BELLA 13575 User Manual [en, es]
TABLE OF CONTENTS
Important Safeguards ...................................................................................................... 2 - 3
Additional Important Safeguards............................................................................................3
Notes on the Plug .................................................................................................................3
Notes on the Cord.................................................................................................................3
Getting to Know Your Waffle Stick Maker ..............................................................................4
Before Using for the First Time ..............................................................................................5
Introduction to Waffle Sticks ..................................................................................................5
To Bake Waffle Sticks ...........................................................................................................6
Waffle Sticks Baking Tips ......................................................................................................6
User Maintenance Instructions ..............................................................................................7
Care & Cleaning Instructions .................................................................................................7
Storing Instructions................................................................................................................7
Recipes ........................................................................................................................... 8-11
Warranty ..............................................................................................................................12
ÍNDICE
Medidas de seguridad importantes .....................................................................................13
Medidas de seguridad importantes adicionales ...................................................................14
Notas sobre el cable ...........................................................................................................14
Notas sobre el enchufe .......................................................................................................14
Datos sobre la máquina para hacer gofres bastón ..............................................................15
Antes de usar el producto por primera vez ..........................................................................16
Presentación de los gofres bastón ......................................................................................16
Para hornear gofres bastón .................................................................................................17
Sugerencias para hornear gofres bastón .............................................................................17
Instrucciones de mantenimiento para el usuario ..................................................................18
Instrucciones de cuidado y limpieza ....................................................................................18
Instrucciones de almacenamiento .......................................................................................18
Fórmulas ....................................................................................................................... 19-23
Garantía ..............................................................................................................................24
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 1 12-07-16 9:38 AM
IMPORTANT SAFEGUARDS
WARNING: When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions before using appliance.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of electric shock, do not immerse or partially immerse the
cord,plugs, or the entire unit in water or any other liquid.
4. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
5. Close supervision is necessary when any appliance is used by or near children.
6. Unplug from wall outlet when not in use and before cleaning. Allow to cool before
cleaning or storing this appliance.
7. Never yank the cord to disconnect the appliance from the outlet. Instead, grasp the
plug and pull to disconnect.
8. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or adjustment.
9. The use of accessories attachments not recommended by the appliance
manufacturer may cause fire, electrical shock or injuries.
10. Do not use outdoors. This is for household only.
11. Do not use for commercial purposes.
12. Do not let the electrical cord hang over the edge of the table or counter,
or touch hot surfaces.
13. Do not place on or near a hot gas or electric burner or in a heated oven.
14. Use on a heat-resistant, flat level surface only.
15. Extreme caution must be used when moving an appliance containing hot food, hot
water, hot oil or other hot liquids.
16. This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to fit into a polarized outlet only one
way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
17. The cord to this appliance should be plugged into a 120V AC electrical outlet only.
18. A short power-supply cord is to be provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord.
19. Longer extension cords are available and may be used if care is exercised in
their use.
20. If an extension cord is used:
a. The marked electrical rating of the detachable power-supply cord or extension
b. If the appliance is of the grounded type, the extension cord should be a
c. The longer cord should be arranged so that it will not drape over the
21. To disconnect, remove plug from outlet.
22. Always unplug after use. The appliance will remain ON unless unplugged.
23. CAUTION HOT SURFACES: This appliance generates heat during use.
24. When using this appliance, provide adequate ventilation above and on all sides
cord should be at least as great as the electrical rating of the appliance.
grounding type 3-wire cord.
counter top or table top where it can be pulled on by children or tripped
over unintentionally.
Proper precautions must be taken to prevent the risk of burns, fire or other damage
to persons or property.
for air circulation. Do not allow this appliance to touch curtains, wall coverings,
clothing, dish towels or other flammable materials during use.
2
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 2 12-07-16 9:38 AM
25. Use with wall receptacle only.
26. Do not use appliance for other than intended use.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
ADDITIONAL
IMPORTANT SAFEGUARDS
CAUTION: This appliance is hot during operation and retains heat for some time
after turning OFF. Always use oven mitts when handling hot materials and allow
metal parts to cool before cleaning. Do not place anything on top of the appliance
while it is operating or while it is hot.
1. All users of this appliance must read and understand this Instruction Manual
before operating or cleaning this appliance.
2. Do not leave this appliance unattended during use.
NOTES ON ThE PLug
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk
of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit
fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
Do not modify the plug in any way.
NOTES ON ThE COrD
The provided short power-supply cord (or detachable power-supply cord) should be used
to reduce the risk resulting from becoming entangled in or tripping over a longer cord.
