Benq W600PLUS User Manual

W600+
Digital Projector
User Manual

Welcome

English

Table of contents

Important safety

instructions .......................3

Introduction......................7

Projector features .................................7

Shipping contents.................................8

Projector exterior view.........................9

Controls and functions.......................10

Positioning your projector .14

Choosing a location............................14

Obtaining a preferred projected image

size .....................................................15

Connection......................18

Connecting a computer ......................18

Connecting Video source devices......19

Connecting HDMI source devices..... 20

Operation........................24

Starting up the projector.....................24

Using the menus.................................25

Securing the projector........................25

Utilizing the password function......... 26

Switching input signal........................29

Adjusting the projected image ...........30

Magnifying and searching for details.32

Playing 3D function...........................32

Selecting the aspect ratio ...................32

Optimizing the image.........................34

Setting the presentation timer ............38

Hiding the image................................39

Locking control keys..........................39

Freezing the image.............................40

Utilizing FAQ function......................40

Operating in a high altitude environment..40

Adjusting the sound........................... 41

Personalizing the projector menu display. 42

Shutting down the projector .............. 42

Menu operation.................................. 43

Maintenance ...................51

Care of the projector.......................... 51

Lamp information.............................. 52

Troubleshooting .............58

Specifications..................59

Projector specifications...................... 59

Dimensions........................................ 60

Timing chart ...................................... 61

Warranty and Copyright

information.....................66

Regulation statements....67

Table of contents2

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you
follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

1. Please read this manual before you
operate your projector. Save it for

future reference.

2. Do not look straight at the projector
lens during operation. The intense
light beam may damage your eyes.

4. Always open the lens shutter or

remove the lens cap when the
projector lamp is on.

5. In some countries, the line voltage is
NOT stable. This projector is
designed to operate safely within a
mains voltage between 100 to 240
volts AC, but could fail if power cuts
or surges of 10 volts occur. In areas

where the mains voltage may
fluctuate or cut out, it is
recommended that you connect
your projector through a power
stabilizer, surge protector or
uninterruptible power supply
(UPS).

English

3. Refer servicing to qualified service
personnel.

6. Do not block the projection lens with
any objects when the projector is
under operation as this could cause
the objects to become heated and
deformed or even cause a fire. To
temporarily turn off the lamp, press
BLANK on the projector or remote
control.

Important safety instructions 3

English

Safety Instructions (Continued)

7. The lamp becomes extremely hot
during operation. Allow the
projector to cool for approximately
45 minutes prior to removing the
lamp assembly for replacement.

10. Do not place this product on an
unstable cart, stand, or table. The
product may fall, sustaining serious
damage.

8. Do not operate lamps beyond the
rated lamp life. Excessive operation
of lamps beyond the rated life could
cause them to break on rare
occasions.

9. Never replace the lamp assembly or
any electronic components unless
the projector is unplugged.

11. Do not attempt to disassemble this
projector. There are dangerous high
voltages inside which may cause
death if you should come into
contact with live parts. The only
user serviceable part is the lamp
which has its own removable cover.

Under no circumstances should you
ever undo or remove any other
covers. Refer servicing only to
suitably qualified professional
service personnel.

12. When the projector is under
operation, you may sense some
heated air and odor from its
ventilation grill. It is a normal
phenomenon and not a product
defect.

Important safety instructions4

3000 m

(10000 feet)

0 m

(0 feet)

Safety Instructions (Continued)

13. Do not place this projector in any of
the following environments.

- Space that is poorly ventilated or
confined. Allow at least 50 cm clearance
from walls and free flow of air around the
projector.

- Locations where temperatures may
become excessively high, such as the
inside of a car with all windows rolled up.

- Locations where excessive humidity,
dust, or cigarette smoke may contaminate
optical components, shortening the
projector's life span and darkening the
image.

- Locations near fire alarms

- Locations with an ambient temperature
above 35°C / 95°F

- Locations where the altitudes are higher
than 3000 m (10000 feet).

14. Do not block the ventilation holes.

- Do not place this projector on a blanket,
bedding or any other soft surface.

- Do not cover this projector with a cloth or
any other item.

- Do not place inflammables near the
projector.

If the ventilation holes are seriously
obstructed, overheating inside the
projector may result in a fire.

15. Always place the projector on a level,
horizontal surface during operation.

- Do not use if tilted at an angle of more
than 10 degrees left to right, nor at angle
of more than 15 degrees front to back.
Using the projector when it is not fully
horizontal may cause a malfunction of, or
damage to, the lamp.

English

16. Do not stand the projector on end
vertically. Doing so may cause the
projector to fall over, causing injury or
resulting in damage to the projector.

Important safety instructions 5

English

Safety Instructions (Continued)

17. Do not step on the projector or place
any objects upon it. Besides probable
physical damage to the projector,
doing so may result in accidents and
possible injury.

18. Do not place liquids near or on the
projector. Liquids spilled into the
projector may cause it to fail. If the
projector does become wet, disconnect
it from the power supply's wall socket
and call BenQ to have the projector
serviced.

19. This product is capable of displaying
inverted images for ceiling mount
installation.

Use only BenQ's Ceiling Mount Kit for
mounting the projector and ensure it
is securely installed.

Ceiling mounting the projector

We want you to have a pleasant
experience using your BenQ projector ,
so we need to bring this safety matter
to your attention to prevent possible
damage to person and property.
If you intend to mount your projector
on the ceiling, we strongly recommend
that you use a proper fitting BenQ
projector ceiling mount kit and that
you ensure it is securely and safely
installed.
If you use a non-BenQ brand projector
ceiling mount kit, there is a safety risk
that the projector may fall from the
ceiling due to an improper attachment
through the use of the wrong gauge or
length screws.
You can purchase a BenQ projector
ceiling mount kit from the place you
purchased your BenQ projector. BenQ
recommends that you also purchase a
separate Kensington lock compatible
security cable and attach it securely to
both the Kensington lock slot on the
projector and the base of the ceiling
mount bracket. This will perform the
secondary role of restraining the
projector should its attachment to the
mounting bracket become loose.

Important safety instructions6

Introduction

Projector features

The projector integrates high-performance optical engine projection and a user-friendly
design to deliver high reliability and ease of use.

The projector offers the following features.

• Dual HDMI (v1.3) inputs

• Filter free design to lower maintenance and operating costs

• Auto keystone function to correct image keystoning automatically

• Brilliant color / UNISHAPE to provide truer, more vibrant colors in picture

• Closed captioning to display the dialogue, narration, and sound effects of TV programs
and videos

• Variable audio output

• Wall color correction allowing projection on surfaces of several predefined colors

• Quick auto search speeding up the signal detecting process

• Selectable password protected function

• 3D color management allowing color adjustments to your liking

• Selectable quick cooling function making the projector cool in a shorter time

• FAQ to troubleshoot operational problems with one quick key press

• High quality manual zoom lens

• One-key auto-adjustment to display the best picture quality

• Adjustable color balance control for data/video display

• Ability to display 16.7 million colors

• Multi-language On-screen Display (OSD) menus

• S witchable normal and economic modes to reduce the power consumption

• Built-in speaker providing mixed mono audio when an audio input is connected

• Component HDTV compatibility (YPbPr)

• HDCP compatibility

• 3D ready function for enjoying the 3D content.

English

• The apparent brightness of the projected image will vary depending on the ambient
lighting conditions, selected input signal contrast/brightness settings, and is directly
proportional to projection distance.

• The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.

Introduction 7

English

(UK) (US)

(EU)

(AU)

(KOREA) (CHINA)

(JAPAN)

P/N: 4J.J4E01.001

W600+
Video Projector

de

2010

Shipping contents

Carefully unpack and verify that you have all of the items shown below. If any of these
items are missing, please contact your place of purchase.

Standard accessories

The supplied accessories will be suitable for your region, and may differ from those
illustrated.

Projector Remote control with battery

Power cord VGA cable

Quick Start Gui

Quick start guide User manual CD

Warranty card*

Optional accessories

1. Spare lamp kit

2. Ceiling mount kit

*The warranty card is only supplied in some specific regions. Please consult your dealer for
detailed information.

Introduction8

3. Presentation Plus

4. Soft Carry Case

5. RS232 Cable

Projector exterior view

Front/upper side

4

3

5

7

1

6

2

Rear/lower side

12 13 14 15 16

171920212223

8 9

10 11

1824

English

1. Front IR remote sensor

2. Quick-release button

3. Projection lens

4. External control panel
(See "Projector" on page 10 for
details.)

5. Vent (cool air intake)

6. Audio speaker

7. Focus ring and Zoom ring

8. S-VIDEO input jack

9. VIDEO input jack

10. AUDIO input jack (L)

11. COMPONENT input jacks

12. AUDIO input jack (R)

13. COMPUTER PC input sjack

14. HDMI 1 input jack

15. HDMI 2 input jack

16. IR receiver

17. Rear adjuster foot

18. Kensington anti-theft lock slot

19. AUDIO output jack

20. Quick-release foot

21. AUDIO input jack

22. RS-232 control port

23. USB input jack

24. AC power cord inlet

Introduction 9

English

POWER TEMP LAMP

9

1
2
3

4

7

5
6

10

8

11
12

13

14

Controls and functions

Projector

1. POWER indicator light

Lights up or flashes when the projector is
under operation. See "Indicators" on page

57 for details.

2. MENU/EXIT

Turns on the On-Screen Display (OSD ) m enu.
Goes back to previous OSD menu, exits and
saves menu settings.

See "Using the menus" on page 25 for details.

3. Left/

Starts the FAQ function. See "Utilizing

FAQ function" on page 40 for details.

4. POWER

Toggles the projector between standby
mode and on.

See "Starting up the projector" on page 24
and "Shutting down the projector" on page

42 for details.

5. MODE/ENTER

Selects an available picture setup mode.
See "Selecting a picture mode" on page 34
for details.
Enacts the selected On-Screen Display
(OSD) menu item. See "Using the menus"

on page 25 for details.

6. BLANK

sed to hide the screen picture. See

U

"Hiding the image" on page 39 for details.

7. Keystone/Arrow keys ( / Down)

Manually corrects distorted ima ges resulting
from an angled projection. See "Correcting

keystone" on page 31 for details.

8. FOCUS/ZOOM Ring

Used to adjust the projected image
appearance. See "" on page 30 for details.

9. TEMPerature indicator light

Lights up red if the projector's
temperature becomes too high. See

"Indicators" on page 57 for details.

10. Keystone/Arrow keys ( / Up)

Manually corrects distorted ima ges resulting
from an angled projection. See "Correcting

keystone" on page 31 for details.

11. LAMP indicator light

Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem. See "Indicators" on page 57 for
details.

12. AUTO

Automatically determines the best picture
timings for the displayed image. See "Auto-

adjusting the image" on page 30 for details.

13. Right/

Activates panel key lock. See "Locking

control keys" on page 39 for details.

When the On-Screen Display (OSD)
menu is activated, the #3, #7, #10, and

#13 keys are used as directional arrows to
select the desired menu items and to make
adjustments. See "Using the menus" on

page 25 for details.

14. SOURCE

Displays the source selection bar. See

"Switching input signal" on page 29 for

details.

Introduction10

Remote control

7
8

13

20

21
22

24

27

17

2

3

4

5
6

9

1

16

18

12

26

19

10

11

23

25

15

14

29

28

English

7. Up cursor/Keystone ( / )

: Navigates and changes settings in the

OSD. See "Using the menus" on

page 25 for details.

: Manually corrects distorted images

resulting from an angled projection.
See "Correcting keystone" on page

31 for details.

8. Left cursor/Information ( / )

: Navigates and changes settings in the

OSD. See "Using the menus" on

page 25 for details.

: Starts the INFORMATION function.

9. MODE/ ENTER

MODE: Choose a suitable preset mode

for usage environment.

ENTER: Enter key for OSD menu.

10. MENU/ EXIT

MENU: Turns on the On-Screen Display

(OSD) menu.

