B and K Reference 20 Plus Owners manual

B&K Components, Ltd.

Reference 20 Plus

A/V System Controller

Owner’s Manual

13258 0303

USER INFORMATION

SETUP SPEAKER SIZE
Model #
Serial #
Date purchased
Purchased from:

City
State
Phone
Contact

1 Front

2 Center

3 Surround

4 Surround Back

5 Subwoofer

next item adjust

MENU setup speakers

SPEAKER LOCATION feet
1 Left Front
2 Center
3 Right Front
4 Right Surround
5 Right Surr Back
6 Left Surr Back
7 Left Surround
8 Subwoofer
next item adjust
MENU setup speakers

SETUP CROSSOVERS + LFE
1 Crossover Hz
2 High Pass dB
3 Low Pass dB
4 Peak Limiter dB
5 LFE Level dB
6 DTS LFE Mode
7 Subwoofer Phase

next item adjust
MENU setup speakers

SETUP SPEAKER LEVELS

1 Left Front dB

2 Center dB

3 Right Front dB

4 Right Surround dB

5 Right Surr Back dB

6 Left Surr Back dB

7 Left Surround dB

8 Subwoofer dB

next item adjust

MENU setup speakers

SETUP ROOM EQUALIZATION

Test Tone 20 Hz Off

Notch Hz dB

Notch Width Hz

Bass Hz dB

Treble Hz dB

next item adjust

MENU setup speakers

B&K Components, Ltd., 2100 Old Union Road, Buffalo New York 14227-2725

Phone [phone], Fax [phone], http://www.bkcomp.com, E-mail: [e-mail]

ii

13258 0303

TABLE OF CONTENTS

User Information.......................................................................................................................................................ii

Table of Contents ....................................................................................................................................................iii

Acknowledgments ................................................................................................................................................... 2

Safety Precuations .................................................................................................................................................. 3

Features.................................................................................................................................................................... 4

The Basics................................................................................................................................................................ 5

Front panel ............................................................................................................................................................... 9

Rear Panel .............................................................................................................................................................. 11

Making the connection.......................................................................................................................................... 13

Audio / Video connections................................................................................................................................... 14

Digital Connections ............................................................................................................................................. 16

Surround Outputs ................................................................................................................................................ 17

Surround Speaker Output Connections .............................................................................................................. 18

Antenna Connections .......................................................................................................................................... 19

Control Outputs / IR Inputs.................................................................................................................................. 19

Frequently Asked Questions ............................................................................................................................... 20

Setup....................................................................................................................................................................... 22

The Menu System ............................................................................................................................................... 22

System Setup ...................................................................................................................................................... 23

Speakers ........................................................................................................................................................... 23

Speaker Size .............................................................................................................................................. 23

Speaker Location........................................................................................................................................ 27

Speaker Levels........................................................................................................................................... 28

Crossovers + LFE....................................................................................................................................... 29

Room Equalization ..................................................................................................................................... 33

Display............................................................................................................................................................... 36

Inputs................................................................................................................................................................. 39

Presets .............................................................................................................................................................. 43

Memory Backup .................................................................................................................................................. 45

Operation................................................................................................................................................................ 46

Power On/Off....................................................................................................................................................... 46

Sleep ................................................................................................................................................................... 46

Choosing a source .............................................................................................................................................. 47

AM/FM Tuner ...................................................................................................................................................... 47

Adjusting the Volume .......................................................................................................................................... 48

Temporary Level Adjustments ............................................................................................................................ 48

Audio Modes ....................................................................................................................................................... 49

MONO ............................................................................................................................................................... 50

STEREO............................................................................................................................................................ 50

SURROUND ..................................................................................................................................................... 50

DVD Audio......................................................................................................................................................... 50

Special Considerations ..................................................................................................................................... 50

Equalization ‘EQ’ ................................................................................................................................................. 52

Zone ‘Z’................................................................................................................................................................ 54

Presets ................................................................................................................................................................ 55

Zone 1 (A) ........................................................................................................................................................... 56

Zone 2 (B) ........................................................................................................................................................... 57

Zone 1 Favorite Presets ...................................................................................................................................... 58

Zone 2 Favorite Presets ...................................................................................................................................... 59

Getting Processor Status .................................................................................................................................... 60

Advanced Features................................................................................................................................................ 61

Advanced .......................................................................................................................................................... 61

Zone 1 Setup (A) ........................................................................................................................................ 61

Zone 2 Setup (B) ........................................................................................................................................ 64

Power On Titles .......................................................................................................................................... 68

Control Outputs........................................................................................................................................... 68

Setup Control Out 1 ............................................................................................................................. 69

Setup Control Out 2 ............................................................................................................................. 69

iii

13258 0303

Setup Control Out 3 ............................................................................................................................. 70

Setup Control Out 4 ............................................................................................................................. 70

Security Options ......................................................................................................................................... 71

DSP Usage ................................................................................................................................................. 73

RS-232 Control Port ................................................................................................................................... 73

Factory Reset ...................................................................................................................................................... 75

Troubleshooting .................................................................................................................................................... 76

A/V System Controller Specifications ................................................................................................................. 77

Returning Equipment ............................................................................................................................................ 78

Rear Panel Enlarged View .................................................................................................................................... 79

The Menu System .................................................................................................................................................. 80

iv

13258 0303

ACKNOWLEDGMENTS

Motorola
of Motorola, Inc.

Manufactured under license from Dolby Laboratories. “Dolby”, ”Pro Logic”, “AC-3", and the double-D symbol are
trademarks of Dolby Laboratories. Confidential Unpublished Works. © 1992-1997 Dolby Laboratories, Inc. All
rights reserved.

Surround EX is a trademark of Dolby Laboratories. Used under authorization.

DTS
Patent 5,451,942 & National Patent applications derived from PCT/US95/00959. Additional U.S. and Foreign
Patents pending. “DTS”, “digital sound”, and “coherent acoustics” logos are trademarks of DTS Technology LLC.
All rights reserved.

Manufactured under license from Lucasfilm Ltd. U.S. patent numbers 5,043,970; 5,189,703; and/or 5,222,059.
European patent number 0 323 830. Other U.S. and foreign patents pending. Lucasfilm and THX are registered
trademarks of Lucasfilm Ltd. Surround EX is a trademark of Dolby Laboratories. Used under authorization.

THX, Home THX Cinema, Lucasfilm THX, Re-Equalization, Timbre Matching, Adaptive Decorrelation and THX
Ultra are registered trademarks of Lucasfilm Ltd.

Accessories included: Owners manual, Remote control Manual, Power cord, Remote control, 4-AAA batteries

®

, , “ * DigitalDNA™, “Powered by Motorola”™, Motorola name and logo are registered trademarks

®

is a registered trademark of Digital Theater Systems, LLC. Additionally licensed under the following US

© Copyright 2000 All Rights Reserved.

