Bally Refrigerated Boxes BESA005L6-HS2 User Manual

BES-Line

10/22/12

Condensing Units

PRODUCT DATA &
SPECIFICATIONS

Bulletin B40-BES-PDS-60-9

1087392

Latest product updates and further information
at www.ballyrefboxes.com

Indoor/Outdoor
Air-Cooled Semi-Hermetic
Condensing Units

1/2 to 22 HP -
High, Medium and Low
Temperature Refrigeration

Indoor Unit Outdoor Unit

CONTENTS

Page

Nomenclature.......................................................................................................................

Features.............................................................................................................................

Capacity Data (Imperial and Metric)...................................................................................

Electrical Data....................................................................................................................

Dimensional Data...............................................................................................................

Specications.....................................................................................................................

Wiring Diagrams.................................................................................................................

EC Motor Application..........................................................................................................

EC Motor Electrical Data....................................................................................................

EC Motor Wiring Diagrams................................................................................................

Generic Service Parts List..................................................................................................

Warranty.............................................................................................................................

2

2 - 3

4 - 25
26 - 29
30 - 35
36 - 37
38 - 42
43 - 45
46 - 47
48 - 49
50 - 51

53

Project Information.............................................................................................................

“As Built” Service Parts List................................................................................................

53

BACK

Model Name

10/22/12

B40-BES-PDS-60-9

- 2 -

B = Bally

Model Series
ES = Excel Semi-Hermetic Air Cooled

Condensing Unit Line

Compressor Manufacturer

A = Copeland
B = Bitzer

Nominal HP

005 - 220 = 1/2 - 22 HP

Application Range

H = High and Med Temp
M = Med Temp
E = Extended Medium T emperature
L = Low Temp

Refrigerant*

2 = R22, 6 = R404A / R507
8 = R404A / R507, R22, R407C

Enclosure

H = Outdoor
I = Indoor

Voltage*

S2 = 208/230-1-60 S3 = 230-1-60
S6 = 200/220-1-50 S7 = 200-1-50
T3 = 208/230-3-60 T4 = 460-3-60
T5 = 575-3-60 T7 = 200/220-3-50
T9 = 380/400-3-50

NOMENCLATURE

B ES A 075 H 8 - H T4 B - A

Optional Feature Packages (Factory Mounted)

A = Standard Features (see below)
B = Standard Features (see below)
Plus Sealed Liquid Line Filter Drier and Sight Glass
C = Standard Features (see below)
Plus Sealed Liquid Line Filter Drier and Sight Glass
Plus Suction Accumulator
Plus Electric Defrost Kit
D = Standard Features (see below)
Plus Sealed Liquid Line Filter Drier and Sight Glass
Plus Heated and Insulated Receiver
E = Standard Features (see below)
Plus Sealed Liquid Line Filter Drier and Sight Glass
Plus Heated and Insulated Receiver
Plus Suction Accumulator
Plus Electric Defrost Kit
F = Standard Features (see below)
Plus Sealed liquid line lter drier and sight glass
Plus Electric Defrost Kit
G = Standard Features (see below)
Plus Sealed liquid line lter drier and sight glass
Plus Electric Defrost Kit
Plus Heated and insulated receiver
H = Standard Features (see below)
Plus Sealed Liquid Line Filter Drier and Sight Glass
Plus Timeclock
J = Standard Features (see below)
Plus Sealed Liquid Line Filter Drier and Sight Glass
Plus Heated and insulated receiver
Plus Suction Accumulator

Series

B = Latest Catalog spec (2nd generation)

* subject to compressor availability

STANDARD FEATURES

Indoor Unit:

• Weatherproof electrical control box with
compressor contactor and fused control circuit

• Spring mounted accessible semi-hermetic
compressor with suction and discharge vibration
eliminator

• High efciency enhanced tube and n condenser

design

• Energy efcient PSC condenser fan motor

• Receiver with fusible plug and liquid shut off

valve

• Fixed high and adjustable low pressure control

• Sentronic oil failure switch (where applicable)

• Receiver inlet and outlet shutoff valve (8HP and

above)

• Suction service valve

• Pre-formed copper tubing

• Unit leak tested and shipped with Helium holding

charge

Outdoor Unit: All Standard Features of
Indoor Unit, Plus:

• Outdoor weather-resistant housing with
removable hood

• Flooded head pressure control (non
adjustable)

• Adjustable head pressure control on large 2 fan
models

• Crankcase heater

• Fan cycling control (all 2 fan models)

OPTIONAL FEATURE PACKAGES (Factory Mounted)

10/22/12

B40-BES-PDS-60-9

- 3 -

Package A:

• Standard Features (see pg. 2)

Package B:

• Standard Features (see pg. 2)

• Plus Sealed Liquid Line Filter Drier & Sight Glass
Package C:

• Standard Features (see pg. 2)

• Plus Sealed Liquid Line Filter Drier & Sight Glass

• Plus Suction Accumulator

• Plus Electric Defrost Kit
Package D:

• Standard Features (see pg. 2)

• Plus Sealed Liquid Line Filter Drier & Sight Glass

• Plus Heated and Insulated Receiver
Package E:

• Standard Features (see pg. 2)

• Plus Sealed Liquid Line Filter Drier & Sight Glass

• Plus Heated and Insulated Receiver

• Plus Suction Accumulator

• Plus Electric Defrost Kit

Package F:

• Standard Features (see pg. 2)

• Plus Sealed liquid line lter drier and sight glass

• Plus Electric Defrost Kit

Package G:

• Standard Features (see pg. 2)

• Plus Sealed liquid line lter drier and sight glass

• Plus Electric Defrost Kit

• Plus Heated and insulated receiver

Package H:

• Standard Features (see pg. 2)

• Plus Sealed Liquid Line Filter Drier and Sight

Glass

• Plus Timeclock

Package J:

• Standard Features (see pg. 2)

• Plus Sealed Liquid Line Filter Drier and Sight

Glass

• Plus Heated and insulated receiver

• Plus Suction Accumulator

OPTIONAL FEATURES (Factory Mounted)

•· Suction accumulator

• Suction accumulator with boil-out coil

• Discharge line Check valve

• Oil separator

• Oil separator c/w oil return lter & solenoid

valve

• Adjustable head pressure control valves

• Receiver inlet ball valve (standard on 2 fan

models)

• Heated and Insulated receiver

• Over-sized receiver

• Sealed liquid line lter drier & sight-glass

• Ball valve - liquid line (shipped loose)

• Insulated suction lines

• Leg Kits

• Discharge air hood

• Sub cooling circuit on 5 - 22 HP models

• Variable speed EC motors

(replaces ooded valve)

• Liquid line solenoid valve-(with standard

230 volt coil)-shipped loose

• Compressor Circuit breaker

• Current sensing relay - for use with Oil

safety control (where applicable)

• Defrost heater contactor c/w fuse block

• Evaporator Fan contactor c/w fuse block

• Disconnect switch

• Disconnect Fusing

• Pump down toggle switch

• Lock out control circuit

• Hoffmann Speed control for condenser fan

(replaces ooded valve)

• Time delay relay for compressor

• Mechanical T ime Clock

• Electronic Defrost Kit

• Electronic Voltage/Phase Monitor

• QuickVac Evacuation and Refrigerant

Recovery Valves

BESA

10/22/12

B40-BES-PDS-60-9

- 4 -

COPELAND

CAPACITY DATA -

R22

HIGH / MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESA008H2

Compressor 30 (-1.1) 8340 (1565) 8020 (1501) 7700 (1439) 7400 (1380) 7090 (1322) 6790 (1263)

Model 25 (-3.9) 7500 (1395) 7210 (1339) 6920 (1287) 6640 (1231) 6360 (1178) 6080 (1125)

KAN2-0075 20 (-6.7) 6710 (1240) 6440 (1190) 6180 (1140) 5920 (1093) 5680 (1043) 5420 (999)

BESA010H2

Compressor 30 (-1.1) 11400 (1565) 11000 (1501) 10600 (1439) 10200 (1380) 9740 (1322) 9330 (1263)

Model 25 (-3.9) 10300 (1395) 9920 (1339) 9530 (1287) 9150 (1231) 8780 (1178) 8390 (1125)

KAR2-0100 20 (-6.7) 9250 (1240) 8900 (1190) 8550 (1140) 8200 (1093) 7860 (1043) 7510 (999)

BESA015H2

Compressor 30 (-1.1) 14500 (1565) 13900 (1501) 13400 (1439) 12900 (1380) 12400 (1322) 11900 (1263)

Model 25 (-3.9) 12900 (1395) 12500 (1339) 12000 (1287) 11500 (1231) 11000 (1178) 10500 (1125)

KAGB-0150 20 (-6.7) 11500 (1240) 11100 (1190) 10600 (1140) 10200 (1093) 9750 (1043) 9330 (999)

BESA020H2

Compressor 30 (-1.1) 19600 (1565) 19000 (1501) 18400 (1439) 17800 (1380) 17100 (1322) 16500 (1263)

Model 25 (-3.9) 17700 (1395) 17200 (1339) 16600 (1287) 16000 (1231) 15400 (1178) 14800 (1125)

KAKB-0200 20 (-6.7) 15900 (1240) 15400 (1190) 14900 (1

BESA030H2

Compressor 30 (-1.1) 32490 (9513) 31310 (9168) 30110 (8816) 28890 (8459) 27650 (8096) 26390 (7727)

Model 25 (-3.9) 29290 (8576) 28210 (8260) 27110 (7938) 26000 (7613) 24860 (7279) 23720 (6945)

ERF1-0310 20 (-6.7) 26290 (7698) 25290 (7405) 24290 (7112) 23270 (6813) 22250 (6515) 21210 (6210)

SATURATED

SUCTION

TEMPERATURE

F° (C°)
45 (7.2) 11200 (2137) 10800 (2055) 10400 (1975) 9950 (1896) 9550 (1817) 9150 (1738)

40 (4.4) 10200 (1934) 9810 (1858) 9420 (1785) 9050 (1712) 8680 (1641) 8310 (1571)
35 (1.7) 9240 (1741) 8890 (1674) 8550 (1606) 8210 (1539) 7870 (1477) 7530 (1410)

15 (-9.4) 5960 (1099) 5730 (1052) 5490 (1011) 5260 (967) 5030 (923) 4800 (882)
10 (-12.2) 5280 (973) 5070 (929) 4850 (891) 4650 (850) 4440 (815) 4220 (777)

5 (-15) 4660 (853) 4460 (818) 4260 (785) 4080 (747) 3890 (715) 3700 (683)

0 (-17.8) 4090 (750) 3910 (721) 3740 (689) 3560 (659) 3390 (627) 3210 (598)
45 (7.2) 15000 (2137) 14500 (2055) 14000 (1975) 13400 (1896) 12900 (1817) 12400 (1738)
40 (4.4) 13800 (1934) 13300 (1858) 12800 (1785) 12300 (1712) 11800 (1641) 11300 (1571)
35 (1.7) 12600 (1741) 12100 (1674) 11700 (1606) 11200 (1539) 10800 (1477) 10300 (1410)

15 (-9.4) 8270 (1099) 7950 (1052) 7630 (1011) 7310 (967) 6990 (923) 6670 (882)
10 (-12.2) 7350 (973) 7070 (929) 6780 (891) 6480 (850) 6190 (815) 5900 (777)

5 (-15) 6520 (853) 6250 (818) 5980 (785) 5720 (747) 5450 (715) 5180 (683)

0 (-17.8) 5760 (750) 5510 (721) 5270 (689) 5030 (659) 4780 (627) 4530 (598)
45 (7.2) 19500 (2137) 18900 (2055) 18200 (1975) 17600 (1896) 17000 (1817) 16400 (1738)
40 (4.4) 17700 (1934) 17100 (1858) 16500 (1785) 15900 (1712) 15400 (1641) 14800 (1571)
35 (1.7) 16100 (1741) 15500 (1674) 14900 (1606) 14400 (1539) 13800 (1477) 13300 (1410)

15 (-9.4) 10200 (1099) 9820 (1052) 9400 (1011) 9000
10 (-12.2) 9040 (973) 8670 (929) 8300 (891) 7940 (850) 7580 (815) 7240 (777)

5 (-15) 8000 (853) 7660 (818) 7330 (785) 7010 (747) 6700 (715) 6390 (683)

0 (-17.8) 7090 (750) 6800 (721) 6510 (689) 6220 (659) 5940 (627) 5680 (598)
45 (7.2) 26200 (2137) 25300 (2055) 24500 (1975) 23700 (1896) 22900 (1817) 22000 (1738)
40 (4.4) 23900 (1934) 23100 (1858) 22400 (1785) 21600 (1712) 20800 (1641) 20100 (1571)
35 (1.7) 21700 (1741) 21000 (1674) 20300 (1606) 19600 (1539) 18900 (1477) 18200 (1410)

15 (-9.4) 14200 (1099) 13800 (1052) 13300 (1011) 12800 (967) 12300 (923) 11800 (882)
10 (-12.2) 12600 (973) 12200 (929) 11700 (891) 11300 (850) 10900 (815) 10400 (777)

5 (-15) 11100 (853) 10700 (818) 10300 (785) 9880 (747) 9480 (715) 9060 (683)

0 (-17.8) 9660 (750) 9270 (721) 8890 (689) 8510 (659) 8130 (627) 7750 (598)
45 (7.2) 43230 (12658) 41720 (12216) 40180 (11765) 38610 (11305) --- --- --- --­40 (4.4) 39460 (11554) 38070 (11147) 36650 (10731) 35200 (10307) 33730 (9876) --- --­35 (1.7) 35880 (10506) 34600 (10131) 33290 (9747) 31960 (9358) 30610 (8963) 29220 (8556)

15 (-9.4) 23480 (6875) 22570 (6608) 21650 (6339) 20730 (6070) 19800 (5797) 18860 (5522)
10 (-12.2) 20870 (6111) 20030 (5865) 19190 (5619) 18360 (5376) 17520 (5130) 16680 (4884)

5 (-15.0) 18450 (5402) 17680 (5177) 16920 (4954) 16160 (4732) 15410 (4512) 14650 (4290)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

AMBIENT TEMPERATURE °F (°C)

R22

(967) 8610 (923) 8220 (882)

140) 14400 (1093) 13800 (1043) 13300 (999)

--- Outside Operating Range

table continues on next page >>>

BESA

10/22/12

B40-BES-PDS-60-9

- 5 -

COPELAND

CAPACITY DATA -

R22

HIGH / MEDIUM TEMPERATURE

(cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESA050H8

Compressor

Model

2DC3R53KE

BESA051H8

Compressor

Model

2DD3R63KE

BESA075H8

Compressor

Model

2DL3R78KE

BESA076H8

Compressor

Model

2DA3R89KE

BESA080H8

Compressor

Model

3DA3R10ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 71050 (20803) 68710 (20118) 66370 (19433) 64030 (18748) 61690 (18063) 59350 (17378)
40 (4.4) 64680 (18938) 62510 (18303) 60330 (17665) 58160 (17029) 56000 (16397) 53830 (15761)
35 (1.7) 58670 (17179) 56660 (16590) 54650 (16002) 52640 (15413) 50630 (14824) 48630 (14239)
30 (-1.1) 53030 (15527) 51160 (14980) 49300 (14435) 47440 (13890) 45580 (13346) 43720 (12801)
25 (-3.9) 47730 (13975) 46000 (13469) 44280 (12965) 42550 (12459) 40830 (11955) 39110 (11451)
20 (-6.7) 42770 (12523) 41160 (12052) 39560 (11583) 37960 (11115) 36360 (10646) 34770 (10181)
15 (-9.4) 38120 (11162) 36630 (10725) 35140 (10289) 33650 (9853) 32160 (9416) 30680 (8983)
10 (-12.2) 33770 (9888) 32380 (9481) 30990 (9074) 29600 (8667) 28210 (8260) 26830 (7856)

5 (-15.0) 29710 (8699) 28400 (8316) 27090 (7932) 25790 (7551) 24490 (7171) 23190 (6790)
45 (7.2) 80180 (23477) 77560 (22710) 74930 (21940) 72320 (21175) 69690 (20405) 67070 (19638)
40 (4.4) 73200 (21433) 70770 (20721) 68350 (20013) 65920 (19301) 63500 (18593) 61080 (17884)
35 (1.7) 66590 (19498) 64350 (18842) 62110 (18186) 59870 (17530) 57640 (16877) 55400 (16221)
30 (-1.1) 60350 (17670) 58280 (17064) 56210 (16458) 54150 (15855) 52090 (15252) 50040 (14652)
25 (-3.9) 54470 (15949) 52560 (15390) 50650 (14830) 48750 (14274) 46850 (13718) 44960 (13164)
20 (-6.7) 48940 (14330) 47180 (13814) 45410 (13296) 43650 (12781) 41900 (12268) 40160 (11759)
15 (-9.4) 43750 (12810) 42110 (12330) 40480 (11853) 38850 (11375) 37240 (10904) 35620 (10430)
10 (-12.2) 38880 (11384) 37350 (10936) 35840 (10494) 34330 (10052) 32830 (9613) 31340 (9176)

5 (-15.0) 34310 (10046) 32890 (9630) 31470 (9214) 30060 (8802) 28670 (8395) 27280 (7988)
45 (7.2) 96090 (28135) 93020 (27236) 89940 (26334) 86840 (25427) 83730 (24516) --- --­40 (4.4) 88070 (25787) 85240 (24958) 82390 (24124) 79530 (23286) 76650 (22443) 73770 (21600)
35 (1.7) 80460 (23559) 77860 (22797) 75230 (22027) 72590 (21254) 69940 (20478) 67280 (19700)
30 (-1.1) 73260 (21451) 70860 (20748) 68440 (20039) 66010 (19328) 63580 (18616) 61140 (17902)
25 (-3.9) 66430 (19451) 64230 (18807) 62010 (18157) 59780 (17504) 57540 (16848) 55310 (16195)
20 (-6.7) 59970 (17559) 57950 (16968) 55910 (16370) 53870 (15773) 51820 (15173) 49770 (14573)
15 (-9.4) 53850 (15767) 51990 (15223) 50120 (14675) 48250 (14128) 46380 (13580) 44510 (13033)
10 (-12.2) 48040 (14066) 46330 (13565) 44620 (13065) 42900 (12561) 41190 (12060) 39480 (11560)

5 (-15.0) 42510 (12447) 40940 (11987) 39370 (11528) 37790 (11065) 36220 (10605) 34660 (10148)
45 (7.2) 112000 (32820) 108200 (31710) 104600 (30660) 100800 (29540) 97100 (28460) 93300 (27340)
40 (4.4) 102400 (30010) 98900 (28980) 95500 (27990) 92000 (26960) 88500 (25940) 85100 (24940)
35 (1.7) 93300 (27340) 90100 (26410) 86900 (25470) 83700 (24530) 80500 (23590) 77300 (22650)
30 (-1.1) 84800 (24850) 81800 (23970) 78800 (23090) 75900 (22240) 72900 (21360) 70000 (20510)
25 (-3.9) 76700 (22480) 74000 (21690) 71200 (20870) 68400 (20050) 65800 (19280) 63000 (18460)
20 (-6.7) 69200 (20280) 66600 (19520) 64100 (18790) 61600 (18050) 59100 (17320) 56500 (16560)
15 (-9.4) 62000 (18170) 59800 (17530) 57400 (16820) 55100 (16150) 52700 (15440) 50400 (14770)
10 (-12.2) 55500 (16270) 53300 (15620) 51200 (15010) 49100 (14390) 46900 (13740) 44700 (13100)

5 (-15.0) 49300 (14450) 47300 (13860) 45400 (13310) 43400 (12720) 41400 (12130) 39400 (11550)
45 (7.2) 132600 (38863) 128500 (37661) 124500 (36489) 120500 (35317) 116600 (34174) 1
40 (4.4) 121700 (35668) 117900 (34555) 114200 (33470) 110500 (32386) 106900 (31331) 103400 (30305)
35 (1.7) 111300 (32620) 107900 (31624) 104400 (30598) 101100 (29631) 97700 (28634) 94400 (27667)
30 (-1.1) 101500 (29748) 98300 (28810) 95200 (27902) 92100 (26993) 89000 (26084) 86000 (25205)
25 (-3.9) 92300 (27052) 89400 (26202) 86500 (25352) 83600 (24502) 80800 (23681) 78000 (22860)
20 (-6.7) 83500 (24472) 80900 (23710) 78200 (22919) 75600 (22157) 73000 (21395) 70400 (20633)
15 (-9.4) 75400 (22098) 72900 (21366) 70500 (20662) 68100 (19959) 65700 (19256) 63300 (18552)
10 (-12.2) 67700 (19842) 65500 (19197) 63200 (18523) 61000 (17878) 58800 (17233) 56700 (16618)

5 (-15.0) 60600 (17761) 58500 (17145) 56500 (16559) 54400 (15944) 52400 (15358) 50400 (14771)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

AMBIENT TEMPERATURE °F (°C)

R22

12800 (33060)

--- Outside Operating Range

table continues on next page >>>

BESA

10/22/12

B40-BES-PDS-60-9

- 6 -

COPELAND

CAPACITY DATA -

R22

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESA100H8

Compressor

Model

3DB3R12ME

BESA120H8

Compressor

Model

3DF3R15ME

BESA150H8

Compressor

Model

3DS3R17ME

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 152000 (44549) 147400 (43200) 142800 (41852) 138200 (40504) 133600 (39156) 128900 (37778)
40 (4.4) 139900 (41002) 135700 (39771) 131400 (38511) 127200 (37280) 122900 (36020) 118600 (34760)
35 (1.7) 128400 (37632) 124500 (36489) 120600 (35346) 116700 (34203) 112700 (33030) 108700 (31858)
30 (-1.1) 117500 (34437) 113900 (33382) 110300 (32327) 106700 (31272) 103100 (30217) 99400 (29132)
25 (-3.9) 107200 (31419) 103900 (30451) 100600 (29484) 97300 (28517) 94000 (27550) 90600 (26553)
20 (-6.7) 97400 (28546) 94400 (27667) 91400 (26788) 88400 (25909) 85300 (25000) 82300 (24121)
15 (-9.4) 88300 (25879) 85500 (25059) 82800 (24267) 80000 (23447) 77200 (22626) 74400 (21805)
10 (-12.2) 79700 (23359) 77200 (22626) 74700 (21893) 72100 (21131) 69600 (20399) 67000 (19637)

5 (-15.0) 71600 (20985) 69300 (20311) 67000 (19637) 64700 (18962) 62400 (18288) 60000 (17585)
45 (7.2) 185600 (54381) 179900 (52711) 174300 (51070) 168600 (49400) 163000 (47759) 157400 (46118)
40 (4.4) 170600 (49986) 165400 (48462) 160100 (46909) 154900 (45386) 149700 (43862) 144600 (42368)
35 (1.7) 156200 (45767) 151400 (44360) 146600 (42954) 141800 (41547) 137000 (40141) 132200 (38735)
30 (-1.1) 142500 (41753) 138100 (40463) 133600 (39145) 129200 (37856) 124800 (36566) 120500 (35307)
25 (-3.9) 129400 (37914) 125400 (36742) 121400 (35570) 117300 (34369) 113300 (33197) 109300 (32025)
20 (-6.7) 117100 (34310) 113400 (33226) 109800 (32171) 106100 (31087) 102400 (30003) 98800 (28948)
15 (-9.4) 105400 (30882) 102200 (29945) 98900 (28978) 95600 (28011) 92200 (27015) 88900 (26048)
10 (-12.2) 94600 (27718) 91700 (26868) 88700 (25989) 85700 (25110) 82700 (24231) 79800 (23381)

5 (-15.0) 84600 (24788) 82000 (24026) 79300 (23235) 76600 (22444) 74000 (21682) 71300 (20891)
45 (7.2) 205700 (60270) 199400 (58424) 193200 (56608) 187000 (54791) 180900 (53004) 175000 (51275)
40 (4.4) 189100 (55406) 183300 (53707) 177600 (52037) 172000 (50396) 166500 (48785) 161000 (47173)
35 (1.7) 173400 (50806) 168100 (49253) 162900 (47730) 157800 (46235) 152700 (44741) 147800 (43305)
30 (-1.1) 158400 (46411) 153600 (45005) 148900 (43628) 144300 (42280) 139700 (40932) 135300 (39643)
25 (-3.9) 144300 (42280) 139900 (40991) 135700 (39760) 131500 (38530) 127400 (37328) 123500 (36186)
20 (-6.7) 131000 (38383) 127000 (37211) 123200 (36098) 119500 (35014) 115800 (33929) 112300 (32904)
15 (-9.4) 118400 (34691) 114900 (33666) 111400 (32640) 108100 (31673) 104800 (30706) 101700 (29798)
10 (-12.2) 106600 (31234) 103400 (30296) 100300 (29388) 97400 (28538) 94500 (27689) 91700 (26868)

5 (-15.0) 95600 (28011) 92700 (27161) 89900 (26341) 87200 (25550) 84700 (24817) 82300 (24114)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

AMBIENT TEMPERATURE °F (°C)

R22

BESA

10/22/12

B40-BES-PDS-60-9

- 7 -

COPELAND

CAPACITY DATA -

R22

MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESA008M2

Compressor

Model

KAE2-0075

BESA010M2

Compressor

Model

KAM2-0100

BESA021M2

Compressor

Model

ERC1-0200

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

25 (-3.9) 8140 (2386) 7850 (2301) 7560 (2216) 7260 (2128) 6960 (2040) 6660 (1952)
20 (-6.7) 7300 (2140) 7030 (2060) 6760 (1981) 6490 (1902) 6220 (1823) 5940 (1741)
15 (-9.4) 6540 (1917) 6290 (1843) 6050 (1773) 5800 (1700) 5540 (1624) 5290 (1550)
10 (-12.2) 5850 (1715) 5620 (1647) 5400 (1583) 5170 (1515) 4940 (1448) 4710 (1380)

5 (-15) 5210 (1527) 5010 (1468) 4800 (1407) 4590 (1345) 4390 (1287) 4180 (1225)
0 (-17.8) 4600 (1348) 4420 (1295) 4230 (1240) 4060 (1190) 3870 (1134) 3690 (1081)

