PD Series LCD Monitor
User Manual
Page 2

Copyright

Copyright © 2018 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

Disclaimer

BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of BenQ Corporation to notify any person of such revision or changes.
The performance of flicker-free may be affected by external factors such as poor cable quality, unstable power supply, signal interference, or poor grounding, and not limited to the above mentioned external factors. (Applicable for flicker-free models only.)
BenQ ecoFACTS
BenQ has been dedicated to the design and development of greener product as part of its aspiration to realize the ideal of the "Bringing Enjoyment 'N Quality to Life" corporate vision with the ultimate goal to achieve a low-carbon society. Besides meeting international regulatory requirement and standards pertaining to environmental management, BenQ has spared no efforts in pushing our initiatives further to incorporate life cycle design in the aspects of material selection, manufacturing, packaging, transportation, using and disposal of the products. BenQ ecoFACTS label lists key eco-friendly design highlights of each product, hoping to ensure that consumers make informed green choices at purchase. Check out BenQ's CSR Website at
http://csr.BenQ.com/ for more details on BenQ's environmental commitments and
achievements.
2
Page 3

Power Safety

0~3000 m10~90 %0~40 C 0~12000 m10~60 %-20~60 C
Please follow these safety instructions for best performance, and long life for your monitor.
• The AC plug isolates this equipment from the AC supply.
• The power supply cord serves as a power disconnect device for pluggable equipment. The socket outlet should be installed near the equipment and be easily accessible.
• This product should be operated from the type of power indicated on the marked label. If you are not sure of the type of power available, consult your dealer or local power company.
• The Class I pluggable equipment Type A must be connected to protective earth.
• An approved power cord greater or equal to H03VV-F or H05VV-F, 2G or 3G, 0.75mm2 must be used.
For Germany only:
• (If the weight of the product is less than or equal to 3 kg) An approved power cord greater or
equal to H03VV-F, 3G, 0.75mm2 must be used.
• (If the weight of the product is more than 3 kg) An approved power cord greater or equal to
H05VV-F or H05RR-F, 3G, 0.75mm2 must be used.
• (If a remote control is provided) RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
For models with adapter:
• Use only the power adapter supplied with your LCD Monitor. Use of another type of power adapter will result in malfunction and/or danger.
• Allow adequate ventilation around the adapter when using it to operate the device or charge the battery. Do not cover the power adapter with paper or other objects that will reduce cooling. Do not use the power adapter while it is inside a carrying case.
• Connect the power adapter to a proper power source.
• Do not attempt to service the power adapter. There are no service parts inside. Replace the unit if it is damaged or exposed to excess moisture.
Care And Cleaning
• Do not place the monitor face down on the floor or a desk surface directly. Otherwise, scratches on the panel surface may occur.
3
Page 4
• The equipment is to be secured to the building structure before operation.
• (For models that support wall or ceiling mounting)
• Install your monitor and monitor mounting kit on a wall with flat surface.
• Ensure that the wall material and the standard wall mount bracket (purchased separately) are stable enough to support the weight of the monitor.
• Turn off the monitor and the power before disconnecting the cables from the LCD monitor.
• Always unplug the product from the power outlet before cleaning. Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid using any liquid, aerosol or glass cleaners.
• Slots and openings on the back or top of the cabinet are for ventilation. They must not be blocked or covered. Your monitor should never be placed near or over a radiator or heat sources, or in a built-in installation unless proper ventilation is provided.
• Do not place heavy loads on the monitor to avoid possible personal injury or damage to the monitor.
• Consider keeping the box and packaging in storage for use in the future when you may need to transport the monitor.
• Refer to the product label for information on power rating, manufacture date, and identification markings.
Servicing
• Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltages or other risks. If any of the above mentioned misuse or other accident such as dropping or mishandling occurs, contact qualified service personnel for servicing.
• Contact your place of purchase or visit the local website from www.BenQ.com for more support.
Caution
• The monitor should be 50 ~ 70 cm (20 ~ 28 inches) away from your eyes.
• Looking at the screen for an extended period of time causes eye fatigue and may deteriorate your eyesight. Rest your eyes for 5 ~ 10 minutes for every 1 hour of product use.
• Reduce your eye strain by focusing on objects far way.
• Frequent blinking and eye exercise help keep your eyes from drying out.
4
Page 5
Typographics
Icon / Symbol Item Meaning
Warning Information mainly to prevent the damage to components,
data, or personal injury caused by misuse and improper operation or behavior.
Tip Useful information for completing a task.
Note Supplementary information.
In this document, the steps needed to reach a menu may be shown in condensed form, for example: Menu > System > Information.
5
Page 6
Table of Contents
Copyright ......................................................................................................................................2
Getting started .............................................................................................................................8
Getting to know your monitor ............................................................................................. 10
Front view.................................................................................................................................................. 10
Back view ................................................................................................................................................... 11
Connections .............................................................................................................................................. 12
How to assemble your monitor hardware ........................................................................ 14
How to detach the stand ....................................................................................................................... 20
Adjusting the monitor height ................................................................................................................ 22
Rotating the monitor .............................................................................................................................. 23
Viewing angle adjustment ....................................................................................................................... 24
Using the monitor wall mounting kit ................................................................................................... 25
Getting the most from your BenQ monitor ...................................................................... 26
How to install the monitor on a new computer .............................................................................. 27
How to upgrade the monitor on an existing computer ................................................................. 28
How to install on Windows 10 system .............................................................................................. 29
How to install on Windows 8 (8.1) system .......................................................................................30
How to install on Windows 7 system ................................................................................................ 31
How to adjust your monitor ................................................................................................. 32
The control panel..................................................................................................................................... 32
5-way controller and basic menu operations .................................................................................... 33
Working with the hot keys.................................................................................................................... 35
Hotkey Puck G2 and its basic operations .......................................................................................... 37
Adjusting Display Mode....................................................................................................................... 39
Choosing an appropriate color mode................................................................................................. 39
Working with two video sources (KVM Switch).......................................................................... 39
Video source selection in PIP mode.................................................................................................... 41
Video source selection in PBP mode................................................................................................... 41
Connecting multiple monitors (Thunderbolt™ 3 daisy chaining) ................................................ 42
Working with HDR technology............................................................................................................ 43
Working with two color settings on the same image (DualView) ............................................ 44
Navigating the main menu ...................................................................................................... 45
Input menu ............................................................................................................................................... 46
Picture menu .......................................................................................................................................... 48
Color menu .............................................................................................................................................. 50
Audio menu ............................................................................................................................................. 54
KVM Switch menu ................................................................................................................................ 55
Custom Key menu ................................................................................................................................ 57
System menu .......................................................................................................................................... 59
6
Page 7
Troubleshooting ........................................................................................................................63
Frequently asked questions (FAQ)....................................................................................................... 63
Need more help?...................................................................................................................................... 65
10/9/18
Page 8

Getting started

When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement.
BenQ LCD Monitor
Monitor Stand
Monitor Base
Back Cover
Quick Start Guide
CD-ROM
Power Cord (Picture may differ from product supplied for your region.)
8 Getting started
Page 9
Video Cable: DP to mini DP
Video Cable: HDMI
Video Cable: Thunderbolt™ 3
A Thunderbolt™ 3 passive cable that supports up to 40 Gb/s data transfer.
Video Cable: USB-C™ (Optional accessory, purchased separately)
The length of USB-C™ cable should be less than 1 meter to make the connection easy.
USB Cable
Hotkey Puck G2
• Available accessories and the pictures shown here may differ from the actual contents and the product supplied for your region. And the package contents may subject to change without prior notice. For cables that are not supplied with your product, you can purchase them separately.
• Consider keeping the box and packaging in storage for use in the future when you may need to transport the monitor. The fitted foam packing is ideal for protecting the monitor during transport.
Always keep the product and accessories out of reach of small children.
9 Getting started
Page 10

