Documentation for

KL6071

SPI Slave Terminal

Version: 1.0 Date: 2007-10-12

Table of contents

1 Foreword 1

1.1 Safety Instructions 1

1.1.1 Personnel Qualification 1

1.1.2 Liability Conditions 1

1.1.3 State at Delivery 1

1.2 Copyright 1

2 Product overview 2

2.1 Functional description 2

2.2 Technical data 3

3 Terminal configuration 3

3.1 Register overview 3

3.2 Register description 4

3.2.1 General register description 4

3.2.2 Terminal-specific register description 6

3.3 Control und Status Byte 7

3.4 Register communication with KL6071 8

3.4.1 Examples for Register Communication 9

4 Appendix 10

4.1 Support und Service 10

4.1.1 Beckhoff's branch offices and representatives 10

4.1.2 Beckhoff Headquarters 10

KL6071

Foreword

1 Foreword

1.1 Safety Instructions

1.1.1 Personnel Qualification

This description is only intended for the use of trained specialists in control and automation engineering who are familiar with the applicable national standards. It is essential that the following notes and explanations are followed when installing and commissioning these components.

1.1.2 Liability Conditions

The responsible staff must ensure that the application or use of the products described satisfy all the requirements for safety, including all the relevant laws, regulations, guidelines and standards.

The documentation has been prepared with care. The products described are, however, constantly under development. For that reason the documentation is not in every case checked for consistency with performance data, standards or other characteristics. None of the statements of this manual represents a guarantee (Garantie) in the meaning of § 443 BGB of the German Civil Code or a statement about the contractually expected fitness for a particular purpose in the meaning of

§ 434 par. 1 sentence 1 BGB. In the event that it contains technical or editorial errors, we retain the right to make alterations at any time and without warning. No claims for the modification of products that have already been supplied may be made on the basis of the data, diagrams and descriptions in this documentation.

1.1.3 State at Delivery

All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of BECKHOFF Automation GmbH.

1.2 Copyright

KL6071 1

Product overview

Shield

Ground

DataIN

DataOUT

2 Product overview

Functionality The KL6071 SPI slave terminals provides communication with a serial

A maximum of 96 byte of data is exchanged between the terminal and the

2.1 Functional description

processor interface (SPI).

peripheral devices. The transmission starts with a rising edge at the CS input and ends when 96 bytes are exchanged or with a falling edge at the CS input. With the falling edge the input data is valid and can be transmitted to the PLC.

13 14

A B

C D

CLK

front view

Connections Inputs (5 Volt TTL,10 kHz):

• DataIN

• CLK

• CS

• Ground

• Shield

Outputs (5 Volt TTL):

• DataOUT Power contacts The KL6071 has no power contacts. LED display The LEDs indicate the states of inputs and outputs. Process data The input process image consists out of 6 byte input data.

Byte-Offset

1, 2, 3, 4, 5

Input of the PLC Output of the PLC

Status Control DataIN0...DataIN4 DataOUT0...DataOUT4

2 KL6071

Terminal configuration

2.2 Technical data

Product name KL6071

Cut off frequency

Current consumption from K-Bus

Electrical isolation

Bit width in the input process image

Bit width in the output process image

Weight

Operating temperature

Storage temperature

Relative humidity

Vibration / Shock resistance

EMC resistance burst / ESD

Installation position

Type of protection

10 kHz typically 50 mA 500 V 5 Byte input data, 1 status byte 5 Byte output data, 1 control byte app. 60 g 0°C ... +55°C

-25°C ... +85°C 95%, no condensation conforms to EN 60068-2-6 / EN 60068-2-27, EN 60068-2-29 conforms to EN 61000-6-2 / EN 61000-6-4 any IP20

(K-Bus / field voltage)

rms

3 Terminal configuration

reserved 0x0000 R

...

... ... ... ...

reserved 0x0000 R

Diagnose-Register - not used 0x0000 R

Command register - not used 0x0000 R

Terminal type 6071 R ROM

Firmware-Version 0x???? R ROM

R10 R11 R12 R13 R14 R15 R16 R17

R30 R31 R32 R33

R63

Multiplex shift register 0x0130 R ROM Signal channels 0x0130 R ROM minimum data length 0x3030 R ROM Data structure 0x0000 R ROM reserved 0x0000 R Alignment register variable R/W RAM Hardware version 0x???? R/W SEEROM reserved 0x0000 R/W SEEROM

...

