GB Instruction for use
Congratulations on your choice of a Quality
Appliance, designed to give you many years of service.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been
removed.
• Leave to stand for at least 4 hours before switching
on, to allow compressor oil to settle, if transported
horizontally.
• If you are discarding an old appliance with a lock or
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the
insulation which are flammable. We suggest you
contact your local authority for information on disposal
and available facilities.
• We do not recommend use of this appliance in an
unheated, cold room. (e.g. garage, conservatory,
annex, shed, out-house etc.)
To obtain the best possible performance and trouble
free operation from your appliance it is very important to
read these instructions carefully. Failure to observe
these instructions may invalidate your right to free
service during the guarantee period.
Please keep these instructions in a safe place for easy
reference.
1
Electrical requirements
Repairs to electrical equipment should only be
nsported only in
• Make sure that the mains cable is not caught
where the temperature is likely to fall below 10
operate in ambient temperatures between +10
GB Instruction for use
Before inserting the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating plate inside the appliance
corresponds to your electricity supply.
We recommend that this appliance is
connected to the mains supply via a suitably
switched and fused socket in a readily
accessible position.
Warning! This appliance must be earthed.
3. Failure to comply with the above
instructions could result in damage to the
appliance, for which the manufacturer will not
be held liable.
4. The appliance must be protected against
rain, moisture and other atmospheric
influences.
Important!
• Care must be taken while cleaning/carrying
the appliance not to touch the bottom of the
condenser metal wires at the back of the
appliance, as this could cause injury to fingers
performed by a qualified technician. Incorrect
repairs carried out by an unqualified person
are carry risks that may have critical
consequences for the user of the appliance.
ATTENTION!
and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use.
You could injure yourself or damage the
appliance.
This appliance operates with R 134a which is
an environmental friendly but flammable gas.
During the transportation and fixing of the
product, care must be taken not to damage
the cooling system. If the cooling system is
damaged and there is a gas leakage from the
system, keep the product away from open
flame sources and ventilate the room for a
while.
under the appliance during and after moving,
as this could damage the cable.
• Do not allow children to play with the
appliance or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room
WARNING - Do not use mechanical devices
or other means to accelerate the defrosting
process, others than those recommended by
degrees C (50 degrees F) at night and/or
especially in winter, as it is designed to
the manufacturer.
WARNING - Do not damage the refrigerant
circuit.
WARNING - Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
Transportation instructions
1. The appliance should be tra
an upright position. The packing as supplied
must be intact during transportation.
2. If during the transport the appliance, has
been positioned horizontally, it must not be
operated for at least 4 hours, to allow the
system to settle.
and +32 degrees C (50 and 90 degrees F). At
lower temperatures the appliance may not
operate, resulting in a reduction in the storage
life of the food.
2. Do not place the appliance near cookers or
radiators or in direct sunlight, as this will
cause extra strain on the appliance's
functions. If installed next to a source of heat
or freezer, maintain the following minimum
side clearances:
From Cookers 30 mm
From Radiators 300 mm
From Freezers 25 mm
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation (Item 2).
• Put the back airing lid to the back of your
refrigerator to set the distance between the
refrigerator and the wall (Item 3).
2
and vegetables should be
covered. Allow hot food and beverages to cool
GB Instruction for use
4. The appliance should be positioned on a
smooth surface. The two front feet can be
adjusted as required.To ensure that your
appliance is standing upright adjust the two
front feet by turning clockwise or anticlockwise, until firm contact is secured with
the floor. Correct adjustment of feet prevents
excessive vibration and noise (Item 4).
5. Refer to "Cleaning and Care" section to
prepare your appliance for use.
Getting to know your appliance
(Item 1)
1 - Thermostat and lamp housing
2 - Adjustable Cabinet shelves
3 - Water collector
4 - Crisper cover
5 - Crispers
6 - Ice tray support and ice tray
7 - Compartment for quickly freezing
8 - Compartments for frozen froods keeping
9 - Adjustable foot
10 - Dairy Compartment
11 - Shelf for jars
12 - Bottle stop
13 - Shelf for bottles
Suggested arrangement of food
in the appliance
Guidelines for obtaining optimum storage and
hygiene:
1. The fridge compartment is for the shortterm storage of fresh food and drinks.
2. The freezer compartment is rated
and suitable for the freezing and storage
of pre-frozen food.
