Black & Decker CBM310BD User Manual

COFFEE GRINDER

BURR MILL GRINDER MOLINO DE FRESAS PARA CAFÉ MOULIN À CAFÉ À MEULES

CBM310BD

Thank you for your purchase!

Gracias por su compra!

Merci de votre achat!

Should you have any questions or concerns with your new product, please call our Customer Service Line at 1-800-231-9786 (US and Canada). Please do not return to the store.

Si usted tiene alguna inquietud o pregunta con su producto, por favor llame a nuestra línea de servicio al cliente una atención inmediata 1-800-231-9786 (EE.UU/Canadá) 01-800-714-2503 (México). No devuela a la tienda.

Si vous avez des questions ou des préoccupations à propos de votre nouveau produit, veuillez communiquer avec notre Service à la clientèle au 1 800 231-9786 (États-Unis et Canada). Veuillez ne pas rapporter le produit au magasin.

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS.

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following:

• Read all instructions prior to use.

• To protect against fire, electrical shock and injury to persons, do not immerse cord, plugs or appliance in any liquids.

• Close supervision is necessary when any appliance is used by or near children.

• Unplug appliance from outlet when not in use.

• Avoid contacting moving parts.

• To reduce the risk of severe injury to persons or damage to the appliance, keep hands and utensils out of the grinding bowl while grinding, and when the appliance is plugged in.

• Blades are sharp. Handle carefully.

• Be certain cover is securely locked in place before

operating appliance.

• Do not attempt to defeat the cover interlock mechanism.

• Check container for presence of foreign objects before using.

• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Contact consumer support at the number listed in this manual.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG (120V models only)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to ﬁt into a polarized outlet only one way. If the plug does not ﬁt fully into the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped

with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of ﬁre or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside. Repair should be done only by authorized service personnel.

• The use of accessory attachments that have not been recommended by the appliance manufacturer may result in fire, electric shock or injury to persons.

• Do not use outdoors.

• Do not let cord hang over edge of table or counter, or touch hot surfaces.

• Do not place appliance on or near a hot gas or electric burner, or in a heated oven.

• To disconnect, turn the unit OFF, then remove plug from wall outlet.

• Do not use this appliance for anything other than its intended use.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

ELECTRICAL CORD

1. A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

2. Extension cords may be used if care is exercised in their use.

3. If a long detachable extension cord is used: a) The marked electrical rating of the

power cord or extension cord should be at least as great as the electrical rating of the appliance. b) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord. c) The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over. Note: If the power cord is damaged, please contact the warranty department listed in these instructions.

WELCOME!

Congratulations on your purchase of the Black + Decker Burr Mill grinder! We have developed this guide to ensure optimal product performance for your complete satisfaction. Save this use and care manual and be sure to register your appliance online at www.prodprotect.com/applica.

CONTENTS

Important Safeguards ............................................... 3

Table of Contents ..................................................4

Getting to know your Burr Mill Grinder ................................. 5

Before Grinding .................................................... 6

Grinding Operations ................................................ 6

Grinding Guidelines................................................. 7

Care and Cleaning .................................................. 7

Troubleshooting.................................................... 8

Warranty and Customer Service Information ............................9

SAVE THESE INSTRUCTIONS.

This product is for household use only.

GETTING TO KNOW YOUR BURR MILL GRINDER*

5 6

*Product image may vary slightly from actual product appearance.

1. Grinding chamber lid (Part # CBM310-01)

2. Grinding wheel (Part # CBM310-02)

3. Grinding chamber

4. Grind selection dial

5. Cup amount selector

6. Power indicator light

7. Power button

8. Grinding chamber lid (Part # CBM310-03)

9. Grounds container (Part # CBM310-01)

BEFORE GRINDING

1. Register your product at www.prodprotect.com/applica

2. Carefully unpack your Burr Mill grinder. Remove all packaging materials, labels, stickers and the plastic band around the power plug.

3. Thoroughly clean all removable parts of your grinder. Rinse and dry these parts prior to placing them back into your grinder. See the Care and Cleaning section of this manual for assistance.

4. Remove any foreign objects or debris from the inside the grinding chamber and grounds container.

GRINDING OPERATIONS

1. Make sure the grinding chamber is empty and clean.

2. Ensure that the grounds container and its lid are secured in place in the cut-out underneath the power button. (A)

Note: As a built-in safety function, the grinder will not operate if the grounds container is not securely in place.

3. Fill the grinding chamber with whole coffee beans. (B) Note: Do not fill the grinding chamber past the MAX fill line.

4. Plug grinder into a standard electrical outlet.

5. Securely place the grinding chamber lid in place over grinding chamber. (C)

Note: As a built in safety function, the grinder will not function if the grinding chamber lid is not securely pressed in place.

