CSA 240 M30W
Table of contents
Loading...
Refrigerator-Freezer type I
Chladnička
-Mrazák typu I
Chladnička
-Mraznička typu I
Chłodziarko
-Zamrażarka typu I
Külmik
-Sügavkülmik I tüüpi
Hladnjak
-Zamrzivač tipa I
CSA240M30W
Bezpieczeństwo przede wszystkim /22
Podłączenie do zasilania /23
Instrukc
ja transportu i ustawienia /23
Montaż /23
Zapoznaj się z twoim urządzeniem /24
Porady dotyc
zące przechowywania żywności /24
Regulacja temperatury /24
Uruchamianie /25
Porady dotyczące przech
owywania zamrożonej
żywności /25
Mrożenie świeżej żywności
/25
Jak
robić kostki lodu /26
Odmrażanie; Wymiana żarówki /26
Czyszczenie urządzenia /26
Zmia
na kierunku otwierania drzwi /27
Środki ostro
żności w trakcie użytkowania /27
Odzysk opakowania / 27
Usuwanie usterek /28
Zużycie energii
; Dźwięki wydawane podczas pracy /28
Odzysk st
arego urządzenia chłodniczego /28
Rozmieszczenie żywności
; Przykłady zastosowań /29
Zalecane ustawienia /29
Ohutus ennekõike! /30
Elektriohutus /31
Transpordieeskirjad /31
Paigaldusjuhised /31
Esmane tutvus seadmega /32
Toiduainete soovitusl
ik paigutus seadmes /32
Tempera
tuuri valik ja reguleerimine /32
Enne seadme kasutamist /32
Külmut
atud toiduainete säilitamine /33
Värs
kete toiduainete külmutamine /33
Jääkuubikute valmistamine /33
Sulatam ine /33
S
isevalgusti pirni vahetamine /34
Puhastamin
e ja hooldus /34
Ukse avanemissuuna muutmine /34
Käsud ja keelud /34
Energiakulu /35
Seadme töötamisel
tekkiv müra ja vibratsioon /35
Probleemide kõrvaldamine /36
Sigurnost na prvom mjestu /37
Električal priključak /38
Upute za tra
nsport; Upute za instalaciju /38
Upoznavanje s uređajem /39
Preporuč
eni raspored hrane u uređaju /39
Kontro
la temperature i podešavanje /39
Prije upotrebe /
39
Pohrana zamrznute hrane /40
Zamrzavanje svježe hrane /40
Pr
iprema kockica leda /40
Odmrzavanje /40
Zamjena sija
lice unutarnjeg osvjetljenja /41
Čišćenje i održavanje /41
Premještanje vrata /41
Učiniti / Ne učiniti /41
Potrošnja energije /42
Informa
cije u vezi buke i vibracija /43
Otklanjanje problema /43
Safety first /1
Electrical requir ements /2
Transportation instructio ns /2
Installation instructions /2
Getting to know your appliance /3
Suggested arrangement of food in the appliance /3
Tempe
rature control and adjustment /3
Before operating /4
Storing frozen food
/4
Freezing fresh food /4
Making ice cubes /4
Defrosting /4
Replacing the interior light bulb /5
Cleaning and care /5
Repositioning the door /5
Do’s and don’ts /5
Energy consumption /6
Information about operating noises /7
Troubleshooting /7
Bezpečnost především /8
Elektrické požadavky /9
Pokyny pro transport /9
Pokyny pro instalaci /9
S
eznámení s vaším spotřebičem /10
Doporučené rozl
ožení potravin ve spotřebiči /10
Kontrola a nastavení teploty /10
Před zahájením provozu
/11
Skladování zmražen
ých potravin /11
Mražení čerstvých potravin /11
Tvorba kostek ledu /11
Odmrazování /11
Výměna vnitřní žárovky /12
Čištění a péče /12
Výměna dvířek
/12
Co dělat a co nedělat /12
Spotřeba energie /13
In
formace o provozních hlucích /14
Odstraňování potíží /14
Bezpečnosť nadovšetko /15
Elektrické požiadavky /16
Prepravné pokyny /16
Inštalačné pokyny /16
Poznávanie spotrebiča /17
Navrhnuté rozmies
tnenie potravín v spotrebiči /17
R
iadenie a nastavenie teploty /17
Pred prevádzkou
/18
Skladovanie zmrazen
ých potravín /18
Mrazenie čerstvých potravín /18
Tvorba kociek ľadu /18
Rozmrazovanie /18
Výmen
a žiarovky vnútorného svetla /19
Čistenie a
údržba /19
Zmena otvárania dverí
/19
Č
o sa má a čo sa nesmie robiť /19
Spotreba energie /20
Informácie o prevádzkovom
hluku /21
Riešenie problémov /21
EN Index
PL Spis treści
SK Index
CZ Obsah
EST Register
BiH Sadržaj
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally friendly refrigerant the
R600a (flammable only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, others than the ones recommended by the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that might have been recommended by the
manufacturer.