EXIT: Goes back to previous OSD menu,

exits and saves menu settings.

See "Using the menus" on page 25 for

1. IR transmitter

Transmits signal to projector.

2. LED indicator

Lights only when the key is pressed

3. POWER ON

Turns on the projector. See "Starting up

the projector" on page 24 for details.

4. VIDEO

Displays the VIDEO source sele ction. See

"Switching input signal" on page 29 for details.

5. COMP

Displays the COMPONENT source
selection. See "Switching input signal" on

page 29 for details.

6. HDMI 1

Displays the HDMI 1 source selection.
See "Switching input signal" on page 29
for details.

details.

11. USER 1/ User 2/ User 3

Select the User memory settings.

Note: User 3 not supported for this
model.

12. BRIGHT

Displays the BRIGHTNESS setting bar. See

"Adjusting

Brightness

" on page 35 for details.

13. MUTE

Mutes the built-in speaker.

14. VOLUME +/-

Adjusts volume. See "Adjusting the

sound level" on page 41 for details.

15. LIGHT

Turns on or off the remote control backlight

for about 10 seconds. Pressing any other
key while the backlight is on keeps the
backlight on for a further 10 seconds.

Introduction 11

English

A

p

p

ro

x.

±

1

5

°

A

p

p

r

o

x

.

±

1

5

°

16. POWER OFF

Turns off the projector. See "Shutting down

the projector" on page 42 for details.

17. S-VIDEO

Displays the S-VIDEO source selection. See

"Switching input signal" on page 29 for detail s.

18. PC

Displays the PC source selection. See

input signal" on page 29

"Switching

for details.

19. HDMI 2

Displays the HDMI 2 source selection. See

"Switching input signal" on page 29 for detail s.

20. Right cursor/Panel Key Lock ( / )

: Navigates and changes settings in the

OSD. See "Using the menus" on page

25 for details.

: Activates panel key lock. See "Locking

control keys" on page 39 for details.

21. Down cursor/Keystone ( / )

: Navigates and changes settings in the

OSD. See "Using the menus" on page

25 for details.

: Manually corrects distorted images

resulting from an angled projection.
See "Correcting keystone" on page

31 for details.

22. ASPECT

Select the display aspect ratios. See

"Selecting the aspect ratio" on page 32

for details.

23. CONTRAST

Displays the CONTRAST setting bar. See

"Adjusting Contrast" on page 35 for deta ils.

24. SHARP

Displays the SHARPNESS setting bar.
See "Adjusting Sharpness" on page 36 for
details.

25. TINT

Displays the TINT setting bar. See

"Adjusting Tint" on page 36 for details.

26. COLOR

Displays the COLOR setting bar. See

"Selecting a Color Temperature" on page
36 for details.

27. Blank

Hides the screen picture. See "Hiding the

image" on page 39 for details.

28. Freeze

Freeze/unfreezes the on-screen picture. See

"Freezing the image" on page 40 for details.

29. TEST

Displays the test pattern.

Remote control effective range

Infra-Red (IR) remote control sensor is located on
the front and the rear of the projector. The remote
control must be held at an angle within 30 degrees
perpendicular to the projector's IR remote control
sensor to function correctly . The distance between
the remote control and the sensor should not
exceed 7 meters (~ 23 feet).

Make sure that there are no obstacles between the
remote control and the IR sensor on the projector
that might obstruct the infra-red beam.

Introduction12

Replacing the remote control battery

1. Remove the battery compartment cover by
sliding the cover in the direction of the
arrow.

2. Insert the supplied batteries taking note of
the polarity (+/-) as shown here.

3. Replace the cover.

English

• Avoid excessive heat and humidity.

• There may be battery damage if the battery is incorrectly replaced.

• Replace only with the same or equivalent type recommended by the battery manufacturer.

• Dispose of the used battery according to the battery manufacturer’s instructions.

• Never throw a battery into a fire. There may be danger of an explosion.

• If the battery is dead or if you will not be using the remote control for a long time, remove
the battery to prevent damage to the remote control from possible battery leakage.

Introduction 13

English

SYSTEM SETUP: Basic

Presentation Timer

English

Language

Projector Position

Menu Settings
Auto Power Off

Panel Key Lock

Blank Timer

Sleep Timer

VIDEO

MENU

Exit

Front Table

Disable
Disable

Off

Disable

Splash Screen

BenQ

Positioning your projector

Choosing a location

Your room layout or personal preference will dictate which installation location you select.
Take into consideration the size and position of your screen, the location of a suitable power
outlet, as well as the location and distance between the projector and the rest of your
equipment.

Your projector is designed to be installed in one of four possible installation locations:

1. Front Table

Select this location with the projector placed on a table in
front of the screen. This is the most common way to
position the projector for quick setup and portability.

2. Front Ceiling

Select this location with the projector suspended upside­down from the ceiling in front of the screen.

Purchase the BenQ Projector Ceiling Mounting Kit from
your dealer to mount your projector on the ceiling.

Set Front Ceiling in the SYSTEM SETUP: Basic >

Projector Position menu after you turn the projector on.

3. Rear Table

Select this location with the projector placed on a table
behind the screen.

Note that a special rear projection screen is required.
Set Rear Table in the SYSTEM SETUP: Basic >

Projector Position menu after you turn the projector on.

4. Rear Ceiling

Select this location with the projector suspended upside­down from the ceiling behind the screen.

Note that a special rear projection screen and the BenQ
Projector Ceiling Mounting Kit are required for this
installation location.

Set Rear Ceiling in the SYSTEM SETUP: Basic >
Projector Position menu after you turn the projector on.

*To set the projector position:

Positioning your projector14

1. Press MENU/EXIT on the projector or remote control

and then press
Basic menu is highlighted.

2. Press

/ until the correct position is selected.

/ until the SYSTEM SETUP:

/ to highlight Projector Position and press

Obtaining a preferred projected image size

The distance from the projector lens to the screen, the zoom setting (if available), and the
video format each factors in the projected image size.

16:9 is the native aspect ratio. W600+ can project a complete 16:9 (widescreen) image.
The projector should always be placed horizontally level (like flat on a table), and

positioned directly perpendicular (90° right-angle square) to the horizontal center of the
screen. This prevents image distortion caused by angled projections (or projecting onto
angled surfaces).

The modern digital projector does not project directly forward (like older style reel-to-reel
film projectors did). Instead, digital projectors are designed to project at a slightly upward
angle above the horizontal plane of the projector. This is so that they can be readily placed
on a table and will project forward and upwards onto a screen positioned so that the bottom
edge of the screen is above the level of the table (and everyone in the room can see the
screen).

If the projector is mounted on a ceiling, it must be mounted upside-down so that it projects
at a slightly downward angle.

You can see from the diagram on page 17, that th is type of projection causes the bottom
edge of the projected image to be vertically offset from the horizontal plane of the projector .
When ceiling mounted, this refers to the top edge of the projected image.

If the projector is positioned further away from the screen, the projected image size
increases, and the vertical offset also increases proportionately.

When determining the position of the screen and projector, you will need to account for
both the projected image size and the vertical offset dimension, which are directly
proportional to the projection distance.

BenQ has provided a table of screen sizes to assist you in determining the ideal location for
your projector. Refer to "W600+ projection dimensions" on page 17. There are two
dimensions to consider, the perpendicular horizontal distance from the center of the screen
(projection distance), and the vertical offset height of the projec tor from the horizontal edge
of the screen (offset).

English

Positioning your projector 15

English

How to determine the position of the projector for a given screen size

1. Select your screen size.

2. Refer to the table and find the closest match to your screen size in the left columns

labelled "16:9 screen". Using this value, look across this row to the right to find the
corresponding average distance from screen value in the column labelled "Average".
This is the projection distance.

3. On that same row, look across to the right column and make note of the "Vertical

offset in mm" value. This will determine the final vertical offset placement of the

projector in relation to the edge of the screen.

4. The recommended position for the projector is aligned perpendicular to the horizontal

center of the screen, at the distance from the screen determined in step 2 above, and
offset by the value determined in step 3 above.

For example, if you are using a 120-inch screen, the average projection distance is 4358 mm
and with a vertical offset of 269 mm.

If you place the projector in a different position (to that recommended), you will have to tilt
it down or up to center the image on the screen. In these situations, some image distortion
will occur. Use the Keystone function to correct the distortion. See "Correcting keystone"

on page 31 for details.

How to determine the recommended screen size for a given distance

This method can be used for situations where you have purchased this projector and would
like to know what screen size will fit in your room.

The maximum screen size is limited by the physical space available in your room.

1. Measure the distance between the projector and where you want to position the

screen. This is the projection distance.

2. Refer to the table and find the closest match to your measurement in the average

distance from screen column labelled "Average". If the min and max values are
available on the table, check that your measured distance is between the min and max
distances listed on either side of the average distance value.

3. Using this value, look across that row to the left to find the corresponding screen

diagonal listed in that row. That is the projected image size of the projector at that
projection distance.

4. On that same row, look across to the right column and make note of the "Vertical

offset in mm" value. This will determine the final placement of the screen in relation

to the horizontal plane of the projector.

For example, if your measured projection distance was 3.5 m (3500 mm), the closest match
in the "Average" column is 3632 mm. Looking across this row shows that a 100-inch screen
is required.

Positioning your projector16

W600+ projection dimensions

Projection distance

Center of lens

Screen

Vertical offset

Maximum zoom

Minimum zoom

Refer to "Dimensions" on page 60 for the center of lens dimensions of this projector before
calculating the appropriate position.

English

16:9 screen

diagonal Width

Height

Inches mm mm mm

Recommended projection distance

from screen in mm

Min

length

(with max.

zoom)

Average

Max

length

(with min.

zoom)

Vertical

offset in mm

30 762 664 374 1009 1090 1170 67
40 1016 886 498 1345 1453 1560 90
50 1270 1107 623 1681 1816 1950 112
60 1524 1328 747 2018 2179 2340 134

80 2032 1771 996 2690 2905 3121 179
100 2540 2214 1245 3363 3632 3901 224
120 3048 2657 1494 4035 4358 4681 269
150 3810 3321 1868 5044 5448 5851 336
200 5080 4428 2491 6726 7263 7801 448
220 5588 4870 2740 7398 7990 8582 493
250 6350 5535 3113 8407 9079 9752 560
300 7620 6641 3736 10088 - - 672

There is 5% tolerance among these numbers due to optical component variations. BenQ
recommends that if you intend to permanently install the projector, you should physically test
the projection size and distance using the actual projector before you permanently install it,
so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installa tion location.

Positioning your projector 17

English

2

3

1

1. Audio cable

2. VGA cable

3. HDMI cable

Connection

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

In the connections shown below, some cables may not be included with the projector (see

"Shipping contents" on page 8). They are commercially available from electronics stores.

Connecting a computer

Connecting a computer

The projector provides a VGA input socket that allows you to connect it to both IBM®
compatibles and Macintosh
needed if you are connecting legacy version Macintosh computers.

To connect the projector to a notebook or desktop computer:

2. If you wish to make use of the projector (mixed mono) speaker in your presentations,

The final connection path should be like that shown in the following diagram:

® computers. A Mac adapter (an optional accessory) is

• With a VGA cable: • With a HDMI cable:

Your computer must be

equipped with a HDMI output
socket.

1. Take a VGA cable and connect one
end to the D-Sub output socket of
the computer. Connect the other end
of the VGA cable to the
COMPUTER PC signal input
socket on the projector.

1. Take a HDMI cable and connect one
end to the HDMI socket of the
computer. Connect the other end of
the cable to the HDMI 1 or 2 signal
input socket on the projector.

take a suitable audio cable and connect one end of the cable to the audio output socket
of the computer, and the other end to the AUDIO socket of the projector. Once
connected, the audio can be controlled by the projector On-Screen Display (OSD)
menus. See "Audio Settings" on page 45 for details.

