Fruit & Vegetable Juicer
FRUIT AND VEGETABLE
JUICE EXTRACTOR
EXTRACTOR DE JUGO PARA
FRUTAS Y VEGETALES
use and care manual
manual de uso y cuidado
JE2500B
JE2500B_29529_ES_IB_E.indd 1JE2500B_29529_ES_IB_E.indd 1 11/21/22 1:52 PM11/21/22 1:52 PM
Thank you for your purchase!
Gracias por su compra!
www.prodprotect.com/blackanddecker
Should you have any questions or concerns with your new product,
please call our Customer Service Line at 1-800-465-6070 (US).
Please do not return to the store.
Si usted tiene alguna inquietud o pregunta con su producto, por
favor llame a nuestra línea de servicio al cliente una atención
inmediata 1-800-465-6070 (EE.UU) 01-800-714-2503 (México).
No devuela a la tienda.
2
JE2500B_29529_ES_IB_E.indd 2JE2500B_29529_ES_IB_E.indd 2 11/21/22 1:52 PM11/21/22 1:52 PM
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS.
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following:
• Read all instructions.
• To protect against risk of electrical
shock, do not immerse cord, plug
or base unit in water or other
liquid.
• Close supervision is necessary
when any appliance is used by or
near children.
• Turn the appliance OFF, then
unplug from the outlet when
not in use, before assembling or
disassembling parts and before
cleaning. To unplug, grasp the plug
and pull from the outlet. Never pull
from the power cord.
• Avoid contact with moving parts.
Do not attempt to defeat any
safety interlock mechanisms.
• Do not operate any appliance
with a damaged cord or plug or
after the appliance malfunctions
or is dropped or damaged in any
manner. Contact the consumer
service number listed in this
manual.
• This appliance has important
markings on the plug blade. The
attachment plug or entire cordset
(if plug is molded onto cord) is
not suitable for replacement. If
damaged, the appliance shall be
replaced.
• The use of accessories or
attachments not recommended
or sold by the manufacturer may
cause re, electric shock or injury.
• Do not use outdoors.
• Do not let cord hang over edge of
the table or counter.
• Always make sure juicer cover
is clamped securely in place
before motor is turned on. Do not
unfasten clamps while juicer is in
operation.
• Be sure to turn switch to OFF (0)
position after each use of your
juicer. Make sure the motor stops
completely before disassembling.
• Do not put your ngers or other
objects into juicer opening while
it is in operation. If food becomes
lodged in opening, use food pusher
or other piece of fruit or vegetable
to push it down. When this method
is not possible, turn the motor off
and disassemble juicer to remove
the remaining food.
• Do not use this appliance if the
cutter/strainer is damaged.
• Do not operate the juice extractor
without pulp container in place.
• This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use
of the appliance by a person
responsible for their safety.
• Children should be supervised to
ensure that they do not play with
the appliance.
3
JE2500B_29529_ES_IB_E.indd 3JE2500B_29529_ES_IB_E.indd 3 11/21/22 1:52 PM11/21/22 1:52 PM
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will t into a polarized outlet
only one way. If the plug does not t fully into the outlet, reverse the plug.
If it still does not t, contact a qualied electrician. Do not modify the plug
in any way.
TAMP ER-RESI STANT SCR E W
Warning: This appliance is equipped with a tamper-resistant screw to
prevent removal of the outer cover. To reduce the risk of re or electric
shock, do not attempt to remove the outer cover. There are no userserviceable parts inside. Repair should be done only by authorized service
personnel. For service, repair or any questions regarding your appliance,
please call our Customer Service Line at 1-800-465-6070 (US and Canada).
ELECTRICAL CORD
a) A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
b) Extension cords are available and may be used if care is exercised in
their use.
c) If an extension cord is used:
1) The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance;
2) If the appliance is of the grounded type, the extension cord should be
a grounding-type 3-wire cord; and
3) The cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over.
Note: If the power cord is damaged, please contact the warranty
department listed in these instructions.
4
JE2500B_29529_ES_IB_E.indd 4JE2500B_29529_ES_IB_E.indd 4 11/21/22 1:52 PM11/21/22 1:52 PM
GETTING TO KNOW YOUR JUICE EXTRACTOR
1
2
3
9
4
5
6
7
10
8
1. Fruit and vegetable pusher
2. Food chute
3. Clear cover
4. Stainless steel cutter/strainer
7. On/off (I/0) control
8. Non-slip rubber feet
9. Removable pulp container
10. Easy clean brush
5. Pulp separator
6. Non-drip spout
Product may vary slightly from what is illustrated.
5
JE2500B_29529_ES_IB_E.indd 5JE2500B_29529_ES_IB_E.indd 5 11/21/22 1:52 PM11/21/22 1:52 PM
GETTING STARTED
This appliance is intended for household use only.
• Remove all packing material, any stickers, and the plastic band around the
power plug.
• Go to www.prodprotect.com/blackanddecker to register your product.
• Wash all removable parts as instructed in CARE AND CLEANING.
HOW TO DISASSEMBLE
1. To remove the pulp container, hold the finger grips
firmly and slide it out, bottom first. (A)
2. To remove the clear cover, take out the fruit and
vegetable pusher, grasp the clear cover and twist
to open. (B).
3. To remove the cutter/strainer, twist open the pulp
separator (C) to release the cutter/strainer.
Caution: The cutter/strainer teeth are very sharp.
Handle carefully.
A
B
C
6
JE2500B_29529_ES_IB_E.indd 6JE2500B_29529_ES_IB_E.indd 6 11/21/22 1:52 PM11/21/22 1:52 PM