UPOZORNĚNÍ!
Aby byl zajištěn normální provoz vaší chladničky, která používá pro životní prostředí zcela neškodné chladicí médium R600a
(vznětlivé pouze za určitých podmínek), musíte dodržet následující pravidla:
Nebraňte ve volné cirkulaci vzduchu kolem přístroje.
Nepoužívejte mechanická zařízení pro zrychlení odmražení kromě těch, která jsou doporučená výrobcem.
Nelikvidujte chladicí okruh.
Nepoužívejte elektrické spotřebiče uvnitř prostoru pro potraviny kromě těch, která by mohl doporučit výrobce.
VAROVANIE!
Aby sa zabezpečila normálna prevádzka vašej chladničky, ktorá používa úplne ekologicky nezávadné chladivo R600a (horľavé len pri
určitých podmienkach), musíte dodržiavať nasledujúce pravidlá:
Nebráňte voľnej cirkulácii vzduchu okolo spotrebiča.
Nepoužívajte mechanické prístroje na urýchľovanie rozmrazovacieho procesu, iné ako odporúča výrobca.
Neporušujte chladiaci okruh.
Nepoužívajte elektrické spotrebiče vo vnútri pípacieho priestoru potravín, iné ako tie, ktoré odporúčal výrobca.
UWAGA!
Producent nie będzie ponosić odpowiedzialności za szkody wynikłe z niestosowania się do zaleceń zawartych w instrukcji obsługi.
Instrukcję obsługi należy przechowywać w bezpiecznym miejscu tak, aby można było z niej korzystać w razie konieczności. Może
być ona przydatna również dla innego użytkownika.
HOIATUS!
Et külmutusseade, mis kasutab igati keskkonnasõbralikku külmutusagensit R600a (tuleohtlik ainult teatavatel tingimustel), töötaks
normaalselt, peate järgima järgmisi eeskirju:
Ärge blokeerige õhu vaba ringlust seadme ümbr us es.
Ärge püüdke sulamist kiirendada mehaaniliste abivahenditega, mida tootja ei ole soovitanud.
Ärge kahjustage külmutusagensikontuuri.
Ärge kasutage toiduainete hoiukambrites elektriseadmeid, mida tootja ei ole soovitanud.
UPOZORENJE!
Kako bi se osigurao normalan rad vašeg zamrzivača koji koristi kompletno ekološki prihvatljivo rashladno sredstvo R600a (zapaljivo
samo pod određenim uvjetima), trebate se pridržavati slijedećih pravila:
Ne ometati slobodnu cirkulaciju zraka oko zamrzivača.
Ne koristiti mehanička sredstva za ubrzavanje odleđivanja, koja nije preporučio proizvođač.
Paziti da se ne ošteti krug rashladnog sredstva.
Unutar prostora zamrzivača za spremanje namirnice ne koristiti električne uređaje koje nije preporučio proizvođač.
1
C
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
2
3
4
5
6
7
8
9
10
Congratulations on your choice of a BEKO Quality
Appliance, designed to give you many years of service.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been
removed.
• Leave to stand for at least 4 hours before switching
on, to allow compressor oil to settle, if transported
horizontally.