Notebook or desktop computer

Many notebooks do
not turn on their
external video ports
when connected to a
projector. Usually a
key combo like FN + F3
or CRT/LCD key turns
the external display on/
off. Locate a function
key labeled CRT/LCD
or a function key with a
monitor symbol on the
notebook. Press FN
and the labeled
function key
simultaneously. Refer
to your notebook's
documentation to find
your notebook's key
combination.

Connection18

Connecting Video source devices

You can connect your projector to various V ideo source devices that provide any one of the
following output sockets:

• HDMI

• Component Video

•S-Video

• Video (composite)
You need only connect the projector to a Video source device using just one of the above

connecting methods, however each provides a different level of video quality. The method
you choose will most likely depend upon the availability of matching terminals on both the
projector and the Video source device as described below:

Best video quality

The best available video connection method is HDMI. If your source device is equipped
with a HDMI socket, you can enjoy uncompressed digital video quality.

See "Connecting HDMI source devices" on page 20 for how to connect the projector to a
HDMI source device and other details.

If no HDMI source is available, the next best video signal is Component Video (not to be
confused with composite Video). Digital TV tuners and DVD players output Component
Video natively, so if available on your devices, they should be your connection method of
choice in preference to S-Video or (composite) Video.

See "Connecting Component Video source devices" on page 21 for how to connect the
projector to a Component Video device.

Better video quality

The S-Video method provides a better quality analog video th an stand ard composite Video.
If you have both composite Video and S-Video output terminals on your Video source
device, you should elect to use the S-Video option.

Least video quality

Composite Video is an analog video and will result in a perfectly acceptable, but less than
optimal result from your projector, being the least video quality of the available methods
described here.

See "Connecting S-Video source devices" on page 22 for how to connect the projector to an
S-Video or Video device.

Connecting Audio

The projector has a built-in mono speaker which is designed to provide basic audio
functionality accompanying data presentations for business purposes only. They are not
designed for, nor intended for stereo audio reproduction use as might be expected in home
theater or home cinema applications. Any stereo audio input (if provided), is mixed into a
common mono audio output through the projector speakers.

English

Connection 19

English

HDMIHDMI

AV device

HDMI cable

Connecting HDMI source devices

The projector provides a HDMI input socket that allows you to connect it to a HDMI source
device like a DVD player, a DTV tuner or a display.

HDMI (High-Definition Multimedia Interface) supports uncompressed video data
transmission between compatible devices like DTV tuners, DVD players and displays over
a single cable. It provides pure digital viewing and listening experience.

Examine your Video source device to determine if it has a set of unused HDMI output
sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to an HDMI source device:

1. Take a HDMI cable and connect one end to the HDMI output socket of the HDMI
source device. Connect the other end of the cable to the HDMI 1 or 2 signal input
socket on the projector. Once connected, the audio can be controlled by the projector
On-Screen Display (OSD) menus. See "Audio Settings" on page 45 for details.

The final connection path should be like that shown in the following diagram:

• In the unlikely event that you connect the projector to a DVD player and the projected

picture displays wrong colors, please change the color space. See "Changing Color

Space" on page 29 for details.

• If no signal is detected after establishing the connection, turn off the Quick Auto Search

function in the SOURCE menu. See "Switching input signal" on page 29 for details.

Connection20

Connecting Component Video source devices

Component Video cable

AV device

Audio cable

Examine your Video source device to determine if it has a set of unused Component Video
output sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to a Component Video source device:

1. Take a Component Video cable and connect the end with 3 RCA type connectors to
the Component Video output sockets of the Video source device. Match the color of
the plugs to the color of the sockets; green to green, blue to blue, and red to red.

2. Connect the other end of the Component Video cable to the COMPONENT socket
on the projector. Match the colors of the plugs to the colors of the jacks-green to
green, blue to blue, and red to red.

To connect the projector to an Audio source device:

1. Take a suitable audio cable and connect one end to the AUDIO OUT jack of the AV
device. Connect the other end of the cable to the AUDIO IN jack on the projector.
Once connected, the audio can be controlled by the projector On-Screen Display
(OSD) menus. See "Audio Settings" on page 45 for details.

The final connection path should be like that shown in the following diagram:

English

• If the selected video image is not displayed after the projector is turned on and the correct

video source has been selected, check that the Video source device is turned on and
operating correctly . Also check that the signal cables have been connected correctly.

• If you have already made an HDMI Video connection between the projector and this

Component Video source device using HDMI Video connections, you need not connect to
this device using a Component Video connection as this makes an unnecessary second
connection of poorer picture quality. See "Connecting Video source devices" on page 19
for details.

Connection 21

English

AV device

Audio device

S-Video device

Connecting S-Video source devices

Examine your Video source devic e to determine if it has an unused S-Video output socket
available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to an S-Video source device:

1. Take an S-Video cable and connect one end to the S-V ideo outp ut socket of the Video
source device.

2. Connect the other end of the S-Video cable to the S-VIDEO socket on the projector.

To connect the projector to an Audio source device:

1. Take a suitable audio cable and connect one end to the AUDIO OUT jack of the AV
device. Connect the other end of the cable to the AUDIO IN jack on the projector.
Once connected, the audio can be controlled by the projector On-Screen Display
(OSD) menus. See "Audio Settings" on page 45 for details.

The final connection path should be like that shown in the following diagram:

• If the selected video image is not displayed after the projector is turned on and the correct

video source has been selected, check that the Video source device is turned on and
operating correctly . Also check that the signal cables have been connected correctly.

• If you have already made a Component Video connection between the projector and this

S-Video source device using Component Video connections, you need not connect to this
device using an S-Video connection as this makes an unnecessary second connection of
poorer picture quality. See "Connecting Video source devices" on page 19 for details.

Connection22

Connecting Composite Video source devices

AV device

Audio cable

Video cable

Examine your Video source device to determine if it has a set of unused composite Video
output sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to a composite Video source device:

1. Take a Video cable and connect one end to the composite Video output socket of the
Video source device.

2. Connect the other end of the Video cable to the VIDEO socket on the projector .

To connect the projector to an Audio source device:

1. Take a suitable audio cable and connect one end to the AUDIO OUT jack of the AV
device. Connect the other end of the cable to the AUDIO IN jack on the projector.
Once connected, the audio can be controlled by the projector On-Screen Display
(OSD) menus. See "Audio Settings" on page 45 for details.

The final connection path should be like that shown in the following diagram:

English

• If the selected video image is not displayed after the projector is turned on and the correct

video source has been selected, check that the Video source device is turned on and
operating correctly . Also check that the signal cables have been connected correctly.

• You need only connect to this device using a composite Video connection if HDMI and

Component Video and S-Video inputs are unavailable for use. See "Connecting Video

source devices" on page 19 for details.

Connection 23

English

Please select language

Press Enter to confirm, Exit to leave

Operation

Starting up the projector

1. Plug the power cord into the projector and
into a wall socket. Turn on the wall socket
switch (where fitted). Check that the
POWER indicator light on the projector
lights orange after power has been applied.

Please use the original accessories (e.g. power
cable) only with the device to avoid possible
dangers such as electric shock and fire.

2. Press POWER on the projector or
remote control to start the projector

and a start up tone sounds. The POWER
indicator light flashes green and stays
green when the projector is on.

The start up procedure takes about 30
seconds. In the later stage of start up, a
startup logo is projected.

(If necessary) Rotate the focus ring to
adjust the image clearness.

To turn of f the ring tone, see "Turning off the Power on/off ring ton e" on page 41 for details.

If the projector is still hot from previous activity, it will run the cooling fan for approximately 90
seconds before energizing the lamp.

3. To use the OSD menus, please set them to your familiar
language first. See "Personalizing the projector menu

display" on page 42 for details.

4. If you are prompted for a password, press the arrow keys
to enter a five digit password. See "Utilizing the

password function" on page 26 for details.

5. Switch all of the connected equipment on.

6. The projector will start to search for input signals. The
current input signal being scanned displays in the upper
left corner of the screen. If the projector doesn't detect a
valid signal, the message 'No Signal' will continue
displaying until an input signal is found.

You can also press SOURCE on the projector or remote
control to select your desired input signal. See "Switching input signal" on page 29 for
details.

If the frequency/resolution of the input signal exceeds the projector's operating range, you wi ll
see the message 'Out of Range' displayed on a blank screen. Please cha nge to an i nput signal
which is compatible with the projector's resolution or set the input signal to a lower setting.
See "Timing chart" on page 61 for details.

To maint ain the lamp life, once you turn the project or on, wait at least 5 minutes before turning
if off.

Operation24

Using the menus

Current input signal

Main menu icon

Main menu

Sub-menu

Highlight

Press MENU/
EXIT to the
previous
page or to
exit.

Status

Wall Color
Aspect Ratio
Auto Keystone

Position

Phase
H. Size
Digital Zoom

Off

Auto

15

0

ENTER

MENU Exit

PC

Keystone

On

Auto

DISPLAY

3D Sync
3D Sync Invert

Off

Disable

DISPLAY

Wall Color
Aspect Ratio

Keystone
Position
Phase
H. Size

Auto

MENU

Exit

Auto Keystone

15

0

VIDEO

Digital Zoom

Off

On

3D Sync
3D Sync Invert

Off

Disable

SYSTEM SETUP: Basic

Presentation Timer

English

Language

Projector Position

Auto Power Off
Blank Timer

Sleep Timer

Panel Key Lock

Splash Screen

Exit

Front Table

Disable
Disable

Off

Disable

BenQ

Menu Settings

Disable

MENU

VIDEO

SYSTEM SETUP: Basic

Presentation Timer

English

Language

Projector Position

Menu Settings
Auto Power Off

Panel Key Lock

Blank Timer

Sleep Timer

VIDEO

MENU

Exit

Front Table

Disable
Disable

Off

Disable

Splash Screen BenQ

The projector is equipped with On-Screen Display (OSD) menus for making various
adjustments and settings.
Below is the overview of the OSD menu.

To use the OSD menus, please set them to your familiar language first.

1. Press MODE/ENTER on the projector or

remote control to turn the OSD menu on.

3. Press to highlight Language

and press / to select a
preferred language.

English

2. Use / to highlight the SYSTEM

Securing the projector

Using a security cable lock

The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock,
such as a Kensington lock, to secure the projector. You can locate a Kensington lock slot on
the left side of the projector. See "Kensington anti-theft lock slot" on page 9 for details.

A Kensington security cable lock is usually a combination of key(s) and a lock. Refer to the
lock’s documentation for finding out how to use it.

SETUP: Basic menu.

4. Press MODE/ENTER twice* on

the projector or remote control to
leave and save the settings.

*The first press leads you back to
the main menu and the second
press closes the OSD menu.

Operation 25

English

INPUT NEW PASSWORD

BackMENU

Utilizing the password function

For security purposes and to help prevent unauthorized use, the projector includes an option
for setting up password security. The password can be set through the On-Screen Display
(OSD) menu. For details of the OSD menu operation, please refer to "Using the menus" on

page 25.

You will be inconvenienced if you activate the power-on lock functionality and subsequently
forget the password. Print out this manual (if necessary) and write the password you used in
this manual, and keep the manual in a safe place for later recall.

Setting a password

Once a password has been set, the projector cannot be used unless the correct password is
entered every time the projector is started.

1. Open the OSD menu and go to the SYSTEM SETUP: Advanced > Security
Settings menu. Press MODE/ENTER. The Security Settings page displays.

2. Highlight Power on Lock and select On by pressing / .

3. As pictured to the right, the four arrow keys ( ,

, , ) respectively represent 4 digits (1, 2,
3, 4). According to the password you desire to
set, press the arrow keys to enter five digits for
the password.

4. Confirm the new password by re-entering the
new password.
Once the password is set, the OSD menu returns
to the Security Settings page.

5. To activate the Power on Lock function, press / to highlight Power on Lock
and press / to select On.

The digits being input will display as aste risks on-scr een. W rit e your select ed p assword dow n
here in this manual in advance or right after the password is entered so that it is available to
you should you ever forget it.

