Page 1

Digital Projector

User Manual

EX600 / EW600 / EH600

V 1.00

Page 2

Warranty and Copyright information

Limited warranty

BenQ warrants this product against any defects in material and workmanship, under normal usage and storage.

Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.

Important: The above warranty shall be void if the customer fails to operate the product in accordance with BenQ's written instructions, especially the ambient humidity must be in-between 10% and 90%, temperature in-between 0°C and 35°C, altitude lower than 4920 feet, and avoiding to operate the projector in a dusty environment. This warranty gives you specific legal rights, and you may have other rights which vary from country to country.

For other information, please visit www.BenQ.com.

Copyright © 2019 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

Disclaimer

BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.

*DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments. Others are copyrights of their respective companies or organizations.

Patents

Please go to http://patmarking.benq.com/ for the details on BenQ projector patent coverage.

2 Warranty and Copyright information

Page 3

Table of Contents

Warranty and Copyright information ................................................................................ 2

Important safety instructions .............................................................................................. 4

Introduction .......................................................................................................................... 7

Shipping contents ....................................................................................................................................... 7

Projector exterior view ............................................................................................................................ 9

Controls and functions............................................................................................................................ 10

Positioning your projector ................................................................................................. 14

Choosing a location ................................................................................................................................. 14

Obtaining a preferred projected image size....................................................................................... 15

Mounting the projector ..........................................................................................................................17

Adjusting the projected image ..............................................................................................................18

Connection .......................................................................................................................... 20

Starting up the projector ................................................................................................... 22

Operation (under Launcher source) ................................................................................ 25

BenQ Launcher ....................................................................................................................................25

Operation (under non-Launcher source) ......................................................................... 63

Using the projector menus under non-Launcher source ...............................................................63

Securing the projector ............................................................................................................................ 64

Switching input signal ...............................................................................................................................66

Menu operation ........................................................................................................................................ 67

Shutting down the projector ............................................................................................. 82

Direct power off ...................................................................................................................................... 82

Maintenance ........................................................................................................................ 83

Care of the projector .............................................................................................................................. 83

Light information ...................................................................................................................................... 83

Troubleshooting ................................................................................................................. 89

Specifications ...................................................................................................................... 90

Projector specifications ..........................................................................................................................90

Dimensions ................................................................................................................................................91

Timing chart............................................................................................................................................... 92

3 Table of Contents

Page 4

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product.

1. Please read this manual before you operate your projector. Save it for future reference.

2. Do not look straight at the projector lens during operation. The intense light beam may damage your eyes.

3. Refer servicing to qualified service personnel.

6. In some countries, the line voltage is NOT stable. This projector is designed to operate safely within a mains voltage between 100 to 240 volts AC, but could fail if power cuts or surges of ±10 volts occur. In areas where

the mains voltage may fluctuate or cut out, it is recommended that you connect your projector through a power stabilizer, surge protector or uninterruptible power supply (UPS).

7. Do not block the projection lens with any objects when the projector is under operation as this could cause the objects to become heated and deformed or even cause a fire. To temporarily turn off the lamp, use the blank function.

4. Always open the lens shutter (if any) or

remove the lens cap (if any) when the projector lamp is on.

5. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45 minutes prior to removing the lamp assembly for replacement.

8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond the rated life could cause them to break on rare occasions.

4 Important safety instructions

Page 5

9. Never replace the lamp assembly or any electronic components unless the projector is unplugged.

10. Do not place this product on an unstable cart, stand, or table. The product may fall, sustaining serious damage.

11. Do not attempt to disassemble this projector. There are dangerous high voltages inside which may cause death if you should come into contact with live parts. The only user serviceable part is the lamp which has its own removable cover.

Under no circumstances should you ever undo or remove any other covers. Refer servicing only to suitably qualified professional service personnel.

13. Always place the projector on a level, horizontal surface during operation.

- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of more than 15 degrees front to back. Using the projector when it is not fully horizontal may cause a malfunction of, or damage to, the lamp.

14. Do not stand the projector on end vertically. Doing so may cause the projector to fall over, causing injury or resulting in damage to the projector.

15. Do not step on the projector or place any objects upon it. Besides probable physical damage to the projector, doing so may result in accidents and possible injury.

12. Do not block the ventilation holes.

- Do not place this projector on a blanket, bedding or any other soft surface.

- Do not cover this projector with a cloth or any other item.

- Do not place inflammables near the projector.

If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire.

16. When the projector is under operation, you may sense some heated air and odor from its ventilation grill. It is a normal phenomenon and not a product defect.

5 Important safety instructions

Page 6

17. Do not place liquids near or on the projector.

3000 m

(10000 feet)

0 m

(0 feet)

Liquids spilled into the projector may cause it to fail. If the projector does become wet, disconnect it from the power supply's power outlet and call BenQ to have the projector serviced.

18. This product is capable of displaying inverted images for ceiling/wall mount installation.

20. Do not place this projector in any of the following environments.

- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls and free flow of air around the projector.

- Locations where temperatures may become excessively high, such as the inside of a car with all windows rolled up.

- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical components, shorten the projector's life span and darken the image.

- Locations near fire alarms

- Locations with an ambient temperature above 40°C / 104°F

- Locations where the altitudes are higher than 3000 m (10000 feet).

19. This apparatus must be earthed.

Hg - Lamp contains mercury. Manage in accordance with local disposal laws. See www.lamprecycle.org.

To avoid damaging the DLP chips, never aim a high-power laser beam into the projection lens.

6 Important safety instructions

Page 7

Introduction

Shipping contents

Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase.

Standard accessories

Projector

Warranty card* Power cord VGA cable

Wireless dongle

• The supplied accessories will be suitable for your region, and may differ from those illustrated.

• *The warranty card is only supplied in some specific regions. Please consult your dealer for detailed information.

Optional accessories

1. Spare lamp kit

2. 3D glasses

Remote control with

batteries

Quick start guide

Replacing the remote control batteries

1. Press and open the battery cover, as illustrated.

2. Remove the old batteries (if applicable) and install two AAA batteries. Make sure that the positive and negative ends are positioned correctly, as illustrated.

3. Replace the battery cover until it clicks into place.

7 Introduction

Page 8

• Avoid leaving the remote control and batteries in an excessive heat or humid environment like the kitchen, bathroom, sauna, sunroom or in a closed car.

• Replace only with the same or equivalent type recommended by the battery manufacturer.

• Dispose of the used batteries according to the manufacturer's instructions and local environment regulations for your region.

• Never throw the batteries into a fire. There may be danger of an explosion.

• If the batteries are dead or if you will not be using the remote control for an extended period of time, remove the batteries to avoid damage to the remote control from possible battery leakage.

Installing the wireless dongle

The projector only supports Wi-Fi and/or Bluetooth connections when the wireless dongle (WDR02U) is installed.

1. Loosen the screw that secures the I/O port cover to remove the I/O port cover.

2. Remove the cap from the provided wireless dongle and insert the dongle into the port WIRELESS DONGLE.

3. Re-install the I/O port cover.

8 Introduction

Page 9

Projector exterior view

3 4

8 3

12 14 1610

1. Focus ring and zoom ring

2. Vent (air exhaust)

3. Adjuster feet

4. Projection lens

5. IR remote sensor

6. External control panel

(See Controls and functions on page 10.)

7. Lamp cover

8. Vent (air inlet)

9. Audio input jacks

Audio output jack

10. RGB (PC) signal output jack

11. RS-232 control port

12. RGB (PC) signal input jacks

13. HDMI input port

14. USB Mini-B port

15. USB Type A port

16. USB Type A port

17. AC power jack

18. Wall mount holes

19. Security bar

20. USB Type A port (for wireless dongle)

21. Wireless dongle cover

9 Introduction

Page 10

Controls and functions

3 4

• All the key presses described in this document are available on the remote control or projector.

• The remote control is without laser pointer in Japan.

Projector & Remote control

10 12

13 14 15 16

19 20 21 22 23 24

No.

3. IR remote sensor

POWER

ON/ Off

POWER indicator light/TEMPerature warning light/LAMP indicator light

(BACK)

When the input source is BenQ Launcher

Toggles the projector between standby mode and on.

(See Indicators on page 88.)

When the input source is NOT BenQ Launcher

Returns to the previous menu, main settings menu or exit the app.

Goes back to previous OSD menu or exits menu settings.

10 Introduction

Page 11

No.

Arrow keys ( , , , )

Keystone keys ( , )

Vol um e ke ys /

When the input source is BenQ Launcher

Moves through the menu items or toggle through the available options.

(Not available.)

When the input source is NOT BenQ Launcher

When the On-Screen Display (OSD) menu is activated, these keys are used as directional arrows to select the desired menu items and to make adjustments.

Displays the keystone correction page.

Decreases or increase the projector volume.

(SOURCE)

Displays the source selection bar. Used to hide the screen picture.

7. ECO BLANK, BLANK

8. OK

Confirms the selected menu item.

Do not block the projection lens from projecting as this could cause the blocking object to become heated and deformed or even cause a fire.

Confirms the selected On-Screen Display (OSD) menu item.

Turns on or off the projector’s

(MENU)

Enters the Settings menu.

On-Screen Display (OSD) menu.

10.

11.

(HOME)

Source selection buttons: HDMI, PC, LAUNCHER

Returns to the home screen. (Not available.)

Selects an input source for display.

Toggles projector audio between on and off.

12.

Decreases the projector volume. Increase the projector volume.

Customizes buttons, the default is iOS mobile projection

13. Control buttons: F1, F2, F3

settings (F1) / Android mobile projection settings (F2) /

(Not available.)

Laptop mobile projection settings (F3).

14. LASER Emits visible laser pointer light for presentation purposes. Enters the Internet menu in

15.

(WiFi)

Settings.

(Not available.)

16. PICTURE Selects an available picture mode.

17.

18.

19.

20.

(Cursor)

(Android menu)

(Hotspot)

(Clear memory)

Activates the cursor function. (Not available.)

Goes to the Settings menu. If app related settings can be

(Not available.) called from within the app. Enters the Hotspot menu in Settings. Goes into one key speedup

(one key empty) mode.

(Not available.)

11 Introduction

Page 12

No.

When the input source is BenQ Launcher

When the input source is NOT BenQ Launcher

21. BRIGHTNESS Adjusts brightness.

22. CONTRAST Adjusts contrast.

23. LIGHT MODE

Displays the Light Mode menu for selecting a suitable lamp operating mode.

Automatically determines the

24. AUTO (Not available.)

best picture timings for the displayed image when PC signal (analog RGB) is selected.

Operating the LASER pointer

The Laser Pointer is a presentation aid for professionals. It emits red colored light when you press it. The laser beam is visible. It is necessary to press and hold LASER for continuous output.

The laser pointer is not a toy. Parents should be mindful of the dangers of laser energy and keep this remote control out of the reach of children.

Do not look into the laser light window or shine the laser light beam on yourself or others. See the warning messages on the back of the remote control prior to using it.

12 Introduction

Page 13

Remote control effective range

The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor(s) to function correctly. The distance between the remote control and the sensor(s) should not exceed 8 meters (~ 26 feet).

Make sure that there are no obstacles between the remote control and the IR sensor(s) on the projector that might obstruct the infra-red beam.

• Operating the projector from the front • Operating the projector from the top

13 Introduction

Page 14

Positioning your projector

Choosing a location

Before choosing an installation location for your projector, take the following factors into consideration:

• Size and position of your screen

• Electrical outlet location

• Location and distance between the projector and the rest of your equipment

You can install your projector in the following ways.

1. Front Table

Select this location with the projector placed on the table in front of the screen. This is the most common way to position the projector for quick setup and portability.

3. Front Ceiling

Select this location with the projector suspended upside-down in front of the screen. Purchase the BenQ Projector Ceiling/Wall Mount Kit from your dealer to mount your projector.

2. Rear Table

Select this location with the projector placed on the table behind the screen. Note that a special rear projection screen is required.

4. Rear Ceiling

Select this location with the projector suspended upside-down from behind the screen. Note that a special rear projection screen and the BenQ Projector Ceiling/Wall Mount Kit are required for this installation location.

After turning on the projector, go to Advanced Menu - Settings > Projector Installation > Projector Installation and press / to select a setting.