• If you are discarding an old appliance with a lock or
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the
insulation which are flammable. We suggest you
contact your local authority for information on disposal
and available facilities .
• We do not recommend use of this appliance in an
unheated, cold room. (e.g. garage, conservatory,
annex, shed, out-house etc.)
To obtain the best possible performance and trouble
free operation from your appliance it is very important to
read these instructions carefully. Failure to observe
these instructions may invalidate your right to free
service during the guarantee period.
Please keep these instructions in a safe place for easy
reference.
Original Spare parts will be provided for 10 years,
following the product purchasing date
EN Instruction for use
1
This appliance is not intended for use by person with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
EN Instruction for use
Electrical requir ement s
Before inserting the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating plate inside the appliance
corresponds to your electricity supply.
We recommend that this appliance is
connected to the mains supply via a suitably
switched and fused socket in a readily
accessible positio n.
Warning! This appliance must be earthed.
Repairs to electrical equipment should only be
performed by a qualified technician. Incorrect
repairs carried out by an unqualified person
are carry risks that may have critical
consequences for the user of the appl i ance.
ATTENTION!
This appliance operates with R600a which is
an environmental friendly but flammable gas.
During the transportation and fixing of the
product, care must be taken not to damage
the cooling system. If the cooling system is
damaged and there is a gas leakage from the
system, keep the product away from open
flame sources and ventilate the room for a
while.
WARNING - Do not use mechanical devices
or other means to accelerate the defrosting
process, others than those recommended by
the manufacturer.
WARNING - Do not damage the refrigerant
circuit.
WARNING - Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they ar e of the ty pe
recommended by the manufacturer.
WARNING - If the supply cord is damaged, it
must be replaced by the manufacturer, its
service agent or similarly qualified persons in
order to avoid a hazard.
Transportation instructions
1. The appliance should be transported only in
an upright position. The packing as supplied
must be intact during transportation.
2. If during the transport the appliance, has
been positioned horizontally, it must not be
operated for at least 4 hours, to allow the
system to settle.
3. Failure to comply with the above
instructions could result in damage to the
appliance, for which the manufacturer will not
be held liable.
4. The appliance must be protect ed ag ai ns t
rain, moisture and other atmospheric
influences.
Important!
• Care must be taken while cleaning/carrying
the appliance not to touch the bottom of the
condenser metal wires at the back of the
appliance, as this could cause injury to fingers
and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use.
You could injure yourself or damage the
appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving,
as this could damage the cable.
• Do not allow children to play with the
appliance or tamper with the controls.
Installation instr uctions
1. Do not keep your appliance in a room
where the temperature is likely to fall below 10
degrees C (50 degrees F) at night and/or
especially in winter, as it is designed to
operate in a
mbient temperatures between +10
and +38 degrees C (50 and 107 degrees F).
At lower temperatures the appl i a nce may not
operate, resulting in a reduction in the storage
life of the food.
2. Do not place the appliance near cooker s o r
radiators or in direct sunlight, as this will
cause extra strain on the appliance's
functions. If installed next to a source of heat
or freezer, maintain the following minimum
side clearances:
From Cookers 30 mm
From Radiators 300 mm
From Freezers 25 mm
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation (Item 2).
• Put the back airing lid to the back of your
refrigerator to set the distance between the
refrigerator and the wall (Item 3).
2
EN Instruction for use
4. The appliance should be positioned on a
smooth surface. The two front feet can be
adjusted as required.To ensure that your
appliance is standing upright adjust the two
front feet by turning clockwise or anti-
clockwise, until firm contact is secured with
the floor. Correct adjust me nt of feet prevents
excessive vibration and noise (Item 4).
5. Refer to "Cleaning and Care" section to
prepare your appliance for use.
Getting to know your appli a nc e
(Item 1)
1 - Thermostat and lamp housing
2 - Adjustable Cabinet s helves
3 - Water collector
4 - Crisper cover
5 - Crispers
6 - Compartment for quickly freezing
7 - Ice tray support & ice tray
8 - Compartments for fr ozen froods keeping
9 - Adjustable foot
10 - Shelf for jars
11 - Shelf for bottles
Suggested arrangement of food i n
the appliance
Guidelines for obtaining optimum storage and
hygiene:
1. The fridge compartmen t is for the short-
term storage of fresh food and drinks .