Password: __ __ __ __ __
Keep this manual in a safe place.

6. To leave the OSD menu, press MENU/EXIT.

Operation26

If you forget the password

Password Error

Please Try again.

Please write down the recall code,
and contact BenQ
Customer Center.

Recall code:

12345678

RECALL PASSWORD

Back

MENU

Password Changed

Entering the password recall procedure

Changing the password

If the password function is activated, you will be asked
to enter the five-digit password every time you turn on
the projector. If you enter the wrong password, the
password error message as pictured to the right
displays lasting for three seconds, and the message
'INPUT PASSWORD' follows. You can retry by
entering another five-digit password, or if you did not
record the password in this manual, and you absolutely do not remember it, you can use the
password recall procedure. See "Entering the password recall procedure" on page 27 for
details.

If you enter an incorrect password 5 times in succession, the projector will automatically
shut down in a short time.

1. Press and hold AUTO on the projector for 3
seconds. The projector will display a coded
number on the screen.

2. Write down the number and turn off your
projector.

3. Seek help from the local BenQ service center to
decode the number. You may be required to
provide proof of purchase documentation to
verify that you are an authorized user of the
projector.

1. Open the OSD menu and go to the SYSTEM SETUP: Advanced > Security
Settings > Change password menu.

2. Press MODE/ENTER. The message 'INPUT CURRENT PASSWORD' displays.

3. Enter the old password.

• If the password is correct, another message 'INPUT NEW PASSWORD'

displays.

• If the password is incorrect, the password error message displays lasting for three

seconds, and the message 'INPUT CURRENT PASSWORD' displays for your
retry. You can press MENU/EXIT to cancel the change or try another password.

4. Enter a new password.

The digits being input will display as aste risks on-scr een. W rit e your select ed p assword dow n
here in this manual in advance or right after the password is entered so that it is available to
you should you ever forget it.

Password: __ __ __ __ __
Keep this manual in a safe place.

5. Confirm the new password by re-entering the new password.

6. You have successfully assigned a new password
to the projector. Remember to enter the new
password next time the projector is started.

7. To leave the OSD menu, press MENU/EXIT.

English

Operation 27

English

Disabling the password function

To disable password protection, go back to the SYSTEM SETUP: Advanced > Security
Settings > Power on Lock menu after opening the OSD menu system. Select Off by

pressing / . The message 'INPUT PASSWORD' displays. Enter the current password.

i. If the password is correct, the OSD menu returns to the Security Settings page

with Off show in the row of Power on Lock. You will not have to enter the
password next time you turn on the projector.

ii. If the password is incorrect, the password error message displays lasting for three

seconds, and the message 'INPUT PASSWORD' displays for your retry. You can
press MENU/EXIT to cancel the change or try another password.

Though the password function is disabled, you need to keep the old password in hand should
you ever need to re-activate the password function by entering the old password.

Operation28

Switching input signal

PC

HDMI 1

HDMI 2

COMPONENT

S-VIDEO

VIDEO

The projector can be connected to multiple devices at the same time. However, it can only
display one full screen at a time.

Be sure the Quick Auto Search function in the SOURCE menu is On (which is the default
of this projector) if you want the projector to automatically search for the signals.

You can also manually cycle through the
available input signals.

1. Press SOURCE on the projector or press
input source directly from the remote
control. A source selection bar displays.

2. Press / until your desired signal is
selected and press MODE/ENTER.
Once detected, the selected source
information will display on the screen for
seconds. If there is multiple equipment
connected to the projector, repeat steps 1-2
to search for another signal.

• When SOURCE is activated, the Quick Auto

Search function will be turned off
automatically until restarting the projector.

• The brightness level of the projected image

will change accordingly when you switch
between different input signals. Data (graphic)
"PC" presentations using mostly static
images are generally brig ht er than "Video"
using mostly moving images (movies).

• The native display resolution of this projector is in a 16:9 aspect ratio. For best display

picture results, you should select and use an input signal which output s at this resol ution.
Any other resolutions will be scaled by the projector depending upon the 'aspect ratio'
setting, which may cause some image distortion or loss of picture clarity. See "Selecting

the aspect ratio" on page 32 for details.

English

Changing Color Space

In the unlikely event that you connect the projector to a DVD player via the projector’s
HDMI input and the projected picture displays wrong colors, please change the color space.

To do this:

1. Press MENU/EXIT and then press / until the SOURCE menu is highlighted.

2. Press to highlight Color Space Conversion and press / to select the setting.

This function is only available when the HDMI input socket is in use.

Operation 29

English

1

2

Adjusting the projected image

Adjusting the projection angle

The projector is equipped with 1 quick-release adjuster foot and 1 rear adjuster foot. These
adjusters change the image height and projection angle. To adjust the projector:

1. Press the quick-release button and lift the
front of the projector. Once the image is
positioned where you want it, release the
quick-release button to lock the foot in
position.

2. Screw the rear adjuster foot to fine tune the
horizontal angle.

To retract the foot, hold up the projector while
pressing the quick-release button, then slowly
lower the projector. Screw the rear adjuster foot in
a reverse direction.

If the projector is not placed on a flat surface or the screen and the projector are not
perpendicular to each other, the projected image becomes trapezoidal. To correct this
situation, see "Correcting keystone" on page 31 for details.

• Do not look into the lens while the lamp is on. The strong light from the lamp may cause

damage to your eyes.

• Be careful when you press the adjuster button as it is close to the exhaust vent where hot

air comes from.

Auto-adjusting the image

In some cases, you may need to optimize the picture
quality. To do this, press AUTO on the projector. Within 3
seconds, the built-in Intelligent Auto Adjustment function
will re-adjust the values of Frequency and Clock to
provide the best picture quality.

The current source information will be displayed in the
upper left corner of the screen for 3 seconds.

• The screen will be blank while AUTO is functioning.

• This function is only available when PC signal (analog RGB) is selected.

Fine-tuning the image size and clarity

1. Adjust the projected image to the size that
you need using the ZOOM ring.

Operation30

FOCUS

2. Then sharpen the image by rotating the

Press /.Press /.

6

KEYSTONE

Back

MENU

FOCUS ring.

FOCUS

Correcting keystone

Keystoning refers to the situation where the projected image is noticeably wider at either the
top or bottom. It occurs when the projector is not perpendicular to the screen.

To correct this, besides adjusting the height of the projector, you can use Auto Keystone or
Keystone manually correct it following one of these steps.

•Using Auto Keystone

It can correct Keystone to optimal status by automatically.

• Using the remote control

1. Press MENU/EXIT and then press / until the

2. Press to highlight Auto Keystone and press / to select Off to disable Auto
Keystone function.

3. Press / on the projector or remote
control to display the Keystone correction

page. Press to correct keystoning at
the top of the image. Press to correct

keystoning at the bottom of the image.

• Using the OSD menu

1. Press MENU/EXIT and then press /

until the

DISPLAY menu is

highlighted.

2. Press to highlight Auto Keystone and
press / to select Off to disable Auto

Keystone function.

3. Press MENU/EXIT and then press / until the

4. Press to highlight Keystone and press MODE/ENTER. The Keystone correction
page displays.

5. Press to correct keystoning at the top of the
image or press to correct keystoning at the

bottom of the image.

DISPLAY menu is highlighted.

DISPLAY menu is highlighted.

English

Operation 31

English

Magnifying and searching for details

If you need to find the details on the projected picture, magnify the picture. Use the
direction arrow keys for navigating the picture.

1. Press MENU/EXIT and then press / until the DISPLAY menu is highlighted.

2. Press

3. Press on the projector repeatedly to magnify the picture to a desired size.

4. To navigate the picture, press MODE/ENTER to switch to the paning mode and

5. To reduce size of the picture, press MODE/ENTER to switch back to the zoom in/out

The picture can only be navigated after the picture is magnified. You can further magnify the
picture while searching for details.

to highlight Digital Zoom and press MODE/ENTER. The Zoom bar

displays.

press the directional arrows ( , , , ) to navigate the picture.

functionality, and press AUTO to restore the picture to its original size. You can also
press repeatedly until it is restored to the original size.

Playing 3D function

1. To enter the special preset mode, press MENU/EXIT and then press / until the
DISPLAY menu is highlighted, and press / to enable or disable 3D Sync. When

the 3D Sync is enabled, the current picture mode adjustment will be disabled.

2. To invert the image, press MENU/EXIT and then press / until the DISPLAY
menu is highlighted, and press / to enable or disable 3D Sync Invert.

3. 3D Requirement:

• PC: PC with graphic card with stereo capability ( Quad buffer feature) and can run

at 120Hz refresh rate.

• Video: standard NTSC DVD player to output 60Hz movie.

• 55% of the brightness will loss.

To enjoy the 3D function, first enable the Play Movie in 3D setting found in your DVD devices
under the 3D Disc Menu.

Selecting the aspect ratio

The 'aspect ratio' is the ratio of the image width to the image height. For W600+, the default
aspect ratio is 16:9. Most analog TV and computers are in 4:3 ratio, and digital TV and
DVDs are usually in 16:9 ratio.

With the advent of digital signal processing, digital display devices like this projector can
dynamically stretch and scale the image output to a different aspect than that of the image
input signal.

To change the projected image ratio (no matter what aspect the source is):

1. Press MENU/EXIT and then press / until the DISPLAY menu is highlighted.

2. Press

3. Press / to select an aspect ratio to suit the format of the video signal and your

Operation32

to highlight Aspect Ratio.

display requirements.

About the aspect ratio

16:10 picture

15:9 picture

4:3 picture

16:9 picture

4:3 picture

16:9 picture

In the pictures below, the black portions are inactive areas and the white portions are acti ve
areas. OSD menus can be displayed on those unused black areas.

1. Auto:
Scales an image proportionally to fit the
projector's native resolution in its
horizontal width. This is suitable for the
incoming image which is neither in 4:3
nor 16:9 and you want to make most use
of the screen without altering the image's
aspect ratio.

2. Real:

The image is projected as its original
resolution, and resized to fit within the
display area. For input signals with lower
resolutions, the projected image will
display smaller than if resized to full
screen. You could adjust the zoom setting
or move the projector away from the
screen to increase the image size if
necessary. You may also need to refocus
the projector after making these
adjustments.

OSD menus can be displayed in the unused
black areas.

3. 4:3:
Scales an image so that it is displayed in
the center of the screen with a 4:3
aspect ratio. This is most suitable for
4:3 images like computer monitors,
standard definition TV and 4:3 images
aspect DVD movies, as it displays them
without aspect alteration.

4. 16:9:
Scales an image so that it is displayed in
the center of the screen with a 16:9
aspect ratio. This is most suitable for
images which are already in a 16:9
aspect, like high definition TV, as it
displays them without aspect alteration.

English

Operation 33

English

Optimizing the image

Using Wall Color

In the situation where you are projecting onto a colored surface such as a painted wall which
may not be white, the Wall Color feature can help correct the projected picture’s color to
prevent possible color difference between the source and projected pictures.

To use this function, go to the DISPLAY > Wall Color menu and press / to select a
color which is the closest to the color of the projection surface. There are several
precalibrated colors to choose from: Light Yellow, Pink, Light Green, Blue, and

Blackboard.

Selecting a picture mode

The projector is preset with several predefined picture
modes so that you can choose one to suit your operating
environment and input signal picture type.

To select an operation mode that suits your need, you can
follow one of the following steps.

• Press MODE/ENTER on the projector repeatedly until

your desired mode is selected.

•Go to the PICTURE > Picture Mode menu and press / to select a desired mode.

Picture modes for different types of signals

The picture modes available for different types of signals are listed below.

1. Dynamic mode: Maximizes the brightness of the projected image. This mode is
suitable for environments where extra-high brightness is required, such as using the
projector in well lit rooms.

2. Standard mode (Default): Is designed for presentations. The brightness is
emphasized in this mode to match PC and notebook coloring.

