Billion BiPAC 7404VGOX, BiPAC 7404VGPX, BiPAC 7404VOX, BiPAC 7404VPX Quick Start Guide

BiPAC 7404V(G)OX
BiPAC 7404V(G)PX
3G/ VoIP/ (802.11g) ADSL2+
(VPN) Firewall Router
Quick Start Guide
Quick Start Guide
Billion BiPAC 7404V(G)OX/ 7404V(G)PX 3G/ VoIP/ (802.11g) ADSL2+ (VPN) Firewall Router
PLEASE READ THE QUICK START GUIDE AND FOLLOW THE
Do not use the
router
in high humidity or high temperatures.
 Avoid using this
product
and all
accessories
outdoors.
Place the router on a stable surface.
STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON CD-ROM.
Package Contents
BiPAC 7404V(G)OX/7404V(G)PX ADSL2+ Router
CD containing the on-line manual
RJ-11 ADSL/telephone cable
Ethernet (RJ-45) cable
One 2dBi detachable antenna (Wireless Router only)
Power adapter
RJ-45 to RS-232 Console Kit
This Quick Start Guide
Splitter/ Micro-filter (Optional)
  Do not use the same power source for the router as other
equipment.
Do not open or repair the case yourself. If the router is too hot,
turn off the power immediately and have it repaired at a qualified service center.
Warning
  Only use the power adapter that comes with the package. Using a
different voltage rating power adaptor may damage the router.
Attention
-1-
Quick Start Guide
Connect the
Connect the supplied
Press it to reset
Connect your
Connect the
Lit when power is ON
Connect RJ
-
11 cable
Connect RJ
-
11 cable
Lit when connected to an
Lit gre
en
Lit Green when
Lit green when the
Lit
green when the
Power
switch
Lit red when WAN port fails to
Lit
when successfully
Lit when the SIP
Orange for Phone 2
Push WPS button to
3G/ HSDPA USB
Hardware Overview
The Front LEDs
USB device is ready. Flashes when sending/ receiving
data.
Registration is OK. Green for Phone 1;
successfully connected to an ADSL DSLAM, (“line sync”).
Ethernet device. Green for 100Mbps; Orange for 10Mbps. Blinking when data is Transmitted / Received
wireless connection is established. Flashes when sending / receiving data
when the phone is off-hook
connected to PSTN.
The Rear Ports
detachable antenna
to this port when connecting to the telephone wall jack
computer to a LAN port, using the included Ethernet cable
the device or restore to factory default settings
get IP address. Lit green when WAN port gets IP address successfully. Lit off when device in bridged mode or WAN connection not present.
supplied power adapter to this jack
RJ-11 cable to this port when connecting to the ADSL/telephone network
-2-
modem backup for Internet access
to this port when connecting to an analog phone set
trigger Wi-Fi Protected Setup
ON/OFF
Billion BiPAC 7404V(G)OX/ 7404V(G)PX 3G/ VoIP/ (802.11g) ADSL2+ (VPN) Firewall Router
Plug the supplied power adapter to the wall jack and the other side to the router.
Hardware Connection
Hardware Installation
1. Power Connection
Please note that the plug type may differ according to different countries.
2. LAN Connection
Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other side to the PC’s Ethernet interface.
-3-
Quick Start Guide
3. USB Connection
The USB 2.0 port supports 3G/ HSDPA modem connectivity: users can conveniently access Internet via 3G, eliminating the limitations of the wired network. This solution also employs an auto fail-over feature to ensure always-on connectivity for SOHO users.
4. Phone Connection
Connect RJ-11 cable to the router’s “phone 1” or “phone 2” when connecting to an analog phone set. Both ports (“Phone 1” and “Phone 2”) can make VoIP calls simultaneously. But only one phone is allowed to make PSTN call at the same
.
time
5. Line Connection
a) Connect RJ-11 cable to the router Line port and the splitter phone port.
b) Connect RJ-11 cable to the router DSL port and the splitter ADSL port.
c) Connect RJ-11 cable to the splitter Line port and the phone jack on the wall.
-4-
Billion BiPAC 7404V(G)OX/ 7404V(G)PX 3G/ VoIP/ (802.11g) ADSL2+ (VPN) Firewall Router
6. Splitter/ Micro-filter Connection
The Splitter / Micro-filter are important for ADSL installation, they help direct high-frequency signals to the ADSL modem & low frequency signals to the telephone or other analogue device to prevent inter-modulation distortion & get good speed/stable ADSL sync rate.
a) Splitter connection
If the installation has only a single telephone and a single ADSL modem, then a splitter can be employed.
b) Micro-filter connection
If the installation has several telephones or other analog devices, then an internal micro-filter can be employed at each analog device.
Setup Utility
After you complete the hardware installation insert CD into the CD Drive to run the setup utility. The setup utility will auto-run. Follow the step-by-step configuration wizard & it will guide you to setting up the basic network configuration.
Connecting to the Router
1. Open the web browser and type http://192.168.1.254 in the browser's address box. This number is the default IP address for this router. Press Enter.
2. A username and password window will appear. The default username and password are admin and admin. Press OK to proceed.
-5-
Quick Start Guide
3. You will get a status report web page and main menu screen.
Please see the relevant sections of user manual for detailed instructions on how to configure your router.
Troubleshooting
1. None of the LEDs are on when you turn on the router.
Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. In this case you should contact technical support.
2. You have forgotten your router login and/or password.
Try the default login and password, please refer user manual. If this fails, you can restore your router to its factory settings by holding the Reset button on the back of your router for 6 seconds or more.
3. Can’t ping any PCs on the LAN.
Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC connected. If it is off, check the cables between your router and the PC. Make sure you have uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet mask are consistent between the router and the workstations.
4. Frequent loss of ADSL linesync (disconnections).
Ensure that all other devices connected to the same telephone line as your router (e.g. telephones, fax machines, analogue modems) have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure that all line filters are correctly installed and the right way around. Missing line filters or line filters installed the wrong way around can cause problems with your ADSL connection, including causing frequent disconnections. If you have a back-to-base alarm system you should contact your security provider for a technician to make any necessary changes.
Product Support and Contact Information
Most problems can be solved by referring to the Troubleshooting section in the User Manual. If you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer where you purchased this product.
Contact Billion
WORLDWIDE
http://www.billion.com
Billion Product Registration
Billion is committed to before and after sales customer services. You will get the most out of your Billion's products after registration. Please register online at from us.
http://www.billion.com/register to receive valuable services and support
-6-
BiPAC 7404V(G)OX/V(G)PX:V1.00EN