Getting to know your monitor

1

Front view

1. Power LED indicator
10 Getting to know your monitor
Page 11

Back view

2 3
4
5678910111213
15
5
14
2. Power button
3. Control keys
4. Headphone jack
5. USB 3.1 Gen 2 ports (downstream; connecting to the USB devices)
6. USB 3.1 Gen 2 port (upstream; connecting to the PC)
7. Hotkey Puck G2 socket
8. HDMI1 socket
9. HDMI2 socket
10. DisplayPort socket
11. Thunderbolt™ 3 socket 1 (*)
12. Thunderbolt™ 3 socket 2 (**)
13. Kensington lock slot
14. AC power input jack
15. USB-C™ port (for data transfer only)
• *: 1) Thunderbolt™ 3 with up to 40Gbs bandwidth; 2) supports up to two 4K monitors by daisy chain; 3) power delivery up to 85W. See Power delivery of Thunderbolt™ 3 ports on your monitor on page 13 for more information.
• **: 1) Thunderbolt™ 3 with up to 40Gbs bandwidth; 2) supports up to two 4K monitors by daisy chain; 3) power delivery up to 15W. See Power delivery of Thunderbolt™ 3 ports on your monitor on page 13 for more information.
• With Thunderbolt™ 3 video input, the USB data transmission speed is up to USB 3.1 Gen 2. With DP or HDMI video input, the USB data transmission speed is up to USB 3.1 Gen 1.
• Above diagram may vary depending on the model.
• Picture may differ from product supplied for your region.
11 Getting to know your monitor
Page 12
33
33
PC / Notebook
Headphone/ Speakers
USB peripherals
External graphics card / storage / monitor
USB peripherals

Connections

The following connection illustrations are for your reference only. For cables that are not supplied with your product, you can purchase them separately.
For detailed connection methods, see page 16 - 18.
12 Getting to know your monitor
Page 13
Connectivity of Thunderbolt™ 3 port on your monitor
The Thunderbolt™ 3 ports on your product are compatible with Thunderbolt™ 3 and USB-C™ connectors. The connectivity, however, may vary depending on the cable used and the capability of the connected computer.
Computer’s port
for connection
Thunderbolt™ 3 port
Cable for connection
• Passive Thunderbolt™ 3 cable (as provided)
Monitor’s port for
connection
Thunderbolt™ 3 port
Connectivity
OK
• USB-C™ cable (purchased separately)
USB-C™ port Passive Thunderbolt™ 3
cable (as provided)
USB-C™ port Active Thunderbolt™ 3
cable (purchased
Thunderbolt™ 3 port
Thunderbolt™ 3 port
OK
OK (*)
separately)
USB-C™ port USB-C™ cable
(purchased separately)
• The length of USB-C™ cable should be less than 1 meter to make the connection easy.
• *: The connectivity is available only when working with compatible Intel IC launched in 2019. Make sure you have a compatible IC before purchasing the cable.
Thunderbolt™ 3 port
OK
Power delivery of Thunderbolt™ 3 ports on your monitor
With the power delivery function, your monitor helps supply power to the connected Thunderbolt™ 3 devices. Available power varies by port. Make sure the devices are connected to the appropriate ports to be activated properly with sufficient power.
Thunderbolt™ 1
()
Thunderbolt™ 2
()
5V / 3A 5V / 3A
9V / 3A N/A
15V / 3A N/A
20V / 4.25A N/A
13 Getting to know your monitor
Page 14

How to assemble your monitor hardware

1
• If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so.
• The following illustrations are for your reference only. The location and available input and output jacks may vary depending on the purchased model.
Avoid finger pressure on the screen surface.
1. Attach the monitor base.
Please be careful to prevent damage to the monitor. Placing the screen surface on an object like a stapler or a mouse will crack the glass or damage the LCD substrate voiding your warranty. Sliding or scraping the monitor around on your desk will scratch or damage the monitor surround and controls.
Protect the monitor and screen by clearing a flat open area on your desk and placing a soft item like the monitor packaging bag on the desk for padding.
Gently lay the screen face down on a flat clean padded surface.
Attach the monitor stand to the monitor base as illustrated.
Raise the thumbscrew lid and tighten the thumbscrew as illustrated. Then push the lid back.
14 How to assemble your monitor hardware
2
Page 15
Lift the end of the monitor stand high and orient and align the stand arm with the monitor, then push them together until they click and lock into place.
Gently attempt to pull them back apart to check that they have properly engaged.
Carefully lift the monitor, turn it over and place it upright on its stand on a flat even surface.
You might want to adjust the monitor stand height. See
Adjusting the monitor height on page 22 for more
information.
2
1
You should position the monitor and angle the screen to minimize unwanted reflections from other light sources.
Your monitor is an edge-to-edge monitor and should be handled with care. Avoid finder pressure on the screen surface. Adjust the screen angle by placing your hands on the top and on the bottom of the monitor as illustrated. Excessive force on the display is prohibited.
15 How to assemble your monitor hardware
Page 16
2. Connect the PC video cable.
3
3
3
3
or or or
The video cables included in your package and the socket illustrations in this document may vary depending on the product supplied for your region.
1. Establish a video cable connection.
• Connect the plug of the HDMI cable to the HDMI port on the monitor.
• Connect the plug of the DP cable to the monitor video socket.
• Connect the plug of the Thunderbolt™ 3 cable to the monitor video socket. Connect to the
if power supply to the video source is required.
port
2. Connect the other end of the video cable to an appropriate port of a digital output source (e.g., a computer).
3. Tighten all finger screws to prevent the plugs from accidentally falling out during use.
(DP input only) After the monitor and the computer are powered on, if the image is not displayed, disconnect the DP cable. Connect the monitor to any video source other than DP first. Go to System > Advanced > DisplayPort on the OSD menu of the monitor and change the setting from unplug the current video cable and re-connect the DP cable. To go to the OSD menu, see 5-way controller and
basic menu operations on page 33.
1.4 to 1.1. Once the setting is done,
16 How to assemble your monitor hardware
Page 17
3. Connect the headphone.
You may connect the headphones to the headphone jack.
4. Connect the USB devices.
1. Connect the USB cable between the PC and the monitor (via the upstream USB port). This upstream USB port transmits data between the PC and the USB devices connected to the mon­itor. Note that this step is not required if the video source is from the Thunderbolt™ 3 input.
2. Connect USB devices via other USB ports (downstream) on the monitor. These downstream USB ports transmit data between the connected USB devices and the upstream port.
The USB-C™ port on PD3220U works as downstream port and connects with USB devices.
17 How to assemble your monitor hardware
Page 18
5. Connect the Hotkey Puck G2 to the monitor.
1
2
Connect the Hotkey Puck G2 to the mini USB port (exclusively or Hotkey Puck G2 connection) on the rear of the monitor. For more information on Hotkey Puck G2, see Hotkey Puck G2 and its basic
operations on page 37.
6. Connect the power cable to the monitor.
Plug one end of the power cord into the socket labelled
on the rear of the monitor. Do not connect the
other end to a power outlet just yet.
7. Install the back cover.
Align the back cover with the holes on the back of the monitor, and press both sides and the upper part of the cover against the holes to lock it into place as illustrated.
Push the lower part of the back cover toward the monitor to secure it.
8. Organize the cables.
Route the cables via the cable clip.
18 How to assemble your monitor hardware
Page 19
9. Connect-to and turn-on the power.
1
2
Plug the other end of the power cord into a power outlet and turn it on.
Picture may differ from product supplied for your region.
Turn on the monitor by pressing the power button on the monitor.
Turn on the computer too, and press the 5-way controller to select an input source.
Follow the instructions in Getting the most from your
BenQ monitor on page 26 to install the monitor
software.
To extend the service life of the product, we recommend that you use your computer's power management function.
19 How to assemble your monitor hardware
Page 20

