IN STRUC TION BOOK
OP ER ATING IN STRUC TIONS
WITH PARTS LIST
MODEL 4450
THRULINE ® WATTMETER
© Copy right 1994 by Bird Elec tronic Cor po ra tion
In struc tion Book Part Num ber 920-4450-1 Rev.B
THRULINE® is a reg is tered trade mark of Bird Elec tronic Cor po ra tion
Safety Pre cau tions
i
Safety Pre cau tions
The fol low ing are gen eral safety pre cau tions that are not nec es sar ily re lated to any spe c ific part or pro ce dure and do not nec es sar ily ap pear else where in this pub li ca tion. These pre cau tions must be thor oughly un de r stood and ap ply to all phases of op er a tion and main te nance.
KEEP AWAY FROM LIVE CIR CUITS
Op er ating per son nel must at all times ob serve gen eral safety pre cau tions. Do not re place c om po nents or make ad just ments in side equip ment with the high volt age sup ply turned on. To avoid ca su al ties, al ways re move p ower.
DO NOT SER VICE OR AD JUST ALONE
Un der no cir cum stances should any per son reach into an en clo sure for the pur pose of ser vice or ad just ment of equip ment ex cept in the pres ence of some one who is ca pa ble of ren der ing aid.
CHEM I CAL HAZ ARD
Dry clean ing sol vents used to clean parts may be po ten tially dan ger ous. Avoid in ha la tion o f fumes and also pro longed con tact with skin.
RE SUS CI TA TION
Per son nel work ing with or near high volt ages should be fa mil iar with mod ern meth ods of re s us ci ta tion.
SAFETY SYM BOLS
WARNING
Warn ing notes call at ten tion to a pro ce dure, which if not cor rectly per formed, could re sult in per sonal in jury.
CAU TION
Cau tion notes call at ten tion to a pro ce dure, which if not cor rectly per formed, could re sul t in dam age to the in stru -
ment.
MODEL 4450 THRULINE WATTMETER WARNING STATE MENTS
The fol low ing safety warn ings ap pear in the text and are re peated here for em pha sis.
WARNING
Ex po sure to RF power ra di a tion and the pos si bil ity of RF shock or burns ex ists with some o p er at ing con di tions. Al ways be sure to turn off trans mit ter when con nect ing or dis con nect ing wattmeter. Be sure tra ns mis sion line is ter mi -
nated into a load or an tenna.
WARNING
Pro vide ad e quate ven ti la tion and ob serve nor mal pre cau tions when us ing dry clean ing sol vents. Many dry clean ing
agents emit toxic fumes that be harm ful to your health if in haled. Avoid ex ces sive skin con tac t or in ha la tion of the
fumes when us ing any dry clean ing sol vents.
MODEL 4450 THRULINE WATTMETER CAU TION STATE MENTS
ii
The fol low ing equip ment cau tions ap pear in the text and are re peated here for em pha sis.
CAU TION
Do not drop the Thruline Wattmeter equip ment or sub mit it to hard blows. The volt me ter cir cuit ry or microammeter ,
even though it is shock mounted, may be dam aged by se vere im pact.
CAU TION
Clean the me ter glass only when nec es sary and be care ful not to use an ex ces sive amount of wa ter/de ter gent so lu tion
that might drip in side the hous ing and dam age the elec tri cal com po nents.
About This Man ual
About This Man ual
This in struc tion book cov ers the model 4450 Thruline Wattmeter
This in struc tion book is ar ranged so that es sen tial in for ma tion on safety is con tained in the front of the book. Read ing the
Safety Pre cau tions Sec tion be fore op er at ing the equip ment is strongly ad vised.
The re main der of this In struc tion Book is di vided into Chap ters and Sec tions. Fig ures and t a bles are num bered se quen tially
within each chap ter. At the be gin ning of each chap ter a gen eral over view will be given, de sc rib ing the con tents of that chap ter.
OP ER A TION
First time op er a tors should read Chap ter 1 - In tro duc tion, and Chap ter 3 - Prep a ra tion f or Use, to get an over view of equip ment ca pa bil i ties and how to in stall it. An ex pe ri enced op er a tor can re fer to Chap ter 4 - Op er ating In struc tions. All in struc tions nec es sary to op er ate the equip ment, are con tained in this sec tion.
