802.11g ADSL VPN Firewall Router
BIPAC 7402G
Quick Start Guide
Billion BIPAC 7402G 802.11g ADSL VPN Firewall Router
A
Quick Start Guide
For more detailed instructions on configuring and using
the 802.11g ADSL VPN Firewall Router, please refer to
the on-line manual.
Package Contents
BIPAC 7402G 802.11g ADSL VPN Firewall Router
CD-ROM containing the on-line manual
RJ-11 ADSL/telephone Cable
Ethernet (CAT-5 LAN) Cable
Console (PS2-RS232) Cable
AC-DC power adapter (12VDC, 1A)
External Antenna
This Quick Start Guide
Warning
ttention
9 DO NOT use the BIPAC 7402G in high humidity or high
temperatures.
9 DO NOT use the same power source for the BIPAC 7402G as
other equipment.
9 DO NOT open or repair the case yourself. If the BIPAC
7402G is too hot, turn off the power immediately and have it
repaired at a qualified service center.
9 Avoid using this product and all accessories outdoors.
9 Place the BIPAC 7402G on a stable surface.
9 Only use the power adapter that comes with the package.
Using a different voltage rating power adaptor may damage
the router.
The Front LEDs
PWR
SYS
LED Meaning
PPP / MAIL
ADSL
LAN Port
1X — 4X
(RJ-45
connector)
WLAN
SYS Lit when the system is ready.
PWR Lit when power is ON.
Lit steady when there is a PPPoA / PPPoE connection.
Lit and flashed periodically when there is email in the Inbox.
When lit, it indicates that the ADSL (Line) port is connected to the DSLAM and
working properly.
Lit when the LAN link is connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps.
Blinking when data is Transmitted / Received.
Lit green when the wireless connection is established.
Flashes when sending/receiving data.
LAN
123
4
PPP/MAIL ADSL WLAN
1
2
Billion BIPAC 7402G 802.11g ADSL VPN Firewall Router
Quick Start Guide
The Rear Ports
Port Meaning
Power Switch
1
PWR
2
3 RESET
LAN
4
1X — 4X
(RJ-45 connector)
CONSOLE
5
LINE
6
6
4
3
1
5
2
Power ON/OFF switch
Connect the supplied power adapter to this jack.
After the device is powered on, press it to reset the device or
restore to factory default settings.
0-3 seconds: reset the device
6 seconds above: restore to factory default settings (this is used
when you can not login to the router, e.g. forgot the password)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the
four LAN ports when connecting to a PC or an office/home
network of 10Mbps or 100Mbps.
Connect a PS2/RS-232 cable to this port when connecting to a
PC’s RS-232 port (9-pin serial port).
Connect the supplied RJ-11 (“telephone”) cable to this port when
connecting to the ADSL/telephone network.
Connecting Your ADSL Router
1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network.
2. Power on the device.
3. Make sure the PWR, SYS, and WLAN LEDs are lit steadily and that the relevant LAN LED
is lit.
SYS
PWR
LAN
4
3
21
ADSL WLAN
PPP/MAIL
3
4
Billion BIPAC 7402G 802.11g ADSL VPN Firewall Router
Quick Start Guide
Configuring PC in Windows XP
1. Go to Start / Control Panel (in Classic
View). In the Control Panel, double-click on
Network Connections
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window, click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
Configuring PC in Windows 2000
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
Dial-up Connections.
2. Double-click Local Area Connection.
3. In the Local Area Connection Status window
click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
5
6
Billion BIPAC 7402G 802.11g ADSL VPN Firewall Router
Quick Start Guide
Configuring PC in Windows 98/Me
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
choose the Configuration tab.
2. Select TCP/IP ->
NE2000 Compatible, or the name of your
Network Interface Card (NIC) in your PC.
3. Select the Obtain an IP address
automatically radio button.
4. Then select the DNS Configuration tab.
5. Select the Disable DNS radio button and click
OK to finish the configuration.
Configuring PC in Windows NT4.0
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
choose the Protocols tab.
2. Select TCP/IP Protocol and click Properties.
3. Select the Obtain an IP address from a
DHCP server radio button and click OK.
7
8
Billion BIPAC 7402G 802.11g ADSL VPN Firewall Router
/
Configuring Your ADSL VPN Firewall Router
Quick Start Guide
Verifying Your Local Network Connection with the Device
To configure this device, you must have IE 5.0
Netscape 4.5 or above installed
Connecting to the Router
1. Open the web browser and type
http://192.168.1.254
address box. This number is the default IP
address for this router. Press Enter.
2. A user name and password window will
appear. The default U
assword are “admin” and” admin”.
P
Press OK to logon to the router.
in the browser’s
ser Name and
To see if this ADSL Router is
visible on the local network, go
to Start / Run. In the Run dialog
box, type “ping 192.168.1.254”
then press OK.
A command prompt window will
pop out. If your ping is
successful which means your
local network is able to reach to
the device, then the command
prompt window will close up
automatically.
Connection fails, when you see
“Request timed out” in the
command prompt window. You
may need to check your set up.
9
10
Billion BIPAC 7402G 802.11g ADSL VPN Firewall Router
Product Support and Contact Information
Most problems can be solved by referring to the Troubleshooting section in the User’s
Manual. If you cannot resolve the problem with the Troubleshooting chapter, please contact
the dealer where you purchased this product.
Contact Billion
WORLDWIDE
http://www.billion.com
Mac OS is a registered Trademark of Apple Computer, Inc.
Windows 98, Windows NT, Windows 2000, Windows Me and Windows XP are registered Trademarks of Microsoft
Corporation.