-5 (-20.6) 4030 (1181) 3860 (1131) 3700 (1084) 3540 (1038) 3380 (991) 3210 (941)
30 (-1.1) 12700 (3722) 12200 (3576) 11700 (3429) 11300 (3312) 10800 (3165) 10300 (3019)
25 (-3.9) 11500 (3370) 11000 (3224) 10600 (3107) 10100 (2960) 9700 (2843) 9280 (2720)
20 (-6.7) 10300 (3019) 9890 (2899) 9480 (2778) 9070 (2658) 8680 (2544) 8290 (2430)
15 (-9.4) 9190 (2693) 8820 (2585) 8450 (2477) 8080 (2368) 7710 (2260) 7360 (2157)
10 (-12.2) 8150 (2389) 7810 (2289) 7480 (2192) 7140 (2093) 6810 (1996) 6490 (1902)

5 (-15) 7150 (2096) 6860 (2011) 6560 (1923) 6250 (1832) 5960 (1747) 5680 (1665)

0 (-17.8) 6210 (1820) 5950 (1744) 5690 (1668) 5420 (1589) 5160 (1512) 4900 (1436)
25 (-3.9) 19800 (5803) 19000 (5569) 18300 (5363) 17500 (5129) 16700 (4894) 16000 (4689)
20 (-6.7) 17600 (5158) 16900 (4953) 16200 (4748) 15500 (4543) 14900 (4367) 14200 (4162)
15 (-9.4) 15500 (4543) 14900 (4367) 14300 (4191) 13700 (4015) 13100 (3839) 12500 (3664)
10 (-12.2) 13600 (3986) 13100 (3839) 12600 (3693) 12000 (3517) 11500 (3370) 11000 (3224)

5 (-15) 11900 (3488) 11500 (3370) 11000 (3224) 10500 (3077) 10000 (2931) 9570 (2805)

0 (-17.8) 10400 (3048) 10000 (2931) 9570 (2805) 9150 (2682) 8710 (2553) 8290 (2430)

-5 (-20.6) 9080 (2661) 8700 (2550) 8310 (2436) 7920 (2321) 7530 (2207) 7140 (2093)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

AMBIENT TEMPERATURE °F (°C)

R22

BESA

10/22/12

B40-BES-PDS-60-9

- 8 -

COPELAND

CAPACITY DATA -

R404A

R507

HIGH / MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESA050H8

Compressor

Model

2DC3R53KE

BESA051H8

Compressor

Model

2DD3R63KE

BESA075H8

Compressor

Model

2DL3R78KE

BESA076H8

Compressor

Model

2DA3R89KE

BESA080H8

Compressor

Model

3DA3R10ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

40 (4.4) 66260 (19401) 63070 (18467) 59920 (17545) 56790 (16628) 53690 (15720) 50630 (14824)
35 (1.7) 60610 (17747) 57700 (16895) 54810 (16048) 51940 (15208) 49110 (14379) 46300 (13557)
30 (-1.1) 55200 (16163) 52540 (15384) 49910 (14614) 47300 (13849) 44720 (13094) 42170 (12347)
25 (-3.9) 50040 (14652) 47630 (13946) 45240 (13246) 42880 (12555) 40540 (11870) 38220 (11191)
20 (-6.7) 45150 (13220) 42970 (12582) 40820 (11952) 38690 (11328) 36570 (10708) 34480 (10096)
15 (-9.4) 40530 (11867) 38580 (11296) 36640 (10728) 34730 (10169) 32840 (9616) 30960 (9065)
10 (-12.2) 36210 (10602) 34470 (10093) 32740 (9586) 31030 (9086) 29330 (8588) 27660 (8099)

5 (-15.0) 32190 (9425) 30650 (8974) 29110 (8523) 27590 (8078) 26080 (7636) 24590 (7200)
0 (-17.8) 28500 (8345) 27130 (7944) 25770 (7545) 24420 (7150) 23080 (6758) 21750 (6368)

-5 (-20.6) 25130 (7358) 23920 (7004) 22730 (6655) 21530 (6304) 20350 (5958) 19170 (5613)
40 (4.4) 76190 (22308) 72660 (21275) 69110 (20235) 65540 (19190) 61960 (18142) 58370 (17091)
35 (1.7) 70010 (20499) 66770 (19550) 63520 (18599) 60250 (17641) 56970 (16681) 53680 (15718)
30 (-1.1) 64030 (18748) 61070 (17881) 58100 (17012) 55130 (16142) 52130 (15264) 49130 (14385)
25 (-3.9) 58270 (17061) 55580 (16274) 52880 (15483) 50190 (14696) 47480 (13902) 44760 (13106)
20 (-6.7) 52770 (15451) 50330 (14737) 47900 (14025) 45460 (13311) 43020 (12596) 40570 (11879)
15 (-9.4) 47540 (13920) 45350 (13278) 43160 (12637) 40970 (11996) 38780 (11355) 36590 (10714)
10 (-12.2) 42630 (12482) 40660 (11905) 38700 (11331) 36750 (10760) 34800 (10189) 32850 (9618)

5 (-15.0) 38050 (11141) 36290 (10626) 34540 (10113) 32810 (9607) 31080 (9100) 29360 (8597)
0 (-17.8) 33840 (9908) 32270 (9449) 30720 (8995) 29190 (8547) 27670 (8102) 26160 (7660)

-5 (-20.6) 30020 (8790) 28630 (8383) 27250 (7979) 25900 (7584) 24570 (7194) 23260 (6811)
40 (4.4) 88330 (25863) 84230 (24663) 80140 (23465) 76060 (22270) 71980 (21076) 67910 (19884)

35 (1.7) 81450 (23849) 77700 (22751) 73950 (21653) 70220 (20560) 66480 (19465) 62750 (18373)
30 (-1.1) 74800 (21901) 71370 (20897) 67970 (19902) 64550 (18900) 61150 (17905) 57750 (16909)
25 (-3.9) 68400 (20028) 65290 (19117) 62190 (18209) 59100 (17304) 56010 (16400) 52920 (15495)
20 (-6.7) 62270 (18233) 59460 (17410) 56660 (16590) 53860 (15770) 51070 (14953) 48280 (14136)
15 (-9.4) 56450 (16529) 53910 (15785) 51390 (15047) 48870 (14309) 46370 (13577) 43860 (12842)
10 (-12.2) 50940 (14915) 48670 (14251) 46400

5 (-15.0) 45790 (13407) 43750 (12810) 41720 (12216) 39710 (11627) 37690 (11036) 35680 (10447)
0 (-17.8) 41000 (12005) 39180 (1

-5 (-20.6) 36610 (10719) 34970 (10239) 33350 (9765) 31730 (9291) 30120 (8819) 28510 (8348)
40 (4.4) 106500 (31210) 101600 (29780) 96600 (28310) 91700 (26870) 86700 (25410) 81800 (23970)
35 (1.7) 97900 (28690) 93300 (27340) 88700 (26000) 84200 (24680) 79700 (23360) 75200 (22040)
30 (-1.1) 89700 (26290) 85500 (25060) 81200 (23800) 77000 (22570) 72900 (21360) 68700 (20130)
25 (-3.9) 81700 (23940) 77800 (22800) 74100 (21720) 70200 (20570) 66400 (19460) 62600 (18350)
20 (-6.7) 74300 (21780) 70700 (20720) 67200 (19690) 63600 (18640) 60200 (17640) 56800 (16650)
15 (-9.4) 67100 (19660) 63900 (18730) 60700 (17790) 57500 (16850) 54400 (15940) 51200 (15010)
10 (-12.2) 60300 (17670) 57400 (16820) 54600 (16000) 51700 (15150) 48900 (14330) 46000 (13480)

5 (-15.0) 54000 (15830) 51300 (15030) 48800 (14300) 46200 (13540) 43700 (12810) 41100 (12050)
0 (-17.8) 48000 (14070) 45700 (13390) 43400 (12720) 41000 (12020) 38800 (11370) 36400 (10670)

-5 (-20.6) 42400 (12430) 40400 (11840) 38300 (11220) 36200 (10610) 34200 (10020) 32100 (9410)
40 (4.4) 121100 (35492) 115500 (33851) 110100 (32268) 104800 (30715) 99600 (29191) 94400 (27667)
35 (1.7) 111600 (32708) 106500 (31213) 101600 (29777) 96800 (28370) 92000 (26964) 87300 (25586)
30 (-1.1) 102500 (30041) 97900 (28693) 93400 (27374) 89000 (26084) 84800 (24853) 80500 (23593)
25 (-3.9) 93700 (27462) 89600 (26260) 85500 (25059) 81600 (23916) 77800 (22802) 73900 (21659)
20 (-6.7) 85300 (25000) 81600 (23916) 78100 (22890) 74600 (21864) 71100 (20838) 67700 (19842)
15 (-9.4) 77400 (22685) 74100 (21717) 70900 (20780) 67800 (19871) 64800 (18992) 61700 (18083)
10 (-12.2) 69900 (20487) 67000 (19637) 64200 (18816) 61500 (18025) 58700 (17204) 56000 (16413)

5 (-15.0) 62900 (18435) 60300 (17673) 57900 (16970) 55400 (16237) 53100 (15563) 50600 (14830)
0 (-17.8) 56400 (16530) 54100 (15856) 51900 (15211) 49800 (14596) 47700 (13980) 45500 (13335)

-5 (-20.6) 50300 (14742) 48300 (14156) 46400 (13599) 44600 (13072) 42700 (12515) 40700 (11928)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

1472) 37370 (10942) 35560 (10412) 33760 (9885) 31970 (9361)

R404A R507

(13586) 44150 (12927) 41900 (12268) 39650 (11610)

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range

table continues on next page >>>

BESA

10/22/12

B40-BES-PDS-60-9

- 9 -

COPELAND

CAPACITY DATA -

R404A

R507

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESA100H8

Compressor

Model

3DB3R12ME

BESA120H8

Compressor

Model

3DF3R15ME

BESA150H8

Compressor

Model

3DS3R17ME

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

40 (4.4) 137300 (40240) 131100 (38423) 124900 (36606) 118700 (34789) 112500 (32972) 106300 (31155)
35 (1.7) 127000 (37222) 121300 (35551) 115700 (33910) 110000 (32239) 104300 (30569) 98600 (28898)
30 (-1.1) 117100 (34320) 111900 (32796) 106800 (31301) 101600 (29777) 96500 (28283) 91300 (26758)
25 (-3.9) 107600 (31536) 102900 (30158) 98300 (28810) 93600 (27433) 88900 (26055) 84200 (24678)
20 (-6.7) 98600 (28898) 94300 (27638) 90100 (26407) 85900 (25176) 81700 (23945) 77400 (22685)
15 (-9.4) 89900 (26348) 86100 (25234) 82400 (24150) 78600 (23036) 74800 (21923) 70900 (20780)
10 (-12.2) 81800 (23974) 78400 (22978) 75000 (21981) 71600 (20985) 68100 (19959) 64700 (18962)

5 (-15.0) 74000 (21688) 71000 (20809) 67900 (19900) 64900 (19021) 61800 (18113) 58700 (17204)
0 (-17.8) 66700 (19549) 64000 (18757) 61300 (17966) 58500 (17145) 55800 (16354) 53000 (15533)

-5 (-20.6) 59800 (17526) 57400 (16823) 54900 (16090) 52400 (15358) 49900 (14625) 47400 (13892)
40 (4.4) 177000 (51861) 168900 (49488) 160800 (47114) 152800 (44770) 144900 (42456) 136900 (40112)
35 (1.7) 163200 (47818) 155900 (45679) 148500 (43511) 141200 (41372) 133900 (39233) 126700 (37123)
30 (-1.1) 150100 (43979) 143400 (42016) 136700 (40053) 130100 (38119) 123500 (36186) 116900 (34252)
25 (-3.9) 137500 (40288) 131400 (38500) 125400 (36742) 119400 (34984) 113400 (33226) 107500 (31498)
20 (-6.7) 125500 (36772) 120100 (35189) 114600 (33578) 109300 (32025) 103900 (30443) 98600 (28890)
15 (-9.4) 114200 (33461) 109300 (32025) 104500 (30619) 99600 (29183) 94800 (27776) 90000 (26370)
10 (-12.2) 103500 (30326) 99200 (29066) 94800 (27776) 90500 (26517) 86200 (25257) 82000 (24026)

5 (-15.0) 93500 (27396) 89600 (26253) 85800 (25139) 81900 (23997) 78100 (22883) 74300 (21770)
0 (-17.8) 84200 (24671) 80700 (23645) 77200 (22620) 73800 (21623) 70400 (20627) 67000 (19631)

-5 (-20.6) 75500 (22122) 72400 (21213) 69300 (20305) 66200 (19397) 63100 (18488) 60100 (17609)
40 (4.4) 191000 (55963) 182200 (53385) 173500 (50836) 164800 (48286) 156100 (45737) 147500 (43218)
35 (1.7) 176600 (51744) 168500 (49371) 160500 (47027) 152600 (44712) 144600 (42368) 136800 (40082)
30 (-1.1) 162600 (47642) 155300 (45503) 148000 (43364) 140800 (41254) 133600 (39145) 126400 (37035)
25 (-3.9) 149300 (43745) 142600 (41782) 136100 (39877) 129500 (37944) 123000 (36039) 116500 (34135)
20 (-6.7) 136500 (39995) 130600 (38266) 124600 (36508) 118700 (34779) 112900 (33080) 107000 (31351)
15 (-9.4) 124400 (36449) 119100 (34896) 113800 (33343) 108500 (31791) 103200 (30238) 98000 (28714)
10 (-12.2) 113000 (33109) 108200 (31703) 103400

5 (-15.0) 102200 (29945) 97900 (28685) 93700 (27454) 89400 (26194) 85300 (24993) 81100 (23762)
0 (-17.8) 92100 (26985) 88300 (25872) 84500 (24759) 80700 (23645) 77000 (22561) 73200 (21448)

-5 (-20.6) 82700 (24231) 79200 (23206) 75800 (22209) 72500 (21243) 69100 (20246) 65700 (19250)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

R404A R507

(30296) 98700 (28919) 94000 (27542) 89300 (26165)

AMBIENT TEMPERATURE °F (°C)

BESA

10/22/12

B40-BES-PDS-60-9

- 10 -

COPELAND

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60Hz

CONDENSING

UNIT

MODEL

BESA010M6

Compressor

Model

KARB-010E

BESA020M6

Compressor

Model

KAKA-020E

BESA021M6

Compressor

Model

ERCA-021E

BESA030M6

Compressor

Model

ERFA-031E

SATURATED

SUCTION

TEMPERATURE

° F ° C

25 (-3.9) 10300 (3019) 9860 (2890) 9360 (2743) 8870 (2600) 8370 (2453) 7870 (2307)
20 (-6.7) 9530 (2793) 9070 (2658) 8620 (2526) 8160 (2392) 7690 (2254) 7230 (2119)
15 (-9.4) 8680 (2544) 8260 (2421) 7840 (2298) 7420 (2175) 6990 (2049) 6560 (1923)
10 (-12.2) 7840 (2298) 7450 (2183) 7070 (2072) 6670 (1955) 6280 (1841) 5880 (1723)

5 (-15) 7010 (2055) 6650 (1949) 6300 (1846) 5950 (1744) 5590 (1638) 5230 (1533)
0 (-17.8) 6240 (1829) 5920 (1735) 5600 (1641) 5280 (1547) 4960 (1454) 4650 (1363)

-5 (-20.6) 5550 (1627) 5260 (1542) 4990 (1462) 4700 (1377) 4420 (1295) 4130 (1210)
25 (-3.9) 17100 (5012) 16300 (4777) 15400 (4513) 14600 (4279) 13700 (4015) 12800 (3751)
20 (-6.7) 15700 (4601) 14900 (4367) 14100 (4132) 13300 (3898) 12500 (3664) 11800 (3458)
15 (-9.4) 14200 (4162) 13500 (3957) 12800 (3751) 12100 (3546) 11400 (3341) 10700 (3136)
10 (-12.2) 12700 (3722) 12100 (3546) 11400 (3341) 10800 (3165) 10200 (2989) 9570 (2805)

5 (-15) 11300 (3312) 10700 (3136) 10200 (2989) 9620 (2819) 9060 (2655) 8510 (2494)
0 (-17.8) 10100 (2960) 9560 (2802) 9050 (2652) 8550 (2506) 8040 (2356) 7550 (2213)

-5 (-20.6) 9040 (2649) 8580 (2515) 8120 (2380) 7650 (2242) 7200 (2110) 6750 (1978)
25 (-3.9) 21600 (6331) 20500 (6008) 19400 (5686) 18300 (5363) 17100 (5012) 16100 (4719)
20 (-6.7) 19600 (5744) 18500 (5422) 17500 (5129) 16500 (4836) 15500 (4543) 14500 (4250)
15 (-9.4) 17700 (5188) 16700 (4894) 15800 (4631) 14900 (4367) 14000 (4103) 13000 (3810)
10 (-12.2) 16000 (4689) 15100 (4426) 14200 (4162) 13400 (3927) 12500 (3664) 11700 (3429)

5 (-15) 14300 (4191) 13500 (3957) 12700 (3722) 12000 (3517) 11200 (3283) 10500 (3077)
0 (-17.8) 12700 (3722) 12000 (3517) 11300 (3312) 10600 (3107) 9910 (2904) 9230 (2705)

-5 (-20.6) 11100 (3253) 10500 (3077) 9860 (2890) 9230 (2705) 8610 (2523) 7990 (2342)
25 (-3.9) 31330 (9173) 29860 (8743) 28360 (8304) 26840 (7859) 25320 (7414) 23780 (6963)
20 (-6.7) 28410 (8318) 27070 (7926) 25700 (7525) 24320 (7121) 22930 (6714) 21530 (6304)
15 (-9.4) 25680 (7519) 24450 (7159) 23210 (6796) 21950 (6427) 20690 (6058) 19420 (5686)
10 (-12.2) 23130 (6772) 22010 (6445) 20880 (6114) 19730 (5777) 18580 (5440) 17430 (5104)

5 (-15.0) 20750 (6076) 19730 (5777) 18700 (5475) 17650 (5168) 16600 (4860) 15550 (4553)
0 (-17.8) 18520 (5423) 17590 (5150) 16640

-5 (-20.6) 16440 (4814) 15570 (4559) 14700 (4304) 13810 (4044) 12930 (3786) 12050 (3528)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

R404A R507

(4872) 15680 (4591) 14720 (4310) 13770 (4032)

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range

BESA

10/22/12

B40-BES-PDS-60-9

- 11 -

COPELAND

CAPACITY DATA -

R407C

HIGH / MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESA050H8

Compressor

Model

2DC3R53KE

BESA051H8

Compressor

Model

2DD3R63KE

BESA075H8

Compressor

Model

2DL3R78KE

BESA076H8

Compressor

Model

2DA3R89KE

BESA080H8

Compressor

Model

3DA3R10ME

BESA100H8

Compressor

Model

3DB3R12ME

BESA120H8

Compressor

Model

3DF3R15ME

BESA150H8

Compressor

Model

3DS3R17ME

--- Outside Operating Range
NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.

It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 68500 (20075) 66100 (19372) 63800 (18698) 61600 (18053) 59400 (17408) 57300 (16793)
40 (4.4) 61600 (18053) 59400 (17408) 57300 (16793) 55200 (16178) 53200 (15591) 51200 (15005)
35 (1.7) 55300 (16207) 53200 (15591) 51200 (15005) 49300 (14448) 47400 (13892) 45500 (13335)
30 (-1.1) 49400 (14478) 47500 (13921) 45600 (13364) 43800 (12837) 42100 (12338) 40400 (11840)
25 (-3.9) 44000 (12895) 42200 (12368) 40500 (11869) 38800 (11371) 37200 (10902) 35600 (10433)
20 (-6.7) 39000 (11430) 37400 (10961) 35800 (10492) 34300 (10052) 32800 (9613) 31400 (9202)
15 (-9.4) 34500 (10111) 33000 (9671) 31600 (9261) 30200 (8851) 28800 (8440) 27600 (8089)
10 (-12.2) 30400 (8909) 29100 (8528) 27800 (8147) 26500 (7766) 25300 (7415) 24200 (7092)
45 (7.2) 77400 (22684) 74800 (21922) 72300 (21189) 69800 (20456) 67500 (19782) 65200 (19108)
40 (4.4) 69800 (20456) 67400 (19753) 65100 (19079) 62800 (18405) 60600 (17760) 58400 (17115)
35 (1.7) 62800 (18405) 60500 (17731) 58300 (17086) 56200 (16471) 54100 (15855) 52100 (15269)
30 (-1.1) 56200 (16471) 54100 (15855) 52100 (15269) 50100 (14683) 48200 (14126) 46400 (13598)
25 (-3.9) 50200 (14712) 48300 (14155) 46400 (13598) 44600 (13071) 42800 (12543) 41100 (12045)
20 (-6.7) 44600 (13071) 42900 (12573) 41200 (12075) 39500 (11576) 37900 (11107) 36400 (10668)
15 (-9.4) 39600 (11606) 38000 (11137) 36400 (10668) 34900 (10228) 33500 (9818) 32100 (9408)
10 (-12.2) 35000 (10257) 33600 (9847) 32200 (9437) 30900 (9056) 29600 (8675) 28400 (8323)
45 (7.2) 92900 (27226) 90000 (26376) 87100 (25526) 84300 (24706) 81600 (23915) --- --­40 (4.4) 84200 (24677) 81400 (23856) 78700 (23065) 76100 (22303) 73500 (21541) 71000 (20808)
35 (1.7) 76000 (22273) 73400 (21511) 70900 (20779) 68400 (20046) 66000 (19343) 63700 (18669)
30 (-1.1) 68400 (20046) 66000 (19343) 63600 (18639) 61300 (17965) 59100 (17321) 57000 (16705)
25 (-3.9) 61300 (17965) 59100 (17321) 56900 (16676) 54800 (16060) 52800 (15474) 50900 (14917)
20 (-6.7) 54800 (16060) 52800 (15474) 50800 (14888) 48900 (14331) 47100 (13804) 45300 (13276)
15 (-9.4) 48800 (14302) 47000 (13774) 45200 (13247) 43600 (12778) 41900 (12280) 40400 (11840)
10 (-12.2) 43400 (12719) 41800 (12250) 40300 (11811) 38800 (11371) 37400 (10961) 36000 (10551)
45 (7.2) 109500 (32090) 106000 (31070) 102500 (30040) 99100 (29040) 95800 (28080) 92600 (27140)
40 (4.4) 99100 (29040) 95800 (28080) 92600 (27140) 89500 (26230) 86400 (25320) 83400 (24440)
35 (1.7) 89400
30 (-1.1) 80300 (23530) 77500 (22710) 74800 (21920) 72100 (21
25 (-3.9) 71900 (21070) 69300 (20310) 66800 (19580) 64400 (18870) 62000 (18170) 59600 (17470)
20 (-6.7) 64200 (18820) 61800 (181
15 (-9.4) 57100 (16730) 54900 (16090) 52900 (15500) 50800 (14890) 48800 (14300) 46800 (13720)
10 (-12.2) 50600 (14830) 48700 (14270) 46800 (13720) 44900 (13160) 43000 (12600) 41200 (12070)
45 (7.2) 124200 (36399) 1
40 (4.4) 113800 (33351) 109800 (32179) 105800 (31007) 101900 (29864) 98100 (28750) 94200 (27607)
35 (1.7) 103900 (30450) 100200 (29366) 96700 (28340) 93100 (27285) 89600 (26259) 86000 (25204)
30 (-1.1) 94400 (27666) 91100 (26699) 87900 (25761) 84700 (24823) 81400 (23856) 78100 (22889)
25 (-3.9) 85400 (25028) 82500 (24178) 79600 (23328) 76600 (22449) 73600 (21570) 70400 (20632)
20 (-6.7) 76900 (22537) 74300 (21775) 71600 (20984) 68900 (20193) 66000 (19343) 63000 (18463)
15 (-9.4) 69000 (20222) 66600 (19519) 64200 (18815) 61600 (18053) 58800 (17233) 55900 (16383)
10 (-12.2) 61600 (18053) 59500 (17438) 57100 (16734) 54600 (16002) 52000 (15240) 49100 (14390)
45 (7.2) 141600 (41499) 136600 (40034) 131700 (38597) 126800 (37161) 121800 (35696) --- --­40 (4.4) 130400 (38216) 125900 (36898) 121400 (35579) 116900 (34260) 112300 (32912) 107600 (31534)
35 (1.7) 119600 (35051) 115500 (33850) 111400 (32648) 107300 (31447) 103000 (30186) 98600 (28897)
30 (-1.1) 109200 (32003) 105500 (30919) 101800 (29835) 97900 (28692) 94000 (27549) 89900 (26347)
25 (-3.9) 99200 (29073) 95900 (28106) 92500 (27109) 89000 (26083) 85300 (24999) 81400 (23856)
20 (-6.7) 89800 (26318) 86800 (25439) 83600 (24501) 80300 (23534) 76800 (22508) 73100 (21423)
15 (-9.4) 80900 (23709) 78200 (22918) 75200 (22039) 72100 (21130) 68700 (20134) 65100 (19079)
10 (-12.2) 72600 (21277) 70000 (20515) 67300 (19724) 64200 (18815) 61000 (17877) 57400 (16822)
45 (7.2) 174600 (51170) 168200 (49295) 161900 (47448) 155800 (45660) 149600 (43843) 143600 (42085)
40 (4.4) 160000 (46891) 154300 (45221) 148700 (43580) 143100 (41938) 137500 (40297) 131900 (38656)
35 (1.7) 146000 (42788) 140900 (41294) 135900 (39828) 130800 (38334) 125700 (36839) 120600 (35344)
30 (-1.1) 132600 (38861) 128100 (37542) 123600 (36224) 119000 (34875) 114300 (33498) 109500 (32091)
25 (-3.9) 119900 (35139) 115900 (33967) 111800 (32765) 107600 (31534) 103300 (30274) 98800 (28955)
20 (-6.7) 107900 (31622) 104300 (30567) 100700 (29512) 96800 (28369) 92800 (27197) 88600
15 (-9.4) 96700 (28340) 93500 (27402) 90200 (26435) 86600 (25380) 82800 (24266) 78800 (23094)
10 (-12.2) 86300 (25292) 83400 (24442) 80300 (23534) 77000 (22566) 73400 (21511) 69400 (20339)
45 (7.2) 192500 (56416) 185700 (54423) 178900 (52430) 172400 (50525) 165900 (48620) 159400 (46716)
40 (4.4) 176900 (51844) 170700 (50027) 164700 (48269) 158700 (46510) 152900 (44811) 147000 (43081)
35 (1.7) 161800 (47419) 156300 (45807) 150900 (44224) 145600 (42671) 140300 (41118) 134900 (39535)
30 (-1.1) 147400 (43199) 142500 (41763) 137700 (40356) 132900 (38949) 128100 (37542) 123100 (36077)
25 (-3.9) 133700 (39184) 129400 (37923) 125100 (36663) 120700 (35374) 116300 (34084) 111700 (32736)
20 (-6.7) 120800 (35403) 117000 (34289) 113100 (33146) 109100 (31974) 105000 (30772) 100700 (29512)
15 (-9.4) 108700 (31857) 105200 (30831) 101700 (29805) 98000 (28721) 94100 (27578) 90000 (26376)
10 (-12.2) 97300 (28516) 94200 (27607) 90900 (26640) 87400 (25614) 83600 (24501) 79600 (23328)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

