ONE
COMPLETE HOME CLEANING SYSTEM
USER GUIDE
MODEL 114 R
CONGRATULATIONS ON YOUR PURCHASE
Thank you for purchasing a BENNETT READ ONE complete home cleaning system.
Your BENNETTT READ ONE incorporates the latest technological
advances in home cleaning systems. It imitates the most powerful forces of nature in a sleek, elegant machine to ensure that your home is easily and properly cleaned.
Your new BENNETTT READ ONE is manufactured to a high standard of quality and is backed up by a 24 month guarantee by Tevo.
Should you need any support from us, please visit www.tevo.co.za or call 0861 77 88 88.
PLEASE KEEP THIS USER GUIDE IN A SAFE PLACE
AND READ IT CAREFULLY BEFORE USING YOUR
BENNETTT READ ONE FOR THE FIRST TIME.
1
IMPORTANT SAFETY INSTRUCTIONS
!
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
BASIC SAFETY PRECAUTIONS SHOULD BE OBSERVED WHEN USING YOUR BENNETT READ ONE, INCLUDING THE FOLLOWING:
•Your BENNETT READ ONE is for household use only
•Do not immerse any part of the system in water or any other liquids
•Do not operate the system if the appliance or any other part of the system has been dropped or damaged
•Do not disassemble or attempt to repair your BENNETT READ ONE. Return the unit for examination and repair
•Do not use the vacuum to pick up flammable or combustible liquids such as gasoline and do not use it in areas where they may be present
•Do not use the vacuum to pick up anything that is burning or smoking such as cigarettes, matches or hot ashes
•Use extra care when cleaning on stairs
•Do not use your BENNETT READ ONE without the filters in place
•Do not leave your BENNETT READ ONE plugged in when unattended
•Unplug the electrical cord when not in use and before cleaning or servicing
•Keep loose clothing, hair and all parts of body away from openings and moving parts
•Not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge
•Keep out of reach of children
•Do not allow your BENNETT READ ONE to be used as a toy
•Extra care is necessary when using your BENNETT READ ONE near children, animals or plants
2
•Do not pull the electrical cord or use the cord as a handle
•Take care to not close doors on the electrical cord and do not pull the cord around sharp edges or corners
•Do not run the machine over it’s own electrical cord
•Do not allow the cord to touch hot surfaces
•Turn off all controls before unplugging from the electrical outlet
•To unplug your BENNETT READ ONE, grasp the plug. Do not unplug by pulling on the electrical cord
•Do not handle the plug or vacuum with wet hands
•Do not operate your BENNETT READ ONE while barefoot
•Do not put any objects into the machine openings
•Do not use your BENNETT READ ONE while any opening is blocked
•Keep your BENNETT READ ONE free of dust, lint, hair or anything else which may reduce airflow
•Keep your work area well lit
•Using improper voltage may result in damage to the motor and possible injury to the user
The correct voltage is listed on the rating label. For operation on 220-240V, 50/60Hz power supply only
•Only use the accessories supplied with your BENNETT READ ONE vacuum
•Only use spare parts recommended by Tevo
•Store your BENNETT READ ONE indoors in a cool, dry area
SAVE THESE INSTRUCTIONS FOR FUTURE USE | FOR HOUSEHOLD USE ONLY
3
25
10
24
12
11
33
23
9
7
1
8
2
30
3
5
29
4
6
4
PRODUCT VIEW
10 |
13 |
14 |
15 |
16 |
17 |
18 |
19 |
20 |
21 |
22 |
23 |
26 |
27 |
28 |
31 |
32 |
33 |
34 |
1.Power Switch
2.Pump Switch
3.Spray Hose Connection
4.Flexi Hose Suction Inlet
5.Securing Clips
6.Dirt Collection Tank
7.Motor Unit
8.Detachable Cleaning Solution Tank
9.Carry Handle
10.Post-motor Filter
11.Retractable Power Cable
12.Cleaning Solution Inlet Port
13.Dust Filter Bag (Dry Vacuuming Only)
14.Pre-motor Microparticle Filter (Dry Vacuuming Only)
15.Filter Securing Lock
16.Air flow cut-off float valve
(Wet Vacuuming / Deep Cleaning)
17.Foam Filter (Wet Vacuuming/Deep Cleaning)
18.High-efficiency Multi-floor Surface Vacuum Nozzle
19.Crevice Tool
20.Dusting Brush
21.Hard Floor Wet Spill Tool
22.Adjustable Stainless Steel Extension Wand
23.Spray Hose Securing Clips X 5
24.Variable Suction Control Valve
25.Multi Directional Swivel Handle
26.Cleaning Solution Spray Pipe
27.Detachable Spray Trigger
28.Wire Reinforced Flexi Hose
29.Flexi Hose Inlet Connector
30.Dual Flexi Hose Securing Clips
31.Carpet Deep Cleaning Attachment
32.Upholstery Deep Cleaning Attachment
33.Cleaning Solution Suction Pipe Assembly
34.Cleaning Solution Spray Pipe Extension
5
OPERATING INSTRUCTIONS
INSTALLING THE FILTERS
1 |
|
2 |
|
3 |
|
|
|
|
|
Open motor unit by releasing both securing clips (5)
4
Lift motor unit from dirt collection tank (6) |
Attach dust filter bag (13): |
||
|
|
Line up filter bag connector with housing on inside of dirt tank |
|
|
|
Twist clockwise to lock bag in place |
|
|
|
|
|
5 |
|
6 |
|
|
|
|
|
Insert microparticle filter (14) as shown |
Replace motor unit on dirt collection tank |
Secure motor using the securing clips (5) |
Secure microparticle filter by inserting and |
|
|
turning securing lock clockwise (15) |
|
|
6
IMPORTANT: |
Please read these instructions carefully, failure to operate your BENNETT READ ONE according to |
|
these instructions may cause serious damage to your machine and result in the warranty being void. |
||
|
||
|
|
7 |
|
8 |
|
|
|
Attach flexi hose inlet connector (29) by inserting into flexi hose inlet (4) Push until you hear both flexi hose securing clips click (30)
9
Insert swivel handle (25) into end of stainless steel extension wand (22)
10
Extend wand to desired length by pressing extension catch and pulling free end of wand
Attach multi floor surface cleaning head (18) to free end of extension wand until it locks in place. To remove cleaning head, press securing button and pull attachment away from wand in a simultaneous pulling/twisting motion
7