... ... ... ...

reserved 0x0000 R/W SEEROM Code-Wort-Register variable R/W RAM Feature-Register 0x0000 R/W SEEROM reserved 0x0000 R/W SEEROM

...

... ... ... ...

reserved 0x0000 R/W SEEROM

3.1 Register overview

KL6071 3

Terminal configuration

3.2 Register description

The complex terminals can be adjusted to different operating modes or

functionalities. The General Description of Register describes the contents of the registers, which are identical for all complex terminals.

The terminal-specific registers are explained in the section following to it. The access to the internal registers of the terminal is described in the

section Register Communication.

3.2.1 General register description

Complex terminals that possess a processor are capable of bidirectionally

ex-changing data with the higher-level control system. Below, these terminals are referred to as intelligent bus terminals. They include the analog inputs, the analog outputs, serial interface terminals (RS485, RS232, TTY etc.), counter terminals, encoder interfaces, SSI interfaces, PWM terminals and all other parameterizable terminals.

Internally, all intelligent terminals possess a data structure that is identical in terms of it's essential characteristics. This data area is organized in words and embraces 64 registers. The essential data and parameters of the terminal can be read and adjusted by way of the structure. Function calls with corresponding parameters are also possible. Each logical channel of an intelligent terminal has such a structure (therefore, 4-channel analog terminals have 4 register sets.

This structure is broken down into the following areas:

0 to 7

8 to 15 16 to 30 31 to 47 48 to 63

Process variables Type register Manufacturer parameters User parameters Extended user area

Process variables

R0 to R7: Registers in the terminal’s internal RAM

The process variables can be used in additional to the actual process image and their functions are specific to the terminal.

R0 to R5: Terminal specific registers

The function of these registers depends on the respective terminal type (see terminal-specific register description).

R6: Diagnostic register

The diagnostic register may contain additional diagnostic information. In the case of serial interface terminals, for example, parity errors that have occurred during data transfer are indicated.

R7: Command register

High-Byte_Write = function parameter Low-Byte_Write = function number High-Byte_Read = function result Low-Byte_Read = function number

Type registers

R8 to R15: Registers in the terminal’s internal ROM

The type and system parameters are programmed permanently by the manufacturer and can only be read by the user but cannot be modified.

4 KL6071

Terminal configuration

R8: Terminal type:

The terminal type in register R8 is needed to identify the terminal.

R9: Firmware version X.y

The firmware version can be read as an ASCII character string.

3.2.1.1 R10: Data length

R10 contains the number of multiplexed shift registers and their length in bits. The bus coupler sees this structure.

R11: Signal channels

In comparison with R10, the number of logically existing channels is located here. For example, one physically existing shift register may consist of several signal channels.

R12: Minimum data length

The respective byte contains the minimum data length of a channel to be transferred. If the MSB is set, then the control/status byte is not necessarily needed for the function of the terminal and, with appropriate configuration of the coupler, is not transferred to the control system.

R13: Data type register

Data type register

0x00 0x01 0x02 0x03 0x04 0x05 0x06 0x07 0x08 0x11 0x12

0x13 0x14

0x15 0x16

Terminal without valid data type Byte array 1 byte n bytes structure Word array 1 byte n words structure Double word array 1 byte n double words structure 1 byte 1 double word structure 1 byte 1 double word structure Byte-array with a variable logical channel length 1 byte n bytes structure with a variable logical channel

length (eg 60xx) Word-array with a variable logical channel length 1 byte n words structure with a variable logical channel

length Double word array with a variable logical channel length 1 byte n double words structure with a variable logical

channel length

R14: not used R15: Alignment bits (RAM)

The analog terminal is set to a byte limit in the terminal bus with the alignment bits.

Manufacturer parameters

R16 to R30: Manufacturer parameter area (SEEROM)

The manufacturer parameters are specific to each terminal type. They are programmed by the manufacturer but can also be modified from the control system. The manufacturer parameters are stored permanently in a serial EEPROM and are therefore not destroyed by power failures. These registers can only be modified after setting a code word in R31.

KL6071 5

Terminal configuration

User parameters

Note

Extended application area

The KL6071 has no terminal specific registers!

R31 to R47: User parameter area (SEEROM)

The user parameters are specific to each terminal type. They can be modified by the programmer. The user parameters are stored permanently in a serial EEPROM in the terminal and cannot be destroyed by power failures. The user area is write protected over a Codeword.