(26200) 86400 (25320) 83400 (24440) 80500 (23590) 77600 (22740) 74800 (21920)

10) 59500 (17440) 57300 (16790) 55100 (16150) 52900 (15500)

19700 (35081) 1

15400 (33820) 111100 (32560) 106900 (31329) 102700 (30098)

R407C

AMBIENT TEMPERATURE °F (°C)

130) 69500 (20370) 66900 (19610)

(25966)

BESA

10/22/12

B40-BES-PDS-60-9

- 12 -

COPELAND

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60Hz

CONDENSING

UNIT

MODEL

BESA005L6

Compressor

Model

KANB-005E

BESA008L6

Compressor

Model

KAMB-007E

BESA010L6

Compressor

Model

KAJB-010E

BESA015L6

Compressor

Model

KALB-015E

BESA020L6

Compressor

Model

EADB-021E

BESA021L6

Compressor

Model

EAVB-021E

SATURATED

SUCTION

TEMPERATURE

° F ° C

0 (-17.8) 4200 (1231) 3920 (1149) 3660 (1073) 3390 (994) 3130 (917) 2860 (838)

-5 (-20.6) 3690 (1081) 3430 (1005) 3190 (935) 2960 (868) 2720 (797) 2490 (730)

-10 (-23.3) 3190 (935) 2970 (870) 2750 (806) 2540 (744) 2340 (686) 2120 (621)

-15 (-26.1) 2730 (800) 2530 (742) 2340 (686) 2150 (630) 1970 (577) 1780 (522)

-20 (-28.9) 2310 (677) 2130 (624) 1960 (574) 1790 (525) 1630 (478) 1460 (428)

-25 (-31.7) 1930 (566) 1760 (516) 1610 (472) 1460 (428) 1320 (387) 1170 (343)

-30 (-34.4) 1580 (463) 1430 (419) 1300 (381) 1170 (343) 1040 (305) 910 (267)

-35 (-37.2) 1280 (375) 1150 (337) 1030 (302) 920 (270) 790 (232) 680 (199)

-40 (-40.0) 1030 (302) 920 (270) 800 (234) 700 (205) 590 (173) 480 (141)
0 (-17.8) 6440 (1887) 6130 (1797) 5820 (1706) 5500 (1612) 5180 (1518) 4850 (1421)

-5 (-20.6) 5760 (1688) 5470 (1603) 5190 (1521) 4910 (1439) 4620 (1354) 4320 (1266)

-10 (-23.3) 5090 (1492) 4830 (1416) 4580 (1342) 4330 (1269) 4070 (1193) 3790 (1111)

-15 (-26.1) 4450 (1304) 4220 (1237) 4000 (1172) 3770 (1105) 3520 (1032) 3280 (961)

-20 (-28.9) 3850 (1128) 3650 (1070) 3440 (1008) 3230 (947) 3020 (885) 2790 (818)

-25 (-31.7) 3320 (973) 3130 (917) 2950 (865) 2760 (809) 2560 (750) 2350 (689)

-30 (-34.4) 2860 (838) 2690 (788) 2520 (739) 2350 (689) 2160 (633) 1970 (577)

-35 (-37.2) 2480 (727) 2330 (683) 2170 (636) 2020 (592) 1840 (539) 1660 (487)

-40 (-40.0) 2210 (648) 2070 (607) 1930 (566) 1770 (519) 1610 (472) 1430 (419)
0 (-17.8) 8130 (2383) 7680 (2251) 7250 (2125) 6810 (1996) 6360 (1864) 5910 (1732)

-5 (-20.6) 7280 (2134) 6880 (2016) 6480 (1899) 6080 (1782) 5680 (1665) 5260 (1542)

-10 (-23.3) 6490 (1902) 6130 (1797) 5760 (1688) 5400 (1583) 5030 (1474) 4660 (1366)

-15 (-26.1) 5750 (1685) 5420 (1589) 5090 (1492) 4750 (1392) 4420 (1295) 4090 (1199)

-20 (-28.9) 5060 (1483) 4760 (1395) 4460 (1307) 4150 (1216) 3850 (1128) 3550 (1040)

-25 (-31.7) 4410 (1292) 4140 (1213) 3870 (1134) 3610 (1058) 3340 (979) 3070 (900)

-30 (-34.4) 3810 (1117) 3570 (1046) 3330 (976) 3090 (906) 2850 (835) 2620 (768)

-35 (-37.2) 3270 (958) 3050 (894) 2830 (829) 2620 (768) 2410 (706) 2190 (642)

-40 (-40.0) 2760 (809) 2560 (750) 2370 (695) 2180 (639) 2000 (586) 1810 (530)
0 (-17.8) 12600 (3693) 12000 (3517) 11300 (3312) 10700 (3136) 10000 (2931) 9370 (2746)

-5 (-20.6) 11300 (3312) 10700 (3136) 10100 (2960) 9510 (2787) 8920 (2614) 8330 (2441)

-10 (-23.3) 10000 (2931) 9500 (2784) 8960 (2626) 8430 (2471) 7890 (2312) 7350 (2154)

-15 (-26.1) 8880 (2603) 8380 (2456) 7900 (2315) 7410 (2172) 6920 (2028) 6440 (1887)

-20 (-28.9) 7790 (2283) 7350 (2154) 6910 (2025) 6470 (1896) 6030 (1767) 5580 (1635)

-25 (-31.7) 6790 (1990) 6390 (1873) 5980 (1753) 5590 (1638) 5190 (1521) 4790 (1404)

-30 (-34.4) 5850 (1715) 5490 (1609) 5130 (1504) 4770 (1398) 4410 (1292) 4050 (1187)

-35 (-37.2) 5000 (1465) 4670 (1369) 4340 (1272) 4020 (1

-40 (-40.0) 4200 (1231) 3900 (1143) 3610 (1058) 3310 (970) 3010 (882) 2700 (791)
0 (-17.8) 14600 (4279) 13800 (4045) 12900 (3781) 12100 (3546) 11300 (3312) 10500 (3077)

-5 (-20.6) 13000 (3810) 12200 (3576) 11400 (3341) 10700 (3136) 9940 (2913) 9220 (2702)

-10 (-23.3) 11500 (3370) 10800 (3165) 10100 (2960) 9360 (2743) 8680 (2544) 8030 (2353)

-15 (-26.1) 10100 (2960) 9410 (2758) 8780 (2573) 8140 (2386) 7530 (2207) 6950 (2037)

-20 (-28.9) 8760 (2567) 8170 (2394) 7590 (2225) 7020 (2057) 6480 (1899) 5960 (1747)

-25 (-31.7) 7560 (2216) 7050 (2066) 6520 (1911) 6000 (1758) 5530 (1621) 5080 (1489)

-30 (-34.4) 6490 (1902) 6020 (1764) 5550 (1627) 5100 (1495) 4680 (1372) 4300 (1260)

-35 (-37.2) 5530 (1621) 5100 (1495) 4690 (1375) 4300 (1260) 3930 (1152) 3620 (1061)

-40 (-40.0) 4680 (1372) 4300 (1260) 3930 (1152) 3590 (1052) 3290 (964) 3040 (891)
0 (-17.8) 15900 (4660) 15100 (4426) 14200 (4162) 13400 (3927) 12600 (3693) 11800 (3458)

-5 (-20.6) 14300 (4191) 13500 (3957) 12800 (3751) 12000 (3517) 11300 (3312) 10600 (3107)

-10 (-23.3) 12700 (3722) 12000 (3517) 11400 (3341) 10700 (3136) 10100 (2960) 9400 (2755)

-15 (-26.1) 11200 (3283) 10600 (3107) 10000 (2931) 9430 (2764) 8840 (2591) 8250 (2418)

-20 (-28.9) 9820 (2878) 9290 (2723) 8770 (2570) 8220 (2409) 7670 (2248) 7120 (2087)

-25 (-31.7) 8550 (2506) 8080 (2368) 7580 (2222) 7080 (2075) 6560 (1923) 6040 (1770)

-30 (-34.4) 7400 (2169) 6960 (2040) 6500 (1905) 6020 (1764) 5510 (1615) 4990 (1462)

-35 (-37.2) 6390 (1873) 5960 (1747) 5510 (1615) 5030 (1474) 4520 (1325) 3990 (1169)

-40 (-40.0) 5510 (1615) 5090 (1492) 4620 (1354) 4120 (1208) 3590 (1052) 3050 (894)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

R404A R507

AMBIENT TEMPERATURE °F (°C)

178) 3690 (1081) 3360 (985)

table continues on next page >>>

BESA

10/22/12

B40-BES-PDS-60-9

- 13 -

COPELAND

CAPACITY DATA -

R404A

LOW TEMPERATURE (cont’d)

R507

60Hz

CONDENSING

UNIT

MODEL

BESA030L6

Compressor

Model

LAHA-032E

BESA032L6

Compressor

Model

LACA-032E

BESA035L6

Compressor

Model

2DF3F16KE

BESA040L6

Compressor

Model

2DL3F20KE

BESA060L6

Compressor

Model

2DB3F25KE

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

0 (-17.8) 26650 (7803) 25250 (7393) 23870 (6989) 22490 (6585) 21090 (6175) 19680 (5762)

-5 (-20.6) 23750 (6954) 22470 (6579) 21190 (6204) 19900 (5827) 18610 (5449) 17300 (5065)

-10 (-23.3) 20990 (6146) 19810 (5800) 18630 (5455) 17440 (5106) 16250 (4758) 15030 (4401)

-15 (-26.1) 18360 (5376) 17280 (5060) 16200 (4743) 15110 (4424) 14020 (4105) 12900 (3777)

-20 (-28.9) 15870 (4647) 14890 (4360) 13920 (4076) 12930 (3786) 11930 (3493) 10910 (3194)

-25 (-31.7) 13550 (3967) 12670 (3710) 11780 (3449) 10900 (3192) 9990 (2925) 9060 (2653)

-30 (-34.4) 11380 (3332) 10600 (3104) 9820 (2875) 9020 (2641) 8210 (2404) 7370 (2158)

-35 (-37.2) 9400 (2752) 8710 (2550) 8030 (2351) 7330 (2146) 6610 (1935) 5860 (1716)

-40 (-40.0) 7600 (2225) 7020 (2055) 6420 (1880) 5820 (1704) 5190 (1520) 4520 (1323)
0 (-17.8) ---- --- ---- --- ---- --- ---- --- ---- --- ---- ---

-5 (-20.6) ---- --- ---- --- ---- --- ---- --- ---- --- ---- ---

-10 (-23.3) ---- --- ---- --- ---- --- ---- --- ---- --- ---- ---

-15 (-26.1) ---- --- ---- --- ---- --- ---- --- ---- --- ---- ---

-20 (-28.9) 19310 (5654) 18220 (5335) 17140 (5019) 16070 (4705) 15030 (4401) 14010 (4102)

-25 (-31.7) 16820 (4925) 15810 (4629) 14810 (4336) 13820 (4046) 12840 (3760) 11870 (3476)

-30 (-34.4) 14470 (4237) 13570 (3973) 12670 (3710) 11770 (3446) 10880 (3186) 9990 (2925)

-35 (-37.2) 12210 (3575) 11440 (3350) 10660 (3121) 9890 (2896) 9110 (2667) 8330 (2439)

-40 (-40.0) 9990 (2925) 9380 (2746) 8770 (2568) 8140 (2383) 7500 (2196) 6850 (2006)
0 (-17.8) 33210 (9724) 31580 (9247) 29980 (8778) 28400 (8316) 26820 (7853) 25260 (7396)

-5 (-20.6) 29850 (8740) 28390 (8313) 26950 (7891) 25540 (7478) 24130 (7065) 22710 (6649)

-10 (-23.3) 26660 (7806) 25360 (7425) 24080 (7051) 22810 (6679) 21540 (6307) 20270 (5935)

-15 (-26.1) 23650 (6925) 22490 (6585) 21350 (6251) 20210 (5917) 19070 (5584) 17930 (5250)

-20 (-28.9) 20840 (6102) 19810 (5800) 18780 (5499) 17760 (5200) 16730 (4899) 15680 (4591)

-25 (-31.7) 18240 (5341) 17300 (5065) 16380 (4796) 15450 (4524) 14500 (4246) 13540 (3965)

-30 (-34.4) 15840 (4638) 14990 (4389) 14140 (4140) 13280 (3888) 12400 (3631) 11500 (3367)

-35 (-37.2) 13650 (3997) 12860 (3765) 12070 (3534) 11260 (3297) 10420 (3051) 9560 (2799)

-40 (-40.0) 11680 (3420) 10920 (3197) 10160 (2975) 9380 (2746)
0 (-17.8) 40500 (11858) 38610 (11305) 36730 (10755) 34850 (10204) 32980 (9657) 31100 (9106)

-5 (-20.6) 36420 (10664) 34720 (10166) 33020 (9668) 31320 (9170) 29620 (8673) 27920 (8175)

-10 (-23.3) 32580 (9539) 31050 (9091) 29510 (8641) 27980 (8193) 26440 (7742) 24910 (7294)

-15 (-26.1) 28970 (8482) 27590 (8078) 26210 (7674) 24830 (7270) 23440 (6863) 22060 (6459)

-20 (-28.9) 25600 (7496) 24350 (7130) 231

-25 (-31.7) 22450 (6573) 21330 (6245) 20220 (5920) 19090 (5590) 17970 (5262) 16850 (4934)

-30 (-34.4) 19540 (5721) 18530 (5426) 17520 (5130) 16510 (4834) 15490 (4535) 14470 (4237)

-35 (-37.2) 16850 (4934) 15930 (4664) 15010 (4395) 14090 (4126) 13160 (3853) 12230 (3581)

-40 (-40.0) 14380 (4210) 13540 (3965) 12690 (3716) 11840 (3467) 10990 (3218) 10130 (2966)
0 (-17.8) 50110 (14672) 47880 (14019) 45640 (13363) 43400 (12708) 41130 (12043) 38840 (11372)

-5 (-20.6) 45110 (13208) 43090 (12617) 41080 (12028) 39060 (11437) 37030 (10842) 34980 (10242)

-10 (-23.3) 40380 (11823) 38560 (11290) 36760 (10763) 34950 (10233) 33130 (9700) 31300 (9165)

-15 (-26.1) 35930 (10520) 34300 (10043) 32680 (9569) 31060 (9094) 29440 (8620) 27810 (8143)

-20 (-28.9) 31760 (9299) 30290 (8869) 28840 (8444) 27390 (8020) 25950 (7598) 24510 (7177)

-25 (-31.7) 27880 (8163) 26540 (7771) 25230 (7387) 23940 (7010) 22660 (6635) 21380 (6260)

-30 (-34.4) 24270 (7106) 23050 (6749) 21860 (6401) 20700 (6061) 19560 (5727) 18420 (5393)

-35 (-37.2) 20920 (6125) 19800 (5797) 18710 (5478) 17660 (5171) 16630 (4869) 15620 (4574)

-40 (-40.0) 17830 (5221) 16790 (4916) 15780 (4620) 14820 (4339) 13880 (4064) 12960 (3795)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 40.6) 110 (43.3)

R404A R507

10 (6767) 21870 (6404) 20620 (6038) 19370 (5672)

AMBIENT TEMPERATURE °F (°C)

8560 (2506) 7710 (2257)

table continues on next page >>>

BESA

10/22/12

B40-BES-PDS-60-9

- 14 -

COPELAND

CAPACITY DATA -

R404A

LOW TEMPERATURE (cont’d)

R507

60Hz

CONDENSING

UNIT

MODEL

BESA061L6

Compressor

Model

3DA3F28KE

BESA075L6

Compressor

Model

3DB3F33KE

BESA090L6

Compressor

Model

3DF3F40KE

BESA100L6

Compressor

Model

3DSF46KE

BESA130L6

Compressor

Model

4DBNF54KE

BESA150L6

Compressor

Model

4DHNF63KE

BESA220L6

Compressor

Model

4DJNF76KE

--- Outside Operating Range

SATURATED SUC-

TION

TEMPERATURE

° F ° C

0 (-17.8) 54630 (15996) 52300 (15313) 49990 (14637) 47670 (13958) 45330 (13273) 42960 (12579)

-5 (-20.6) 49260 (14423) 47180 (13814) 45110 (13208) 43040 (12602) 40930 (11984) 38780 (11355)

-10 (-23.3) 44170 (12933) 42320 (12391) 40480 (11853) 38620 (11308) 36730 (10755) 34780 (10184)

-15 (-26.1) 39380 (11530) 37740 (11050) 36100 (10570) 34430 (10081) 32720 (9580) 30960 (9065)

-20 (-28.9) 34900 (10219) 33440 (9791) 31980 (9364) 30480 (8925) 28940 (8474) 27320 (7999)

-25 (-31.7) 30750 (9004) 29450 (8623) 28140 (8239) 26790 (7844) 25370 (7428) 23880 (6992)

-30 (-34.4) 26940 (7888) 25770 (7545) 24580 (7197) 23340 (6834) 22030 (6450) 20640 (6043)

-35 (-37.2) 23470 (6872) 22410 (6562) 21310 (6240) 20160 (5903) 18930 (5543) 17600 (5153)

-40 (-40.0) 20360 (5961) 19370 (5672) 18330 (5367) 17230 (5045) 16040 (4697) 14760 (4322)
0 (-17.8) 62460 (18288) 59770 (17501) 57110 (16722) 54480 (15952) 51870 (15188) --- ---

-5 (-20.6) 56450 (16529) 54060 (15829) 51690 (15135) 49340 (14447) 47010 (13765) --- ---

-10 (-23.3) 50770 (14865) 48660 (14248) 46550 (13630) 44460 (13018) 42380 (12409) 40300 (11800)

-15 (-26.1) 45440 (13305) 43560 (12754) 41700 (12210) 39830 (11662) 37960 (11115) 36090 (10567)

-20 (-28.9) 40440 (11841) 38780 (11355) 37120 (10869) 35450 (10380) 33760 (9885) 32070 (9390)

-25 (-31.7) 35780 (10476) 34300 (10043) 32810 (9607) 31300 (9165) 29760 (8714) 28210 (8260)

-30 (-34.4) 31450 (9209) 30120 (8819) 28760 (8421) 27370 (8014) 25950 (7598) 24500 (7174)

-35 (-37.2) 27430 (8032) 26210 (7674) 24950 (7305) 23650 (6925) 22300 (6529) 20920 (6125)

-40 (-40.0) 23720 (6945) 22560 (6606) 21360 (6254) 20100 (5885) 18800 (5505) 17440 (5106)

0 (-17.8) 79100 (23183) 75800 (22216) 72600 (21278) 69400 (20340) 66200 (19402) 63000 (18464)

-5 (-20.6) 71200 (20868) 68300 (20018) 65400 (19168) 62500 (18318) 59600 (17468) 56700 (16618)

-10 (-23.3) 63700 (18669) 61100 (17907) 58500 (17145) 56000 (16413) 53400 (15651) 50800 (14889)

-15 (-26.1) 56700 (16618) 54400 (15944) 52200 (15299) 49900 (14625) 47600 (13951) 45300 (13277)

-20 (-28.9) 50300 (14742) 48200 (14127) 46200 (13540) 44100 (12925) 42100 (12339) 40000 (11723)

-25 (-31.7) 44300 (12984) 42400 (12427) 40600 (11899) 38800 (11372) 37000 (10844) 35100 (10287)

-30 (-34.4) 38700 (11342) 37100 (10873) 35500 (10404) 33800 (9906) 32200 (9437) 30500 (8939)

-35 (-37.2) 33700 (9877) 32200 (9437) 30700 (8998) 29200 (8558) 27700 (8118) 26100 (7649)

-40 (-40.0) 29100 (8529) 27700 (8118) 26400
0 (-17.8) 86100 (25234) 82500 (24179) 78800 (23095) 75200 (22040) 71600 (20985) 68000 (19930)

-5 (-20.6) 78000 (22860) 74800 (21923) 71500 (20955) 68200 (19988) 64900 (19021) 61700 (18083)

-10 (-23.3) 70300 (20604) 67400 (19754) 64500 (18904) 61500 (18025) 58500 (17145) 55600 (16295)

-15 (-26.1) 63000 (18464) 60400 (17702) 57800 (16940) 55100 (16149) 52400 (15358) 49800 (14596)

-20 (-28.9) 56200 (16471) 53800 (15768) 51400 (15064) 49000 (14361) 46600 (13658) 44200 (12954)

-25 (-31.7) 49700 (14566) 47600 (13951) 45400 (13306) 43200 (12661) 41000 (12016) 38900 (11401)

-30 (-34.4) 43600 (12778) 41800 (12251) 39800 (11665) 37800 (11079) 35800 (10492) 33800 (9906)

-35 (-37.2) 38100 (1

-40 (-40.0) 33000 (9672) 31400 (9203) 29700 (8705) 28000 (8206) 26300 (7708) 24500 (7181)

0 (-17.8) 102500 (30040) 98100 (28750) 93800 (27490) 89500 (26230) 85200 (24970) 80800 (23680)

-5 (-20.6) 91900 (26930) 88000 (25790) 84200 (24680) 80400 (23560) 76600 (22450) 72700 (21310)

-10 (-23.3) 82300 (24120) 78900 (23120) 75500 (22130) 72100 (21130) 68700 (20130) 65200 (19110)

-15 (-26.1) 73500 (21540) 70400 (20630) 67400 (19750) 64400 (18870) 61300 (17970) 58100 (17030)

-20 (-28.9) 65400 (19170) 62700 (18380) 60000 (17580) 57200 (16760) 54400 (15940) 51400 (15060)

-25 (-31.7) 57900 (16970) 55500 (16270) 53000 (15530) 50400 (14770) 47800 (14010) 45000 (13190)

-30 (-34.4) 50900 (14920) 48600 (14240) 46300 (13570) 43900 (12870) 41400 (12130) 38700 (11340)

-35 (-37.2) 44200 (12950) 42000 (12310) 39800 (11660) 37400 (10960) 34900 (10230) 32300 (9470)

-40 (-40.0) 37700 (11050) 35500 (10400) 33300 (9760) 30900 (9060) 28400 (8320) 25700 (7530)

0 (-17.8) 118300 (34670) 113000 (33120) 107700 (31560) 102700 (30100) 97800 (28660) 93100 (27280)

-5 (-20.6) 107200 (31420) 102200 (29950) 97400 (28550) 92700 (27170) 88200 (25850) 83900 (24590)

-10 (-23.3) 96800 (28370) 92200 (27020) 87700 (25700) 83400 (24440) 79300 (23240) 75400 (22100)

-15 (-26.1) 87100 (25530) 82800 (24270) 78700 (23060) 74800 (21920) 71000 (20810) 67400 (19750)

-20 (-28.9) 78000 (22860) 74100 (21720) 70300 (20600) 66700 (19550) 63200 (18520) 59900 (17550)

-25 (-31.7) 69400 (20340) 65800 (19280) 62300 (18260) 58900 (17260) 55800 (16350) 52800 (15470)

-30 (-34.4) 61200 (17940) 57800 (16940) 54600 (16000) 51500 (15090) 48600 (14240) 45900 (13450)

-35 (-37.2) 53200 (15590) 50100 (14680) 47100 (13800) 44300 (12980) 41600 (12190) 39100 (11460)

-40 (-40.0) 45500 (13330) 42600 (12480) 39800 (11660) 37100 (10870) 34700 (10170) 32300 (9470)
0 (-17.8) 136300 (39936) 130000 (38090) 124000 (36332) 118200 (34633) 112600 (32992) 107300 (31439)

-5 (-20.6) 124400 (36449) 118600 (34750) 1

-10 (-23.3) 113000 (33109) 107700 (31556) 102700 (30091) 97700 (28626) 92900 (27220) 88200 (25843)

-15 (-26.1) 102100 (29915) 97300 (28509) 92600 (27132) 88100 (25813) 83600 (24495) 79200 (23206)

-20 (-28.9) 91600 (26839) 87300 (25579) 83000 (24319) 78800 (23088) 74700 (21887) 70500 (20657)

-25 (-31.7) 81600 (23909) 77700 (22766) 73800 (21623) 69900 (20481) 66000 (19338) 62000 (18166)

-30 (-34.4) 71900 (21067) 68400 (20041) 64800 (18986) 61200 (17932) 57500 (16848) 53700 (15734)

-35 (-37.2) 62600 (18342) 59400 (17404) 56100 (16437) 52700 (15441) 49100 (14386) 45500 (13332)

-40 (-40.0) 53500 (15676) 50600 (14826) 47500 (13918) 44300 (12980) 40900 (11984) 37300 (10929)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

1166) 36400 (10668) 34600 (10141) 32800 (9613) 30900 (9056) 29000 (8499)

R404A R507

(7737) 24900 (7298) 23500 (6887) 22100 (6477)

13100 (33138) 107700 (31556) 102600 (30062) 97600 (28597)

AMBIENT TEMPERATURE °F (°C)

BESB

10/22/12

B40-BES-PDS-60-9

- 15 -

BITZER

CAPACITY DATA -

R22

HIGH / MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESB010H8

Compressor

Model

2C0173SH

BESB015H8

Compressor

Model

2C0222SH

BESB020H8

Compressor

Model

2C0278SH

BESB025H8

Compressor

Model

2C0323SH

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 15600 (4570) 15100 (4430) 14500 (4250) 14000 (4100) 13400 (3930) 12900 (3780)
40 (4.4) 14200 (4160) 13700 (4020) 13200 (3870) 12700 (3720) 12200 (3580) 11700 (3430)
35 (1.7) 12900 (3780) 12400 (3630) 11900 (3490) 11500 (3370) 11000 (3220) 10600 (3110)
30 (-1.1) 11600 (3400) 11200 (3280) 10800 (3170) 10300 (3020) 9900 (2900) 9500 (2780)
25 (-3.9) 10400 (3050) 10000 (2930) 9600 (2810) 9200 (2700) 8800 (2580) 8500 (2490)
20 (-6.7) 9300 (2730) 8900 (2610) 8500 (2490) 8200 (2400) 7800 (2290) 7500 (2200)
15 (-9.4) 8200 (2400) 7900 (2320) 7500 (2200) 7200 (2110) 6900 (2020) 6600 (1930)
10 (-12.2) 7200 (2110) 6900 (2020) 6600 (1930) 6300 (1850) 6000 (1760) 5700 (1670)