14 Positioning your projector

Page 15

Obtaining a preferred projected image size

Projection distance

Center of lens

Screen

4:3 Screen diagonal

Offset

The distance from the projector lens to the screen, the zoom setting (if available), and the video format each factors in the projected image size.

Projection dimensions

EX600

• The screen aspect ratio is 4:3 and the projected picture is in a 4:3 aspect ratio

Screen size Projection distance (mm)

Inch mm (max. zoom) (min. zoom)

30 762 457 610 1195 1253 1311 45

40 1016 610 813 1593 1670 1748 61

50 1270 762 1016 1991 2088 2184 76

60 1524 914 1219 2390 2505 2621 91

70 1778 1067 1422 2788 2923 3058 107

80 2032 1219 1626 3186 3341 3495 122

90 2286 1372 1829 3584 3758 3932 137

100 2540 1524 2032 3983 4176 4369 152

110 2794 1676 2235 4381 4593 4806 168

120 3048 1829 2438 4779 5011 5243 183

130 3302 1981 2642 5178 5428 5679 198

140 3556 2134 2845 5576 5846 6116 213

150 3810 2286 3048 5974 6264 6553 229

160 4064 2438 3251 6372 6681 6990 244

170 4318 2591 3454 6771 7099 7427 259

180 4572 2743 3658 7169 7516 7864 274

190 4826 2896 3861 7567 7934 8301 290

200 5080 3048 4064 7965 8352 8738 305

250 6350 3810 5080 9957 10439 10922 381

300 7620 4572 6096 11948 12527 13106 457

H (mm) W (mm)

Min distance

Average

Max distance

Offset (mm)Diagonal

For example, if you are using a 120-inch screen, the recommended projection distance is 5011 mm.

If your measured projection distance is 6200 mm, the closest match in the "Projection distance (mm)" column is 6264 mm. Looking across this row shows that a 150'' (about 3.8 m) screen is required.

To optimize your projection quality, we suggest to do the projection within non-gray area.

All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics. This will help you determine the exact mounting position so that it best suits your installation location.

15 Positioning your projector

Page 16

EW600

Projection distance

Center of lens

Screen

16:10 Screen diagonal

Offset

• The screen aspect ratio is 16:10 and the projected picture is in a 16:10 aspect ratio

Screen size Projection distance (mm)

Inch mm (max. zoom) (min. zoom)

30 762 406 646 1002 1050 1098 0

40 1016 538 862 1335 1400 1465 0

50 1270 673 1077 1669 1750 1831 0

60 1524 808 1292 2003 2100 2197 0

70 1778 942 1508 2337 2450 2563 0

80 2032 1007 1723 2671 2800 2929 0

90 2286 1212 1939 3005 3150 3295 0

100 2540 1346 2154 3339 3500 3662 0

110 2794 1481 2369 3672 3850 4028 0

120 3048 1615 2585 4006 4200 4394 0

130 3302 1750 2800 4340 4550 4760 0

140 3556 1885 3015 4676 4900 5126 0

150 3810 2019 3231 5008 5250 5492 0

160 4064 2154 3446 5342 5600 5859 0

170 4318 2289 3662 5676 5950 6225 0

180 4572 2423 3877 6009 6300 6591 0

190 4826 2558 4092 6343 6650 6957 0

200 5080 2692 4308 6677 7000 7323 0

250 6350 3365 5385 8346 8750 9154 0

300 7620 4039 6462 10016 10500 10985 0

H (mm) W (mm)

Min distance

Average

Max distance

Offset (mm)Diagonal

For example, if you are using a 120-inch screen, the recommended projection distance is 4200 mm.

If your measured projection distance is 5200 mm, the closest match in the "Projection distance (mm)" column is 5250 mm. Looking across this row shows that a 150'' (about 3.8 m) screen is required.

16 Positioning your projector

To optimize your projection quality, we suggest to do the projection within non-gray area.

Page 17

EH600

Projection distance

Center of lens

Screen

16:9 Screen diagonal

Offset

• The screen aspect ratio is 16:9 and the projected picture is in a 16:9 aspect ratio

Screen size Projection distance (mm)

Inch mm (max. zoom) (min. zoom)

30 762 374 664 990 1039 1089 30

40 1016 498 886 1319 1386 1452 40

50 1270 623 1107 1649 1732 1815 50

60 1524 747 1328 1979 2079 2178 60

70 1778 872 1550 2309 2425 2541 70

80 2032 996 1771 2639 2772 2905 80

90 2286 1121 1992 2969 3118 3268 90

100 2540 1245 2214 3299 3465 3631 100

110 2794 1370 2435 3628 3811 3994 110

120 3048 1494 2657 3958 4158 4357 120

130 3302 1619 2878 4288 4504 4720 130

140 3556 1743 3099 4618 4850 5083 139

150 3810 1868 3321 4948 5197 5446 149

160 4064 1992 3542 5278 5543 5809 159

170 4318 2117 3763 5608 5890 6172 169

180 4572 2241 3985 5937 6236 6535 179

190 4826 2366 4206 6267 6583 6898 189

200 5080 2491 4428 6597 6929 7261 199

250 6350 3113 5535 8246 8661 9077 249

300 7620 3736 6641 9896 10394 10892 299

H (mm) W (mm)

Min distance

Average

Max distance

Offset (mm)Diagonal

For example, if you are using a 120-inch screen, the recommended projection distance is 4158 mm.

If your measured projection distance is 5200 mm, the closest match in the "Projection distance (mm)" column is 5197 mm. Looking across this row shows that a 150'' (about 3.8 m) screen is required.

To optimize your projection quality, we suggest to do the projection within non-gray area.

Mounting the projector

If you intend to mount your projector, we strongly recommend that you use a proper fitting BenQ projector mounting kit and that you ensure it is securely and safely installed.

If you use a non-BenQ brand projector mounting kit, there is a safety risk that the projector may fall down due to an improper attachment through the use of the wrong gauge or length screws.

17 Positioning your projector

Page 18

Before mounting the projector

Ceiling/Wall mount screw: M4 (Max L = 25 mm; Min L = 20 mm)

Unit: mm

• Purchase a BenQ projector mounting kit from the place you purchased your BenQ projector.

• BenQ recommends that you also purchase a separate Kensington lock compatible security cable and attach it securely to both the Kensington lock slot on the projector and the base of the mounting bracket. This will perform the secondary role of restraining the projector should its attachment to the mounting bracket become loose.

• Ask your dealer to install the projector for you. Installing the projector on your own may cause it to fall and result in injury.

• Take necessary procedures to prevent the projector from falling off such as during an earthquake.

• The warranty doesn’t cover any product damage caused by mounting the projector with a non-BenQ brand projector mounting kit.

• Consider the surrounding temperature where the projector is ceiling/wall mounted. If a heater is used, the temperature around the ceiling/wall may be higher than expected.

• Read the user manual for the mounting kit about the range of torque. Tightening with torque exceeding the recommended range may cause damage to the projector and subsequently falling off.

• Make sure the power outlet is at an accessible height so that you can easily shut down the projector.

Ceiling/Wall mount installation diagram

Adjusting the projected image

Adjusting the projection angle

If the projector is not placed on a flat surface or the screen and the projector are not perpendicular to each other, the projected image becomes trapezoidal. You can screw the adjuster feet to fine-tune the horizontal angle.

To retract the feet, screw the adjuster feet in a reverse direction.

100

75146

Do not look into the lens while the lamp is on. The strong light from the lamp may cause damage to your eyes.

18 Positioning your projector

Page 19

Auto-adjusting the image

Press .

In some cases, you may need to optimize the picture quality. To do this, press AUTO. Within 3 seconds, the built-in Intelligent Auto Adjustment function will re-adjust the values of Frequency and Clock to provide the best picture quality.

The current source information will be displayed in the corner of the screen for 3 seconds.

This function is only available when PC signal (analog RGB) is selected.

Fine-tuning the image size and clarity

Adjust the projected image to the size that you need using the zoom ring.

Sharpen the image by rotating the focus ring.

Correcting keystone

Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection.

To correct this, you will need to manually correct it following these steps.

1. Do one of the following steps to display the keystone correction page.

• Press / on the projector or remote control.

• Go to Advanced Menu - Display > Keystone and press OK.

2. After the Keystone correction page displays. Press to correct keystoning at the top of the image. Press to correct keystoning at the bottom of the image.

19 Positioning your projector

Page 20

Connection

55 6

2 1

Laptop or desktop computer

VGA cable

VGA to DVI-A cable

USB cable

Component Video to VGA (D-Sub) adapter cable

Audio cable

HDMI cable

USB flash drive

Wireless dongle (WDR02U)

2345678

Speakers

Monitor

Wireless Connection

A/V device

Laptop or desktop computer

Ta b l e t P C

Smartphone

Bluetooth speakers

Wireless AP

Keyboard/Mouse

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

• In the connections above, some cables may not be included with the projector (see Shipping contents on page 7). They are commercially available from electronics stores.

• The connection illustrations are for reference only. The rear connecting jacks available on the projector vary with each projector model.

• Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + function key with a monitor symbol turns the external display on/off. Press FN and the labeled function key simultaneously. Refer to your notebook's documentation to find your notebook's key combination.

• If the selected video image is not displayed after the projector is turned on and the correct video source has been selected, check that the video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly.

20 Connection

Page 21

You need only connect the projector to a video source device using just one of the connecting methods, however each provides a different level of video quality.

Te r m i n a l Picture quality

HDMI

Component Video (through RGB

input)

Best

Better

Connecting audio

The projector has built-in mono speaker(s) which are designed to provide basic audio functionality accompanying data presentations for business purposes only. They are not designed for, nor intended for stereo audio reproduction use as might be expected in home theater or home cinema applications. Any stereo audio input (if provided), is mixed into a common mono audio output through the projector speaker(s).

The built-in speaker(s) will be muted when the AUDIO OUT jack is connected.

• The projector is only capable of playing mixed mono audio, even if a stereo audio input is connected.

21 Connection

Page 22

Starting up the projector

1. Plug the power cord. Turn on the power outlet switch (where fitted). The power indicator on the projector lights orange after power has been applied.

2. Press on the projector or on the remote control to start the projector. The power indicator

flashes green and stays green when the projector is on.

The start up procedure takes about 30 seconds. In the later stage of start up, a startup logo is projected.

(If necessary) Rotate the focus ring to adjust the image clearness.

• Please use the original accessories (e.g. power cord) to avoid possible dangers such as electric shock and fire.

• If the projector is still hot from previous activity, it will run the cooling fan for approximately 90 seconds before energizing the lamp.

3. If this is the first time you turn on the projector, the setup wizard appears to guide you through setting up the projector. If you have already done this, skip this process.

• Use the arrow keys ( , , , ) to move through the menu items.

• Use OK to confirm the selected menu item.

• Use the back button to return to the previous menu.

• Use the menu button to skip a menu.

The Setup Wizard screenshots are for reference only and may differ from the actual design.

Step 1:

Choosing a Projector Position.

22 Starting up the projector

Page 23

Step 2:

Choosing a Language.

Available languages may vary by the product supplied for your region and may be updated without prior notice.

Step 3:

Adjusting Keystone.

Step 4:

Configure the Wireless Setting by selecting a wireless network and entering the password.

23 Starting up the projector

Page 24

Step 5:

Specify Time Zone.

Step 6:

Read the Privacy Announcement and press OK to agree with the statement.

If at a future time you want to remove your consent to the privacy agreement, you may do so in the General > About > Privacy Announcement menu of the BenQ Launcher Settings menu. See About on page 53 for more information.

Once you’ve completed the setup wizard; you may start using the projector.

24 Starting up the projector

Page 25

Operation (under Launcher source)

BenQ Launcher

BenQ Launcher is the projector’s operating system that allows you to wirelessly cast your device’s screen, play files, run apps, as well as adjust projector settings.

Use the remote control or connect a USB mouse to the projector’s USB-1 or USB-2 ports to navigate BenQ Launcher and operate its functions.

The BenQ Launcher home screen

Upon initial start up or when BenQ Launcher is selected in the input source menu, the projector will display BenQ Launcher. If the projector is projecting from an input source (e.g. HDMI or PC), you

can return to BenQ Launcher mode by pressing the source button or the LAUNCHER button on the remote control and then selecting BenQ Launcher in the input source menu.

