RF Directional
Thruline® Wattmeter
Model 43
Also Covers Models 4431, 43P
And Series 4300 and 4520
OPERATING INSTRUCTIONS
©Copyright 2011
Instruction Book Part Number 920-43 Rev. K
Thruline® and Termaline® are registered trademarks
by Bird Electronic Corporation
of Bird Electronic Corporation
THIS PAGE INTENTIONALLY LEFT BLANK
Safety Precautions
The following are general safety precautions that are not necessarily related to
any specific part or procedure, and do not necessarily appear elsewhere in this
publication. These precautions must be thoroughly understood and apply to all
phases of operation and maintenance.
WARNING
Keep Away From Live Circuits
Operating Personnel must at all times observe general safety precautions. Do not
replace components or make adjustments to the inside of the test equipment with
the high voltage supply turned on. To avoid casualties, always remove power.
WARNING
Shock Hazard
Do not attempt to remove the RF transmission line while RF power is present.
WARNING
Do Not Service Or Adjust Alone
Under no circumstances should any person reach into an enclosure for the
purpose of service or adjustment of equipment except in the presence of
someone who is capable of rendering aid.
WARNING
Safety Earth Ground
An uniterruptible earth safety ground must be supplied from the main power
source to test instruments. Grounding one conductor of a two conductor
power cable is not sufficient protection. Serious injury or death can occur if
this grounding is not properly supplied.
WARNING
Resuscitation
Personnel working with or near high voltages should be familiar with modern
methods of resuscitation.
WARNING
Remove Power
Observe general safety precautions. Do not open the instrument with the
power on.
iii
Safety Symbols
WARNING
Warning notes call attention to a procedure, which if not correctly performed,
could result in personal injury.
CAUTION
Caution notes call attention to a procedure, which if not correctly performed,
could result in damage to the instrument.
The caution symbol appears on the equipment indicating there is
important information in the instruction manual regarding that particular area
Note: Calls attention to supplemental information.
Warning Statements
The following safety warnings appear in the text where there is danger to operating and maintenance personnel, and are repeated here for emphasis.
WARNING
Leaking RF energy is a potential health hazard. Never attempt to connect or
disconnect equipment from the transmission line while RF power is being applied.
Severe burns, electrical shock, or death can occur.
On page 11.
WARNING
When working with RF powers of 200 watts or more, the potential of the
center conductor of the line section will be over 100 volts. Do not touch the
center conductor while RF power is on.
On page 13.
Caution Statements
The following equipment cautions appear in the text and are repeated here for
emphasis.
CAUTION
For low reflection measurements, do not rotate the reflected power element
to read forward power. Damage to the element or wattmeter could result.
On page 7.
iv
CAUTION
Handle elements with care. Calibration could be disturbed if they are
dropped.
On page 11.
CAUTION
Do not attempt to remove the RF center conductor. This will damage the line
section.
On page 20.
v
Safety Statements
USAGE
ANY USE OF THIS INSTRUMENT IN A MANNER NOT
SPECIFIED BY THE MANUFACTURER MAY IMPAIR THE
INSTRUMENT’S SAFETY PROTECTION.
USO
EL USO DE ESTE INSTRUMENTO DE MANERA NO
ESPECIFICADA POR EL FABRICANTE, PUEDE ANULAR LA
PROTECCIÓN DE SEGURIDAD DEL INSTRUMENTO.
BENUTZUNG
WIRD DAS GERÄT AUF ANDERE WEISE VERWENDET ALS VOM
HERSTELLER BESCHRIEBEN, KANN DIE GERÄTESICHERHEIT
BEEINTRÄCHTIGT WERDEN.
UTILISATION
TOUTE UTILISATION DE CET INSTRUMENT QUI N’EST PAS
EXPLICITEMENT PRÉVUE PAR LE FABRICANT PEUT
ENDOMMAGER LE DISPOSITIF DE PROTECTION DE
L’INSTRUMENT.
IMPIEGO
QUALORA QUESTO STRUMENTO VENISSE UTILIZZATO IN
MODO DIVERSO DA COME SPECIFICATO DAL PRODUTTORE
LA PROZIONE DI SICUREZZA POTREBBE VENIRNE
COMPROMESSA.
SERVICE
SERVICING INSTRUCTIONS ARE FOR USE BY SERVICE TRAINED PERSONNEL ONLY. TO AVOID DANGEROUS
ELECTRIC SHOCK, DO NOT PERFORM ANY SERVICING
UNLESS QUALIFIED TO DO SO.
SERVICIO
LAS INSTRUCCIONES DE SERVICIO SON PARA USO EXCLUSIVO
DEL PERSONAL DE SERVICIO CAPACITADO. PARA EVITAR EL
PELIGRO DE DESCARGAS ELÉCTRICAS, NO REALICE NINGÚN
SERVICIO A MENOS QUE ESTÉ CAPACITADO PARA HACERIO.
vi
WARTUNG
ANWEISUNGEN FÜR DIE WARTUNG DES GERÄTES GELTEN
NUR FÜR GESCHULTES FACHPERSONAL. ZUR VERMEIDUNG
GEFÄHRLICHE, ELEKTRISCHE SCHOCKS, SIND
WARTUNGSARBEITEN AUSSCHLIEßLICH VON
QUALIFIZIERTEM SERVICEPERSONAL DURCHZUFÜHREN.
ENTRENTIEN
L’EMPLOI DES INSTRUCTIONS D’ENTRETIEN DOIT ÊTRE
RÉSERVÉ AU PERSONNEL FORMÉ AUX OPÉRATIONS
D’ENTRETIEN. POUR PRÉVENIR UN CHOC ÉLECTRIQUE
DANGEREUX, NE PAS EFFECTUER D’ENTRETIEN SI L’ON N’A
PAS ÉTÉ QUALIFIÉ POUR CE FAIRE.
ASSISTENZA TECNICA
LE ISTRUZIONI RELATIVE ALL’ASSISTENZA SONO PREVISTE
ESCLUSIVAMENTE PER IL PERSONALE OPPORTUNAMENTE
ADDESTRATO. PER EVITARE PERICOLOSE SCOSSE
ELETTRICHE NON EFFETTUARRE ALCUNA RIPARAZIONE A
MENO CHE QUALIFICATI A FARLA.
vii
RF VOLTAGE MAY BE PRESENT IN RF ELEMENT SOCKET - KEEP
ELEMENT IN SOCKET DURING OPERATION.