B&K Components, Ltd., 2100 Old Union Road, Buffalo New York 14227-2725

Phone [phone], Fax [phone], http://www.bkcomp.com, E-mail: [e-mail]

2

13258 0303

SAFETY PRECUATIONS

WARNING: to prevent fire or shock hazard, do not expose this unit to rain or moisture. Care should be taken to
prevent objects or liquid from entering the enclosure. Never handle the power cord with wet hands.

The lightning flash with arrowhead, within an equilateral triangle, is intended to alert the user of the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may constitute a risk of electric shock to you.

The exclamation point within an equilateral triangle is intended to alert the user of the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the unit.

Caution: To prevent the risk of electric shock, do not remove cover. No user-serviceable parts inside. Refer

servicing to qualified service personnel.

If an outdoor antenna is connected to the antenna input, be sure it is grounded to provide some protection against
voltage surges and built up static charges. Keep the outdoor antenna away from power lines.

Unplug the processor from the AC outlet when plugging in or unplugging cables, when left unused for an
extended period of time, moving the processor, or when you suspect lightning in your area.

Prevent damage to the power cord. Do not bend, pull, place objects on, alter, etc. Replace the power cord if it
becomes damaged. Always grasp the plug on the power cord when plugging in or unplugging the processor from
the AC outlet.

Your system may produce sound levels capable of causing permanent hearing loss. Do not operate for extended
periods of time at high volume levels.

Make sure the processor is placed on a level surface.

Protect the processor from impact. (Do not drop it!!!)

Do not climb on top of the processor or place heavy objects on its top cover.

The processor is equipped with raised feet to provide ventilation, reduce acoustic feedback, and provide
protection against scratching the surface the unit is resting on. We advise against removing or altering feet.

Do not stack anything on top of the processor (processor, source, etc.) Leave a minimum of 3” clearance from the
top of the processor to the next shelf (or component).

The processor should be located away from heat sources such as heaters or amplifiers.

Do not perform any internal modifications to the processor.

Always connect the processor’s power cord to an unswitched AC outlet for normal operation.

If young children are present, adult supervision should be provided until the children are capable of following all
rules for safe operation.

Do not plug the processor’s power cord into an outlet with an unreasonable number of other devices. Be careful if
using extension cords and ensure the total power used by all devices does not exceed the power rating
(watts/amperes) of the extension cord. Excessive loads may cause the insulation on the cord to heat and possibly
melt.

Mistaking CONTROL OUTPUT or IR INPUT connectors for audio/video inputs or outputs may damage your
processor or other components.

Damage can occur to your speakers if the power rating of each individual driver is exceeded by the amplifiers
connected to your processor. Ensure that all the drivers in your system are capable of handling not only the
average power being delivered by the amplifiers, but also the peak power that is likely to be generated during
strong passages. If you are unsure of your speaker's power rating, contact the speaker manufacturer or the dealer
where you purchased them.

The processor should be serviced by qualified personnel when:

A.

The processor is not functioning properly.

B. Objects have entered the chassis.
C. The processor was exposed to rain or other type of moisture.

D. The processor was dropped, or the chassis is damaged.

PLEASE READ BEFORE INSTALLING

3

13258 0303

FEATURES

Your new processor is a versatile audio/video control center. The processor is designed to sound sensational and be an
attractive, easy-to-use addition to your audio/video system. Although you already have a good idea of your processor’s
features, we would like to take a moment to point out certain highlights.

Matrix Decoding - incorporates further processing to allow for the precise decoding of Dolby Digital Surround EX and DTS-ES

soundtracks via matrix decoding.

Two-zone operation - complete digital/analog preamp/processor for Zone 1 (A) plus an additional independent analog A/V

preamp internally for use with a second listening/viewing area - Zone 2 (B).

Internal Digitally Synthesized AM/FM Stereo tuner - store up to 40 AM or FM stations in A/V presets.

Analog inputs/outputs - seven A/V inputs and five A/V outputs all with stereo audio, composite video and S-video plus one

set of 7.1 surround outputs.

Digital inputs/outputs - six coaxial and five optical inputs with one optical and one 1/8” mini coax output.

Control Outputs - four 12 VDC @ 50 mA outputs for turning on amplifiers and controlling external systems such as a

projection screen or B & K amplifier.

IR inputs/outputs - two IR inputs and up to three IR outputs let you integrate the processor with an infrared repeater control

system.

Gold Plated Connectors - better sound with minimum signal loss and degradation.

Plug and Play operation - automatically selects the optimum input, surround sound format, and performs a wide range of

automated functions to provide invisible and easy operation.

A/V presets - 40 favorite preset memories allow instant configuration and recall of user settings.

Customized input and A/V preset names - assign names to presets, inputs, or the turn on message.

Front Panel Operation - nearly all processor functions can be controlled directly from the front panel.

Remote Control – designed to interface with standard or learning B&K multi-source universal remote controls, allows total

control of B&K and/or other brand user equipment.

RS-232 Control - easy control and interface of your B&K product with other system controllers.

96/24 bit A/D and D/A Conversion - Ultra High Resolution reproduction of musical details.

96/24 bit processing - 96/24 bit digital data and analog source material use 96 kHz, 24 bit DSP processing during all stereo

listening modes.

Selectable Bass Management Crossover Frequency and Slope - allows system versatility for bass adjustments and

management to assure optimum performance from your speaker system.

Room Equalization - a sweepable notch filter and variable equalization is available in the digital domain for use in achieving

the best possible room response.

Upgradeable - modular design allows for future A/D, D/A, DSP and Digital Receiver. State of the art today, state of the art

tomorrow.

4

13258 0303

THE BASICS

The following is intended to familiarize users with common terms and applications of Home Theater equipment.

Sources - your processor can directly provide audio from its built-in AM/FM tuner. It can also provide limited

video from its on-screen menu system. Typically you will want to connect a number of additional sources (VCR,
DVD player, etc.) to your processor. Your processor is designed to accommodate a wide range of audio and
video signals.

The following table lists the most popular home theater media and how the audio information is stored.

Source Media Analog PCM Dolby Digital DTS

Audio Cassette X
Video Cassette X
Laser disc (LD) X X X X

Compact Disc (CD)
Digital Versatile Disc (DVD)
Satellite Broadcast
Digital Audio Tape (DAT) X X X X

Digital Compact Cassette
(DCC)
Mini disc (MD)

Analog vs. Digital Audio - This refers to the method used to place audio information on the source material and

how they are delivered to your processor from the source. Analog signals exactly represent the sound you will
hear through a continuously varying voltage. Audio and video cassettes are analog recordings and are normally
delivered to your processor over a pair of coaxial audio cables.