When the Auto Source Search function is enabled in the Advanced > Settings menu of the projector’s OSD menu, the projector will display the BenQ Launcher home screen by default every time it is powered on. If the Auto Source Search function is disabled, the projector will detect if a signal is available from the input source that was last used and switch to that input source if it is available, if a signal is not available or the projector was set to BenQ Launcher during the previous session, the projector will enter the BenQ Launcher home screen. See

Settings on page 78.

Actual screen may vary based on your BenQ Launcher firmware version.

The BenQ Launcher home screen features five main sections:

• Status Bar icons - Icons that display the time, Bluetooth, and wireless status.

• Wireless Projection buttons - Provides instructions on how to project wirelessly via iOS/Android devices or a laptop/PC.

• Source menu - Allows you to select open media files from storage devices connected to the USB-1 or USB-2 ports, or video input source connected to the HDMI or PC ports for projection.

• App Shortcuts - Quick access to the pre-installed File Manager, BenQ Suggests, along with other installed apps.

25 Operation (under Launcher source)

Page 26

• Settings menus - Shortcuts to the settings menus to adjust wireless network, Bluetooth and other

Source Menu

settings.

Press the down button to access the Source menu, App shortcuts, and Settings menus.

Navigating the BenQ Launcher home screen

1. From the BenQ Launcher home screen, press / / / to select the desired function and press OK.

2. Follow on-screen instructions for further operations.

Using the source menu

Press the down button from the BenQ Launcher home screen to access the Source menu, which displays the input source options: USB, HDMI, and PC. Press OK to select the desired input source. See Connection on page 20 for more information.

You may also press the source button from any screen within BenQ Launcher to access the Source menu.

Using the app menu

Press the down button twice from the BenQ Launcher home screen to access the app shortcuts menu, which displays the pre-installed BenQ Suggests, and File Manager apps as well as other apps that have been installed on the projector.

26 Operation (under Launcher source)

Page 27

To access all the apps installed on the projector, see All Apps on page 52. For details on how to

App Shortcuts

Full Settings Menu Sub-Menu Shortcuts

re-order the shortcuts see Screen Settings on page 56.

Using the BenQ Launcher Settings menus

Press the down button three times from the BenQ Launcher home screen to access the settings menu section, which features a button for the projector’s full settings menu as well as shortcut buttons for various sub-menus within the settings menus.

Actual screen may vary based on your BenQ Launcher firmware version.

For more information on the settings menus see About the Settings menu on page 47.

Inputting text

Various menus within BenQ Launcher may require that you input text. You may either connect a keyboard to the USB-1 port at the rear of the projector or follow the steps below:

1. Select the text field where you want to input text.

2. Press OK and a full alphanumeric keyboard will appear on screen.

3. Press / / / to navigate the keyboard, and press OK to select the letter/key/symbol you want to enter into the text field.

27 Operation (under Launcher source)

Page 28

4. Press the back button at anytime to exit out of the keyboard.

Actual keyboard types may vary based on your language preference setting. See Keyboard on page 58 for more information.

Switching to BenQ Launcher from an input source

When HDMI or PC is selected in the source menu, the projector will exit the BenQ Launcher interface to project video from the input source (e.g. a Blu-Ray/DVD player, set-top box, or PC). The projector will remain outside of the BenQ Launcher interface as long as the HDMI or PC input source is selected or (depending on Auto Source Search settings) until the projector is powered off and back on again.

As a result, anytime the user wants to wirelessly cast their device’s screen, view media files stored on a flash drive, or run apps, they must return to the BenQ Launcher interface. To return to BenQ Launcher:

1. Press the source button or the LAUNCHER button on the remote control.

2. Select BenQ Launcher in the source menu.

When the Auto Source Search function is enabled in the Advanced > Settings menu of the projector’s OSD menu, the projector will display the BenQ Launcher home screen by default once it is powered on. If the Auto Source Search function is disabled, the projector will detect if a signal is available from the input source that was last used and switch to that input source if it is available, if a signal is not available or the projector was set to BenQ Launcher during the previous session, the projector will enter the BenQ Launcher home screen. See Settings on

page 78.

Wireless Connections

Connecting the projector to a wireless network

Before you can project wirelessly via the projector, you must first connect the projector to a wireless network. To connect your projector to a wireless network, or to switch wireless networks:

If you have already connected the projector to a wireless network during the setup wizard you may skip the steps in this section.

1. Install the provided wireless dongle into the wireless dongle port (see Installing the wireless dongle

on page 8).

2. Power on the projector (see Operation (under Launcher source) on page 25).

28 Operation (under Launcher source)

Page 29

3. On the home screen of the BenQ Launcher interface, select Wireless Network Settings and press OK to access the wireless settings menu.

4. Select Wireless Network Settings and press OK to enable.

5. Select the SSID for the wireless AP you want to connect to and press OK.

• To connect to a hidden wireless network select Add A Network and enter the SSID, security setting, and password for the network.

• The list of available wireless networks will be refreshed every 10 seconds. If the desired SSID is not listed please wait for refreshing to complete.

29 Operation (under Launcher source)

Page 30

6. If you chose a secured SSID for the first time, a window appears prompting you to enter the appropriate password. Use the virtual keypad to enter the password. After you have entered the password, select Next and the projector will automatically connect.

• The password will be stored in the projector’s memory. In the future, if you select the same SSID again, you will not be prompted to enter a password unless you delete the SSID from the projector’s memory.

• If the password is typed incorrectly, you can select either re-enter the password or press the back button to return to the list of SSIDs.

7. Once you have successfully connected to the wireless AP a wireless connection icon will appear at the top right corner of the BenQ Launcher interface. You can now connect your devices wirelessly to the projector to cast your device’s screen.

Wireless Projection for iOS & macOS

To connect an iOS device to the projector and cast your device’s screen via AirPlay:

1. On the home screen of the BenQ Launcher interface, select Wireless Projection for iOS & macOS and press OK.

30 Operation (under Launcher source)

Page 31

2. On your iOS mobile device’s wireless network menu connect to the wireless network shown on the Wireless Projection for iOS & macOS screen and then select Next.

3. Follow the instructions shown on the Wireless Projection for iOS & macOS screen to project your iOS device’s screen via AirPlay.

4. Select Finished on the Wireless Projection for iOS & macOS menu to finish the tutorial and return to the home screen.

The quality of the wireless projection may depend on the quality of the wireless signal along with the screen mirroring compatibility of the mobile device.

Once you have finished projecting, disable AirPlay on your iOS device to end the connection.

31 Operation (under Launcher source)

Page 32

Wireless Projection for Android

To connect an AndroidTM device to the projector and cast your device’s screen:

1. On the home screen of the BenQ Launcher interface, select Wireless Projection for Android™ and press OK.

2. On your Android mobile device’s wireless network menu connect to the wireless network shown on the Wireless Projection for Android™ screen and then select Next.

3. Follow the instructions shown on the Wireless Projection for Android™ screen to project your Android device’s screen.

32 Operation (under Launcher source)

Page 33

4. Select Finished on the Wireless Projection for Android™ menu to finish the tutorial and return to the home screen.

The quality of the wireless projection may depend on the quality of the wireless signal along with the screen mirroring compatibility of the mobile device.

Once you have finished projecting, disable screencasting on your Android device to end the connection.

Wireless Projection for PC

To connect an PC to the projector and cast your PC’s screen:

1. On the home screen of the BenQ Launcher interface, select Wireless Projection for PC and press OK.

33 Operation (under Launcher source)

Page 34

2. On your PC’s wireless network menu connect to the wireless network shown on the Wireless Projection for PC screen and then select Next.

3. Follow the instructions shown on the Wireless Projection for PC screen to project your PC’s screen.

4. Select Finished on the Wireless Projection for PC menu to finish the tutorial and return to the home screen.

The quality of the wireless projection may depend on the quality of the wireless signal along with the screen mirroring compatibility of the PC.

Once you have finished projecting, disable screencasting on your PC to end the connection.

34 Operation (under Launcher source)

Page 35

Wireless Hotspot

In situations where the projector is out-of-range of a wireless network (for example while on a camping trip), you can configure the projector to act as a wireless hotspot to create a closed network for devices to connect directly to the projector via a wireless connection and to project files from their local storage.

The projector will have no access to the Internet while in wireless hotspot mode.

To create a wireless hotspot:

1. Install the wireless dongle provide into the wireless dongle port (see Installing the wireless dongle

on page 8).

2. Power on the projector (see Operation (under Launcher source) on page 25).

3. On the home screen of the BenQ Launcher interface, press the down arrow key the three times to navigate to the Settings menus.

4. Select Settings and press OK.

5. Select Hotspot and press OK.

35 Operation (under Launcher source)

Page 36

6. (Optional) Select Hotspot Password and press OK to change the password of the wireless hotspot.

The projector will have no access to the Internet while in wireless hotspot mode.

7. Select Hotspot and press OK to enable wireless hotspot.

8. Once wireless hotspot is enabled, use the name shown in the Hotspot Name field as the SSID to connect to from your mobile device’s wireless menu and use the password shown in the Hotspot Password field as the connection password.

36 Operation (under Launcher source)

Page 37

9. If the wireless hotspot can not be found by your device, select Normal (2.4G) under the Internet Quality heading.

After the wireless hotspot is setup, follow the corresponding connection instructions described in the previous section(s) to connect to the projector directly and cast your device’s screen.

37 Operation (under Launcher source)

Page 38

External Storage Connections

Connecting a flash drive

Connect a USB-A flash drive to the USB-1 or USB-2 port at the rear of the projector to play files stored on the flash drive.

• If you want to play media from a flash drive while the projector is set to the HDMI or PC input source, you must first return to the BenQ Launcher interface by pressing the source button

the remote control and then selecting BenQ Launcher.

• A red dot will appear above the USB icon in the Source menu anytime a USB-A flash drive is connected to the projector.

To play files stored on a flash drive:

1. Connect the USB-A flash drive to the USB-1 or USB-2 port at the rear of the projector.

2. A pop-up notification from the File Manager app will appear indicating that a storage device is detected. Select All Files and press OK to open the device.

or the LAUNCHER button on

• If you do not want to open the media file immediately after connecting the storage device, press the back button

to remain on the current screen.

• If you are trying to open a media file from a storage device that was already previously connected, select USB in the Source menu, press OK, and select All Files.

38 Operation (under Launcher source)

Page 39

3. The File Manager app will launch and show selections for your connected device, select Mobile Device1 and press OK.

If flash drives are connected to both USB-A ports at the rear of the projector, select Mobile Device1 for the storage device that was connected first or Mobile Device2 for the storage device that was connected most recently.

4. Navigate to the folder where the media file you want to play is located and press OK.

5. Select the media file you want to play and press OK.

39 Operation (under Launcher source)

Page 40

6. A prompt will appear asking you to choose a media player app, select the app you want to use to open the media file and press OK.

Check the Set as default box to configure the selected media player app as the default app for opening the type of media file (e.g. video, photo, music) of the selected file.

7. The media file will open in the selected media player app.

Using WPS Office to view documents

The WPS Office app allows you to open document files including PDFs as well as Microsoft Word, PowerPoint and Excel documents.

To edit a file with WPS Office:

1. Select Open ( ) on the left panel to browse and open a file located in either the projector’s

internal memory or an external storage device.

40 Operation (under Launcher source)

Page 41

Select the function menu on the top panel to access the file format's various functions.

The description below is for a PowerPoint file, the function menus for other file formats will vary.

Function Description

File Select to open, save, share, print, and manage your presentations.

View Select to change or edit the presentation views.

Play Select to start or set up a slide show.

Edit Select to edit the content or format of the slides.

Insert Select to insert tables, pictures, charts, comments, video, or audio.

Transitions Select to apply or adjust the timing of a transition.

Pen Select to write, draw, paint or sketch to the slides.

Play ()

Save As ()

Undo ()

Redo ()

Close ()

Back ()

Next ()

Select to start a slide show.

Select to save the presentation file on either the display’s internal memory, an external storage device, or cloud storage.

Select to undo an action.

Select to redo the last action.