3. sRGB mode: Maximizes the purity of RGB colors to provide true-to-life images
regardless of brightness setting. It is most suitable for viewing photos taken with an
sRGB compatible and properly calibrated camera, and for viewing PC graphic and
drawing applications such as AutoCAD.

4. Cinema mode: Is appropriate for playing colorful movies, video clips from digital
cameras or DVs through the PC input for best viewing in a blackened (little light)
environment.

5. User 1/User 2 mode: Recalls the settings customized based on the current available
picture modes. See "Setting the User 1/User 2 mode" on page 35 for details.

Operation34

Setting the User 1/User 2 mode

+50

+30

+70

There are two user-definable modes if the current available picture modes are not suitable
for your need. You can use one of the picture modes (except the User 1/User 2) as a starting
point and customize the settings.

1. Press MENU/EXIT to open the On-Screen Display (OSD) menu.

2. Go to the PICTURE > Picture Mode menu.

3. Press / to select User 1 to User 2.

4. Press to highlight Reference Mode.

This function is only available when User 1 or User 2 mode is selected up in the Picture Mode
sub-menu item.

5. Press / to select a picture mode that is closest to your need.

6. Press to select a sub-menu item to be changed and adjust the value with / .
See "Fine-tuning the image quality in user modes" below for details.

7. When all settings have been done, highlight Save Settings and press MODE/ENTER
to store the settings.

8. The confirmation message 'Setting Saved' displays.

Fine-tuning the image quality in user modes

According to the detected signal type, there are some user-definable functions available
when User 1 or User 2 mode is selected. You can make adjustments to these functions
based on your needs.

Adjusting Brightness

Highlight Brightness in the PICTURE menu and adjust the values by pressing / on
the projector or remote control.

The higher the value, the brighter the image. And lower
the setting, darker the image. Adjust this control so the
black areas of the image appear just as black and that
detail in the dark areas is visible.

Adjusting Contrast

Highlight Contrast in the PICTURE menu and adjust the values by pressing / on the
projector or remote control.

The higher the value, the greater the contrast. Use this
to set the peak white level after you have previously
adjusted the Brightness setting to suit your selected
input and viewing environment.

+30

0

English

-30

Operation 35

English

Adjusting Color

Highlight Color in the PICTURE menu and adjust the values by pressing / on the
projector or remote control.

Lower setting produces less saturated colors. If the setting is too high, colors on the image
will be overpowering, which makes the image unrealistic.

Adjusting Tint

Highlight Tint in the PICTURE menu and adjust the values by pressing / on the
projector or remote control.

The higher the value, the more reddish the picture becomes. The lower the value, the more
greenish the picture becomes.

Adjusting Sharpness

Highlight Sharpness in the PICTURE menu and adjust the values by pressing / on
the projector or remote control.

The higher the value, the sharper the picture becomes. The lower the value, the softer the
picture becomes.

Adjusting Brilliant Color

Highlight Brilliant Color in the PICTURE menu and select by pressing / on the
projector or remote control.

This feature utilizes a new color-processing algorithm and system level enhancements to
enable higher brightness while providing truer, more vibrant colors in picture. It enables a
greater than 50% brightness increase in mid-tone images, which are common in video and
natural scenes, so the projector reproduces images in realistic and true colors. If you prefer
images with that quality, select On. If you don’t need it, select Off.

On is the default and recommended selection for this projector. When Off is selected, the
Color Temperature function is not available.

Selecting a Color Temperature

Highlight Color Temperature in the PICTURE menu and adjust the values by pressing

/ on the projector or remote control.

The options available for color temperature* settings vary according to the signal type
selected.

1. T1: With the highest color temperature, T1 makes the image appear the most bluish
white than other settings.

2. T2: Makes images appear bluish white.

3. T3: Maintains normal colorings for white.

4. T4: Makes images appear reddish white.

*About color temperatures:

There are many different shades that are considered to be "white" for various purposes. One
of the common methods of representing white color is known as the “color temperature”. A
white color with a low color temperature appears to be reddish white. A white color with a
high color temperature appears to have more blue in it.

Operation36

RED

BLUE

GREEN

Yellow

Cyan

Magenta

3D Color Management

In most installation situations, color management will not be necessary, such as in
classroom, meeting room, or lounge room situations where lights remain on, or where
building external windows allow daylight into the room.

Only in permanent installations with controlled lighting levels such as boardrooms, lecture
theaters, or home theaters, should color management be considered. Color management
provides fine color control adjustment to allow for more accurate color reproduction, should
you require it.

Proper color management can only be achieved under controlled and reproducible viewing
conditions. You will need to use a colorimeter (color light meter), and provide a set of
suitable source images to measure color reproduction. These tools are not provided with the
projector, however, your projector supplier should be able to provide you with suitable
guidance, or even an experienced professional installer.

The Color Management provides six sets (RGBCMY) of colors to be adjusted. When you
select each color, you can independently adjust its range and saturation according to your
preference.

If you have purchased a test disc which contains various color test patterns and can be used
to test the color presentation on monitors, TVs, projectors, etc. You can project any image
from the disc on the screen and enter the 3D Color Management menu to make
adjustments.

To adjust the settings:

1. Go to the PICTURE menu and highlight 3D Color Management.

2. Press MODE/ENTER and the 3D Color Management page displays.

3. Highlight Primary color and press / to select a color from among Red, Green,
Blue, Cyan, Magenta and Yellow.

4. Press to highlight Hue and press / to select its range. Increase in the range
will include colors consisted of more proportions of its two adjacent colors.

Please refer to the illustration to the right for
how the colors relate to each other.
For example, if you select Red and set its
range at 0, only pure red in the projected
picture will be selected. Increasing its range
will include red close to yellow and red close
to magenta.

5. Press to highlight Saturation and adjust
its values to your preference by pressing /

. Every adjustment made will reflect to the

image immediately.
For example, if you select Red and set its

value at 0, only the saturation of pure red will be affected.

6. Press to highlight Gain and adjust its values to your preference by pressing /

. The contrast level of the primary color you select will be affected. Every

adjustment made will reflect to the image immediately.

7. Repeat steps 3 to 6 for other color adjustments.

8. Make sure you have made all of the desired adjustments.

9. Press MENU/EXIT to exit and save the settings.

Saturation is the amount of that color in a video picture. Lower settings produce less
saturated colors; a setting of “0” removes that color from the image entirely. If the saturation
is too high, that color will be overpowering and unrealistic.

English

Operation 37

English

Presentation Timer

Timer period

Timer display
Timer position
Timer counting direction

Always

Top-Left

Count Down

On

Off

MENU

Back

15

Sound reminder

Off

5 min

5 min

5 min

5 min

Are you sure to turn on the
Presentation Timer?

Yes

No

Setting the presentation timer

The presentation timer can indicate the presentation
time on the screen to help you achieve better time
management when giving presentations. Follow these
steps to utilize this function:

1. Go to the

Presentation Timer
ENTER

2. Press to highlight Timer period and decide the timer period by pressing / .
The length of time can be set from 1 to 5 minutes in 1-minute increments and 5 to 240
minutes in 5-minute increments.

If the timer is already on, the timer will restar t whenever the Timer period is reset.

3. Press to highlight Timer display and choose if you want the timer to show up on
the screen by press

Selection Description

Always Displays the timer on screen throughout the presentation time.
1 min/2 min/3 min Displays the timer on screen in the last 1/2/3 minute(s).
Never Hides the timer throughout the presentation time.

4. Press to highlight Timer position and set the timer
position by pressing /

Top-Left Bottom-Left Top-Right Bottom­Right

5. Press to highlight Timer counting direction and select
your desired counting direction by pressing /

Selection Description

Count Up Increases from 0 to the preset time.
Count Down Decrease from the preset time to 0.

6. Press to highlight Sound reminder to select On. A notice sound alerts 30 seconds
before and at the end of the Presentation Timer countdown.

7. To activate the presentation timer, press and
press / to select On and press MODE/

ENTER.

8. A confirmation message displays. Highlight Yes
and press MODE/ENTER to confirm. You will

see the message “Timer is On” displaying on the
screen. The timer starts counting at the time the
timer is on.

SYSTEM SETUP: Basic

menu and press

to display the

Presentation Timer

ing / .

.

>

MODE/

page.

.

To cancel the timer, perform the following steps.

1. Go back to the Presentation Timer page.

2. Press and press / to highlight Off and press MODE/ENTER. A
confirmation message displays.

3. Highlight Yes and press MODE/ENTER to confirm. You will see the message
“Timer is Off” displaying on the screen.

Operation38

Hiding the image

In order to draw the audience's full attention
to the presenter, you can use BLANK on the
projector or remote control to hide the screen
image. Press any key on the projector or
remote control to restore the image. The
word 'BLANK' appears at the lower right
corner of the screen while the image is
hidden.

You can set the blank time in the

SETUP: Basic > Blank Timer

after a period of time when there is no action taken on the blank screen.
No matter

• Do not block the projection lens from projecting as this could cause the blocking object to

Blank Timer is activated or disabled, you can press any key except PAGE /

, ENTER on the remote control, or ENTER on the projector to restore the picture.

become heated and deformed or even cause a fire.

SYSTEM

menu to let the projector return the image automatically

Locking control keys

With the control keys on the projector locked, you can prevent your projector settings from
being changed accidentally (by children, for example). When the Panel Key Lock is on, no
control keys on the projector will operate except POWER.

English

1. Press / on the projector or go to the

SETUP: Basic > Panel Key Lock menu

On by pressing / on the projector or remote

control.

2. A confirmation message displays. Select Yes to
confirm.

To release panel key lock, press and hold / for 3
seconds on the projector.

You can also use the remote control to enter the SYSTEM SETUP: Basic > Panel Key
Lock and press / to select Off.

• Keys on the remote control are still in use when panel key lock is enabled.

• If you press POWER to turn off the projector without disabling panel key lock, the

projector will still be in locked status the next time it is turned on.

SYSTEM

, and select

Operation 39

English

We recommend you use the High Altitude
mode by selecting it whenever your
environment is higher than 1500m.

Yes

No

Notice

Do you want to turn High Altitude
Mode ON?

Freezing the image

Utilizing FAQ function

Operating in a high altitude environment

Operation40

Press FREEZE on the remote control to freeze the image. The word
'FREEZE' will display in the upper left corner of the screen. To release
the function, press any key on the projector or remote control.

Even if an image is frozen on the screen, the pictures are running on the
video or other device. If the connected devices have active audio output,
you will still hear the audio even though the image is frozen on screen.

The INFORMATION menu contains possible solutions to problems encountered by users
regarding image quality, installation, special feature operation and service information.

To get the FAQ information:

1. Press / on the projector or press

MENU/EXIT

to

open the OSD menu and press / to highlight the

INFORMATION

menu.

2. Press to highlight FAQ-Image and Installation or
FAQ-Features and Service based on the information
you want to know.

3. Press MODE/ENTER.

4. Press / to select a problem and press MODE/ENTER for possible solutions.

5. Press MENU/EXIT to exit the OSD.

We recommend you use the High Altitude Mode when your environment is between
1500 m –3000 m above sea level, and temperature is between 5°C–23°C.

Do not use the High Altitude Mode if your altitude is between 0 m and 1500 m and temper ature
is between 5°C and 28°C. The projector will be over cooled, if you turn the mode on under
such a condition.

To activate the High Altitude Mode:

1. Press MENU/EXIT and then press /
until the SYSTEM SETUP: Advanced menu
is highlighted.

2. Press to highlight High Altitude Mode and
press / to select On. A confirmation

message displays.

3. Highlight Yes and press MODE/ENTER.

Operation under "High Altitude Mode" may cause a
higher decibel operating noise level because of increased fan speed necessary to improve
overall system cooling and performance.

If you use this projector under other extreme conditions excluding the above, it may display
auto shut-down symptoms, which is designed to protect your projector from over-heating.
In cases like this, you should switch to High Altitude mode to solve these symptoms.
However, this is not to state that this projector can operate under any and all harsh or
extreme conditions.