MAIN TE NANCE
All per son nel should be fa mil iar with pre ven tive main te nance found in Chap ter 5 - Main te nance. If a fail ure should oc cur, the
trou ble shoot ing sec tion will aid in iso lat ing and re pair ing the fail ure.
PARTS
For lo ca tion of ma jor as sem blies or parts re fer to the part lists and as so ci ated draw ings in the main te nance chap ter.
CHANGES
Changes to this pub li ca tion will be made avail able in sup ple ments. To keep your in struc tion book ac cu rate and up to date, it
is rec om mended that a pe ri odic re quest of the lat est sup ple ment be made. It will be sup pli ed at no cost. When re quest ing up dates, ref er ence your in struc tion book part num ber and its re vi sion level listed on the ti t le page.
RE PORTING ER RORS
It is our goal to pro vide our us ers with the in for ma tion needed to op er ate and main tain the Thruline Wattmeter. If you should
dis cover any er rors in this pub li ca tion, or if you have sug ges tions for im prov ing this in struc tion book, please send your com ments to our fac tory.
Ta ble of Con tents
v
Safety Pre cau tions ............................ i
Model 4450 Thruline Wattmeter Warn ing State ments ............. i
Model 4450 Thruline Wattmeter Cau tion State ments .............. ii
About This Man ual ........................... iii
In tro duc tion Chap ter 1
Pur pose and func tion .......................... 1-1
De scrip tion .............................. 1-1
Per for mance Char ac ter is tics and Ca pa bil ities ................ 1-1
Power Re quire ments .......................... 1-1
Spec i fi ca tions .............................. 1-2
Out line Draw ing ............................. 1-2
Sche matic Di a gram ........................... 1-3
The ory Of Op er a tion Chap ter 2
Traveling Wave Con cept ........................ 2-1
Traveling Wave vs Stand ing Wave .................... 2-1
Cou pling Cir cuit ............................ 2-1
Re flected Power Read ing ........................ 2-1
In stal la tion Chap ter 3
Por ta bil ity .............................. 3-1
Con nec tions ............................. 3-1
Op er ating In struc tions Chap ter 4
Pre lim i nary Set-up ........................... 4-1
Re verse Power Op er a tion ........................ 4-1
Load Power ............................. 4-1
VSWR Cal cu la tions .......................... 4-2
Main te nance Chap ter 5
Gen eral ................................ 5-1
Sales / Re pair Fa cil ities ......................... 5-1
Sales Fa cil ities ............................ 5-1
Pre ven tive Main te nance .......................... 5-2
Trou ble shooting ............................. 5-2
Re pair ................................. 5-3
Re move Back Cover .......................... 5-3
Cir cuit Board Re pair or Re place ment ................... 5-3
Cal i bra tion Board and Me ter Re moval ................... 5-3
Range and Mode Switch Re place ment .................. 5-4
Re place ment Parts List .......................... 5-5
List of Fig ures
vi
Out line Draw ing ............................. 1-2
Schematic Di a gram ........................... 1-3
Zero Ad just ment Screw .......................... 4-1
VSWR Con ver sion Mono graph ....................... 4-2
Chap ter 1
1-1
In tro duc tion
Purpose and function The Model 4450 Thruline Wattmeter is an in ser tion-type RF wattmeter de signed to mea sure RF
power flow and load match in 50 ohm RF co ax ial trans mis sion lines. Its pri mary in tended use i s
for the test and eval u a tion of power line car rier equip ment, al though it is well suited low f re quency low power RF ap pli ca tion. When used in a 50 ohm ap pli ca tion, with N type con nec tors, it
has an in ser tion VSWR of less than 1.10 for fre quen cies from 25W and 0 to 100W to cor re spond
with the range switch (S-2) set tings.
This unit will not only give for ward power in di ca tions with a high de gree of ac cu racy, but a lso
will in di cate re flected power with a turn of mode switch S-1.
Description The Model 4450 Thruline Wattmeter is a por ta ble unit con tained in a formed alu mi num hous ing,
with formed sheet alu mi num back clo sure which is eas ily re moved. The unit is equipped with a
leather strap for car ry ing, four rub ber shock feet on the base, and four rub ber bump ers on the back,
which al low the unit to be used stand ing ver ti cally or hor i zon tally. The me ter is spe ciall y shock
mounted for ad di tional pro tec tion and has a slot ted ad just ment screw on the front face of th e me ter
be zel for me chan i cal ze ro ing ad just ment. Just be low the me ter on the front face is a mode switch
for se lect ing power range or OFF po si tion. On the sides of the unit are the RF con nec tors whi ch
are la beled for in put and out put.