5 (-15.0) 6300 (1850) 6000 (1760) 5700 (1670) 5400 (1580) 5200 (1520) 4900 (1440)
45 (7.2) 20100 (5890) 19400 (5690) 18700 (5480) 18000 (5280) 17300 (5070) 16600 (4860)
40 (4.4) 18400 (5390) 17700 (5190) 17100 (5010) 16400 (4810) 15800 (4630) 15100 (4430)
35 (1.7) 16700 (4890) 16100 (4720) 15500 (4540) 14900 (4370) 14300 (4190) 13700 (4020)
30 (-1.1) 15100 (4430) 14600 (4280) 14000 (4100) 13500 (3960) 12900 (3780) 12400 (3630)
25 (-3.9) 13600 (3990) 13100 (3840) 12600 (3690) 12100 (3550) 11600 (3400) 11100 (3250)
20 (-6.7) 12300 (3600) 11800 (3460) 11300 (3310) 10800 (3170) 10400 (3050) 9900 (2900)
15 (-9.4) 10900 (3190) 10500 (3080) 10100 (2960) 9700 (2840) 9200 (2700) 8800 (2580)
10 (-12.2) 9700 (2840) 9300 (2730) 8900 (2610) 8500 (2490) 8200 (2400) 7800 (2290)

5 (-15.0) 8600 (2520) 8200 (2400) 7900 (2320) 7500 (2200) 7200 (2110) 6800 (1990)
45 (7.2) 24500 (7180) 23700 (6950) 22800 (6680) 21900 (6420) 21100 (6180) 20200 (5920)
40 (4.4) 22500 (6590) 21700 (6360) 20900 (6130) 20100 (5890) 19300 (5660) 18500 (5420)
35 (1.7) 20600 (6040) 19800 (5800) 19100 (5600) 18400 (5390) 17600 (5160) 16900 (4950)
30 (-1.1) 18700 (5480) 18100 (5300) 17400 (5100) 16700 (4890) 16100 (4720) 15400 (4510)
25 (-3.9) 17000 (4980) 16400 (4810) 15700 (4600) 15100 (4430) 14600 (4280) 14000 (4100)
20 (-6.7) 15400 (4510) 14800 (4340) 14200 (4160) 13700 (4020) 13100 (3840) 12600 (3690)
15 (-9.4) 13800 (4040) 13300 (3900) 12800 (3750) 12300 (3600) 11800 (3460) 11300 (3310)
10 (-12.2) 12300 (3600) 11900 (3490) 11400 (3340) 11000 (3220) 10500 (3080) 10100 (2960)

5 (-15.0) 11000 (3220) 10600 (3110) 10100 (2960)
45 (7.2) 29100 (8530) 28100 (8240) 27100 (7940) 26100 (7650) 25100 (7360) 24100 (7060)
40 (4.4) 26700 (7820) 25700 (7530) 24800 (7270) 23900 (7000) 23000 (6740) 22100 (6480)
35 (1.7) 24400 (7150) 23500 (6890) 22700 (6650) 21800 (6390) 21000 (6150) 20200 (5920)
30 (-1.1) 22200 (6510) 21400 (6270) 20700 (6070) 19900 (5830) 19100 (5600) 18400 (5390)
25 (-3.9) 20100 (5890) 19400 (5690) 18700 (5480) 18000 (5280) 17400 (5100) 16700 (4890)
20 (-6.7) 18200 (5330) 17600 (5160) 16900 (4950) 16300 (4780) 15700 (4600) 15100 (4430)
15 (-9.4) 16400 (4810) 15800 (4630) 15200 (4450) 14600 (4280) 14100 (4130) 13500 (3960)
10 (-12.2) 14700 (4310) 14100 (4130) 13600 (3990) 13100 (3840) 12600 (3690) 12100 (3550)

5 (-15.0) 13100 (3840) 12600 (3690) 12100 (3550) 11600 (3400) 11200 (3280) 10800 (3170)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

AMBIENT TEMPERATURE °F (°C)

R22

9700 (2840) 9300 (2730) 8900 (2610)

--- Outside Operating Range

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 16 -

BITZER

CAPACITY DATA -

R22

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB029H8

Compressor

Model

2C0407SH

BESB030H8

Compressor

Model

2C0484SH

BESB035H8

Compressor

Model

2C0572SH

BESB040H8

Compressor

Model

2C0692SH

BESB050H8

Compressor

Model

4C0770SH

BESB060H8

Compressor

Model

4C0969SH

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 36800 (10780) 35500 (10400) 34300 (10050) 33100 (9700) 31800 (9320) 30600 (8970)
40 (4.4) 33700 (9880) 32500 (9520) 31300 (9170) 30200 (8850) 29100 (8530) 27900 (8180)
35 (1.7) 30700 (9000) 29600 (8670) 28600 (8380) 27500 (8060) 26500 (7770) 25400 (7440)
30 (-1.1) 27900 (8180) 26900 (7880) 25900 (7590) 25000 (7330) 24000 (7030) 23100 (6770)
25 (-3.9) 25300 (7410) 24400 (7150) 23500 (6890) 22600 (6620) 21700 (6360) 20800 (6100)
20 (-6.7) 22800 (6680) 22000 (6450) 21200 (6210) 20400 (5980) 19600 (5740) 18800 (5510)
15 (-9.4) 20500 (6010) 19800 (5800) 19000 (5570) 18300 (5360) 17500 (5130) 16800 (4920)
10 (-12.2) 18400 (5390) 17700 (5190) 17000 (4980) 16300 (4780) 15700 (4600) 15000 (4400)

5 (-15.0) 16400 (4810) 15800 (4630) 15100 (4430) 14500 (4250) 13900 (4070) 13300 (3900)
45 (7.2) 43100 (12630) 41600 (12190) 40200 (11780) 38700 (11340) 37300 (10930) 35800 (10490)
40 (4.4) 39400 (11550) 38100 (11170) 36700 (10760) 35300 (10350) 34000 (9960) 32600 (9550)
35 (1.7) 35900 (10520) 34700 (10170) 33400 (9790) 32100 (9410) 30900 (9060) 29600 (8670)
30 (-1.1) 32700 (9580) 31500 (9230) 30300 (8880) 29100 (8530) 27900 (8180) 26800 (7850)
25 (-3.9) 29600 (8670) 28500 (8350) 27400 (8030) 26300 (7710) 25200 (7390) 24100 (7060)
20 (-6.7) 26700 (7820) 25700 (7530) 24600 (7210) 23600 (6920) 22600 (6620) 21600 (6330)
15 (-9.4) 24000 (7030) 23000 (6740) 22100 (6480) 21100 (6180) 20200 (5920) 19300 (5660)
10 (-12.2) 21500 (6300) 20600 (6040) 19700 (5770) 18800 (5510) 17900 (5250) 17100 (5010)

5 (-15.0) 19100 (5600) 18300 (5360) 17500 (5130) 16600 (4860) 15800 (4630) 15000 (4400)
45 (7.2) 52200 (15300) 50400 (14770) 48700 (14270) 46900 (13740) 45100 (13220) 43400 (12720)
40 (4.4) 47700 (13980) 46100 (13510) 44400 (13010) 42700 (12510) 41100 (12050) 39500 (11580)
35 (1.7) 43500 (12750) 41900 (12280) 40400 (11840) 38900 (11400) 37300 (10930) 35800 (10490)
30 (-1.1) 39500 (11580) 38100 (11170) 36600 (10730) 35200 (10320) 33800 (9910) 32300 (9470)
25 (-3.9) 35800 (10490) 34400 (10080) 33100 (9700) 31700 (9290) 30400 (8910) 29100 (8530)
20 (-6.7) 32200 (9440) 31000 (9090) 29800 (8730) 28500 (8350) 27300 (8000) 26100 (7650)
15 (-9.4) 28900 (8470) 27800 (8150) 26700 (7820) 25500 (7470) 24400 (7150) 23200 (6800)
10 (-12.2) 25900 (7590) 24800 (7270) 23800 (6980) 22700 (6650) 21600 (6330) 20600 (6040)

5 (-15.0) 23000 (6740) 22000 (6450) 21100 (6180)
45 (7.2) 61900 (18140) 59700 (17500) 57500 (16850) 55300 (16210) 53100 (15560) 50900 (14920)
40 (4.4) 56800 (16650) 54700 (16030) 52700 (15440) 50600 (14830) 48600 (14240) 46500 (13630)
35 (1.7) 52000 (15240) 50000 (14650) 48100 (14100) 46200 (13540) 44300 (12980) 42400 (12430)
30 (-1.1) 47400 (13890) 45600 (13360) 43800 (12840) 42000 (12310) 40200 (11780) 38400 (11250)
25 (-3.9) 43000 (12600) 41300 (12100) 39700 (11630) 38000 (1
20 (-6.7) 38900 (11400) 37400 (10960) 35800 (10490) 34300 (10050) 32700 (9580) 31200 (9140)
15 (-9.4) 35100 (10290) 33600 (9850) 32200 (9440) 30800 (9030) 29300 (8590) 27900 (8180)
10 (-12.2) 31500 (9230) 30200 (8850) 28800 (8440) 27500 (8060) 26200 (7680) 24800 (7270)

5 (-15.0) 28200 (8260) 26900 (7880) 25700 (7530) 24400 (7150) 23200 (6800) 21900 (6420)
45 (7.2) 73700 (21600) 71200 (20870) 68800 (20160) 66400 (19460) 63900 (18730) 61500 (18020)
40 (4.4) 67300 (19720) 65000 (19050) 62800 (18400) 60500 (17730) 58200 (17060) 56000 (16410)
35 (1.7) 61300 (17970) 59100 (17320) 57100 (16730) 55000 (16120) 52900 (15500) 50800 (14890)
30 (-1.1) 55600 (16290) 53600 (15710) 51700 (15150) 49700 (14570) 47800 (14010) 45800 (13420)
25 (-3.9) 50200 (14710) 48400 (14180) 46600 (13660) 44800 (13130) 43000 (12600) 41200 (12070)
20 (-6.7) 45200 (13250) 43600 (12780) 41900 (12280) 40200 (11780) 38600 (11310) 36900 (10810)
15 (-9.4) 40500 (11870) 39000 (11430) 37500 (10990) 35900 (10520) 34400 (10080) 32900 (9640)
10 (-12.2) 36100 (10580) 34700 (10170) 33300 (9760) 31900 (9350) 30500 (8940) 29100 (8530)

5 (-15.0) 32100 (9410) 30800 (9030) 29500 (8650) 28200 (8260) 26900 (7880) 25500 (7470)
45 (7.2) 87200 (25560) 84200 (24680) 81200 (23800) 78200 (22920) 75200 (22040) 72200 (21160)
40 (4.4) 79900 (23420) 77100 (22600) 74300 (21780) 71600 (20980) 68700 (20130) 65900 (19310)
35 (1.7) 73000 (21390) 70400 (20630) 67800 (19870) 65200 (19110) 62600 (18350) 60000 (17580)
30 (-1.1) 66400 (19460) 64000 (18760) 61600 (18050) 59200 (17350) 56800 (16650) 54400 (15940)
25 (-3.9) 60200 (17640) 58000 (17000) 55800 (16350) 53600 (15710) 51300 (15030) 49100 (14390)
20 (-6.7) 54400 (15940) 52400 (15360) 50300 (14740) 48200 (14130) 46200 (13540) 44100 (12920)
15 (-9.4) 48900 (14330) 47100 (13800) 45100 (13220) 43200 (12660) 41300 (12100) 39400 (11550)
10 (-12.2) 43800 (12840) 42100 (12340) 40300 (11810) 38500 (11280) 36800 (10780) 35000 (10260)

5 (-15.0) 39000 (11430) 37400 (10960) 35800 (10490) 34100 (9990) 32500 (9520) 30800 (9030)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

AMBIENT TEMPERATURE °F (°C)

R22

20100 (5890) 19100 (5600) 18100 (5300)

1140) 36400 (10670) 34700 (10170)

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 17 -

BITZER

CAPACITY DATA -

R22

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB076H8

Compressor

Model

4C1145SH

BESB090H8

Compressor

Model

4C1385SH

BESB100H8

Compressor

Model

4C1480SH

BESB120H8

Compressor

Model

4C1761SH

BESB150H8

Compressor

Model

4C2067SH

BESB200H8

Compressor

Model

4C2397SH

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 109800 (32180) 106100 (31090) 102500 (30040) 98800 (28960) 95200 (27900) 91500 (26820)
40 (4.4) 100400 (29420) 97000 (28430) 93600 (27430) 90200 (26430) 86800 (25440) 83400 (24440)
35 (1.7) 91500 (26820) 88300 (25880) 85200 (24970) 82100 (24060) 78900 (23120) 75800 (22210)
30 (-1.1) 83100 (24350) 80200 (23500) 77300 (22650) 74400 (21800) 71500 (20950) 68600 (20100)
25 (-3.9) 75200 (22040) 72500 (21250) 69800 (20460) 67100 (19660) 64500 (18900) 61800 (18110)
20 (-6.7) 67800 (19870) 65300 (19140) 62800 (18400) 60400 (17700) 57900 (16970) 55400 (16240)
15 (-9.4) 60800 (17820) 58600 (17170) 56300 (16500) 54000 (15830) 51700 (15150) 49400 (14480)
10 (-12.2) 54400 (15940) 52300 (15330) 50200 (14710) 48100 (14100) 46000 (13480) 43800 (12840)

5 (-15.0) 48300 (14160) 46400 (13600) 44500 (13040) 42500 (12460) 40600 (11900) 38600 (11310)
45 (7.2) 127700 (37430) 123500 (36190) 119200 (34930) 115000 (33700) 110800 (32470) 106500 (31210)
40 (4.4) 117000 (34290) 113100 (33150) 109200 (32000) 105200 (30830) 101300 (29690) 97400 (28550)
35 (1.7) 106900 (31330) 103300 (30270) 99600 (29190) 96000 (28130) 92300 (27050) 88700 (26000)
30 (-1.1) 97300 (28520) 94000 (27550) 90600 (26550) 87200 (25560) 83800 (24560) 80400 (23560)
25 (-3.9) 88300 (25880) 85200 (24970) 82100 (24060) 78900 (23120) 75800 (22210) 72600 (21280)
20 (-6.7) 79800 (23390) 76900 (22540) 74000 (21690) 71100 (20840) 68200 (19990) 65300 (19140)
15 (-9.4) 71800 (21040) 69200 (20280) 66500 (19490) 63800 (18700) 61100 (17910) 58400 (17120)
10 (-12.2) 64400 (18870) 61900 (18140) 59400 (17410) 57000 (16700) 54500 (15970) 52000 (15240)

5 (-15.0) 57400 (16820) 55100 (16150) 52800 (15470) 50600 (14830) 48200 (14130) 45900 (13450)
45 (7.2) 136700 (40060) 132100 (38710) 127500 (37370) 122900 (36020) 118500 (34730) 114100 (33440)
40 (4.4) 125700 (36840) 121300 (35550) 117100 (34320) 112900 (33090) 108700 (31860) 104700 (30680)
35 (1.7) 115100 (33730) 111100 (32560) 107200 (31420) 103300 (30270) 99500 (29160) 95700 (28050)
30 (-1.1) 105100 (30800) 101400 (29720) 97800 (28660) 94200 (27610) 90700 (26580) 87300 (25590)
25 (-3.9) 95600 (28020) 92200 (27020) 88900 (26050) 85600 (25090) 82400 (24150) 79200 (23210)
20 (-6.7) 86700 (25410) 83600 (24500) 80500 (23590) 77500 (22710) 74600 (21860) 71700 (21010)
15 (-9.4) 78200 (22920) 75400 (22100) 72600 (21280) 69900 (20490) 67200 (19690) 64500 (18900)
10 (-12.2) 70300 (20600) 67700 (19840) 65200 (19110) 62700 (18380) 60200 (17640) 57800 (16940)

5 (-15.0) 62800 (18400) 60500 (17730) 58200 (17060)
45 (7.2) 171500 (50260) 165700 (48560) 160000 (46890) 154300 (45220) 148600 (43550) 143100 (41940)
40 (4.4) 157200 (46070) 151900 (44520) 146600 (42960) 141300 (41410) 136100 (39890) 131000 (38390)
35 (1.7) 143700 (42110) 138800 (40680) 133900 (39240) 129000 (37810) 124200 (36400) 119500 (35020)
30 (-1.1) 130900 (38360) 126400 (37040) 121900 (35730) 117400 (34410) 1
25 (-3.9) 118900 (34850) 114700 (33620) 110600 (32410) 106500 (31210) 102500 (30040) 98500 (28870)
20 (-6.7) 107500 (31510) 103700 (30390) 100000 (29310) 96200 (28190) 92600 (27140) 89000 (26080)
15 (-9.4) 96900 (28400) 93400 (27370) 90000 (26380) 86600 (25380) 83300 (24410) 80000 (23450)
10 (-12.2) 86900 (25470) 83800 (24560) 80700 (23650) 77600 (22740) 74500 (21830) 71600 (20980)

5 (-15.0) 77600 (22740) 74800 (21920) 71900 (21070) 69100 (20250) 66400 (19460) 63700 (18670)
45 (7.2) 199400 (58440) 192700 (56470) 186100 (54540) 179600 (52640) 173200 (50760) 166800 (48880)
40 (4.4) 183000 (53630) 176900 (51840) 170800 (50060) 164800 (48300) 158800 (46540) 152900 (44810)
35 (1.7) 167500 (49090) 161800 (47420) 156200 (45780) 150600 (44140) 145100 (42520) 139800 (40970)
30 (-1.1) 152700 (44750) 147500 (43230) 142300 (41700) 137200 (40210) 132200 (38740) 127300 (37310)
25 (-3.9) 138700 (40650) 133900 (39240) 129200 (37860) 124600 (36520) 120000 (35170) 115500 (33850)
20 (-6.7) 125500 (36780) 121200 (35520) 116900 (34260) 112600 (33000) 108400 (31770) 104300 (30570)
15 (-9.4) 113100 (33150) 109200 (32000) 105200 (30830) 101300 (29690) 97500 (28570) 93800 (27490)
10 (-12.2) 101500 (29750) 97900 (28690) 94300 (27640) 90800 (26610) 87300 (25590) 84000 (24620)

5 (-15.0) 90600 (26550) 87300 (25590) 84100 (24650) 80900 (23710) 77800 (22800) 74700 (21890)
45 (7.2) 224200 (65710) 216600 (63480) 209200 (61310) 201700 (59110) 194400 (56970) 187100 (54830)
40 (4.4) 206200 (60430) 199200 (58380) 192300 (56360) 185400 (54340) 178600 (52340) 171900 (50380)
35 (1.7) 189100 (55420) 182600 (53510) 176200 (51640) 169900 (49790) 163600 (47950) 157400 (46130)
30 (-1.1) 172700 (50610) 166800 (48880) 160900 (47150) 155100 (45460) 149300 (43760) 143600 (42080)
25 (-3.9) 157200 (46070) 151800 (44490) 146300 (42880) 141000 (41320) 135700 (39770) 130500 (38250)
20 (-6.7) 142500 (41760) 137500 (40300) 132500 (38830) 127600 (37400) 122800 (35990) 118100 (34610)
15 (-9.4) 128700 (37720) 124100 (36370) 119500 (35020) 115000 (33700) 110600 (32410) 106300 (31150)
10 (-12.2) 115600 (33880) 111400 (32650) 107200 (31420) 103200 (30240) 99100 (29040) 95200 (27900)

5 (-15.0) 103300 (30270) 99500 (29160) 95700 (28050) 92000 (26960) 88300 (25880) 84800 (24850)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

AMBIENT TEMPERATURE °F (°C)

R22

55900 (16380) 53700 (15740) 51500 (15090)

13000 (33120) 108700 (31860)

--- Outside Operating Range

BESB

10/22/12

B40-BES-PDS-60-9

- 18 -

BITZER

CAPACITY DATA -

R404A

R507

HIGH / MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESB010H8

Compressor

Model

2C0173SH

BESB015H8

Compressor

Model

2C0222SH

BESB020H8

Compressor

Model

2C0278SH

BESB025H8

Compressor

Model

2C0323SH

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

40 (4.4) 14100 (4130) 13400 (3930) 12700 (3720) 12000 (3520) 11300 (3310) 10600 (3110)
35 (1.7) 13000 (3810) 12300 (3600) 11600 (3400) 11000 (3220) 10300 (3020) 9700 (2840)
30 (-1.1) 11900 (3490) 11200 (3280) 10600 (3110) 10000 (2930) 9400 (2750) 8800 (2580)
25 (-3.9) 10800 (3170) 10200 (2990) 9700 (2840) 9100 (2670) 8500 (2490) 8000 (2340)
20 (-6.7) 9800 (2870) 9300 (2730) 8700 (2550) 8200 (2400) 7700 (2260) 7200 (2110)
15 (-9.4) 8800 (2580) 8300 (2430) 7800 (2290) 7400 (2170) 6900 (2020) 6500 (1900)
10 (-12.2) 7900 (2320) 7400 (2170) 7000 (2050) 6600 (1930) 6200 (1820) 5800 (1700)

5 (-15.0) 7000 (2050) 6600 (1930) 6200 (1820) 5800 (1700) 5500 (1610) 5100 (1490)
0 (-17.8) 6200 (1820) 5800 (1700) 5500 (1610) 5100 (1490) 4800 (1410) 4500 (1320)

-5 (-20.6) 5400 (1580) 5100 (1490) 4800 (1410) 4500 (1320) 4200 (1230) 3900 (1140)
40 (4.4) 19700 (5770) 18800 (5510) 17800 (5220) 16900 (4950) 16000 (4690) 15000 (4400)
35 (1.7) 18100 (5300) 17200 (5040) 16300 (4780) 15500 (4540) 14600 (4280) 13700 (4020)
30 (-1.1) 16500 (4840) 15700 (4600) 14900 (4370) 14100 (4130) 13300 (3900) 12500 (3660)
25 (-3.9) 15000 (4400) 14300 (4190) 13500 (3960) 12800 (3750) 12100 (3550) 11400 (3340)
20 (-6.7) 13600 (3990) 12900 (3780) 12300 (3600) 11600 (3400) 10900 (3190) 10300 (3020)
15 (-9.4) 12300 (3600) 11600 (3400) 11000 (3220) 10400 (3050) 9800 (2870) 9200 (2700)
10 (-12.2) 11000 (3220) 10400 (3050) 9900 (2900) 9300 (2730) 8800 (2580) 8200 (2400)

5 (-15.0) 9800 (2870) 9300 (2730) 8800 (2580) 8300 (2430) 7800 (2290) 7300 (2140)
0 (-17.8) 8700 (2550) 8200 (2400) 7800 (2290) 7300 (2140) 6900 (2020) 6400 (1880)

-5 (-20.6) 7700 (2260) 7200 (2110) 6800 (1990) 6400 (1880) 6000 (1760) 5600 (1640)
40 (4.4) 23800 (6980) 22700 (6650) 21500 (6300) 20400 (5980) 19200 (5630) 18100 (5300)
35 (1.7) 21900 (6420) 20900 (6130) 19800 (5800) 18800 (5510) 17700 (5190) 16700 (4890)
30 (-1.1) 20100 (5890) 19200 (5630) 18200 (5330) 17200 (5040) 16200 (4750) 15300 (4480)
25 (-3.9) 18400 (5390) 17500 (5130) 16600 (4860) 15700 (4600) 14800 (4340) 13900 (4070)
20 (-6.7) 16700 (4890) 15900 (4660) 15100 (4430) 14300 (4190) 13500 (3960) 12600 (3690)
15 (-9.4) 15200 (4450) 14400 (4220) 13600 (3990) 12900 (3780) 12200 (3580) 11400 (3340)
10 (-12.2) 13600 (3990) 13000 (3810) 12300

5 (-15.0) 12200 (3580) 11600 (3400) 11000 (3220) 10400 (3050) 9800 (2870) 9100 (2670)
0 (-17.8) 10900 (3190) 10300 (3020) 9800 (2870) 9200 (2700) 8600 (2520) 8100 (2370)

-5 (-20.6) 9600 (2810) 9100 (2670) 8600 (2520) 8100 (2370) 7600 (2230) 7100 (2080)
40 (4.4) 27700 (8120) 26400 (7740) 25100 (7360) 23800 (6980) 22500 (6590) 21200 (6210)
35 (1.7) 25500 (7470) 24300 (7120) 23100 (6770) 21900 (6420) 20700 (6070) 19500 (5710)
30 (-1.1) 23400 (6860) 22300 (6540) 21200 (6210) 20000 (5860) 18900 (5540) 17800 (5220)
25 (-3.9) 21400 (6270) 20300 (5950) 19300 (5660) 18300 (5360) 17300 (5070) 16300 (4780)
20 (-6.7) 19500 (5710) 18500 (5420) 17600 (5160) 16600 (4860) 15700 (4600) 14800 (4340)
15 (-9.4) 17600 (5160) 16800 (4920) 15900 (4660) 15100 (4430) 14200 (4160) 13400 (3930)
10 (-12.2) 15900 (4660) 15100 (4430) 14300 (4190) 13600 (3990) 12800 (3750) 12000 (3520)

5 (-15.0) 14300 (4190) 13500 (3960) 12800 (3750) 12100 (3550) 1
0 (-17.8) 12700 (3720) 12100 (3550) 11400 (3340) 10800 (3170) 10200 (2990) 9600 (2810)

-5 (-20.6) 11300 (3310) 10700 (3140) 10100 (2960) 9600 (2810) 9000 (2640) 8500 (2490)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

R404A R507

(3600) 11600 (3400) 10900 (3190) 10200 (2990)

AMBIENT TEMPERATURE °F (°C)

1500 (3370) 10800 (3170)

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 19 -

BITZER

CAPACITY DATA -

R404A

R507

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB029H8

Compressor

Model

2C0407SH

BESB030H8

Compressor

Model

2C0484SH

BESB035H8

Compressor

Model

2C0572SH

BESB040H8

Compressor

Model

2C0692SH

BESB050H8

Compressor

Model

4C0770SH

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C
40 (4.4) 36700 (10760) 35000 (10260) 33300 (9760) 31600 (9260) 29900 (8760) 28200 (8260)

