QUICKwash
DELUXE
USER'S GUIDE
68W6 SERIES 220-240V
2
Thank You
3
Safety Instructions
4
Product View
5
Assembly
6-10
Operations
11
Maintenance and Care
12
Troubleshooting
™
13
Replacement Parts
14
Accessories
15
Guarantee
16
Consumer Care
Thanks for buying a BISSELL deep cleaner
We’re glad you purchased a BISSELL deep cleaner. Everything we
know about floor care went into the design and construction of
this complete, high-tech home cleaning system.
Your BISSELL deep cleaner is well made, and we back it with a
limited two year guarantee. We also stand behind it with a
knowledgeable, dedicated Consumer Care department, so, should
you ever have a problem, you’ll receive fast, considerate assistance.
My great-grandfather invented the floor sweeper in 1876.
Today, BISSELL is a global leader in the design, manufacture,
and service of high quality homecare products like your BISSELL
deep cleaner.
Thanks again, from all of us at BISSELL.
Mark J. Bissell
Chairman & CEO
2
www.bissell.com
IMPORTANT SAFETY INSTRUCTIONS
■
When using an electrical
basic precautions should be observed,
including the following:
appliance,
READ ALL INSTRUCTIONS BEFORE
USING YOUR DEEP CLEANER.
WARNING:
To reduce the risk of fire,
electric shock, or injury:
■
Do not leave appliance when plugged in.
■
Unplug from electrical socket when not in use
and before servicing.
■
Do not modify earthed plug.
■
Use indoors only.
■
Do not allow to be used as a toy.
■
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory and mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe
way and understand the hazards involved.
Cleaning and user maintenance shall not be
made by children without supervision.
■
Children should be supervised to ensure that
they do not play with the appliance.
■
Use only as described in the user guide.
■
Use only manufacturer’s recommended
attachments.
■
Do not use with damaged cable or plug.
■
If the supply cable is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid
a hazard.
■
Do not immerse in water or liquid.
■
If appliance is not working as it should, has
been dropped, damaged, left outdoors, or
dropped into water; do not attempt to operate
it and return it to a service center.
■
Liquid or steam must not be directed towards
equipment containing electrical components.
■
Do not pull or carry by cable, use cable as
a handle, close door on cable, or pull cable
around sharp edges or corners.
■
Do not run appliance over cable.
■
Keep cable away from heated surfaces.
■
Do not unplug by pulling on cable.
■
To unplug, grasp the plug, not the cable.
■
Do not handle plug or appliance with
wet hands.
■
Do not put any object into openings.
www.bissell.com
Do not use with any opening blocked; keep
free of dust, lint, hair, and anything that may
reduce air flow.
■
Keep hair, loose clothing, fingers, and all parts
of body away from openings and moving parts.
■
Turn off all controls before unplugging.
■
Use extra care when cleaning on stairs.
■
Do not use to pick up flammable or combus-
tible liquids, such as petrol, or use in areas
where they may be present.
■
Do not pick up toxic material (chlorine bleach,
ammonia, drain cleaner, etc.)
■
Do not use appliance in an enclosed space
filled with vapors given off by oil base paint,
some mothproofing substances, flammable
dust, or other explosive or toxic vapors.
■
Do not pick up hard or sharp objects such as
glass, nails, screws, coins, etc.
■
Keep appliance on a level surface.
■
Do not carry appliance while in use.
■
If your appliance is fitted with a nonrewireable
BS 1363 plug it must not be used unless a 13
amp (ASTA approved to BS 1362) fuse is fitted
in the carrier contained in the plug. Spares
may be obtained from your BISSELL supplier.
If for any reason the plug is cut off, it must be
disposed of, as it is an electric shock hazard
should it be inserted into a mains socket.
SAVE THESE
INSTRUCTIONS
THIS MODEL IS FOR HOUSEHOLD USE ONLY.
WARNING:
This appliance must be earthed
WARNING:
To reduce the risk of fire and electric shock –
use indoors only. Do not immerse. Use only on
surfaces moistened by the cleaning process.
Use only bissell cleaning products intended for
use with this machine.
WARNING:
To reduce the risk of electric shock, always
install float before any wet pick-up operation
IMPORTANT
FOR OPERATION ON A 220-240 VOLT
A.C. 50/60 Hz POWER SUPPLY ONLY.
.
3
Product view
Spray Trigger
Quick Release
Cord Wrap
Handle
Assembly
Power Cord
Upper Body
ReadyTools™
Dial
Collection
Tank
Removable
Nozzle
Tough Stain
Tool
Hose
Wrap
Hose
WARNING:
To reduce the risk of fire and
electric shock due to internal
component damage, use only
BISSELL cleaning formulas
intended for use with the
deep cleaner.