R31: Code word register in the RAM

The code word 0x1235 must be entered here to enable modification of parameters in the user area. Write-protection is set if a different value is entered in this register. When write protection is inactive, the code word is returned during reading of the register. The register contains the value zero when write protection is active.

R32: Feature register

This register defines the operating modes of the terminal. For example, a user-specific scaling can be activated for the analog I/Os.

R33 to R47

Registers that depend on the terminal type

R47 to R63

These registers have not been implemented.

3.2.2 Terminal-specific register description

6 KL6071

Terminal configuration

3.3 Control und Status Byte

Control byte during process data exchange

The control byte is transmitted from the controller to the terminal. It can be

used

• during process data exchange (REG = 0

• in register mode (REG = 1

bin

) or

Bit Name

7 6 5 4 3 2 1 0

REG=0 0 0 A4 A3 A2 A1 A0

Key

Bit Name Comment

7 REG 6 0 5 0

0 for Process data mode reserved reserved

4-0 A4-A0 Offset from where reading or writing is done.

The offset is calculated as follows: (A4…A0) x 5

Status byte during process data exchange

The status byte is transferred from the terminal to the control system. It

acknowledges the bits of the control byte.

Bit Name

7 6 5 4 3 2 1 0

REG=0 0 CS_ST A4 A3 A2 A1 A0

Key

Bit Name Comment

7 REG 6 0 5 CS_ST

4-0 A4-0

0 for Process data mode reserved State of the CS Input Address bits 0 to 4

KL6071 7

Terminal configuration

Terminal´s

HHL

3.4 Register communication with KL6071

When bit 7 of the control byte is set, the first two bytes of the user data are not used for process data transfer, but are written into or read out of the terminal’s register.

Bit 6=0: read Bit 6=1: write

In bit 6 of the control byte, you define whether a register is to be read or written. When bit 6 is not set, a register is read without modification. The value can be taken from the input process image. When bit 6 is set, the user data is written into a register. The operation is concluded as soon as the status byte in the input process image has supplied an acknowledgement (see examples).

Bits 0 to 5: address The address of the register to be addressed is entered in bits 0 to 5 of the

control byte.

Control byte in the register mode

Bit Name

7 6 5 4 3 2 1 0

REG=1 W/R A5 A4 A3 A2 A1 A0

Key

Bit Name Comment

7 REG 6 W/R0

1 for access to register structure 0: Read register

1: Write register

5-0 A5...A0 A total of 64 registers can be addressed with the

addresses A5...A0

To the bus coupler

K-Bus

Control-/ status byte

C/S-bit 7

If control bit 6=0: read If control bit 6=1: write

User data

2 or mors bytes

If control bit 7=0: input/output

If control bit 7=1: registerconfiguration

If control bit 7=1: adress in the control bit 0-5

Complex bus terminal

The control or status byte occupies the lowest address of a logical channel.

The corresponding register values are located in the following 2 data bytes (the BK2000 is an exception to the rule: here, an unused data byte is inserted after the control or status byte, thus setting the register value to a word limit).

8 KL6071

Terminal configuration

3.4.1 Examples for Register Communication

Example 1 Reading register 8 in the BK2000 with a Kl3022 and the end terminal.

If the following bytes are transferred from the controller to the terminal,

Byte Name Value

Byte3 Byte2 Byte1 Byte0 Data OUT, low byte Data OUT, high byte Not used Control 0xXX 0xXX 0xXX 0x88

the terminal returns the following type designation (0x0BCE corresponds to

the unsigned integer 3022).

Byte Name Value

Byte3 Byte2 Byte1 Byte0 Data IN, low byte Data IN, high byte Not used Status 0xCE 0x0B 0x00 0x88

Example 2 Writing register 31 in the BK2000 with an intelligent terminal and the end

terminal. If the following bytes (user code word) are transferred from the controller to

the terminal,

Byte Name Value

Byte3 Byte2 Byte1 Byte0 Data OUT, low byte Data OUT, high byte Not used Control 0x35 0x12 0xXX 0xDF

the user code word is set and the terminal returns the register address with

the bit 7 for register access and the acknowledgement.

Byte Name Value

Byte3 Byte2 Byte1 Byte0 Data IN, low byte Data IN, high byte Not used Status 0x00 0x00 0x00 0x9F

KL6071 9