DE LA TENSION H.F. PEAT ÊTRE PRÉSENTE DANS LA PRISE DE
L'ÉLÉMENT H.F. - CONSERVER L'ÉLÉMENT DANS LA PRISE LORS
DE L'EMPLOI.
HF-SPANNUNG KANN IN DER HF-ELEMENT-BUCHSE ANSTEHEN ELEMENT WÄHREND DES BETRIEBS EINGESTÖPSELT LASSEN.
PUEDE HABER VOLTAJE RF EN EL ENCHUFE DEL ELEMENTO RF MANTENGA EL ELEMENTO EN EL ENCHUFE DURANTE LA
OPERACION.
IL PORTAELEMENTO RF PUÒ PRESENTARE VOLTAGGIO RF TENERE L'ELEMENTO NELLA PRESA DURANTE IL
FUNZIONAMENTO.
viii
About This Manual
This manual covers the operating and maintenance instructions for the following models:
43 43P 4301 4305A 4431 4527
4521 4522 4526
Changes to this Manual
We have made every effort to ensure this manual is accurate. If you discover any
errors, or if you have suggestions for improving this manual, please send your
comments to our Solon, Ohio factory. This manual may be periodically updated.
When inquiring about updates to this manual refer to the part number and revision on the title page.
Literature Contents
Chapter Layout
Introduction — Describes the features of the 43 Wattmeter, lists equipment
supplied and optional equipment, and provides power-up instructions.
Theory of Operation — Describes how the 43 Wattmeter works and
Installation — Describes how to set up and prepare the 43 Wattmeter for use.
Operation - All instructions necessary to operate the equipment appears in
this chapter.
Maintenance — Lists routine maintenance tasks as well as troubleshooting for
common problems.
Model Differences — Describes how each indivdual models vary from
each other.
Specifcations — Specifications and parts information are included in this
chapter.
ix
Table of Contents
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Warning Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Caution Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Safety Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Changes to this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Chapter Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Purpose and Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Performance Characteristics and Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 2 Theory of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Travelling Wave Viewpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Formulas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Forward . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Reflected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Coupling Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Load Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Standing Wave vs. Travelling Wave Viewpoint (ρ vs. φ) . . . . . . . . . . . . . . . . 5
Low Reflection Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Transmitter Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Component Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Measuring Insertion Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Frequency Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Impedance Mismatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replacing Quick-Change Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Remote Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 4 Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Load Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chapter 5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Troublehshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Contact Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
xiii
Zero Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Bird 43 Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Bird 43 Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Available “QC” Type Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Chapter 6 Model Differences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Bird 43P Peak Wattmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Peak Detector Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Rectangular Pulses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Peak Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Bird 4301 Thruline Wattmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Bird 4305A Thruline Wattmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Bird 4305A Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Bird 4431 Thruline Wattmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Bird 4431 Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Customer Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Service Only Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Bird 4520 Series Thruline Wattmeters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Bird 4520 Series Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . 34
4521 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4522 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4526/27 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Service Only Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Chapter 7 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
xiv
xv
Chapter 1 Introduction
Purpose and Function
The 43 is an insertion-type RF wattmeter, designed to measure RF power and
load match in 50 ohm coaxial transmission lines. It is intended for use with CW,
AM, FM, and TV modulation, but not pulse modulation. When used in 50 ohm
applications, the 43 has a maximum VSWR of 1.05 for frequencies up to 1000
MHz. The meter provides direct readings in watts with an expanded scale for
easy reading. The scale is graduated for 25, 50, and 100 full scale. Elements are
available in a variety of power and frequency ranges (see the Bird Electronic Corporation Catalog for details).
This manual covers the operation of the Bird 43 Thruline Wattmeter and its
descendants. Two models have RF sampler ports, while the Bird 43P can measure peak power. The Bird 4520 series comes ready for panel mounting. Differences are discussed in Chapter 6, on page 27. Except where indicated,
instructions and specifications for the 43 apply to other models also.
Performance Characteristics and Capabilities
The Bird 43 is portable, with an attached carrying strap. It has an aluminum
housing and an easily removed back cover, with bumpers on the base and back
that allow the meter to stand or lie flat. For additional protection, the
microammeter is specially shock mounted. A slotted screw on the lower front
face of the meter is used to zero the pointer. Below the meter face, the RF line
section protrudes slightly from the wattmeter housing with the element socket
in the center.
A shielded cable connects the RF line section to the rest of the wattmeter. This lets
you remove the line section from the wattmeter housing for custom installation and
still make measurements. The RF line section is precision machined to provide the
best possible impedance match to the transmission line under test. A formed phosphor-bronze spring finger protrudes into the element socket to make contact with
the element.
At each end of the line section are Bird Quick-Change RF connectors that may be
interchanged with any other Bird “QC” connector. The wattmeter housing does
not interfere with connector changes.
To make measurements, a Bird Plug-In Element is inserted into the line section
socket and rotated against one of the stops. A small catch in the corner of the
socket face presses on the shoulder of the element to keep it in proper alignment. This assures good contact between the spring finger and the element contact and between the lower edge of the element and the line section body (see
Figure 1).
1
Figure 1 Securing an element
Contacts on opposite sides of the element connect with the spring finger when
the element is in the forward or reverse position. This occurs when the stop pin
on the element is against either stop and the catch is in place.
Figure 2 Bird 43 Thruline Wattmeter Outline Drawing
2
Chapter 2 Theory of Operation
WfWattsForward E
f
2
Zo⁄ I
f
2
ZoEfL
f
====
WrWattsReflected E
r
2
Zo⁄ I
r
2
ZoErL
r
====
Travelling Wave Viewpoint
The easiest way to visualize Thruline operation is from a travelling wave viewpoint. In transmission lines the voltages, currents, standing waves, etc., on any
uniform line section result from the interaction of two travelling waves:
• Forward Wave (and its power) travels from the source to the load. It
has RF voltage E
• Reflected Wave (and its power) originates by reflection at the load and
travels from the load back to the source. It has an RF voltage E
rent I
in phase, with Er / Ir = Zo.
r
Formulas
Each wave is mathematically simple and has a constant power:
Forward
Reflected
and current If in phase, with Ef / If = Zo.
f
and cur-
r
Note: Z
useful lines it is usually a pure resistance of 50 ohms. The RF circuit of
the Bird 43 is a length of uniform air line with Z
Coupling Circuit
The coupling circuit that samples the travelling waves is in the Bird Plug-In Element. The element circuitry and its relationship to the rest of the Bird 43 are
illustrated in Figure 3.
is the characteristic impedance of a uniform line section. For
o
= 50 ohms.
o
3
Figure 3 Thruline Wattmeter Schematic
W1WattsIntoLoad WfWr–==
Current is produced in the coupling circuit by the travelling waves in the line
section. Both inductive and capacitive coupling contribute to this. The inductive current flows in the direction of the travelling wave. The capacitive current is independent of the direction of the travelling wave. Therefore, the
inductive current produced by one of the travelling waves will add in phase
with the corresponding capacitive current, while that produced by the wave
travelling in the opposite direction will subtract. The additive or “arrow” direction is assigned to the forward wave.