Digital signals closely approximate the original audio signals with a set of numbers referred to as a bitstream. CDs
and DVDs are sources of digital audio and are normally connected to your processor through a coaxial or optical
digital cable. There are several different bitstream formats available. The simplest format is called Pulse Code
Modulation (PCM). In PCM, the bitstream directly represents the original 2-channel audio. In Dolby Digital and
DTS (see “Surround Formats” below) bitstreams are modified using a process called compression to squeeze
more information into limited space. DTS squeezes 5.1 channels into the space normally required for two
uncompressed channels, while Dolby Digital squeezes 5.1 channels into about ¼ the space required for two
channels. Your processor automatically detects the bitstream currently being provided from the source and
performs the required decompression and surround processing. If no digital signal is present your processor will
automatically switch to analog processing.

All sounds that you hear from your speakers are analog. Digital signals are automatically converted to analog by
your processor before being output to your the speakers.

If analog signals exactly represent the audio, while digital signals only approximate it, why would I want to
use digital?

All analog sources add some amount of noise and distortion to the audio signal. Additional noise can be
picked up through the cables from the source to your processor. It is impossible for the processor to tell
the difference between the desired signal and the added noise and distortion, so it reproduces both of
them. The result is increased background noise and decreased dynamic range and fidelity. Digital signals
are virtually immune to noise and distortion. The processor can, therefore, reproduce the signal with the
greatest possible fidelity. We recommend you use digital signals wherever possible. Also Dolby Digital
and DTS (see “Surround Formats” below) work only

Audio and Surround Formats - Your source material will be in one of seven possible formats described below.

Monaural (Mono) - This is the oldest format available. It contains a single, full range audio channel.

Modern recordings are seldom made in this format, but most older movies and music are available only in
this format. You may get mono from any source - digital or analog. Sound will normally come from the

X X X
X X X
X X

X (compressed)

X (compressed)

with digital signals.

5

13258 0303

seven speaker channels, but your processor can produce mono in one to seven channels (see “Audio
Modes under Operation”). Since all modern sources are stereo, the mono information is usually
replicated from both the left and right channels.

Stereo - Stereo contains two discrete, front left and right full range audio channels. This is the most

common format for music and is also used on many movies. You may get stereo from any source - digital
or analog. Sound will normally come from the seven speaker channels, but your processor can produce
stereo in one (mono) to seven channels (see “Audio Modes under Operation”).

Dolby Pro Logic - Dolby Pro Logic is a refinement of Dolby Surround, which was the earliest form of true

surround processing. Like Stereo, Dolby Surround contains two discrete, full range audio channels. In
addition, a monaural, limited range surround channel is encoded on the two stereo channels in a process
called matrixing. The surround channel information is encoded in positive polarity on the left channel and
in negative polarity on the right channel. The Dolby Processor can detect this encoding (left minus right)
and send that information to the surround channels. Dolby Pro Logic adds additional processing to
produce a full range center channel by extracting the mono information from the left and right channel.
This is the most common format for all but the most recent movies. Music sources are occasionally
encoded in Dolby Surround. However, many people prefer to use Pro Logic processing on all of their
stereo sources. The center channel extraction process often yields improved stereo imaging, especially
when you are sitting away from the “sweet spot” at center of the listening area. The surround channel
processing often lends a pleasing ambiance even to material that is not encoded in Dolby Surround.
Dolby Pro Logic is fully compatible with stereo and you may get it from any source - digital or analog.
Sound will normally come from all seven speakers in your system, but your processor can produce sound
in one (mono) to seven channels (see “Audio Modes under Operation”).

Dolby Digital - Dolby Digital contains up to five discrete, full range audio channels plus an additional Low

Frequency Effects (LFE) channel. The LFE channel contains only low frequency information for enhanced
sound effects in movies. This combination of five discrete channels plus a LFE channel is often referred
to as 5.1 channels. Dolby Digital is a digital format only. It must be delivered to your processor over a
coaxial or optical digital cable. As of the writing of this manual, Dolby Digital is commercially available on
DVD and Satellite (Also see Dolby Digital RF below). It is also possible to create your own Dolby Digital
CDs and DATs if you have the recording equipment. You can’t directly record Dolby Digital onto mini disc
or digital compact cassette since these devices add their own compression, which is incompatible with
the Dolby Digital compression. Not all Dolby Digital recordings will include all five channels, and, in fact, it
is common on DVDs to have two channel Dolby Digital with or without Pro Logic processing. Sound will
normally come from all seven speakers in your system, but your processor can produce sound in one
(mono) to seven channels (see “Audio Modes under Operation”).

Dolby Digital RF - Dolby Digital RF is identical to normal Dolby Digital except that it uses a special RF

encoding scheme to put the bitstream on Laser discs without replacing the normal stereo (or Dolby
Surround) PCM bitstream that is normally available from laser disc. In order to use Dolby Digital RF laser
discs you must have a B&K DT-1 RF demodulator or similar product from another manufacturer. For best
results with your processors Plug and Play capability we recommend the B&K DT-1.

Dolby Digital Surround EX - Dolby Digital Surround EX is a new movie sound track that greatly

enhances the sense of spatial and positioning of the surround channel sound. This system was
developed jointly by Lucasfilm THX and Dolby Laboratories, using Lucas film’s idea of improving spatial
expression and achieving a 360-degree sound positioning with Dolby Laboratories’ matrix encoding
technology. The surround back channel is matrix-encoded and inserted into both Dolby Digital SL
(surround left) and Dolby Digital SR (surround right) channels. Upon playback, the signals may be
decoded by a high precision digital matrix decoder within the Dolby Digital decoder into SL, SR and SB
channels.

DTS (Digital Theater Systems) - DTS is similar to Dolby Digital in that it provides 5.1 discrete audio

channels. However, it uses more digital data to encode the information and may provide greater fidelity
than Dolby Digital. DTS is a digital format only. It must be delivered to your processor over a coaxial or
optical digital cable. No RF demodulator is required for DTS laser discs since the DTS bitstream replaces
the normal PCM bitstream. Like Dolby Digital, you can create your own DTS DATs or CDs but not mini
disc or digital compact cassette. As with Dolby Digital, sound will normally come from all seven speakers

6

13258 0303

in your system, but your processor can produce sound in one (mono) to seven channels (see “Audio
Modes under Operation”).

DVD Audio (also referred to as MLP) - Meridian Lossless Packing (MLP) is a lossless coding system for

high-quality linear PCM audio. For DVD-Audio MLP performs lossless compression of up to 6 channels of
up to 24-bit material sampled at rates between 44.1kHz and 192kHz. Lossless coding does not alter the
final signal, it ‘packs’ the audio data into a smaller rate and space. Currently, DVD Audio can only be
delivered to your processor via the 6 coaxial digital inputs. The coax digital inputs may be configured
internally for use as an analog 5.1 input. Sound will normally come from all seven speakers in your
system, but your processor can produce sound in one (mono) to seven channels (see “Audio Modes
under Operation”).