35 (1.7) 33700 (9880) 32200 (9440) 30600 (8970) 29000 (8500) 27400 (8030) 25900 (7590)
30 (-1.1) 30800 (9030) 29400 (8620) 28000 (8210) 26500 (7770) 25100 (7360) 23600 (6920)
25 (-3.9) 28100 (8240) 26800 (7850) 25500 (7470) 24100 (7060) 22800 (6680) 21500 (6300)
20 (-6.7) 25500 (7470) 24300 (7120) 23100 (6770) 21900 (6420) 20700 (6070) 19500 (5710)
15 (-9.4) 23000 (6740) 21900 (6420) 20800 (6100) 19700 (5770) 18700 (5480) 17600 (5160)
10 (-12.2) 20700 (6070) 19700 (5770) 18700 (5480) 17700 (5190) 16700 (4890) 15800 (4630)

5 (-15.0) 18500 (5420) 17600 (5160) 16700 (4890) 15800 (4630) 15000 (4400) 14100 (4130)

0 (-17.8) 16500 (4840) 15700 (4600) 14900 (4370) 14100 (4130) 13300 (3900) 12500 (3660)

-5 (-20.6) 14600 (4280) 13900 (4070) 13100 (3840) 12400 (3630) 11700 (3430) 11000 (3220)
40 (4.4) 43400 (12720) 41400 (12130) 39400 (11550) 37400 (10960) 35400 (10370) 33500 (9820)
35 (1.7) 39900 (11690) 38100 (11170) 36300 (10640) 34400 (10080) 32600 (9550) 30800 (9030)
30 (-1.1) 36600 (10730) 34900 (10230) 33200 (9730) 31600 (9260) 29900 (8760) 28200 (8260)
25 (-3.9) 33400 (9790) 31900 (9350) 30300 (8880) 28800 (8440) 27300 (8000) 25700 (7530)
20 (-6.7) 30400 (8910) 29000 (8500) 27600 (8090) 26200 (7680) 24800 (7270) 23400 (6860)
15 (-9.4) 27500 (8060) 26200 (7680) 25000 (7330) 23700 (6950) 22400 (6560) 21200 (6210)
10 (-12.2) 24800 (7270) 23600 (6920) 22500 (6590) 21300 (6240) 20200 (5920) 19000 (5570)

5 (-15.0) 22200 (6510) 21200 (6210) 20100 (5890) 19100 (5600) 18100 (5300) 17000 (4980)
0 (-17.8) 19800 (5800) 18900 (5540) 18000 (5280) 17000 (4980) 16100 (4720) 15100 (4430)

-5 (-20.6) 17600 (5160) 16700 (4890) 15900 (4660) 15100 (4430) 14200 (4160) 13400 (3930)
40 (4.4) 51300 (15030) 49000 (14360) 46600 (13660) 44300 (12980) 41900 (12280) 39600 (11610)
35 (1.7) 47200 (13830) 45000 (13190) 42800 (12540) 40700 (11930) 38500 (11280) 36300 (10640)
30 (-1.1) 43200 (12660) 41200 (12070) 39200 (11490) 37200 (10900) 35200 (10320) 33200 (9730)
25 (-3.9) 39400 (11550) 37600 (11020) 35800 (10490) 33900 (9940) 32100 (9410) 30300 (8880)
20 (-6.7) 35800 (10490) 34100 (9990) 32500 (9520) 30800 (9030) 29100 (8530) 27500 (8060)
15 (-9.4) 32400 (9500) 30900 (9060) 29300 (8590) 27800 (8150) 26300 (7710) 24800 (7270)
10 (-12.2) 29200 (8560) 27800 (8150) 26400 (7740) 25000 (7330)

5 (-15.0) 26100 (7650) 24900 (7300) 23600 (6920) 22400 (6560) 21100 (6180) 19900 (5830)
0 (-17.8) 23300 (6830) 22100 (6480) 21000 (6150) 19900 (5830) 18800 (5510) 17700 (5190)

-5 (-20.6) 20600 (6040) 19600 (5740) 18600 (5450) 17600 (5160) 16600 (4860) 15600 (4570)
40 (4.4) 59800 (17530) 57000 (16700) 54200 (15880) 51400 (15060) 48700 (14270) 45900 (13450)
35 (1.7) 55100 (16150) 52600 (15420) 50000 (14650) 47500 (13920) 44900 (13160) 42400 (12430)
30 (-1.1) 50700 (14860) 48300 (14160) 46000 (13480) 43600 (12780) 41300 (12100) 38900 (11400)
25 (-3.9) 46400 (13600) 44200 (12950) 42100 (12340) 39900 (11690) 37800 (1
20 (-6.7) 42300 (12400) 40300 (11810) 38300 (11220) 36400 (10670) 34400 (10080) 32500 (9520)
15 (-9.4) 38400 (11250) 36600 (10730) 34800 (10200) 33000 (9670) 31200 (9140) 29400 (8620)
10 (-12.2) 34600 (10140) 33000 (9670) 31400 (9200) 29800 (8730) 28200 (8260) 26600 (7800)

5 (-15.0) 31100 (9110) 29600 (8670) 28200 (8260) 26700 (7820) 25300 (7410) 23900 (7000)
0 (-17.8) 27800 (8150) 26500 (7770) 25200 (7390) 23900 (7000) 22600 (6620) 21300 (6240)

-5 (-20.6) 24700 (7240) 23500 (6890) 22300 (6540) 21200 (6210) 20000 (5860) 18900 (5540)
40 (4.4) 69500 (20370) 66300 (19430) 63100 (18490) 59900 (17550) 56800 (16650) 53600 (15710)
35 (1.7) 63900 (18730) 61000 (17880) 58000 (17000) 55100 (16150) 52100 (15270) 49200 (14420)
30 (-1.1) 58600 (17170) 55800 (16350) 53100 (15560) 50400 (14770) 47700 (13980) 45000 (13190)
25 (-3.9) 53400 (15650) 50900 (14920) 48500 (14210) 46000 (13480) 43500 (12750) 41000 (12020)
20 (-6.7) 48600 (14240) 46300 (13570) 44000 (12900) 41700 (12220) 39500 (11580) 37300 (10930)
15 (-9.4) 43900 (12870) 41900 (12280) 39800 (11660) 37700 (11050) 35700 (10460) 33600 (9850)
10 (-12.2) 39600 (11610) 37700 (11050) 35800 (10490) 33900 (9940) 32100 (9410) 30200 (8850)

5 (-15.0) 35400 (10370) 33700 (9880) 32000 (9380) 30400 (8910) 28700 (8410) 27000 (7910)
0 (-17.8) 31600 (9260) 30000 (8790) 28500 (8350) 27000 (7910) 25500 (7470) 24000 (7030)

-5 (-20.6) 28000 (8210) 26600 (7800) 25300 (7410) 23900 (7000) 22600 (6620) 21200 (6210)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

R404A R507

AMBIENT TEMPERATURE °F (°C)

23700 (6950) 22300 (6540)

1080) 35600 (10430)

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 20 -

BITZER

CAPACITY DATA -

R404A

R507

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB060H8

Compressor

Model

4C0969SH

BESB076H8

Compressor

Model

4C1145SH

BESB090H8

Compressor

Model

4C1385SH

BESB100H8

Compressor

Model

4C1480SH

BESB120H8

Compressor

Model

4C1761SH

BESB150H8

Compressor

Model

4C2067SH

BESB200H8

Compressor

Model

4C2397SH

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

40 (4.4) 83300 (24410) 79400 (23270) 75400 (22100) 71500 (20950) 67600 (19810) 63700 (18670)
35 (1.7) 76900 (22540) 73200 (21450) 69600 (20400) 65900 (19310) 62300 (18260) 58700 (17200)
30 (-1.1) 70700 (20720) 67300 (19720) 63900 (18730) 60600 (17760) 57200 (16760) 53900 (15800)
25 (-3.9) 64700 (18960) 61600 (18050) 58500 (17140) 55400 (16240) 52300 (15330) 49300 (14450)
20 (-6.7) 59000 (17290) 56100 (16440) 53300 (15620) 50500 (14800) 47700 (13980) 44900 (13160)
15 (-9.4) 53500 (15680) 50900 (14920) 48300 (14160) 45700 (13390) 43200 (12660) 40700 (11930)
10 (-12.2) 48300 (14160) 45900 (13450) 43600 (12780) 41300 (12100) 39000 (11430) 36700 (10760)

5 (-15.0) 43400 (12720) 41200 (12070) 39100 (11460) 37000 (10840) 34900 (10230) 32900 (9640)
0 (-17.8) 38700 (11340) 36800 (10780) 34900 (10230) 33000 (9670) 31100 (9110) 29300 (8590)

-5 (-20.6) 34400 (10080) 32700 (9580) 30900 (9060) 29200 (8560) 27600 (8090) 25900 (7590)
40 (4.4) 104400 (30600) 99600 (29190) 94700 (27750) 89900 (26350) 85000 (24910) 80200 (23500)
35 (1.7) 96000 (28130) 91500 (26820) 87000 (25500) 82500 (24180) 78100 (22890) 73700 (21600)
30 (-1.1) 87900 (25760) 83800 (24560) 79600 (23330) 75500 (22130) 71500 (20950) 67400 (19750)
25 (-3.9) 80100 (23470) 76300 (22360) 72600 (21280) 68800 (20160) 65100 (19080) 61400 (17990)
20 (-6.7) 72800 (21340) 69300 (20310) 65900 (19310) 62400 (18290) 59000 (17290) 55700 (16320)
15 (-9.4) 65800 (19280) 62600 (18350) 59500 (17440) 56400 (16530) 53300 (15620) 50200 (14710)
10 (-12.2) 59100 (17320) 56300 (16500) 53500 (15680) 50700 (14860) 47900 (14040) 45100 (13220)

5 (-15.0) 52900 (15500) 50300 (14740) 47800 (14010) 45300 (13280) 42800 (12540) 40300 (11810)
0 (-17.8) 47100 (13800) 44800 (13130) 42500 (12460) 40200 (11780) 38000 (11140) 35700 (10460)

-5 (-20.6) 41600 (12190) 39600 (11610) 37500 (10990) 35500 (10400) 33500 (9820) 31500 (9230)
40 (4.4) 120000 (35170) 114500 (33560) 109000 (31940) 103500 (30330) 98000 (28720) 92500 (27110)
35 (1.7) 110800 (32470) 105700 (30980) 100600 (29480) 95500 (27990) 90500 (26520) 85400 (25030)
30 (-1.1) 101900 (29860) 97200 (28490) 92500 (27110) 87900 (25760) 83200 (24380) 78500 (23010)
25 (-3.9) 93300 (27340) 89000 (26080) 84800 (24850) 80500 (23590) 76200 (22330) 72000 (21100)
20 (-6.7) 85100 (24940) 81200 (23800) 77300 (22650) 73400 (21510) 69500 (20370) 65600 (19230)
15 (-9.4) 77300 (22650) 73700 (21600) 70200 (20570) 66700 (19550) 63100 (18490) 59600 (17470)
10 (-12.2) 69900 (20490) 66700 (19550) 63500 (18610) 60300 (17670) 57100 (16730) 53900 (15800)

5 (-15.0) 62800 (18400) 59900 (17550) 57100 (16730) 54200 (15880) 51300 (15030) 48400 (14180)
0 (-17.8) 56200 (16470) 53600 (15710) 51000 (14950) 48500 (14210) 45900 (13450) 43300 (12690)

-5 (-20.6) 50000 (14650) 47700 (13980) 45400 (13310) 43100 (12630) 40700 (11930) 38400 (11250)
40 (4.4) 126800 (37160) 120800 (35400) 114800 (33640) 109000 (31940) 103100 (30220) 97400 (28550)
35 (1.7) 1
30 (-1.1) 107600 (31530) 102400 (30010) 97300 (28520) 92200 (27020) 87200 (25560) 82300 (24120)
25 (-3.9) 98600 (28900) 93800 (27490) 89000 (26080) 84300 (24710) 79700 (23360) 75200 (22040)
20 (-6.7) 89900 (26350) 85500 (25060) 81100 (23770) 76800 (22510) 72600 (21280) 68400 (20050)
15 (-9.4) 81700 (23940) 77600 (22740) 73600 (21570) 69600 (20400) 65700 (19250) 61900 (18140)
10 (-12.2) 73800 (21630) 70100 (20540) 66400 (19460) 62800 (18400) 59300 (17380) 55800 (16350)

5 (-15.0) 66400 (19460) 63000 (18460) 59600 (17470) 56300 (16500) 53100 (15560) 49900 (14620)
0 (-17.8) 59400 (17410) 56300 (16500) 53200 (15590) 50200 (14710) 47300 (13860) 44500 (13040)

-5 (-20.6) 52700 (15440) 49900 (14620) 47200 (13830) 44500 (13040) 41800 (12250) 39300 (11520)
40 (4.4) 161600 (47360) 154000 (45130) 146300 (42880) 138700 (40650) 131000 (38390) 123400 (36160)
35 (1.7) 148700 (43580) 141700 (41530) 134600 (39450) 127600 (37400) 120500 (35310) 113500 (33260)
30 (-1.1) 136400 (39970) 129900 (38070) 123400 (36160) 117000 (34290) 110500 (32380) 104000 (30480)
25 (-3.9) 124600 (36520) 118700 (34790) 112700 (33030) 106800 (31300) 100800 (29540) 94900 (27810)
20 (-6.7) 113400 (33230) 107900 (31620) 102500 (30040) 97100 (28460) 91700 (26870) 86300 (25290)
15 (-9.4) 102700 (30100) 97700 (28630) 92800 (27200) 87900 (25760) 83000 (24320) 78100 (22890)
10 (-12.2) 92500 (27110) 88100 (25820) 83600 (24500) 79200 (23210) 74700 (21890) 70300 (20600)

5 (-15.0) 83000 (24320) 79000 (23150) 75000 (21980) 70900 (20780) 66900 (19610) 62900 (18430)
0 (-17.8) 74000 (21690) 70400 (20630) 66800 (19580) 63200 (18520) 59600 (17470) 56000 (16410)

-5 (-20.6) 65600 (19230) 62400 (18290) 59200 (17350) 55900 (16380) 52700 (15440) 49500 (14510)
40 (4.4) 186300 (54600) 177400 (51990) 168500 (49380) 159500 (46740) 150500 (44110) 141400 (41440)
35 (1.7) 171900 (50380) 163700 (47980) 155500 (45570) 147200 (43140) 138800 (40680) 130400 (38220)
30 (-1.1) 158000 (46310) 150500 (44110) 142900 (41880) 135300 (39650) 127500 (37370) 119800 (35110)
25 (-3.9) 144700 (42410) 137800 (40390) 130800 (38330) 123800 (36280) 116700 (34200) 109600 (32120)
20 (-6.7) 131800 (38630) 125600 (36810) 119200 (34930) 112800 (33060) 106300 (31150) 99800 (29250)
15 (-9.4) 1
10 (-12.2) 108000 (31650) 102800 (30130) 97600 (28600) 92300 (27050) 87000 (25500) 81600 (23910)

5 (-15.0) 96900 (28400) 92300 (27050) 87600 (25670) 82800 (24270) 78000 (22860) 73200 (21450)
0 (-17.8) 86500 (25350) 82400 (24150) 78100 (22890) 73900 (21660) 69600 (20400) 65200 (19110)

-5 (-20.6) 76700 (22480) 73000 (21390) 69300 (20310) 65500 (19200) 61600 (18050) 57700 (16910)
40 (4.4) 207500 (60810) 197900 (58000) 188200 (55160) 178400 (52280) 168600 (49410) 158800 (46540)
35 (1.7) 191700 (56180) 182700 (53540) 173700 (50910) 164600 (48240) 155500 (45570) 146400 (42910)
30 (-1.1) 176500 (51730) 168200 (49290) 159800 (46830) 151400 (44370) 142900 (41880) 134400 (39390)
25 (-3.9) 161800 (47420) 154100 (45160) 146400 (42910) 138600 (40620) 130800 (38330) 123000 (36050)
20 (-6.7) 147800 (43320) 140700 (41230) 133500 (39120) 126400 (37040) 119200 (34930) 112000 (32820)
15 (-9.4) 134300 (39360) 127800 (37450) 121300 (35550) 114700 (33620) 108200 (31710) 101500 (29750)
10 (-12.2) 121500 (35610) 115600 (33880) 109600 (32120) 103600 (30360) 97600 (28600) 91600 (26850)

5 (-15.0) 109300 (32030) 103900 (30450) 98500 (28870) 93100 (27280) 87600 (25670) 82100 (24060)
0 (-17.8) 97800 (28660) 93000 (27260) 88100 (25820) 83100 (24350) 78200 (22920) 73200 (21450)

-5 (-20.6) 87000 (25500) 82600 (24210) 78200 (22920) 73800 (21630) 69300 (20310) 64800 (18990)

CAPACITY BTU/H (WATTS)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

17000 (34290) 111400 (32650) 105900 (31040) 100400 (29420) 95000 (27840) 89700 (26290)

19600 (35050) 113900 (33380) 108100 (31680) 102300 (29980) 96400 (28250) 90500 (26520)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BESB

10/22/12

B40-BES-PDS-60-9

- 21 -

BITZER

CAPACITY DATA -

R407C

HIGH / MEDIUM TEMPERATURE

60Hz

CONDENSING

UNIT

MODEL

BESB010H8

Compressor

Model

2C0173SH

BESB015H8

Compressor

Model

2C0222SH

BESB020H8

Compressor

Model

2C0278SH

BESB025H8

Compressor

Model

2C0323SH

--- Outside Operating Range
NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.

It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 14100 (4130) 13500 (3960) 13000 (3810) 12500 (3660) 11900 (3490) 11400 (3340)
40 (4.4) 12700 (3720) 12200 (3580) 11700 (3430) 11200 (3280) 10700 (3140) 10300 (3020)
35 (1.7) 11400 (3340) 10900 (3190) 10500 (3080) 10000 (2930) 9600 (2810) 9200 (2700)
30 (-1.1) 10200 (2990) 9700 (2840) 9300 (2730) 8900 (2610) 8500 (2490) 8200 (2400)
25 (-3.9) 9000 (2640) 8600 (2520) 8200 (2400) 7900 (2320) 7500 (2200) 7200 (2110)
20 (-6.7) 7900 (2320) 7500 (2200) 7200 (2110) 6900 (2020) 6600 (1930) 6300 (1850)
15 (-9.4) 6900 (2020) 6600 (1930) 6200 (1820) 6000 (1760) 5700 (1670) 5400 (1580)
10 (-12.2) 5900 (1730) 5600 (1640) 5300 (1550) 5100 (1490) 4800 (1410) 4600 (1350)
45 (7.2) 18300 (5360) 17600 (5160) 16900 (4950) 16100 (4720) 15400 (4510) 14800 (4340)
40 (4.4) 16500 (4840) 15800 (4630) 15200 (4450) 14500 (4250) 13900 (4070) 13200 (3870)
35 (1.7) 14800 (4340) 14200 (4160) 13600 (3990) 13000 (3810) 12400 (3630) 11800 (3460)
30 (-1.1) 13200 (3870) 12600 (3690) 12100 (3550) 11500 (3370) 11000 (3220) 10500 (3080)
25 (-3.9) 11700 (3430) 11100 (3250) 10600 (3110) 10200 (2990) 9700 (2840) 9200 (2700)
20 (-6.7) 10300 (3020) 9800 (2870) 9300 (2730) 8900 (2610) 8500 (2490) 8100 (2370)
15 (-9.4) 8900 (2610) 8500 (2490) 8100 (2370) 7700 (2260) 7300 (2140) 7000 (2050)
10 (-12.2) 7700 (2260) 7300 (2140) 7000 (2050) 6600 (1930) 6300 (1850) 5900 (1730)
45 (7.2) 22900 (6710) 22000 (6450) 21100 (6180) 20100 (5890) 19200 (5630) 18300 (5360)
40 (4.4) 20900 (6130) 20000 (5860) 19200 (5630) 18300 (5360) 17500 (5130) 16700 (4890)
35 (1.7) 19000 (5570) 18200 (5330) 17400 (5100) 16600 (4860) 15900 (4660) 15100 (4430)
30 (-1.1) 17200 (5040) 16400 (4810) 15700 (4600) 15000 (4400) 14300 (4190) 13700 (4020)
25 (-3.9) 15500 (4540) 14800 (4340) 14100 (4130) 13500 (3960) 12900 (3780) 12300 (3600)
20 (-6.7) 13800 (4040) 13200 (3870) 12600 (3690) 12100 (3550) 11500 (3370) 11000 (3220)
15 (-9.4) 12300 (3600) 11800 (3460) 11200 (3280) 10700 (3140) 10200 (2990) 9700 (2840)
10 (-12.2) 10900 (3190) 10400 (3050) 9900 (2900) 9400 (2750) 9000 (2640) 8600 (2520)
45 (7.2) 27300 (8000) 26200 (7680) 25100 (7360) 24100 (7060) 23000 (6740) 22000 (6450)
40 (4.4) 24900 (7300) 23900 (7000) 22900 (6710) 21900 (6420) 21000 (6150) 20000 (5860)
35 (1.7) 22600 (6620) 21700 (6360) 20800 (6100) 19900 (5830) 19000 (5570) 18200 (5330)
30 (-1.1) 20400 (5980) 19600 (5740) 18800 (5510) 18000 (5280) 17200 (5040) 16400 (4810)
25 (-3.9) 18400 (5390) 17600 (5160) 16900 (4950) 16100 (4720) 15400 (4510) 14800 (4340)
20 (-6.7) 16500 (4840) 15800 (4630) 15100 (4430) 14500 (4250) 13800 (4040) 13200 (3870)
15 (-9.4) 14700 (4310) 14000 (4100) 13400 (3930) 12900 (3780) 12300 (3600) 11700 (3430)
10 (-12.2) 13000 (3810) 12400 (3630) 11900 (3490) 11400 (3340) 10900 (3190) 10400 (3050)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

R407C

AMBIENT TEMPERATURE °F (°C)

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 22 -

BITZER

CAPACITY DATA -

R407C

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB029H8

Compressor

Model

2C0407SH

BESB030H8

Compressor

Model

2C0484SH

BESB035H8

Compressor

Model

2C0572SH

BESB040H8

Compressor

Model

2C0692SH

BESB050H8

Compressor

Model

4C0770SH

BESB060H8

Compressor

Model

4C0969SH

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 34700 (10170) 33300 (9760) 31900 (9350) 30600 (8970) 29300 (8590) 27900 (8180)
40 (4.4) 31500 (9230) 30300 (8880) 29000 (8500) 27800 (8150) 26600 (7800) 25400 (7440)
35 (1.7) 28600 (8380) 27400 (8030) 26300 (7710) 25100 (7360) 24000 (7030) 23000 (6740)
30 (-1.1) 25800 (7560) 24700 (7240) 23700 (6950) 22700 (6650) 21700 (6360) 20700 (6070)
25 (-3.9) 23200 (6800) 22200 (6510) 21300 (6240) 20400 (5980) 19500 (5710) 18600 (5450)
20 (-6.7) 20800 (6100) 19900 (5830) 19000 (5570) 18200 (5330) 17400 (5100) 16600 (4860)
15 (-9.4) 18500 (5420) 17700 (5190) 17000 (4980) 16200 (4750) 15500 (4540) 14700 (4310)
10 (-12.2) 16400 (4810) 15700 (4600) 15000 (4400) 14300 (4190) 13700 (4020) 13000 (3810)
45 (7.2) 39900 (11690) 38200 (11200) 36500 (10700) 34800 (10200) 33100 (9700) 31400 (9200)
40 (4.4) 36300 (10640) 34700 (10170) 33200 (9730) 31600 (9260) 30100 (8820) 28500 (8350)
35 (1.7) 32900 (9640) 31400 (9200) 30000 (8790) 28600 (8380) 27200 (7970) 25800 (7560)
30 (-1.1) 29700 (8700) 28400 (8320) 27100 (7940) 25800 (7560) 24500 (7180) 23200 (6800)
25 (-3.9) 26700 (7820) 25500 (7470) 24300 (7120) 23100 (6770) 21900 (6420) 20700 (6070)
20 (-6.7) 23900 (7000) 22800 (6680) 21700 (6360) 20600 (6040) 19500 (5710) 18400 (5390)
15 (-9.4) 21300 (6240) 20300 (5950) 19300 (5660) 18300 (5360) 17300 (5070) 16300 (4780)
10 (-12.2) 18900 (5540) 17900 (5250) 17000 (4980) 16100 (4720) 15200 (4450) 14300 (4190)
45 (7.2) 48400 (14180) 46400 (13600) 44300 (12980) 42300 (12400) 40300 (11810) 38300 (11220)
40 (4.4) 44000 (12900) 42100 (12340) 40300 (11810) 38400 (11250) 36500 (10700) 34700 (10170)
35 (1.7) 39900 (11690) 38100 (11170) 36400 (10670) 34700 (10170) 33000 (9670) 31300 (9170)
30 (-1.1) 36000 (10550) 34400 (10080) 32800 (9610) 31200 (9140) 29700 (8700) 28100 (8240)
25 (-3.9) 32300 (9470) 30900 (9060) 29400 (8620) 28000 (8210) 26600 (7800) 25200 (7390)
20 (-6.7) 28900 (8470) 27600 (8090) 26300 (7710) 25000 (7330) 23700 (6950) 22400 (6560)
15 (-9.4) 25700 (7530) 24500 (7180) 23300 (6830) 22100 (6480) 20900 (6130) 19800 (5800)
10 (-12.2) 22800 (6680) 21700 (6360) 20600 (6040) 19500 (5710) 18400 (5390) 17300 (5070)
45 (7.2) 57400 (16820) 55000 (16120) 52500 (15390) 50100 (14680) 47600 (13950) 45200 (13250)
40 (4.4) 52400 (15360) 50200 (14710) 47900 (14040) 45600 (13360) 43400 (12720) 41100 (12050)
35 (1.7) 47700 (13980) 45600 (13360) 43500 (12750) 41400 (12130) 39300 (11520) 37200 (10900)
30 (-1.1) 43200 (12660) 41300 (12100) 39300 (11520) 37400 (10960) 35500 (10400) 33600 (9850)
25 (-3.9) 39000 (11430) 37200 (10900) 35400 (10370) 33600 (9850) 31900 (9350) 30100 (8820)
20 (-6.7) 35000 (10260) 33400 (9790) 31700 (9290) 30100 (8820) 28500 (8350) 26900 (7880)
15 (-9.4) 31300 (9170) 29800 (8730) 28300 (8290) 26800 (7850) 25300 (7410) 23800 (6980)
10 (-12.2) 27800 (8150) 26400 (7740) 25100 (7360) 23700 (6950) 22300 (6540) 21000 (6150)
45 (7.2) 68200 (19990) 65500 (19200) 62700 (18380) 60000 (17580) 57200 (16760) 54500 (15970)
40 (4.4) 62000 (18170) 59400 (17410) 56900 (16680) 54400 (15940) 51800 (15180) 49300 (14450)
35 (1.7) 56100 (16440) 53700 (15740) 51400 (15060) 49100 (14390) 46800 (13720) 44400 (13010)
30 (-1.1) 50500 (14800) 48400 (14180) 46200 (13540) 44100 (12920) 42000 (12310) 39900 (1
25 (-3.9) 45300 (13280) 43400 (12720) 41400 (12130) 39500 (11580) 37500 (10990) 35600 (10430)
20 (-6.7) 40500 (11870) 38700 (11340) 36900 (10810) 35100 (10290) 33300 (9760) 31500 (9230)
15 (-9.4) 36000 (10550) 34300 (10050) 32700 (9580) 31000 (9090) 29400 (8620) 27800 (8150)
10 (-12.2) 31800 (9320) 30300 (8880) 28800 (8440) 27300 (8000) 25800 (7560) 24300 (7120)
45 (7.2) 81500 (23890) 78000 (22860) 74500 (21830) 71100 (20840) 67600 (19810) 64200 (18820)
40 (4.4) 74300 (21780) 71100 (20840) 67900 (19900) 64700 (18960) 61600 (18050) 58400 (17120)
35 (1.7) 67600 (19810) 64600 (18930) 61700 (18080) 58700 (17200) 55800 (16350) 52900 (15500)
30 (-1.1) 61200 (17940) 58500 (17140) 55700 (16320) 53000 (15530) 50300 (14740) 47600 (13950)
25 (-3.9) 55100 (16150) 52600 (15420) 50100 (14680) 47700 (13980) 45200 (13250) 42700 (12510)
20 (-6.7) 49400 (14480) 47200 (13830) 44900 (13160) 42600 (12480) 40300 (11810) 38100 (11170)
15 (-9.4) 44100 (12920) 42000 (12310) 40000 (11720) 37900 (11110) 35800 (10490) 33700 (9880)
10 (-12.2) 39200 (11490) 37300 (10930) 35300 (10350) 33400 (9790) 31500 (9230) 29600 (8670)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

R407C

AMBIENT TEMPERATURE °F (°C)

1690)

--- Outside Operating Range
NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.