Performance
Characteristics and
Capabilities
The Model 4450 Thruline Wattmeter is ca pa ble of mea sur ing RF power up to 100 Watts in three
ranges: 5, 25, and 100 Watts. These power lev els are se lected by ad just ing the range switch and
can be used for ei ther for ward or re flected power by ad just ing the mode switch to RFL or FWD
po si tion. When check ing re flected power greater res o lu tion can be ob tained by se lect ing a lower
power set ting on the range switch.
If nec es sary, the in put and out put con nec tions may be re versed with out loss of ac cu racy; how ever,
the mode switch will be just the op po site of nor mal set tings, i.e. RFL po si tion will in di cate for ward power and FWD po si tion will in di cate re flected power.
The RF con nec tors are the Quick-Change (QC) type and may changed to other avail able QC types
if nec es sary.
Power Requirements The Model 4450 Thruline Wattmeter has no bat ter ies and re quires no out side util ity power sourc e
for op er a tion other than the RF power to be mea sured. This makes the unit es pe cially suited f or
mo bile, ma rine, and field use.
Spec i fi ca tions
Bird Model 4450 Thruline Wattmeter
1-2
Im ped ance 50 ohms nom i nal
Power range 5/25/100 Watts
In ser tion VSWR 1.10 max i mum
Con nec tors Bird QC type, Fe male N nor mally Sup -
plied
Tem per a ture Range
Op er ating
Stor age
Ac cu racy* (From 5°C to 45°C)
30 to 535 kHz
20 kHz to 1 MH z
Di men sions 3"D x 3
In ser tion Loss 0.2 dB max i mum
Directivity 25 db min i mum
Weight 2lb (0.91 kg)
* On the 5 Watt range only the lower fre quency is 30 kHz for 10% ac cu racy and the
am bi ent tem per a ture is lim ited to 15°C to 25°C for this ac cu racy.
+5°C to +45°C (41°F to 113°F)
-10°C to +45°C (14°F to 113°F)
(Into a 50 ohm load)
5% of full scale
10% of full scale
53
“W x 6
64
7
”H
8
(76 x 97.2 x 175mm)
Out line Draw ing
Sche matic Di a gram
-
1-3
Bird Model 4450 Thruline Wattmeter
1-4
Chap ter 2
2-1
The ory Of Op er a tion
Traveling Wave
Concept
Traveling Wave vs
Standing Wave
The op er a tion of the Model 4450 Wattmeter is based on the trav el ing wave con cept of RF trans mis sion. As RF power is ap plied to a trans mis sion line, there is a for ward wave trav el ing fr om the
trans mit ter to the load, and a re flected wave trav el ing from the load to the trans mit ter. Th e closer
the load is matched to the line, the smaller the re flected wave will be. To de ter mine the watts dis si pated in the load it is nec es sary to de ter mine the power of the for ward wave and the power of the
re flected wave. The dif fer ence be tween the two will in di cate ef fec tive power dis si pa tion .
The in ter fer ence be tween for ward and re flected waves pro duces a stand ing wave in the co ax ial
sys tem. In the stand ing wave con cept, VSWR (volt age stand ing wave ra tio) is a widely used im ple ment. There is a sim ple re la tion ship be tween for ward power, re flected power, and VSWR.
Where: Wf = for ward power and Wr = re flected power.
Since there is a def i nite re la tion ship be tween stand ing wave ra tio and the for ward-reflect ed power
ra tio, the for ward and re flected pow ers may be read as in di cated by the Thruline me ter, and con ve niently con verted to VSWR. The charts fur nished in this in struc tion book may be used for this
pur pose.
Coupling Circuit When the wattmeter is con nected into a co ax ial sys tem, the RF power is di rected through the me -
tered line sec tion, which is a short sec tion of 50 ohm air line. This line sec tion will not im p air the
im ped ance of the RF co ax ial line into which it is in serted.