The electrical characteristics of the element are carefully adjusted so that, for the
reverse travelling wave, the inductive current will completely cancel the capacitive
current. The result is directivity greater than 25 dB. Thus, the element is sensitive
at either of its settings, but to only one of the two travelling waves. Thruline Wattmeter measurements are also independent of position along the transmission
line.
Like similar diode devices, the Bird 43 indicates the carrier component of amplitude modulation, with very little response to side band components added by
modulation.
Load Power
For loads with a VSWR of 1.2 or less, the power dissipated in a load (Wl) is
equivalent (with less than one percent error) to the forward power (W
appreciable power is reflected, as with an antenna, it is necessary to use the
exact load power which is given by:
Good load resistors, such as Bird Termaline loads, will give negligible reflected
power.
4
). When
f
Standing Wave vs. Travelling Wave Viewpoint (ρ vs. φ)
ρ
1 φ+
1 φ–
----------------=
φ
ρ 1–
ρ 1+
------------
2
=
As mentioned previously, the Thruline Wattmeter reacts to forward and reverse
travelling waves to measure power in a transmission line. The standing wave
viewpoint, also widely used, is highly developed both in theory and in practice.
This viewpoint can be traced to the early use of slotted transmission lines.
The slotted line measures the standing wave ratio by mechanically positioning a
voltage detector at peaks and nulls along a length of line section. Its drawbacks
are that it is usually too long, too expensive for good accuracy, not portable, and
too slow. These problems grow rapidly as the measurement frequency drops
below 1000 MHz. The Thruline Wattmeter by comparison is fast, convenient, and
accurate. It provides the same information as a slotted line with the exception of
the phase angle of the reflection coefficient (distance, load to minimum).
The simple relationships:
and
Note: Where r = VSWR and f = Wr / Wf
These can be used to convert between the standing wave ratio (ρ) and the
reflected/forward power ratio (φ), which can be directly read from the Thruline Wattmeter. The relationship between ρ and φ is graphed in Figure 4 and
Figure 5.
Note: Attenuation, measured in dB, can be derived from the power
ratio by the equation N
VSWR scales and their attendant controls for setting the reference point have
been intentionally omitted from the Bird 43. Experience using the Thruline
Wattmeter for transmitter tune-up, antenna matching, etc. will show that the
power ratio measurement is as useful in practice as the standing wave ratio.
A trial is suggested – forget about VSWR for a few days and think in terms of φ
= W
/ Wf. The two meter readings, Wr and Wf, give a useful, approximate pic-
r
ture of the results without bothering to calculate the power ratio exactly. Consider that, for an antenna matching problem, the main objective usually is to
minimize W
. Anything done experimentally to this end will be seen when the
r
element is turned to the reflected power position.
= 10 log φ.
db
5
Figure 4 Percent Reflected Power vs. VSWR (1.0 – 1.3)
6
Figure 5 Percent Reflected Power vs. VSWR (1.0 – 8.0)
Low Reflection Measurements
φ = 10% (ρ = 2) is the typical limit of antenna match. Further effort is frequently
not worthwhile because below this level reflected power is hard to measure,
and W
can not be significantly increased. TV and VHF transmitters are examples
l
of systems requiring lower reflected power but for reasons other than maximizing power transmission.
CAUTION
For low reflection measurements, do not rotate the reflected power element
to read forward power. Damage to the element or wattmeter could result
7
When the same element is used to measure both forward and reflected power,
meaningful readings are possible down to about φ = 5% (ρ = 1.5). For accurate
measurement of very low levels of reflected power, i.e. φ =0.6% (ρ =1.17), use a
second element rated at one tenth of the full scale power of the forward element. This method should not be used with element ranges differing by more
than 10:1.
Example - Consider an 80 watt transmitter and a Bird 43
with 100 and 10 watt elements. Measure W
element. Measure W
arrow pointing towards the transmitter). W
sured down to at least 0.5 W, so that φ = 0.5 / 80 or about
0.6%, corresponding to ρ = 1.17.
using the 10 W element (with the
r
with the 100 W
f
can be mea-
r
Transmitter Monitoring
The Thruline Wattmeter can be used for the continuous monitoring of transmitter output or reflected power, for instance in checking intermittent antenna or
line faults.
Component Testing
The Bird 43 is very helpful in component testing, and may be employed in several ways:
• VSWR or φ may be measured by placing the component under test
between the wattmeter and a good load resistor.
• Attenuation (power lost by heat in a line) as well as VSWR may be mea-
sured by inserting the unknown line between two Thruline wattmeters, or
between a Thruline wattmeter and a Termaline absorption wattmeter.
Note: Very small attenuations require allowance for normal instrument errors. To correct for this without any calculations, simply connect the wattmeters directly, with no line between them, and adjust
their zero settings until they are both zeroed.
• Line loss using open circuit calibration: The high directivity of elements
can be exploited in line loss measurements, because of the equality of
forward and reflected power with the load connector open or short
circuited. In this state the forward and reflected waves have equal
power, so that φ = 100% and ρ = ∞. Open circuit testing is preferred to
short circuit, because a high quality open circuit is easier to create than
a high quality short.
8
Measuring Insertion Loss
1. Check forward and reverse power equality with a high quality open circuit,
2. Connect an open-circuited, unknown line to the wattmeter.
3. Measure the line twice (once down and once back).
Note: The measured φ is the attenuation for two passes along the line.
4. Compare the attenuation with published data for line type and length
(remember to halve N
or double the line length to account for the mea-
db
surement technique).