2. The freezer compart men t is
rated
and suitable for the freezing and storage
of pre-frozen food.
The recommendation for storage as
stated on the food packaging should be
observed at all times.
3. Dairy products should be stored in the
special compartment provided in the door
liner.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped produce can be kept on
the shelf. Fresh fr
uit and vegetables should be
cleaned and stored in the crispers.
6. Bottles can be kept in the door section.
7. To store raw meat, wrap in polythene
bags and place on the lowest shelf. Do not
allow to come into contact with cooked food,
to avoid contamination. For safety, only store
raw meat for two to three days.
8. For maximum efficiency, the removable
shelves should not be covered with paper or
other materials to allow free circulation of cool
air.
9. Do not keep vegetable oil on door
shelves. Keep the food packed, wrapped or
covered. Allow hot food and beverages to cool
before refrigerating. Leftover canned food
should not be stored in the can.
10. Fizzy drinks should not be frozen and
products such as flavoured water ices should
not be consumed too cold.
11. Some fruit and vegetables suffer damage
if kept at temperatures near 0°C. Therefore
wrap pineapples, melons, cucumbers,
tomatoes and similar produce in polythene
bags.
12. High-proof alcohol must be stored uprig ht
in tightly closed containers. Never store
products that contain an inflammable
propellant gas (e.g. cream dispensers, spray
cans, etc.) or explosive substances. These
are an explosion hazard.
13. To take out the baskets from the fre ezer
compartment please proceed as in Item 9.
Temperature control and a djustment
Operating temperatures are controlled by the
thermostat knob (Item 5) and may be set at
any position between 1 and 5 (the coldest
position).
The average temperature inside the fridge
should be around +5°C (+41°F).
Therefore adjust the thermostat to obtain the
desired temperature. Some sections of the
fridge may be cooler or warmer (such as
salad crisper and top part of the cabinet)
which is quite normal. We recommend that
you check the temperature periodically with a
thermometer to ensu
re that the cabinet is kept
to this temperature. Freq uent door op eni ng s
cause internal temperatures to rise, so it is
advisable to close the door as soon as
possible after use.
3
EN Instruction for use
Before operating
Final Check
Before you start using the appliance check
that:
1. The feet have been adjusted for perf ect
levelling.
2. The interior is dry and air can circulate
freely at the rear.
3. The interior is clean as recommended
under "Cleaning and care.”
4. The plug has been inserted into the wall
socket and the electricity is switched on.
When the door is open the interior light will
come on.
And note that:
5. You will hear a noise as the compressor
starts up. The liquid and gases sealed within
the refri geration system may also make some
(noise), whether the compressor is running or
not. This is quite normal.
6. Slight undulation of the top of the cabinet is
quite normal due to the manufacturing
process used; it is not a defect.
7. We recommend setting the
thermostat knob
midway and monitor the temperature to
ensure the appliance maintains desired
storage temperatures (See section
Temperature Control and Adjustment).
8. Do not load the appliance immediately it is
switched on. Wait until the correct storage
temperature has been reached. We
recommend checking the temperature with an
accurate thermometer ( see; Temp er atur e
Control and Adjustment).
Storing frozen food
Your freezer is suitable for the long-term
storage of commercially frozen foods and also
can be used to freeze and store fres h food .
If there is a power failure, do not open the
door. Frozen food should not be affected if the
failure lasts for less than 16 hrs. If the failure
is longer, then the food should be checked
and either eaten immediatel y or cooked and
then re-frozen.
Freezing fresh food
Please observe the following instructions to
obtain the best results.
Do not freeze too large a quantity at any one
time. The quality of the food is best preserved
when it is frozen right through to the core as
quickly as possible.
Do not exceed the freezing capacity of your
appliance in 24 h.
Placing warm food into the freezer
compartment causes the refrigeration
machine to operate continously until the food
is frozen solid. This can temporarily lead to
excessive cooling of the refrigeration
compartment.