It is important that all components of a system are selected correctly

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 23 -

BITZER

CAPACITY DATA -

R407C

HIGH / MEDIUM TEMPERATURE (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB076H8

Compressor

Model

4C1145SH

BESB090H8

Compressor

Model

4C1385SH

BESB100H8

Compressor

Model

4C1480SH

BESB120H8

Compressor

Model

4C1761SH

BESB150H8

Compressor

Model

4C2067SH

BESB200H8

Compressor

Model

4C2397SH

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 102900 (30160) 98700 (28930) 94500 (27700) 90300 (26460) 86100 (25230) 81900 (24000)
40 (4.4) 93600 (27430) 89700 (26290) 85800 (25150) 82000 (24030) 78100 (22890) 74300 (21780)
35 (1.7) 84800 (24850) 81300 (23830) 77700 (22770) 74200 (21750) 70600 (20690) 67100 (19660)
30 (-1.1) 76600 (22450) 73300 (21480) 70000 (20510) 66800 (19580) 63600 (18640) 60400 (17700)
25 (-3.9) 68900 (20190) 65800 (19280) 62900 (18430) 59900 (17550) 57000 (16700) 54000 (15830)
20 (-6.7) 61600 (18050) 58900 (17260) 56100 (16440) 53400 (15650) 50800 (14890) 48100 (14100)
15 (-9.4) 54800 (16060) 52300 (15330) 49900 (14620) 47400 (13890) 45000 (13190) 42500 (12460)
10 (-12.2) 48600 (14240) 46300 (13570) 44000 (12900) 41800 (12250) 39600 (11610) 37400 (10960)
45 (7.2) 119000 (34880) 114100 (33440) 109200 (32000) 104300 (30570) 99400 (29130) 94500 (27700)
40 (4.4) 108700 (31860) 104100 (30510) 99600 (29190) 95000 (27840) 90500 (26520) 86000 (25200)
35 (1.7) 98900 (28980) 94600 (27720) 90400 (26490) 86200 (25260) 82000 (24030) 77900 (22830)
30 (-1.1) 89600 (26260) 85700 (25120) 81800 (23970) 77900 (22830) 74100 (21720) 70300 (20600)
25 (-3.9) 80800 (23680) 77200 (22630) 73700 (21600) 70100 (20540) 66600 (19520) 63100 (18490)
20 (-6.7) 72600 (21280) 69300 (20310) 66000 (19340) 62800 (18400) 59500 (17440) 56300 (16500)
15 (-9.4) 64900 (19020) 61900 (18140) 58900 (17260) 55900 (16380) 52900 (15500) 50000 (14650)
10 (-12.2) 57700 (16910) 54900 (16090) 52200 (15300) 49400 (14480) 46700 (13690) 44000 (12900)
45 (7.2) 124500 (36490) 119500 (35020) 114500 (33560) 109700 (32150) 104900 (30740) 100100 (29340)
40 (4.4) 113900 (33380) 109300 (32030) 104700 (30680) 100200 (29370) 95800 (28080) 91400 (26790)
35 (1.7) 103800 (30420) 99500 (29160) 95300 (27930) 91200 (26730) 87100 (25530) 83200 (24380)
30 (-1.1) 94100 (27580) 90200 (26430) 86400 (25320) 82600 (24210) 78900 (23120) 75300 (22070)
25 (-3.9) 85000 (24910) 81500 (23890) 78000 (22860) 74500 (21830) 71200 (20870) 67900 (19900)
20 (-6.7) 76500 (22420) 73200 (21450) 70100 (20540) 66900 (19610) 63900 (18730) 60900 (17850)
15 (-9.4) 68400 (20050) 65500 (19200) 62600 (18350) 59800 (17530) 57000 (16700) 54400 (15940)
10 (-12.2) 60900 (17850) 58200 (17060) 55600 (16290) 53100 (15560) 50600 (14830) 48200 (14130)
45 (7.2) 157000 (46010) 150700 (44170) 144400 (42320) 138200 (40500) 132100 (38710) 126200 (36990)
40 (4.4) 143100 (41940) 137300 (40240) 131600 (38570) 125900 (36900) 120300 (35260) 114800 (33640)
35 (1.7) 130000 (38100) 124700 (36550) 119500 (35020) 114300 (33500) 109200 (32000) 104200 (30540)
30 (-1.1) 117700 (34490) 1
25 (-3.9) 106100 (31090) 101700 (29810) 97300 (28520) 93000 (27260) 88800 (26020) 84700 (24820)
20 (-6.7) 95200 (27900) 91200 (26730) 87300 (25590) 83400 (24440) 79600 (23330) 75900 (22240)
15 (-9.4) 85000 (24910) 81400 (23860) 77900 (22830) 74400 (21800) 71000 (20810) 67700 (19840)
10 (-12.2) 75600 (22160) 72300 (21190) 69100 (20250) 66000 (19340) 62900 (18430) 60000 (17580)
45 (7.2) 182000 (53340) 174800 (51230) 167700 (49150) 160600 (47070) 153700 (45040) 146800 (43020)
40 (4.4) 166200 (48710) 159600 (46770) 153000 (44840) 146600 (42960) 140200 (41090) 133900 (39240)
35 (1.7) 151200 (44310) 145100 (42520) 139100 (40770) 133200 (39040) 127400 (37340) 121700 (35670)
30 (-1.1) 137000 (40150) 131400 (38510) 125900 (36900) 120600 (35340) 115300 (33790) 110100 (32270)
25 (-3.9) 123500 (36190) 118500 (34730) 113500 (33260) 108600 (31830) 103900 (30450) 99200 (29070)
20 (-6.7) 110900 (32500) 106300 (31150) 101800 (29830) 97400 (28550) 93100 (27280) 88900 (26050)
15 (-9.4) 99100 (29040) 94900 (27810) 90900 (26640) 86900 (25470) 83000 (24320) 79300 (23240)
10 (-12.2) 88000 (25790) 84300 (24710) 80600 (23620) 77100 (22600) 73600 (21570) 70300 (20600)
45 (7.2) 203800 (59730) 195700 (57350) 187600 (54980) 179700 (52660) 171800 (50350) 164000 (48060)
40 (4.4) 186700 (54720) 179200 (52520) 171800 (50350) 164400 (48180) 157100 (46040) 150000 (43960)
35 (1.7) 170300 (49910) 163400 (47890) 156600 (45890) 149800 (43900) 143100 (41940) 136600 (40030)
30 (-1.1) 154600 (45310) 148300 (43460) 142100 (41650) 135900 (39830) 129800 (38040) 123900 (36310)
25 (-3.9) 139700 (40940) 134000 (39270) 128300 (37600) 122700 (35960) 117200 (34350) 111800 (32770)
20 (-6.7) 125700 (36840) 120400 (35290) 115300 (33790) 110200 (32300) 105200 (30830) 100300 (29390)
15 (-9.4) 112400 (32940) 107700 (31560) 103000 (30190) 98400 (28840) 93900 (27520) 89500 (26230)
10 (-12.2) 100000 (29310) 95700 (28050) 91500 (26820) 87300 (25590) 83300 (24410) 79400 (23270)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY BTU/H (WATTS)

12800 (33060) 108000 (31650) 103300 (30270) 98700 (28930) 94200 (27610)

R407C

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range
NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.

It is important that all components of a system are selected correctly

CAPACITY DATA -

10/22/12

B40-BES-PDS-60-9

- 24 -

BESB 60Hz

LOW TEMPERATURE

R404A

R507

BITZER

CONDENSING

UNIT

MODEL

BESB010L6

Compressor

Model

2C0278SL

BESB015L6

Compressor

Model

2C0407SL

BESB020L6

Compressor

Model

2C0484SL

BESB025L6

Compressor

Model

2C0572SL

SAT. SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 9800 (2870) 9300 (2730) 8800 (2580) 8200 (2400) 7700 (2260) 7200 (2110)

-5 (-20.6) 8800 (2580) 8300 (2430) 7800 (2290) 7300 (2140) 6800 (1990) 6300 (1850)

-10 (-23.3) 7800 (2290) 7300 (2140) 6900 (2020) 6400 (1880) 6000 (1760) 5600 (1640)

-15 (-26.1) 6800 (1990) 6400 (1880) 6000 (1760) 5600 (1640) 5200 (1520) 4800 (1410)

-20 (-28.9) 5900 (1730) 5600 (1640) 5200 (1520) 4800 (1410) 4500 (1320) 4100 (1200)

-25 (-31.7) 5100 (1490) 4800 (1410) 4500 (1320) 4100 (1200) 3800 (1110) 3500 (1030)

-30 (-34.4) 4400 (1290) 4100 (1200) 3800 (1110) 3500 (1030) 3200 (940) 2900 (850)

-35 (-37.2) 3700 (1080) 3400 (1000) 3100 (910) 2900 (850) 2600 (760) 2300 (670)

-40 (-40.0) 3000 (880) 2800 (820) 2500 (730) 2300 (670) 2100 (620) 1800 (530)
0 (-17.8) 14700 (4310) 14000 (4100) 13200 (3870) 12400 (3630) 11700 (3430) 10900 (3190)

-5 (-20.6) 13200 (3870) 12500 (3660) 11800 (3460) 11100 (3250) 10400 (3050) 9700 (2840)

-10 (-23.3) 11700 (3430) 11100 (3250) 10500 (3080) 9800 (2870) 9200 (2700) 8600 (2520)

-15 (-26.1) 10400 (3050) 9800 (2870) 9200 (2700) 8700 (2550) 8100 (2370) 7600 (2230)

-20 (-28.9) 9100 (2670) 8600 (2520) 8100 (2370) 7600 (2230) 7100 (2080) 6600 (1930)

-25 (-31.7) 7900 (2320) 7400 (2170) 7000 (2050) 6500 (1900) 6100 (1790) 5700 (1670)

-30 (-34.4) 6800 (1990) 6400 (1880) 6000 (1760) 5600 (1640) 5200 (1520) 4800 (1410)

-35 (-37.2) 5800 (1700) 5400 (1580) 5100 (1490) 4700 (1380) 4400 (1290) 4000 (1170)

-40 (-40.0) 4900 (1440) 4600 (1350) 4200 (1230) 3900 (1140) 3600 (1060) 3200 (940)
0 (-17.8) 17300 (5070) 16400 (4810) 15600 (4570) 14700 (4310) 13800 (4040) 13000 (3810)

-5 (-20.6) 15500 (4540) 14700 (4310) 13900 (4070) 13200 (3870) 12400 (3630) 11600 (3400)

-10 (-23.3) 13800 (4040) 13100 (3840) 12400 (3630) 11700 (3430) 11000 (3220) 10300 (3020)

-15 (-26.1) 12300 (3600) 11600 (3400) 11000 (3220) 10300 (3020) 9700 (2840) 9100 (2670)

-20 (-28.9) 10800 (3170) 10200 (2990) 9600 (2810) 9100 (2670) 8500 (2490) 7900 (2320)

-25 (-31.7) 9400 (2750) 8900 (2610) 8400 (2460) 7900 (2320) 7300 (2140) 6800 (1990)

-30 (-34.4) 8100 (2370) 7700 (2260) 7200 (2110) 6700 (1960) 6300 (1850) 5800 (1700)

-35 (-37.2) 6900 (2020) 6500 (1900) 6100 (1790) 5700 (1670) 5300 (1550) 4900 (1440)

-40 (-40.0) 5900 (1730) 5500 (1610) 5100
0 (-17.8) 20400 (5980) 19400 (5690) 18300 (5360) 17300 (5070) 16200 (4750) 15200 (4450)

-5 (-20.6) 18300 (5360) 17400 (5100) 16400 (4810) 15400 (4510) 14500 (4250) 13600 (3990)

-10 (-23.3) 16300 (4780) 15400 (4510) 14600 (4280) 13700 (4020) 12900 (3780) 12000 (3520)

-15 (-26.1) 14400 (4220) 13600 (3990) 12900 (3780) 12100 (3550) 11300 (3310) 10600 (3110)

-20 (-28.9) 12700 (3720) 12000 (3520) 11300 (3310) 10600 (3110) 9900 (2900) 9200 (2700)

-25 (-31.7) 11000 (3220) 10400 (3050) 9800 (2870) 9100 (2670) 8500 (2490) 7900 (2320)

-30 (-34.4) 9500 (2780) 9000 (2640) 8400 (2460) 7800 (2290) 7300 (2140) 6700 (1960)

-35 (-37.2) 8100 (2370) 7600 (2230) 7100 (2080) 6600 (1930) 6100 (1790) 5600 (1640)

-40 (-40.0) 6900 (2020) 6400 (1880) 5900 (1730) 5500 (1610) 5000 (1470) 4500 (1320)

CAPACITY BTU/H (WATTS)

R404A R507

(1490) 4700 (1380) 4300 (1260) 4000 (1170)

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range

table continues on next page >>>

CAPACITY DATA -

10/22/12

B40-BES-PDS-60-9

- 25 -

BESB 60Hz

LOW TEMPERATURE (cont’d)

R404A

R507

BITZER

CONDENSING

UNIT

MODEL

BESB030L6

Compressor

Model

2C0692SL

BESB031L6

Compressor

Model

4C0770SL

BESB039L6

Compressor

Model

4C0969SL

BESB050L6

Compressor

Model

4C1145SL

BESB060L6

Compressor

Model

4C1385SL

BESB080L6

Compressor

Model

4C1761SL

BESB100L6

Compressor

Model

4C2067SL

BESB120L6

Compressor

Model

4C2397SL

--- Outside Operating Range

SAT. SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 26800 (7850) 25500 (7470) 24200 (7090) 22900 (6710) 21600 (6330) 20300 (5950)

-5 (-20.6) 23900 (7000) 22700 (6650) 21600 (6330) 20400 (5980) 19200 (5630) 18100 (5300)

-10 (-23.3) 21200 (6210) 20200 (5920) 19100 (5600) 18100 (5300) 17000 (4980) 16000 (4690)

-15 (-26.1) 18700 (5480) 17700 (5190) 16800 (4920) 15900 (4660) 15000 (4400) 14000 (4100)

-20 (-28.9) 16400 (4810) 15500 (4540) 14700 (4310) 13900 (4070) 13000 (3810) 12200 (3580)

-25 (-31.7) 14200 (4160) 13500 (3960) 12700 (3720) 12000 (3520) 11300 (3310) 10500 (3080)

-30 (-34.4) 12300 (3600) 11600 (3400) 10900 (3190) 10300 (3020) 9600 (2810) 8900 (2610)

-35 (-37.2) 10500 (3080) 9900 (2900) 9300 (2730) 8700 (2550) 8100 (2370) 7500 (2200)

-40 (-40.0) 8800 (2580) 8300 (2430) 7700 (2260) 7200 (2110) 6700 (1960) 6100 (1790)
0 (-17.8) 28900 (8470) 27400 (8030) 26000 (7620) 24600 (7210) 23200 (6800) 21800 (6390)

-5 (-20.6) 25800 (7560) 24500 (7180) 23200 (6800) 22000 (6450) 20700 (6070) 19400 (5690)

-10 (-23.3) 22900 (6710) 21800 (6390) 20600 (6040) 19500 (5710) 18300 (5360) 17200 (5040)

-15 (-26.1) 20200 (5920) 19200 (5630) 18200 (5330) 17100 (5010) 16100 (4720) 15100 (4430)

-20 (-28.9) 17800 (5220) 16800 (4920) 15900 (4660) 15000 (4400) 14000 (4100) 13100 (3840)

-25 (-31.7) 15500 (4540) 14600 (4280) 13800 (4040) 12900 (3780) 12100 (3550) 11300 (3310)

-30 (-34.4) 13300 (3900) 12600 (3690) 11800 (3460) 11100 (3250) 10300 (3020) 9600 (2810)

-35 (-37.2) 11400 (3340) 10700 (3140) 10000 (2930) 9400 (2750) 8700 (2550) 8000 (2340)

-40 (-40.0) 9600 (2810) 9000 (2640) 8400 (2460) 7800 (2290) 7200 (2110) 6500 (1900)
0 (-17.8) 36200 (10610) 34300 (10050) 32500 (9520) 30600 (8970) 28800 (8440) 27000 (7910)

-5 (-20.6) 32300 (9470) 30600 (8970) 29000 (8500) 27300 (8000) 25700 (7530) 24100 (7060)

-10 (-23.3) 28700 (8410) 27200 (7970) 25700 (7530) 24200 (7090) 22700 (6650) 21300 (6240)

-15 (-26.1) 25400 (7440) 24000 (7030) 22600 (6620) 21300 (6240) 20000 (5860) 18700 (5480)

-20 (-28.9) 22200 (6510) 21000 (6150) 19800 (5800) 18600 (5450) 17400 (5100) 16300 (4780)

-25 (-31.7) 19300 (5660) 18200 (5330) 17100 (5010) 16100 (4720) 15000 (4400) 14000 (4100)

-30 (-34.4) 16700 (4890) 15700 (4600) 14700 (4310) 13700 (4020) 12800 (3750) 11900 (3490)

-35 (-37.2) 14200 (4160) 13300 (3900) 12400 (3630) 11600 (3400) 10700 (3140) 9900 (2900)

-40 (-40.0) 12000 (3520) 11200 (3280) 10400
0 (-17.8) 45200 (13250) 42900 (12570) 40700 (11930) 38400 (11250) 36200 (10610) 34000 (9960)

-5 (-20.6) 40400 (11840) 38300 (11220) 36200 (10610) 34200 (10020) 32200 (9440) 30200 (8850)

-10 (-23.3) 35800 (10490) 33900 (9940) 32100 (9410) 30300 (8880) 28500 (8350) 26700 (7820)

-15 (-26.1) 31600 (9260) 29900 (8760) 28200 (8260) 26600 (7800) 25000 (7330) 23400 (6860)

-20 (-28.9) 27600 (8090) 26100 (7650) 24700 (7240) 23200 (6800) 21800 (6390) 20400 (5980)

-25 (-31.7) 24000 (7030) 22700 (6650) 21300 (6240) 20100 (5890) 18800 (5510) 17500 (5130)

-30 (-34.4) 20700 (6070) 19500 (5710) 18300 (5360) 17100 (5010) 16000 (4690) 14900 (4370)

-35 (-37.2) 17600 (5160) 16600 (4860) 15500 (4540) 14500 (4250) 13400 (3930) 12400 (3630)

-40 (-40.0) 14900 (4370) 13900 (4070) 12900 (3780) 12000 (3520) 11100 (3250) 10100 (2960)
0 (-17.8) 52600 (15420) 50100 (14680) 47500 (13920) 44900 (13160) 42300 (12400) 39800 (11660)

-5 (-20.6) 47100 (13800) 44800 (13130) 42500 (12460) 40100 (11750) 37800 (11080) 35500 (10400)

-10 (-23.3) 42000 (12310) 39900 (11690) 37800 (11080) 35700 (10460) 33600 (9850) 31500 (9230)

-15 (-26.1) 37200 (10900) 35300 (10350) 33400 (9790) 31500 (9230) 29700 (8700) 27800 (8150)

-20 (-28.9) 32700 (9580) 31000 (9090) 29300 (8590) 27600 (8090) 26000 (7620) 24300 (7120)

-25 (-31.7) 28500 (8350) 27000 (7910) 25500 (7470) 24000 (7030) 22500 (6590) 21000 (6150)

-30 (-34.4) 24700 (7240) 23400 (6860) 22000 (6450) 20700 (6070) 19300 (5660) 18000 (5280)

-35 (-37.2) 21200 (6210) 20000 (5860) 18800 (5510) 17600 (5160) 16400 (4810) 15200 (4450)

-40 (-40.0) 18100 (5300) 16900 (4950) 15800 (4630) 14700 (4310) 13600 (3990) 12500 (3660)
0 (-17.8) 70300 (20600) 66700 (19550) 63200 (18520) 59600 (17470) 56100 (16440) 52700 (15440)

-5 (-20.6) 62900 (18430) 59600 (17470) 56400 (16530) 53200 (15590) 50000 (14650) 46900 (13740)

-10 (-23.3) 55900 (16380) 53000 (15530) 50000 (14650) 47100 (13800) 44300 (12980) 41400 (12130)

-15 (-26.1) 49400 (14480) 46700 (13690) 44100 (12920) 41500 (12160) 38900 (11400) 36300 (10640)

-20 (-28.9) 43300 (12690) 40900 (11990) 38500 (11280) 36100 (10580) 33800 (9910) 31600 (9260)

-25 (-31.7) 37700 (11050) 35500 (10400) 33300 (9760) 31200 (9140) 29200 (8560) 27100 (7940)

-30 (-34.4) 32400 (9500) 30500 (8940) 28500 (8350) 26600 (7800) 24800 (7270) 23000 (6740)

-35 (-37.2) 27600 (8090) 25900 (7590) 24100 (7060) 22400 (6560) 20700 (6070) 19100 (5600)

-40 (-40.0) 23200 (6800) 21600 (6330) 20000 (5860) 18500 (5420) 17000 (4980) 15500 (4540)
0 (-17.8) 79400 (23270) 75400 (22100) 71400 (20930) 67500 (19780) 63600 (18640) 59700 (17500)

-5 (-20.6) 71100 (20840) 67500 (19780) 63800 (18700) 60300 (17670) 56700 (16620) 53200 (15590)

-10 (-23.3) 63300 (18550) 60000 (17580) 56700 (16620) 53500 (15680) 50300 (14740) 47100 (13800)

-15 (-26.1) 56000 (16410) 53000 (15530) 50000 (14650) 47100 (13800) 44200 (12950) 41400 (12130)

-20 (-28.9) 49100 (14390) 46400 (13600) 43700 (12810) 41100 (12050) 38500 (11280) 36000 (10550)

-25 (-31.7) 42700 (12510) 40300 (11810) 37900 (11110) 35500 (10400) 33200 (9730) 30900 (9060)

-30 (-34.4) 36800 (10780) 34600 (10140) 32400 (9500) 30300 (8880) 28200 (8260) 26200 (7680)

-35 (-37.2) 31300 (9170) 29300 (8590) 27400 (8030) 25400 (7440) 23600 (6920) 21800 (6390)

-40 (-40.0) 26200 (7680) 24400 (7150) 22700 (6650) 20900 (6130) 19300 (5660) 17600 (5160)
0 (-17.8) 88900 (26050) 84400 (24740) 79900 (23420) 75400 (22100) 70900 (20780) 66400 (19460)

-5 (-20.6) 79800 (23390) 75700 (22190) 71600 (20980) 67600 (19810) 63500 (18610) 59400 (17410)

-10 (-23.3) 71200 (20870) 67500 (19780) 63800 (18700) 60100 (17610) 56400 (16530) 52700 (15440)

-15 (-26.1) 63100 (18490) 59800 (17530) 56400 (16530) 53100 (15560) 49800 (14590) 46400 (13600)

-20 (-28.9) 55500 (16270) 52500 (15390) 49500 (14510) 46500 (13630) 43500 (12750) 40500 (11870)

-25 (-31.7) 48400 (14180) 45700 (13390) 42900 (12570) 40200 (11780) 37600 (11020) 34900 (10230)

-30 (-34.4) 41700 (12220) 39300 (11520) 36900 (10810) 34400 (10080) 32000 (9380) 29600 (8670)

-35 (-37.2) 35600 (10430) 33400 (9790) 31200 (9140) 29000 (8500) 26800 (7850) 24700 (7240)

-40 (-40.0) 29900 (8760) 27900 (8180) 25900 (7590) 23900 (7000) 22000 (6450) 20100 (5890)

CAPACITY BTU/H (WATTS)

R404A R507

(3050) 9600 (2810) 8800 (2580) 8100 (2370)

AMBIENT TEMPERATURE °F (°C)

BESA

10/22/12

B40-BES-PDS-60-9

- 26 -

COPELAND

ELECTRICAL DATA

COPELAND MODELS

60Hz

CONDENSING

UNIT

MODEL

BESA008H2- *

BESA010H2- *

BESA015H2- *

BESA020H2- *

BESA030H2- *

BESA008M2- *

BESA010M2- *

BESA020M2- *

BESA021M2- *

BESA050H8- *

BESA051H8- *

BESA075H8- *

BESA076H8- *

BESA080H8- *

BESA100H8- *

BESA120H8- *

BESA150H8- *

BESA010M6- *

BESA020M6- *

BESA021M6- *

BESA030M6- *

* I = Indoor, H = Outdoor. Above listed RLA value is based on UL rating method and may differ from published compressor RLA data.