Note: This measurement should be supplemented by either time
domain reflectometry or DC continuity and leakage checks, since the
attenuation measurement alone cannot account for faults such as
open or short circuits partway down the line.
Note: Tery small attenuations require allowance for normal instrument errors. Make sure to note exact readings, or their difference, on
the initial equality check, and correct for this.
Frequency Response
Bird Plug-In Elements have a flat frequency response over their specified operating range. A sample set of curves is shown in Figure 6. Notice that for the low
power element, the rolloff outside its frequency band is more pronounced than
for the high power elements.
Example - At 40 MHz the 10C element will have a loss of 4
dB, giving a reading of about 40% of the true value For the
100C, the loss will only be about 1 dB, for a reading at 80%
of the true value, and the 500C should be within the normal 5% of full scale tolerance.
Figure 6 Representative Frequency Response
9
These curves are typical for all element types (H, A, B, C, D, ...) at their respective
frequencies. Since a C type element has a frequency range of 100 - 250 MHz,
response curves for other element types can be approximated by replacing the
100 and 250 MHz points on the chart with the extremes of the element’s frequency range, and recalc-ulating the other frequency points accordingly.
Example - For a B element (range 50 - 125 MHz) simply
divide all frequencies by two. For an E element (range 400 1000 MHz) multiply all frequencies by four.
Harmonics or subharmonics that lie outside of the frequency range of the element may exist in the circuit under test. A rough approximation of the element’s
response to harmonics can be made with these curves. Using an element for
measurements outside of its frequency range is not recommended. The
response curves presented are only typical, and not guaranteed.
Impedance Mismatch
There may be cases where it is necessary to use the Bird 43 with a non-50 ohm
transmission line. If the reflected power is less than 10% and the frequency is
below 200 MHz, the resulting mismatch will not be too serious. At higher test
frequencies and/or higher reflected power levels, the load impedance will
change when the wattmeter is removed from the circuit.
When the line and load impedances are known, the system’s VSWR equals the
ratio of the two. Always divide the larger impedance by the smaller, since VSWR
must always be greater than 1.
Example - Consider using a Bird 43 to tune a 70 ohm line.
If the load impedance is also 70 ohms, the wattmeter will
measure a VSWR of 70/50 = 1.4. However, if the wattmeter
is removed, the VSWR will actually be 1.0. Similarly, if the
load impedance is 35.7 ohms, the VSWR will be 50/35.7 =
1.4 with the wattmeter and 70/35.7 = 2.0 without it.
Caution must therefore be used, since both good and bad matches can have the
same measured VSWR. In this case, the correct impedance can be determined
by slightly changing the load impedance. When the load impedance is near 70
ohms, the Bird 43 will read increasing VSWR as the load impedance is increased.
Note: When working with non-50 ohm lines, it is especially important to calculate the load power by subtracting the reflected power
from the forward power.
10
Chapter 3 Installation
When transporting the Bird 43, insert the original dust plug, or an element with
the arrow pointing upward, in the element socket and secure with the catch.
This will shunt the meter circuit and protect the meter by dampening needle
action during handling and shipping. Also, secure spare elements in their sockets
with the pivoting knob; just insert the element and twist the knob one-quarter
turn.
CAUTION
Handle elements with care. Calibration could be disturbed if they are
dropped.
Connections
WARNING
Leaking RF energy is a potential health hazard. Never attempt to connect or
disconnect equipment from the transmission line while RF power is being
applied. Severe burns, electrical shock, or death can occur.
Insert the Bird 43 in coaxial transmission lines of 50 ohms nominal impedance.
The RF source can be connected to either side of the wattmeter without affecting readings.
If non-50 ohm cables are used, a mismatch will occur causing inaccuracies in
readings. However, if a mismatch cannot be avoided, refer to "Impedance Mismatch" on page 10 for instructions.
It is strongly advised that this condition be avoided.
The Bird 43 is normally supplied with Quick-Change Female N type connectors.
Other Bird “QC” connectors are available, refer to the Replacement Parts List in
the Maintenance Chapter.
Replacing Quick-Change Connectors
1. Remove the 8-32 screw at each corner of the connector
2. Pull it straight outward.
3. Install the new connector by reversing Steps 1 and 2.
11
Remote Installation
Note: To replace the RF line section, reverse these steps.
1. Unscrew the four 8-32 flat head screws securing the back cover.
2. Grasp the back cover by the side tabs behind the line connectors and pull
straight back to remove it.
3. Remove the two 10-32 oval screws on the front of the housing.
4. Slide the line section out of the housing.
Note: Do not loosen the two oval screws on the sides of the housing
in line with the meter. These hold the shock ring in place.
5. Replace the cable attaching the line section to the meter with one of sufficient length to complete the remote installation.
In some systems it may be desirable to have two or more line sections permanently installed. In this case, one set of elements and one meter can be used to
measure several separate RF transmission lines. Additional RF line sections are
available.
The RF line section of the Bird 43 lends itself very readily to panel mounting. A
layout for the panel cut is given in Figure 7. The thickness of the panel should be
1
about
⁄4 inch. On thinner panels, build up the thickness with pads or washers to
achieve a flush-face mounting. Attach the line section so that the finger catch is
in the most accessible position.
Figure 7 Panel Cut for Mounting RF Body
12
Chapter 4 Operating Instructions
WARNING
When working with RF powers of 200 watts or more, the potential of the
center conductor of the line section will exceed 100 volts. Do not touch the
center conductor while RF power is on.
The Bird 43 uses plug-in elements to make measurements. The element’s frequency range and maximum power are listed on its label. The transmitter test
frequency should be within the band of the element used. See "Frequency
Response" on page 9 for information on using the elements outside of their
specified frequency range.
The arrow on the element indicates directional sensitivity; i.e., the direction of
power flow that the meter will read. Rotate the element to select forward or
reverse power measurement.
Combining the Thruline Wattmeter with a Bird Termaline Load Resistor creates an
accurate absorption wattmeter. With this combination, readings only need to be
taken in the forward direction because the reflected power will be negligible.
Normal Operation
1. Insert the appropriate element in the line section socket.
2. Turn the element so that the arrow points towards the load to measure forward power and towards the source for reflected power.
3. Turn on the RF source.
4. Read the power using the scale whose full-scale marking matches the element’s maximum power.
13
Figure 8 Element Direction
When readings are being made with the wattmeter connected to an auxiliary RF
line section, do not put an element in the unused line section. Otherwise, the DC
circuit will be unbalanced or shorted, causing inaccurate or zero power readings.