Vent Cover
(Foam Filter)
Collection
Tank Latch
Cleaning formula:
Keep plenty of genuine BISSELL 2X cleaning formula on hand so you can clean and
protect whenever it fits your schedule. Always use genuine BISSELL deep cleaning formulas.
Non-BISSELL cleaning formulas may harm the machine and will void the guarantee.
1.5 L 2X
Wash &
Protect PRO
Professional
Stain &
Odour
Formula w/
Scotchgard™
Protector
#1089E
4
www.bissell.com
1.5 L 2X
Wash &
Protect PET
Pet Stain
& Odour
Formula w/
Scotchgard
Protector
#1087E
1.5 L 2X
Wash
& Protect
Stain
& Odour
Formula w/
™
Scotchgard
Protector
#1086E
1.5 L 2X
Wash &
Refresh
Blossom
& Breeze
Fragrance
™
Formula w/
Febreze®
Freshness
#1078E
1.5 L 2X
Wash &
Refresh
Cotton
Fresh Formula
w/Febreze®
Freshness
#1079E
1.5L 2X
Wash
& Refresh
Natural
Orange
Formula
#1146E
650 mL
Stain
Pretreat
#1147E
Assembly
Your deep cleaner assembles quickly
and easily. The only tool you will
need for assembly is a Phillips head
screwdriver.
1. Slide upper body onto lower body.
2. Secure with screws.
3. Attach hose wrap to upper handle by
sliding it up the bottom of the handle
until it snaps firmly in place.
4. Slide upper handle into upper body,
until it will not go any further and
secure with screw.
5. Place solution tank on back of unit.
6. Wrap power cord and flex hose.
7. Keep flex hose snugly in place by using
the hose secure latch.
8. Attach tool to end of hose.
Assembly is now complete.
1.
3.
5.
2.
4.
6.
www.bissell.com
7.
8.
5
Operations
Special features
Your BISSELL deep cleaner is a home
cleaning system that uses a combination of hand hot tap water, BISSELL
cleaning formula, brush agitation and
suction to safely clean carpets.
™
DirtLifter
The DirtLifter PowerBrush is designed to
enhance cleaning performance. The bristle
pattern safely lifts out the deep down dirt while
gently grooming carpet fibers. The floating
suspension self-adjusts to all carpet heights.
When the power is ON and the machine is in
the upright position, your carpet is protected
because the brush is lifted up off the carpet.
ReadyTools
The Ready Tools feature allows you to choose
between FLOOR CLEANING or cleaning with
TOOLS simply by turning the dial. The TOOLS
setting allows for above floor cleaning of
upholstery, stairs, creases along baseboards,
and other hard to reach areas. Simply choose
the tool that is appropriate for the job, attach to
flex hose, and you are ready to go.
Microban® antibacterial
product protection
Microban antibacterial product protection is
built into key components to help prevent
the growth of harmful common household
bacteria. It helps to keep the unit fresher an
cleaner between uses.
Scotchgard
Carpet protection applied at the mill typically
wears down over time from heavy foot traffic
and everyday cleaning, including deep cleaning. To help restore this important protection,
only BISSELL offers cleaning formulas with
Scotchgard protector. This offers extra protection against dirt and tough stains to keep your
carpets looking good longer.
Before you clean
1. Move furniture to another area if
cleaning an entire room. (Optional)
2. Vacuum carpet thoroughly.
3. Plan your cleaning route to leave an exit
path. It is best to begin cleaning in the
corner farthest from your exit.
Powerbrush
™
Dial
™
Protector
WARNING:
To reduce the risk of fire, use
only BISSELL deep cleaning
formula for full size machines
in your deep cleaner. Use of
cleaning formulas that contain
lemon or pine oil may damage
this appliance and void the
guarantee. Chemical spot
cleaners or solvent-based soil
removers should not be used.
These products may react with
the plastic materials used in your
deep cleaner causing cracking
or pitting.
6
www.bissell.com
Operations
Before you clean continued
4. Pretreating (optional) Pretreat stubborn
stains and highly soiled carpet in hallways
and other high-traffic areas.
4a. Generously spray BISSELL Stain Pretreat
evenly over soiled area.
Caution: DO NOT OVER WET CARPET
4b. Wait 3-5 minutes before deep cleaning.
Fill the tank
1. Remove the solution tank by lifting it straight
up, then away from the lower body.
2. Unscrew the black cap at the bottom of
the solution tank.