The recommendation for storage
as stated on the food packaging should be
observed at all times.
3. Dairy products should be stored in the
special compartment provided in the door
liner.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped produce can be kept on
the shelf. Fresh fruit
cleaned and stored in the crispers.
6. Bottles can be kept in the door section.
7. To store raw meat, wrap in polythene
bags and place on the lowest shelf. Do not
allow to come into contact with cooked food,
to avoid contamination. For safety, only store
raw meat for two to three days.
8. For maximum efficiency, the removable
shelves should not be covered with paper or
other materials to allow free circulation of cool
air.
9. Do not keep vegetable oil on door
shelves. Keep the food packed, wrapped or
before refrigerating. Leftover canned food
should not be stored in the can.
10. Fizzy drinks should not be frozen and
products such as flavoured water ices should
not be consumed too cold.
11. Some fruit and vegetables suffer damage
if kept at temperatures near 0°C. Therefore
wrap pineapples, melons, cucumbers,
tomatoes and similar produce in polythene
bags.
12. High-proof alcohol must be stored upright
in tightly closed containers. Never store
products that contain an inflammable
propellant gas (e.g. cream dispensers, spray
cans, etc.) or explosive substances. These
are an explosion hazard.
3
Temperatur
e control and
ensure that the cabinet is kept
Before operating
7. We recommend setting the thermostat knob
GB Instruction for use
adjustment
Operating temperatures are controlled by the
thermostat knob and may be set at any
position between MIN and MAX (the coldest
position).
The average temperature inside the fridge
should be around +5°C (+41°F).
Therefore adjust the thermostat to obtain the
desired temperature. Some sections of the
fridge may be cooler or warmer (such as
salad crisper and top part of the cabinet)
which is quite normal. We recommend that
you check the temperature periodically with a
thermometer to
to this temperature. Frequent door openings
cause internal temperatures to rise, so it is
advisable to close the door as soon as
possible after use.
Final Check
Before you start using the appliance check
that:
1. The feet have been adjusted for perfect
levelling.
2. The interior is dry and air can circulate
freely at the rear.
3. The interior is clean as recommended
under "Cleaning and care.”
4. The plug has been inserted into the wall
socket and the electricity is switched on.
When the door is open the interior light will
come on.
And note that:
5. You will hear a noise as the compressor
starts up. The liquid and gases sealed within
the refrigeration system may also make some
(noise), whether the compressor is running or
not. This is quite normal.
6. Slight undulation of the top of the cabinet is
quite normal due to the manufacturing
process used; it is not a defect.
midway and monitor the temperature to
ensure the appliance maintains desired
storage temperatures (See section
Temperature Control and Adjustment).
8. Do not load the appliance immediately it is
switched on. Wait until the correct storage
temperature has been reached. We
recommend checking the temperature with an
accurate thermometer (see; Temperature
Control and Adjustment).
4
Storing frozen food
door. Frozen food should not be affected if the
Defrosting
compartment at least twice a year or when the
up, especially in the upper side
GB Instruction for use
Your freezer is suitable for the long-term
storage of commercially frozen foods and also
can be used to freeze and store fresh food.
If there is a power failure, do not open the
failure lasts for less than 20 hrs. If the failure
is longer, then the food should be checked
and either eaten immediately or cooked and
then re-frozen
Freezing fresh food
Please observe the following instructions to
obtain the best results.
Do not freeze too large a quantity at any one
time. The quality of the food is best preserved
when it is frozen right through to the core as
quickly as possible.
Do not exceed the freezing capacity of your
appliance in 24 h.
Placing warm food into the freezer
compartment causes the refrigeration
machine to operate continously until the food
is frozen solid. This can temporarily lead to
excessive cooling of the refrigeration
compartment.
We recommanded you to press fast freeze
button nearly 2 hours before you load your
fresh food to freeze.
This will shorten your freezeng time period.
Take special care not to mix already frozen
food and fresh food.
Making ice cubes
Fill the ice - cube tray 3/4 full with water and
place it in the freezer. Loosen frozen trays
with a spoon handle or a similar implement;
never use sharp-edged objects such as
knives or forks.
A) Fridge compartment
The fridge compartment defrosts
automatically. The defrost water runs to the
drain tube via a collection container at the
back of the appliance (Item 5).