How to detach the stand

1
2
1. Prepare the monitor and area.
Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable.
2. Remove the back cover.
Remove the back cover from its bottom as illustrated. Unplug all cables carefully.
Protect the monitor and screen by clearing a flat open area on your desk and placing a soft item like a towel on the desk for padding, before laying the screen face down on a flat clean padded surface.
Please be careful to prevent damage to the monitor. Placing the screen surface on an object like a stapler or a mouse will crack the glass or damage the LCD substrate voiding your warranty. Sliding or scraping the monitor around on your desk will scratch or damage the monitor surround and controls.
3. Remove the monitor stand.
While pressing and holding the quick release button, detach the stand from the monitor.
If the monitor stand is removed for wall mounting, see Using
the monitor wall mounting kit on page 25 and the
instruction manual of your wall mount bracket (purchased separately) for more information.
20 How to assemble your monitor hardware
Page 21
4. Remove the monitor base.
1
Release the thumbscrew on the bottom of the monitor base.
And then detach the base from the stand.
2
21 How to assemble your monitor hardware
Page 22

Adjusting the monitor height

To adjust the monitor height, hold both the left and the right sides of the monitor to lower the monitor or lift it up to the desired height.
• Avoid placing hands on the upper or lower part of the height-adjustable stand or at the bottom of the monitor, as ascending or descending monitor might cause personal injuries. Keep children out of reach of the monitor while performing this operation.
• If the monitor has been rotated to portrait mode and height adjustment is desired, you should be noted that the wide screen will keep the monitor from being lowered to its minimum height.
22 How to assemble your monitor hardware
Page 23

Rotating the monitor

90
1. Pivot the display.
Before rotating the monitor with a portrait viewing orientation, the display has to be rotated 90 degrees.
Right-click the desktop and select Screen resolution from the popup menu. Select Portrait in
Orientation, and apply the setting.
Depending on the operating system on your PC, different procedures should be followed to adjust the screen
orientation. Refer to the help document of your operating system for details.
2. Fully extend the monitor and tilt it.
Gently lift the display up and extend it to the maximum extended position. Then tilt the monitor.
The monitor should be vertically extended to allow to rotate
from landscape to portrait mode.
3. Rotate the monitor 90 degrees clockwise as illustrated.
23 How to assemble your monitor hardware
Page 24
To avoid the edge of the LCD display hitting the monitor base surface while it is being
rotated, do tilt and extend the monitor to the highest position before you start to rotate the display. You should also make sure there are no obstacles around the monitor and there is enough room for cables.
4. Adjust the monitor to the desired viewing angle.

Viewing angle adjustment

You may position the screen to the desired angle with the monitor tilt, swivel, and height adjustment functions. Refer to the product specifications for details.
24 How to assemble your monitor hardware
Page 25

Using the monitor wall mounting kit

The back of your LCD monitor has a VESA standard mount with 100mm pattern, allowing the installation of a wall mount bracket. Before starting to install a monitor wall mounting kit, please read the precautions carefully.
Precautions
• Install your monitor and monitor mounting kit on a wall with flat surface.
• Ensure that the wall material and the standard wall mount bracket (purchased separately) are stable enough to support the weight of the monitor. Refer to the product specifications for weight information.
• Turn off the monitor and the power before disconnecting the cables from the LCD monitor.
1. Remove the monitor stand.
Lay the screen face down on a clean and well-padded surface. Detach the monitor stand as instructed in How
to detach the stand on page 20.
Use a cross-pointed screwdriver to release the screws that fixing the back cover to the monitor.The use of a magnetic-head screwdriver is recommended to avoid of losing the screws.
In case you intend to use your monitor on the stand in the future, please keep the monitor base, monitor stand, and screws somewhere safe for future use.
2. Follow the instruction manuals of the wall mount bracket you purchased to complete the installation.
Use four M4 x 10 mm screws to fix a VESA standard wall mount bracket to the monitor. Make sure that all screws are tightened and secured properly. Consult a professional technician or BenQ service for wall mount installation and safety precautions.
25 How to assemble your monitor hardware
Page 26

Getting the most from your BenQ monitor

To gain the most benefit from your new BenQ LCD monitor, you should install the custom BenQ LCD Monitor driver software as provided on the BenQ LCD Monitor CD-ROM.
The circumstances under which you connect and install your BenQ LCD Monitor will determine which process you need to follow to successfully install the BenQ LCD Monitor driver software. These circumstances relate to which version of Microsoft Windows you are using, and whether you are connecting the monitor and installing the software onto a new computer (without existing monitor driver software), or whether you are upgrading an existing installation (which already has existing monitor driver software) with a newer monitor.
In either case however, the very next time you turn on your computer (after connecting the monitor to your computer), Windows will automatically recognize the new (or different) hardware, and will launch its
Follow the wizard instructions until it asks you to select a monitor model. At that point, click the
Have Disk button, insert the BenQ LCD Monitor CD-ROM and select the appropriate
monitor model. Further details and step-by-step instructions for either an automatic (new) or upgrade (existing) installation, see:
Found New Hardware wizard.
How to install the monitor on a new computer on page 27.
How to upgrade the monitor on an existing computer on page 28.
• If you require a User Name and Password to login to your Windows computer, you must be logged on as an Administrator or as a member of the Administrators group in order to install the monitor driver software. Furthermore, if your computer is connected to a network which has security access requirements, network policy settings may prevent you from installing software on your computer.
• To check the name of the purchased model, refer to the specification label on the back of the monitor.
26 Getting the most from your BenQ monitor
Page 27

How to install the monitor on a new computer

This instruction details the procedure for selecting and installing the BenQ LCD Monitor driver software on a new computer which has never had a monitor driver installed before. This instruction is only suitable for a computer which has never been used before, and for which the BenQ LCD Monitor is the first ever monitor to be connected to it.
If you are adding the BenQ LCD Monitor to an existing computer that has already had another monitor connected to it (and has monitor driver software installed), you should not be following these instructions. You should instead be following the instructions for How to upgrade the monitor on an existing computer.
1. Follow the instructions in How to assemble your monitor hardware on page 14.
When Windows starts, it will automatically detect the new monitor and launch the Found New
Hardware Wizard. Follow the prompts until it displays the option to Install Hardware Device Drivers.
2. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer.
3. Check Search for a suitable driver for my device option, and click Next.
4. Check the option for CD-ROM drives (uncheck all others) and click Next.
5. Look to confirm that the wizard has selected the correct name of your monitor and click
Next.
6. Click Finish.
7. Restart the computer.
To find the suitable driver files for the purchased model, refer to the following table.
Driver files Suitable models
PD3220U PD3220U / PD3220UE
27 Getting the most from your BenQ monitor
Page 28

How to upgrade the monitor on an existing computer

This instruction details the procedure for manually updating the existing monitor driver software on your Microsoft Windows computer. It is currently tested as compatible for Windows 10, Windows 8 (8.1), and Windows 7 Operating System (OS).
The BenQ LCD Monitor driver for your model may well function perfectly with other versions of Windows, however, as at the time of writing, BenQ has done no testing of this driver on other versions of Windows and cannot guarantee its operation on those systems.
Installing monitor driver software involves selecting an appropriate information file (.inf) on the BenQ LCD Monitor CD-ROM for the particular model monitor you have connected, and letting Windows install the corresponding driver files from the CD. You need only steer it in the right direction. Windows has an Upgrade Device Driver Wizard to automate the task and guide you through the file selection and installation process.
See:
How to install on Windows 10 system on page 29.
How to install on Windows 8 (8.1) system on page 30.
How to install on Windows 7 system on page 31.
28 Getting the most from your BenQ monitor
Page 29

