Benq DC 2110 User Manual
Digital Camera 2110
User’s Manual
Copyright
Copyright (c) 2002 by Benq Corporation. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system or translated
into any language or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual or otherwise, without prior written permission from Benq Corporation.
Brands and product names are trademarks or registered trademarks of their respective
companies.
Disclaimer
Benq makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Benq assumes no responsibility for any error that may appear in this document. Benq
makes no commitment to update nor to keep current the information contained in this
document.
Taking care of your camera
• Do not use your camera over the following environmental range: temperature: O
to 40
C, relative humidity: 45% ~ 85%.
• Do not use or store your camera in environments listed below:
Direct sunlight.
High humidity and dusty places.
Next to the air conditioner, electric heater or the other heat sources.
In a closed car that is directly under the sun.
Avoid shaky places.
• If your camera becomes wet, wipe it with dry cloth as soon as possible.
• Salt of seawater may cause severe camera damage.
• Do not use organic solvents, such as alcohol, etc., to clean your camera.
• If the lens or viewfinder is dirty, please use the lens brush or soft cloth to clean the
lens. Do not touch the lens with your fingers.
• To prevent electrical shock, do not attempt to disassemble or repair your camera by
yourself.
• Water may cause a fire or electric shock. Therefore, please store your camera in a dry
place.
• Do not use your camera outdoors when it is raining or snowing.
• Do not use your camera in the water.
• If the foreign substance or water gets in your camera, please tum the power off imme-
diately and disconnect the batteries and the transformer. Remove the foreign substance or water, and send it to the maintenance center.
• Transfer the data to the computer as soon as possible to avoid losing your image data.
C
Benq DC 2110 User’s Manual
1. Touring your DC 2110 ..........................1
1.1. Checking package contents ..................................1
1.2. Parts of the DC 2110 and their names ..............1
1.2.1. Front View .......................................................................... 1
1.2.2. Rear View ............................................................................ 2
1.2.3. Connection Ports ............................................................ 2
1.2.4. Bottom View ...................................................................... 2
2. Preparing your DC 2110 for using .......3
2.1. Installing batteries and memory card .................3
2.2 Insert And Remove The SmartMediaTMCard .....4
2.3. LCD Panel Indicator ...............................................5
2.4. Flash Mode ................................................................5
3. Using the DC 2110 ................................6
3.1. Working Mode ........................................................6
3.1.1. Recording Mode ................................................................6
3.1.2. Playback Mode ................................................................... 7
3.1.3. Video Mode ...................................................................... 10
3.1.4. Setup Mode ........................................................................10
3.1.5. PC Connection Mode .....................................................11
3.2. Taking Pictures ...................................................... 12
4. PC Dependent Features .....................14
4.1. Installing digital camera software ......................14
4.2. The software of this installation CD .................15
4.3. Connect to PC ......................................................16
1
Benq DC 2110 User’s Manual
5. Troubleshooting ..............................15
6. Specifications ...................................16
7. Service information ........................18
2
Benq DC 2110 User’s Manual
1. T
OURING YOUR
DC 2110
1.1. Checking package contents
The package should include the following items:
DC 2110 digital camera
2 pcs of AA Battery
Hand Strap
Camera pouch
SmartMedia
TM
card
User’s Manual
USB cable
DC 2110 software CD-
1.2. Parts of the DC 2110 and their names
1.2.1. Front View
Shutter Button
LCD Panel
TV cable
Mode Dial
Self-timer Indicator LED
Hand Stop
Lens
Macro Button
Flash Button
Viewfinder
Flash
Connection Ports Cover
1
Benq DC 2110 User’s Manual
1.2.2. Rear View
Viewfinder
AF LED
Flash LED
TFT LCD Monitor
1.2.3. Connection Ports
LCD Button
Menu/ Enter button
Power Switch
Direction Button
(Up/Down/Right/Left)
Video Connection Terminal (Video Output
USB Connection Terminal
DC Input Connection Point (DC 3V
Memory Card Cover
1.2.4. Bottom View
Battery cover
Mode Dial
Recording Mode ( )
Playback Mode ( ) PC Connection Mode ( )
Video Mode ( )
Strap Eyelet
Memory Card Slot
Card Cover Open Lever
Tripod socket
Setup Mode ( )
2
Benq DC 2110 User’s Manual
2. P
REPARING YOUR
DC 2110
FOR USING
2.1. Installing batteries and memory card
Follow the steps below to install battery and memory card.
If batteries are used:
1. Open the Battery Cover.
2. Load the batteries into the battery
chamber following the polarity
indications(+,
3. Close the Battery Cover until
you hear a click sound.
On the LCD Panel you can see the battery status as below:
( ) Batteries are with sufficient electricity power to support the camera's operations.
( ) Batteries are about to drain soon. Please prepare new batteries.
( ) Batteries drained. Replace with new batteries.
If an AC adapter is used:
1. Make sure the AC adapter is 3V/2.0A.
2. Plug the AC adapter into the DC Power Terminal.
• Batteries may lose electricity power if kept inside the camera for a long time without using.
Please remove the batteries if the batteries are expected not to be in use for a long period.
• Do not use manganese batteries as they cannot supply sufficient power to support the
camera's operations.
• Batteries may not be able to work normally under 0
• Please avoid using the TFT LCD Monitor if possible. Using TFT LCD Monitor will need
considerable electricity power which may drain the batteries sooner than expected.
• Do not mix to use old and new or different types of batteries.
• It is normal that the temperature of the camera body rises when used for a long period.
• It is suggested to use an AC adapter if you expect to use the camera for a long period.
• Please make sure the AC adapter meets the specification requirement which is 3V/2.0A.
• Please make sure to switch off the power first before you unplug the AC adapter from the
camera.
_
).
Note
Note
o
C.
3
Benq DC 2110 User’s Manual
2.2 Insert And Remove The SmartMedia
Insert The SmartMedia
(1) Pull down the Card Cover Open Lever.
(2) Insert the SmartMedia
(3) Close the Memory Card Cover until you hear a click sound.
Remove The SmartMediaTM Card
(1) Switch off the power.
(2) Pull down the Card Cover Open Lever.
(3) Remove the SmartMedia
Cover until you hear a click sound.
TM
Card
TM
card.
TM
card and close the Memory Card
TM
Card
If a new SmartMedia
details.
• Images stored in the SmartMediaTM card may be ruined or damaged if you turn off the camera while it is in process of reading, formatting...etc.
•SmartMedia
please avoid any strikes.
• Please do not place the SmartMedia
tronic or magnetic fields such like loud speakers or TV receivers.
• Please avoid using the camera in high or low temperatures.
• Please keep the camera away from dirt, sand and water or substances that may cause
malfunction of the memory card.
• Please clean the camera with a soft cloth.
• Please keep the SmartMedia
SmartMedia
• Please make sure you switch off the power before you remove the SmartMedia
TM
card is used, you'll have to format it first. Please refer to page 9 for
TM
cards are a delicate electronic device. Please do not bend or drop it and
TM
card may get warm after use.
TM
Note
Note
TM
card in or near to an environment of strong elec-
card in its plastic bag when it's not in use. It's normal that the
TM
card.
4