Select to close the presentation file.

Select to return to the previous page.

Select to go to the next page.

Exit ()

Select to exit WPS Office.

41 Operation (under Launcher source)

Page 42

Bluetooth Connections

The projector is able to connect to a Bluetooth-enabled speaker or headphones to output audio directly for greater sound, particularly in outdoor settings.

• The Bluetooth connection does not support any data transfer as the projector only allows Bluetooth connections for audio output.

• You may not use the projector to broadcast audio from a Bluetooth-enabled mobile device.

Pairing/Connecting to a Bluetooth speaker or headphones

Pairing is the process by which your projector creates a connection to a Bluetooth speaker or headphones for the first time. Once both devices have been successfully paired each device will have the corresponding device’s pairing information stored internally and both will be able to connect automatically when they are within an ~10 meter range of each other and Bluetooth is enabled on the projector.

To pair your projector to a Bluetooth speaker or headphones:

1. Install the provided wireless dongle into the wireless dongle port (see Installing the wireless dongle

on page 8).

2. Power on the projector (see Operation (under Launcher source) on page 25).

3. Press the down arrow key and right arrow key to navigate to the settings sub-menu shortcuts.

4. Select Bluetooth and press OK.

5. Select Bluetooth and press OK to enable Bluetooth.

42 Operation (under Launcher source)

Page 43

6. Activate Bluetooth-pairing mode on the speaker or headphones.

7. Select the speaker or headphones from the Device List in the Bluetooth setting menu and press OK.

8. When the projector and speaker or headphones have successfully connected the device listing in the Bluetooth setting menu will be labeled Connected, you can now output the audio from the projector to the speaker or headphone.

Once you have successfully paired your projector with the Bluetooth speaker, pairing information will be stored on both devices and a connection will automatically be made when Bluetooth is enabled on both devices and both devices are within range of each other.

• If you replace the wireless dongle on your projector anytime after you have paired your projector with a Bluetooth device you will need to re-pair your projector to the device in order to create a Bluetooth connection.

• The quality of the Bluetooth transmission may depend on the quality of the Bluetooth signal along with the compatibility of the mobile device.

Ending the Bluetooth connection

In cases where you want to disconnect a speaker or headphones from the projector and connect to another speaker or headphones follow the steps below:

1. Press the down arrow key and right arrow key to navigate to the settings sub-menu shortcuts.

2. Select Bluetooth and press OK.

3. Select the already connected speaker or headphones from the Device List in the Bluetooth setting menu and press OK.

4. Confirm that you want to disconnect the speaker or headphones from the projector.

5. Activate Bluetooth-pairing mode on the new speaker or headphones.

6. Select the new speaker or headphones from the Device List in the Bluetooth setting menu and press OK.

Deactivating the Bluetooth speaker or headphones

To deactivate Bluetooth on the projector so that it no longer outputs its audio to a separate speaker or headphones:

1. Press the down arrow key and right arrow key to navigate to the settings sub-menu shortcuts.

2. Select Bluetooth and press OK.

43 Operation (under Launcher source)

Page 44

3. Select Bluetooth and press OK to disable Bluetooth.

Apps

The Shortcut section of BenQ Launcher features shortcuts to the pre-installed File Manager, and BenQ Suggests apps, as well as a customizable selection of downloaded apps.

Certain apps require the use of a mouse and/or keyboard to operate. It is suggested that you connect a mouse and/or keyboard to the projector before opening any apps from the Shortcut section.

To access all the apps installed on the projector, select All Apps in the Settings menu, see All Apps on

page 52.

To configure the apps that appear in the Shortcut section, see Screen Settings on page 56.

44 Operation (under Launcher source)

Page 45

BenQ Suggests

The BenQ Suggests allows you to view apps suggested by BenQ for download.

Select the category on the left panel to browse the suggested apps based on the type. Select an app from the selected category and press OK to view a basic description of the app and access the download link.

Certain apps require the use of a mouse and/or keyboard to operate. It is suggested that you connect a mouse and/or keyboard to the projector before downloading any apps from BenQ Suggests.

File Manager

The File Manager app allows you to browse, open, and manage files stored on your projector’s internal storage or in connected storage devices (e.g. a USB flash drive).

Function Description

Select to open the list of available installation files for Android apps stored internally or on an external storage device.

APK

For APK files located on external storage devices, the files must be saved in the outer

most directory of the storage device to be able to be detected by File Manager.

45 Operation (under Launcher source)

Page 46

Video

All Files


Function Description

Select to open the list of available video files stored internally or on an external storage device.

For video files located on external storage devices, the files must be saved in the outer

most directory of the storage device to be able to be detected by File Manager.

Select to browse the various storage options for the projector including internal storage or connected external storage devices.

Select Local to browse the projector’s internal storage, select Mobile Device1 or Mobile Device2 to browse external storage devices. For information on opening media files located on external storage devices, see Connecting a flash drive on page 38.

Select to open the list of available image files stored internally or on an external storage device.

For image files located on external storage devices, the files must be saved in the outer

most directory of the storage device to be able to be detected by File Manager.

Music

Settings

Select to open the list of available music files stored internally or on an external storage device.

For music files located on external storage devices, the files must be saved in the outer

most directory of the storage device to be able to be detected by File Manager.

Select to configure file management settings including options for

Display Mode, Auto cleaning up APK file, Image view, Quick Open, Hidden File, and Clear Association.

46 Operation (under Launcher source)

Page 47

Navigating the Settings Menu

About the Settings menu

To let you make various adjustments or settings on the projector, its wireless connections, and the projected image, BenQ Launcher provides a Settings menu. Under the Settings menu are sub-menus for various settings.

To access the Settings menu, in the BenQ Launcher home screen press the down button three times, and then select Settings.

If the projector is not of the latest version of firmware, a red dot will appear on the Settings icon. In such a circumstance, users can go to the About > Software Update menu and then select Update to start firmware update. The red dot will disappear when the projector is updated with the latest version of firmware. See System

Update on page 62 for more information.

Under the settings menu there are three subcategories: General, Display, and Preference.

The sub-menus in the Display category feature only a partial number of items that adjust your projector’s display settings, for a full menu of display related settings enter the Advanced OSD settings menu. See Advanced menu on

page 68 for a listing of the full Display settings.

47 Operation (under Launcher source)

Page 48

Using the Settings menu

To access the various settings menus:

• Use the left and right arrow keys ( / ) to move through the main settings menus.

• Use OK to select the desired menu.

• When configuring items within a menu:

• Use the up and down arrow keys ( / ) to move to the item you want to configure.

• Use left and right arrow keys ( / ) to toggle through the available options.

• Use OK to enable/disable options or select sub-menu options.

• Use the back button to return to the main settings menu.

• Use the home button to return to the BenQ Launcher home screen.

Internet

Enables a wireless network connection for the projector. See Connecting the

Wireless

projector to a wireless network on page 28 for details.

Network Settings

This function is only available when Hotspot is disabled.

Speed Test Tests the speed of the projector’s Internet connection.

Diagnosing Diagnoses the status of the projector’s Internet connection.

Allows you to add a specific network that may be hidden or undetected in the

Add Network

Available Networks. Once selected you will be prompted to enter the SSID and

security settings for the network.

Lists the available wireless access points which the projector can connect to. See

Connecting the projector to a wireless network on page 28 for details.

Available Networks

Available Networks is only available when Wireless Network Settings is disabled.

48 Operation (under Launcher source)

Page 49

Hotspot

Hotspot Name

Hotspot Password

Internet Quality

Enables wireless hotspot for the projector, allowing other devices to connect to the projector directly. See Wireless Hotspot on page 35 for details.

Sets the name for the projector’s wireless hotspot, which appears in the wireless network list for devices looking to connect directly to the projector.

The default name for the projector’s wireless hotspot is "BenQ E600-xxxx". The final four digits are

the last four digits of its MAC Address.

Sets the password for the projector’s wireless hotspot.

The password needs to be at least 8 characters.

Sets the frequency for the projector’s wireless hotspot signal. Available options include Higher (5G) and Normal (2.4G).

49 Operation (under Launcher source)

Page 50

Bluetooth

My Devices

Scan for Devices

Available Devices

Enables Bluetooth for the projector, allowing the projector to output its audio to a Bluetooth speaker or headphones.

Lists of previously paired Bluetooth devices.

This function is only accessible when Bluetooth is enabled.

Refreshes the list of devices.

This function is only available when Bluetooth is enabled.

Lists the available Bluetooth devices which the projector can pair and connect to.

This function is only available when Bluetooth is enabled.

50 Operation (under Launcher source)

Page 51

Sounds

Feedback Sound

Volume Adjusts the sound level for the projector.

Mute Disables/Enables audio for the projector.

Enables/Disables feedback on the audio provided by the projector.

Clear Memory

Clears out the memory of unnecessary files and boosts available RAM.

51 Operation (under Launcher source)

Page 52

All Apps

Select the All Apps menu to access all the apps that have been installed on the projector.

• Select an app and press OK to launch the app.

• Select an app and press the menu button ( ) to uninstall the app.

Recent Apps

Select the Recent Apps menu to access a list of apps that have been recently used.

• Select any icon and press the down button ( ) to remove the icon from the list of recently used apps.

• Select any icon and press the menu button ( ) to clear all icons from the list of recently used apps.

52 Operation (under Launcher source)

Page 53

About

Projector Information

Android System Information

Software Update

Privacy Announcement

Android System Reset


Displays information on the current status of the projector including the current

Native Resolution, Picture Mode, Light Mode, Light Usage Time, Firmware Version, and Service Code.

Displays information on the Android operating system including Android Version, Ram, System storage, Internal storage, and MAC address.

Allows you to update the Android operating system via an Over-The-Air (OTA) update or a USB flash drive. For more information see System Update on page 62,

Allows you to view and accept or reject BenQ’s privacy policy.

Returns all settings to the factory preset values.

The options available for the Picture settings menu are the same as the options available in the OSD menu. See Advanced menu on page 68 for the Picture settings options.

53 Operation (under Launcher source)

Page 54

Light Settings

The options available for the Light Settings settings menu are the same as the options available in the OSD menu. See Advanced menu on page 68 for the Light Settings settings options.

Keystone

The options available for the Keystone settings menu are the same as the options available in the OSD menu. See Advanced menu on page 68 for the Keystone settings options.

54 Operation (under Launcher source)

Page 55

Projector Position

The options available for the Projector Position settings menu are the same as the options available in the OSD menu. See Advanced menu on page 68 for the Projector Position settings options.

The options available for the 3D settings menu are the same as the options available in the OSD menu. See Advanced menu on page 68 for the 3D settings options.

55 Operation (under Launcher source)

Page 56

Screen Settings

Sets which app shortcuts are displayed on the BenQ Launcher home screen and their sequence. The home screen requires at least one shortcut and allows up to ten shortcuts.

• Auto: Enables the projector to automatically arrange the sequence of app shortcuts on the home screen so that the most recently used app will appear first in the row.

Shortcut

Settings

• Manual: Enables the user to manually arrange which app shortcuts to be displayed on the home screen and their sequence. Press OK on an app in the Adjust menu and then press / to adjust the sequence of the apps in the apps shortcuts section. Press OK on an app in the Show/Hide Apps menu to check (show) or uncheck (hide) the shortcuts.

This function is only available when Auto is disabled.

Sets which settings menu shortcuts are displayed on the BenQ Launcher home screen and their sequence. The home screen requires at least one shortcut and allows up to eight shortcuts.

• Manual: Enables the user to manually arrange which settings menu shortcuts to be displayed on the home screen and their sequence. Press OK on a settings menu in the Adjust menu and then press / to adjust the sequence of the settings menu shortcuts in the settings menu section. Press OK on an settings menu in the Show/Hide settings menu to check (show) or uncheck (hide) the shortcuts.

56 Operation (under Launcher source)

Page 57

Date & Time

Time Zone Sets the time zone for the projector

Format Sets the date and time format as either HH:MM or YYYY/MM/DD HH:MM.

Language

Sets the language for BenQ Launcher.

57 Operation (under Launcher source)

Page 58

Keyboard

Current Keyboard

Keyboard Settings

Displays the current keyboard setting.