How to install on Windows 10 system

1. Open Display Properties.
Go to Start, Settings, Devices, Devices and Printers and right-click the name of your monitor from the menu.
2. Select Properties from the menu.
3. Click the Hardware tab.
4. Click Generic PnP Monitor, and then the Properties button.
5. Click the Driver tab and the Update Driver button.
6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer.
7. In the Update Driver Software window, select the option Browse my computer for
driver software
8. Click Browse and navigate to the following directory: d:\BenQ_LCD\Driver\ (where d is
the drive letter designator for the CD-ROM drive).
The drive letter for your CD drive may differ from the example above depending upon your system - it may be 'D:' or 'E:' or 'F:' etc.
.
9. Select the correct folder name of your monitor from provided driver list, and click
This will copy and install the appropriate monitor driver files to your computer.
10. Click Close.
You may be prompted to restart your computer after the driver update is complete.
Next.
29 Getting the most from your BenQ monitor
Page 30

How to install on Windows 8 (8.1) system

1. Open Display Properties.
Move the cursor to the lower-right of the screen or press the Windows + C buttons on the keyboard to bring up the Charm bar. Go to Settings, Control Panel, Devices and Printers and right-click the name of your monitor from the menu.
Alternatively, right-click the desktop and select Personalize, Display, Devices and Printers, and right-click the name of your monitor from the menu.
2. Select Properties from the menu.
3. Click the Hardware tab.
4. Click Generic PnP Monitor, and then the Properties button.
5. Click the Driver tab and the Update Driver button.
6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer.
7. In the Update Driver Software window, select the option Browse my computer for
driver software
8. Click Browse and navigate to the following directory: d:\BenQ_LCD\Driver\ (where d is
the drive letter designator for the CD-ROM drive).
The drive letter for your CD drive may differ from the example above depending upon your system - it may be 'D:' or 'E:' or 'F:' etc.
.
9. Select the correct folder name of your monitor from provided driver list, and click Next.
This will copy and install the appropriate monitor driver files to your computer.
10. Click Close.
You may be prompted to restart your computer after the driver update is complete.
30 Getting the most from your BenQ monitor
Page 31

How to install on Windows 7 system

1. Open Display Properties.
Go to Start, Control Panel, Hardware and Sound, Devices and Printers and right-click the name of your monitor from the menu.
Alternatively, right-click the desktop and select Personalize, Display, Devices and Printers, and right-click the name of your monitor from the menu.
2. Select Properties from the menu.
3. Click the Hardware tab.
4. Click Generic PnP Monitor, and then the Properties button.
5. Click the Driver tab and the Update Driver button.
6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer.
7. In the Update Driver Software window, select the option Browse my computer for
driver software
8. Click Browse and navigate to the following directory: d:\BenQ_LCD\Driver\ (where d is
the drive letter designator for the CD-ROM drive).
The drive letter for your CD drive may differ from the example above depending upon your system - it may be 'D:' or 'E:' or 'F:' etc.
.
9. Select the correct folder name of your monitor from provided driver list, and click Next.
This will copy and install the appropriate monitor driver files to your computer.
10. Click Close.
You may be prompted to restart your computer after the driver update is complete.
31 Getting the most from your BenQ monitor
Page 32

How to adjust your monitor

12 3

The control panel

All OSD (On Screen Display) menus can be accessed by the control keys. You can use the OSD menu to adjust all the settings on your monitor
No. Name Description
1. Power key Turns the power on or off.
2. 5-way controller Accesses the functions or menu items as instructed by the on-screen icons. See 5-way controller and basic menu
operations on page 33 for more information.
3. Custom keys Accesses the functions or menu items displayed on the screen, right next to each key. See Working with the hot keys on page
35 for more information.
32 How to adjust your monitor
Page 33

5-way controller and basic menu operations

Left Right
Up
Down
1
2
The 5-way controller is located at the rear of the monitor. While sitting in front of the monitor, move the controller to the directions instructed by the on-screen icons for menu navigation and operations.
OSD icon
5-way controller
operation
(When no menu has been activated)
N/A Press the 5-way
controller
• (Without video cable connection) Activates the video source selection menu.
• (With video cable connection) Activates the hotkey menu.
(When the video source selection menu has been activated)
Move the 5-way
Switches to the desired input source. controller to the desired direction
(When the hotkey menu has been activated)
Move to the right Activates the main menu.
Move up Adjusts brightness.
Move down Adjusts contrast.
Function
Move to the left Closes the hotkey menu.
(When the main menu has been activated)
Press Confirms the selection.
Move to the right • Enters sub menus.
• Confirms the selection.
Move up • Goes to the previous menu item.
• For up / increase adjustment.
33 How to adjust your monitor
Page 34
OSD icon
12
34
5-way controller
operation
Function
Move down • Goes to the next menu item.
• For down / decrease adjustment.
Move to the left • Returns to the previous menu.
• Exits OSD menu.
All OSD (On Screen Display) menus can be accessed by the control keys. You can use the OSD menu to adjust all the settings on your monitor. Available menu options may vary depending on the input sources, functions and settings.
1. Press the 5-way controller.
2. The hot key menu is displayed. The top and down icons are designated for particular functions.
3. Select
(Menu) to access the main menu.
4. On the main menu, follow the on-screen icons on the bottom of the menu to make adjustments or selection. See Navigating the main menu on page 45 for details on the menu options.
34 How to adjust your monitor
Page 35

Working with the hot keys

1
2
The custom keys (located next to the 5-way controller) perform as hot keys to provide direct access to pre-defined functions. You can change the default setting and designate different functions for these keys.
Accessing the hot key functions
1. Press any of the custom keys on the rear of the monitor.
2. Press the key with the desired function repeatedly to cycle through available options on the list.
Input
HDMI-1
HDMI-2
DP
1
2
OSD icon Function
Switches to a list of Color Mode options by default. To change the default settings, see Customizing the hot keys on page 35.
Switches to a list of Input options by default. To change the default settings, see Customizing the hot keys on page 35.
Customizing the hot keys
1. Press the 5-way controller to bring up the hotkey menu.
2. Select (Menu) to access the main menu.
3. Go to Custom Key.
4. Select the custom key you want to change. It is either Custom Key 1 or Custom Key 2.
5. On the sub menu, select a category.
35 How to adjust your monitor
Page 36
6. Under the category, check to select up to 3 items for quick access by this key.
Input Custom Key 1
Custom Key 2
Controller Key 1, 2, 3
Rotation Key
Controller Key Dial
Color
Audio
KVM Switch
Custom Key
Please check 2 or 3 items
MoveBack Edit
System
2
Mode: sRGB
Color Mode
DualView
KVM Switch
Input
Mute
Display-P3
DCI-P3
HDR
Rec.709
sRGB
CAD CAM
Animation
Low Blue Light
• OSD = On Screen Display. The hot keys only operate while the main menu is not currently displaying. Hot key displays will disappear after a few seconds of no key activity.
• To unlock the OSD controls, press and hold any key for 10 seconds.
36 How to adjust your monitor
Page 37

