Verification Kit
for use with
AT-500
Antenna Tester
© Copyright 2007 by Bird Electronic Corporation
Instruction Book Only Part Number 920-7000A545 Rev A
Verification Kit Part Number 7000A546
Introduction
ρ VSWR-1()VSWR+1()⁄=
Connecting a mismatch of a known value and measuring it with the Antenna
Tester provides a test to determine the degree of measurement accuracy.
Measurement accuracy is specified to be ± 0.040 of Rho (p), where:
Because of the manufacturing tolerance, each mismatch is analyzed across the
frequency band of the Antenna Tester. Rho data is recorded so that future comparisons can be made without regard to the manufacturing tolerance.
This verification kit is used to verify Antenna Tester performance. It is intended
for use with the AT-500 Antenna Tester. These instructions were written with
the understanding that the operator is familiar with the operation of the Antenna
Tester. Refer to the Antenna Tester Operator Manual for more information.
Kit Contents and Specifications
Standard Mismatch—p/n 2-T-MN-1R50 (includes verification data)
VSWR 1.5:1 (nominal)
Rho () 0.200 (nominal)
Connector Type N (M)
Power Rating 1 Watt cw maximum
Operating Temperature 20° to 30°C (68° to 86°F)
Storage Temperature 0° to 50°C (32° to 122°F)
Adapter—p/n4240-403
Connector N (F) to Universal Adapter (M)
Impedance 50 nominal
Verification Data—Rho data included with mismatch,
Data Uncertainty
VSWR ± 2.4%
Rho ± 0.0121
Bird Technologies
Instructions
1. Connect the adapter to the test port on the Antenna Tester.
2. Connect the mismatch to the adapter.
3. Press the ON key.
4. Press the MENU key.
5. Press the MEAS MATCH key.
6. Press the SINGLE FREQ key.
7. Press the UNITS key.
8. Press the RHO key.
9. Press the FREQ MHz key.
10. Using the numeric keys, enter the frequency for the first data point as documented in the test data for the mis-match.
11. Press the ENTER key.
12. Compare the resultant value to the minimum and maximum values listed for
the frequency entered in Step 10.
13. Repeat Step 10 through Step 12 for each frequency point listed in the mismatch test data sheet. To enter another frequency repeatedly press the
SELECT key until the cursor is blinking on the frequency, then use the
numeric keys to enter the desired frequency.
14. If any value is outside the listed minimum and maximum acceptable values
see the Calibration section on page 3.
2
Calibration
For maximum performance and accuracy, the Antenna Tester should be calibrated once every 12 months or if the verification test indicates the accuracy is not
within the specified range. Return the unit to the Bird Electronic authorized service center listed below.
Service Center
U.S.A. Sales and Manufacturing
Service Group
Bird Electronic Corporation
30303 Aurora Road
Cleveland (Solon), Ohio 44139-2794
Phone: (440) 248-1200 Cable: BIRDELEC
Fax: (440)248-5426 Telex: 706898 Bird Elec UD
Sales Offices
For the location of the Sales Office nearest you, call us or visit our WebSite at:
http://www.bird-electronic.com
3