Sets the projector’s virtual keyboard for inputting text. The available options are BenQ Keyboard and Android keyboard (AOSP).

To input Chinese characters, set the language preference to traditional Chinese or simplified

Chinese, and set the keyboard to BenQ Keyboard.

58 Operation (under Launcher source)

Page 59

BenQ Smart Control

The settings menu also features a link to install the BenQ Smart Control app, which lets you transform your smartphone into a remote control to control the projector via buttons and/or touch gestures.

Installing the BenQ Smart Control app on your smartphone

To i n s t a l l t h e BenQ Smart Control app on your smartphone:

1. Choose one of the following options:

• Connect your smartphone to the same wireless network as your projector.

• Enable wireless hotspot for your projector and then connect your smartphone to the projector’s wireless hotspot. For instructions on how to enable wireless hotspot for your projector see

Hotspot on page 49.

2. Select BenQ Smart Control in the Settings menu of the BenQ Launcher home screen and then press OK.

3. Scan the QR code shown on the projector with your smartphone, this will open a download link on your smartphone.

4. Download and install the BenQ Smart Control on to your smartphone.

For some smartphones you may first need to allow your smartphones to install apps using downloaded installation files from your smartphones settings menu.

Using the BenQ Smart Control app

To begin using the BenQ Smart Control app:

59 Operation (under Launcher source)

Page 60

1. Choose one of the following options:

• Connect your smartphone to the same wireless network as your projector.

• Enable wireless hotspot for your projector and then connect your smartphone to the projector’s wireless hotspot. For instructions on how to enable wireless hotspot for your projector see

Hotspot on page 49.

You must be connected to either the same wireless network as the projector or the projector’s wireless hotspot for BenQ Smart Control to work correctly.

2. Open the BenQ Smart Control app on your smartphone.

3. Select the projector from the BenQ Smart Control device list.

The default name for the projector is "BenQ E600-xxxx" where the final four digits are the last four digits of its MAC Address.

4. Choose one of the following methods to use BenQ Smart Control:

• Tap DPad to use the pre-configured buttons in the app to control your projector.

60 Operation (under Launcher source)

Page 61

• Tap Mouse to use touch gestures on your smartphone to control the cursor on the projector similar to a mouse.

61 Operation (under Launcher source)

Page 62

System Update

It is suggested that users regularly update their projector with the latest version of the firmware to optimize the user experience. The projector uses Over-the-Air (OTA) updates to install the update file wirelessly.

When a new version is available on the BenQ OTA server, a message will pop up once the projector is connected to a wireless network. Follow the steps below to begin updating the firmware:

1. Select DOWNLOAD to download the update file.

2. Once the download is completed, the projector will restart automatically. Do not turn off or unplug the projector before the projector is finished updating and BenQ Launcher reappears on the screen.

If you select CANCEL when the system upgrade message appears, a System Update button will appear in the settings menu of the BenQ Launcher home screen and feature a red dot as a reminder that a newer version of firmware is available on the BenQ OTA server. Users can select the System Update and press OK to upgrade the system at any time.

62 Operation (under Launcher source)

Page 63

Operation (under non-Launcher source)

Basic Menu

Brightness

Aspect Ratio

Light Mode

Picture Mode

Volume

Information

Menu Type

Auto

Presentation

SmartEco

Enter

Exit

Wireless LAN

14253

Using the projector menus under non-Launcher source

When the input signal is HDMI or PC/YPbPr, you can use 2 types of On-Screen Display (OSD) menus for making various adjustments and settings.

• Basic OSD menu: provides primary menu functions. (See Basic menu on page 67)

• Advanced OSD menu: provides full menu functions. (See Advanced menu on page 68)

To access the OSD menu, press on the projector or remote control.

• Use the arrow keys ( / / / ) on the projector or remote control to move through the menu items.

• Use OK on the projector or remote control to confirm the selected menu item.

The first time you use the projector (after finishing the initial setup), Basic OSD menu displays.

The OSD screenshots below are for reference only, and may differ from the actual design.

Below is the overview of the Basic OSD menu.

Menu Type

Press OK to enter the menu.

Main menu Status

Current input signal

Press to go to the previous page or to exit.

If you intend to switch from the Basic OSD menu to the Advanced OSD menu, follow the instructions below:

1. Go to Basic Menu > Menu Type.

2. Press OK and press / to select Advanced. Next time when you turn on the projector, you

may access the Advanced OSD menu by pressing .

63 Operation (under non-Launcher source)

Page 64

Below is the overview of the Advanced OSD menu.


Picture Mode

Brightness

Contrast

Color

Sharpness

Brilliant Color

Off

Reference Mode

Advanced Color Settings

Display

Settings

Information

Enter Exit

Return

Presentation

Reset Picture

System

Input New Password

Return

Main menu & Main menu icon

Press to go to the previous page.

Press to go to

Sub-menu

the previous page

or to exit. Current input signal

Status

Press OK to enter the menu.

Likewise, when you wish to switch from the Advanced OSD menu to the Basic OSD menu, follow the instructions below:

1. Go to Advanced Menu - System > Menu Settings and press OK.

2. Select Menu Type and OK.

3. Press / to select Basic. Next time when you turn on the projector, you may access the Basic OSD menu by pressing .

Securing the projector

Using a security cable lock

The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock to secure the projector. You can locate a security bar on the bottom side of the projector. See item 19 on page 9.

Utilizing the password function

Setting a password

1. Go to Advanced Menu - Settings > Security Settings. Press OK. The Security Settings page appears.

2. Highlight Change Password and press OK.

3. The four arrow keys ( , , , ) respectively represent 4 digits (1, 2, 3, 4). According to the password you desire to set, press the arrow keys to enter six digits for the password.

4. Confirm the new password by re-entering the new

5. To activate the Power On Lock function, press / to

password. Once the password is set, the OSD menu returns to the Security Settings page.

highlight Power On Lock and press / to select On. Input the password again.

64 Operation (under non-Launcher source)

Page 65

• The digits being input will display as asterisks on-screen. Make a note of your selected password and keep it in a

Password Error

Please try again.

Please write down the recall code, and contact BenQ Customer Center.

Recall C ode:

Recall Password

Return

safe place in advance or right after the password is entered so that it is available to you should you ever forget it.

• Once a password has been set and the power on lock is activated, the projector cannot be used unless the correct password is entered every time the projector is started.

If you forget the password

If you enter the wrong password, the password error message will appear, and the Input Current Password message follows. If you absolutely do not remember the password, you can use the password recall procedure. See

Entering the password recall procedure on page 65.

If you enter an incorrect password 5 times in succession, the projector will automatically shut down in a short time.

Entering the password recall procedure

1. Press and hold AUTO for 3 seconds. The projector will display a coded number on the screen.

2. Write down the number and turn off your projector.

3. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

Changing the password

1. Go to Advanced Menu - Settings > Security Settings > Change Password.

2. Press OK. The message “Input Current Password” appears.

3. Enter the old password.

• If the password is correct, another message “Input New Password” appears.

• If the password is incorrect, the password error message will appear, and the message “Input Current Password” appears for your retry. You can press to cancel the change or try

another password.

4. Enter a new password.

5. Confirm the new password by re-entering the new password.

Disabling the password function

To disable password protection, go to Advanced Menu - Settings > Security Settings > Power On Lock and press / to select Off. The message “Input Current Password” appears. Enter the

current password.

• If the password is correct, the OSD menu returns to the Security Settings page. You will not have to enter the password next time turning on the projector.

• If the password is incorrect, the password error message will appear, and the message “Input Current Password” appears for your retry. You can press to cancel the change or try

another password.

Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password.

65 Operation (under non-Launcher source)

Page 66

Switching input signal

The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. When starting up, the projector automatically searches for the available signals.

When the Advanced Menu - Settings > Auto Source Search menu is On, the projector will automatically search for BenQ Launcher.

To select the source:

1. Press . A source selection bar appears.

2. Press / until your desired signal is selected and press OK.

Once detected, the selected source information will appear at the corner of the screen for seconds. If there is multiple equipment connected to the projector, repeat steps 1-2 to search for another signal.

For best display picture results, you should select and use an input signal which outputs at the projector’s native resolution. Any other resolutions will be scaled by the projector depending upon the “aspect ratio” setting, which may cause some image distortion or loss of picture clarity. See Aspect Ratio on page 72.

66 Operation (under non-Launcher source)

Page 67

Menu operation

Please note that the on-screen display (OSD) menus vary according to the signal type selected and the projector model you are using.

The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.

Menu System

Basic menu

Main menu Options Brightness Aspect Ratio Auto/Real/4:3/16:9/16:10

0~50~100

Picture Mode

Volume Light Mode Normal/Economic/SmartEco/LampSave

Information

Menu Type Basic/Advanced

Bright/Presentation/Infographic/Video/sRGB/ (3D)/User 1/User 2

0~5~10

Native Resolution Detected Resolution Source Picture Mode Light Mode 3D Format Color System Light Usage Time Firmware Version Service Code

67 Operation (under non-Launcher source)

Page 68

Advanced menu

Main menu Submenu Options


Picture Mode

Reference Mode

Brightness Contrast Color Sharpness

Bright/Presentation/Infographic/ Video/sRGB/(3D)/User 1/User 2

Bright/Presentation/Infographic/ Video/sRGB/(3D) 0~50~100

-50~0~50

-50~0~50 0~15~31

Brilliant Color On/Off

Color Temperature

Cool/Normal/Warm

R Gain (0~50~100) G Gain (0~50~100)

Color

B Gain (0~50~100)

Temperature Tuning

R Offset (-50~0~50) G Offset (-50~0~50) B Offset (-50~0~50) R (Primary Color/Hue/

Saturation/Gain)

Advanced Color Settings

G (Primary Color/Hue/ Saturation/Gain)

B (Primary Color/Hue/

Color Management

Saturation/Gain) C (Primary Color/Hue/

Saturation/Gain) M (Primary Color/Hue/

Saturation/Gain) Y (Primary Color/Hue/

Saturation/Gain)

Wall Color

Off/Light Yellow/Pink/Light Green/Blue/Blackboard

Reset Picture Reset/Cancel

68 Operation (under non-Launcher source)

Page 69

Main menu Submenu Options

Aspect Ratio Auto/Real/4:3/16:9/16:10 Keystone

-40~0~40

Test Pattern On/Off

Display

PC & Component YPbPr Tuning

Phase H. Size H：-5~0~5

Position

V：-5~0~5 Auto/Top Bottom/Frame

3D Mode

Sequential/Frame Packing/Side by Side/Off

3D Sync Invert Disable/Invert

HDMI Format

Image Resizing

Apply 3D Settings

Save 3D Settings

Digital Zoom Digital Shrink &

Shift

3D Settings 1/3D Settings 2/3D Settings 3/Off

3D Settings 1/3D Settings 2/3D Settings 3

Auto/RGB Limited/RGB Full/ YUV Limited/YUV Full

1.0X~1.8X/2.0X

0.75X~1.0X

Reset Display Reset/Cancel

69 Operation (under non-Launcher source)

Page 70

Main menu Submenu Options

Settings

Projector Installation

Front Table/Rear Table/Rear

Ceiling/Front Ceiling Remote Receiver Front/Top/Front+Top Auto Source Search On/Off Auto Sync On/Off

Normal/Economic/SmartEco/

LampSave

Reset/Cancel

Light Settings

Light Mode

Reset Light Timer

Light Usage Time Quick Cooling On/Off

Disable/5 min/10 min/15 min/

20 min/25 min/30 min

On/Off

Operation Settings

Blank Timer

Reminder Message

High Altitude Mode

Direct Power On

Power On/Off Settings

Signal Power On

Auto Power Off

Power Off Timer

Instant Restart On/Off Panel Key Lock On/Off

Security Settings

Change Password Power On Lock On/Off

Baud Rate

HDMI Equalizer

HDMI

9600/14400/19200/38400/57600/

115200

Auto/Lower/Low/Middle/High/

Higher Reset Settings Reset/Cancel

70 Operation (under non-Launcher source)

Page 71

Main menu Submenu Options

Language

Bhs Ind

System

Standby

Standby Mode Eco/Normal

Settings

Background Settings

Audio Pass Through

Off/Audio in/HDMI

Background BenQ/Black/Blue/Purple Splash Screen BenQ/Black/Blue Menu Type Basic/Advanced

Menu Settings

Menu Display Time

5 sec/10 sec/20 sec/30 sec/Always

Mute On/Off

Audio Settings

Volume Power On/Off

Ring Tone

0~5~10

On/Off

Factory Default Reset/Cancel Reset System Reset/Cancel Native Resolution Detected Resolution Source Picture Mode

Information

Light Mode 3D Format Color System Light Usage Time Firmware Version Service Code

71 Operation (under non-Launcher source)

Page 72

Basic menu

15:9 picture

(EX600)

(EW600)

(EH600)

4:3 picture

16:9 picture

4:3 picture 16:9 picture

16:10 picture

Brightness

Aspect Ratio

The higher the value, the brighter the image. Adjust this control so the black areas of the image appear just as black and that detail in the dark areas is visible.