3. Fill with hand hot (60°C/140°F MAX)
tap water to the WATER line. Fill the rest
of the tank with BISSELL 2X Formula to
the FORMULA line. Replace and tighten
the black cap. NOTE: Do not boil or
microwave water as it can damage
the solution tank.
4. Place solution tank on lower body.
Carpet cleaning
1. Set ReadyTools dial to "FLOOR CLEANING".
2. Plug into proper outlet.
3. Turn the power switch to the ON (I)
position (located on the back of unit)
4. With foot, press the red recline lever
(located on the back of unit).
5. Cleaning Strokes. While pressing the
spray trigger, make one slow forward wet
pass and another one back. Caution: Do
not overwet.
6. Release the spray trigger and make one
slow forward and backward pass over the
same area.
7. Repeat steps 5 and 6 until solution being
pulled up appears clean.
8. Empty the collection tank when dirty water
reaches the full line, or when the solution
tank is empty.
Empty the collection tank
1. Turn power switch OFF (O) and unplug
power cord from outlet.
2. Remove the collection tank from base of unit.
1.
1.
2.
4.3.
3. & 4.
Recline
Lever
Power
www.bissell.com
7
Operations
Empty the collection tank continued
2a. Release collection tank latches
(on each side) by pulling up from the
bottom of latch and then out.
2b. Carefully remove the top of the
tank by lifting up on the tank handle.
3. Carry collection tank to a toilet or sink.
To empty, pour out contents using
opening at back of tank.
4. Rinse collection tank thoroughly and
replace on unit.
5. Refill solution tank and continue cleaning.
Cleaning with attachments
Your deep cleaner is equipped with a
hose and at least one attachment for
cleaning stairs, upholstery, and more.
1. Important! If using to clean upholstery,
check upholstery tags.
1a. Check manufacturer’s tag before clean-
ing. “W” or “WS” on the tag means you
can use your deep cleaner. If the tag is
coded with an “X” or an “S” (with a diagonal stripe through it), or says “Dry Clean
Only”, do not proceed with any deep
cleaning machine. Do not use on velvet or
silk. If manufacturer’s tag is missing or not
coded, check with your furniture dealer.
1b. Check for colourfastness in an
inconspicuous place.
1c. If possible, check upholstery stuffing.
Coloured stuffing may bleed through
fabric when wet.
1d. Plan activities to allow upholstery time
to dry.
1e. Vacuum area thoroughly.
2. Follow the instructions on page 7 for filling
the tank.
3. Set the ReadyTools dial to the “TOOLS” setting.
4. Attach the cleaning tool to the end of the hose.
NOTE: If your deep cleaner came with
a Deep Reach Tool, do not follow the
cleaning instructions in this section.
Instead, follow the "Cleaning with
deep reach tool" instructions in the
next section.
2a.
3.
2b.
3.
4.
8
www.bissell.com
Operations
Cleaning with attachments continued
5. Plug in and turn the power switch to the
ON position.
6. Clean by pressing the spray trigger
to spray solution onto the area to be
cleaned. Slowly move the tool back and
forth over the soiled surface. Release
the spray trigger to suction dirty water.
Continue to clean in the area, working
in small sections, until dirt is removed.
Caution: Do Not Overwet.
7. When finished cleaning, remove and
rinse tool(s) in clean, running water.
8. It is recommended that you suction clean
water from a bowl to rinse out the hose.
9. Lift end of hose and stretch out to ensure
all water is cleared from hose.
10. Wrap flex hose around hose wrap.
11. Empty collection tank and rinse out,
following instructions on page 10
under "Cleaning after use."
12. Return ReadyTools dial to “FLOOR
CLEANING” setting.
Deep reach tool attachment
(Select models only)
1. Follow the instructions on page 7 for
Filling the tank.
2. Follow instructions 1-5 on pages 8 and
9 under "Cleaning with attachments".
3. Set tool on stain and press the spray
trigger to spray trigger solution onto the
area to be cleaned.
4. Slowly move the tool back and forth over
the soiled surface, keeping the tool in
contact with the carpet.
5. Release the spray trigger and move tool
slowly over the soiled area to suction up
water and dirt.
6. Continue to clean the area, working in
small sections, until no more dirt can be
removed.
7. Remove tool from hose when finished.
Clean under warm water before storing
8. Follow cleaning attachment instructions
8-12 in the "Cleaning with attachments"
section above.
3.
5.
7.
9.8.
www.bissell.com
9
Operations
Cleaning after use
1. Unplug the unit.
2. Rinse collection tank thoroughly.
2a. Remove ReadyTools Dial by
rotating it halfway between “TOOLS” &
“FLOOR CLEANING.”