The main line or cen ter con duc tor of this line sec tion passes through a toroid coil, which acts as a
cur rent trans former hav ing a one turn pri mary. The sec ond ary turns of this toroid coil vary a nd are
de ter mined by the power range in volved.
The cur rent in duced in the sec ond ary wind ings of the toroid coil are fed to a re sis tive net work
which pro duces volt ages pro por tional to the line cur rent.
There is also a ca pac i tive di vider net work in the line that senses the line volt age. This net work
pro duces a volt age nearly equal to volt age pro duced by the re sis tive net work.
When the mode switch is in the for ward po si tion, these volt ages will add in phase. This volt ag e is
rec ti fied and is cal i brated to give an in di ca tion on the microammeter equal to for ward powe r in the
line sec tion.
Reflected Power
Reading
A cou pling cir cuit, iden ti cal to the for ward power cou pling cir cuit, is used for the re flec ted power
read ing. This cir cuit is po si tioned so that it will sense the power in the di rec tion op po si te to the
for ward di rec tion. The me ter will in di cate this power when the mode switch is placed in the R FL
po si tion. The en ergy re sult ing from the in duc tively cou pled com po nent of the for ward wav e will
bring about can cel la tion as de scribed above.
When the mode switch is in the re flected (RFL) po si tion these volt ages will op pose and al most
com pletely can cel each other when a good 50 ohm load ter mi na tion is used. This re sul tant vol t age
will be in di cated on the microammeter as the power op po site to the for ward power, or re flecte d
Bird Model 4450 Thruline Wattmeter
2-2
power.
Chap ter 3
3-1
In stal la tion
Portability The Model 4450 THRULINE Wattmeter is a por ta ble unit and the hous ing is not de signed for
fixed mount ing. A leather strap han dle is pro vided on the unit for car ry ing pur poses. When tr ans port ing the Model 4450 turn the range switch to the OFF po si tion. This will shunt the me ter mov e ment and ef fec tively dampen the pointer ac tion to pro tect it dur ing han dling or ship ping.
C A U T I O N
Do not drop the THRULINE Wattmeter equip ment or sub mit it to hard blows. The volt me ter
cir cuitry or microammeter, even though it is shock mounted, may be dam aged by se vere im -
pact.
Connections
W A R N I N G
Exposure to RF power radiation and the possibility of RF shock or burns exists with some
operating conditions Always be sure to turn off transmitter when connecting or
disconnecting wattmeter. Be sure transmission line is terminated into a load or antenna.
In sert the Model 4450 THRULINE Wattmeter in trans mis sion lines of 50 ohms nom i nal im ped ance. At tach ment is made through the con nec tors on ei ther side of the wattmeter hous ing. A sh ort
length of 50 ohm co ax ial trans mis sion ca ble fit ted with ap pro pri ate mat ing con nec tors s hould be
used when in stall ing the wattmeter. The in put side of the wattmeter, la beled “IN PUT”, must be
con nected to the trans mit ter out put ca ble and the OUT PUT side of the wattmeter to a suit able
dummy load or an tenna.
The Model 4450 is nor mally sup plied with two Fe male N con nec tors which are of the Bird
Quick-Change de sign. These con nec tors may be readily and eas ily changed to other “QC” type
con nec tors listed in the Re place ment Parts List. These con nec tors are avail able from Bird El ec tronic Cor po ra tion and may be re quested at time of or der to fa cil i tate con nec tion to the user’s sys tem.
These “QC” con nec tors are eas ily changed by re mov ing the four 6-32 pan head ma chine screws
from the cor ners of the con nec tor flange and pull ing the con nec tor straight off. To in stall con nec tors, re verse the re moval pro ce dure mak ing sure the cen ter con tact pin aligns prop erly with its
mat ing socket.
Bird Model 4450 Thruline Wattmeter
3-2
Chap ter 4
4-1
Op er ating In struc tions
The ap par ent fea tures of the Thruline equip ment have been dis cussed in the pre ced ing sec tio ns. As
pre vi ously men tioned, no bat ter ies or ex ter nal power source is re quired to op er ate the wa ttmeter.
A suf fi cient amount of power is taken from the RF trans mis sion line to op er ate the unit. This
power is neg li gi ble and does not af fect the power out put to a no tice able de gree.