Hotkey Puck G2 and its basic operations

1
2
3
4
6
5
Apart from the control keys, Hotkey Puck G2 also provides a quick way to control and access the OSD menu.
• You need to connect the Hotkey Puck G2 to your monitor prior to use. Follow the instructions in Connect
the Hotkey Puck G2 to the monitor. on page 18.
• Hotkey Puck G2 is designed for BenQ LCD Monitor exclusively and is available for compatible models only. Do not connect it to other devices with mini USB ports.
No. Name Description
1 Dial key (If no menu is displayed)
• Turn right or left to adjust Brightness by default. To change the default settings, press and hold for 3 seconds to bring up the setup menu to change the default setting. Alternatively, go to Custom Key > Controller Key Dial on the monitor.
• Press to bring up the main menu.
(On a menu)
• Turn right to scroll down the menu.
• Turn left to scroll up the menu.
• Press to confirm the selection.
(If a control bar is displayed)
• Turn right to increase the value.
• Turn left to decrease the value.
2 Return key • Returns to the previous menu.
3 Controller Key 1 • Press to switch to DCI-P3 (Color Mode) by default.
• Exits OSD menu.
• Press and hold for 3 seconds to bring up the setup menu to change the default setting. Alternatively, see Customizing
the Controller Keys on Hotkey Puck G2 on page 38.
37 How to adjust your monitor
Page 38
No. Name Description
4 Controller Key 2 • Press to switch to sRGB (Color Mode).
• Press and hold for 3 seconds to bring up the setup menu to change the default setting. Alternatively, see Customizing
the Controller Keys on Hotkey Puck G2 on page 38.
5 Controller Key 3 • Press to switch to Display P3 (Color Mode).
• Press and hold for 3 seconds to bring up the setup menu to change the default setting. Alternatively, see Customizing
the Controller Keys on Hotkey Puck G2 on page 38.
6 Rotation Key • Press repeatedly to cycle through available settings.
• Press and hold for 3 seconds to bring up the setup menu to change the default setting. Alternatively, go to Custom Key > Rotation Key on the monitor.
Customizing the Controller Keys on Hotkey Puck G2
Keys on the Hotkey Puck G2 are designated for particular functions. You can change the default settings as desired.
1. Press the 5-way controller to bring up the hotkey menu.
2. Select (Menu) to access the main menu.
3. Go to Custom Key.
4. Select Controller Key 1, 2, 3.
5. On the sub menu, select a category.
6. Under the category, check to select up to 3 items for quick access by the Controller Keys on Hotkey Puck G2. The numbers displayed by the chosen items refer to the Controller Keys that the options are assigned to.
Alternatively, press and hold a key on the Hotkey Puck G2 for 3 seconds to bring up the setup menu to change the default setting.
Controlling the display with Display Pilot
The Display Pilot software is provided as an alternative to control the display. Download and install from www.benq.com or from the supplied CD (if came with the CD).
The main functions include:
• Control of the main functions / configurations of the monitor.
• Setup of rotating the display with the monitor automatically (see page 23).
• Additional tools to extend the monitor’s functionalities.
For more information, visit www.BenQ.com for Display Pilot manual.
Display Pilot is available on Windows 7, Windows 8 (8.1), and Windows 10.
38 How to adjust your monitor
Page 39

Adjusting Display Mode

To display images of aspect ratio other than 16:9 and size other than the panel size of your purchased model, you can adjust the display mode on the monitor.
1. Press the 5-way controller to bring up the hotkey menu, and select (Menu) to access
the main menu.
2. Go to Picture > Advanced > Display Mode.
3. Select an appropriate display mode. The setting will take effect immediately.

Choosing an appropriate color mode

Your monitor provides various color modes that are suitable for different types of images. See
Color Mode on page 50 for all the available color modes.
Go to Color > Color Mode for a desired color mode.
The computer’s color profile (ICC profile) may not best suit your monitor. If you want to make sure to obtain the accurate color matching representation, change the computer’s ICC profile to ensure the computer works better with the monitor. Visit www.BenQ.com > the purchased model > the
Manual
tab to access the ICC Profile Installation Guide for instructions.
Downloads or Support tab > the User

Working with two video sources (KVM Switch)

If you have two computer systems, you might find yourself busy going back and forth between two sets of keyboard and mouse to control each display separately. Now with the KVM feature and sufficient I/O ports on one monitor, you can work with one set of keyboard and mouse only.
To use KVM Switch feature, toggle between Thunderbolt 3 or USB Upstream under KVM Switch.
KVM Switch > Thunderbolt 3: Switches to the Thunderbolt™ 3 input.
KVM Switch > USB Upstream: Switches to one of the video inputs other than Thunderbolt™ 3. With appropriate setting, the display is switched to the set input while the keyboard and mouse control is switched as well. To determine the input, see Setting up the
second video source for KVM Switch before use on page 39.
You can designate one of the custom keys to KVM Switch to toggle between the options quickly. See Customizing the hot keys on page 35.
Setting up the second video source for KVM Switch before use
One of the video source is pre-defined to be transmitted via Thunderbolt™ 3 and cannot be changed. The other source can come from other available inputs and should be set appropriately in advance.
1. Connect the second video source to one of the video inputs other than Thunderbolt™ 3
on the monitor using an appropriate cable.
2. Press the 5-way controller to bring up the hotkey menu, and select (Menu) to access
the main menu.
3. Go to KVM Switch > Video Input.
39 How to adjust your monitor
Page 40
4. Change the setting according to your scenario.
PC 1 PC 2
PC 1 / PC 2
Thunderbolt™ 3 cable
Video cable
PC 1 PC 2
Thunderbolt™ 3 cable
Video cable
USB cable (type A to type B)
• For Scenario A: Working with two computers and one monitor on page 40, select the video input just connected. When USB Upstream under KVM Switch is selected, the display and USB control change from Thunderbolt™ 3 to the other connected video input.
• For Scenario B: Working with two computers and two monitors on page 40 and Scenario C:
Working in PBP mode on page 41, select None. This is because two video inputs are displayed
simultaneously and require no switch. The None option will switch USB control only.
If None is selected from KVM Switch > Video Input for Scenario A: Working with two computers and one
monitor and USB Upstream is selected for KVM Switch, the screen does not display anything from the second
source as there is none. You cannot control the current display (from Thunderbolt™ 3) either as the keyboard and mouse control has been switched away. In this case, select a video input manually from Input > Signal Input.
• After the second source has been set properly from KVM Switch > Video Input, you can go to KVM Switch > Auto Switch and turn on the Auto Switch function. Once enabled, if USB or Thunderbolt™ 3 cable is disconnected, the USB input source and the control will be switched to the other computer automatically.
• The KVM Auto Switch might not switch video and USB signals simultaneously if None is selected from KVM Switch > Video Input. In this case, select a video input manually from Input > Signal Input.
Scenario A: Working with two computers and one monitor
1. Establish cable connection as instructed in Connect the PC video cable on page 12.
2. Go to System > Power Awake > USB and select ON.
3. Set up the second video source as instructed in Setting up the second video source for
KVM Switch before use on page 39.
4. Go to KVM Switch and switch between Thunderbolt 3 and USB Upstream. If one of the custom key is set for KVM Switch, press the custom key to switch.
Scenario B: Working with two computers and two monitors
PC 1 PC 2
40 How to adjust your monitor
Page 41
1. Establish cable connection as instructed in Connect the PC video cable on page 12.
PC 1
PC 2
PC 1 PC 2
Video cable
Thunderbolt™ 3 cable
2. Go to System > Power Awake > USB and select ON.
3. Go to KVM Switch > Video Input and select None.
4. Go to KVM Switch and switch between Thunderbolt 3 and USB Upstream. If one of the custom key is set for KVM Switch, press the custom key to switch.
Scenario C: Working in PBP mode
1. Establish cable connection as instructed in Connect the PC video cable on page 12.
2. Go to System > Power Awake > USB and select ON.
3. Enable PBP function from Input > PBP. Select sources properly as instructed in Video
source selection in PBP mode on page 41.
4. Go to KVM Switch > Video Input and select None.
5. Go to KVM Switch and switch between Thunderbolt 3 and USB Upstream. If one of the custom key is set for KVM Switch, press the custom key to switch.

Video source selection in PIP mode

For first time use, go to Input > PIP, and press the 5-way controller. Your monitor scans for the available video sources in the following order: Thunderbolt™ 3, DP, and HDMI, and displays the first available one as the main source in PIP mode, and the second one as the sub source. If only one input signal is found, connect the desired video source with an appropriate cable, and go to Input > PIP > Sub to select the sub source manually. Under Input > PIP > Main, the main source can be changed manually as well.
The monitor keeps the setting of two input sources for future use until the setting is manually changed.