There are several options to set the image's aspect ratio depending on your input signal source.

• Auto: Scales an image proportionally to fit the projector's native resolution in its horizontal or vertical width.

• Real: Projects an image as its original resolution and resizes it to fit within the display area. For input signals with lower resolutions, the projected image will be displayed in its original size.

• 4:3: Scales an image so that it is displayed in the center of the screen with a 4:3 aspect ratio.

• 16:9: Scales an image so that it is displayed in the center of the screen with a 16:9 aspect ratio.

Picture Mode

• 16:10: Scales an image so that it is displayed in the center of the screen with a 16:10 aspect ratio.

The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type.

• Bright: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.

• Presentation: Is designed for presentations. The brightness is emphasized in this mode to match PC and notebook coloring.

• Infographic: Is perfect for presentations with the mixture of text and graphics due to its high color brightness and better color gradation to see the details clearly.

• Video: Is suitable for playing videos in an environment where there is ambient light. Dynamic color details are preserved by BenQ enhancement technology.

• sRGB: Maximizes the purity of RGB colors to provide true-to-life images regardless of brightness setting. It is most suitable for viewing photos taken with an sRGB compatible and properly calibrated camera, and for viewing PC graphic and drawing applications such as AutoCAD.

• 3D: Is appropriate for playing 3D images and 3D video clips.

• User 1/User 2: Recalls the settings customized based on the current available picture modes. See Reference Mode on page 74.

72 Operation (under non-Launcher source)

Page 73

Volume Adjusts the sound level.

Light Mode See Setting the Light Mode on page 84.

• Native Resolution: Shows the native resolution of the projector.

• Detected Resolution: Shows the native resolution of the input signal.

• Source: Shows the current signal source.

• Picture Mode: Shows the selected mode in the Picture menu.

Information

Menu Type

• Light Mode: Shows the selected mode in the Light Settings menu.

• 3D Format: Shows the current 3D mode.

• Color System: Shows input system format.

• Light Usage Time: Shows the number of hours the lamp has been used.

• Firmware Version: Shows the firmware version of your projector.

• Service Code: Show the projector’s serial number.

Switches to the Advanced OSD menu. See Using the projector menus under

non-Launcher source on page 63.

73 Operation (under non-Launcher source)

Page 74

Advanced menu


The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type.

• Bright: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.

• Presentation: Is designed for presentations. The brightness is emphasized in this mode to match PC and notebook coloring.

• Infographic: Is perfect for presentations with the mixture of text and graphics due to its high color brightness and better color gradation to see the details

Picture Mode

clearly.

• Video: Is suitable for playing videos in an environment where there is ambient light. Dynamic color details are preserved by BenQ enhancement technology.

Reference Mode

Brightness

Contrast

Color

• 3D: Is appropriate for playing 3D images and 3D video clips.

• User 1/User 2: Recalls the settings customized based on the current available picture modes. See Reference Mode on page 74.

There are 2 user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/User 2) as a starting point and customize the settings.

1. Go to Picture > Picture Mode.

2. Press / to select User 1 or User 2.

3. Press to highlight Reference Mode, and press / to select a picture

mode that is closest to your need.

4. Press to select a menu item to be changed and adjust the value. The

adjustments define the selected user mode.

The higher the value, the brighter the image. Adjust this control so the black areas of the image appear just as black and that detail in the dark areas is visible.

The higher the value, the greater the contrast. Use this to set the peak white level after you have previously adjusted the Brightness setting to suit your selected input and viewing environment.

Lower setting produces less saturated colors. If the setting is too high, colors on the image will be overpowering, which makes the image unrealistic.

Sharpness The higher the value, the sharper the picture becomes.

74 Operation (under non-Launcher source)

Page 75

Brilliant Color

RED

GREEN

BLUE

Magenta

Cyan

Yellow

This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in picture. It enables a greater than 50% brightness increase in mid-tone images, which are common in video and natural scenes, so the projector reproduces images in realistic and true colors. If you prefer images with that quality, select On. When Off is selected, the Color Temperature function is not available.

Color Temperature

There are several preset color temperature settings available. The available settings may vary according to the signal type selected.

• Normal: Maintains normal colorings for white.

• Cool: Makes images appear bluish white.

• Warm: Makes images appear reddish white.

Color Temperature Tuning

You can also set a preferred color temperature by adjusting the following options.

• R Gain/G Gain/B Gain: Adjusts the contrast levels of Red, Green, and Blue.

• R Offset/G Offset/B Offset: Adjusts the brightness levels of Red, Green, and Blue.

Advanced Color Settings

Color Management

This function provides six sets (RGBCMY) of colors to be adjusted. When you select each color, you can independently adjust its range and saturation according to your preference.

• Primary Color: Selects a color from among R (Red), G (Green), B (Blue), C (Cyan), M (Magenta), or Y (Yellow).

• Hue: Hue is used for adjusting the color balance. Increase in the value will include colors consisted of more proportions of its adjacent colors in counterclockwise order. Decrease in the value will have effect in clockwise order. Please refer to the illustration for how the colors relate to each other For example, if you select Red and set its value at 0, only pure red in the projected picture will be selected. Increasing its value will include red close to yellow while decreasing its value will include red close to magenta.

• Saturation: Adjusts the values to your preference. Every adjustment made will reflect to the image immediately. For example, if you select Red and set its value at 0, only the saturation of pure red will be affected.

Saturation is the amount of that color in a video picture. Lower settings produce less saturated colors; a setting of “0” removes that color from the image entirely. If the saturation is too high, that color will be overpowering and unrealistic.

• Gain: Adjusts the values to your preference. The contrast level of the primary color you select will be affected. Every adjustment made will reflect to the image immediately.

75 Operation (under non-Launcher source)

Page 76

Advanced

15:9 picture

(EX600)

(EW600)

(EH600)

4:3 picture

16:9 picture

4:3 picture 16:9 picture

16:10 picture

Color Settings

Wall Color

Corrects the projected picture’s color when the projection surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s colors to prevent possible color difference between the source and projected pictures. There are several precalibrated colors to choose from:

Light Yellow, Pink, Light Green, Blue, and Blackboard.

Reset Picture

Display

Aspect Ratio

Returns all of the adjustments you’ve made for the Picture menu to the factory preset values.

There are several options to set the image's aspect ratio depending on your input signal source.

• Auto: Scales an image proportionally to fit the projector's native resolution in its horizontal or vertical width.

• 4:3: Scales an image so that it is displayed in the center of the screen with a 4:3 aspect ratio.

• 16:9: Scales an image so that it is displayed in the center of the screen with a 16:9 aspect ratio.

• 16:10: Scales an image so that it is displayed in the center of the screen with a 16:10 aspect ratio.

Keystone Corrects any keystoning of the image. See Correcting keystone on page 19.

Adjusts the image size and focus and check that the projected image is free from distortion.

Test Pattern

• Phase: Adjusts the clock phase to reduce image

PC & Component YPbPr Tuning

distortion. This function is only available when a PC signal (analog RGB) or YPbPr signal is selected.

• H. Size: Adjusts the horizontal width of the image. This function is only available when a PC signal (analog RGB) is selected.

76 Operation (under non-Launcher source)

Page 77

Position

Displays the position adjustment page. To move the projected image, use the directional arrow keys. This function is only available when a PC signal (analog RGB) is selected.

This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.

• 3D Mode: The default setting is Off. If you want the projector to automatically choose an appropriate 3D format when detecting 3D contents, select Auto. If the projector cannot recognize the 3D format, press / to choose a 3D mode from among Top Bottom, Frame Sequential, Frame Packing and Side by Side.

When 3D function is activated:

• The brightness level of the projected image will decrease.

• The following settings cannot be adjusted: Picture Mode, Reference Mode.

• The Keystone can only be adjusted within limited degrees.

• 3D Sync Invert: When you discover the inversion of the image depth, enable this function to correct the problem.

• Apply 3D Settings: After the 3D settings are saved, you can decide if you would like to apply them by choosing a set of 3D settings that you have saved. Once applied, the projector will automatically play the incoming 3D contents if it matches the 3D settings saved.

HDMI Format

Only the set(s) of 3D settings with memorized data is available.

• Save 3D Settings: When you have successfully displayed the 3D contents after making the appropriate adjustments, you can enable this function and choose a set of 3D settings to memorize current 3D settings.

Selects a suitable color format to optimize display quality.

• Auto: Automatically selects a suitable color space and gray level for the incoming HDMI signal.

• RGB Limited: Utilizes the Limited range RGB 16-235.

• RGB Full: Utilizes the Full range RGB 0-255.

• YUV Limited: Utilizes the Limited range YUV 16-235.

• YUV Full: Utilizes the Full range YUV 0-255.

77 Operation (under non-Launcher source)

Page 78

Image Resizing

Digital Zoom

Magnifies or reduces the projected image size.

1. After the adjustment bar displays, press / repeatedly to reduce or magnify the image to a desired size.

2. Press OK to enter panning mode.

3. Press the directional arrows ( , , , ) on the projector or remote control to navigate the picture.

The picture can only be navigated after it is magnified. You can further magnify the picture while searching for details.

Digital Shrink & Shift

Shrinks and/or shifts the projected image.

1. After the adjustment bar displays, press / repeatedly to shrink or magnify the picture to a desired size.

2. Press OK to activate digital shift function.

3. After digital shift function is activated, press the directional arrows ( , , ,

) to shift the image.

Reset Display

Settings

Projector Installation

Remote Receiver

Auto Source Search

Auto Sync

4. Press AUTO to restore the picture to its original size.

The picture can only be shifted after it shrank.

Returns all of the adjustments you’ve made for the Display menu to the factory preset values.

See Choosing a location on page 14.

Allows you to enable all the remote receivers or one specific remote receiver on the projector.

Allows the projector to automatically search for a signal.

• On: Allows the projector to automatically determines the best picture timings for

the displayed image when PC signal (analog RGB) is selected and AUTO is pressed.

• Off: The projector will not respond when AUTO is pressed.

• Light Mode: See Setting the Light Mode on page 84.

Light Settings

• Reset Light Timer: See Resetting the lamp timer on page 87.

• Light Usage Time: Displays the number of hours the lamp has been used.

78 Operation (under non-Launcher source)

Page 79

Quick Cooling

Selecting On enables the function and projector cooling time will be shortened from a normal 90-second duration to approximately 15 seconds.

Blank Timer

Sets the image blank time when there is no action taken on the blank screen, once elapsed the image will return to the screen. If the preset time spans are not suitable for your need, select Disable. No matter Blank Timer is activated or not, you can press most of the keys on the projector or remote control to restore the picture.

Reminder Message

Sets the reminder messages on or off.

High Altitude Mode

We recommend you use the High Altitude Mode when your environment is between 1500 m –3000 m above sea level, and ambient temperature is between 0°C–30°C.

Operation under "High Altitude Mode" may cause a higher decibel operating noise level because of increased fan speed necessary to improve overall system cooling and performance.

Operation Settings

If you use this projector under other extreme conditions excluding the above, it may display auto shut-down symptoms, which is designed to protect your projector from over-heating. In cases like this, you should switch to High Altitude mode to solve these symptoms. However, this is not to state that this projector can operate under any and all harsh or extreme conditions.

Do not use the High Altitude Mode if your altitude is between 0 m and 1500 m and ambient temperature is between 0°C and 35°C. The projector will be over cooled, if you turn the mode on under such a condition.

