Behringer VT15CD, VT15FX, VT250FX, VT30FX Instruction Manual

Electric Guitar Ampliers
VIRTUBE VT250FX/VT100FX/VT100FXH VT50FX/VT30FX/VT15FX/VT15CD
Two-Channel Guitar Ampliers with hi-quality FX, VTC Tube Modeling and Original BUGERA Speakers
Powerful 2-channel guitar ampliers with authentic VTC Tube Modeling:
• VT15FX - 15-Watts
• VT15CD - 15-Watts
• VT30FX - 30-Watts
• VT50FX - 60-Watts
• VT100FX - 100-Watts
• VT100FXH - 100-Watts
• VT250FX - 2 X 50-Watts Stereo
Awesome digital FX processor with reverb, chorus, anger and delay
FX loop for external eects devices (rack eects, stomp boxes, wah-wah pedals, etc.) (VT50FX, VT100FX, VT100FXH and VT250FX only)
Original heavy-duty BUGERA vintage guitar speakers for classic sound reproduction
2 full-featured channels oering everything you need from clean to super-fat distortion sounds
2 switchable modes on each channel: Clean/Crunch on the Clean and OD1/ OD2 on the Overdrive channel (VT100FX, VT100FXH only)
Where are the tubes?
Ask any guitarist what they want most from an amp and they’ll answer with a single word — TONE. That quest for tone drove us to develop our family of VIRTUBE ampliers. Our proprietary VTC (Virtual Tube Circuitry) gives these amazing amps their in-your-face tube-amp tone. Amps with such rich, harmonic character and buttery tube-like goodness, you’ll wonder where we hid the tubes.
All VIRTUBE amps have split-personalities: one that features dulcet-clean output, and one that drives your tone with an aggressive punch that only tubes, or our VTC modeling, can generate. So when the time comes,
you’ll be ready for everything from mellow blues to metal mayhem.
Revolutionary VTC Technology
The secret behind VIRTUBE’s incredible sound is our VTC Tube Modeling processor, which exudes the very essence of tube saturation and compression. But VTC does so much more than just generate a cheap copy of a specic amp character. It accurately emulates the interaction between classic tube stages, responding to the subtle tonal changes that occur when one stage hands the signal o the next. The resulting signal is rich in harmonic content and far more true to the nature of tube amps.
Continued on next page
Radical bass, mid and treble controls — for every sound from traditional to scooped modern (VT15FX & VT15CD, only)
Independent Bass and Treble tone controls on each channel for awesome sound shaping (VT30FX, VT50FX, VT100FX, VT100FXH, VT250FX only)
Page 2 of 7
VIRTUBE VT250FX/VT100FX VT100FXH/VT50FX VT30FX/VT15FX VT15CD
Contour control for radical midrange sweep—from traditional to scooped modern (VT30FX, VT50FX, V T100FX, VT100FXH, VT250FX)
Additional Headphone and Line output with integrated speaker simulation
Dedicated CD input for playback of line-level signals (e.g. CD player, drum machine)
Dual footswitch FS112VT for Channel selection and FX bypass included (VT30FX, VT50FX, VT100FX, VT100FXH, VT250FX only)
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Two-Channel Operation
VIRTUBE’s Clean channel is elegant in its simplicity. The sound is open and uncolored and can be tailored to your needs by Volume and the analog passive equalizer. The Overdrive channel features Gain, Volume, Bass, Treble and our proprietary Contour control, with its radical midrange sweep. All this versatility enables you to artfully dene your “perfect” tone, from traditional to scooped modern and anything in-between.
Digital FX
All VIRTUBE models, with the exception of the VT15CD, come with state-of-the-art eects — and not some cheap-and-cheesy reverb chip, but a full-blown 24-bit digital eects processor with 16 great-sounding reverbs, choruses, angers and delays. This tasty collection of eects is a must­have for any guitarist and includes room, stage, concert and cathedral reverbs, slap-back and medium echoes, two long delays, plus slow and fast modulation eects — all right at your ngertips.
Handmade Speakers
It takes a special speaker to handle all this incredible technology, tube-like tone and brutal output power. That’s why we t each VIRTUBE combo with handmade, heavy-duty BUGERA Vintage Guitar speakers. These babies were custom-designed and handcrafted specically for the VIRTUBE Series, and are ideally suited for classic sound reproduction.
Get Connected
Whether you’re recording or just jamming on your latest ri, you need the right connections — VIRTUBE really has you covered. The PHONES/LINE OUT B jack is much more than just a place for your headphones to call home. As the name implies, this jack can also be used to send your guitar signal, with speaker simulation, to another amp or mixer.* When the PHONES/ LINE OUT B jack is in use, the internal loudspeaker is muted, allowing you to crank your guitar into the wee morning hours, without bothering the neighbors.
If you’d like to play along with previously recorded tracks, just plug the output of your CD/Tape/mp3 deck into the CD IN/LINE OUT A jack. This jack also serves a second purpose, providing yet another Line Out, this time without speaker simulation.*
* Note: Use a standard ¼" TS cable to connect this line-level signal to the destination device. If a hum is detected, or the cable run is more than a few feet, you may get better results using a Direct Injection box, like our DI100 or DI20.
VIRTUBE VT250FX/VT100FX VT100FXH/VT50FX VT30FX/VT15FX VT15CD
VT15FX
Page 3 of 7Page 3 of 7
Input jack
Clean channel Volume control
Channel select switch with LED indicators for Clean and Overdrive channels
Equally perfect for aspiring and for accomplished guitarists for practicing or warm-up with uncompromised sound options. Armed with 15-Watts, a custom-designed 8" BUGERA speaker, and sixteen
FX Preset selector —
Overdrive channel Gain control
Overdrive channel Volume control
Clean and Overdrive channel Bass control
Clean and Overdrive channel MID control
Allows user to choose from 16 factory presets for reverb, chorus, anger and delay (both channels)
Clean and Overdrive channel Treble control
digital eects, including four each of the following: reverb, delay, chorus and anger, this baby is ready to rock!
CD IN/LINE OUT A — Dual­purpose jack can be used to connect the output of CD/Tape/
VTC switch
FX Level — Setting determines the amount of the selected eect is applied to the signal (both channels)
mp3 deck to amp or to send guitar signal to an external amp or mixer (no speaker simulation)
PHONES/LINE OUT B — Dual­purpose jack can be used to connect headphones for private listening or to send guitar signal to an external amp or mixer (with speaker simulation)
VT15CD
For the guitarist who already has a toolbox-full of their favorite eects gadgets, the VT15CD has all the features of the VT15FX, except the FX. With a
Input jack
Clean channel Volume control
Channel select switch with LED indicators for Clean and Overdrive channels
Overdrive channel Gain control
Overdrive channel Volume control
Clean and Overdrive channel Bass control
Clean channel, as well as an Overdrive channel with 3-band EQ, the VT15CD is all about tone!
Clean and Overdrive channel Bass control
Clean and Overdrive channel MID control
CD IN/LINE OUT A — Dual­purpose jack connects output of CD/Tape/mp3 deck to amp or sends signal to external amp or mixer (no speaker simulation)
VTC switch
PHONES/LINE OUT B — Dual-purpose jack connects headphones for private listening or sends signal to external amp or mixer (with speaker simulation)
Power switch