Video source selection in PBP mode

1. Go to Input > PBP or PBPx4.
2. Select the preferred source for each window.
41 How to adjust your monitor
Page 42

Connecting multiple monitors (Thunderbolt™ 3 daisy chaining)

Thunderbolt™ 3 cable
Thunderbolt™ 3 cable
With monitor connection via Thunderbolt™ 3 ports, you can output content to up to 6 devices (including 2 monitors) via daisy chain function.
1. Connect your laptop to the Thunderbolt™ 3 port ( ) on the monitor using a Thunder­bolt™ 3 cable. This port supplies power to the laptop.
2. Connect the second monitor to the first one using a Thunderbolt™ 3 cable as illustrated.
3. Power on the laptop and the monitors.
4. On your laptop, decide the way you want the content to be displayed on the connected monitors: Duplicate, Extend, or Projector only. Additional software (purchased separately) may be used to manage the display. Refer to the manual of the purchased software for more information.
Supported resolution
To perform Thunderbolt™ 3 daisy chaining, a limited number of connected monitors is required to ensure image quality. The following information shows the image resolution available to each monitor.
st
1
monitor 2nd monitor
3840 x 2160 (60Hz) 3840 x 2160 (60Hz)
3840 x 2160 (60Hz) 2560 x 1440 (60Hz)
Supported resolution
The signal output from a laptop to your monitor is always 3840 x 2160. If multiple monitors are connected, you can adjust each monitor’s resolution from the operating system of your laptop.
2560 x 1440 (60Hz) 2560 x 1440 (60Hz)
2560 x 1440 (60Hz) 1920 x 1080 (60 Hz)
Please also be noted that the supported number of devices for connection may vary by graphic card. To find out the capability of your graphic card, check its specifications or contact its manufacturer.
42 How to adjust your monitor
Page 43

Working with HDR technology

• Your monitor supports HDR10 technology.
• The information regarding HDR-compatible devices and content in this document is most up-to-date at the time of publication. For the latest information, contact your device manufacturer and content provider.
To enable HDR function, you need to have a compatible player and content.
1. Make sure a FHD/4K HDR player is ready. Players with the following names and resolutions are supported. Note that the 4K content on a FHD monitor get resized and is displayed at 1920 x 1080.
Commonly used names for
FHD, 4K, 4K Ultra HD, UHD, UHD 4K, Ultra HD, 2160p FHD/4K (may vary by manufacturer)
Supported resolution or modes 3840 x 2160 @ 24 Hz, 50 Hz, or 60 Hz
Commonly used names for HDR10
HDR Premium, High Dynamic Range, HDR, Ultra HD
Premium (may vary by manufacturer)
2. Make sure HDR content is available. Content may come from 4K UHD (Blue-Ray) or new HDR games on Xbox One S and PS4 Pro.
3. Make sure the player and the monitor have been connected via an appropriate cable:
• the provided HDMI / DP / DP to mini DP cable / USB-C™ cable / Thunderbolt™ 3 cable (if available)
• an HDMI cable that is HDMI High Speed or HDMI Premium certified
• a DP / DP to mini DP cable that is DisplayPort compliance certified
• a certified USB-C™ cable
Enabling HDR function
If the instructions in Working with HDR technology on page 43 are followed and the input content is HDR-compatible, the OSD message HDR: On is displayed on the screen. This means your content player and content are HDR-compatible and the HDR function is properly enabled. The monitor is following the ST2084 standard to process the HDR content.
If the connection is complete and no OSD message is displayed, follow the instructions to enable HDR-emulated mode.
1. Press the 5-way controller to bring up the hotkey menu, and select
(Menu) to access
the main menu.
2. Go to Color and Color Mode.
3. Select HDR. An OSD message HDR: Emulated is displays. This means the input content is not HDR-compatible and the monitor is in HDR-emulated mode.
HDR Demo is provided as a comparison between HDR and non-HDR image representation. See HDR Demo
options and HDR function availability on page 62 for more information.
43 How to adjust your monitor
Page 44
Working with two color settings on the same image
Picture with the setting from
Color > Color Mode.
Picture with the setting from
Color > DualView.
(DualView)
DualView helps improve your image editing efficiency by showing an image of two different
color modes side-by-side.
1. Select one color mode from Color > Color Mode.
2. Go to Color > DualView. The screen is divided into two windows and the selected color mode is applied to the left window.
3. A list of available color modes for the right window is displayed. Select one to apply the setting.
44 How to adjust your monitor
Page 45

Navigating the main menu

You can use the OSD (On Screen Display) menu to adjust all the settings on your monitor.
Press the 5-way controller to bring up the hot key menu, and press (Menu) to access the main menu. See 5-way controller and basic menu operations on page 33 for details.
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
The OSD menu languages may differ from the product supplied to your region, see Language on page 60 under System and OSD Settings for more details.
For more information on each menu, please refer to the following pages:
Input menu on page 46
Picture menu on page 48
Color menu on page 50
Audio menu on page 54
KVM Switch menu on page 55
Custom Key menu on page 57
System menu on page 59
45 Navigating the main menu
Page 46

Input menu

Signal Input
PIP
PBP
PBPx4
SWAP
Input
Color
Audio
KVM Switch
Custom Key
MoveBack Confirm
System
2
Mode: sRGB
Left
Right
Thunderbolt 3
DisplayPort
HDMI1
HDMI2
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select Input.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
Item Function Range
Signal Input
Use this to change the input to that appropriate to your video cable connection type.
Manual selection of signal input will disable the source switch
function of KVM Switch. If you prefer to use KVM Switch after manual source selection here, be sure follow the instructions in
Setting up the second video source for KVM Switch before use on page 39 again to set properly.
Thunderbolt 3
•DisplayPort
HDMI1
HDMI2
46 Navigating the main menu
Page 47
Item Function Range
PIP Sets the PIP mode. Pictures from two independent video
sources are displayed on the screen at the same time.
The audio input is from the main source if the PIP mode is activated.
Not available when HDR function is enabled.
Main Determines the main video source. Thunderbolt
•DisplayPort
HDMI1
HDMI2
3
Sub Determines the second video source for PIP
mode.
PIP Size Determines the size of the inset window in the
PIP mode.
PIP Positio n
Adjusts the position of the inset window in the PIP mode.
PBP Sets the PBP mode to have two pictures displayed
side-by-side. Determines the video sources for the left and the right windows respectively.
Not available when HDR function is enabled.
Thunderbolt 3
•DisplayPort
HDMI1
HDMI2
Small
Medium
Large
To p R i g h t
To p L e f t
Bottom Right
Bottom Left
Left
Right
PBPx4 Sets the PBP mode to have four pictures displayed
side-by-side. Determines the video sources for four windows respectively.
Not available when HDR function is enabled.
SWAP Swaps the video screens.
•For PIP / PBP mode: the main and the sub sources will be switched.
•For PBPx4 mode: the sources will be switched clockwise.
Top Left
To p R i g h t
Bottom Left
Bottom Right
47 Navigating the main menu
Page 48

Picture menu

Input
Color
Audio
KVM Switch
Custom Key
MoveBack Confirm
System
2
Mode: sRGB
Brightness
Contrast
Sharpness
Advanced
0
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select Picture.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
Item Function Range
Brightness Adjusts the balance between light and dark shades. 0 to 100
Contrast Adjusts the degree of difference between darkness and lightness. 0 to 100
Sharpness Adjusts the clarity and visibility of the edges of the subjects in the
1 to 10
image.
Advanced Dynamic
Contrast
The function is to automatically detect the distribution of an input visual signal, and then to create the optimal contrast.
0 to 5
48 Navigating the main menu
Page 49
Item Function Range
Display Mode
This feature is provided to allow aspect ratios other than 16:9 to be displayed without geometric distortion.
The options under Display Mode will be different depending on the input signal sources.
Depending on your selection of Color Mode, different Display Mode option is pre-set. Change the setting if needed.
Full Scales the input image to fill the screen.
Ideal for 16:9 aspect images.
1: 1 Displays the input image in its native
resolution without scaling.
Overscan Slightly enlarges the input image. Use this feature to
hide annoying edge noise if present around your image.
Available only when the input source is HDMI.
ON
OFF
49 Navigating the main menu
Page 50