2b. Pop out knob by using the opening
on the back of the tank. Rinse and replace
knob and collection tank.
3. Remove tank vent & foam filter (located
on top of the collection tank) and rinse.
4. Clean nozzle window by lifting latch
and removing from machine. Rinse
under running water.
5. When finished, replace nozzle and
secure with latch.
NOTE: For best results, it is
recommended that the nozzle
is cleaned after each use.
6. Remove lint and hair from red gasket in
base of unit. (Do not remove gasket)
7. Replace the collection tank to the base
of the machine and secure with latches.
2a.
2b.
3.
5. 6.
2b.
4.
10
www.bissell.com
Maintenance and care
Machine storage
For best results, a few simple steps
can assure your machine is well maintained after your cleaning is complete.
1. Wrap power cord around Quick Release
Cord Wrap™ on side of the machine.
2. Wipe all surfaces with a soft cloth. Store
cleaner upright in a protected, dry area.
NOTE: You may have cleaning
solution remaining in the solution
tank. You may store your machine
this way for the next cleaning
task, but never keep dirty water
in the collection tank.
WARNING:
To reduce the risk of injury from
moving parts and/or electrical
shock, turn power switch OFF
and disconnect plug from
electrical outlet before
performing maintenance or
troubleshooting checks.
CAUTION:
Do not store unit where
freezing may occur.
Damage to internal
components may result.
www.bissell.com
11
Troubleshooting
Reduced Spray OR No Spray in Upright Mode
Possible causes Remedies
1. Solution tank empty 1. Refill tank with water and formula
2. Lint screen on solution tank cap clogged 2. Soak solution tank cap in warm water and then rinse under
running water
Reduce Spray or No Spray Attachment
Possible causes Remedies
1. Solution tank empty 1. Refill tank with water and formula
2. Spray nozzle clogged 2. Clean spray nozzle by rinsing tool under water
3. Pump needs priming 3. Place tool on floor and press spray trigger
4. Machine is reclined 4. Return machine to full upright position until it locks
into place
5. ReadyTools dial is set to “FLOOR CLEANING” 5. Choose “TOOLS” setting on ReadyTools dial
Deep cleaner not picking up cleaning solution
Possible causes Remedies
1. Collection tank not aligned/secured 1. Check tank alignment and secure with side latches
2. Collection tank full 2. Empty tank
3. Removable nozzle installed improperly 3. Unplug unit. Align four "hooks" on nozzle into bottom first,
then snap into place on top
4. Removable nozzle full of debris 4. Unplug unit. Remove nozzle and rinse under running water
5. Red lint screen under collection tank clogged 5. Remove debris from lint screen
6. ReadyTools dial not set properly 6. Choose either “FLOOR CLEANING” or “TOOLS” for desired
cleaning method
Other maintenance or service not included in the manual should be
performed by an authorized service representative.
Thank you for selecting a BISSELL product.
Please do not return this product to the store.
12
www.bissell.com
Replacement parts
Below please find a list of common replacement parts. While not all of these
parts may have come with your specific machine, all are available to you for
purchase, if desired.
Item Part No. Part Name
1 160-3147 Handle Assembly (includes screws)
2 203-5661 Solution Tank (Includes Cap and Insert Assembly)
3 203-8271 Collection Tank (with diverter)
4 203-5546 DirtLifter PowerBrush
5 203-8118 Cord Wrap (upper)
6 203-5658 Hose Wrap Clip
7 203-8119 Upper body with Screws
8 203-5659 Lower Hose Wrap
9 203-8120 Nozzle
10 203-5662 Solution Tank Cap & Insert
*Not all parts are included with every model.
1
6
2
7
3
8
4 5
9
10
www.bissell.com
13
Accessories
Item Part No. Part Name
1 203-6651 3” Tough Stain Tool
2 203-6652 Powered TurboBrush™ Hand Tool
3 203-6653 4” Upholstery Tool
4 203-6654 6” Stair Tool
5 203-6655 Spraying Crevice Tool
6 203-7412 Deep Reach™ Tool
7 203-5683 Hard Floor Tool,
*Not all parts are included with every model.
1
6
Cleaning Formula: Refer to bottom of page 4 of this guide for a full selection
of cleaning formula available for purchase.
2
3
4 5
7
14
www.bissell.com
Guarantee
This Guarantee only applies outside of the USA and Canada. It is provided by BISSELL International
Trading Company BV (“BISSELL”).