6. Set the grind selection dial to your desired grind coarseness. (D)

7. Using the arrow printed on the outer ring, turn the cup selection knob to align with the number of coffee cups you intend to brew. (E)

Note: The larger the cup selection, the longer the grinder will run.

8. Press in the power button dispense ground coffee according to the number of cups selected.

9. Clean your Burr Mill grinder according to the instructions in the Care and Cleaning section.

. The grinder will

GRINDING GUIDELINES

Selecting Grind Setting:

The proper grind is important for the best coffee ﬂavor. The quicker the brewing process, the ﬁner the grind used. Coffee that is ground too ﬁne for a particular brewing process will result in bitter tasting coffee. Coffee that is ground too coarse will result in weak, watery coffee.

BREW METHOD GRIND APPEARANCE

Percolator or French Press

Coarse Like Kosher salt

Drip or Vacuum

Espresso

CARE AND CLEANING

Basic Cleaning

Follow the directions below to clean your Burr Mill grinder after each use.

1. Make sure your grinder is unplugged.

2. Discard any remaining whole beans from the grinding chamber.

3. Discard any remaining grounds from the grounds container.

4. Remove grinding chamber lid, grinding wheel (F), grounds container and grinding chamber lid.

Note: To remove grinding wheel, simultaneously pull and twist grinding wheel clockwise. To insert grinding wheel back into the grinding chamber, push and twist the grinding wheel counter-clockwise.

5. Wipe the outside of the grinder and power cord with a damp cloth.

6. Wash each part of the grinder using the directions in the chart below.

Caution: Do not use abrasive cleansers or scouring pads on this product. Never immerse this product in water. Do not oil or sharpen the grinding blades.

Medium Like coarse-ground pepper

Fine Like ﬁne bread crumbs

GRINDER PART CLEANING INSTRUCTIONS

Housing Power cord Grinding chamber

Grinding wheel

Grinding chamber lid Grounds container lid Grounds container

Wipe with a soft, damp cloth.

Wash by hand in warm soapy water, or in the dishwasher (top rack only).

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION

Grinder will not start.

Ground coffee is ejecting from grounds container.

Coffee tastes like nuts or spices or other foods.

Coffee has a poor taste.

The ﬁne/coarse selector is not working.

The grinder is not plugged in or outlet is not working.

The grinding chamber lid is not secured ﬁrmly over the grinding chamber.

The grounds container is not securely placed into the unit.

The grounds container lid may not be in place in the unit, on the grounds container.

Excessive amount of coffee beans are used.

Grinder has been used for other grinding operations.

Oil in the coffee beans will become rancid if left in the grinder.

The grinding wheel is not correctly positioned into the unit.

Plug grinder into a working outlet.

Align grinding chamber lid over grinding chamber and press down ﬁrmly.

Remove and replace the grounds container securely into the grinder.

Ensure the grounds container lid is secured onto the grounds container within the unit.

Do not ﬁll grinding chamber past the MAX ﬁll line to eliminate overﬂows.

Grinder will share ﬂavors; consider purchasing an additional grinder for grinding other items.

Be sure to clean the grinder immediately following each use.

Remove, clean, and replace the grinding wheel in the grinder. Ensure that it is securely in place.

If additional assistance is needed,

please contact our consumer service team at

1-800-231-9786.

WARRANTY AND CUSTOMER SERVICE INFORMATION

For service, repair or any questions regarding your appliance, call the appropriate 800 number listed within this section. Please DO NOT return the product to the place of purchase. Also, please DO NOT mail product back to manufacturer, nor bring it to a service center. You may also want to consult the website listed on the cover of this manual.

Two-Year Limited Warranty (Applies only in the United States and Canada)

What does it cover?

• Any defect in material or workmanship provided; however, Spectrum Brands,

Inc.’s liability will not exceed the purchase price of product.

For how long?

• Two years from the date of original purchase with proof of purchase.

What will we do to help you?

• Provide you with a reasonably similar replacement product that is either new or

factory refurbished.

How do you get service?

• Save your receipt as proof of date of sale.

• Visit the online service website at www.prodprotect.com/applica, or call toll-free

1-800-231-9786, for general warranty service.

• If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use

• Damage from misuse, abuse or neglect

• Products that have been modiﬁed in any way

• Products used or serviced outside the country of purchase

• Glass parts and other accessory items that are packed with the unit

• Shipping and handling costs associated with the replacement of the unit

• Consequential or incidental damages (Please note, however, that some states do

not allow the exclusion or limitation of consequential or incidental damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

• This warranty gives you speciﬁc legal rights. You may also have other rights that

vary from state to state or province to province.