S2 KAN2-0075-CAV 208-230/1/60 6.1 36 1 0.5 8.1 15
T3 KAN1-0075-TAC 208-230/3/60 3.5 19.9 1 0.5 4.9 15
S2 KAR2-0100-CAV 208-230/1/60 7.4 40 1 0.5 9.8 15
T3 KAR1-0100-TAC 208-230/3/60 4.3 27 1 0.5 5.9 15
S2 KAGB-0150-CAV 208-230/1/60 9.6 55 1 1.1 13.1 20
T3 KAGA-0150-TAC 208-230/3/60 5.5 35.5 1 1.1 8.0 15
T4 KAGA-0150-TAD 460/3/60 2.5 18.2 1 0.6 3.7 15
S2 KAKB-0200-CAV 208-230/1/60 10.6 55 1 1.1 14.4 25
T3 KAKA-0200-TAC 208-230/3/60 6.8 50 1 1.1 9.6 15
T4 KAKA-0200-TAD 460/3/60 3.0 25 1 0.6 4.4 15
S3 ERF2-0310-CAB 230/1/60 17.0 86.0 1 2.1 23.4 40
T3 ERF1-0310-TAC 208-230/3/60 11.7 82.0 1 2.1 15.7 25
T4 ERF1-0310-TAD 460/3/60 6.4 41.0 1 0.9 8.9 15

S2 KAE2-0075-CAV 208-230/1/60 5.4 36 1 0.5 7.3 15
T3 KAE1-0075-TAC 208-230/3/60 3.4 19.9 1 0.5 4.8 15
S2 KAM2-0100-CAV 208-230/1/60 7.5 40 1 0.5 9.9 15
T3 KAM1-0100-TAC 208-230/3/60 4.5 27 1 0.5 6.1 15

S3
T3 KAKA-0200-TAC 208-230/3/60 6.8 50 1 1.1 9.6 15
T4 KAKA-0200-TAD 460/3/60 3.0 25 1 0.6 4.4 15
S3
T3 ERC1-0200-TAC 208-230/3/60 6.8 46 1 1.1 9.6 15
T4 ERC1-0200-TAD 460/3/60 3.6 23 1 0.6 5.1 15
T5 ERC1-0200-TAE 575/3/60 3.2 20 1 0.5 4.5 15
T3 2DC3R53KE-TFC 208-230/3/60 22.3 120.0 1 2.1 30.0 50
T4 2DC3R53KE-TFD 460/3/60 10.4 60.0 1 1.1 14.1 20
T5 2DC3R53KE-TFE 575/3/60 7.7 49.0 1 0.9 10.5 15
T3 2DD3R63KE-TFC 208-230/3/60 22.3 120.0 1 2.1 30.0 50
T4 2DD3R63KE-TFD 460/3/60 10.5 60.0 1 1.1 14.2 20
T5 2DD3R63KE-TFE 575/3/60 7.9 49.0 1 0.9 10.8 15
T3 2DL3R78KE-TFC 208-230/3/60 31.6 169.0 1 2.1 41.6 70

T4 2DL3R78KE-TFD 460/3/60 13.8 85.0 1 1.1 18.4 30
T5 2DL3R78KE-TFE 575/3/60 13.2 67.0 1 0.9 17.4 30
T3 2DA3R89KE-TFC 208-230/3/60 32.0 169 2 4.2 44.2 70
T4 2DA3R89KE-TFD 460/3/60 14.1 85 2 2.2 19.8 30
T5 2DA3R89KE-TFE 575/3/60 13.3 67 2 1.8 18.4 30
T3 3DA3R10ME-TFC 208-230/3/60 41.0 215 2 4.2 55.5 90
T4 3DA3R10ME-TFD 460/3/60 20.0 106 2 2.2 27.2 45
T5 3DA3R10ME-TFE 575/3/60 16.5 84 2 1.8 22.4 35
T3 3DB3R12ME-TFC 208-230/3/60 43.6
T4 3DB3R12ME-TFD 460/3/60 20.0 106 2 2.2 27.2 45
T5 3DB3R12ME-TFE 575/3/60 16.5 84 2 1.8 22.4 35
T3 3DF3R15ME-TFC 208-230/3/60 48.1 275 2 7.2 67.3 110
T4 3DF3R15ME-TFD 460/3/60 23.6
T3 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 7.2 81.7 125
T4 3DS3R17ME-TFD 460/3/60 29.0 138 2 3.4 39.7 60
T5 3DS3R17ME-TFE 575/3/60 23.6 110 2 2.8 32.3 50

S2 KARB-010E-CAV 208-230/1/60 7.4 40 1 0.5 9.8 15
T3 KARA-010E-TAC 208-230/3/60 4.3 27 1 0.5 5.9 15
S2 KAKB-021E-CAV 208-230/1/60 10.6 55 1 1.1 14.4 25
T3 KAKA-020E-TAC 208-230/3/60 6.8 50 1 1.1 9.6 15
T3 ERCA-021E-TAC 208-230/3/60 8.8 46 1 1.1 12.1 20
T4 ERCA-020E-TAD 460/3/60 3.5 23 1 1.1 5.5 15
T5 ERCA-020E-TAE 575/3/60 3.1 20 1 0.6 4.5 15
S3 ERFB-031E-CAB 230/1/60 17.0 86.0 1 2.1 23.4 40
T3 ERFA-031E-TAC 208-230/3/60 12.4 82.0 1 2.1 17.6 30
T4 ERFA-031E-TAD 460/3/60 5.8 41.0 1 1.1 8.4 15

COMPRESSOR

MODEL NO.

KAKB-0200-CAV 208-230/1/60 10.6 55 1 1.1 14.4 25

ERC2-0200-CAB 230/1/60 10.9 58 1 1.1 14.7 25

POWER

SUPPLY

COMPRESSOR

RLA LRA QTY FLA

215 2 4.2 58.7 100

138 2 3.4 32.9 50

CONDENSER FAN

MOTOR

MCA MOP

table continues on next page >>>

BESA

10/22/12

B40-BES-PDS-60-9

- 27 -

COPELAND

ELECTRICAL DATA

COPELAND MODELS (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESA005L6- *

BESA008L6- *

BESA010L6- *

BESA015L6- *

BESA020L6- *

BESA021L6- *

BESA030L6- *

BESA032L6- *

BESA035L6- *

BESA040L6- *

BESA060L6- *

BESA061L6- *

BESA075L6- *

BESA090L6- *

BESA100L6- *

BESA130L6- *

BESA150L6- *

BESA220L6- *

COMPRESSOR

MODEL NO.

S2 KANB-005E-CAV 208-230/1/60 3.6 24 1 0.5 5.0 15
T3 KANA-006E-TAC 208-230/3/60 2.2 13.2 1 0.5 3.3 15
S2 KAMB-007E-CAV 208-230/1/60 5.6 36 1 0.5 7.5 15
T3 KAMA-007E-TAC 208-230/3/60 3.2 19.9 1 0.5 4.5 15
S2 KAJB-010E-CAV 208-230/1/60 6.9 40 1 0.5 9.1 15
T3 KAJA-011E-TAC 208-230/3/60 4.6 27 1 0.5 6.3 15
S2 KALB-015E-CAV 208-230/1/60 9.9 55 1 1.1 13.5 20
T3 KALA-016E-TAC 208-230/3/60 6.6 50 1 1.1 9.4 15
T4 KALA-016E-TAD 460/3/60 3.4 25 1 0.6 4.9 15
S3 EADB-021E-CAB 230/1/60 10.0 58 1 1.1 13.6 20
T3 EADA-020E-TAC 208-230/3/60 6.8 46 1 1.1 9.6 15
S3 EAVB-021E-CAV 208-230/1/60 14.7 102 1 1.1 19.5 30
T3 EAVA-021E-TAC 208-230/3/60 7.4 50 1 1.1 10.4 15
T4 EAVA-021E-TAD 460/3/60 3.9 26.6 1 0.6 5.5 15
T5 EAVA-021E-TAE 575/3/60 3.1 20 1 0.5 4.4 15
S3 LAHB-032E-CAB 230/1/60 16.7 105.0 1 2.1 23.0 35
T3 LAHA-032E-TAC 208-230/3/60 12.8 112.0 1 2.1 18.1 30
T4 LAHA-032E-TAD 460/3/60 6.0 56.0 1 1.1 8.6 15
T5 LAHA-032E-TAE 575/3/60 4.1 30.0 1 0.9 6.0 15
S3 LACB-032E-CAB 230/1/60 15.5 105.0 1 2.1 21.5 35
T3 LACA-032E-TAC 208-230/3/60 12.8 112.0 1 2.1 18.1 30
T4 LACA-032E-TAD 460/3/60 6.0 56.0 1 1.1 8.6 15
S3 2DF3F16KE-CFB 230/1/60 23.2 125 1 2.1 31.0 50
T3 2DF3F16KE-TFC 208-230/3/60 16.8 102.0 1 2.1 23.1 35
T4 2DF3F16KE-TFD 460/3/60 8.1 52.0 1 1.1 11.2 15
T5 2DF3F16KE-TFE 575/3/60 6.7 41.0 1 0.9 9.3 15
T3 2DL3F20KE-TFC 208-230/3/60 26.3 161.0 1 2.1 35.0 60
T4 2DL3F20KE-TFD 460/3/60 10.2 60.0 1 1.1 13.9 20
T5 2DL3F20KE-TFE 575/3/60 7.7 49.0 1 0.9 10.5 15
T3 2DB3F25KE-TFC 208-230/3/60 28.2 161.0 1 2.1 37.4 60
T4 2DB3F25KE-TFD 460/3/60 13.3 80.0 1 1.1 17.7 30
T5 2DB3F25KE-TFE 575/3/60 9.6 63.0 1 0.9 12.9 20
T3 3DA3F28KE-TFC 208-230/3/60 30.3 150.0 1 2.1 40.0 70
T4 3DA3F28KE-TFD 460/3/60 13.7 77.0 1 1.1 18.2 30
T5 3DA3F28KE-TFE 575/3/60 10.5 62.0 1 0.9 14.0 20
T3 3DB3F33KE-TFC 208-230/3/60 31.5 161.0 1 2.1 41.5 70
T4 3DB3F33KE-TFD 460/3/60 16.1 83.0 1 1.1 21.2 35
T5 3DB3F33KE-TFE 575/3/60 11.0 67.0 1 0.9 14.7 25
T3 3DF3F40KE-TFC 208-230/3/60 37.0 215 2 4.2 50.5 80
T4 3DF3F40KE-TFD 460/3/60 16.7 106
T5 3DF3F40KE-TFE 575/3/60 15.7 84 2 1.8 21.4 35
T3 3DS3F46KE-TFC 208-230/3/60 42.0 215 2 4.2 56.7 90
T4 3DS3F46KE-TFD 460/3/60 18.6 106 2 2.2 25.5 40
T5 3DS3F46KE-TFE 575/3/60 16.8 84 2 1.8 22.8 35
T3 4DBNF54KE-TSK 208/230/3/60 51.3 220 2 7.2 71.8 110
T4 4DBNF54KE-TSK 460/3/60 25.6 11
T3 4DHNF63KE-TSK 208/230/3/60 52.6 278 2 7.2 73.0 125
T4 4DHNF63KE-TSK 460/3/60 26.3 139 2 3.4 36.3 60
T5 4DHNF63KE-TSE 575/3/60 20.9 113 2 2.8 28.9 40
T3 4DJNF76KE-TSK 208/230/3/60 64.3 374 2 7.2 87.6 150
T4 4DJNF76KE-TSK 460/3/60 32.1 187 2 3.4 43.5 70
T5 4DJNF76KE-TSE 575/3/60 24.1 135 2 2.8 32.9 50

POWER
SUPPLY

COMPRESSOR

RLA LRA QTY FLA

0 2 3.4 35.4 60

CONDENSER FAN

MOTOR

2 2.2 23.1 40

MCA MOP

* I = Indoor, H = Outdoor. Above listed RLA value is based on UL rating method and may differ from published compressor RLA data.

BESB

10/22/12

B40-BES-PDS-60-9

- 28 -

BITZER

ELECTRICAL DATA

BITZER MODELS

60Hz

CONDENSING

UNIT

MODEL

BESB010H8-*

BESB015H8-*

BESB020H8-*

BESB025H8-*

BESB029H8-*

BESB030H8-*

BESB035H8-*

BESB040H8-*

BESB050H8-*

BESB060H8-*

BESB076H8-*

BESB090H8-*

BESB100H8-*

BESB120H8-*

BESB150H8- *

BESB200H8- *

* I = Indoor, H = Outdoor. Above listed RLA value is based on UL rating method and may differ from published compressor RLA data.

S2 2C0173SH-2EU-Y 208-230/1/60 9.2 37 1 0.5 12.0 20
T3 2C0173SH-2DU-Y 208-230/3/60 6.0 32 1 0.5 8.0 15
S2 2C0222SH-2EU-Y 208-230/1/60 10.5 40 1 1.1 14.2 20
T3 2C0222SH-2DU-Y 208-230/3/60 7.4 40 1 1.1 10.4 15
T4 2C0222SH-4SU-Y 460/3/60 3.2 20 1 0.6 4.6 15
T5 2C0222SH-5SU-Y 575/3/60 2.4 16 1 0.5 3.5 15
S2 2C0278SH-2EU-Y 208-230/1/60 14.0 58.5 1 1.1 18.6 30
T3 2C0278SH-2DU-Y 208-230/3/60 12.3 54 1 1.1 16.5 25
T4 2C0278SH-4SU-Y 460/3/60 4.5 24 1 0.6 6.2 15
T5 2C0278SH-5SU-Y 575/3/60 3.6 17 1 0.5 5.0 15
S2 2C0323SH-2EU-Y 208-230/1/60 17.8 58.5 1 1.1 23.4 40
T3 2C0323SH-2DU-Y 208-230/3/60 12.1 54 1 1.1 16.2 25
T4 2C0323SH-4SU-Y 460/3/60 4.8 24 1 0.6 6.6 15
T5 2C0323SH-5SU-Y 575/3/60 3.7 17 1 0.5 5.1 15
T3 2C0407SH-2DU-Y 208-230/3/60 13.9 60.0 1 2.1 19.5 30
T4 2C0407SH-4SU-Y 460/3/60 5.7 27.5 1 1.1 8.2 15
T5 2C0407SH-5SU-Y 575/3/60 4.9 19.0 1 0.9 7.0 15
S2 2C0484SH-2EU-Y 208-230/1/60 28.9 109.0 1 2.1 38.2 60
T3 2C0484SH-2DU-Y 208-230/3/60 17.3 97.0 1 2.1 23.7 40
T4 2C0484SH-4SU-Y 460/3/60 7.3 39.5 1 1.1 10.2 15
T5 2C0484SH-5SU-Y 575/3/60 5.9 28.5 1 0.9 8.3 15
S2 2C0572SH-2EU-Y 208-230/1/60 29.6 113.0 1 2.1 39.1 60
T3 2C0572SH-2DU-Y 208-230/3/60 18.8 97.0 1 2.1 25.6 40
T4 2C0572SH-4SU-Y 460/3/60 8.1 39.5 1 1.1 11.2 15
T5 2C0572SH-5SU-Y 575/3/60 5.7 28.5 1 0.9 8.0 15
T3 2C0692SH-2DU-Y 208-230/3/60 22.4 115.5 1 2.1 30.1 50
T4 2C0692SH-4SU-Y 460/3/60 9.1 47.5 1 1.1 12.5 20
T5 2C0692SH-5SU-Y 575/3/60 7.3 34.0 1 0.9 10.0 15
T3 4C0770SH-2DU-Y 208-230/3/60 29.9 163.0 1 2.1 39.5 60
T4 4C0770SH-4SU-Y 460/3/60 14.6 66.5 1 1.1 19.4 30
T5 4C0770SH-5SU-Y 575/3/60 9.7 48.0 1 0.9 13.0 20
T3 4C0969SH-2DU-Y 208-230/3/60 34.6 163.0 1 2.1 45.4 70
T4 4C0969SH-4SU-Y 460/3/60 14.9 66.5 1 1.1 19.7 30
T5 4C0969SH-5SU-Y 575/3/60 10.5 48.0 1 0.9 14.0 20
T3 4C1145SH-2DU-Y 208-230/3/60 38.1 215 2 4.2 51.8 80
T4 4C1145SH-4SU-Y 460/3/60 17.0 88 2 2.2 23.5 40
T5 4C1145SH-5SU-Y 575/3/60 12.3 63.5 2 1.8 17.2 25
T3 4C1385SH-2DU-Y 208-230/3/60 42.1 215 2
T4 4C1385SH-4SU-Y 460/3/60 19.0 88 2 2.2 26.0 45
T5 4C1385SH-5SU-Y 575/3/60 15.2 63.5 2 1.8 20.8 35
T3 4C1480SH-2NU-Y 208-230/3/60 47.4 222 2 4.2 63.5 110
T4 4C1480SH-2NU-Y 460/3/60 21.4 111 2 2.2
T5 4C1480SH-5PU-Y 575/3/60 17.1 89 2 1.8 23.2 40
T3 4C1761SH-2NU-Y 208-230/3/60 52.1 252 2 7.2 72.3 110
T4 4C1761SH-2NU-Y 460/3/60 23.6 126 2 3.4 32.9 50
T5 4C1761SH-5PU-Y 575/3/60 18.9 101 2 2.8 26.4 45
T3 4C2067SH-2NU-Y 208-230/3/60 60.0 294 2 7.2 82.2 125
T4 4C2067SH-2NU-Y 460/3/60 27.0 147 2 3.4 37.2 60
T5 4C2067SH-5PU-Y 575/3/60 21.8 117 2 2.8 30.1 50
T3 4C2397SH-2NU-Y 208-230/3/60 71.1 352 2 7.2 96.1 150
T4 4C2397SH-2NU-Y 460/3/60 32.1 176 2 3.4 43.5 70
T5 4C2397SH-5PU-Y 575/3/60 26.3 140 2 2.8 35.7 60

COMPRESSOR

MODEL NO.

POWER
SUPPLY

COMPRESSOR

RLA LRA QTY FLA

CONDENSER FAN

MOTOR

4.2 56.8 90

MCA MOP

29.0 50

table continues on next page >>>

BESB

10/22/12

B40-BES-PDS-60-9

- 29 -

BITZER

ELECTRICAL DATA

BITZER MODELS (cont’d)

60Hz

CONDENSING

UNIT

MODEL

BESB010L6-*

BESB015L6-*

BESB020L6-*

BESB025L6-*

BESB030L6-*

BESB031L6-*

BESB039L6-*

BESB050L6-*

BESB060L6-*

BESB080L6-*

BESB100L6-*

BESB120L6-*

COMPRESSOR

MODEL NO.

T3 2C0278SL-2EU-Y 208-230/1/60 12.8 56.5 1 0.5 16.5 25
T4 2C0278SL-2DU-Y 208-230/3/60 8.1 42 1 0.5 10.6 15
S2 2C0407SL-2EU-Y 208-230/1/60 14.6 60 1 1.1 19.4 30
T3 2C0407SL-2DU-Y 208-230/3/60 11.1 54 1 1.1 15.0 25
T4 2C0407SL-4SU-Y 460/3/60 4.6 24 1 0.6 6.4 15
T5 2C0407SL-5SU-Y 575/3/60 3.6 17 1 0.5 5.0 15
T3 2C0484SL-2DU-Y 208-230/3/60 13.3 70 1 1.1 17.7 30
T4 2C0484SL-4SU-Y 460/3/60 5.4 28.5 1 0.6 7.4 15
T5 2C0484SL-5SU-Y 575/3/60 4.0 20.5 1 0.5 5.5 15
T3 2C0572SL-2DU-Y 208-230/3/60 14.5 80.5 1 1.1 19.2 30
T4 2C0572SL-4SU-Y 460/3/60 6.4 33 1 0.6 8.6 15
T5 2C0572SL-5SU-Y 575/3/60 4.7 23.5 1 0.5 6.4 15
S2 2C0692SL-2EU-Y 208-230/1/60 25.4 115.0 1 2.1 33.9 50
T3 2C0692SL-2DU-Y 208-230/3/60 16.5 97.0 1 2.1 22.7 35
T4 2C0692SL-4SU-Y 460/3/60 7.0 39.5 1 1.1 9.9 15
T5 2C0692SL-5SU-Y 575/3/60 5.6 28.5 1 0.9 7.9 15
T3 4C0770SL-2DU-Y 208-230/3/60 22.2 115.5 1 2.1 29.9 50
T4 4C0770SL-4SU-Y 460/3/60 9.0 47.5 1 1.1 12.4 20
T5 4C0770SL-5SU-Y 575/3/60 6.9 34.0 1 0.9 9.5 15
T3 4C0969SL-2DU-Y 208-230/3/60 24.8 142.0 1 2.1 33.1 50
T4 4C0969SL-4SU-Y 460/3/60 10.3 58.0 1 1.1 14.0 20
T5 4C0969SL-5SU-Y 575/3/60 8.3 51.5 1 0.9 11.3 15
T3 4C1145SL-2DU-Y 208-230/3/60 25.4 163.0 1 2.1 33.9 50
T4 4C1145SL-4SU-Y 460/3/60 12.0 66.5 1 1.1 16.1 25
T5 4C1145SL-5SU-Y 575/3/60 10.0 48.0 1 0.9 13.4 20
T3 4C1385SL-2DU-Y 208-230/3/60 30.9 215.0 1 2.1 40.7 70
T4 4C1385SL-4SU-Y 460/3/60 15.8 88.0 1 1.1 20.9 35
T5 4C1385SL-5SU-Y 575/3/60 12.5 63.5 1 0.9 16.5 25
T3 4C1761SL-2NU-Y 208-230/3/60 34.7 180 2 4.2 47.6 80
T4 4C1761SL-2NU-Y 460/3/60 15.7 90 2 2.2 21.8 35
T5 4C1761SL-5PU-Y 575/3/60 13.6 72 2 1.8 18.8 30
T3 4C2067SL-2NU-Y 208-230/3/60 42.7 222 2 4.2 57.6 100
T4 4C2067SL-2NU-Y 460/3/60 19.3 111 2 2.2 26.3 45
T5 4C2067SL-5PU-Y 575/3/60 16.0 89 2 1.8 21.8 35
T3 4C2397SL-2NU-Y 208-230/3/60 49.0 252 2 4.2 65.5 110
T4 4C2397SL-2NU-Y 460/3/60 22.1 126 2 2.2 29.8 50
T5 4C2397SL-5PU-Y 575/3/60 17.7 101 2 1.8 23.9 40

POWER
SUPPLY

COMPRESSOR

RLA LRA QTY FLA

CONDENSER FAN

MOTOR

MCA MOP

* I = Indoor, H = Outdoor. Above listed RLA value is based on UL rating method and may differ from published compressor RLA data.