Preliminary Set-up Be fore ap ply ing any RF power, make sure the me ter pointer is ex actly set on the ZERO mark of
the scale. If ad just ment is re quired, the pointer must be set on the ZERO mark un der no-power
con di tions with the range switch set on one of the lower power ranges. Using a small screw driver ,
turn the zero ad just screw on the be zel of the me ter clock wise or coun ter clock wise as nec es sary
un til the pointer ex actly aligns with the ZERO mark on the me ter scale.
Zero Ad just ment Screw
Figure 4-1
The range switch should be in the OFF po si tion or at least on the 100 watt range, when power is
ap plied. This is es pe cially true when the amount of power be ing ap plied is un known. Af ter RF
power is ap plied, the range switch may be turned to a po si tion where a power in di ca tion is gi ven
in the up per one-third of the scale.
The mode switch should nor mally be in the FWD po si tion and switched to the RFL po si tion af ter
a for ward read ing has been taken. In the RFL po si tion a more ac cu rate re flected power read i ng can
be ob tained by turn ing the range switch to a lower set ting. How ever, with this con di tion care must
be taken not to turn the mode switch back the the FWD po si tion un til the range switch has been r e turned to its orig i nal set ting. Fail ure to do this will cause overranging of the me ter and pos si ble
dam age. This prac tice, of course, is not pos si ble when power less than five watts is be ing mea sured.
Reverse Power
Operation
The Model 4450 may be in stalled back ward in the trans mis sion line if nec es sary, i.e. trans mi t ter
out put to wattmeter out put and wattmeter in put to load; how ever, the for ward and re flected po wer
in di ca tions will be re versed. There fore when the mode switch is in the FWD po si tion, re vers e
power will be in di cated and the RFL po si tion will in di cate for ward power. Since the line cou plers
and cir cuitry are sim i lar, ac cept able power in di ca tions are given with lit tle, if any, cha nge in ac cu racy. Re versing the unit in the trans mis sion line should only be done when ab so lutely nec es s ary
since there is the po ten tial dan ger of overranging the me ter move ment.
Load Power Where an ap pre cia ble amount of power is re flected from a load, as with some an ten nas, it is n ec es -
sary to sub tract the re flected power read ing from the for ward power to ob tain ac tual load pow er.
RF power de liv ered to and dis si pated in a load is given by the for mula:
WL = watts into load = Wf - Wr
This cor rec tion is neg li gi ble (less than 1 per cent) if the load is such as to have a VSWR of 1.2 to
1.0 or less. Good load re sis tors such as Bird TERMALINE Loads will give this neg li gi ble or un read able re flected power.
VSWR Calculations Af ter ob tain ing the for ward and re flected power read ings de scribed above, the VSWR may be
Bird Model 4450 Thruline Wattmeter
4-2
found by cal cu la tion as de scribed on page 2-1 Traveling wave vs. Stand ing wave. Con ver sion
nomographs to sim plify de ter min ing VSWR are pro vided be low. Sim ply find the num bers on the
hor i zon tal and ver ti cal axis of the nomograph which cor re spond to the ac tual for ward and r e verse
power read ings re spec tively. Fol low the cross lines un til they in ter sect, and read the VSWR from
the near est slanted line.
Figure 4-2
VSWR Con ver sion
Mono graph
Power Values vs.
VSWR
Chap ter 5
5-1
Main te nance
Gen eral
This chap ter con tains op er a tor main te nance in struc tions, trou ble shoot ing and parts in f or ma tion.
With the rel a tively sim ple cir cuitry, con struc tion, and self-contained na ture of the Model 4 450
Thruline equip ment, only a mod er ate amount of main te nance is re quired. The ma jor pre cau tio n for
the safe keep ing and main te nance of the wattmeter is han dling; use rea son able care and do not drop
the unit.
Any main te nance or ser vice pro ce dure be yond the scope of those pro vided in this sec tion sho uld
be re ferred to a qual i fied ser vice cen ter.