PLASTICIzEr WArNINg
CAUTION: To prevent Plasticizers from migrating to the finish of the counter top or table top
or other furniture, place NON-PLASTIC coasters or place mats between the appliance
and the finish of the counter top or table top. Failure to do so may cause the finish to darken;
permanent blemishes may occur or stains can appear.
ELECTrIC POWEr
If the electrical circuit is overloaded with other appliances, your appliance may not operate
properly. It should be operated on a separate electrical circuit from other appliances.
3
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 3 12-07-16 9:38 AM
gETTINg TO KNOW YOur WAFFLE STICK MAKEr
Product may vary slightly from illustrations.
Figure 1
Lid
Non-Stick Upper and
Lower Cooking Plates
with 6 Waffle Stick Molds
Lid Handle with Locking Latch
Polarized Plug
Non-skid Feet (Not Shown)
Figure 1A
Orange POWER ON Light
Green READY Light
4
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 4 12-07-16 9:38 AM
BEFOrE uSINg FOr ThE FIrST TIME
1. Carefully unpack the waffle maker and remove all packaging and materials.
2. Before using your Waffle Stick Maker for the first time, wipe the cooking plates with a
damp cloth to remove all dust, and then dry. Wipe outer surfaces with a slightly damp,
soft cloth or sponge.
CAUTION: Take care to prevent water from running into the appliance. NEVER
IMMERSE WAFFLE STICK MAKER BODY IN WATER OR ANY OTHER LIQUIDS!
3. Set the appliance on a dry, clean and flat surface. Keep the Waffle Stick Maker closed
until use.
TO BAKE WAFFLE STICKS
1. Lift the top lid to the open position.
2. Before baking the first waffle sticks of the day, brush the upper and lower cooking plates
with vegetable oil, spread with an absorbent kitchen towel and wipe the excess oil.
Close the lid.
3. Plug unit into a 120V AC electrical outlet. The orange POWER ON light will illuminate as
the Waffle Stick Maker preheats.
NOTE: When your Waffle Stick Maker is heated for the first time, it may emit slight
smoke or odor. This is normal and should disappear after 1 or 2 uses. This does not
affect the safety of the appliance. However, as it may affect the flavor of the first waffle
sticks prepared in the Waffle Stick Maker, it is recommended that these be discarded.
4. While preheating, prepare waffle batter.
5. After approximately 3 to 4 minutes, the green READY light will illuminate, indicating the
unit is preheated and is ready for use.
6. IMPORTANT: Never use non-stick cooking spray on the non-stick plates as this will
cause residue buildup on your plates.
7. Recipes will vary in cook time and brownness; batters with more sugar will brown
quicker. Note the perfect bake times for each batter recipe for future use.
8. Depending on the batter, pour 1/2 to 3/4 cup waffle batter onto the center of the lower
cooking plate. If necessary, spread slightly to fill the entire area. Try not to overfill, batter
will expand when cooked.
9. Using the handle, close the lid. The handle latch will lock the lid into place.
10. Allow the Waffle Stick Maker to bake for 3 to 4 minutes, according to recipe directions.
NOTE: The green READY light will cycle on and off as the unit maintains baking
temperatures.
11. Wipe the outside with a clean paper towel or cleaning cloth as necessary.
12. At the end of the cook time, lift the top lid gently; if it pulls, continue cooking for 30
seconds and test again. If the waffle sticks need to bake to a darker finish, close the lid
and continue baking until the desired color is achieved.
13. Remove waffle sticks from the cooking plates using a wooden or plastic spatula.
CAUTION: To avoid damage to the non-stick surface, never use any sharp,
pointed or metal objects.
WARNING: Cooking sur faces are hot, do not touch; use caution until cooking
plates are cool.
NOTE: If additional waffle sticks are to be baked, keep the Waffle Stick Maker closed
to retain heat. Always wait until the green READY light illuminates before baking more
waffle sticks.
NOTE: Waffle sticks made later will bake faster because extra heat has been retained.
It may be necessary to adjust to a shorter cooking time to accommodate.
14. When baking is complete, after waffle sticks have been removed, unplug the power cord
from electric outlet. Lift the top lid to expose the cooking plates and allow unit to cool.
15. Do not clean until unit has been fully cooled.
5
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 5 12-07-16 9:38 AM
WAFFLE STICKS BAKINg TIPS
• Do not open the Waffle Stick Maker during the first minute of baking or the waffle will
separate. Completely bake the waffle before removing.
• When waffle sticks are done, the top lid should lift easily. Lift gently; if it pulls,
continue cooking for 1 minute and test again.
