Bazooka EL808 Installation Manual
DESIGN &
ENGINEERING
AWARD
I
N
N
O
V
A
T
I
O
N
S
'
9
1
C
O
N
S
U
M
E
R
E
L
E
C
T
R
O
N
I
C
S
S
H
O
W
S
CONGRATULATIONS
Dear Friend,
Thank you for selecting Bazooka®subwoofer speaker systems for your car
stereo system. The Bazooka EL series represents SAS‘s continued commitment
to efficiency and design. An innovative manufacturing process developed by
SAS for the Bazooka provides consumers with state-of-the-art speaker system
design. At SAS, we take pride in manufacturing the most revolutionary bass
®
speaker systems ever created, featuring o ur patented Bass Tubes
design, and we hope you will take pride in owning them.
Several years ago, we realized that efficiency was the wave of the future
in autosound, so we made a commitment to design, manufacture, and
deliver the most efficient speaker systems possible.
Today we market our patented speaker systems worldwide and the high
quality of the Bazooka brand is well respected by co nsumers and dealers
of all nationalities.
When properly installed, Bazooka subwoofer speaker systems will give
you years of clean uninterrupted sound reproduction. Therefore, I urge you
to take a few minutes of your time to review this instruction bo oklet. It was
designed to give you a better understanding of our products and to explain
how to apply them properly.
enclosure
Thank you again for choosing Bazookas. Our early commitment to quality
has made them the product o f choice, and I am sure you will agree that
you have made the right one! Enjoy!
Sincerely,
JON C. JORDAN
President
SAS/ BAZOOKA
1
CONTENTS
System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 4,5
Mounting The Bazooka . . . . . . . . . . . . . . . . . . . . . . . . . .pg 6,7,8
Hooking Up The Bazookas To Power . . . . . . . . . . . . . . . . .pg 9
Technical Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 9,10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 10
PRACTICE SAFE LISTENING
Continuous exposure to high volumes of sound may cause permanent hearing loss. High powered auto sound systems are capable of producing
sounds well over 13 0 dB. Even short periods of play at high volume levels
can impair your ability to hear necessary traffic sounds and may constitute
a hazard. Please use commo n sense and practice SAFE LISTENING !
If you have any questions contact
the SAS Technical Support Department at:
Phone - (504) 272 7135 • Fax - (504) 272-9844
Email - tech@ sasbazooka.com • Website - www.sasbazooka.com
In Canada: (604) 988 2966
15049 Florida Blvd., Baton Rouge, LA. 70819
2
SYSTEM FEATURES
EL504 EL604/608 EL804/808 EL104/108
Woofer Size 5“ 6.5“ 8“ 10“
Voice Coil Size 1“ high power /high temp 1“ high power /high temp 1.5“ high power /high temp 1.5“ high power /high temp
Magnet Size 20 oz. 20 oz. 28 oz. 28 oz.
Frequency response 39-5000 hz. 39-1500 hz. 39-1500 hz. 39-1000 hz.
Efficiency 97 dB* 100 dB* 102 dB* 104 dB*
Power Handling 6 to 50 watts/channel 6 to 100 watts/channel 6 to 150 watts/channel 6 to 200 watts/channel
Dimensions 18“x5“x6“ 18“x6.75“x8“ 18“x8.5“x10“ 20.75“x10.3“x12.2“
Weight 10 lbs. 11 lbs. 15.5 lbs. 23 lbs.
Impedance 4 ohms 4 ohms/8 ohms 4 ohms/8ohms 4 ohms/8ohms
BASS TUBES
®
enclosure - patented Bass Reflex/ducted port alignment
5”, 6.5”, 8”, or 10” PURE-PISTON WOOFER
TURBO COOLED VOICE COILS
BASS REFLEX, DUCTED PORT ENCLOSURE
CORNER LOADING
COPLANAR OUTPUT
HIGH OUTPUT EFFICIENCY
MOISTURE RESISTANT ENCLOSURE AND WOOFER
QUICK CONNECT WIRE TERMINALS
MAXIMIZED SPACE EFFICIENCY
SPECIFICATIONS
* The efficiency levels of all Bazooka subwoofer speaker systems are measured in the
typical enviro nment: In the low bass region with one watt of power.