Color menu

Input Color Mode
DualView
Color Temperature
Advanced
Color
Audio
KVM Switch
Custom Key
MoveBack Confirm
System
2
Mode: sRGB
Gamma
Hue
Saturation
Reset Color
AMA
HDMI RGB PC Range
505050505050
RGBCMY
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select Color.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
Item Function Range
Color Mode Select a color mode that best suits the type of images shown on
the screen.
DCI-P3 For better color matching representation with
Standard DCI-P3.
Display P3 For better color matching representation with
HDR For better color matching representation with High
Standard Display-P3.
Dynamic Range (HDR) technology.
Not available when PIP / PBP mode is enabled.
50 Navigating the main menu
Page 51
Item Function Range
sRGB For better color matching representation with the
peripheral devices, such as printers, digital cameras, etc.
Rec. 709 For better color matching representation with
Standard Rec. 709.
CAD / CAM Enhances the contrast if a CAD / CAM software is
used.
Animation Enhances the contrast of the dark shades so you
could work on the details easily when making an animation.
Low Blue Light
Decreases the blue light emitted from the display to reduce the risk of blue light exposure to your eyes.
The value for each Low Blue Light mode indicates how much blue light is decreased compared with the Standard mode.
Multimedia For viewing multimedia files.
Web
For web surfing.
Surfing
Office For office works or office
environment.
Reading For reading e-books or documents.
Darkroom For image editing and viewing in a post-processing
environment with a dim light. This mode enhances the sharpness and clarity of shades and shows more details.
0 ~ 10
M-book Minimizes the visual differences between the
monitor and the connected MacBook series product.
DICOM For viewing DICOM images. It is recommended for
displaying medical images.
DICOM as the abbreviation of Digital Imaging and Communications in Medicine is a standard for handling, storing, printing, and transmitting medical images.
User Applies a combination of picture settings defined by
users.
51 Navigating the main menu
Page 52
Item Function Range
DualView Displays the preview of screen images under the selected modes.
Once enabled, the screen will be divided into two windows; the left window demonstrates the image under the mode selected from Color Mode, while the right window presents the image under the mode specified here.
Not available when HDR function is enabled.
Color Temperature
6500K Allows video and still photographs to be viewed
with natural coloring. This is the factory default color.
OFF
DCI-P3
Display P3
sRGB
Rec. 709
CAD / CAM
Animation
Low Blue Light
Darkroom
M-book
DICOM
User
9300K Applies a cool tint to the image and is factory
pre-set to the PC industry standard white color.
5000K Applies a warm tint to the image and is factory
pre-set to the news print standard white color.
User Define The blend of the Red, Green and Blue primary
colors can be altered to change the color tint of the image. Go to the succeeding R (red), G (green), and B (blue) menus to change the settings. Decreasing one or more of the colors will reduce their respective influence on the color tint of the image. (e.g. if you reduce the Blue level the image will gradually take on a yellowish tint. If you reduce Green, the image will become a magenta tint.)
Advanced Gamma Adjusts the tone luminance. The default value is
2.2 (the standard value for Windows).
R (0~100)
G (0~100)
B (0~100)
1.8
2.0
2.2
2.4
2.6
52 Navigating the main menu
Page 53
Item Function Range
Hue Adjusts the degree of how we perceive colors. R (0~100)
G (0~100)
B (0~100)
C (0~100)
M (0~100)
Y (0~100)
Saturation Adjusts the purity degree of colors. R (0~100)
G (0~100)
B (0~100)
C (0~100)
M (0~100)
Y (0~100)
Reset Color Resets the custom color settings to the factory
defaults.
AMA Improves the gray level response time of the LCD
panel.
HDMI RGB PC Range
Determines the range of color scales. Select an option that matches the RGB range setting on the connected HDMI device.
YES
NO
OFF
High
Premium
Auto
Full (0 ~
255)
Limited (16 ~ 235)
53 Navigating the main menu
Page 54

Audio menu

Input
Color
Audio
KVM Switch
Custom Key
MoveBack Confirm
System
2
Mode: sRGB
30
Volume
Mute
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select Audio.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
Item Function Range
Vol um e Adjusts the audio volume. 0 ~ 100
Mute Mutes the audio input. • ON
OFF
54 Navigating the main menu
Page 55

KVM Switch menu

Thunderbolt 3
DisplayPort
HDMI1
HDMI2
None
Input
Color
Audio
KVM Switch
Custom Key
MoveBack Confirm
System
2
Mode: sRGB
Thunderbolt 3
USB Upstream
Video Input
Auto Switch
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select KVM Switch.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
Item Function Range
Thunderbolt 3 Switches the keyboard and mouse control over the input
source / display connected to the Thunderbolt™ 3 port.
USB Upstream Switches the keyboard and mouse control over the input
source / display connected to the USB Upstream port. The video input that goes with this USB Upstream port has to be pre-defined. See Setting up the second video source for
KVM Switch before use on page 39.
55 Navigating the main menu
Page 56
Item Function Range
Video Input Presets a video input to go with the USB Upstream port.
See Setting up the second video source for KVM Switch
before use on page 39.
If None is selected from KVM Switch > Video Input for
Scenario A: Working with two computers and one monitor on page 40 and USB Upstream is selected for KVM Switch, the
screen does not display anything from the second source as there is none. You cannot control the current display (from Thunderbolt™ 3) either as the keyboard and mouse control has been switched away. In this case, select a video input manually from Input > Signal Input.
Auto Switch Once enabled, if USB or Thunderbolt™ 3 cable is
disconnected, the USB input source and the control will be switched to the other computer automatically.
DisplayPort
HDMI1
HDMI2
None
ON
OFF
56 Navigating the main menu
Page 57

Custom Key menu

Input Custom Key 1
Custom Key 2
Controller Key 1, 2, 3
Rotation Key
Controller Key Dial
Color
Audio
KVM Switch
Custom Key
Please check 2 or 3 items
MoveBack Edit
System
2
Mode: sRGB
Color Mode
Input
DualView
KVM Switch
Mute
Display P3
DCI-P3
HDR
Rec.709
sRGB
CAD/CAM
Animation
Low Blue Light
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select Custom Key.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
Item Function Range
Custom Key 1
Custom Key 2
Sets the function to be accessed by custom key 1. Select a category first, and choose up to 3 options to be accessed by this key.
Sets the function to be accessed by custom key 2. Select a category first, and choose up to 3 options to be accessed by this key.
Color Mode
Input
DualView
KVM Switch
Mute
57 Navigating the main menu
Page 58
Item Function Range
Controller Key 1, 2, 3
Rotation Key
Controller Key Dial
Sets the function to be accessed by controller key 1 / 2 / 3 on Hotkey Puck G2. See Hotkey Puck G2 and its basic
operations on page 37 for the location of the keys.
Select a category first, and choose up to 3 options to be accessed by these keys. The numbers displayed next to the selected items are the controller keys that the options are designated to.
Sets the function to be accessed by the Rotation key on Hotkey Puck G2. See Hotkey Puck G2 and its basic
operations on page 37 for the location of the key.
Select a category first, and choose up to 3 options to be accessed by this key.
Sets the function to be accessed by the Dial key on Hotkey Puck G2. See Hotkey Puck G2 and its basic operations on
page 37 for the location of the key.
Color Mode
Input
DualView
KVM Switch
Mute
Color Mode
Input
DualView
KVM Switch
Mute
Brightness
Contrast
Volu me
58 Navigating the main menu
Page 59