For convenience, a set of VSWR conversion nomographs is included in this manual. With these charts, VSWR may be determined from the forward and
reflected power readings. Find the intersection of the forward and reflected
power measurements. The slanted line passing closest to this point indicates the
VSWR.
14
Figure 9 VSWR Conversion Graph (Reflected Power 0.2 – 20.0)
15
Figure 10 VSWR Conversion Graph (Reflected Power 0.01 – 1.00)
16
Load Matching
When a Bird 43 is used to tune a load to a transmitter and a good match is
obtained, removing the unit will not change the match quality. A good 50 ohm
load can terminate a 50 ohm transmission line of any length without altering
conditions at the transmitter. The 43 is just an extra length of 50 ohm line in
series with the measurement.
When the load is not well matched (an antenna with a VSWR of 1.5 or 2.0) the
line length between the load and the transmitter will transform the load impedance as seen at the transmitter. Removing the wattmeter shortens the total line
length by four inches plus two connectors. This is still not significant at low frequencies where five inches is a small fraction of a wavelength, but at higher frequencies the frequency or power output of the transmitter may be affected.
Transmission line theory shows that if the line length changes by exactly
length, the impedance is unchanged. To have identical match with the wattmeter
in or out of the circuit, insert or remove
1
⁄2 wavelength of line (including the unit).
To do this, use a length of cable which, when added to the unit, equals a
length at the frequency of interest. If multiple frequencies are needed, a separate cable length is required for each. See Figure 11 for sample cable lengths.
Note: Cable length is measured from end to end of the connector’s
outer conductor, except for UHF or mini-UHF plugs where the length is
measured from tip to tip of the center pins.
Note: Dimensions shown are for solid polyethylene cable like
RG-58C/U or RG-8/U, which have a velocity of propagation 66% of
that of air. If RG-58 or RG-8 type cables containing foam poly-ethylene
(velocity of propagation of 79%) are used, the dimensions in the graph
must be multiplied by the ratio of the relative velocities; 79% ÷ 66% =
1.2 in this case.
1
⁄2 wave-
1
⁄2 wave-
17
Figure 11 Cable Length / Wavelength Matching
18
Chapter 5 Maintenance
The rugged and simple design of the Bird 43 means that it requires minimal routine maintenance.
Troublehshooting
The following table contains troubleshooting information for problems that can
occur during normal operation. Find the problem on the table, review possible
causes, and perform the corrective action listed.
This manual does not list all malfunctions that may occur, or all corrective
actions. If a malfunction is not listed or not corrected by the listed actions, contact the nearest Bird Service Center for assistance.
Problem Possible Cause Corrective Action
No meter reading No RF power Check RF source
“Arrow” on element
pointing wrong way
DC contact bent Adjust contact (page 20)
Open or short circuit
in meter
Rotate element
Replace defective cable
(RG-58/U)
Intermittent or
inconsistent meter
reading
High VSWR or
reflected power
Meter burned out or
damaged
Dirty DC contact on
element
Faulty transmission
line or antenna
Sticky or defective
meter
Foreign material in
line section or in RF
connector
Open or shorted
transmission line
Bad load or poor
connectors
Return wattmeter for
service
Clean contact (page 20)
Inspect line
Return wattmeter for
service
Clean connectors
(page 20)
Inspect line
Inspect load, antenna,
and connectors
19
Cleaning
It is important to keep the following surfaces clean:
• Socket bore
• DC contacts on the element
• Teflon insulators
If any of the contacts or line connectors are dirty, clean them with a cotton swab
dipped in commercial contact cleaner or isopropyl alcohol.
CAUTION
Do not attempt to remove the RF center conductor. This will damage the line
section.
If the RF line section seems dirty, do not loosen any connections. Clean accessible
components as described above and use dry, clean air to blow out the interior.
The outside of the meter housing can be cleaned with a soft cloth dampened
with a mild detergent solution. Do not wipe the meter glass with a dry cloth, or a
static charge could develop that would cause an erroneous meter indication.
Contact Adjustment
When cleaning the socket bore, do not disturb the spring finger of the DC contact. If necessary, the contact can be adjusted manually. The button must be out
far enough to maintain good contact, but not so far as to interfere with easy
entry of the element body. To remove the DC jack and spring finger:
1. Unscrew both 4-40 fillister head screws holding the jack assembly against
the side of the RF line section.
2. Retract the assembly.
Note: Be careful not to lose the small teflon bead that straddles the
base of the spring and nests in a counterbore on the side of the line
section.
3. Replace the assembly.
Note: Make sure that the bead is properly inserted) and the two
screws.
20
Zero Adjust
The meter’s zero setting should be checked when no RF power is present. When
no power is applied the pointer should rest exactly on zero. If adjustment is
required, turn the adjustment screw until the pointer is set at zero (see
Figure 12).
Figure 12 Zero Adjust
Storage
When storing the meter, keep an element or dust plug in the element socket to
prevent the intrusion of dust and to prevent damage to the meter movement.
When using an element, use the highest power element available. Turn it so that
the “arrow” points up (midway between the FWD and RFL positions). This protects the meter and will not expose the element diode to dangerous potentials
should the line section be energized.
21
Customer Service
Any maintenance or service procedure beyond the scope of those in this chapter
should be referred to a qualified service center.
If the unit needs to be returned for any reason, request an RMA through the Bird
Technologies website. All instruments returned must be shipped prepaid and to
the attention of the RMA number.