When freezing fresh food, keep the
thermostat knob at medium position. Small
quantities of food up to 1/2 kg. (1 lb) can be
frozen without adjusting the temperature
control knob.
Take special care not to mix already frozen
food and fresh food.
Making ice cubes
Fill the ice - cube tray 3/4 full with water and
place it in the freezer. Loosen frozen tr ays
with a spoon handle or a similar implement;
never use sharp-edged objects such as
knives or forks.
Defrosting
A) Fridge compartment
The fridge compartment defrosts automatically.
The defrost water runs to the dr ain tube via a
collection container at the back of the appliance
(Item 6).
During defrosting, water droplets may form at
the back of the fridge compartment where a
concealed evaporator is located. Some droplets
may remain on the liner and refreeze when
defrosting is compl eted. Do not use pointed or
sharp-edged objects such as knives or forks to
remove the droplets which have refrozen.
If, at any time, the defrost water does not drain
from the collection channel, check that no food
particles have blocked the drain tube. The drain
tube can be cleared with a pipe-cleaner or
similar implement.
Check that the tube is permanently placed with
its end in the collecting tray on the compressor
to prevent the water spilling on the electric
installation or on the floor (Item 7).
4
EN Instruction for use
B) Freezer compartment
Defrosting is very straig htforward and without
mess, thanks to a special def r ost collection
basin.
Defrost twice a year or when a frost layer of
around 7 (1/4") mm has formed. To start the
defrosting procedure, s witch off the appliance at
the socket outlet and pull out the mains plug.
All food should be wrapped in se veral layers of
newspaper and stored in a cool place ( e.g.
fridge or larder).
Containers of warm water may be placed
carefully in the freezer to s peed up the
defrosting.
Do not use pointed or sharp-edged objects,
such as knives or forks to remo ve the frost.
Never use hairdryers, electrical heaters or other
such electrical appliances for defrosting.
Sponge out the defrost water col lec ted in the
bottom of the freezer compartment. After
defrosting, dry the inter ior thoroughly (Item 8).
Insert the plug into the wall sock et and switch
on the electricity supply.
Replacing the interi or light bulb
To change the Bulb/LED used for illumination
of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance is not
suitable for household room illumination. The
intended purpose of this lamp is to assist the
user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable
way.
The lamps used in this appliance have to
withstand extreme physical conditions such as
temperatures below -20°C.
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outl et and pull out the
mains plug before cleani ng.
2. Never use any sharp instruments or
abrasive substances, s oap, household cleaner,
detergent or wax polish for cleaning.
3. Use luke warm water to clean t he c abinet of
the appliance and wipe it dr y.
4. Use a damp cloth wrung out in a solution of
one teaspoon of bicarbonate of soda to one pint
of water to clean the interior and wipe it dry.
5. Make sure that no water enters the
temperature control box .
6. If the appliance is not going to be us ed for a
long period of time, switc h it off, remove all food,
clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to protect
the high quality paint fi nis h.
8. Any dust that gathers on the condenser,
which is located at the back of the appliance,
should be removed once a year with a vacuum
cleaner.
9. Check door seals regularly to ensure they
are clean and free from food particles.
10. Never:
• Clean the appliance with unsuitable material; eg
petroleum based products.
• Subject it to high temperatures in any way,
• Scour, rub etc., with abrasive material.
11. Removal of dairy cover and door tray :
• To remove the dairy cover, first lift the cover up
by about an inch and pull it off from the side where
there is an opening on the cover.
• To remove a door tray, remove all the contents
and then simply push the door tray upwards from
the base.
12. Make sure that the special plastic container at
the back of the appliance which collects defrost
water is clean at all times. If you want to remove
the tray to clean it, follow the instructions below:
• Switch off at the socket outlet and pull out the
mains plug
• Gently uncrimp the stud on the compressor,
using a pair of pliers, so that the tray can be
removed
• Lift it up.
• Clean and wipe it dry
• Reassemble, reversing the sequence and
operations
13. To remove a drawer, pull it as far as possible,
tilt it upwards and then pull it out completely.