Sales / Repair
Facilities
U.S.A. Sales and Man u fac turing
Ser vice Group
Bird Elec tronic Cor po ra tion
30303 Au rora Road
Cleve land (Solon), Ohio 44139-2794
Phone: (440) 248-1200 Ca ble: BIRDELEC
Fax: (440) 248-5426 Telex: 706898 Bird Elec UD
Sales Facilities For the lo ca tion of the sales of fice near est you, give us a call or visit our Web site at:
http :// www .bird-electronic.com
Pre ven tive Main te nance
Bird Model 4450 Thruline Wattmeter
5-2
W A R N I N G
Provide adequate ventilation and observe normal precautions when using dry cleaning
solvents. Many dry cleaning agents emit toxic fumes that may be harmful to your health if
inhaled. Avoid excessive skin contact or inhalation of the fumes when using any dry
cleaning solvent
If any of the con tacts or line con nec tors be come dirty, they should be cleaned with an aero sol type
cleaner that leaves no res i due, or any dry clean ing sol vent on a soft cloth or cot ton swab sti ck.
Clean all con tact sur faces and the ex posed sur face of the Tef lon in su la tors.
The hous ing and me ter glass can be cleaned with a soft cloth and a mild de ter gent so lu tion.
CAU TION
Clean the me ter glass only when nec es sary and be care ful not to use an ex ces sive amount of
wa ter/de ter gent so lu tion that might drip in side the hous ing and dam age the elec tri cal
com po nents.
Trou ble shooting
Ta ble 5-1 con tains trou ble shoot ing in for ma tion for prob lems which can oc cur dur ing nor m al op er a tion. Lo cate the prob lem, re view the pos si ble causes, and per form the ac tion listed.
PROB LEM CAUSE AREAS TO CHECK / COR REC TION
No me ter in -
No RF power 4 Check trans mit ter or trans mis sion line
di ca tion
4
Open or short
in dc cir cuit
4 Check me ter leads or cir cuit board and re -
lated com po nents
De fec tive me ter 4 Check me ter
In ter mit tent
or in con sis tent me ter
read ings
Faulty load 4 Check dc re sis tance of load
Faulty trans -
mis sion line
De fec tive con -
nec tion or cold
4 Check line for shorts, opens, bad con nec -
tions or de fec tive con nec tors
4 Check cir cuit board and re lated parts for
bad con nec tions
sol der joints
Sticky or de fec -
4 Check me ter and re place if nec es sary
tive me ter
Re pair
-
5-3
Al though the Model 4450 is de signed to be rug ged and pro vide years of trou ble-free ser vice, o c ca sional re pair or re place ment may be come nec es sary. This sec tion con tains re pair and re pla ce ment
pro ce dures.
Re pairs should not be at tempted by the user for the first year war ranty pe riod as this may void the
war ranty.
If a prob lem should oc cur in the line sec tion or cou pling cir cuits, the unit should be re turn ed to the
fac tory for re pair and recalibration .
Remove Back Cover Fol low the in struc tions be low when re mov ing the back cover is nec es sary for parts re place ment or
re pair.
1. With draw four screws lo cated on the back half of both sides.
2. Pull back cover straight off.
Circuit Board Repair
or Replacement
1. Re move back cover.
2. Peel off the rub ber feet lo cated in the back half of the bot tom sec tion to gain ac cess to flat head screws se cur ing the line sec tion
mount ing bracket.
3. Re move the two screws.
4. Pull the line sec tion out of the back slightly and dis con nect the
three wires that con nect to the cir cuit board.
5. With draw four pan head screws in each cor ner of con nec tor flanges
and pull QC con nec tors straight off.
6. With draw the four screws on the line sec tion hous ing po si tioned
near the top edge. Do not re move the screws that se cure the mount ing bracket to the hous ing. The cir cuit board will lift straight out of
the hous ing with the cen ter con duc tor at tached.
7. Com plete re as sem bly by re vers ing the pro ce dure above. See note be low.
+ NOTE: When re as sem bling the cir cuit board and line sec tion in the hous ing, po si tion the cir -
cuit board so that the 5k cal i brat ing po ten ti om eters, R5 and R6, face away from the side of the
hous ing on which the mount ing bracket is at tached. These con trols must face out ward for cal i bra tion pur poses and also to main tain cor rect in put and out put con fig u ra tion.
Calibration Board and
Meter Removal
1. Re move the rear cover.
2. Un plug the rib bon ca ble con nec tor from the cal i bra tion board.
3. Re move the two nuts that se cure the cal i bra tion board to the ter mi nals of the me ter. The cal i bra tion board can now be taken out of the
hous ing.
4. To re move the me ter, un screw the three Phil lips head screws from
the front face of the me ter hous ing. The me ter may now be pulled
straight out of the hous ing. No tice the rub ber shock ring on the
front of the me ter. It must be re placed when re as sem bling me ter to
case.