Home THX Cinema Processing - THX is an exclusive set of standards and technologies established by

the world-renowned film production company, Lucasfilm Ltd. THX grew from George Lucas’ personal
desire to make your experience of the film soundtrack, in both movie and in your home theater, as faithful
as possible to whate

Cinema Processing.

ver the director intended. Currently, the Reference 20 Plus does not support Home THX

7

13258 0303

Bass Management - Dolby Digital and DTS formats contain up to 5 full range channels plus LFE. Only a system

with five full-range (large) speakers plus a subwoofer can directly reproduce these formats. However, almost all
commercially available center channel speakers are small and incapable of reproducing the lowest bass
frequencies without distortion or even damage to the speaker. Many people also use small speakers in the rear of
their system, while others use small speakers all around. Use of a subwoofer is almost mandatory when using five
small speakers, but people with at least two large speakers may or may not choose to use a subwoofer. Some
people may not use a center channel or surround speakers at all. In order to handle any possible combination of
large, small, or missing speakers, a home theater system must contain good bass management, a concept often
missing from two-piece systems where the Dolby Digital or DTS decoder is separate from the preamp. Your
processor contains a complete bass management system. You can use as few as two large front left and right
speakers or two small left and right speakers plus a subwoofer or as many as seven full range speakers plus a
subwoofer or any combination in between without missing any information. Wherever small speakers are used the
bass management system prevents low bass information from going to that speaker (“high pass”). This bass
information is rerouted to a speaker that can handle it, usually a subwoofer, but it can also send center, surround,
or LFE bass to large front speakers if no subwoofer is available. When center or surround speakers are not used
at all, the missing channel is sent (“down mixed”) to the front speakers.

Preamp - A preamp typically includes the capability to select from a number of sources, adjust volume levels and

route the data to an amplifier. Your processor includes a high quality preamp.

Processor - A processor typically includes the capability to decode one or more surround formats, and convert

between digital and analog as required. Your A/V system controller includes a high quality processor capable of
decoding the surround formats described above.

Zone - A zone is usually a room that has speakers installed in it. Your processor includes a full preamp/processor

for Zone 1 (A) plus an additional analog stereo preamp for Zone 2 (B). This allows, for example, watching a Dolby
Digital movie in zone one while simultaneously using the built-in AM/FM tuner in another room.

Amplifier - An amplifier takes the output of a preamp/processor and increases its level to that necessary to drive

a speaker.

Speakers - A surround sound system use to typically use 5 speakers located left front, center front, right front,

right surround, and left surround plus a subwoofer located anywhere in the room. With the new developments in
surround technology from companies such as Dolby Laboratories, DTS, and Lucasfilm, it is now possible to
improve spatial expressions with an additional channel of information for use with a 6th and/or 7th surround back
speaker. Although best results are achieved using seven large speakers plus a subwoofer, this is not always
practical. Excellent results can be achieved using small and/or fewer speakers, as long as you go through the set
up procedures described later in the manual. Your processor includes the capability of reproducing up to 6.1
channels of surround information.

Component video vs. S-video vs. Composite video - Composite video is the oldest standard for color video. It

combines the luminance (brightness or black-and-white) and chrominance (color) information onto a single
conductor. These signals must be separated again for display resulting in some degradation of the video quality.
S-video is a newer standard that uses separate conductors for the luminance (Y) and chrominance (C)
information resulting in better video quality. Component video is the newest form of video introduced with DVD.
This video format uses separate conductors for luminance (Y), red - luminance (R - Y), and blue - luminance (B ­Y). Using these signals a component video capable monitor allows for even better and higher resolution video
quality. Your processor is capable of switching composite and S-video with no support of component video
signals. Also, you unit cannot convert between video types.

8

13258 0303

FRONT PANEL

1. Headphone Jack - Stereo headphones having a standard ¼ inch binaural plug can be connected to the

headphone output. The processor must be on and in HEADPHONE Mode for proper headphone operation.

2. Front panel buttons

SLEEP

PRESET

ENTER

MENU

DOW N UP

SOURCE

MODE

SAVE

Puts the receiver in standby (low power) mode.

Steps through audio / video presets for instant recall of setups.
Pressing ENTER recalls the preset.

Confirm selection or display current status of the receiver.

Enter / exit menu system

Step through menus, sources, or audio modes.

Steps through the audio / video sources.

Steps through the audio modes.

Pressing SAVE followed by ENTER saves a favorite preset

3. Main power switch - Removes all power to the processor. Normal operation of the processor requires the
power switch to remain on. Use the Sleep button for daily on and off of the processor. It places the unit in standby
mode that allows turning back on with the remote control. Turn the processor off with the main power switch when
not using the processor for an extended period of time.

4. Volume control - For controlling system volume. Turning the jog-shuttle type volume control clockwise
increases the volume level, counterclockwise decreases the volume level. The volume knob is also used to
change other processor settings. See THE MENU SYSTEM and OPERATION

9

13258 0303

5. Status indicators - Displays current status of the processors audio processor. Indicators have been supplied
to show when the DSP is decoding Dolby Digital ‘2 Digital’, Dolby Pro Logic ‘2 Pro Logic’, or DTS audio.
There is an indicator to show the input to the S/PDIF digital receiver is 96kHz 24 bit data ‘96/24’ or an analog
input that is being sampled using 96kHz/24bits. Finally, there is an indicator to show processed audio is sourced
from the selected analog input ‘Analog’. See MODE OPERATION

6. Display - The processor display is a 16 character alphanumeric fluorescent display. Displays current status of
processor and any changes being performed.

10

13258 0303

REAR PANEL

The processor’s back panel is organized into groups of inputs and outputs for audio and video as shown below.
See back of this manual for an enlarged view.

1. AC fuse holder - Holds the AC Line fuse. Replace only with same type and value.

2. AC input receptacle - For attaching the supplied AC power cord to the processor.

3. RS-232 input - Computer interface applications.

4. Zone 1 (A) and Zone 2 (B) audio outputs - Variable level outputs to your external amplifiers.

5. Serial Number location

6. Antenna inputs - Connections for the AM and FM antennas.

7. Line inputs - Connections from your audio/video sources.

Red RCA jacks - right analog audio
White RCA jacks - left analog audio
Yellow RCA jacks - composite video
4 pin din jacks - S-video

8. Line level A/V outputs – Switched fixed level A/V outputs to an audio or video recorder.

9. Zone 1 (A) and Zone 2 (B) video outputs - Outputs to your video monitors.

10. IR in - Accepts input from external IR receptors. Connect an IR repeater (“home run”) to IR IN for controlling

the processor. This method of control is useful when the front IR receptor is blocked (for example, by a cabinet
door) or to control the processor from another room. This input is typically used in place of an emitter attached to
the front panel.