Bird Service Center
30303 Aurora Road
Cleveland (Solon), Ohio 44139-2794
Fax: (440) 248-5426
E-mail: bsc@bird-technologies.com
For the location of the Sales Office nearest you, visit our Web site at:
http://www.bird-technologies.com
22
Bird 43 Replacement Parts List
Note: See “Customer Replacement Parts” on page 32
Description Qty. Part Number
Housing Assembly 1 4210-018
Cover Assembly 1 4210-005-1
Line Section Assembly 1 4230-018
Carrying Strap 1 8580A003
Dust Plug, Aluminum 1 3610-031
DC Connector Assembly 1 4230-010
DC Connector 1 7500-076
Microammeter 1 2080-002
Coaxial Cable Assembly 1 4220-097-1
Turnbutton 2 4300-015
Spring Washer 2 5-1144-1
Rubber Stem Bumper 8 5-1388
Pushnut 2 5-1076-1
Replacement Meter Kit 1 8-000
RF Connectors 2 See list on next page
Bird 43 Replacement Parts List
Customer Replacement Part Consists of Description
RPK43-1 - Housing Kit 4210-018 Housing
923-RPK43-1 Instruction Sheet
RPK43-2 - Rear Cover Kit 4210-005-1 Cover
923-RPK43-2 Instruction Sheet
RPK43-3 - Line Section Kit 4230-018 Line Section
923-RPK43-3 Instruction Sheet
RPK43-4 - Meter Kit 8-000 Replacement Meter
4220-087 Shock Mount
923-RPK43-4 Instruction Sheet
23
Customer Replacement Part Consists of Description
RPK43-5 - External Hardware Kit 1118-0614-00 #8-32x3/8 Phillips
Flathead Machine
Screw
1120-0820-00 #10-32x1/2 Phillips
Oval Screw
1136-0813-00 #10-32x1/2 Phillips
Pan Screw
5-1388 Rubber Bumper Stem
5-1763 Gray Rubber Bumper
Foot
8240-054 Strap Spacer Screw
8580A003 Plastic Handle
923-RPK43-5 Instruction Sheet
24
Available “QC” Type Connectors
Connector Part Number Connector Part Number
BNC-Female 4240-125 Open Term.
# 10-32 Nut
BNC-Male 4240-132 SC-Female 4240-090
C-Female 4240-100 SMA-Female 4240-336
C-Male 4240-110 SMA-Male 4240-334
HN-Female 4240-268 TNC-Female 4240-156
HN-Male 4240-278 TNC-Male 4240-160
LC-Female 4240-031 UHF-Female 4240-050
LC-Male 4240-025 UHF-Male 4240-179
LT-Female 4240-018 7/16” IEC (Jack)
Type 169-4
LT-Male 4240-012 7/16” IEC (Plug)
Type 169-4
Mini UHF-Female 4240-346 7/8” EIA 4240-002
N-Female 4240-062 1-5/8” EIA Fixed 4240-096
N-Male 4240-063 1-5/8” EIA Swivel 4240-208
4240-363
4240-344
4240-080
25
26
Chapter 6 Model Differences
Bird 43P Peak Wattmeter
The Bird 43P Thruline Wattmeter is the same as the Bird 43, with the added
capability of measuring peak power in AM, SSB, and some pulse applications. A
conversion kit (P/N 4300-400) is available to give peak reading capability to any
standard Bird 43. This kit comes with all necessary parts and easy to follow
instructions for simple and quick conversion.
Special elements are not required. However, the element power rating must
match the peak power to be measured.
Example - If 1000 watt peaks are expected, use a 1000
watt element.
Operation
There is a push button on/off switch on the right side of the meter.
• To read peak power, push the switch in. The red LED will light.
• To read CW power, push the switch again. The LED will turn off.
Peak Detector Response
Since the peak detector’s response time is about one second, a short delay may
be noticed before the meter reading stabilizes. This will also be noticed when
the transmitter is turned off. In voice modulated systems, the meter reading may
fluctuate by 2–3 minor scale divisions as the peak detector attempts to follow
the power variations.
Rectangular Pulses
When measuring rectangular pulse power, note the following signal requirements:
• Duty Cycle: 2%, minimum
• Rep. Rate: 100 pps, minimum
• Pulse Width: 200 µs, minimum
27
Peak Calibration
+
U1
+
-+
If recalibration is required, refer to figure 15 and these instructions:
1. Unscrew the four 8-32 flat head screws securing the back cover.
2. Grasp the back cover by the side tabs behind the line connectors and pull
straight back to remove it.
3. Insert the Bird 43P between a reliable CW signal source and a 50 ohm load.
4. Insert an element with the appropriate power and frequency range into the
Bird 43P. Turn it to read forward power.
5. Set the wattmeter to CW mode (LED off).
6. Turn on the signal source and adjust the source power to give a stable reading in the upper half of the wattmeter’s scale.
7. Switch the wattmeter to PEAK mode (LED on).
8. Adjust the potentiometer (R9) until the PEAK reading is the same as the CW
reading.
9. Replace the back cover.
Maintenance
Maintenance of the Bird 43P is the same as for the Bird 43 except for battery
replacement. Battery life should typically be 48 hours.
If the unit does not function properly in peak mode or if calibration cannot be
achieved, the batteries may be low. Replace with two new 9 V alkaline or lithium
batteries. The batteries fit very tightly in their retaining clips and may have to be
pried out one at a time.
Figure 13 Model 43P
28
Bird 4301 Thruline Wattmeter
The Bird 4301 Thruline Wattmeter is the same as the Bird 43 except for the following physical differences:
The auxiliary DC connector on the Model 4301 can be used to connect to an
accessory line section. Make the connection with a standard RG-58/U cable.
Bird 4305A Thruline Wattmeter
The Bird 4305A Thruline Wattmeter is the same as the Bird 43 except for the following physical differences:
• The Bird 4305A’s dimensions are 4-5/16”L x 4”W x 6-7/8”H (110 x 102 x
175 mm), including element and bumper feet.
• The Bird 4305A’s weight is 3.25 lb. (1.5 kg), including the element.
• The Bird 4305A does not have holders for spare elements.
• The Bird 4305A line section has higher operating power capability and
is 1-5/8” in diameter, instead of 15/16” as in the Bird 43.
Theory, maintenance, and all instructions for the Bird 43 also apply to the Bird
4305A.
29
Bird 4305A Replacement Parts List
Customer Replacement Part Consists of Description
RPK4305-1 - Housing Kit 4305A003 Housing, Meter
Assembly
RPK4305-5 External Hardware Kit
923-RPK4305-1 Instruction Sheet
RPK4305-2 - Rear Cover Kit 4305A002 Cover Assembly
1118-0419-00 #8-32x1/4 Phillips Screw
923-RPK4305-2 Instruction Sheet
RPK4305-3 - Line Section Kit 4305-005 Line Section Assembly
923-RPK4305-3 Instruction Sheet
RPK4305-4 - Meter Kit 2150A015-1 Meter 25/50/100W
4220-097-22 Cable, Coax/Assy 48 in
923-RPK4305-4 Instruction Sheet
RPK4305-5- External Hardware
Kit
1116-0400-00 #6-32X1/4 Pan Screws
1120-0819-00 #10-32x1/2 Phillips
Screws
4285-002-4 Clamp Spacer
923-RPK4305-5 Instruction Sheet
30
Bird 4431 Thruline Wattmeter
The Bird 4431 RF Sampling Wattmeter is the same as the Bird 43 Thruline Wattmeter except for an RF signal sampler probe.