5. Re in stall the me ter and cal i bra tion board by re vers ing the dis as sem -
Bird Model 4450 Thruline Wattmeter
5-4
bly pro ce dure. Do not tighten the me ter mount ing screws ex ces sively.
Range and Mode
Switch Replacement
1. Re move back cover.
2. Peel off the rub ber feet lo cated in the back half of the bot tom sec tion to gain ac cess to flat head screws se cur ing the line sec tion
mount ing bracket.
3. Re move the two screws.
4. Pull the line sec tion out of the back slightly and dis con nect the
three wires that con nect to the cir cuit board.
5. Using a 5/64 Al len wrench, loosen the set screws in the switch
knobs and re move the knobs.
6. Re move the nuts that se cure the switches to the front panel with a
9/16 end wrench. Un plug the rib bon ca ble con nec tor from the cal i bra tion board. The switch and ca ble har ness as sem bly can now be
re moved from the me ter hous ing as sem bly for re pair or re place ment.
If only one switch is to be re placed, be sure to re at tach the wires
in di vid u ally to the cor rect switch lugs as orig i nal.
7. To re in stall the switch as sem bly, sim ply re verse the dis as sem bly
pro ce dure. When re plac ing the knobs, make sure the ar row of the
knob points to the cor rect set ting be fore tight en ing the set screws.
Re place ment Parts List
-
5-5
QTY . DE SCRIP TION PART NUMBER
1 Line sec tion as sem bly 4450-003
1 Mount ing bracket 450-020
2 PC board mount ing brack ets 4450-019
1 30 uA me ter 2080-063
2 Switch knobs 4110-016
1 Me ter hous ing 4450-009
1 Carrying strap 8580-003
8 Bumper feet 5-875
1 Back cover as sem bly 4450-005
2 “QC” con nec tors *See Be low
1 PC board as sem bly (line sec tion) 4450-015
1 PC board as sem bly (me ter) 4450-014
2 RF choke (2.4 uH ) (L1 & L2) 5-1546
1 Switch (2 pole, 2 po si tion) 5-1361
1 Switch (2 pole, 4 po si tion) 4450-026
2 N617 di odes (RCA SK3087) (D1 & D2) 5-1571
2 25 k po ten ti om eters (R1 & R3) 5-1364-2
2 100 k po ten ti om eters (R2 & R4) 5-1364-5
2 5k po ten ti om eters (R5 & R6) 5-1572
2 13 ohm (R7 & R8) 5-581
1 1.8 k sensistor (SR1) 5-595-1
1 5 k sensistors (SR3) 5-595-7
1 10 k sensistor (SR2) 5-595-8
2 1000pF ce ramic (C1 & C2) 5-1564-1
2 5000pF ce ramic (C3 & C6) 5-1564-2
2 15-60pF vari able (C4 & C5) 5-1570
1 Switch as sem bly (In cludes both
switches & wire har ness) 4450-004
*Avail able “QC” Type Con nec tors
N-Female 4240-062 LT-Female 4240-018
N-Male 4240-063 LT-Male 4240-012
HN-Female 4240-268 C-Female 4240-100
HN-Male 4240-278 C-Male 4240-110
LC-Female 4240-031 UHF-Female (SO-239) 4240-050
LC-Male 4240-025 UHF-Male (PL-259) 4240-179
BNC-Female 4240-125 7/8" EIA Air Line 4240-002
BNC-Male 4240-132
QUAL ITY IN STRU MENTS
FOR RF POWER MEASUEMENT
From 2 to 2300 MHz and from 25 milliwatts
to 250 ki lo watts in 50 ohm co ax ial line sys tems
TERMALINE ®
AB SORP TION
WATT ME TERS
LOAD RE SIS TORS
CAL O RIM E TERS
THRULINE ®
DI REC TIONAL
MON I TORING
WATT ME TERS
TENULINE ®
ATTENUATORS
COAXWITCH ®
SE LEC TOR
SWITCHES
CO AX IAL RF FIL TERS
SENTRILINE ®
FIL TER-COUPLERS
ELEC TRONIC COR PO RA TION
30303 Au rora Road, Cleve land, (Solon) Ohio 44139-2794
Loading...