Adjusting the sound

-

The sound adjustments made as below will have an effect on the projector speakers. Be sure
you have made a correct connection to the projector audio input. See

for how the audio input is connected.

18

"Connection" on page

English

INPUT SOURCE AUDIO IN

Computer
PC

HDMI 1/2 HDMI mini jack
Component RCA mini jack
VIDEO RCA mini jack
S-VIDEO RCA mini jack

mini jack mini jack

AUDIO
OUT

Muting the sound

To temporarily turn off the sound,

• Using the remote control

Press MUTE to temporarily turn off the sound. While the sound is off,
the screen will display in the upper right corner of the screen.

To restore the sound, press MUTE again.

• Using the OSD menu

1. Press MENU/EXIT and then press / until the SYSTEM
SETUP: Advanced menu is highlighted.

2. Press to highlight Audio Settings and press ENTER.
The Audio Settings page displays.

3. Highlight Mute and press / to select On.

4. To restore the sound, repeat steps 1-3 and press / to select Off.

Adjusting the sound level

To adjust the sound level,

• Using the remote control

Press or to select a desired sound level.

• Using the OSD menu

1. Repeat steps 1-2 above.

2. Press to highlight Volume and press / to select a
desired sound level.

Turning off the Power on/off ring tone

1. Repeat steps 1-2 above.

2. Press to highlight Power on/off ring tone and press /
to select Off.

The only way to change Power on/off ring tone is setting On or Off here. Setting the sound
mute or changing the sound level will not affect the Power on/off ring tone.

Operation 41

English

Personalizing the projector menu display

The On-Screen Display (OSD) menus can be set according to your preferences. The
following settings do not affect the projection settings, operation, or performance.

• Menu display time in the SYSTEM SETUP: Basic > Menu Settings menu sets the

length of time the OSD will remain active after your last key press. The time length
ranges from 5 to 30 seconds in 5-second increments. Use / to select a suitable time

frame.

• Menu position in the SYSTEM SETUP: Basic > Menu Settings menu sets the OSD

position in five locations. Use / to select a preferred position.

• Language in the SYSTEM SETUP: Basic menu sets your familiar language for the

OSD menus. Use / to select your language.

• Splash Screen in the SYSTEM SETUP: Basic menu sets a preferred logo screen to be

displayed during projector start-up. Use / to select a screen.

Shutting down the projector

1. To turn the projector off, press POWER
OFF on the remote control to turn
projector off directly. Or you can press

POWER on the projector and a

warning message appears.
Press POWER again.

2. Once the cooling process finishes, the
POWER indicator light is a steady
orange and fans stop.

3. Disconnect the power cord from the
wall socket if the projector will not be
used in an extended period of time.

• To protect the lamp, the projector will not

respond to any commands during the
cooling process.

• To shorten the cooling time, you can also

activate the Quick Cooling function. See "Quick Cooling" on page 49 for details.

• If the projector is not properly shut down, to protect the lamp, when you attempt to re-start

the projector, the fans will run for a few minutes to cool down. Press POWER again to start
the projector after the fans stop and the POWER indicator light turns orange.

• Lamp life results will vary depending on environmental conditions, and usage.

Operation42

Menu operation

Menu system

Please note that the on-screen display (OSD) menus vary according to the signal type
selected.

Main menu Sub-menu Options

Off/Light Yellow/Pink/Light

Green/Blue/Blackboard

T1/T2/T3/T4

On/Off
Auto/RGB/SDTV/HDTV

1.

DISPLAY

2.


3. SOURCE

Wall Color
Aspect Ratio Auto/Real/4:3/16:9

Auto Keystone On/Off
Keystone
Position
Phase
H. Size
Digital Zoom
3D Sync On/Off
3D Sync Invert Disable/Invert
Picture Mode
Reference Mode Dynamic/Standard/sRGB/Cinema
Brightness
Contrast
Color
Tint
Sharpness
Brilliant Color On/Off
Color

Temperature

3D Color
Management

Save Settings
Quick Auto Search

Color Space Conversion

Dynamic/

Primary color R/G/B/C/M/Y
Hue
Saturation
Gain

Standard/sRGB/Cinema/User 1/User 2

English

Operation 43

English

6.

INFORMATI
ON

4.

SYSTEM
SETUP:
Basic

FAQ-Image and Installation
FAQ-Features and Service

• Source

• Picture Mode

Current System Status

Timer period 1~240 minutes
Timer display Always/1 min/2 min/3 min/Never

Presentation
Timer

Language

Projector Position

Menu Settings

Auto Power Off

Blank Timer
Panel Key Lock On/Off

Sleep Timer
Splash Screen BenQ/Black/Blue

Timer position

Timer counting
direction

Sound reminder On/Off
On/Off

Menu display
time

Menu position

• Resolution

• Color System

• Equivalent Lamp Hour

• Firmware Version

Top-Left/Bottom-Left/Top-Right/
Bottom-Right

Count Down/Count Up

Front Table/Rear Table/

Rear Ceiling/Front Ceiling
5 sec/10 sec/15 sec/20 sec/

25 sec/30 sec
Center/Top-left/Top-right/Bottom-

right/Bottom-left
Disable/5 min/10 min/15 min/20

min/25 min/30 min
Disable/5 min/10 min/15 min/20

min/25 min/30 min

Disable/30 min/1 hr/2 hr/3 hr/4
hr/8 hr/12 hr

Operation44

Quick Cooling Off/On
High Altitude Mode Off/On

5.

SYSTEM
SETUP:
Advanced

Audio Settings Mute

Lamp Settings

Security
Settings

Baud Rate
Test Pattern Off/On

Closed Caption

Reset All Settings

Volume
Power on/off
ring tone

Lamp Mode Normal/Economic
Reset lamp timer
Equivalent Lamp Hour
Change password
Power on Lock Off/On

Closed Caption
Enable

Caption Version CC1/CC2/CC3/CC4

Off/On
Range : 0 ~ 10
Off/On

9600/19200/38400/57600/

115200

Off/On

Note that the menu items are available when the projector detects at least one valid signal. If
there is no equipment connected to the projector or no signal detect ed, limited menu items
are accessible.

English

Operation 45

English

1. DISPLAY menu

Description of each menu

FUNCTION DESCRIPTION

Wall Color

Aspect Ratio

Auto
Keystone

Keystone

Position

Phase

H. Size

Digital Zoom
3D Sync

Corrects the projected picture’s color when the projection surface is
not white. See "Using Wall Color" on page 34 for details.

There are four options to set the image's aspect ratio depending on
your input signal source. See "Selecting the aspect ratio" on page 32
for details.

Corrects any keystoning of the image automatically. See "Correcting

keystone" on page 31 for details.

Corrects any keystoning of the image manually. See "Correcting

keystone" on page 31 for details.

Displays the position adjustment page. To move the projected image,
use the directional arrow keys. The values shown on the lower
position of the page change with every key press you made until they
reach their maximum or minimum.

This function is only available when a PC signal (analog RGB) is
selected.

Adjusts the clock phase to reduce image
distortion.
This function is only available when a PC
signal (analog RGB) is selected.

Adjusts the horizontal width of the image.
This function is only available when a PC signal (analog RGB) is
selected.

Magnifies or reduces the projected image. See "Magnifying and

searching for details" on page 32 for details.

Enable 3D function.

3D Sync
Invert

Operation46

Invert 3D sync.

Picture Mode

2. PICTURE menu

3. SOURCE

menu

Reference
Mode

Brightness
Contrast

Color

Tint

Sharpness

Brilliant Color
Color

Temperature

Pre-defined picture modes are provided so you can optimize your
projector image set-up to suit your program type.
See "Selecting a picture mode" on page 34 for details.

Selects a picture mode that most suits your need for the image quality
and further fine-tune the image based on the selections listed on the
same page below.
See "Setting the User 1/User 2 mode" on page 35 for details.

Adjusts the brightness of the image.
See "Adjusting Brightness" on page 35 for details.

Adjusts the degree of difference between dark and light in the image.
See "Adjusting Contrast" on page 35 for details.

Adjusts the color saturation level -- the amount of each color in a
video image. See "Adjusting Color" on page 36 for details.

The function is only available when Video or S-Video with NTSC
system is selected.

Adjusts the red and green color tones of the image.
See "Adjusting Tint" on page 36 for details.

The function is only available when Video or S-Video with NTSC
system is selected.

Adjusts the image to make it look sharper or softer.
See "Adjusting Sharpness" on page 36 for details.

The function is only available when Video or S-Video with NTSC
system is selected.

Adjusts white peaking while maintaining correct color presentation.
See "Adjusting Brilliant Color" on page 36 for details.

See "Selecting a Color Temperature" on page 36 for details.

English

3D Color
Management

Save Settings
Quick Auto

Search
Color Space

Conversion

See "3D Color Management" on page 37 for details.

Saves the settings made for User 1 or User 2 mode.

See "Switching input signal" on page 29 for details.

Only action for HDMI Input source.

Operation 47

English

4. SYSTEM SETUP: Basic

menu

FUNCTION DESCRIPTION

Presentation
Timer

Language
Projector

Position

Menu
Settings

Auto Power
Off

Blank Timer

Panel Key
Lock

Sleep Timer
Splash

Screen

Reminds the presenter to finish the presentation within a certain time
frame. See "Setting the presentation timer" on page 38 for details.

Timer period

Sets a preferred length of time for presentation.

Timer display

Sets whether to display the timer on screen.

Timer position

Sets the position where the timer displays on screen.

Timer counting direction

Sets the timer counting direction.
Sets the language for the On-Screen Display (OSD) menus.

See "Using the menus" on page 25 for details.
The projector can be installed on a ceiling or behind a screen, or with

one or more mirrors.
See "Choosing a location" on page 14 for details.

Menu display time

Sets the length of time the OSD will remain active after your last key
press. The range is from 5 to 30 seconds in 5-second increments.

Menu position

Sets the On-Screen Display (OSD) menu position.
Allows the projector to turn off automatically if no input signal is

detected after a set period of time.
See "Setting Auto Power Off" on page 52 for details.

Sets the image blank time when the Blank f
eature is activated, once elapsed the image will return to the screen.
See "Hiding the image" on page 39 for details.

Disables or enables all panel key functions except POWER on the
projector and keys on the remote control.
See "Locking control keys" on page 39 for details.

Sets the auto-shutdown timer. The timer can be set to a value between
30 minutes and 12 hours.

Allows you to select which logo screen will display during projector
start-up. Four options are available: BenQ logo, Black screen, or Blue
screen.

Operation48

Quick

5. SYSTEM SETUP:

Advanced menu

Cooling

High Altitude
Mode

Audio Setting

Lamp
Settings

Security
Settings

Baud Rate

Test Pattern

Closed
Caption

Selecting On enables the function and the projector cooling time will
be shortened to a few seconds.

If you attempt to restart the projector right after the quick
cooling process, it may not be turned on successfully and will
rerun its cooling fans.

A mode for operation in high altitude areas.
See "Operating in a high altitude environment" on page 40 for details.

Mute
Volume
Power On/Off ring tone

See "Adjusting the sound" on page 41 for details.

Lamp Mode

See "Setting Lamp mode as Economic" on page 52 for details.

Reset lamp timer

See "Resetting the lamp timer" on page 56 for details.

Equivalent Lamp Hour

See "Getting to know the lamp hour" on page 52 for details on

how the total lamp hour is calculated.

Change password

You will be asked to enter the current password before changing to a
new one.
See "Utilizing the password function" on page 26 for details.

Power on Lock

Selects a baud rate that is identical with your computer’s so that you
can connect the projector using a suitable RS-232 cable and update or
download the projector’s firmware. This function is intended for
qualified service personnel.

Selecting On enables the function and the projector displays the grid
test pattern. It helps you adjust the image size and focus and check
that the projected image is free from distortion.

Selecting On enables the function. The closed captioning text is
displayed if available.