11. Control outs - Outputs that allow you to remotely control external devices. (See “Making The Connection“).

12. Optical and Coax Digital output - Zone 1 (A) optical and 1/8” mini-plug coax output to carry digital

information from the selected digital input of the processor out to digital recorders, personal computers, etc.

13. Surround outputs - Variable level outputs for driving external power amplifiers or powered speakers.

14. Optical Digital inputs - Optical digital inputs are used to connect digital audio signals from your source to the

processor. The incoming signal may be PCM, Dolby Digital or DTS.

11

13258 0303

15. Coax Digital inputs - Coax digital inputs are used to connect digital audio signals from your source to the
receiver. The incoming signal may be PCM, Dolby Digital (AC-3) or DTS.

(Optional)
DVD Audio inputs – Optional connections for a DVD audio or other 5.1 source device.

Center (TV-V3) RCA jacks - center front surround audio inputs
Sub (SAT) RCA jacks - sub audio inputs
Ls ( V2) RCA jacks - left rear surround audio inputs
Rs (CD) RCA jacks - right rear surround audio inputs
Lf ( V1) RCA jacks - left front surround audio inputs
Rf ( DVD/VLD) RCA jacks - right front surround audio inputs

12

13258 0303

MAKING THE CONNECTION

It’s tempting to just plug in your new A/V processor and have great sound pour out. Before you do that, take a few
minutes to plan out how you want the processor to fit into your audio/video system. Ask yourself the following
questions:

y What source components do I want to connect to my processor? (CD, VCR, etc.)

y What equipment will be receiving the audio and video? (TV monitor, Speakers, etc.)

The answers to your questions determine how many cables you need to connect to the back of the processor.
Good preplanning equals great sound. Keep these recommendations in mind:

y List all components in your system and indicate which jacks of the processor each component will be

connected to. Your processor has seven sets of inputs. It is convenient to connect a DVD player to the input
labeled DVD or a VCR to the input labeled V1 or TAPE, etc. However, your equipment may differ from the
labeling on the back of your processor. In most cases you can connect any type of source to any input (see
FREQUENTLY ASKED QUESTIONS). For example, if you don’t have a satellite receiver you can connect a
DAT player or a second cassette deck to SAT. You can also reprogram the source name that will appear on
your processor’s front panel and on-screen display (see SYSTEM SETUP - INPUTS)

y Also note the length of the cable for each component’s connection and describe how it should be routed or

draw your routing scheme below your list. You may want to label each cable with a name or number at both
ends. Use high quality connections to maintain high quality audio and video.

y Think about the type and length of cable you need and obstacles in the cable’s path (doorways, furniture,

walkways, etc.). To decide which ones are right for you talk to your dealer about the various cable products
that are available.

y For safety, keep all cables out of high traffic areas (hallways or doorways) and away from equipment that

radiates power, including amplifiers, power cords, heaters, etc.

y If you might expand your audio/video system later, keep these ideas in mind as you plan current cable runs.

y To provide the best tuner reception, make sure the antenna is at least several feet away from the processor

and any other equipment that may produce high frequency interference such as Personal computers, CD
players, halogen lamps, etc.

Take a look at the back panel of the processor. You will notice that the RCA-type audio input and output
connectors are identified by colors, red for right channel and white for the left channel audio. Composite video
input and output connectors are identified by yellow. Coaxial digital inputs are identified by orange. The surround
outputs are the Black connectors.

13

13258 0303

AUDIO / VIDEO CONNECTIONS

Connecting your analog sources to your processor

Audio / Video source - connecting a DVD/VLD player to the processor’s analog inputs. Use the same

instructions for connecting to other audio / video sources such as a television, satellite receiver, cable box, etc.
See Connecting Video for use with other than composite and S-video (Omit the video connections for an audio­only component such as a CD player)

Attach one end of the audio interconnect cable to the left audio
output on the DVD/VLD player, then attach the other end to the
left (white) DVD/VLD audio input on the processor. Repeat for
the right (red) audio connection. Attach one end of the
composite video interconnect cable to the video out on the
DVD/VLD player, then attach the other end to the yellow video
input on the processor labeled DVD/VLD. Repeat for the S­video connections if you are using S-video.

DVD

S-Video input
from DVD output

Composite video input
from DVD output

Left audio input from
DVD output

Right audio input from
DVD output

ZA

S-Video output
to m onitor input

Composite video output
to monitor input

Video Monitor - Attach one end of the composite video

LINE INPUTS

interconnect cable to the video input on the monitor, then attach
the other end to the yellow video output on the processor’s
ZONE OUTPUTS. Repeat for the S-video connections if you are

ZONE OUTPUTS

using S-video. Dual zone operation requires connections be
made to (ZA) for Zone 1, and (ZB) for Zone 2.

VCR or audio recorder - connect a VCR to V1 . Use the same instructions for connecting to the V2 and TAPE
analog inputs. If connecting a cassette deck or other audio-only recorder then omit the video connections.

V1

S-Video output
to VCR input

Composite video output
to VCR input

Left audio output
to VCR input

Right audio output
to VCR input

V1

S-Video input
from VCR output

Composite video input
from VCR output

Left audio input
from VCR output

Right audio input
from VCR output

LINE OUTPUTS

LINE INPUTS

Attach one end of the audio interconnect cable to the left audio output on the VCR, then attach the other end to
the left (white) V1 audio input on the processor. Repeat for the right (red) audio connection. Attach one end of the
composite video interconnect cable to the composite video output on the VCR, then attach the other end to the
yellow video input on the processor labeled V1. Repeat for the S-video connections if you are using S-video.

Attach one end of the audio interconnect cable to the left audio input on the VCR, then attach the other end to the
left (white) V1 audio output on the processor. Repeat for the right (red) audio connection. Attach one end of the
composite video interconnect cable to the composite video input on the VCR, then attach the other end to the
yellow video output on the processor labeled V1. Repeat for the S-video connections if you are using S-video.

14

13258 0303

DVD Audio using the Coax digital inputs (optional) – your processor allows for an option to connect a 5.1
DVD Audio or other 5.1 surround format device, to the processor’s DVD Audio input when NO coax digital inputs
are to be used. This option calls for the setting of a push button switch internal to the unit. Please contact

B&K customer service for further details if this option is desired.

Attach one end of an audio interconnect cable to the center output on the DVD Audio source device, then attach
the other end to the Center (TV-V3) DVD Audio input on the processor. Repeat for the Left surround (V2) and Left
front (V1) audio connection. Attach one end of an audio interconnect cable to the sub output on the DVD Audio
source device, then attach the other end to the SUB (SAT) DVD Audio input on the processor. Repeat for the
Right surround (CD) and Right front (DVD/VLD) audio connection.