Repositioning the door
Proceed in numerical order (Item 10).
Do’s and don’ts
Do- Clean and defrost your appliance regularly
(See "Defrosting")
Do- Keep raw meat and poultry below cooked
food and dairy products.
Do- Take off any unusable leaves on vegetables
and wipe off any soil.
Do- Leave lettuce, cabbage, parsley and
cauliflower on the stem.
5
EN Instruction for use
Do- Wrap cheese firstly in greaseproof paper and
then in a polythene bag, excluding as much
air as possible. For best results, take out of
the fridge compartment an hour before
eating.
Do- Wrap raw meat and poultry loosely in
polythene or aluminium foil. This prevents
drying.
Do- Wrap fish and offal in polythene bags.
Do- Wrap food with a strong odour or which may
dry out, in polythene bags, or aluminium foil
or place in airtight container.
Do- Wrap bread well to keep it fresh.
Do- Chill white wines, beer, lager and mineral
water before serving.
Do- Check contents of the freezer every so often.
Do- Keep food for as short a time as possible
and adhere to "Best Before" and "Use by"
etc. dates.
Do- Store commercially frozen food in
accordance with the instructions given on the
packets.
Do- Always choose high quality fresh food and
be sure it is thoroughly clean before you
freeze it.
Do- Prepare fresh food for freezing in small
portions to ensure rapid freezing.
Do- Wrap all food in aluminium foil or freezer
quality polythene bags and make sure any
air is excluded.
Do- Wrap frozen food immediately after
purchasing and put it in to the freezer as
soon as possible.
Do- Defrost food in the fridge compartment.
Don’t- Store bananas in your fridge
compartment.
Don’t- Store melon in your fridge. It can be
chilled for short periods as long as it is
wrapped to prevent it flavouring other
food.
Don’t- Cover the shelves with any protective
materials which may obstruct air
circulation.
Don’t- Store poisonous or any dangerous
substances in your appliance. It has
been designed for the storage of edible
foodstuffs only.
Don’t- Consume food which has been
refrigerated for an excessive length of
time.
Don’t- Store cooked and fresh food together in
the same container. They should be
packaged and stored separately.
Don’t- Let defrosting food or food juices drip
onto food.
Don’t- Leave the door open for long periods, as
this will make the appliance more costly
to run and cause excessive ice
formation.
Don’t- Use sharp edged objects such as knives
or forks to remove the ice.
Don’t- Put hot food into the appliance. Let it
cool down first.
Don’t- Put liquid-filled bottles or sealed cans
containing carbonated liquids into the
freezer, as they may burst.
Don’t- Exceed the maximum freezing loads
when freezing fresh food.
Don’t- Give children ice-cream and water ices
direct from the freezer. The low
temperature may cause 'freezer burns'
on lips.
Don’t- Freeze fizzy drinks.
Don’t- Try to keep frozen food which has
thawed; it should be eaten within 24
hours or cooked and refrozen.
Don’t- Remove items from the freezer with
wet hands.
Energy Consumption
Maximum frozen food storage volume is
achieved without using the drawers provided
in the freezer compartment. Energy
consumption of your appliance is declared
while the freezer compartment is fully loaded
without using the drawers.
Practical advice concerning the reduction
of the electricity consumption
1. Make sure that the appliance is loc ated in
well-ventilated areas, far from any source of
heat (cooker, radiator etc.). At the same time,
the location of the applianc e must be done in
such a way that it prevents it to be under the
direct incidence of the sunbeams.
2. Make sure that the food purchas ed in
refrigerated
/frozen condition is placed into the
appliance as soon as possible, es pecially during
summertime. It is recommended to use thermal
insulated bags to transport the food home.
3. We recommend the thawing of the packets
taken out from the freezer compartment be
done in the refrigerator compartment. For this
purpose, the packet which is going to be thawed
will be placed in a vessel so that the water
resulting from the thawing does not leak in the
refrigerator compartment. We recommend you
to start the thawing at leas t
24 hours before the
use of the frozen food.
6
4. We recommend reducing the number of door
openings to the minimum.