This Guarantee is provided by BISSELL. It gives you specific rights. It is offered as an additional
benefit to your rights under law. You also have other rights under law which may vary from country
to country. You can find out about your legal rights and remedies by contacting your local consumer
advice service. Nothing in this Guarantee will replace or lessen any of your legal rights or
remedies. If you need additional instruction regarding this Guarantee or have questions regarding
what it may cover, please contact BISSELL Consumer Care or contact your local distributor.
This Guarantee is given to the original purchaser of the product from new and is not transferable.
You must be able to evidence the date of purchase in order to claim under this Guarantee.
Limited Two-Year Guarantee
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL will for two years from
the date of purchase by the original purchaser repair or replace (with new or remanufactured
components or products), at BISSELL’s option, free of charge, any defective or malfunctioning part
or product.
BISSELL recommends that the original packaging and evidence of the date of purchase be kept
for the duration of the Guarantee period in case the need arises within the period to claim on
the Guarantee. Keeping the original packaging will assist with any necessary re-packaging and
transportation but is not a condition of the Guarantee.
If for your product is replaced by BISSELL under this Guarantee, the new item will benefit from
the remainder of the term of this Guarantee (calculated from the date of the original purchase).
The period of this Guarantee shall not be extended whether or not your product is repaired
or replaced.
*EXCEPTIONS AND EXCLUSIONS FROM THE TERMS OF THE GUARANTEE
This Guarantee applies to products used for personal domestic use and not commercial or hire
purposes. Consumable components such as filters, belts and mop pads, which must be replaced or
serviced by the user from time to time, are not covered by this Guarantee.
This Guarantee does not apply to any defect arising from fair wear and tear. Damage or malfunction caused by the user or any third party whether as a result of accident, negligence, abuse,
neglect, or any other use not in accordance with the User Guide is not covered by this Guarantee.
An unauthorised repair (or attempted repair) will void this Guarantee whether or not damage has
been caused by that repair/attempt.
Removing or tampering with the Product Rating Label on the product or rendering it illegible will
void this Guarantee.
SAVE AS SET OUT BELOW BISSELL AND ITS DISTRIBUTORS ARE NOT LIABLE FOR ANY LOSS OR
DAMAGE THAT IS NOT FORESEEABLE OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE ASSOCIATED WITH THE USE OF THIS PRODUCT INCLUDING WITHOUT
LIMITATION LOSS OF PROFIT, LOSS OF BUSINESS, BUSINESS INTERRUPTION, LOSS OF
OPPORTUNITY, DISTRESS, INCONVENIENCE OR DISAPPOINTMENT. SAVE AS SET OUT BELOW
BISSELL’S LIABILITY WILL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCT.
BISSELL does not exclude or limit in any way its liability for (a) death or personal injury caused by
our negligence or the negligence of our employees, agents or subcontractors; (b) fraud or fraudulent
misrepresentation; (c) or for any other matter which cannot be excluded or limited under law.
www.bissell.com
15
BISSELL consumer care
If your BISSELL product should require service:
Call BISSELL Consumer Care at the numbers below and we will give you the location
of a BISSELL Authorized Service Center in your area. If you have questions about your
guarantee or need replacement parts please contact the numbers below.
For UK inquiries:
Monday - Thursday 9 am - 5 pm
Friday 9 am - 4 pm
BISSELL Homecare (Overseas) Inc.
Ground Floor
226 Berwick Avenue
Slough
For all other inquiries:
Monday – Friday 8 am - 4 pm
BISSELL Homecare, Inc.
PO Box 1888
Grand Rapids, Michigan 49501 USA
Telephone: 01-616-453-4451
Fax: 01-616-453-1383
Berkshire, SL1 4QT
United Kingdom
Telephone: 0844-888-6644
Or visit the BISSELL website - www.bissell.com
When contacting BISSELL, have model number of cleaner available.
Please record your Model Number: ___________________
Please record your Purchase Date: ___________________
NOTE: Please keep your original sales receipt.
It provides proof of purchase date in the event
of a guarantee claim. See Guarantee on page 15
for details.
Do not throw the appliance away with the normal
household waste at the end of its life, but hand it in
at an official collection point for recycling. By doing
this you will help to preserve the environment.
16
www.bissell.com
©2013 BISSELL Homecare, Inc
All rights reserved. Printed in China
Part Number 160-3173
Rev 10/13
Visit our website at:
www.bissell.com
Scotchgard is a trademark of 3M
Microban® is a registered
trademark of Microban Products
Company
Febreze is a trademark of The
Proctor & Gamble Company,
Cincinnati, Ohio used under
license by BISSELL Homecare, Inc.
Loading...