Close Caption will disable when aspect change to 16:9 or rear.

English

Reset All
Settings

Returns all settings to the factory preset values.

The following settings will still remain: Position, Phase, H. Size,
User 1, User 2, Projector Position, High Altitude Mode, Security
Settings, Baud Rate.

Operation 49

English

6. INFORMATION menu

FUNCTION DESCRIPTION

FAQ-Image
and
Installation

FAQ-

Displays possible solutions to problems you may encounter.

Features and
Service

Source

Shows the current signal source.

Picture Mode

Shows the selected mode in the PICTURE menu.

Current
System
Status

The INFORMATION menu shows you the current operating status of the projector.

Resolution

Shows the native resolution of the input signal.

Color System

Shows input system format, NTSC, PA L, SECAM, or RGB.

Equivalent Lamp Hour

Displays the number of hours the lamp has been used.

Firmware Version

Displays the firmware version of the projector.

Operation50

Maintenance

Care of the projector

Your projector needs little maintenance. The only thing you need to do on a regular basis is
to keep the lens clean.

Never remove any parts of the projector except the lamp. Contact your dealer if other parts
need replacing.

Cleaning the lens

Clean the lens whenever you notice dirt or dust on the surface.

• Use a canister of compressed air to remove dust.

• If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens

cleaner and gently wipe the lens surface.

Never use any type of abrasive pad, alkaline/acid cle aner , scouring powd er , or volati le solvent,
such as alcohol, benzene, thinner or insecticide. Using such materials or maintaining
prolonged contact with rubber or vinyl materials may result in damage to the projector surface
and cabinet material.

Cleaning the projector case

Before you clean the case, turn the projector off using the proper shutdown procedure as
described in "Shutting down the projector" on page 42 and unplug the power cord.

• To remove dirt or dust, wipe the case with a soft, lint-free cloth.

• To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral pH

detergent. Then wipe the case.

Never use wax, alcohol, benzene, thinner or other chemical detergents. These can damage the
case.

English

Storing the projector

If you need to store the projector for an extended time, please follow the instructions below:

• M ake sure the temperature and humidity of the storage area are within the

recommended range for the projector. Please refer to "Specifications" on page 59 or
consult your dealer about the range.

• Retract the adjuster feet.

• Remove the battery from the remote control.

• P ack the projector in its original packing or equivalent.

Transporting the projector

It is recommended that you ship the projector with its original packing or equivalent.
When you carry the projector yourself, please use the original box or a suitable soft carry
case.

Maintenance 51

English

Lamp information

Getting to know the lamp hour

When the projector is in operation, the duration (in hours) of lamp usage is automatically
calculated by the built-in timer. The method of calculating the equivalent lamp hour is as
follows:

Total (equivalent) lamp hour
= 1 (hours used in Economic mode) + 4/2.5 (hours used in normal mode)

See "Setting Lamp mode as Economic" below for more information on Economic mode.

To obtain the lamp hour information:

1. Press Menu/Exit and then press / until the SYSTEM SETUP: Advanced menu
is highlighted.

2. Press to highlight Lamp Settings and press MODE/ENTER. The Lamp Settings
page displays.

3. You will see the Equivalent lamp hour information displaying on the menu.

4. To leave the menu, press Menu/Exit.

You can also get the lamp hour information on the INFORMATION menu.

Extending lamp life

The projection lamp is a consumable item that normally can last up to 3500-4000 hours with
proper usage. To keep the lamp life as long as possible, you can do the following settings
via the OSD menu.

Setting Lamp mode as Economic

Using Economic mode reduces system noise and power consumption by 20%. If the
Economic mode is selected, the light output will be reduced and result in darker projected

pictures.
Setting the projector in Economic mode also extends the lamp operation life. To set

Economic mode, go into the SYSTEM SETUP: Advanced > Lamp Settings > Lamp
mode menu and press / .

Setting Auto Power Off

This function allows the projector to turn off automatically if no input source is detected
after a set period of time to prevent unnecessary waste of lamp life.

To set Auto Power Off, go into the SYSTEM SETUP: Basic > Auto Power Off menu and
press / . The time period can be set from 5 to 30 minutes in 5-minute increments. If the
preset time lengths are not suitable for your presentation, select Disable. The projector will
not automatically shut down in a certain time period.

Maintenance52

Timing of replacing the lamp

Order a new lamp at lamp.benq.com

OK

Order Replacement Lamp

Lamp > 3500 Hours

Notice

OK

Replacing Lamp soon

Lamp > 3950 Hours

Notice

Order a new lamp at lamp.benq.comOrder a new lamp at lamp.benq.com

OK

Replace Lamp Now

Lamp > 4000 Hours
Lamp usage time exceeded

Notice

Order a new lamp at lamp.benq.com

OK

Out of Lamp Usage Time

Replace lamp (Refer to user manual)
Then reset lamp timer

Notice

Order a new lamp at lamp.benq.com

When the Lamp indicator lights up red or a message appears suggesting it is time to
replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a
malfunction in the projector and in some instances the lamp may explode.

Go to http://lamp.benq.com for a replacement lamp.

The Lamp indicator light and Temperature warning light will light up if the lamp becomes too
hot. Turn the power off and let the projector cool for 45 minutes. If the Lamp or Temp indicator
still lights up after turning the power back on, please contact your dealer. See "Indicators" on

page 57 for details.

The following lamp warning displays will remind you to change the lamp.

Status Message

The lamp has been in operation for 3500 hours.
Install a new lamp for optimal performance. If the
projector is normally run with Economic selected
(See "Setting Lamp mode as Economic" on page

52), you may continue to operate the projector

until the 3950 hour lamp warning appears.

The lamp has been in operation for 3950 hours. A
new lamp should be fitted to avoid the
inconvenience when the projector runs out of lamp
time.

English

The lamp has been in operation for 4000 hours.
It is strongly recommended that you replace the

lamp at this age. The lamp is a consumable item.
The lamp brightness diminishes with use. This is
normal lamp behavior. You can replace the lamp
whenever you notice that the brightness level has
significantly diminished. If the lamp is not
replaced beforehand, it must be replaced after
4000 hours usage.

The lamp MUST be replaced before the projector
will operate normally.

Maintenance 53

English

Replacing the lamp

• If lamp replacement is performed while the projector is suspended upside-down from the

ceiling, make sure that no one is underneath the lamp socket to avoid any possible injury
or damage to the human eyes caused by fractured lamp.

• To reduce the risk of electrical shock, always turn the projector off and disconnect the

power cord before changing the lamp.

• To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes

before replacing the lamp.

• To reduce the risk of injuries to fingers and damage to internal components, use caution

when removing lamp glass that has shattered into sharp pieces.

• To reduce the risk of injuries to fingers and/or compromising image quality by touching

the lens, do not touch the empty lamp compartment when the lamp is removed.

• This lamp contains mercury. Consult your local hazardous waste regulations to dispose of

this lamp in a proper manner.

• To assure optimal performance from the projector , it i s recommended that you purc hase a

BenQ projector lamp for lamp rep lacement.

1. Turn the power off and disconnect the projector from the wall socket. If the lamp is
hot, avoid burns by waiting for approximately 45 minutes until the lamp has cooled.

2. Loosen the two captive screws on the
lamp compartment cover.

3. Remove the lamp compartment cover.

4. Loosen the two captive screws that
secure the lamp.

• Do not turn the power on with the lamp

cover removed.

• Do not insert your fingers between the

lamp and the projector. The sharp edges
inside the projector may cause injuries.

Maintenance54

5. Lift the handle so that it stands up. Use
the handle to slowly pull the lamp out
of the projector.

• Pulling it too quickly may cause the lamp

to break and scatter broken glass in the
projector.

• Do not place the lamp in locations where

water might splash on it, children can
reach it, or near flammable materials.

• Do not insert your hands into the projector

after the lamp is removed. If you touch the
optical components inside, it could cause
color unevenness and distortion of the
projected images.

6. Insert the new lamp into the lamp
compartment and make sure it fits in
the projector.

• Ensure the connectors are aligned.

• If you experience resistance, lift the lamp

and start again.

7. Tighten the screws that secure the lamp.

8. Ensure the handle is fully laid flat and
locked in place.

• Loose screw may cause a bad connection,

which could result in malfunction.

• Do not over tighten the screw.

English

9. Replace the lamp cover on the projector
and tighten the captive screws.

10. Restart the projector.

Do not turn the power on with the lamp cover removed.

Maintenance 55

English

Reset Lamp Timer?

Reset

Cancel

Notice

Resetting the lamp timer

11. After the startup logo, open the On-Screen
Display (OSD) menu. Go to the SYSTEM
SETUP: Advanced > Lamp Settings
menu. Press MODE/ENTER. The Lamp
Settings page displays. Press to
highlight Reset lamp timer and press
MODE/ENTER. A warning message
displays asking if you want to reset the lamp timer. Highlight Reset and press
MODE/ENTER. The lamp time will be reset to '0'.

Do not reset if the lamp is not new or replaced as this could cause damage.

Maintenance56

Indicators

Light Status & Description
Power Temp Lamp
Power events

Orange Off Off

Green

Flashing

Green Off Off

Orange

Flashing

Off Off

Off Off

Lamp events

Orange

Flashing

Off Off Red

Off Red

Thermal events

Off Red Off
Off Red Red
Off Red Green

Off Red Orange
Red Red Red
Red Red Green
Red Red Orange

Green Red Red
Green Red Green

System events

Off Green Red

Off Green Green

Off Green Orange

Stand-by mode
Powering up
Normal operation

The projector needs to cool for 90 seconds after the power is
turned off.

The lamp ignition retries if the lamp fails during startup.

1. The projector needs 90 seconds to cool down. Or

2. Please contact your dealer for assistance.

The projector has shutdown automatically. If you try to re­start the projector, it will shutdown again. Please contact your
dealer for assistance.

The projector has shutdown automatically. If you try to re­start the projector, it will shutdown again. Please contact your
dealer for assistance.

English

Maintenance 57

English

Troubleshooting

The projector does not turn on.

Cause Remedy

There is no power from the power
cable.

Attempting to turn the projector on
again during the cooling process.

No picture

Cause Remedy

The video source is not turned on or
connected correctly.

The projector is not correctly
connected to the input signal device.

The input signal has not been
correctly selected.

Blurred image

Cause Remedy

The projection lens is not correctly
focused.

The projector and the screen are not
aligned properly.

Plug the power cord into the AC inlet on the
projector, and plug the power cord into the
power outlet. If the power outlet has a switch,
make sure that it is switched on.

Wait until the cooling down process has
completed.

Turn the video source on and check that the
signal cable is connected correctly.

Check the connection.
Select the correct input signal with the

SOURCE key on the projector or remote
control.

Adjust the focus of the lens using the focus
ring.

Adjust the projection angle and direction as
well as the height of the unit if necessary.

Remote control does not work

Cause Remedy

The battery is out of power. Replace the battery with new one.
There is an obstacle between the

remote control and the projector.
You are too far away from the

projector.

Remove the obstacle.
Stand within 7 meters (23 feet) of the

projector.

The password is incorrect

Cause Remedy

You do not remember the password.

Troubleshooting58

Please see "Entering the password recall

procedure" on page 27 for details.

Specifications

Projector specifications

All specifications are subject to change without notice.