Connect to the DVD audio
player Left Surround output

(TV-V3) (V2) (V1)

Connect to the DVD audio
player Center output

Connect to the DVD audio
player Subwoofer output

CENTER

SUB

(SAT) (CD) (DVD/VLD)

Ls

Rs

Lf

Connect to the DVD audio
player Left Front output

Connect to the DVD audio
player Right Front output

Rf

Connect to the DVD audio
player Right Surround output

15

13258 0303

DIGITAL CONNECTIONS

Connect digital inputs (DVD, VLD, etc.) to the processor. You will need either coaxial or optical digital inputs to
play Dolby Digital (AC-3) or DTS surround sound processing. Digital connections are also recommended for PCM
sources. If your source has both optical and coaxial
outputs connect only one.

Coaxial digital inputs - standard RCA type connectors.
Attach one end of your digital coaxial cable to your source
coaxial digital out and the other end to the appropriate
processor coaxial digital (orange) input.

Optical digital inputs - First, remove the cap on
the optical digital input. Save the cap. Attach one
end of your digital optical cable to your source and
the other end to the appropriate digital input on the
back of the processor.

DT-1

COAX DIGITAL

TV V2 V1

MAIN

OUTPUT

SAT DVDCD

Coax digital input

from VLD output

AC-3 RF input

from VLD output

automatically. Connect the laser disc’s AC3-RF output to the DT-1’s AC-3 RF input. Connect either the laser disc
player’s PCM coaxial or optical digital output (not both) to the DT-1’s coaxial or optical input. Connect the DT-1’s
coaxial output to the desired coaxial digital input on your processor.

Digital Outputs - Separate
and independent coax digital
outputs are available for
Zone 1 (A) and Zone 2 (B).
Connect to a digital recorder

OPTICAL DIGITAL INPUTS

(CD-R, mini disc, DAT,
personal computer, etc.)
These signals are the same
as the incoming digital signal
from the selected source on
each zone. If your digital
recorder has both optical and
coaxial inputs you need only
connect one. Zone 1 (A)
selected digital input is
converted to both coaxial and
optical. You may connect one
digital recorder to the optical
output and another recorder to
the coaxial output.

COAX
INPUT

AC-3 RF

INPUT

V2DVDCDSAT

V1

COAX INPUT

COAX DIGITAL INPUTS

TV-V 3 V 2 V 1

Coax digital input

SAT DVDCD

OPTICAL DIGITAL

V2DVDCDSAT

V1

from DVD output

Optical digital output
from source

Connecting A Laser disc Player - Dolby Digital
(AC-3) laser discs use a special technique called AC­3 RF to encode the Dolby Digital bitstream. If the
laser disc player is capable of playing back Dolby
Digital discs it will have a separate output for this
bitstream in addition to the normal coaxial and/or
optical outputs. Do not connect the AC3-RF output
directly to your processor. The AC-3 RF bitstream
must first be converted to a normal (non-RF) Dolby
Digital type signal. It is recommended that a B&K
DT-1 be used to convert and select between the
Laser’s AC-3 RF and PCM/DTS signals. The output
from a DT-1 will automatically select between the
connected PCM/DTS bitstreams and the converted
AC-3 RF Dolby Digital signal. Other AC-3 RF to
Dolby Digital decoders may not make this switch

DIGITAL OUTPUTS

OPTICAL 3.5mm COAX

V3

3.5mm

Zone 1 (A) Coax digital
output to digital recorder

Zone 1 (A) Optical digital
output to digital recorder

16

13258 0303

SURROUND OUTPUTS

Your processor has multiple surround processor outputs for use with external amplifier(s) or powered speakers.
The Reference 20 Plus processor allows further processing of the surround channels for the precise decoding of
Dolby Digital Surround EX and DTS-ES soundtracks via matrix decoding.

Here is a typical processor surround output setup

:

Connect to the Surround Back Right
'Sbr' power amplifier input

Connect to the Center power
amplifier input

Connect to the Subwoofer 'SW'
power amplifier input

Connect to the Surround Back Left
'Sbl' power amplifier input

SURROUND OUTPUTS

CENTER

SUB R BACK R SURR FRONT R

L BACK L SURR FRONT L

Connect to the Surround Left
'Sl' power amplifier input

Connect to the Left Front
power amplifier input

Connect to the Right Front
power amplifier input

Connect to the Surround Right
'Sr' power amplifier input

Subwoofer Output - Connect an RCA cable from the processor’s SW output (part of the surround outputs). If
your subwoofer does not contain its own amplifier you will need to purchase an external B&K or other power
amplifier. Connect the processor’s SW output to the audio input of the external amplifier. Connect the external
amplifier’s speaker output to your subwoofer.

17

13258 0303

SURROUND SPEAKER OUTPUT CONNECTIONS

Connect the A/V System Controller’s surround outputs to your external amplifier(s) or powered speakers as
described previously. Connect your speakers to your external amplifier(s) as shown below.

L

FRONT

LEFT

(-) (+)

SURROUND LEFT SURROUND RIGHT

PLUS

MINUS

PLUS

MINUS

Sl

(-) (+)

CENTER

MINUS

(-) (+)

SURROUND BACK

PLUS

C

CENTER

LEFT

MINUS

PLUS

SURROUND BACK

RIGHT

PLUS

MINUS

R

FRONT

RIGHT

(-) (+)

FRONT LEFT FRONT RIGHT

PLUS

MINUS

PLUS

MINUS

Sr

(-) (+)

SURROUND

LEFT

Sbl

(-) (+)

SURROUND

BACK LEFT

18

Sbr

(-) (+)

SURROUND

RIGHT

SURROUND

BACK RIGHT

13258 0303

ANTENNA CONNECTIONS

The FM jack is a standard screw on F-type
connector. The AM is a push type. Strip ¼ inch of
insulation off your AM antenna wires and insert one
wire end into each hole while holding the tabs down.

TUNER

FM antenna

FM Antenna Input
from Indoor/Outdoor Antenna,
Cable Box, etc.

Release the tabs to lock in the AM antenna wires.

CONTROL OUTPUTS / IR INPUTS

AM antenna

AM Antenna Input
from Loop Antenna

CONTROL OUT

12

+12VDC

50mA

IR IN

ZA

CAUTION!

Control Outputs - These connections are used for

controlling other equipment such as an external B&K
Components, Ltd. amplifier, projection screen, etc.
Connect your control cable to the processor using a

3.5 mm control output
to am plifier, etc.

34

3.5 mm IR in
from remote repeater

ZB

mono 3.5 mm jack shown at left. The plug must be
wired as tip (+) and the long barrel section (-).

The Control outputs are programmable for each source in your system (see “Advanced Setup”). However, the
processor provides the following factory preprogrammed setup that should serve for most standard system
applications.

Control 1 - HEADPHONE - On (+12 VDC) when Zone 1 (A) is on and not in Headphone mode, off when Zone 1
(A) is off or in Headphone Mode. This mode may be used for controlling external amplifiers or powered
subwoofers in Zone 1 (A).