• When preparing waffle batter, do not over-mix or waffle sticks will be tough. Stir batter
only until large lumps of dry ingredients disappear.
• The optimal amount of batter to produce a full-shaped waffle, without overflowing,
will vary with different waffle batters.
• For more evenly shaped waffle sticks, spread thick batters to the outer edge of the lower
cooking plate using a heat-proof rubber spatula or other non-metallic utensil before
closing the lid.
• To retain crispness, move baked waffle sticks to a paper napkin or a wire cooling rack
to absorb any condensation. To keep waffle sticks hot, place in an ovenproof dish on
an oven rack and warm at about 200-250°F (90-120°C). Waffles sticks will keep for about
15 minutes before they begin to dry out.
• Cooled waffle sticks can be re-warmed and re-crisped individually by returning to hot
Waffle Stick Maker. Place waffle sticks on lower cooking plate to match molds; close lid
and heat for 1 minute, watching carefully to prevent burning.
• Baked waffle sticks freeze well. Cool waffle sticks completely on a wire rack. Store in a
plastic freezer bag or in a covered container, separating each waffle stick with wax paper.
Reheat frozen waffle sticks in a toaster oven or oven, until hot and crisp.
6
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 6 12-07-16 9:38 AM
uSEr MAINTENANCE INSTruCTIONS
This appliance requires little maintenance. It contains no user serviceable parts.
Do not try to repair it yourself. Contact a qualified appliance repair technician if the product
requires servicing.
CArE & CLEANINg INSTruCTIONS
CAUTION: Unplug from electrical outlet and allow to cool thoroughly before cleaning
or storing.
1. The Waffle Stick Maker does not disassemble for cleaning.
2. Never immerse appliance in water or other liquids. Never place Waffle Stick Maker in
dishwasher.
3. The waffle stick cooking plates should be cleaned and conditioned before each heating.
4. Brush cooking plates with a clean, soft pastry brush or cloth. To condition plates,
lightly coat the cooking surfaces with solid vegetable shortening or vegetable oil.
Carefully follow suggested cleaning procedures below. After a time, if waffle sticks show
signs of sticking, recondition as needed.
5. To protect the non-stick surfaces, use only plastic, nylon or wooden utensils.
6. To remove any batter baked onto the cooking plates, pour a small amount of cooking
oil onto the hardened batter. Allow to set for 5 minutes, then wipe softened batter off with
a paper towel or soft cloth. Remove stubborn stains with a plastic mesh puff or pad.
For best results, use only products with directions stating they are safe for cleaning
non-stick cooking surfaces. Do not use steel wool or coarse scouring pads.
7. The exterior finish should be cleaned with a non-abrasive cleaner and a soft, damp cloth.
Dry thoroughly.
STOrINg INSTruCTIONS
1. Make sure unit is unplugged and fully cooled.
WARNING: Never store Waffle Stick Maker while it is hot or still plugged in.
2. Use the cord wrap on the bottom of the Waffle Stick Maker to store the cord.
3. Do not place any stress on cord where it enters unit, as this could cause cord to fray
and break.
4. Store Waffle Stick Maker in its box, in a cool dry area.
7
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 7 12-07-16 9:38 AM
recetaS
Strawberry waffle
StickS
4 tablespoons strawberry preserves
6 tablespoons unsalted butter
2 large eggs
1/2 cup milk
1 (6 oz) strawberry yogurt
1/2 teaspoon pure vanilla extract
1 cup all-purpose flour
3 tablespoons cornstarch
2 tablespoons granulated sugar
1 tablespoon baking powder
1. Place butter and preserves in a microwave-safe bowl. Heat on HIGH
power for 1 minute. Remove from oven and stir. Cut solid remaining
butter into smaller pieces and mix. Set aside, allow to cool.
2. In a medium bowl, combine dry ingredients and whisk to combine.
3. In a small bowl, combine liquid ingredients and (not hot) melted
4. Pour the liquid ingredients into the dry. Whisk together until just
mixed. Batter should be thick, but pourable. Add milk to thin batter
5. Pour a scant 3/4 cup batter into the center of the waffle plate. Use a
knife to spread batter to all corners of the mold. Bake waffle sticks for
Dip these precious waffle sticks in strawberry sauce.
Serve with your favorite ice cream, whipped cream or chocolate sauce.
butter mixture. Whisk to combine.
if necessary.
3 to 4 minutes or until golden brown.
5. Repeat with remaining batter.
Enjoy with fresh strawberries and whipped cream.
8
SO-309150_13575 BELLA Waffle Stick Maker IM Interior_R2.indd 8 12-07-16 9:39 AM
Loading...
