Instruction Manual
SI–2600, SI–2610
Steam Iron
Steam Iron SI–2600, SI–2610
ENGLISH ........................................ 4
FRANÇAIS .....................................12
РУССКИЙ..................................... 20
ENGLISHFRANÇAISРУССКИЙ
УКРА¯НСЬКА ............................... 28
3
УКРА¯НСЬКА
Steam Iron SI-2600, SI-2610
Please read the safety instructions carefully before using
this appliance. Please retain the instructions for future
reference.
SAFETY MEASURES
When using your appliance, the following basic
safety precautions should always be followed:
Before using for the first time, check that the appli-
ance voltage is the same as your local supply.
Only use the appliance for the purposes stipu-
lated by the instructions.
Only use attachments supplied with the equip-
To avoid electric shocks, do not immerse the appliance,
plug or power cord in water or any other liquids. Do
not place the appliance where it could come into contact with
water or other liquids. If the appliance comes in contact with
water, immediately disconnect it from the mains. Do not use
the machine again until it has been serviced by an autho-
rized service center.
Do not let children use the appliance without supervision.
If the power cord plug does not fit to your wall socket,
consult a qualified electrician.
Use of various adapters may result in damage to the
appliance and termination of warranty.
Always supervise the equipment while in use.
To avoid a circuit overload, do not operate any other high
voltage equipment on the same circuit.
Always unplug before moving the appliance from one
place to another, cleaning and storing.
Never pull the cord to disconnect the appliance, instead grasp
the plug and pull it to disconnect.
Do not allow the cord or the machine itself to come in contact
with hot surfaces.
Position the appliance and the cord so that nobody can acci-
dentally overturn it.
Do not use the appliance if it has been dropped, or it has a
damaged power cord or plug. Do not modify or repair the
machine yourself.
Do not dismantle the appliance as improper assembly might
result in an electric shock during the subsequent use of the
equipment. Repairs should only be done by authorized
service centers.
Do not use the device in areas where combustible gas mixtures
or inflammable liquid vapors could present in the air, or in
areas with inflammable air-borne dust or fibers.
This equipment is intended for household use only, not for
commercial or industrial use.
Please follow all the requirements of this guide
Do not use the appliance if it has mechanical defects (dents,
cracks etc.), get it checked by the nearest authorized service
center.
ment.
4
SPECIAL SAFETY MEASURES
Do not leave the iron unattended when it is
connected to a mains supply outlet. Always
switch the iron off even when you leave the
room for short periods of time.
Do not leave the hot iron in a horizontal posi-
tion: place it upright on a heat resistant surface.
The iron gets hot when in operation: any skin contact with
metal surfaces, vapor or water may result in burns.
During operation of the appliance keep children away from it
especially when steam ironing.
Never iron or steam iron articles being worn by a person.
Avoid any contacts between the sole plate and plastic fittings
of an article: buttons, zippers, labels, etc.
Always disconnect the iron from the mains when filling or drain-
ing the water tank.
Store the iron in a vertical position to avoid damaging the sole
plate.
The iron should always be connected to a grounded main
electricity supply.
DESCRIPTION OF
COMPONENTS
1. Casing
2. Handle
3. Water inlet opening
4. Water tank cover
5. Water tank with maximum limit mark
6. Spray nozzle
7. Spray button
8. Burst of steam button (turbo steam, burst of steam in a vertical
position)
9. Steam control knob
10.Temperature control knob
11.Operation indicator
12.Iron sole plate
13.Power plug
14.Power cord
15.Measuring jug
ENGLISH
BEFORE USE
Remove all packaging from the appliance.
Turn the steam control knob (9) into the
“0” position, and the temperature control
knob (10) — into the “Min” position.
If you intend to iron with spray or steam,
push the cover (4) up and fill the tank (5)
the measuring jug (15) for convenience and ease.
with water through the opening (3). Use
5
Note: if your area has hard water, we recommend you use
filtered or bottled water.
Attention: always disconnect the iron from the electricity
mains supply prior to filling the tank (5). Do not
overfill the tank (see the “Max” mark on the tank
(5). Do not fill the tank (5) with other liquids.
Prior to first use iron a clean old piece of cotton cloth to make
sure the sole plate and the water tank are absolutely clean
(see subsection “Steam ironing”).
Note: light smoke may emit during the first use of the
appliance: it is a normal occurrence that will soon
disappear.
INSTRUCTIONS FOR USE
1. Place the iron into a vertical position.
2. Insert the power plug (13) into the mains supply
outlet.
3. Turn the temperature control knob (10) to set
the temperature recommended by the manufacturer of the textile article (usually indicated on the article’s label).
Note: in case the manufacturer’s recommendations are
missed, select the temperature setting, which
corresponds to the type of the cloth to be ironed (see
section “Useful advice”).
4. The operation indicator (11) will light up to indicate that the
iron is being heated to the set temperature level. When the set
temperature level is reached, the light indicator (11) will turn off.
