BB-400
Installation Manual and
Operating Instructions
BB-400
This Product should be installed according to this manual.
Please read this manual carefully and install properly.
Please keep this manual for future reference.
Please register Warranty for proper service.
PERSONLAL HYGIENE APPLIANCE
Head office:
205 Berg St
Algonquin, IL 30102
U.S.A
Tel
: (847) 854-7292
Fax: (847) 854-1296
BBC Innovation Corporation
www.biobidet.com
lifestyle Upgrade
3
lifestyle Upgrade
Installation Manual and Operating Instructions
lifestyle Upgrade
2
Installation Manual and Operating Instructions
Thank you for purchasing Bio Bidet Advanced Toilet Seat
This unit was manufactured for household use.
MAINTENANCE
WATER DRAINING
TROUBLE SHOOTING
SPECIFICATIONS
WARRANTY
INFORMATION TO THE USER
INSTALLATION
SEPARATION OF THE UNIT FROM
THE TOILET BOWL
OPERATION (BASIC)
OPERATION (DETAILS)
Product structure and designations
IMPORTANT SAFEGUARDS /
GENERAL CAUTIONS
CAUTIONS BEFORE INSTALLATION
CARTON CONTENTS / IDENTIFICATION
PREPARATION INSTALLATION OPERATION MAINTENANCE
Contents
4
6
8
8
11
14
12
15
18
19
20
21
22
23
5
lifestyle Upgrade
Installation Manual and Operating Instructions
lifestyle Upgrade
4
Installation Manual and Operating Instructions
The following terms are used in this manual to indicate hazards of varying degrees of severity
Indicates potentially hazardous situation which, if not avoided, may result in minor or
moderate injury or in damage to the product or other property.
Indicates potentially hazardous situation which, if not avoided,
could result in death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
DANGER
CAUTION
READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE
DANGER - To reduce the risk of electrocution
WARNING - To reduce the risk of burns, electrocution, fire, or injury to persons
PLEASE OBSERVE THE FOLLOWING PRECAUTION BEFORE USING THIS PRODUCT
PREPARATION
Do not open the product to repair or remodel.
Only qualified service personnel should service this product.
Do not use attachments not recommended by the manufacturer.
Do not dismantle
Connect this product to cold water supply pipe
carrying portable water.
Do not connect to an industrial water supply line that
does not carry water of drinking quality.
This will negatively effect hygiene and performance.
Prohibited
About Low Temperature Burns-
A burn occurs when the skin has been exposed to high temperatures. However,
a low temperature burn may occur when the skin has been in contact with an object at
relatively low temperature (about 104
℉). Close supervision is
necessary when this product is used by children or adults with sensitive skin.
Prohibited
If using any chemical toilet bowl cleaner, be sure to wipe up
any spills that splash onto Electric Bidet.
Do not use benzene or any acid chemical detergent.
Only neutral detergent permitted.
Prohibited
Do not plug in the power cord before connecting
the water supply hose.
Prohibited
This product must be grounded.
An approved Ground Fault Circuit Interrupt must be used.
Grounding
Do not splash water on this product. Please provide adequate
ventilation to avoid damage to electronic components due to
high level of humidity.
It is necessary to provide adequate ventilation with a fan, open
door or open window when bathing.
Do not spray water
Do not touch the power cord with wet hands.
Do not reach for a product that has fallen into water.
Unplug immediately!
Wet hands prohibited
This product must be connected to a standard
voltage power source. Do not connect power
cord if the cord is damaged or broken.
Do not plug the unit into a loose electric outlet.
Observe at all times
Please disconnect the power cord when you clean
this product or detach it from toilet bowl.
Do not supply electrical power to the unit until the
plumbing work has been completed.
Observe at all times
Keep the electrical cord away from heated surfaces to
prevent a fire hazard. Also, keep any flammable materials away
from this product at all times.
Use of fire prohibited
1
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
7
lifestyle Upgrade
Installation Manual and Operating Instructions
lifestyle Upgrade
6
Installation Manual and Operating Instructions
PREPARATION
CAUTION
Never operate this product if it is not working
properly, if it has been dropped or damaged,
or dropped into water. Return the product to
a service center for examination and repair.
Prohibited
Do not obstruct or put
anything into the dry air
outlet. Do not apply
excessive force to the
shower nozzle.
Prohibited
Do not strain or push the connected hose and tube connecter;
it may cause water leakage. Never drop or insert any object
into any opening or hose. Use proper plumbing supplies if any
modification is to be made.
Prohibited
Drain the water from unit and unplug the power if it is
not going to be used for an extended period of time.
Refer to page 19
Observe at all times
Do not stand or sit on
the seat cover lid.
It is not designed to
support a user’s
body weight.
Prohibited
Allow the seat
and lid to close
automatically
do not force the
lid closed.
Prohibited
Use this product only as described
in the operating instructions. Never
use while sleeping or drowsy.
Do not use while bathing.
Observe at all times
Be careful so that
this product does not
become stained with
excrement and urine.
Observe at all times
- SAVE THESE INSTRUCTIONS -
THIS PRODUCT MUST BE PLUGGED into a regular voltage Grounded GFCI outlet (North
America 120V ac, 60Hz / Europe 220-240V~ , 50/60Hz). The rated power consumption is 660W /
600-700W. In locations where only a standard two-prong outlet is available, it is the responsibility
of the user to install a grounded three-prong outlet. Using a higher voltage is dangerous and may
result in a fire or other accident. This product is not responsible for damage resulting from the use of
it on other than specified voltage, or operating it without proper grounding.
WIRING REQUIREMENT
This product has a three-prong grounding plug, which must be plugged into an outlet that is properly installed and
grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat blade terminal. The wire with insulation having an outer surface that is green with or
without yellow stripes is the grounding wire. Check with a qualified electrician or serviceman if the grounding
instructions are not completely understood, or if in doubt as to whether the product is properly grounded.
This product is for use on a nominal 120V circuit, and has a grounding plug that looks like the plug illustrated in
sketch A in Figure 1. A temporary adapter, which looks like the adapter illustrated in sketches B and C, may be
used to connect this plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly grounded outlet (sketch A) can be installed by a qualified
electrician. The green colored rigid ear, lug, or the like extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by the screw.
This appliance has to be earthed.
GROUND INSTRUCTIONS
GROUNDING PIN
ADAPTER
ADAPTER
METAL SCREW
TAB for
Grounding Screw
GROUNDED
OUTLET
- Figure 1-
The use of an extension cord is not recommended or advised. If it is necessary to use an extension cord, use
only a three-prong extension cord (one to one), and a three slot built-in GFCI receptacle that will accept the
plug on this product. The marked rating of the extension cord should be equal to or greater than the electrical
rating of the unit (10amp). Consult a qualified electrician or service person if you are not sure whether the unit is
properly grounded.
IMPROPER GROUNDING CAN RESULT IN A RISK OF ELECTRIC SHOCK.
Electric wiring has to be done in accordance with all local codes,
or in the absence of local codes, with the National Electrical Codes.
DANGER
This Product must be on a separate circuit.
No other appliance should share the circuit with this product.
Sharing a circuit could cause the branch circuit fuse to blow
or the circuit breaker to trip. Continuous usage under these
conditions could result in fire or property damage.
WARNING
GROUNDED
OUTLET BOX
2
CAUTIONS BEFORE INSTALLATION
(1)
(2)