5. Do not keep the door of the appliance open
more than necessary and make sure that after
each opening the door is well closed.
Information concerni ng t he noi s e
and the vibrations whic h mi ght
appear during the operation of the
appliance
1. The operation noise can increase during the
operation.
- I n order to keep the temperatures at the adjus
ted
temperatures, the compressor of the appliance
starts periodically. The noise produced by the
compressor becomes stronger when it starts and
a click can be heard when it stops.
- The performance and operation features of the
appliance can change according to the
modifications of the temperature of the ambient
environment. They must be considered as
normal.
2. Noises like liquids flowing or as being sprayed
- These noises are caused by the flow of the
refrigerant in the circuit of the appliance and
comply with the operation principle of the
appliance.
3. Other vibrations and noises.
- The level of noise and vibrations can be caused
by the type and the aspect of the floor on which
the appliance is placed. Make sure that the floor
does not have significant level distortions or if it
can yield to the weight of the appliance (it is
flexible).
- Another source of noise and vibrations is
represented by the objects placed on the
appliance. These objects must be removed from
the appliance
- The bottles and the vessels placed in the
refrigerator touching each other. In such cases
move the bottles and the vessels so that there is
a small distance between them.
EN Instruction for use
7
Troubleshooting
If the appliance does not operate when switched
on, check;
• That the plug is inserted proper ly in the socket
and that the power supply is on. ( To check the
power supply to the socket , plug in another
appliance)
• Whether the fuse has blown/cir c uit breaker
has tripped/main distribution switch has been
turned off.
• That the temperature control has been set
correctly.
• That the new plug is wired correctly, if you
have changed the fitted, moul d ed pl ug .
If the appliance is still not operating at all after
above checks, contact t he dealer fr om w hom
you purchased the unit.
Please ensure that abov e checks have been
done, as a charge will be made if no fault is
found.
The symbol on the product or on packaging indicates that this product may not be treated as
household waste. Instead it shall be handed over to the applicable col lect ion point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will
help prevent potential negatyve consequences for the environment and humann health, which
could otherwise be otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city office, you
household waste disposal service or the shop where you purchased the product.
Blahopřejeme k výběru kvalitního spotřebiče BEKO,
který je určen pro mnoho let služby.
Bezpečnost především!
Nezapojujte spotřebič do napájecí sítě, dokud
neodstraníte všechny obalové a přepravní materiály.
• Před zapnutím nechte nejméně 4 hodin stát, aby se
usadil olej v kompresoru po přepravě v horizontální
poloze.
• Pokud likvidujete starý spotřebič s zámkem nebo
západkou na dveřích, ujistěte se, že je v bezpečném
stavu a dětem nehrozí uvíznutí uvnitř.
• Tento spotřebič musí být používán pro stanovený
účel.
• Neodkládejte spotřebič do ohně. Váš spotřebič
obsahuje v izolační vrstvě látky bez CFC, které jsou
hořlavé. Doporučujeme kontaktovat místní úřady pro
informace o likvidaci a dostupných zařízeních.
• Nedoporučujeme používat tento spotřebič v
nevytápěné chladné místnosti. (např. garáž, sklad,
přístavba, kůlna, hospodářské stavení atd.)
Pro co nejlepší výkonnost a bezporuchovou službu
vašeho spotřebiče je velmi důležité pozorně si přečíst
tyto pokyny. Nedodržením těchto pokynů se vystavujete
riziku zrušení možnosti bezplatného servisu po dobu
záruční lhůty.
Uschovejte tyto pokyny na bezpečném místě pro
snadné vyhledání.
EN Instruction for use
CZ Pokyny pro používání
8
Tento spotřebič by neměly používat osoby se sníženou fyzickou, senzorickou nebo mentální
způsobilostí a nebo s nedostatečnými zkušenostmi a poznatky. Tyto osoby mohou spotřebič
používat jen pod dohledem osoby zodpovědné za jejich bezpečnost, a nebo pokud je
zodpovědná osoba poučila o správném používaní spotřebiče.
Děti by měly být pod dozorem, aby si nehrály se spotřebičem.