The RF sampler provides a low power sample of the signal being transmitted
through the wattmeter’s linesection. This signal is available at the female BNC
connector labeled “RF SAMPLE”, on the right side of the housing. The signal level
can be set with the control knob on the front of the meter. The table below lists
approximate attenuation levels, and notes maximum suggested adjustment. The
sampler output may be fed to any suitable RF signal monitoring device; e.g. a
frequency counter, spectrum analyzer, or oscilloscope. All other operation
instructions are the same as for the Bird 43.
Sampler at max
(Fully clockwise)
Freq.
(MHz)
2 69 300 38 800 36
10 57 400 34 900 35.5
25 46 500 30 1000 35
50 42 600 29.5
75 39 700 29 * Approximate
100 36 800 28.5
200 31 900 28
Atten.
(dB)
Turned counter-
clockwise 4 full
turns from max*
Freq.
(MHz)
Atten.
(dB)
Turned counter-
clockwise 7 full
turns from max*
Freq.
(MHz)
attenuation
Atten.
(dB)
Maintenance
Do not make repairs to the probe assembly. If the sampler malfunctions, we recommend returning the unit to the Bird Service Center for repair. To replace the
probe assembly, follow these instructions:
1. Access the probe by unscrewing the four 8-32 flat head screws that secure
the back cover.
2. Grasp the back cover by the side tabs behind the line connectors and pull
straight backward to remove it.
3. Remove the small coupling control knob on the front of the wattmeter with
a 1/16 hex socket wrench.
31
4. Remove the two 8-32 x 1/4” screws fastening the guide and plate assembly
to the back of the line section.
5. Put the control knob back on the shaft, then turn it counterclock-wise until
the collar is free of the shaft.
6. Remove the control knob.
7. Pull the probe plate straight out of the pin and guide bushing.
8. Unscrew the 5/8 hex nut on the BNC connector and pull the sampler connector into the case. The probe plate assembly, P/N 4431-003, is now released
and may be replaced.
Note: The sampler cable (RG-58/U) center conductor is soldered to
the probe’s rear stub. The cable is secured to the side sleeve of the
probe with the same screw used in the dc connector plug assembly,
P/N 7500-076. It may be removed by unscrewing the 3/8 hex screw,
unsoldering the lead tip and pulling out the cable. The probe assembly is formed into the socket and is not replaceable.
9. Replace by carefully reversing the above procedure.
Note: When inserting the control bushing, be sure the alignment pin
is properly positioned.
Bird 4431 Replacement Parts List
Customer Replacement Parts
Customer Replacement Part Consists of Description
RPK4431-1 - Housing Kit 4431-033 Housing
RPK4431-4 Instruction Sheet
RPK4431-2 - Guide Plate, Line
Section Kit
RPK4431-3 - Meter Kit 4230-018 Line Section
RPK43-4 - Meter Kit 2080-002 Meter Assembly
4431-002 Plate, Guide, Assembly
4431-007 Line Section Assembly
4431-003 Plate, Movable Assembly
923-RPK4431-2 Instruction Sheet
923-RPK43-3 Instruction Sheet
5-1066 Strip, Shock
4220-097-1 12 in Coax Cable
4220-087 Mount, Shock Assembly
4410A261 Pad, Neoprene Shock
923-RPK4431-3 Instruction Sheet
32
Customer Replacement Part Consists of Description
RPK4431-4 - External Hardware
Kit
8580A003 Handle, Plastic
5-1388 Bumper, Stem Rubber
5-1763 Bumper Ft, Gray Rubber
1120-0820-00 #10-32x1/2 Phil Screws
1118-0614-00 #8-32x3/8 Phil Screws
1138-0813-00 #10-32x1/2 Phil Screws
4431-035 Label, RF Sample
8240-054 Spacer, Strap, Screw
5-1193 Knob, Knurled BLK
923-RPK4431-4 Instruction Sheet
Service Only Replacement Parts
Replacement Part Consists of Description
RP3610-031 3610-031 (5 per) Aluminum Dust Plug
RP2080-002 2080-002 25/50/100W Mater
RP4300-015 4300-015 Molded Turnbutton
RP5-1388 5-1388 Rubber Bumper Stem
Bird 4520 Series Thruline Wattmeters
The Bird 4520 RF Thruline Wattmeters (models 4521, 4522, 4526, 4527) are the
same as the Bird 43, except that they are panel mounted for rack installation. In
addition, the Bird 4527 has a RF sampler. These units are intended for fixed
installation, generally in rack mounts requiring 19” panels.
Installation
1. Choose a location allowing easy reading and operation of the unit and
where the cables used will be short and without sharp bends.
Note: Avoid the use of angles and adapters.
2. Make sure all connectors are tightened securely.
3. Use four 12-24 screws to fasten the wattmeter panel to the rack.
Operation
The RF sampler on the Bird 4527 provides a low power sample of main RF signal.
This signal is available at the female BNC connector labeled “RF SAMPLE”. The
sampler output may be fed to any RF signal suitable monitoring device; e.g. a
frequency counter, spectrum analyzer, or oscilloscope.
33
Bird 4520 Series Replacement Parts List
The mounting panel entry lists the panel styles for each model. Only parts which
are not used on the Bird 43 are listed here.