System menu

Input OSD Settings
HDR Demo
Auto Switch
Ergonomics
Power Awake
Advanced
System Setting
Information
Color
Audio
KVM Switch
Custom Key
MoveBack Confirm
System
2
Mode: sRGB
Language
Display Time
OSD Lock
Resolution Notice
5 Sec.
10 Sec.
15 Sec.
20 Sec.
25 Sec.
30 Sec.
Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
1. Select (Menu) from the hot key menu.
2. Use or to select System.
3. Select to go to a sub menu, and then use or to select a menu item.
4. Use or to make adjustments, or use to make selection.
5. To return to the previous menu, select .
6. To exit the menu, select .
59 Navigating the main menu
Page 60
Item Function Range
OSD Settings
Language Sets the OSD menu language.
The language options displayed on your OSD may differ from those shown on the right, depending on the product supplied in your region.
English
Français
Deutsch
Italiano
Español
Polski
Česky
Magyar
Română
Nederlands
Русский
Svenska
Português
日本語
한국어
Display
Adjusts the display time of the OSD menu.
Time
OSD Lock Prevents all the monitor settings from being
accidentally changed. When this function is activated, the OSD controls and hotkey operations will be disabled.
To unlock the OSD controls, press and hold any key for 10 seconds.
Resolution Notice
Sets whether to display the resolution notice of the recommended resolution when a new input source is detected by the monitor.
繁體中文
简体中文
• 5 sec.
• 10 sec.
• 15 sec.
• 20 sec.
• 25 sec.
30 sec.
ON
OFF
60 Navigating the main menu
Page 61
Item Function Range
HDR Demo (Works only if the input content is HDR-compatible)
When the function is activated, all color modes are available for a comparison between HDR and non-HDR image representation. See HDR Demo options and HDR function
availability on page 62 for more information.
If this function is activated and a non-HDR mode is selected, the input HDR content may be represented inappropriately.
Auto Switch
Once enabled, the specific port will be in the input auto select loop. Otherwise, it can only be selected by input select or by hot key.
Available only when KVM Switch > Video Input is set to None.
Ergonomics Smart
Reminder
Time
Decides to display the pop-up message that reminds you to rest your eyes.
Sets the interval of the reminder message. 20
Interval (min.)
ON
OFF
DP Auto Switch
HDMI Auto Switch
ON
OFF
40
60
Power Awake
Duration (sec.)
If this function is disabled, the Thunderbolt™ 3 / USB ports are not supplied with power while the monitor is in standby
Sets the time the reminder message lasts on the screen.
mode. To keep supplying power to the Thunderbolt™ 3 / USB ports in monitor’s standby mode, change the setting to ON.
Advanced DDC/CI Allows the monitor settings to be set through
the software on the PC.
DDC/CI, short for Display Data
Channel/Command Interface, which was developed by Video Electronics Standards Association (VESA). DDC/CI capability allows monitor controls to be sent via the software for remote diagnostics.
80
100
5
10
15
20
25
Thunderbolt 3
USB
ON
OFF
61 Navigating the main menu
Page 62
Item Function Range
System Setting
Auto Power Off
Sets the time to power off the monitor automatically in power saving mode.
OFF
10 min
20 min
30 min
DisplayPort Selects an appropriate DP standard for data
transmission.
OSD Key Bri.
Adjusts the brightness of the power key’s LED indicator.
1.1
1.4
1
2
3
Shows the current monitor property settings. Input
Timing
Brightness
Contrast
Pixel Encoding
Color Depth
RGB Range
Information Displays the product information. Model Name
• SN
• Version
Usage Time
Reset All Resets all mode, color and geometry settings to the factory
default values.
• YES
NO
HDR Demo options and HDR function availability
HDR Demo
option
OFF HDR content Switches to HDR mode automatically.
OFF (grayed
out)
Video input Availability of HDR function OSD message
HDR: On Non-HDR color modes are not available.
Non-HDR content Emulated HDR function if HDR mode
is selected under Color > Color
HDR:
Emulated Mode.
ON HDR content Switches to HDR mode automatically.
62 Navigating the main menu
HDR: On Non-HDR color modes are available.
Page 63

Troubleshooting

Frequently asked questions (FAQ)

Imaging
The image is blurred.
Read the instructions on the link "Adjusting the Screen Resolution" on the CD, and then select the correct resolution, refresh rate and make adjustments based on these instructions.
Does the blurring only occur at resolutions lower than the native (maximum) resolution?
Read the instructions on the link "Adjusting the Screen Resolution" on the CD. Select the native resolution.
Pixel errors can be seen.
One of several pixels is permanently black, one or more pixels are permanently white, one or more pixels are permanently red, green, blue or another color.
• Clean the LCD screen.
• Cycle power on-off.
• These are pixels that are permanently on or off and is a natural defect that occurs in LCD technology.
The image has a faulty coloration.
It has a yellow, blue or pink appearance.
Go to Color, Advanced, and Reset Color, and then choose YES to reset the color settings to the factory defaults.
If the image is still not correct and the OSD also has faulty coloration, this means one of the three primary colors is missing in the signal input. Now check the signal cable connectors. If any pin is bent or broken off, please contact your dealer to get necessary support.
The image is distorted, flashes or flickers.
Read the instructions on the link "Adjusting the Screen Resolution" on the CD, and then select the correct resolution, refresh rate and make adjustments based on these instructions.
You are running the monitor at its native resolution, but the image is still distorted.
Images from different input sources may appear distorted or stretched on the monitor running at its native resolution. To have the optimal display performance of each type of input sources, you can use the Display Mode function to set a proper aspect ratio for the input sources. See Display Mode on page 49
for details.
The image is displaced in one direction.
Read the instructions on the link "Adjusting the Screen Resolution" on the CD, and then select the correct resolution, refresh rate and make adjustments based on these instructions.
63 Troubleshooting
Page 64
Faint shadow from the static image displayed is visible on the screen.
• Activate the power management function to let your computer and monitor go into a low power "sleep" mode when not actively in use.
• Use a screensaver to prevent the occurrence of image retention.
Power LED indicator
The LED indicator is white or orange.
• If the LED lights up in solid white, the monitor is powered on.
• If the LED is illuminated in white and there is a message Out of Range on the screen, this means you are using a display mode that this monitor does not support, please change the setting to one of the supported mode. Please read the "Preset display modes" section from the link "Adjusting the Screen Resolution".
• If the LED is illuminated in orange, the power management mode is active. Press any button on the computer keyboard or move the mouse. If that does not help, check the signal cable connectors. If any pin is bent or broken off, please contact your dealer to get necessary support.
• If the LED is off, check the power supply mains socket, the external power supply and the mains switch.
OSD controls
The OSD controls are inaccessible.
To unlock the OSD controls when it is preset to be locked, press and hold any key for 10 seconds.
OSD messages
A message Out of Range on the screen during computer boot up process.
If there is a message Out of Range on the screen during computer boot up process, this means computer compatibility caused by operating system or graphic card. The system will adjust the refresh rate automatically. Just wait until the operating system is launched.
Audio
No sound can be heard from the connected external speakers.
• Remove your headphone (if the headphone is connected to the monitor).
• Check whether the headphone jack is properly connected.
• If the external speakers are USB-powered, check whether the USB connection is OK.
• Increase the volume (volume may be muted or too low) on the external speakers.
64 Troubleshooting
Page 65
Thunderbolt™ 3 connection
When single monitor is connected, no video or audio output from the laptop with Thunderbolt™ 3 connection.
Check the cable connections and menu settings in the following order.
• Check if an appropriate cable has been connected to the monitor and the laptop properly. See Connectivity of Thunderbolt™ 3 port on your monitor on page 13 for more information.
• Check if the input source has been selected to Thunderbolt 3 from Input > Signal Input.
• Check if it is either Thunderbolt™ 3 port or USB-C™ port used on the computer for connection. If a USB-C™ port is used, make sure the port supports video signal transmission.
KVM Switch
No response after selecting KVM Switch > USB Upstream.
Check the cable connections and menu settings in the following order.
• Check if an appropriate cable has been connected to the monitor and the second video source properly. See Connect the PC video cable. on page 16 for more information.
• Check if the input source has been selected to the second video input from KVM Switch > Video Input.

Need more help?

If your problems remain after checking this manual, please contact your place of purchase or visit the local website from www.BenQ.com for more support and local customer service.
65 Troubleshooting
Loading...