CZ Pokyny pro používání
Elektrické požadavky
Před zasunutím zásuvky do sítě se ujistěte,
že napětí a kmitočet (na štítku uvnitř
spotřebiče) odpovídají vašemu zdroji.
Doporučujeme připojit tento spotřebič do sítě
přes vhodně vypínanou a zajištěnou zásuvku
na snadno dostupném místě.
Upozornění! Tento spotřebič musí být
uzemněn.
Opravy elektrického vybavení by měl provádět
jen kvalifikovaný technik. Nesprávné opravy
provedené nekvalifikovanou osobou
představují riziko, které by mohlo mít kritické
dopady pro uživatele spotřebiče.
POZOR!
Tento spotřebič používá R600a, což je plyn,
který je šetrný k životnímu prostředí, ale je
hořlavý. Během přepravy a upevňování
výrobku je třeba dbát zvýšené opatrnosti, aby
nedošlo k
poškození chladicí soustavy. Pokud
je chladicí soustava poškozená a ze systému
uniká plyn, udržte výrobek mimo otevřený
oheň a nějakou dobu v místnosti větrejte.
UPOZORNĚNÍ – Nepoužívejte mechanické
nástroje nebo jiné prostředky k urychlení
procesu odmrazení s výjimkou těch, které
doporučuje výrobce.
UPOZORNĚNÍ – Nepoškozujte chladicí
obvod.
UPOZORNĚNÍ – Nepoužívejte elektrické
spotřebiče uvnitř prostor na skladování
potravin spotřebiče, pokud se nejedná o typy
doporučené výrobcem.
UPOZORNĚNÍ – V případě poškození
napájecího kabelu je nutno jej nechat vyměnit
u výrobce, jeho servisního zástupce či
podobně kvalifikované osoby, aby se předešlo
nebezpečí.
Pokyny pro přepravu
1. Spotřebič se smí přenášet jen ve svislé
pozici. Obaly musí zůstat během přepravy
neporušené.
2. Pokud byl spotřebič během přepravy
umístěn vodorovně, nesmí být používán po
vybalení nejméně 4 hodin, aby se systém
mohl ustálit.
3. Nedodržení výše uvedených pokynů by
mohlo vést k poškození spotřebiče, za které
výrobce nezodpovídá.
4. Spotřebič je třeba chránit proti dešti, vlhku
a jiným atmosférickým vlivům.
Důležité upozornění!
• Při čištění/přenášení spotřebiče se
nedotýkejte spodní části kovových kabelů
kondenzátoru na zadní straně spotřebiče,
mohlo by dojít k poranění prstů a rukou.
• Nepokoušejte se stoupat nebo sedat na
horní okraj spotřebiče, jelikož na toto není
určen. Mohli byste se zranit nebo poškodit
spotřebič.
• Ujistěte se, že napájecí kabel není zachycen
pod spotřebičem během a po přesouvání,
mohlo by to poškodit kabel.
• Nedovolte dětem hrát si se spotřebičem
nebo manipulovat s ovladači.
Pokyny pro instalaci
1. Nepřechovávejte spotřebič v místnosti, kde
může teplota klesnout pod 10°C v noci a/nebo
zejména v noci, jelikož je určen na provoz v
teplotách mezi +10 a +38 stupni Celsia. Při
nižších teplotách nemusí spotřebič fungovat,
čímž poklesne doba skladovatelnosti potravin.
2. Neumisťujte spotřebič do blízkosti sporáků
nebo radiátorů nebo na přímé sluneční světlo,
dojde tím ke zvýšenému napětí funkcí
spotřebiče. Při instalaci v
blízkosti zdroje tepla
nebo mrazničky udržujte minimální odstupy
po stranách:
Od sporáků 30 mm
Od radiátorů 300 mm
Od mrazniček 25 mm
3. Ujistěte se, že kolem spotřebiče je
dostatečný odstup tak, aby se zaručil volný
oběh vzduchu (Položka 2).
• Umístěte zadní odvětrávací víko na zadní
stranu vaší chladničky, abyste viděli
vzdálenost mezi chladničkou a stěnou
(Položka 3).
9
Loading...