4521 Replacement Parts
Customer Replacement Part Consists of Description
RPK4521-1 - Line Section Kit 4230-018 Line Section Assembly
923-RPK4521-1 Instruction Sheet
RPK4521-2 - Meter Kit 2080-002 Meter 25/50-100W
4220-097-5 Cable, Co ax/Assembly
16 in
923-RPK4521-2 Instruction Sheet
RPK4521-3 - Front Panel Kit 4521-002 Panel, Blank
923-RPK4521-3 Instruction Sheet
RPK4521-4 - External Hardware
Kit
1116-0801-25 #6-32x1/2 Round MS
Screw
1132-0201-00 #6 Split Lock Washer
1131-0200-00 #6-32 Hex Nut SS
1120-0820-00 #10-32x1/2 Phillips
Screws
5A2315-2 Label, Safety Symbol
1118-0614-00 #8-32x3/8 Phillips
Screws
4285-002-2 Spacer
923-RPK4521-4 Instruction Sheet
4522 Replacement Parts
Customer Replacement Part Consists of Description
RPK4522-1 - Line Section Kit 4522-002-7 Line Section Assembly
4304-026 Label, Mylar
923-RPK4522-1 Instruction Sheet
RPK4522-2 - Meter Kit 2080-002 Meter 25/50-100W
5A2177 Facenut, Beveled
5A2154 Switch, Toggle
4522-013 Cable, Assembly
923-RPK4521-2 Instruction Sheet
34
Customer Replacement Part Consists of Description
RPK4522-3- External Hardware
Kit
RPK4522-4 - Front Panel Kit 4522-006 Panel, Mounting
1116-0801-25 #6-32x1/2 Round MS
Screw
1132-0201-00 #6 Split Lock Washer
1131-0200-00 #6-32 Hex Nut SS
1120-0820-00 #10-32x1/2 Phillips
Screws
1132-0406-00 #10 External Lock
Washer
5A2315-2 Label, Safety Symbol
1131-0400-00 #10-32 Hex Nut SS
5A2290-2 Label, RFL
5A2290-1 Label, FWD
923-RPK4522-3 Instruction Sheet
5A2290-2 Label, RFL
5A2290-1 Label, FWD
923-RPK4522-4 Instruction Sheet
4526/27 Replacement Parts
Customer Replacement Part Consists of Description
RPK2080-002 2080-002 Meter 25/50-100W
Service Only Replacement Parts
Replacement Part Consists of Description
4526-004 4526-004 Panel
4527-005 4527-005 Panel
4527-002 4527-002 Line Section
Assembly
4430-002 4430-002 RF Cable Assembly
(4527 only)
35
36
Chapter 7 Specifications
These specifications include data covering the Bird 43, 43P, 4305A, 4431, 4521, 4522,
4526, and 4527. Specifications for models not listed are identical to the Bird 43.
Impedance, Nominal 50 ohm
VSWR, Max.
All models except 4431 1.05:1
4431 1.07:1 (when coupling is less than 30 dB)
Connectors
Primary Line Bird “QC” (N Female normally supplied)
RF Sampling (on applicable models) Female BNC
Power and Frequency Range (element dependent)
43,43P,4521/22/26 100 mW – 10 kW
4305 25 kW max, 0.45 – 2.5 MHz
*
4431
4527 1000 W max, 2 – 200 MHz
4527 (approximate) –53 dB, 512 – 10 MHz
4431 (adjustable) 15 – 70 dB
Insertion Loss (4431 only)*
2 – 512 MHz 0.1 dB max
512 – 1000 MHz 0.1 dB max
CW (all models) ± 5% of full scale
Peak Power (43P only) ± 8% of full scale
Power Requirement (43P only) Two 9V alkaline batteries (NEDA 1604)
Battery Life (43P only) 48 hours typical
Dimensions, Nominal
43, 43P 3-5/8”L x 4”W x 6-7/8”H
4305A 4-1/4”L x 3-7/8”W x 6-7/8”H
4431 3-7/8”L x 4”W x 6-7/8”H
4521/22/26/27 19”W x 5-1/4”H x 1-3/4”D
0.45 – 2700 MHz
10 kW max, 2 – 30 MHz
5000 W max, 2 – 30 MHz
1000 W max, 30 – 1000 MHz
500 W max, 200 – 512 MHz
RF Coupling
–70 dB, 10 – 2 MHz
Accuracy
(92 x 102 x 175 mm)
(108 x 99 x 175 mm)
(99 x 102 x 175 mm)
(483 x 134 x 45 mm)
37
Approximate Weight with N-Connectors
4521/22/26/27 3 lb. (1.36 kg)
43, 43P, 4431 4 lb. (1.8 kg)
4305A 3.43 lb. (1.6 kg)
Operating Position Any
Finish Grey Powder Coat
*. Applicable only for maximum coupling less than 30 dB. This requires a minimum
decoupling of four full turns counterclockwise above 200 MHz, and seven full turns
above 800 MHz
38
Limited Warranty
All products manufactured by Seller are warranted to be free from defects in material and
workmanship for a period of one (1) year, unless otherwise specified, from date of shipment and to conform to applicable specifications, drawings, blueprints and/or samples.
Seller’s sole obligation under these warranties shall be to issue credit, repair or replace
any item or part thereof which is proved to be other than as warranted; no allowance
shall be made for any labor charges of Buyer for replacement of parts, adjustment or
repairs, or any other work, unless such charges are authorized in advance by Seller.
If Seller’s products are claimed to be defective in material or workmanship or not to conform to specifications, drawings, blueprints and/or samples, Seller shall, upon prompt
notice thereof, either examine the products where they are located or issue shipping
instructions for return to Seller (transportation charges prepaid by Buyer). In the event
any of our products are proved to be other than as warranted, transportation costs
(cheapest way) to and from Seller’s plant, will be borne by Seller and reimbursement or
credit will be made for amounts so expended by Buyer. Every such claim for breach of
these warranties shall be deemed to be waived by Buyer unless made in writing within
ten (10) days from the date of discovery of the defect.
The above warranties shall not extend to any products or parts thereof which have been
subjected to any misuse or neglect, damaged by accident, rendered defective by reason
of improper installation or by the performance of repairs or alterations outside of our
plant, and shall not apply to any goods or parts thereof furnished by Buyer or acquired
from others at Buyer’s request and/or to Buyer’s specifications. Routine (regularly
required) calibration is not covered under this limited warranty. In addition, Seller’s warranties do not extend to the failure of tubes, transistors, fuses and batteries, or to other
equipment and parts manufactured by others except to the extent of the original manufacturer’s warranty to Seller.
The obligations under the foregoing warranties are limited to the precise terms thereof.
These warranties provide exclusive remedies, expressly in lieu of all other remedies
including claims for special or consequential damages. SELLER NEITHER MAKES NOR
ASSUMES ANY OTHER WARRANTY WHATSOEVER, WHETHER EXPRESS, STATUTORY, OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS, AND NO PERSON IS AUTHORIZED TO ASSUME FOR SELLER ANY OBLIGATION OR LIABILITY NOT
STRICTLY IN ACCORDANCE WITH THE FOREGOING.