Note: during operation of the appliance the light indicator
will light up and turn off periodically; this is normal
and not a malfunction.
Steam ironing
Dry ironing can be used at any temperature setting. To do this
the steam control knob (9) must be put into the “0” position. If
you intend to use the steam function, allow the iron to heat to the
required temperature level then put the control knob (9) into the
required position.
Attention: application of the steam ironing function is
impossible at “•”temperature setting. SI-2610 iron:
the “Drip Stop” system automatically terminates the
steam generation process if the selected temperature
is too low. When the system is activated, you may
hear a click. SI-2600 iron: if the temperature is
insufficient to generate steam, water will start
dripping from the sole plate. To avoid this, always
6
put the steam control knob (9) into the “0” position
prior to ironing at low temperatures.
Turbo steam
To ease ironing of dense cotton, linen and upholstery articles
use the steam burst button (8): engagement of the button (8)
during the ironing process generates an extra burst of steam from
the sole plate to help remove stubborn creases.
Burst of steam in a vertical position
This function helps to freshen the appearance of curtains, jack-
ets, coats, etc. To use this function, take the following steps:
Follow instructions in paragraph 1-4 of the section “Operation
instructions”. While selecting the temperature setting, put the
temperature control knob (10) into the “Max” position.
While holding the iron in a vertical position, aim its sole plate
towards the articles to be ironed and push the steam burst
button (8) to produce a directional strong burst of steam from
the sole plate. Push the button several times with 5-7 seconds
intervals until the article is fully refreshed. If during the process
your water tank (5) runs out of water, disconnect the appliance
from the mains outlet, wait till it cools down, refill the tank and
plug the appliance back into the power supply and continue the
process.
Spray
Using the water spray (7) will help when ironing details of the
article (cuffs, trimmings, plackets, etc) or clothes, which demand
“·” (low temperature) ironing, when steam ironing is not possible.
Push the button several times to moisten the material.
5. When you have finished cleaning or ironing, do not forget to
switch the iron off by putting the steam control knob (9) into
the “0” position, the temperature control knob (10) — into
the “Min” position and unplugging the appliance from the
mains supply outlet.
ENGLISH
CARE AND MAINTENANCE
Cleaning of the sole plate
The scale on the sole plate can be removed
with a rough cotton cloth dampened with a
vinegar solution.
Do not use any abrasive substances and
materials to clean the sole plate.
Cleaning of internal parts of the appliance
SI-2610 iron is equipped with an anti-scale function which
protects it from an accumulation of scale: it does this with a built-in
permanent filter. Therefore the water hardness is reduced and
the useful service life of the iron is extended.
Warning: in areas with very hard water it is recommended
that you regularly remove scale from the appliance to
7
maintain it in good working order. Excess lime scale
may result in damage or malfunction of your product.
If in your area the water is soft and you have average amounts
of clothes to be ironed then we recommend you to de-scale every
6 months. If you use SI-2600 iron and if the water in your area
is very hard or if you iron frequently, then we recommend you
de-scale once a month.
Your iron has a self-cleaning function, which allows you to
clean the internal parts of the appliance from scale or dust. To use
this function perform the following procedure:
1. Set the steam control knob (9) into the “0” position.
2. Fill the tank (5) with water to the “Max” level.
3. Place the iron in a vertical position and plug it into the mains supply
outlet.
4. Set the temperature control knob (10) into the “Max” position. The light indicator (11) will light up showing that the iron
is being heated to the desired temperature.
5. When the iron reaches the maximum temperature, the light
indicator (11) will go out.
6. Whilst holding the appliance horizontally over a sink, set the steam
control knob (9) into the “Self-Clean” position. Hot steam
will discharge from the sole plate (12) removing the scale and
dust. If the blast of steam becomes weaker, set the control
knob (9) into the “0” position and wait for 12-15 seconds until
the iron gets hot again. Then once again set the control knob
into the “Self-clean” position.
7. When the water tank (5) is completely empty, set the steam control
knob (9) into the “0” position.
8. Put the appliance into a vertical position and re-heat the iron.
9. To complete the cleaning process; Iron a piece of a clean old cotton
cloth in order to clean the sole plate (12) of any remaining dust
and scale and to evaporate the remaining water. When you have
finished ironing, always switch the appliance off and disconnect
from the electrical supply.
Storage
Before storing the iron, make sure it is disconnected from the mains
supply outlet and is completely cooled down. Set the temperature
control knob into the “Min” position and the steam control knob
into the “0” position. Drain the remaining water from the tank (5)
by opening the cover (4) and holding the iron upside down over
the sink. Store the appliance in the upright standing position.
8
USEFUL TIPS
Selection of temperature settings
Before ironing, we recommend that you orga-
nize your clothes, into the types of material
and the recommended temperature settings.
We recommend that you start ironing, using
the lower temperature settings first: the appliance gets hot quicker than it cools down.
