BiPAC 6404VGP R3
VoIP/ 802.11g Broadband
Firewall Router
Quick Start Guide
Quick Start Guide
Billion BiPAC 6404VGP R3 VoIP/ 802.11g Broadband Firewall Router
PLEASE READ THE QUICK START GUIDE AND FOLLOW THE
Do not use the
router
in high humidity or high temperatures.
Avoid using this
product
and all
accessories
outdoors.
Place the router on a stable surface.
STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU
INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.
IF YOU NEED MORE INFORMATION ON THIS SOFTWARE
CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON
CD-ROM.
Package Contents
BiPAC 6404VGP R3 Broadband Router
CD containing the on-line manual
Ethernet (RJ-45) cable
One 2dBi detachable antenna
Power adapter
RJ-45 to RS-232 Console Kit
This Quick Start Guide
Do not use the same power source for the router as other
equipment.
Do not open or repair the case yourself. If the router is too hot,
turn off the power immediately and have it repaired at a qualified
service center.
Warning
Only use the power adapter that comes with the package. Using a
different voltage rating power adaptor may damage the router.
Attention
-1-
Quick Start Guide
Lit green wh
en IP connected.
Lit when the SIP
Co
nnect the
Connect RJ
-
11 cable
Press it to reset
Connect your
Connect the
Lit orange
when
Connect RJ
-
11 cable
Lit when connected to an
Lit green
Lit green when the
Power
WAN 10/100M Ethernet
modem here.
Push WPS button to
Hardware Overview
The Front LEDs
power is ON,
Lit green when the
system is ready.
Lit red means system
failure
Ethernet device.
Green for 100Mbps;
Orange for 10Mbps.
Blinking when data is
Transmitted / Received
Registration is OK.
Lit green whenever
phone 1 is off hook
but will lit orange for
phone 2
Lit green or orange
when connected to a
modem or Cable
modem's Ethernet port
well.
wireless connection is
established.
Flashes when sending /
receiving data.
when the
phone is
off-hook
Lit green when the
inbound and outbound
calls are transmitted
through PSTN.
Flashes green when IP connected
and IP traffic is passing through
the device. Lit red when device
attempted to become IP
connected and failed. Lit off when
device in bridged mode or when
connection WAN is absent.
The Rear Ports
detachable antenna
computer to a
LAN port, using
the included
Ethernet cable
the device or
restore to factory
default settings
to this port when
connecting to the
telephone wall jack
to this port when
connecting to an
analog phone set
port (with auto
crossover support);
connect xDSL/ Cable
supplied power
trigger Wi-Fi Protected
Setup
adapter to this jack
ON/OFF
-2-
Billion BiPAC 6404VGP R3 VoIP/ 802.11g Broadband Firewall Router
to the router.
Hardware Connection
Hardware Installation
1. Power Connection
Plug the supplied power adapter to the wall jack and the other side
Please note that the plug type may differ according to different countries.
-3-
Quick Start Guide
2. LAN Connection
Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the
other side to the PC’s Ethernet interface.
3. Phone Connection
Connect RJ-11 cable to the router’s “phone 1” or “phone 2” when connecting to an
analog phone set. Both ports (“Phone 1” and “Phone 2”) can make VoIP calls
simultaneously. But only one phone is allowed to make PSTN call at the same
time.
4. Line Connection
A) Connect RJ-11 cable to the router Line port and the splitter Phone port.
B) Connect RJ-11 cable to the splitter Line port and the telephone wall jack.
C) Connect Modem to the router with an RJ-45 cable while connect Modem to
splitter with RJ-11 cable.
-4-
Billion BiPAC 6404VGP R3 VoIP/ 802.11g Broadband Firewall Router
BiPAC 6404V
GP
R3 V1.00EN
Connecting to the Router
1. Open the web browser and type http://192.168.1.254 in the browser's address box. This
number is the default IP address for this router. Press Enter.
2. A username and password window will appear. The default username and password are
admin and admin. Press OK to proceed.
3. You will get a status report web page and main menu screen.
Please see the relevant sections of user manual for detailed instructions on how to
configure your router.
Troubleshooting
1. None of the LEDs are on when you turn on the router.
Check the connection between the adapter and the router. If the error persists, you may have
a hardware problem. In this case you should contact technical support.
2. You have forgotten your router login and/or password.
Try the default login and password, please refer User Manual. If this fails, you can restore
your router to its factory settings by holding the Reset button on the back of your router for 6
seconds or more.
3. Can’t ping any PCs on the LAN.
Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC
connected. If it is off, check the cables between your router and the PC. Make sure you have
uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet
mask are consistent between the router and the workstations.
Product Support and Contact Information
Most problems can be solved by referring to the Troubleshooting section in the User Manual. If
you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer
where you purchased this product.
Contact Billion
WORLDWIDE
http://www.billion.com
Billion Product Registration
Billion is committed to before and after sales customer services. You will get the most out of your Billion's products
after registration. Please register online at http://www.billion.com/register to receive valuable services and support
from us.
-5-