Control 2 - Zone 2 (B). On (+12 VDC) when Zone 2 (B) is on, off (0 VDC) when Zone 2 (B) is off. This mode is
used for controlling external amplifiers, projection screens, etc. in Zone 2 (B).

Control 3 - Z1 + Z2. On (+12 VDC) when Zone 1 (A), Zone 2 (B), or both zones are turned on. Off (0 VDC) when
both zones are off.

Control 4 -REMOTE. It will repeat a received 38 kHz modulated IR signal. The processor will transmit received IR
signals even in sleep mode.

Note - The control outputs can output a maximum of 50 mA. Check to see that the source you are connecting to
the control out requires 50 mA or less current.

WARNING - Not all manufacturers adhere to the +12 VDC control specification. Check to see if your
sources control inputs are +12 VDC compatible. Do not connect your processor’s control outputs to a
source with control or remote inputs rated at +5 VDC or other voltage rating. Damage to your source may
result.

IR Inputs - Your processor can be controlled by a directly connected IR repeater system in combination with or in

place of the supplied remote control. Connect your IR input cable to the processor using a mono 3.5 mm jack
shown above. The plug must be wired as tip (+) and the long barrel section (-). The inputs are standard 38kHz
modulated IR type with a voltage range of +5 to +12 VDC.

19

13258 0303

FREQUENTLY ASKED QUESTIONS

My collection of equipment differs from the labels on the back of my processor, how can I hook them up?

Your processor provides 5 identical sets of inputs - V1, V2, DVD, CD, and SAT. Each of these has analog
audio, composite video, S-video, coaxial digital audio, and optical digital audio. It is convenient to connect
components as labeled on the back of your processor, but since all the inputs are identical, you can connect any
compatible source to any set of inputs. For example, you can connect a DAT player to V1 instead of a VCR. You
can program your processor to display any 5-character name for any input (see System Setup - Inputs).

The sixth input, TV, is identical to the others except that there is no optical digital. You can also connect
portables to any other coaxial digital input using adapters or special cables. If you have a source with only optical
digital output don’t connect it to TV.

The seventh input, TAPE, has analog audio, composite video and S-video, but has no digital inputs. It is
primarily intended for analog recorders such as VCRs or cassette decks. If you have a three-head cassette or
reel-to-reel tape deck you will prefer the TAPE input since it allows a full tape monitor capability. Tape monitor
allows you to listen to what is actually on the tape as you are recording it. The V2 input also provides full tape
monitor capabilities for Zone 2 (B). If you don’t use Zone 2 (B) you can use V2 as a second independent analog
tape monitor loop. V1 includes a line level output but does not provide true tape monitor capability.

My DVD player (or other source) has both optical and coaxial digital outputs. Should I connect both?

No, connect only one digital cable per source.

Do I need an AC-3 RF demodulator (B&K DT-1 or equivalent) to playback Dolby Digital
DVDs?

No, this is required only for Dolby Digital laser discs.

Do I need an AC-3 RF demodulator (B&K DT-1 or equivalent) to playback DTS laser discs?

No, this is required only for Dolby Digital laser discs.

Do I need to connect both analog and digital audio from my DVD player (or other digital audio source) to
the processor?

In general, it is simpler to connect both. However, if you can meet all of the following criteria you need
only connect digital:

1. I do not use Zone 2 (B). (Zone 2 (B) is analog only - if you use Zone 2 (B) you must connect both left and
right analog to hear audio.)

2. I do not own any old laser discs. (Early laser discs contained only analog audio tracks - you must connect
both left and right analog audio to play these back.)

3. I do not use Tape Monitor. (It is possible to tape digital-only sources. However, if you wish to listen
directly to the tape as you are recording - you must connect both left and right analog audio - the tape monitor
loops are strictly analog.)

If the tape monitor loop is strictly analog, how do I make an analog recording of a digital-only source?

Do not select TAPE. Select the source you wish to record. Select STEREO 9, the LtRt mode. If that
source is digital, the converted digital-to-analog will appear at the tape and V1 outputs. V2 out, like Zone 2 (B)
out, is analog only. (See also Operation - Zone 1 Operation - Mode.)

I want to make direct digital recordings from my CD player (or other digital source) on my CD Recorder,
DAT (or other digital recorder). Can my processor make this connection for me?

Yes, your processor’s digital outputs act much like the analog tape outputs. When you select a source, if

that source has a digital connection to your processor, then that digital signal will appear on the processor’s
coaxial and optical digital outputs. Simply connect all of your sources digital outputs to your processors digital
inputs. You can then connect up to three digital recorder inputs to your processor’s three digital outputs.

20

13258 0303

My laser disc player (or other digital source) has only optical output, but my CD recorder (or other digital
recorder) has only coaxial input. Do I need some sort of converter to make direct digital recordings?

No, your processor will convert optical to coaxial and coaxial to optical. The currently selected digital input
(optical or coaxial) will appear at both of the processor’s digital outputs (optical and coaxial).

Do I need to connect both analog and digital audio from my processor to my CD, DAT, MD, recorder,
etc.?

In general, yes. If all of the sources you wish to record are digital, then you need only connect digital to
your recorder. However, your processor does not provide digital outputs for non-digital inputs. If you wish make a
digital recording from an analog-only source you must also connect analog from your processor (Tape or V1 out)
to your recorder.

Can I connect a phonograph directly to my processor?

No, you will need a separate outboard phono preamplifier. The output of the phono preamp can then be
connected to any analog input on your processor. We recommend our Phono 10 phono preamp. In addition to it’s
superb analog audio processing, it has an option for S/PDIF coax output. Talk to the dealer where you purchased
your processor.

Do I need to connect both S-video and composite video to my processor?

If all of your video equipment has S-video then you need only connect S-video. S-video is a higher quality
video format and you will probably not want to use composite. If all or most of your video equipment is composite
then it is simplest to just connect the composite and omit S-video.

Can I connect mixed composite and S-video sources?

Yes, but your processor will not convert S-video to composite or composite to S-video. If your monitors
and VCRs accept only composite video then there is no point in connecting S-video from other sources. If you use
mixed S-video and composite sources you must connect both

S-video and composite to your monitors and VCRs.
You will need to change your monitor or VCR S-video / composite inputs manually when you change sources.
This can normally be done via the monitor’s or VCR’s remote control (or the supplied universal remote). Some
monitors or VCRs may require you to physically disconnect S-video before they will accept composite video.
Some monitors are capable of automatic switching between S-video and composite. Your processor must be
setup properly in order to work with auto switching monitors - refer Setup Displays.