General

Product name Digital Projector
Model name W600+

Optical

Resolution 720p, 1280 x 720
Display system 1-CHIP DMD

Lens F/Number
Lamp 230 W lamp

Electrical

Power supply AC100–240V, 50/60 Hz (Automatic)
Power consumption

Mechanical

Dimensions 306 mm (W) x 97 mm (H) x 216 mm (D)
Weight 6.05 lbs (2.75 Kg)

Input terminal

Computer input
RGB input D-Sub 15-pin (female)
Video signal input
HDMI Screw type x 2 (V1.3)
COMPONENT RCA jack x 3
S-VIDEO Mini DIN 4-pin port x 1
VIDEO RCA jack x 1
SD/HDTV signal input Component RCA jack x 3
Audio input Mini jack x 1, RCA jack x 2

Output terminal

Audio output Mini jack x 1
Speaker 2W mono speaker

Control terminal

USB Mini B type
RS-232 serial control 9 pin x 1

Environmental Requirements

Operating temperature 5°C–35°C at sea level
Operating relative

humidity
Operating altitude

F = 2.55 to 2.72,
f = 21.35 to 24.49 mm

310W (Max)/
<1W (Standby)

10%–85% (without condensation)

• 0–1499 m at 5°C–28°C

• 1500–3000 m at 5°C–23°C (with High Altitude Mode on)

English

Specifications 59

English

216

97

75

306.00

55.20

75

164

84

115

109.22

106.09

Unit: mm

Ceiling Mount Installation

* Ceiling Mount Screws:
M4 x 14 (Max. L=14, Mi n . L = 12 )

54

98

66 196

60

Dimensions

306 mm (W) x 97 mm (H) x 216 mm (D)

Specifications60

Timing chart

Supported timing for PC input

English

Resolution Horizontal

Frequency

(kHz)

31.469 59.940 25.175 VGA_60

37.861 72.809 31.500 VGA_72

640 x 480

720 x 400 37.927 85.039 35.5 720 x 400 x 85

800 x 600

37.500 75.000 31.500 VGA_75

43.269 85.008 36.000 VGA_85

61.91 119.518 52.5

35.2 56.3 36 SVGA_56

37.879 60.317 40.000 SVGA_60

48.077 72.188 50.000 SVGA_72

46.875 75.000 49.500 SVGA_75

53.674 85.061 56.250 SVGA_85

76.302 119.972 73.25

77.425 119.854 83

48.363 60.004 65.000 XGA_60

Vertical

Frequency

(Hz)

Pixel

Frequency

(MHz)

Mode

640 x 480 120Hz

VESA DMT0D
120Hz

800 x 600 120Hz

1024 x 768

1280 x 800

56.476 70.069 75.000 XGA_70

60.023 75.029 78.750 XGA_75

68.667 84.997 94.500 XGA_85

97.551 119.989 115.5

49.7 59.8 83.5 WXGA_60

62.8 74.9 106.5 WXGA_75

71.554 84.880 122.500 WXGA_85

VESA DMT14
120Hz

Specifications 61

English

Resolution Horizontal

Frequency

(kHz)

63.981 60.020 108.000 SXGA3_60

Vertical

Frequency

(Hz)

Pixel

Frequency

(MHz)

Mode

1280 x 1024

1280 x 960

1440 x 900

1400 x 1050 65.317 59.978 121.750 SXGA+_60

1600 x 1200 75.000 60.000 162.000 UXGA

640 x 480@67Hz 35.000 66.667 30.240 MAC13

832 x 624@75Hz 49.722 74.546 57.280 MAC16

1024 x 768@75Hz 60.240 75.020 80.000 MAC19

1152 x 870@75Hz 68.68 75.06 100.000 MAC21

1024 x 576@60Hz 35.82 60 46.996

1024 x 600@60Hz 37.32 60 48.964

79.976 75.025 135.000 SXGA3_75

91.146 85.024 157.500 SXGA3_85

60.000 60.000 108 1280 x 960_60

85.938 85.002 148.500 1280 x 960_85

55.935 59.887 106.500 WXGA+_60

70.635 74.984 136.750 WXGA+_75

1024 x 576-GTF

1024 x 600-GTF

Specifications62

Supported timing for Component-YPbPr input

Signal Format Horizontal Frequency (kHz) Vertical Frequency (Hz)

480i(525i)@60Hz 15.73 59.94

480p(525p)@60Hz 31.47 59.94

576i(625i)@50Hz 15.63 50.00

576p(625p)@50Hz 31.25 50.00

720p(750p)@60Hz 45.00 60.00

720p(750p)@50Hz 37.50 50.00

1080i(1125i)@60Hz 33.75 60.00

1080i(1125i)@50Hz 28.13 50.00

1080P@60Hz 67.5 60.00

1080P@50Hz 56.26 50.00

Displaying a 1080i(1125i)@60Hz or 1080i(1125i)@50Hz signal may result in slight image

vibration.

Supported timing for Video and S-Video inputs

English

Video mode Horizontal

Frequency

(kHz)

NTSC 15.73 60 3.58

PAL 15.63 50 4.43

SECAM 15.63 50 4.25 or 4.41

PAL-M 15.73 60 3.58

PAL-N 15.63 50 3.58

PAL-60 15.73 60 4.43

NTSC4.43 15.73 60 4.43

Vertical

Frequency

(Hz)

Color sub-carrier

Frequency

(MHz)

Specifications 63

English

Supported timing for HDMI (HDCP) input

Resolution Horizontal

Frequency

(kHz)

720 x 400 37.927 85.039 35.5 720 x 400_85

31.469 59.940 25.175 VGA_60

37.861 72.809 31.500 VGA_72

640 x 480

800 x 600

37.500 75.000 31.500 VGA_75

43.269 85.008 36.000 VGA_85

61.91 119.518 52.5

35.2 56.3 36 SVGA_56

37.879 60.317 40.000 SVGA_60

48.077 72.188 50.000 SVGA_72

46.875 75.000 49.500 SVGA_75

53.674 85.061 56.250 SVGA_85

76.302 119.972 73.25

77.425 119.854 83

48.363 60.004 65.000 XGA_60

Vertical

Frequency

(Hz)

Pixel

Frequency

(MHz)

Mode

640 x 480 120Hz

VESA DMT0D
120Hz

800 x 600 120Hz

1024 x 768

1280 x 800

1280 x 1024

Specifications64

56.476 70.069 75.000 XGA_70

60.023 75.029 78.750 XGA_75

68.667 84.997 94.500 XGA_85

97.551 119.989 115.5

49.7 59.8 83.5 WXGA_60

62.8 74.9 106.5 WXGA_75

71.554 84.880 122.500 WXGA_85

63.981 60.020 108.000 SXGA_60

79.976 75.025 135.000 SXGA_75

91.146 85.024 157.500 SXGA_85

VESA DMT14
120Hz

Resolution Horizontal

Frequency

(kHz)

Vertical

Frequency

(Hz)

Pixel

Frequency

(MHz)

Mode

English

1280 x 960

1440 x 900

1400 x 1050 65.317 59.978 121.750 SXGA+_60

1600 x 1200 75.000 60.000 162.000 UXGA

640 x 480@67Hz 35.000 66.667 30.240 MAC13

832 x 624@75Hz 49.722 74.546 57.280 MAC16

1024 x 768@75Hz 60.241 75.020 80.000 MAC19

1152 x 870@75Hz 68.68 75.06 100.000 MAC21

VIDEO

60.000 60.000 108 1280 x 960_60

85.938 85.002 148.500 1280 x 960_85

55.935 59.887 106.500 WXGA+_60

70.635 74.984 136.750 WXGA+_75

31.47 60 27 480p

31.25 50 27.000 576p

37.50 50 74.25 720p_50

45.00 60 74.25 720p_60

28.13 50 74.25 1080i_50

33.75 60 74.25 1080i_60

67.5 60 148.5 1080p

56.26 50 148.5 1080p

1080P@24Hz 27 24 74.25 1080P@24Hz

1080P@25Hz 28.12 25 74.25 1080P@25Hz

1080P@30Hz 33.75 30 74.25 1080P@30Hz

Displaying a 1080i_50 or 1080i_60 signal may result in slight image vibration.

Specifications 65

English

Warranty and Copyright information

Limited warranty

BenQ warrants this product against any defects in material and workmanship, under normal

usage and storage.

Proof of purchase date will be required with any warranty claim. In the event this product is

found to be defective within the warranty period, BenQ's only obligation and your exclusive

remedy shall be replacement of any defective parts (labor included). To obtain warranty

service, immediately notify the dealer from which you purchased the product of any defects.

Important: The above warranty shall be void if the customer fails to operate the product in

accordance with BenQ's written instructions, especially the ambient humidity must be in-

between 10% and 85%, temperature in-between 5°C and 28°C, altitude lower than 4920

feet, and avoiding to operate the projector in a dusty environment. This warranty gives you

specific legal rights, and you may have other rights which vary from country to country.

For other information, please visit www.BenQ.com.

Copyright

Copyright 2009 by BenQ Corporation. All rights reserved. No part of this publication may

be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any

language or computer language, in any form or by any means, electronic, mechanical,

magnetic, optical, chemical, manual or otherwise, without the prior written permission of

BenQ Corporation.

Disclaimer

BenQ Corporation makes no representations or warranties, either expre ssed or implied, with

respect to the contents hereof and specifically disclaims any warranties, merchantability or

fitness for any particular purpose. Further, BenQ Corporation reserves the right to revise

this publication and to make changes from time to time in the contents hereof without

obligation to notify any person of such revision or changes.

*DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments. Others

are copyrights of their respective companies or organizations.

Warranty and Copyright information66

Regulation statements

FCC statement

CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

— Reorient or relocate the receiving antenna.
— Increase the distance between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

— Consult the dealer or an experienced radio/TV technician for help.

EEC statement

This machine was tested against the 89/336/EEC (European Economic Community) for

EMC (Electronic Magnetic Compatibility) and fulfills these requirements.

WEEE directive

Disposal of Waste Electrical and Electronic Equipment by users in private

households in the European Union.

This symbol on the product or on the packaging indicates that this can not

be disposed of as household waste. You must dispose of your waste

equipment by handling it over to the applicable take-back scheme for the

recycling of electrical and electronic equipment. For more information

about recycling of this equipment, please contact your city office, the

shop where you purchased the equipment or your household waste

disposal service. The recycling of materials will help to conserve natural

resources and ensure that it is recycled in a manner that protects human

health and environment.

English

Regulation statements 67

English

Accessibility Requirements for Rehabilitation Act of 1973,
Section 508

BenQ's commitment to accessible products allows us to support government in making

accessible technology choices BenQ's LCD monitors and projectors are compliant with

Section 508 guidelines by including the assistive features as below:

• BenQ's monitors have colored "Power" indicators. While the indicator shows green, it
means that the monitor is using the full power. While the indicator shows yellow or
amber, it means that the monitor is in suspend or sleep mode and is using less than 2
watts of electricity.

• BenQ's monitors have a variety of settings of pre-programmed flicker-free timing to
make the screen shown on the monitor readily accessible. The default timing setting is
automatically turned on every time the monitor is powered up, and thus reduces the
hassle of user intervention.

• BenQ's monitors and projectors have options for brightness and contrast adjustments
that text and images could be displayed differently to meet the demands of the visually
impaired. Other similar adjustments are also available by using the On-Screen Display
(OSD) controls on the products.

• BenQ's monitors and projectors include user-selectable color controls, such as color
temperature selections (Monitor: 5800K, 6500K and 9300K, Projector: 5500K, 6500K,
7500K and 9300K), with a wide range of contrast levels.

• BenQ's multimedia monitors and projectors usually have one or two speakers for audio
performance which allow users (including hearing impaired) to interact with the
computer systems connected. Speaker controls are typically located on the front-panel.

• Firmware of BenQ's monitors and projectors contain unique product information that
helps computer systems to identify BenQ products and activate their Plug-and-Play
function when connected.

• All BenQ's monitors and projectors are compatible with the PC99 standard. For
example, connectors are color-coded to help users easily connecting products to
computer systems correctly.

• Some models of BenQ's monitors and projectors contain additional USB and DVI ports
for connection to more devices such as a special headphone to assist the hearing
impaired.

• All BenQ monitors and projectors come with user manuals on compact discs which
could be easily read by commercial software such as Adobe Reader via a connected
computer system. These documents are also available on the BenQ's web site
(www.BenQ.com). Other types of documents may be available upon requests.

• BenQ's customer service provides answers and assistance to all our customers through
phone calls, facsimiles, e-mails, or web sites.

Regulation statements68