Power On/Off Settings

• Direct Power On: Allows the projector to turn on automatically once the power is fed through the power cord.

• Signal Power On: Sets whether to turn the projector directly on without

pressing POWER or ON when the projector is in standby mode and detects a VGA signal or a HDMI signal with 5V power.

• Auto Power Off: Allows the projector to turn off automatically if no input signal is detected after a set period of time to prevent unnecessary waste of lamp life.

• Power Off Timer: Sets the auto-shutdown timer.

Security Settings

Instant Restart

Allows you to restart the projector immediately within 90 seconds after turning it off.

See Utilizing the password function on page 64.

79 Operation (under non-Launcher source)

Page 80

Baud Rate

Selects a baud rate that is identical with your computer’s so that you can connect the projector using a suitable RS-232 cable and update or download the projector’s firmware. This function is intended for qualified service personnel.

HDMI Equalizer

Reset Settings

Adjusts the equalizer gain settings for an HDMI signal. The higher the setting, the stronger the gain value. If there are more than one HDMI port on the projector, select the HDMI port first before adjusting the value.

Returns all of the adjustments you’ve made for the Settings menu to the factory preset values.

System

Language Sets the language for the On-Screen Display (OSD) menus.

• Standby Mode

• Eco: The projector maintains at normal standby mode with less than 0.5W power consumption.

Standby Settings

Background Settings

• Normal: Allows the projector to provide audio pass through function in standby mode.

• Audio Pass Through: The projector can play sound when it is in standby mode and the corresponding jacks are correctly connected to devices. Press / to choose the source that you wish to use. See Connection on page 20 for how to make the connection.

• Background: Sets the background color for the projector.

• Splash Screen: Allows you to select which logo screen will be displayed during projector start-up.

Menu Settings

Audio Settings

Factory Default

Reset System

• Menu Type: Switches to the Basic OSD menu.

• Menu Display Time: Sets the length of time the OSD will remain active after your last key press.

• Mute: Temporarily turns off the sound.

• Volume: Adjusts the sound level.

• Power On/Off Ring Tone: Turns on or off the ring tone when the projector is in startup and shutdown process.

The only way to change Power On/Off Ring Tone is setting On or Off here. Setting the sound mute or changing the sound level will not affect the Power On/Off Ring Tone.

Returns all settings to the factory preset values.

The following settings will still remain: Keystone, Projector Installation, Light Usage Time, High Altitude Mode, Security Settings, Baud Rate, HDMI Equalizer.

Returns all of the adjustments you’ve made for the System menu to the factory preset values.

80 Operation (under non-Launcher source)

Page 81

Information

• Native Resolution: Shows the native resolution of the projector.

• Detected Resolution: Shows the native resolution of the input signal.

• Source: Shows the current signal source.

• Picture Mode: Shows the selected mode in the Picture menu.

Information

• Light Mode: Shows the selected mode in the Light Settings menu.

• 3D Format: Shows the current 3D mode.

• Color System: Shows input system format.

• Light Usage Time: Shows the number of hours the lamp has been used.

• Firmware Version: Shows the firmware version of your projector.

• Service Code: Shows the projector serial number.

81 Operation (under non-Launcher source)

Page 82

Shutting down the projector

1. Press on the projector or on the remote control and a confirmation message will appear prompting you. If you don't respond in a few seconds, the message will

disappear.

2. Press or a second time. The power indicator flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to

cool down the projector.

3. Once the cooling process finishes, the power indicator becomes a steady orange and fans stop. Disconnect the power cord from the power outlet.

• To protect the lamp, the projector will not respond to any commands during the cooling process.

• To shorten the cooling time, you can also activate the Quick cooling function. See Quick Cooling on page 79.

• Avoid turning on the projector immediately after turning it off as excessive heat may shorten lamp life.

• Lamp life results will vary depending on environmental conditions and usage.

Direct power off

The AC power cord can be pulled out right after the projector is turned off. To protect the lamp, wait about 10 minutes before re-starting the projector. If you attempt to re-start the projector, the fans may

run for a few minutes to cool down. In such cases, press or again to start the projector after the fans stop and the power indicator turns orange.

82 Shutting down the projector

Page 83

Maintenance

Care of the projector

Cleaning the lens

Clean the lens whenever you notice dirt or dust on the surface. Please be sure to turn off the projector and let it cool down completely before cleaning the lens.

• Use a canister of compressed air to remove dust.

• If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens cleaner and gently wipe the lens surface.

• Never use any type of abrasive pad, alkaline/acid cleaner, scouring powder, or volatile solvent, such as alcohol, benzene, thinner or insecticide. Using such materials or maintaining prolonged contact with rubber or vinyl materials may result in damage to the projector surface and cabinet material.

Cleaning the projector case

Before you clean the case, turn the projector off using the proper shutdown procedure as described in

Menu operation on page 67 and unplug the power cord.

• To remove dirt or dust, wipe the case with a soft, lint-free cloth.

• To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral pH detergent. Then wipe the case.

Never use wax, alcohol, benzene, thinner or other chemical detergents. These can damage the case.

Storing the projector

If you need to store the projector for an extended time, please follow the instructions below:

• Make sure the temperature and humidity of the storage area are within the recommended range for the projector. Please refer to Specifications on page 90 or consult your dealer about the range.

• Retract the adjuster feet.

• Remove the battery from the remote control.

• Pack the projector in its original packing or equivalent.

Transporting the projector

It is recommended that you ship the projector with its original packing or equivalent.

Light information

Getting to know the light hour

When the projector is in operation, the duration (in hours) of light usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows:

1. Light Usage Time = (x+y+z+a) hours, if:

Time used in Normal mode = x hours

Time used in Economic mode = y hours

Time used in SmartEco mode = z hours

83 Maintenance

Page 84

Time used in LampSave mode = a hours

2. Equivalent light source hour = α hours

α = x(A’ / X) + y(A’/Y) + z(A’/Z) + a(A’/A), if

X= lamp life spec of Normal mode

Y= lamp life spec of Economic mode

Z= lamp life spec of SmartEco mode

A= lamp life spec of LampSave mode

A’ is the longest lamp life spec among X, Y, Z, A

When you calculate Equivalent Lamp hour manually, it will probably have deviation from the value shown in OSD menu since projector system calculates time used for each lamp mode in “Minutes” then rounds down to an integer in hours shown in OSD.

For time used in each lamp mode shown in OSD menu:

• Time used is accumulated and rounded down to an integer in hours.

• When time used is less than 1 hour, it shows 0 hours.

To obtain the lamp hour information:

1. Go to Advanced Menu - Settings > Light Settings and press OK. The Light Settings page appears.

2. Press to select Light Usage Time and press OK. The Light Usage Time information is displayed.

You can also get the lamp hour information on the Information menu.

Extending lamp life

• Setting the Light Mode

Go to Advanced Menu - Settings > Light Settings > Light Mode and select a suitable lamp power from among the provided modes.

Setting the projector in Economic, SmartEco or LampSave mode extends lamp life.

Lamp mode Description

Normal Provides full lamp brightness Economic Lowers brightness to extend the lamp life and decreases the fan noise

SmartEco

LampSave

• Setting Auto Power Off

This function allows the projector to turn off automatically if no input signal is detected after a set period of time to prevent unnecessary waste of lamp life.

Adjusts the lamp power automatically depending on the content brightness level while optimizing display quality

Adjusts the lamp power automatically depending on the content brightness level while offering a longer lamp life

To s e t Auto Power Off, go to Advanced Menu - Settings > Operation Settings > Power On/Off Settings > Auto Power Off and press / .

84 Maintenance

Page 85

Timing of replacing the lamp

Order a replace ment lamp

Equivalent lamp hour >XXXX hours

Order a new lamp at www.BenQ.com

Notice

Replace lamp soon

Equivalent lamp hour >XXXX hours

Order a new lamp at www.BenQ.com

Notice

Out of lamp usage time

Replace lamp (refer to user manual) then reset the lamp timer

Order a new lamp at www.BenQ.com

Notice

Replace lamp now

Equivalent lamp hour > XXXX Hours

Order a new lamp at www.BenQ.com

Notice

When the Lamp indicator lights up or a message appears suggesting it is time to replace the lamp, please consult your dealer or go to http://www.BenQ.com before installing a new lamp. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode.

• The apparent brightness of the projected image will vary depending on the ambient lighting conditions, selected input signal contrast/brightness settings, and is directly proportional to projection distance.

• The lamp brightness will decline over time and may vary within the lamp manufacturers specifications. This is normal and expected behavior.

• The LAMP indicator light and TEMPerature warning light will light up if the lamp becomes too hot. Turn the power off and let the projector cool for 45 minutes. If the Lamp or Temp indicator still lights up after turning the power back on, please contact your dealer. See Indicators on page 88.

The following Lamp warning displays will remind you to change the lamp.

Install a new lamp for optimal performance. Press OK to dismiss the message.

It is strongly recommended that you replace the lamp at this age. The lamp is a consumable item. The lamp brightness diminishes with use. This is normal lamp behavior. You can replace the lamp whenever you notice that the brightness level has significantly diminished. Press

OK to dismiss the message.

The lamp MUST be replaced before the projector will operate normally.

OK to dismiss the message.

Press

"XXXX" shown in the above messages are numbers that vary depending on different models.

85 Maintenance

Page 86

Replacing the lamp (FOR SERVICE PERSONNEL ONLY)

• To reduce the risk of electrical shock, always turn the projector off and disconnect the power cord before changing the lamp.

• To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp.

• To reduce the risk of injuries to fingers and damage to internal components, use caution when removing lamp glass that has shattered into sharp pieces.

• To reduce the risk of injuries to fingers and/or compromising image quality by touching the lens, do not touch the empty lamp compartment when the lamp is removed.

• This lamp contains mercury. Consult your local hazardous waste regulations to dispose of this lamp in a proper manner.

• To assure optimal performance from the projector, it is recommended that you purchase a qualified projector lamp for lamp replacement.

• If lamp replacement is performed while the projector is suspended upside-down, make sure that no one is underneath the lamp socket to avoid any possible injury or damage to the human eyes caused by fractured lamp.

• Ensure good ventilation when handling broken lamps. We recommend that you use respirators, safety glasses, goggles or face shield and wear protective clothing such as gloves.

1. Turn the power off and disconnect the projector from the power outlet. If the lamp is hot, avoid burns by waiting for approximately 45 minutes until the lamp has cooled.

2. Loosen the screw(s) that secure the lamp cover on the side of the projector until the lamp cover loosens.

3. Remove the lamp cover from the projector.

• Do not turn the power on with the lamp cover open.

• Do not insert your fingers between the lamp and the projector. The sharp edges inside the projector may cause injuries

4. Disconnect the lamp connector.

5. Loosen the screw(s) that secure the inner lamp.

6. Lift the handle so that it stands up.

7. Use the handle to slowly pull the lamp out of the projector.

86 Maintenance

Page 87

• Pulling it too quickly may cause the lamp to break and scatter

broken glass in the projector.

• Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.

• Do not insert your hands into the projector after the lamp is removed. The sharp edges inside the projector may cause injuries. If you touch the optical components inside, it could cause color unevenness and distortion of the projected images.

8. As shown in the figure, insert the new lamp. Align the lamp connector and 2 sharp points with the projector and push the lamp a bit into the locked position.

9. Insert the lamp connector.

10. Tighten the screw(s) that secures the lamp.

11. Ensure the handle is fully laid flat and locked in place.

• Loose screw may cause a bad connection, which could result in malfunction.

• Do not over tighten the screw.

12. Replace the lamp cover on the projector.

13. Tighten the screw that secures the lamp cover.

• Loose screw may cause a bad connection, which could result in malfunction.

• Do not over tighten the screw.

14. .Connect the power and restart the projector.

Resetting the lamp timer

15. After the startup logo, open the On-Screen Display (OSD) menu. Go to Advanced Menu - Settings > Lamp Settings and press OK. The Lamp Settings page appears. Highlight Reset Lamp Timer and press OK. A warning message is displayed asking if you want to reset the lamp timer. Highlight Reset and press OK. The lamp time will be reset to “0”.

Do not reset if the lamp is not new or replaced as this could cause damage.