To assist you, the processor’s on-screen display will tell you what video is currently selected whenever
you change sources or hit the SEL (remote) or ENTER (remote or front panel) key, but it cannot switch your
monitor or VCR input for you. If you are watching S-video, but the source is composite video only, you will see

“Switch Monitor to Composite” on your Monitor. If you are watching Composite video but your source is S-video
only, you will see “Switch Monitor to S-video” on your monitor. These displays appear only if your processor is
setup for manual monitors.

Can I connect mixed composite and S-video monitors and VCRs?

Yes, but you must connect both S-video and composite from all of your sources - your processor will not
convert between S-video and composite. Refer to the previous question if not all of your sources have both S­video and composite outputs.

For example, it is common to have an S-video monitor and a composite VCR. Connect the monitor to the
Zone 1 (A) S-video and composite outputs and the VCR to the V1 or TAPE composite output. The composite
inputs will appear at the composite outputs for TAPE and V1. (The S-video inputs also appear at the TAPE and
V1 S-video outputs, but, in this example, they are not connected.) To prevent feedback, TAPE IN will not appear
on TAPE OUT and V1 IN will not appear on V1 OUT - this also applies to the audio outputs. Zone 2 (B) works the
same for Zone 2 (B) OUT and V2 OUT with feedback prevention on V2.

Things get a bit more complicated for the Zone 1 (A) output because it contains your processor’s internal
on-screen display system. You must be sure that you tell your processor if you have a monitor which can
automatically switch between S-video and composite outputs, or one which must be manually switched (see
Setup Displays)

21

13258 0303

SETUP

For best results, perform the following set up procedure when you initially install your processor and anytime you
change or add sources, speakers, etc. or when you rearrange your listening area

THE MENU SYSTEM

Setup of your processor will require you to navigate through the menu system. We recommend that you use a
video monitor connected to the Zone 1 (A) output along with the remote control provided with your processor. It is
also possible to set up your processor from the front panel. Do not leave your video monitor on with the processor
in the menu system for long periods of time. This can result in permanently burning the menu display into your
monitor’s screen. This would take several hours so there is no danger of it happening during normal setup
procedures. The following are general instructions for using the menu system. A complete guide to the menu
system is included at the back of this manual.

MENU - If you are not already in the menu system, the MENU button will activate the menu system. Once you are
in the menu system, the MENU button will return you to the next higher-level menu or, if you are already at the
highest level, it will exit from the menu system.

UP/DOWN ARROWS - Once you are in the menu system, use the UP/DOWN ARROWS to move to the desired
menu selection. The currently active menu line is highlighted in a contrasting color.

SEL (remote) or ENTER (remote or front panel) - Some menu selections cause another menu to be activated.
Use the UP/DOWN ARROWS to move to the desired menu line. Pressing SEL or ENTER will activate the next
menu.

NUMERIC KEYS (remote only) - From the remote control you may also go directly to a menu line by typing the
corresponding line number. If there is another menu below that line it will be activated immediately (no ENTER
required).

LEFT/RIGHT ARROWS (remote) or VOLUME KNOB (front panel) - Some menu selections allow you to change
one of the processor settings. Use the UP/DOWN ARROWS to move to the desired menu line. Pressing the
LEFT/RIGHT ARROWS will change the setting. There are no LEFT/RIGHT ARROWS on the front panel. While in
the menu system, the VOLUME KNOB acts as the LEFT/RIGHT ARROWS. This means that you will not be able
to adjust the volume from the front panel while in the menu system. The remote control volume will work in most
menus.

TEXT EDITING - some menu selections will require you to edit text. Use the UP/DOWN ARROWS to change the
current (blinking) character. Use the LEFT/RIGHT ARROWS (or VOLUME KNOB) to move to another character
position.

EXIT (remote only) - From the remote control you may instantly EXIT the menu system.

UNIVERSAL REMOTE - Remember that when you press a source button (DVD, CD, etc.) the remote now
controls the selected device. To return control to your processor, you must press B&K or AUDIO. ALWAYS
check that your remote is set to B&K or (AUDIO) before attempting to control your processor. B&K or
(AUDIO) will be displayed in the remote’s LCD window.

22

13258 0303

SYSTEM SETUP

You should always perform System Setup after first installing your processor and after adding/changing speakers
or sources or rearranging your listening area. Check that the remote is in B&K mode.

From Remote From Front Panel Action

1 B&K or POWER e SLEEP turn on processor
2 MENU

3

À(PAUSE) or §(STOP) . (UP) or - (DOWN)

4 SEL or ENTER

∠ MENU

↵ (ENTER)

activate menu system

move to System Setup
activate SETUP SYSTEM

MAIN MENU
1 Zone 1 Operation
2 Zone 2 Operation
3 Zone 1 Favorite Presets
4 Zone 2 Favorite Presets

5 System Setup

5 System Setup
6 Memory Backup/Restore

next item SEL select
MENU exit menu system

SETUP SYSTEM

1 Speakers

1 Speakers
2 Displays
3 Inputs
4 Presets

next item SEL select
MENU main menu

SETUP SPEAKERSSYSTEM SETUP

From Remote From Front Panel Action

1

À(PAUSE) or §(STOP) . (UP) or - (DOWN)

2 SEL or ENTER

↵ (ENTER)

move to Speakers
activate SETUP SPEAKERS

Speakers

The speakers menu lets you tell your processor how many speakers you have in your system, the relative size of
the speakers, and their location in the room. This is the most important setup procedure you will perform. The
processor comes from the factory setup for 7 small speakers and a subwoofer. If this does not match your
speakers then audio information will be lost. For example, if you do not currently have a center channel speaker
and you do not perform this setup procedure, the center channel information will be lost. If you perform this setup
correctly, the processor will know that you have no center channel speaker and send this information to your front
left and right speakers (along with the normal front left and right information) so no audio information is lost.

Speaker Size

Speaker size generally refers to the size of your speakers. Audio material, particularly Dolby Digital and DTS
movies, often contain large amounts of bass. If this bass information is sent to small speakers that are incapable
of reproducing so much bass, then the bass information will be lost or distorted. MANY SMALL SPEAKERS MAY
BE DAMAGED BY TOO MUCH BASS. By telling your processor the size of your speakers, it will be able to
intelligently route the bass to speakers that can reproduce it correctly. Typically, all bookshelf or satellite speakers
are considered small. Smaller floor standing speakers with single woofers 8” or less should also be considered
small. Floor standing speakers with 10” or larger woofers or multiple smaller woofers may be considered large.
These are general guidelines only - if you are unsure consult your speaker manufacturer or check with the dealer
if they are unsure. If you have all small speakers we strongly recommend use of a subwoofer. If your front left and
right speakers (or more) are large then you may not require a subwoofer, but you may still get better results using
a subwoofer, especially with Dolby Digital and DTS movies. All THX certified speakers are small, regardless of
their physical size, and should be used in audio systems along with a subwoofer.

23

13258 0303
