA” will light up in the display.

To switch the priority on or off:

• Press the TA button.
When pressing TA while a message is being

broadcast, the priority will be cancelled only
for this announcement. The unit will then
switch back to the previous condition. The
priority for other traffic messages remains
active.

Warning beep

If you leave the reception area of the traffic
information station currently tuned into, you
will hear a warning beep after approximately
30 seconds.
This alarm tone will also be released when
pressing a preset button which has no traffic
program allocated to it.

Switching the warning beep off

a) Tune into another traffic program station:

• Press

• press a preset button with a traffic
program station allocated to it.

Alternatively:
b) Switch the priority for traffic announce-

ments off:

• Press TA.
“TA” will disappear from the display.

, or

Automatic seek tuning start

(CD operation)

When leaving the reception area of the traffic
information station tuned into while listening
to a CD, the system will automatically start
searching for a new TA station.
If no such station is found within approxima­tely 30 seconds, CD playback is stopped and
a warning beep will sound. To switch the
warning beep off, proceed as described abo­ve.

Adjusting the volume for traffic
announcements and the warning
beep

This volume was preset at the factory.
If you would like to alter the setting, proceed
as follows:

• Adjust the volume to the same level
that you also wish to be used for play­back of the traffic announcements and
the warning beep.

• Then press TA until “TA-VOL” appears
in the display.

This volume will be stored for the traffic
messages and the warning beep.

24

CD operation

Inserting the disc

• Turn on the radio.

• Insert the CD (label side facing up)
without applying force.

The disc is automatically pulled into the set to
reach the playback position. Then CD repro­duction starts.

Ejecting the disc

• Press the / SRC button for more than
2 seconds. The disc will be ejected.

To protect the CD mechanism, the automatic
insertion or ejection of the disc must not be
impaired in any way.

Selecting a track

The activated CD functions will appear in the
display as soon as the disc is inserted.
Use the
title.

•

When pressing the
playback will start at the beginning of the
currently played track.
The rocker buttons have a sequence switch
function, i.e. several tracks can be skipped at

buttons to select the desired

= To skip titles.
= To repeat titles.

button only once, CD

a time by pressing the corresponding button
repeatedly.
After the “T” (standing for “Track”), the
system shows the track number of the cur­rently selected piece of music.

Fast forward (cue):

• Keep the rocker button

depressed.

Fast backward (review):

• Keep the rocker button

depressed.

The Mix function

When the Mix function is activated, all CD
titles will be played in random order. In this
case, “MIX” lights up in the display. To skip a
track, press the rocker button

.

To switch the Mix function on/off:

• Press MIX.

Changing the audio source with
SRC (source)

When a disc is inserted, you can use the /
SRC button to shift between CD playback

and radio operation.
To switch over:

• Press

/ SRC briefly.

The Loudness function

When listening at a low level, the human ear
is less sensitive to the bass frequencies than
to the treble frequency range.
The Loudness function compensates for this
effect by emphasising the low frequencies at
reduced volume levels.
Since the individual sensation of sound is
influenced by the type of system used (ampli­fier), the location and type of the employed
loudspeakers, and by the vehicle itself, the
Loudness threshold and the bass boost level
can be adjusted.
The bass boost level was adjusted at the
factory such that a natural sound impression
is obtained over a wide frequency range.
However, you may also alter the Loudness
setting. In this case, proceed as follows:

• Press the LD/AUD button until “LOUD”
and the adjusted value appear in the
display (you find this item after “LOUD
ON” / “LOUD OFF”).

• Use the
boost. “1” corresponds to the lowest,
“6” to the highest efficiency level.

The last adjustment will be stored automati­cally.
If the setting remains unchanged within 8
seconds, the display will switch back to the
previous condition.

buttons to adjust the bass

25

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

ESPAÑOL

PORTUGUÊS

Appendix

Summary of default settings
made at the factory

LOUDNESS 3
S-DX 2
S-LO 2
LED ON

Specification

Amplifier

Output power: 4 x 19 watts RMS po-

wer acc. to DIN 45324
4 x 20 watts max. po­wer acc. to DIN 45324

FM

Sensitivity: 0.9 µV at 26 dB signal-

to-noise ratio
Frequency
range: 30 - 16,000 Hz (-3dB)

CD

Frequency
range: 20 - 20,000 Hz (-1dB)

26

Subject to modifications!

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

NEDERLANDS

SVENSKA

ESPAÑOL

Blaupunkt-Werke GmbH

Bosch Gruppe

1/95 K7/VKD 3 D95 162 001 PM

15

PORTUGUÊS
