Bird Technologies 6150-PAGE Datasheet

TX RX Systems Brand

SB II Series Signal Booster Automatic
Voice/Pager Dialer Option

6150-Page

Bird Technologies Group, TX RX Systems brand, 6150-PAGE automatic dialer features busy-line and no
answer detection to ensure prompt transmission of up to 4 prerecorded messages delivered
sequentially to as many as 8 standard telephones, cellular phones, voice and/or numeric pagers.
Messages to both local and long-distance calls can be transmitted.

When activated, the dialer instantly begins calling the numbers in sequence, delivering each message 1
to 3 times in a row, in accordance with the pre-selected number of dialing attempts. Plain-English
prompts walk the user through the programing process in a timely manner.

PROGRAMING OPTIONS

} Store up to 8 telephone/pager numbers.

} Choose 1- 9 calling eorts for the numbers dialed.

} Select 1-3 message repeats.

} Record a variable combination (maximum: 7) of instructional

outgoing messages (total elapsed time: 51 seconds).

} Program up to 4 separate input channels with individually

enable/disable, entry/exit delay and activation options -- Normally
Open (N.O.), Normally Closed (N.C.), including momentary and
continuous activation for each.

} Further individualize each channel by selecting the delay times,

telephone/pager numbers to be dialed and the specic outgoing
messages to be played.

ACCESSIBILITY OPTIONS

Provides reliable emergency notication 24 hours a day.

Ideal for installations where Ethernet connection is not available,
so that the Remote Communication Card cannot be used.

Stand-alone AD-2000 Dialer with dry-contact interface to SBII.

Extensively programmable, oering personalized customization.

SB II Series Signal Booster Automatic Voice/Pager
Dialer Option

6150-Page

30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com

SignalBooster_6283ESeries-03202013