When ironing articles made with combinations of fibers, start
with the temperature recommended for the most delicate material first (for example, to iron a cloth made of cotton and
polyester select the temperature recommended for ironing
polyester first).
If the manufacturer’s label, which gives the recommended
temperature, is missed and the type of material is known, follow the recommendations below.
ENGLISH
If you do not know the fabric type, find a place on the article;
which will not be seen and test iron it to select the appropriate
temperature, start with the minimum setting.
Ironing of selected fabrics
Do not use the water spray button (7) while ironing silk ar-
ticles: drops of water leave spots on silk garments.
Wool, velour, velvet and similar pile fabrics must be ironed on
the inside.
To prevent shiny marks we recommend that you iron woolen
articles through a thin cotton cloth, set the steam control knob
into the maximum position.
9
DISPOSAL
The appliance should be disposed of in accordance
with waste disposal regulations in your country
and with the least damage to the environment.
Only ecologically safe materials are used in the
packaging of our products and the cardboard and
paper can be disposed of with normal paper waste.
AFTER-SALES SERVICE
If your appliance does not operate at all
or operates poorly, call an authorized service
center for help or repairs.
The warranty does not cover the
following:
sures and operation instructions.
Commercial use (use outside the scope of personal household
needs).
Plugging into a mains socket with a voltage different from the
voltage on the appliance rating plate.
Improper care (ingress of liquid, dust, insects, and other for-
eign items and substances inside the appliance).
Use of excessive force during appliance operation or other
damages (mechanical damages resulting from incorrect use,
shocks or dropping of the appliance).
Unauthorized repairs or replacement of the appliance parts
performed by an unauthorized person or service center.
Scale deposit on the appliance regardless of the use of water.
Accidents, such as lightning strike, flood, fire and other acts of
God.
Non-observance of the above safety mea-
10
ENGLISH
Features may be changed by Binatone without any notice.
Warranty details are set out in the warranty card provided with
the product.
Exploitation period: 3 years after the day of purchase.
Manufacture: Binatone Industries Ltd, Great Britain, Vitabiotics
House,1 Apsley Way, Staples Corner, London, NW2 7HF, UK.
11
Le fer à la vapeur SI-2600, SI-2610
Lisez attentivement cette instruction avant le premier usage
pour prendre connaissance du fonctionnement de l’appareil.
Gardez l’instruction pour s’y référer ultérieurement.
MESURES DE SECURITE
En exploitant l’appareil, respectez toujours les
mesures de sécurité suivantes:
Avant le premier usage, assurez-vous que la
tension indiquée sur l’appareil correspond à la
tension du réseau électrique dans votre maison.
Utilisez l’appareil seulement à des fins indiquées
Utilisez seulement les dispositifs qui font partie de la garniture
de l’appareil.
Pour éviter un choc électrique, ne pas plonger l’appareil,
la fiche ou le câble dans l’eau ou dans un autre liquide.
Installez l’appareil dans un endroit où il ne peut pas tomber
dans l’eau ou dans un autre liquide. Si l’appareil a été
accidentellement mouillé, débranchez-le du réseau
immédiatement. N’utilisez pas l’appareil qui est tombé dans
l’eau. Portez-le dans un centre de maintien.
Ne pas laisser les enfants manier l’appareil sans contrôle des
adultes.
Si la fiche mâle de l’appareil ne coïncide pas avec votre
prise selon sa structure, consultez auprès de l’expert.
L’utilisation de différents raccords peut conduire à une
panne de l’appareil et la cessation des garanties.
Ne pas laisser l’appareil branché sur le réseau sans surveil-
lance.
Pour éviter la surcharge du réseau électrique, ne pas brancher
un autre appareil de haute puissance au même réseau que
votre appareil.
Déconnectez l’appareil du réseau avant le déplace-
ment d’un endroit à l’autre et avant le nettoyage et
la conservation.
Ne tirez jamais sur le câble pour déconnecter l’appareil du
réseau; prenez la fiche et faites-la sortir de la prise de courant.
Eviter le contact du câble ou de l’appareil avec des surfaces
chauffées.
Placer l’appareil et le câble de façon à éviter le basculement
accidentel.
Ne pas utiliser l’appareil si le câble ou la fiche de contact est
endommagé. N’essayez pas de réparer l’appareil vous-même.
Le remplacement du câble électrique et de la fiche de contact
doit être effectué par un centre de maintien agréé.
Ne démontez jamais l’appareil vous-même; l’assemblage in-
correct peur résulter en choc électrique pendant l’usage ultérieur
de l’appareil. Tous les travaux de réparation doivent être
effectués seulement par un centre de service agréé.
Ne pas utiliser l’appareil dans des locaux où l’air peut contenir
des mélanges des gaz combustibles, des vapeurs des liquides
inflammables, ou des poussières et fibres inflammables.
dans cette instruction.
12
Loading...