During defrosting, water droplets may form at
the back of the fridge compartment where a
concealed evaporator is located. Some
droplets may remain on the liner and refreeze
when defrosting is completed. Do not use
pointed or sharp-edged objects such as
knives or forks to remove the droplets which
have refrozen.
If, at any time, the defrost water does not
drain from the collection channel, check that
no food particles have blocked the drain tube.
The drain tube can be cleared with a pipecleaner or similar implement.
B) Freezer compartment
We recommend you to defrost the freezer
ice layer is too thick.
Before defrosting, put the thermostat knob on
the highest position so that the food get more
cold. During this time the temperature of the
refrigerator must not be too low.
- Unplug the appliance.
- Take out the frozen food, wrap them in
several sheets of paper and put then in a cool
place.
- Leave the door open for a quick defrosting
and place inside vessels with warm water
(max. 800C) .
• Ice build-up is a normal phenomenon.
• The quantity and the frequency of ice build-
up depends on the ambient conditions and of
the frequency of door opening.
• The ice buildof the compartment, is a natural phenomenon
and does not affect the good operation of the
appliance.
• It is advisable to defrost the appliance when
the quantity of food is the minimum.
5
3. Use luke warm water to clean the cabinet of
6. If the appliance is not going to be used for a
• Clean the appliance with unsuitable material;
regularly. Large accumulation of ice will impair
GB Instruction for use
Do not use sharp metal objects to remove the
ice, because you risk to perforate the
evaporator.
Do not use hair dryers or other heating
electric appliances for defrosting.
After the ice has thawed, remove the water
with a cloth or a sponge, then dry well.
Insert the plug into the wall socket and switch
on the electricity supply.
Replacing the interior light bulb
Should the light fail, switch off at the socket
outlet and pull out the mains plug.
Then ensure the bulb is screwed securely in
the bulb holder. Replace the plug and switch
on.
If the light still fails, obtain a replacement E14
screw-cap type 15 Watt (Max) bulb from your
local electrical store and then fit it
Carefully dispose of the burnt-out light bulb
immediately.
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or
abrasive substances, soap, household
cleaner, detergent or wax polish for cleaning.
the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution of
one teaspoon of bicarbonate of soda to one
pint of water to clean the interior and wipe it
dry.
5. Make sure that no water enters the
temperature control box.
long period of time, switch it off, remove all
food, clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to
protect the high quality paint finish.
8. Any dust that gathers on the condenser,
which is located at the back of the appliance,
should be removed once a year with a
vacuum cleaner.
9. Check door seals regularly to ensure they
areclean and free from food particles.
10. Never:
eg petroleum based products.
• Subject it to high temperatures in any way,
• Scour, rub etc., with abrasive material.
11. Removal of dairy cover and door tray :
• To remove the dairy cover, first lift the cover
up by about an inch and pull it off from the
side where there is an opening on the cover.
• To remove a door tray, remove all the
contents and then simply push the door tray
upwards from the base.
12. Make sure that the special plastic
container at the back of the appliance which
collects defrost water is clean at all times. If
you want to remove the tray to clean it, follow
the instructions below:
• Switch off at the socket outlet and pull out
the mains plug
• Gently uncrimp the stud on the compressor,
using a pair of pliers, so that the tray can be
removed
• Lift it up.
• Clean and wipe it dry
• Reassemble, reversing the sequence and
operations
13. Excess deposit of ice should be removed
the performance of the freezer.
14. To remove a drawer, pull it as far as
possible, tilt it upwards and then pull it out
completely.
Repositioning the door
Proceed in numerical order (Item 6).
6
Do’s and don’ts
as much air as possible. For best results,
Chill white wines, beer, lager and mineral
accordance with the instructions given on
Don’t
-
excessive length of
GB Instruction for use
Do- Clean and defrost your appliance
regularly (See "Defrosting")
Do- Keep raw meat and poultry below
cooked food and dairy products.
Do- Take off any unusable leaves on
vegetables and wipe off any soil.
Do- Leave lettuce, cabbage, parsley and
cauliflower on the stem.
Do- Wrap cheese firstly in greaseproof paper
and then in a polythene bag, excluding
take out of the fridge compartment an
hour before eating.
Do- Wrap raw meat and poultry loosely in
polythene or aluminium foil. This
prevents drying.
Do- Wrap fish and offal in polythene bags.
Do- Wrap food with a strong odour or which
may dry out, in polythene bags, or
aluminium foil or place in airtight
container.