87 Maintenance

Page 88

Indicators

Light

Status & Description

Power events

Stand-by mode

Powering up

Normal operation

Normal power-down cooling

Download

CW start fail

Lamp events

Lamp error in normal operation

Lamp is not lit up

Lamp life exhausted

Lamp door is not closed

: Off

Thermal events

Fan 1 error (the actual fan speed is outside the desired speed)

Fan 2 error (the actual fan speed is outside the desired speed)

Temperature 1 error (over limited temperature)

: Orange On : Green On : Red On

: Orange Flashing : Green Flashing : Red Flashing

88 Maintenance

Page 89

Troubleshooting

The projector does not turn on.

Cause Remedy

There is no power from the power cord.

Attempting to turn the projector on again during the cooling process.

No picture

Cause Remedy

Plug the power cord into the AC power jack on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on.

Wait until the cooling down process has completed.

The video source is not turned on or connected correctly.

The projector is not correctly connected to the input signal device.

The input signal has not been correctly selected. Select the correct input signal with the SOURCE key. The lens cover is still closed. Open the lens cover.

Blurred image

Cause Remedy

The projection lens is not correctly focused. Adjust the focus of the lens using the focus ring. The projector and the screen are not aligned

properly. The lens cover is still closed. Open the lens cover.

Remote control does not work.

Cause Remedy

The batteries are out of power. Replace both of the batteries with new ones. There is an obstacle between the remote control

and the projector. You are too far away from the projector. Stand within 8 meters (26 feet) of the projector.

Turn the video source on and check that the signal cable is connected correctly.

Check the connection.

Adjust the projection angle and direction as well as the height of the projector if necessary.

Remove the obstacle.

The password is incorrect.

Cause Remedy

You do not remember the password. See Entering the password recall procedure on page 65.

89 Troubleshooting

Page 90

Specifications

Projector specifications

All specifications are subject to change without notice.

Optical

Resolution

EX600: 1024 x 768 XGA EW600: 1280 x 800 WXGA EH600: 1920 x 1080 1080p

Display system

1-CHIP DMD

Lens

F = 2.56 ~ 2.68, f = 22 ~ 24.1 mm

Clear focus range

EX600:

2.38–7.15 m @ Wide,

2.62–7.87 m @ Tele EW600: 2–6 m @ Wide, 2.2–6.6 m @ Tele

EH600:

1.98–5.94 m @ Wide,

2.18–6.53 m @ Tele

Lamp

200 W lamp

Electrical

Power supply

AC100–240V, 50–60 Hz (Automatic)

Power consumption

320 W (Max); < 0.5 W (Standby)

Mechanical

Weight

2.5 Kg (5.5 lbs)

Output terminals

RGB output

D-Sub 15-pin (female) x 1

Speaker

2 watt x 1

Audio signal output

PC audio jack x 1

Control

USB

Type-A: 1A Type-A: 1.5A Type-A for wireless dongle: 1.5A Mini-B x 1

RS-232 serial control

9 pin x 1

IR receiver x 2

Input terminals

Computer input

RGB input

D-Sub 15-pin (female) x 1

Video signal input

SD/HDTV signal input

Analog - Component

(through RGB input)

Digital - HDMI x 1

Audio signal input

Audio in

PC audio jack x 1

Environmental Requirements

Operating temperature

0°C–40°C at sea level

Operating relative humidity

10%–90% (without condensation)

Operating altitude

0–1499 m at 0°C–35°C 1500–3000 m at 0°C–30°C (with High Altitude Mode on)

Storage temperature

-20°C–60°C at sea level

Storage humidity

10%–90% RH (without condensation)

Storage altitude

30°C@ 0~12,200m above sea level

Transporting

Original packing or equivalent is recommended

Repairing

Please visit below website and choose your country to find your service contact window. http://www.benq.com/welcome

90 Specifications

Page 91

Dimensions

296

232

120

Unit: mm

296 mm (W) x 120 mm (H) x 232 mm (D)

91 Specifications

Page 92

Timing chart

Supported timing for PC input

Ver ti cal

Resolution Mode

Frequency

(Hz)

VGA_60 59.940 31.469 25.175 Supported Supported Supported

640 x 480

720 x 400 720 x 400_70 70.087 31.469 28.3221

800 x 600

1024 x 768

1152 x 864 1152 x 864_75 75 67.5 108

1024 x 576

1024 x 600

1280 x 720 1280 x 720_60 60 45.000 74.250 Supported Supported Supported 1280 x 768 1280 x 768_60 59.87 47.776 79.5 Supported Supported Supported

1280 x 800

1280 x 1024

1280 x 960

1360 x 768 1360 x 768_60 60.015 47.712 85.5 Supported Supported

1440 x 900 WXGA+_60 59.887 55.935 106.500 Supported Supported 1400 x 1050 SXGA+_60 59.978 65.317 121.750 Supported Supported 1600 x 1200 UXGA 60.000 75.000 162.000 Supported Supported 1680 x 1050 1680 x 1050_60 59.954 65.290 146.250 Supported Supported

640 x 480@67Hz MAC13 66.667 35.000 30.240

832 x 624@75Hz MAC16 74.546 49.722 57.280 1024 x 768@75Hz MAC19 74.93 60.241 80.000 1152 x 870@75Hz MAC21 75.060 68.680 100.000

VGA_72 72.809 37.861 31.500 VGA_75 75.000 37.500 31.500 VGA_85 85.008 43.269 36.000

SVGA_60 60.317 37.879 40.000 Supported Supported Supported SVGA_72 72.188 48.077 50.000 SVGA_75 75.000 46.875 49.500 SVGA_85 85.061 53.674 56.250

SVGA_120

(Reduce Blanking)

XGA_60 60.004 48.363 65.000 Supported Supported Supported XGA_70 70.069 56.476 75.000 XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500

XGA_120 (Reduce

Blanking)

BenQ

Notebook_timing

BenQ

Notebook_timing

WXGA_60 59.810 49.702 83.500 Supported Supported Supported WXGA_75 74.934 62.795 106.500 WXGA_85 84.880 71.554 122.500

WXGA_120

(Reduce Blanking)

SXGA_60 60.020 63.981 108.000 Supported Supported SXGA_75 75.025 79.976 135.000

SXGA_85 85.024 91.146 157.500 1280 x 960_60 60.000 60.000 108.000 Supported Supported 1280 x 960_85 85.002 85.938 148.500

119.854 77.425 83.000 Supported

119.989 97.551 115.5 Supported

60.0 35.820 46.966

64.995 41.467 51.419

119.909 101.563 146.25 Supported

Horizontal

Frequency

(kHz)

Pixel

Frequency

(MHz)

Frame

Sequential

3D format

Top

Bottom

Side by

Side

The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen.

92 Specifications

Page 93

Supported timing for HDMI (HDCP) input

• PC timings

Ver ti cal

Resolution Mode

Frequency

(Hz)

VGA_60 59.940 31.469 25.175 Supported Supported Supported

640 x 480

720 x 400 720 x 400_70 70.087 31.469 28.3221

800 x 600

1024 x 768

1152 x 864 1152 x 864_75 75 67.5 108

1024 x 576@60Hz

1024 x 600@65Hz

1280 x 720 1280 x 720_60 60 45.000 74.250 Supported Supported Supported 1280 x 768 1280 x 768_60 59.870 47.776 79.5 Supported Supported Supported

1280 x 800

1280 x 1024

1280 x 960

1360 x 768 1360 x 768_60 60.015 47.712 85.500 Supported Supported

640 x 480@67Hz MAC13 66.667 35.000 30.240 832 x 624@75Hz MAC16 74.546 49.722 57.280

1024 x 768@75Hz MAC19 75.020 60.241 80.000

1152 x 870@75Hz MAC21 75.06 68.68 100.00

1920 x 1080@60Hz 1920 x 1080_60 60 67.5 148.5 Supported Supported

1920 x 1200

VGA_72 72.809 37.861 31.500 VGA_75 75.000 37.500 31.500 VGA_85 85.008 43.269 36.000

SVGA_60 60.317 37.879 40.000 Supported Supported Supported SVGA_72 72.188 48.077 50.000 SVGA_75 75.000 46.875 49.500 SVGA_85 85.061 53.674 56.250

SVGA_120 (Reduce

Blanking)

XGA_60 60.004 48.363 65.000 Supported Supported Supported XGA_70 70.069 56.476 75.000 XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500

XGA_120 (Reduce

Blanking)

BenQ Notebook

Timing

BenQ Notebook

Timing

WXGA_60 59.810 49.702 83.500 Supported Supported Supported WXGA_75 74.934 62.795 106.500 WXGA_85 84.880 71.554 122.500

WXGA_120

(Reduce Blanking)

SXGA_60 60.020 63.981 108.000 Supported Supported SXGA_75 75.025 79.976 135.000

SXGA_85 85.024 91.146 157.500 1280 x 960_60 60.000 60.000 108 Supported Supported 1280 x 960_85 85.002 85.938 148.500

1920 x 1200_60

(Reduce Blanking)

119.854 77.425 83.000 Supported

119.989 97.551 115.5 Supported

60.00 35.820 46.996

64.995 41.467 51.419

119.909 101.563 146.25 Supported

59.950 74.038 154.0000 Supported Supported

Horizontal

Frequency

(kHz)

Pixel

Frequency

(MHz)

Frame

Sequential

3D format

Top

Bottom

Side by

Side

The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen.

93 Specifications

Page 94

• Video timings

Ver ti cal

Timing Resolution

Frequency

(Hz)

480i 720 x 480 59.94 15.73 27 Supported

480p 720 x 480 59.94 31.47 27 Supported

576i 720 x 576 50 15.63 27

576p 720 x 576 50 31.25 27 720/50p 1280 x 720 50 37.5 74.25 Supported Supported Supported 720/60p 1280 x 720 60 45.00 74.25 Supported Supported Supported Supported

1080/50i 1920 x 1080 50 28.13 74.25 Supported

1080/60i 1920 x 1080 60 33.75 74.25 Supported 1080/24P 1920 x 1080 24 27 74.25 Supported Supported Supported 1080/25P 1920 x 1080 25 28.13 74.25 1080/30P 1920 x 1080 30 33.75 74.25 1080/50P 1920 x 1080 50 56.25 148.5 Supported Supported 1080/60P 1920 x 1080 60 67.5 148.5 Supported Supported

Horizontal Frequency

(kHz)

Pixel

Frequency

(MHz)

Frame

Sequential

3D format

Frame

Packing

Top

Bottom

Side by

Side

Supported timing for Component-YPbPr input

Timing Resolution

480i 720 x 480 59.94 15.73 13.5 Supported

480p 720 x 480 59.94 31.47 27 Supported

576i 720 x 576 50 15.63 13.5

576p 720 x 576 50 31.25 27 720/50p 1280 x 720 50 37.5 74.25 720/60p 1280 x 720 60 45.00 74.25 Supported

1080/50i 1920 x 1080 50 28.13 74.25

1080/60i 1920 x 1080 60 33.75 74.25 1080/24P 1920 x 1080 24 27 74.25 1080/25P 1920 x 1080 25 28.13 74.25 1080/30P 1920 x 1080 30 33.75 74.25 1080/50P 1920 x 1080 50 56.25 148.5 1080/60P 1920 x 1080 60 67.5 148.5

Vertical Frequency

(Hz)

Horizontal Frequency

(kHz)

Pixel Frequency

(MHz)

3D format

Frame

Sequential

Displaying a 1080i(1125i)@60Hz or 1080i(1125i)@50Hz signal may result in slight image vibration.

94 Specifications

Benq 9H.JLV77.13E User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Warranty and Copyright information

Important safety instructions

Introduction

Shipping contents

Projector exterior view

Controls and functions

Positioning your projector

Choosing a location

Obtaining a preferred projected image size

Mounting the projector

Adjusting the projected image

Connection

Starting up the projector

Operation (under Launcher source)

BenQ Launcher

Operation (under non-Launcher source)

Using the projector menus under non-Launcher source

Securing the projector

Switching input signal

Menu operation

Shutting down the projector

Direct power off

Maintenance

Care of the projector

Light information

Troubleshooting

Specifications

Projector specifications

Dimensions

Timing chart