Do- Wrap bread well to keep it fresh.
Do-
water before serving.
Do- Check contents of the freezer every so
often.
Do- Keep food for as short a time as possible
and adhere to "Best Before" and "Use
by" etc. dates.
Do- Store commercially frozen food in
the packets.
Do- Always choose high quality fresh food
and be sure it is thoroughly clean before
you freeze it.
Do- Prepare fresh food for freezing in small
portions to ensure rapid freezing.
Do- Wrap all food in aluminium foil or freezer
quality polythene bags and make sure
any air is excluded.
Do- Wrap frozen food immediately after
purchasing and put it in to the freezer as
soon as possible.
Do- Defrost food in the fridge compartment.
Don’t- Store melon in your fridge. It can be
Don’t- Cover the shelves with any protective
Don’t- Store poisonous or any dangerous
Don’t- Consume food which has been
Don’t- Store cooked and fresh food together
Don’t- Let defrosting food or food juices drip
Don’t- Leave the door open for long periods,
Don’t- Use sharp edged objects such as
Don’t- Put hot food into the appliance. Let it
Don’t- Put liquid-filled bottles or sealed cans
Don’t- Exceed the maximum freezing loads
Don’t- Give children ice-cream and water
Don’t- Freeze fizzy drinks.
Don’t- Try to keep frozen food which has
Don’t- Remove items from the freezer with
Store bananas in your fridge
compartment.
chilled for short periods as long as it
is wrapped to prevent it flavouring
other food.
materials which may obstruct air
circulation.
substances in your appliance. It has
been designed for the storage of
edible foodstuffs only.
refrigerated for an
time.
in the same container. They should
be packaged and stored separately.
onto food.
as this will make the appliance more
costly to run and cause excessive ice
formation.
knives or forks to remove the ice.
cool down first.
containing carbonated liquids into the
freezer, as they may burst.
when freezing fresh food.
ices direct from the freezer. The low
temperature may cause 'freezer
burns' on lips.
thawed; it should be eaten within 24
hours or cooked and refrozen.
wet hands.
7
Trouble
-
shooting
Noises during operation
The bubbling and gurgling noises coming from
GB Instruction for use
In order to keep the temperature at the value
you have adjusted, the compressor of the
appliance starts periodically.
The noises which can be heard in such
situation are normal.
They are redced as soon as the appliance
reaches the operation temperature.
The humming noise is made by the
compressor. It can become a little stronger
when the compressor starts.
the refrigerant circulating in the pipes of the
appliance, are normal operating noises.
There is always a cliking noise when the
thermostat switches the compressor on or off.
The clicking noises can be heard during the
automatic defrosting, when the walls of the
appliance expand or contract and make this
noise.
If the operating noises are too strong, the
reasons are usually minor and can be solved
very easily.
- The appliance is not in horisontal position –
adjust the front feet.
- The appliance is not free-standing – place
the appliance so that it does not lean on the
furniture or on other appliances.
- The drawers, baskets or shelves have
clearance or stick – check the detachable
components and eventually put them back.
- The bottles or vessels touch each other –
move the bottles or vessels so that there is a
small clearance between them.
If the appliance does not operate when
switched on, check;
• That the plug is inserted properly in the
socket and that the power supply is on. (To
check the power supply to the socket, plug
in another appliance)
• Whether the fuse has blown/circuit breaker
has tripped/main distribution switch has
been turned off.
• That the temperature control has been set
correctly.
• That the new plug is wired correctly, if you
have changed the fitted, moulded plug.
If the appliance is still not operating at all after
above checks, contact the dealer from whom
you purchased the unit.
Please ensure that above checks have been
done, as a charge will be made if no fault is
found.
8
GB Instruction for use
Technical data
Brand
Appliance type CS321CA-PBW10 CS321CB-PBW10
Total gross volume (l.) 320 320
Total usable volume (l.) 287 287
Freezer usable volume (l.) 87 87
Refrigerator useful volume 200 200
Freezing capacity (kg/24 h) 7 7
Energy class (1) A B
Power consumption (kWh/year) (2) 332 449
Autonomy (h) 20 20
Noise [dB(A) re 1 pW] 40 40
Ecological refrigerating agent R134 a
(1) Energy class : A . . . G (A = economical . . . G = less economical)
(2) The real power consumption depends on using conditions and appliance location.
9
4576340900
03.03.05