BES

10/22/12

B40-BES-PDS-60-9

- 30 -

AIR

FLOW

DIMENSIONAL DATA

(1 Fan Models - Small Chassis)

INDOOR DIMENSIONS

AIR

FLOW

OUTDOOR DIMENSIONS

NOTE: Discharge hood and legs are optional components

REFER TO PAGES 34-35 FOR

DIMENSIONAL DATA FOR SPECIFIC MODELS

FLO

BES

10/22/12

B40-BES-PDS-60-9

- 31 -

AIR

W

DIMENSIONAL DATA

(1 Fan Models - Large Chassis)

INDOOR DIMENSIONS

AIR

FLOW

OUTDOOR DIMENSIONS

NOTE: Discharge hood and legs are optional components

REFER TO PAGES 34-35 FOR

DIMENSIONAL DATA FOR SPECIFIC MODELS

WIDTH

OPTIONA
DISCHARGE HOOD
A

2 1/16

HOOD

BES

10/22/12

B40-BES-PDS-60-9

- 32 -

DIMENSIONAL DATA

(2 Fan Models - Small Chassis)

HEIGHT

MOUNTING

9/16 9/16

DEPTH

INDOOR DIMENSIONS

2 1/16 8 18 1/2 8 18 1/2 8 2 1/16

HOLES

ND LEGS

L AIR

HEIGHT

8

MOUNTING
HOLES

9/16 9/16

DEPTH

WITH

2 1/16 8 18 1/2 8 18 1/2 8

OUTDOOR DIMENSIONS

NOTE: Discharge hood and legs are optional components

REFER TO PAGES 34-35 FOR

DIMENSIONAL DATA FOR SPECIFIC MODELS

WIDTH

BES

4 15/16

OPTIONAL
DISCHARGE HOOD

A

6

10/22/12

B40-BES-PDS-60-9

- 33 -

AIR

ND LEGS

DIMENSIONAL DATA

(2 Fan Models - Large Chassis)

HEIGHT

MOUNTING

3/4

DEPTH

INDOOR DIMENSIONS

HEIGHT

3/4

4 15/16 8 21 8 21 8

HOLES

WIDTH

10

MOUNTING

3/4

DEPTH

3/4

WITH
HOOD

4 15/16 8 21 8 21 8 4 15/1

HOLES

OUTDOOR DIMENSIONS

NOTE: Discharge hood and legs are optional components

REFER TO PAGES 34-35 FOR

DIMENSIONAL DATA FOR SPECIFIC MODELS

WIDTH

DIMENSIONAL DATA

10/22/12

B40-BES-PDS-60-9

- 34 -

BESA

COPELAND MODELS

60Hz

COPELAND

CONDENSING

UNIT

MODEL

BESA008H2 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA010H2 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA015H2 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA020H2 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495

BESA030H2 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESA008M2 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA010M2 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA020M2 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA021M2 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA010M6 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA015M6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA020M6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA021M6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA030M6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767

BESA050H8 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059

BESA051H8 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059

BESA075H8 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059

BESA076H8 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059

BESA080H8 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059

BESA100H8 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059

BESA120H8 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156

BESA150H8 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156

BESA005L6 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA008L6 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA010L6 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESA015L6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA020L6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA021L6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESA030L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESA032L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 111
BESA035L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESA040L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESA060L6 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059
BESA061L6 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059
BESA075L6 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059
BESA090L6 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059
BESA100L6 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059
BESA130L6 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156
BESA150L6 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156
BESA220L6 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156

WIDTH

Inches mm Inches mm Inches mm Inches mm Inches mm Inches mm Inches mm

OUTDOOR MODELS INDOOR MODELS

Base With Hood

DEPTH

HEIGHT WIDTH DEPTH HEIGHT

4 32 7/8 835 30 3/16 767

BESB

10/22/12

B40-BES-PDS-60-9

- 35 -

BITZER

DIMENSIONAL DATA

BITZER MODELS

60Hz

CONDENSING

UNIT

MODEL

BESB010H8 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESB015H8 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESB020H8 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESB025H8 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESB029H8 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB030H8 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB035H8 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB040H8 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB050H8 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059
BESB060H8 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059
BESB076H8 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059
BESB090H8 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059
BESB100H8 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059
BESB120H8 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156
BESB150H8 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156
BESB200H8 75 7/8 1927 45 3/4 1162 59 1511 45 1/2 1156 75 7/8 1927 45 3/4 1162 45 17/32 1156
BESB010L6 24 7/8 632 30 3/8 772 34 3/8 873 16 7/8 429 24 5/8 625 30 3/8 772 16 1/2 419
BESB015L6 35 3/8 899 29 3/8 746 33 3/8 848 18 7/8 479 35 3/8 899 29 3/8 746 18 1/2 470
BESB020L6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESB025L6 36 3/8 924 30 3/8 772 34 3/8 873 19 7/8 505 36 3/8 924 30 3/8 772 19 1/2 495
BESB030L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB031L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB039L6 43 7/8 1114 32 7/8 835 43 1092 30 3/8 772 43 7/8 1114 32 7/8 835 30 3/16 767
BESB050L6 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911 41 11/16 1059
BESB060L6 52 1/8 1324 35 7/8 911 43 1092 41 7/8 1064 52 1/8 1324 35 7/8 911
BESB080L6 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059
BESB100L6 65 1/8 1654 35 7/8 9
BESB120L6 65 1/8 1654 35 7/8 911 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059

WIDTH

Inches mm Inches mm Inches mm Inches mm Inches mm Inches mm Inches mm

OUTDOOR MODELS INDOOR MODELS

Base With Hood

DEPTH

11 43 1092 41 7/8 1064 65 1/8 1654 35 7/8 911 41 11/16 1059

HEIGHT WIDTH DEPTH HEIGHT

41 11/16 1059

BESA

10/22/12

B40-BES-PDS-60-9

- 36 -

COPELAND

SPECIFICATIONS

COPELAND MODELS

CONDENSING

UNIT

MODEL

BESA008H2 1/2 13 3/8 10 6 2.7 240 109 230 104
BESA010H2 5/8 16 3/8 10 6 2.7 270 122 260 118
BESA015H2 7/8 22 3/8 10 16 7.3 310 141 295 134
BESA020H2 7/8 22 3/8 10 16 7.3 320 145 305 138

BESA030H2 7/8 22 1/2 13 25 11.3 477 216 432 196
BESA008M2 5/8 16 3/8 10 6 2.7 240 109 230 104
BESA010M2 5/8 16 3/8 10 6 2.7 270 122 260 118
BESA021M2 7/8 22 3/8 10 16 7.3 390 177 370 168

BESA050H8 * 1 1/8 29 1/2 13 31 14.1 766 347 721 327
BESA051H8 * 1 1/8 29 1/2 13 31 14.1 769 349 724 328
BESA075H8 * 1 3/8 35 5/8 16 31 14.1 780 354 735 333
BESA076H8 * 1 3/8 35 5/8 16 54 24.5 885 401 830 376
BESA080H8 * 1 3/8 35 5/8 16 54 24.5 885 401 830 376
BESA100H8 * 1 3/8 35 5/8 16 54 24.5 885 401 830 376
BESA120H8 * 1 3/8 35 7/8 22 76 34.5 1085 492 1030 467
BESA150H8 * 1 3/8 35 7/8 22 76 34.5 1085 492 1030 467

BESA010M6 5/8 16 3/8 10 5.2 2.4 270 122 260 118
BESA020M6 7/8 22 3/8 10 14 6.4 320 145 305 138
BESA021M6 7/8 22 3/8 10 14 6.4 390 177 370 168
BESA030M6 7/8 22 1/2 13 22 10.0 477 216 432 196
BESA040M6 1 1/8 29 1/2 13 22 10.0 542 246 497 225

BESA005L6 1/2 13 3/8 10 5.2 2.4 240 109 230 104
BESA008L6 5/8 16 3/8 10 5.2 2.4 270 122 260 118
BESA010L6 5/8 22 3/8 10 5.2 2.4 290 132 275 125
BESA015L6 7/8 22 3/8 10 14 6.4 315 143 300 136
BESA020L6 7/8 22 3/8 10 14 6.4 385 175 370 168
BESA021L6 7/8 22 1/2 13 14 6.4 390 177 375 170
BESA030L6 1 1/8 29 1/2 13 22 10 493 224 448 203
BESA032L6 1 1/8 29 1/2 13 22 10 491 223 446 202
BESA035L6 1 1/8 29 1/2 13 22 10 588 267 543 246
BESA040L6 1 1/8 29 1/2 13 22 10 618 281 573 259
BESA060L6 1 3/8 35 5/8 16 31 14 781 355 736 333

A061L6 1 3/8 35 5/8 16 31 14 819 372 774 350

BES
BESA075L6 1 3/8 35 5/8 16 31 14 827 376 782 354
BESA090L6 1 3/8 35 5/8 16 54 24.5 885 401 830 376
BESA100L6 1 3/8 35 5/8 16 54 24.5 885 401 830 376
BESA130L6 1 5/8 41 7/8 22 76 34.5 1185 538 1130 513
BESA150L6 1 5/8 41 7/8 22 76 34.5 1
BESA220L6 2 1/8 54 7/8 22 76 34.5 1185 538 1130 513

SUCTION (OD) LIQUID (OD) OUTDOOR INDOOR

Inches mm Inches mm Lbs. Kgs Lbs. Kgs Lbs. Kgs

UNIT CONNECTIONS

RECEIVER
CAPACITY

90% FULL

SHIPPING WEIGHT

185 538 1130 513

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407C

1.10 1.15 1.00

R404A

R404A

R22

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

BESB

10/22/12

B40-BES-PDS-60-9

- 37 -

BITZER

SPECIFICATIONS

BITZER MODELS

CONDENSING

UNIT

MODEL

BESB010H8 * 5/8 16 3/8 10 6 3 275 125 260 118
BESB015H8 * 7/8 22 3/8 10 14 6 350 159 330 150
BESB020H8 * 7/8 22 3/8 10 14 6 360 163 340 154
BESB025H8 * 7/8 22 3/8 10 14 6 375 170 355 161
BESB029H8 * 1 1/8 29 1/2 13 22 10 386 175 361 164
BESB030H8 * 1 1/8 29 1/2 13 22 10 437 198 392 178
BESB035H8 * 1 1/8 29 1/2 13 22 10 449 204 404 183
BESB040H8 * 1 1/8 29 1/2 13 22 10 452 205 407 185
BESB050H8 * 1 1/8 29 5/8 16 31 14.1 648 294 603 274
BESB060H8 * 1 3/8 35 5/8 16 31 14.1 652 296 607 275
BESB076H8 * 1 3/8 35 5/8 16 54 24.5 700 318 660 299
BESB090H8 * 1 3/8 35 5/8 16 54 24.5 700 318 645 293
BESB100H8 * 1 3/8 35 5/8 16 54 24.5 800 363 745 338
BESB120H8 * 1 3/8 35 7/8 22 76 34.5 1005 456 950 431
BESB150H8 * 1 5/8 41 7/8 22 76 34.5 1005 456 950 431
BESB200H8 * 1 5/8 41 7/8 22 76 34.5 1005 456 950 431

BESB010L6 5/8 16 3/8 10 6 3 275 125 260 118
BESB015L6 7/8 22 3/8 10 14 6 350 159 330 150
BESB020L6 7/8 22 3/8 10 14 6 360 163 340 154
BESB025L6 7/8 22 3/8 10 14 6 375 170 355 161
BESB030L6 1 1/8 29 1/2 13 22 10 436 198 391 177
BESB031L6 1 1/8 29 1/2 13 22 10 463 210 418 190
BESB039L6 1 1/8 29 1/2 13 22 10 479 217 434 197
BESB050L6 1 3/8 35 5/8 16 31 14.1 647 293 602 273
BESB060L6 1 3/8 35 5/8 16 31 14.1 658 298 613 278
BESB080L6 1 3/8 35 5/8 16 54 24.5 790 358 735 333
BESB100L6 1 3/8 35 5/8 16 54 24.5 800 363 745 338
BESB120L6 1 3/8 35 5/8 16 54 24.5 805 365 750 340

SUCTION (OD) LIQUID (OD) OUTDOOR INDOOR

Inches mm Inches mm Lbs. Kgs Lbs. Kgs Lbs. Kgs

UNIT CONNECTIONS

RECEIVER
CAPACITY

90% FULL

SHIPPING WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407C

1.10 1.15 1.00

R404A

R404A

R22

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

BES

10/22/12

B40-BES-PDS-60-9

- 38 -

TYPICAL SYSTEM WIRING DIAGRAM

208-230/1/60 Unit

with 230V Air Defrost Evaporator

60Hz

BES

10/22/12

B40-BES-PDS-60-9

- 39 -

TYPICAL SYSTEM WIRING DIAGRAM

208-230/3/60 Unit

with 230V Electric Defrost Evaporator

60Hz

BES

10/22/12

B40-BES-PDS-60-9

- 40 -

TYPICAL SYSTEM WIRING DIAGRAM

208-230/3/60 Unit

with Two (2) 230V Electric Defrost Evaps

60Hz

BES

10/22/12

B40-BES-PDS-60-9

- 41 -

TYPICAL SYSTEM WIRING DIAGRAM

460/3/60 Unit

with 460V Electric Defrost Evaps

60Hz

BES

10/22/12

B40-BES-PDS-60-9

- 42 -

TYPICAL SYSTEM WIRING DIAGRAM

460/3/60 Unit

with Two (2) 460V Electric Defrost Evaps

60Hz

BES

10/22/12

B40-BES-PDS-60-9

- 43 -

EC MOTOR APPLICA TION

EC MOTORS

60Hz

EC Motors - Features and Benets

Air cooled condensing units utilizing electrically commu-

tated motor (EC motor) technology offer many benets;

Improved Efciency, Reduced Sound Levels, Speed Con-

trol, Simplicity and Reliability.

Efciency

EC motors are more energy efcient than conventional

AC (PSC and shaded pole) motors. Unlike AC motors that

see efciency decrease as the motor speed is decreased,
an EC motor efciency remains consistent throughout its

range of operation.
Head Pressure Control

EC motors make it easier to maintain stable head pres­sures when motor speeds are varied according to operat-

ing conditions. When compared to a conventional ooded

valve system, EC motors do a much better job maintaining
stable head pressures. System performance is further
enhanced with consistent liquid temperatures that ensure
optimized operation of the nozzle and TX valve in the
evaporator.
In colder climates, special consideration must be given to
the use of heated and insulated receivers and wind guard
protection on the condenser

Reduced Refrigerant Charge

System charges can be reduced by 30 – 40% by utilizing
variable speed EC motors to control head pressures. The
elimination of the head pressure control valve also elimi-

nates the need for extra refrigerant required to ood the

condenser.

Reduced Energy Consumption

When a system’s head pressure is controlled using a

ooded head pressure control valve, the condenser fan

motor runs at 100% fan speed all of the time. When head
pressure is controlled using an EC motor and the motor
speed is varied according to operating conditions, this
results in lower energy consumption of the motor.
There are also potential energy savings available from the
compressor by running with lower head pressure setting
controlled by a simple EC motor controller.

The amount of energy to be saved depends on; ambient

conditions, system operation conditions and head pres­sure set point.

Sound

As EC motor speeds vary for different operating conditions
they also offer reduced sound levels when compared to
conventional motor running full speed. Sound levels are
reduced on cooler days and in evenings.

Simplicity and Reliability

The installation and control of EC motors is very simple
compared to other methods of speed control used on
conventional AC motors. Lower running operating temper­atures and smooth transitional speed changes make EC
motors durable and reliable.

BES

Full RPM

!

10/22/12

B40-BES-PDS-60-9

- 44 -

EC MOTOR APPLICA TION

(cont’d)

EC MOTORS

60Hz

Variable Speed EC Condenser Fan Motors

ECM fan/motor combinations using DC motors with inte­gral AC to DC conversion allow direct connection to the AC

mains with all the energy saving and control benets of a

DC motor. Ideally, with multiple motors on the condenser,
all should simultaneously slow down /speed up together.
This provides for maximum energy savings and smoothest
head pressure control.

Important Warnings:
(Please read before handling motors)

1. When connecting the unit to the power supply,
dangerous voltages occur. Due to motor
capacitor discharge time, do not open the motor
within 5 minutes after disconnection of all phases.

2. With a Control voltage fed in or a set speed value
being saved, the motor will restart automatically
after a power failure.

3. Dangerous external voltages can be present at the
motor terminals even when the unit is turned off.

4. The Electronics housing can get hot.

5. The cycling on and off of EC motors should be
controlled by the DC control voltage (i.e. 0V DC
will turn motor off). Excessive cycling of the motor
by line voltage contactors may cause stress on
the motors and reduce the motor life.

Speed Adjustment Characteristics

The EC motor varies its speed linearly based on a 1-10V
input signal. At 10 VDC, the motor runs at full speed. At 0
to approx. 1 VDC, the motor turns off. A chart of the speed
control curve is shown below. The motor can be controlled
at any speed below its nominal RPM.

Control Signal

The input control signal is supplied by an external control
signal from a factory installed proportional pressure con­trol. Units with factory installed proportional pressure con­trols are adjusted with initial factory settings. These may

require further adjustments to suit local eld conditions.

Proportional Pressure Control (Factory Installed)
Units equipped with factory installed P352 controls use a
proportional/integral pressure controller to vary and main­tain the motor speed at the desired head pressure. The
controller has two main user adjustable features:

• Head Pressure Set point

• Throttling range

Leave the minimum Output setting at 0% and Jumpers
should be set for Direct Acting (do not re-adjust)

Module

User Adjust

Setpoint

Potentiometer

User Adjust

Throttling Range

Potentiometer

0%

Minimum

Output

Potentiometer

LED Indicator

(Percent of Output)

THROT
RANGE

OUTPU

Connector

MIN

T

Operation Mode

Jumper Positions

34
2
1

N

O

Integration DIP Switch

Direct

Acting

RPM

1

Control voltage [V dc]

Head Pressure Set Point

The head pressure set point potentiometer is adjustable
from 90-250 psig. This maintains a minimum condens­ing temp at the corresponding pressure set point. Typical
R404A set points are from 170-200 psig. (i.e. 78oF - 89oF
Condensing Temperature).
Note: Very low set points may cause the fan motors to run
full speed continually even if the condenser is properly
sized. The fans will turn off if the system pressure falls
below the desired set point.

10

BES

10/22/12

B40-BES-PDS-60-9

- 45 -

EC MOTOR APPLICA TION

(cont’d)

EC MOTORS

60Hz

Minimum Output

The minimum output potentiometer controls the minimum
signal sent to the motor and is factory set at 0%. It is ad­justable between 0 and 60% of the output range. If this is
adjusted to 50%, the motors will not start running until 5V
is applied to the motor. The motor will start running at 50%
of full speed. To maximize sound reduction and energy
savings and to provide the most stable control, it is recom­mended this setting be left at 0%.

Throttling range

The throttling range potentiometer controls how far the
system pressure deviates from the control set point to
generate a 100% output signal from the control and is ad­justable from 10 -100 psig. The throttling range determines
how quickly the motor will reach full speed when detecting
a change in head pressure. For example, if the set point
is 190 psig and the throttling range is 50 psig, when the
system pressure is below 190 psig, the fans will be off.
When the system pressure reaches 240 psig (190+50)
the fans will be at full speed. To make the fans ramp more
slowly the throttling range should be increased. To maxi-

mize sound reduction and energy efciency and to provide

for the most stable control, it is recommended this setting
be left at 100 psig.

Direct Acting (DA) mode. Failure to ensure J1 jumper is
in direct acting mode will cause the system to trip on high
head pressure.

Integration constant

The integration constant switch provides ability to change
controller from a proportional only control to a propor­tional plus integral control. To provide the most respon­sive system and to maintain a stable head pressure, it is
recommended the integration setting be left on “fast” with
the Mode switch set to OFF (Proportional AND Integral
activated)

FAST (on)

3 4

2
1

O

N

MEDIUM (off)
SLOW (off)

OFF (set for PROPORTIONAL /
INTEGRAL MODE)

Reverse acting or direct acting mode of operation

The reverse acting/direct acting jumper is used to en­sure the controller responds correctly to the desired head
pressure. In Direct Acting (DA) mode, the motor speed
increases as the pressure rises above desired set point.
For proper condenser operation, this jumper MUST be in

Transducer Wiring

The P352PN controls use a P266 (P399,or P499) pres­sure transducer to generate a 0.5 to 4.5 VDC input signal.
The transducer is wired to the terminal block at the bottom
of the control as shown in the diagram below.

Interior View and Typical Wiring of P352PN Control

BESA

10/22/12

B40-BES-PDS-60-9

- 46 -

COPELAND

ELECTRICAL DATA

COPELAND MODELS with EC MOTOR

EC MOTORS

60Hz

CONDENSING

UNIT

MODEL

BESA008H2- *

BESA010H2- *

BESA015H2- *

BESA020H2- *

BESA030H2- *
BESA050H8- * T3 2DC3R53KE-TFC 208-230/3/60 22.3 120 1 3.5 31.4 50

BESA051H8- * T3 2DD3R63KE-TFC 208-230/3/60 22.3 120 1 3.5 31.4 50
BESA075H8- * T3 2DL3R78KE-TFC 208-230/3/60 31.6 169 1 3.5 43.0 70
BESA076H8- * T3 2DA3R89KE-TFC 208-230/3/60 32.0 169 2 7 47.0 70
BESA080H8- * T3 3DA3R10ME-TFC 208-230/3/60 41.0 215 2 7 58.3 90
BESA100H8- * T3 3DB3R12ME-TFC 208-230/3/60 43.6 215 2 7 61.5 100
BESA120H8- * T3 3DF3R15ME-TFC 208-230/3/60 48.1 275 2 10.6 70.7 110
BESA150H8- * T3 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 10.6 85.1 125

BESA008M2- *

BESA010M2- *

BESA020M2- *

BESA021M2- *

BESA010M6- *

BESA020M6- *

BESA021M6- * T3 ERCA-021E-TAC 208-230/3/60 8.8 46 1 2.0 13.0 20

BESA030M6- *

BESA005L6- *

BESA008L6- *

BESA010L6- *

BESA015L6- *

BESA020L6- *

BESA021L6- *

BESA030L6- *

BESA032L6- *

BESA035L6- *
BESA040L6- * T3 2DL3F20KE-TFC 208-230/3/60 26.3 161 1 3.5 36.4 60

BESA060L6- * T3 2DB3F25KE-TFC 208-230/3/60 28.2 161 1 3.5 38.8 60
BESA061L6- * T3 3DA3F28KE-TFC 208-230/3/60 30.3 150 1 3.5 41.4 70
BESA075L6- * T3 3DB3F33KE-TFC 208-230/3/60 31.5 161 1 3.5 42.9 70
BESA090L6- * T3 3DF3F40KE-TFC 208-230/3/60 37.0 215 2 7 53.3 90
BESA100L6- * T3 3DS3F46KE-TFC 208-230/3/60 42.0 215 2 7 59.5 100
BESA130L6- * T3 4DBNF54KE-TSK 208-230/3/60 51.3 220 2 10.6 74.7 125
BESA150L6- * T3 4DHNF63KE-TSK 208/230/3/60 52.6 278 2 10.6 76.4 125
BESA220L6- * T3 4DJNF76KE-TSK 208/230/3/60 64.3 374 2 10.6 91.0 150

S2 KAN2-0075-CAV 208-230/1/60 6.1 36 1 1.0 8.6 15
T3 KAN1-0075-TAC 208-230/3/60 3.5 19.9 1 1.0 5.4 15
S2 KAR2-0100-CAV 208-230/1/60 7.4 40 1 1.0 10.3 15
T3 KAR1-0100-TAC 208-230/3/60 4.3 27 1 1.0 6.4 15
S2 KAGB-0150-CAV 208-230/1/60 9.6 55 1 2.0 14.0 20
T3 KAGA-0150-TAC 208-230/3/60 5.5 35.5 1 2.0 8.9 15
S2 KAKB-0200-CAV 208-230/1/60 10.6 55 1 2.0 15.3 26
T3 KAKA-0200-TAC 208-230/3/60 6.8 50 1 2.0 10.5 15
S3 ERF2-0310-CAB 230/1/60 17.0 86 1 3.5 24.8 42
T3 ERF1-0310-TAC 208-230/3/60 11.7 82 1 3.5 18.1 25

S2 KAE2-0075-CAV 208-230/1/60 5.4 36 1 1.0 7.8 15
T3 KAE1-0075-TAC 208-230/3/60 3.4 19.9 1 1.0 5.3 15
S2 KAM2-0100-CAV 208-230/1/60 7.5 40 1 1.0 10.4 15
T3 KAM1-0100-TAC 208-230/3/60 4.5 27 1 1.0 6.6 15
S3
T3 KAKA-0200-TAC 208-230/3/60 6.8 50 1 2.0 10.5 15
S3
T3 ERC1-0200-TAC 208-230/3/60 6.8 46 1 2.0 10.5 15

S2 KARB-010E-CAV 208-230/1/60 7.4 40 1 1.0 10.3 15
T3 KARA-010E-TAC 208-230/3/60 4.3 27 1 1.0 6.4 15
S2 KAKB-021E-CAV 208-230/1/60 10.6 55 1 2.0 15.3 25
T3 KAKA-020E-TAC 208-230/3/60 6.8 50 1 2.0 10.5 15

S3 ERFB-031E-CAB 230/1/60 17.0 86 1 3.5 24.8 40
T3 ERFA-031E-TAC 208-230/3/60 12.4 82 1 3.5 19.0 30

S2 KANB-005E-CAV 208-230/1/60 3.6 24 1 1.0 5.5 15
T3 KANA-006E-TAC 208-230/3/60 2.2 13.2 1 1.0 3.8 15
S2 KAMB-007E-CAV 208-230/1/60 5.6 36 1 1.0 8.0 15
T3 KAMA-007E-TAC 208-230/3/60 3.2 19.9 1 1.0 5.0 15
S2 KAJB-010E-CAV 208-230/1/60 6.9 40 1 1.0 9.6 15
T3 KAJA-011E-TAC
S2 KALB-015E-CAV 208-230/1/60
T3 KALA-016E-TAC 208-230/3/60 6.6 50 1 2.0 10.3 15
S3 EADB-021E-CAB 230/1/60 10.0 58 1 2.0 14.5 20
T3 EADA-020E-TAC 208-230/3/60 6.8 46 1 2.0 10.5 15
S3 EAVB-021E-CAV 208-230/1/60 14.7 102 1 2.0 20.4 35
T3 EAVA-021E-TAC 208-230/3/60 7.4 50 1 2.0 11.3 15
S3 LAHB-032E-CAB 230/1/60 16.7 105 1 3.5 24.4 40
T3 LAHA-032E-TAC 208-230/3/60 12.8 112 1 3.5 19.5 30
S3 LACB-032E-CAB 230/1/60 15.5 105 1 3.5 22.9 35
T3 LACA-032E-TAC 208-230/3/60 12.8 112 1 3.5 19.5 30
S3 2DF3F16KE-CFB 230/1/60 23.2 125 1 3.5 32.4 50
T3 2DF3F16KE-TFC 208-230/3/60 16.8 102 1 3.5 24.5 40

COMPRESSOR

MODEL NO.

KAKB-0200-CAV 208-230/1/60 10.6 55 1 2.0 15.3 26
ERC2-0200-CAB 230/1/60 10.9 58 1 2.0 15.6 25

POWER

SUPPLY

208-230/3/60 4.6 27 1 1.0 6.8 15

COMPRESSOR ECM CONDENSER FAN

RLA LRA QTY FLA

9.9 55 1 2.0 14.4 20

MCA MOP

* I = Indoor, H = Outdoor. Above listed RLA value is based on UL rating method and may differ from published compressor RLA data.

BESB

10/22/12

B40-BES-PDS-60-9

- 47 -

BITZER

ELECTRICAL DATA

BITZER MODELS with EC MOTOR

EC MOTORS

60Hz

CONDENSING

UNIT

MODEL

BESB029H8-* T3 2C0407SH-2DU-Y 208-230/3/60 11.5 60 1 3.5 17.9 25
BESB030H8-*

BESB035H8-*
BESB040H8-* T3 2C0692SH-2DU-Y 208-230/3/60 18.5 115.5 1 3.5 26.6 45

BESB050H8-* T3 4C0770SH-2DU-Y 208-230/3/60 24.5 163 1 3.5 34.1 50
BESB060H8-* T3 4C0969SH-2DU-Y 208-230/3/60 28.5 163 1 3.5 39.1 60
BESB076H8-* T3 4C1145SH-2DU-Y 208-230/3/60 31.5 215 2 7 46.4 70
BESB090H8-* T3 4C1385SH-2DU-Y 208-230/3/60 38.1 215 2 7 54.6 90
BESB100H8-* T3 4C1480SH-2NU-Y 208-230/3/60 42.8 222 2 7 60.5 100

BESB120H8-* T3 4C1761SH-2NU-Y 208-230/3/60 47.1 252 2 10.6 69.5 110
BESB150H8- * T3 4C2067SH-2NU-Y 208-230/3/60 54.0 294 2 10.6 78.1 125
BESB200H8- * T3 4C2397SH-2NU-Y 208-230/3/60 64.0 352 2 10.6 90.6 150

BESB030L6-*
BESB031L6-* T3 4C0770SL-2DU-Y 208-230/3/60 18.5 115.5 1 3.5 26.6 45

BESB039L6-* T3 4C0969SL-2DU-Y 208-230/3/60 20.5 142 1 3.5 29.1 45
BESB050L6-* T3 4C1145SL-2DU-Y 208-230/3/60 21.0 163 1 3.5 29.8 50
BESB060L6-* T3 4C1385SL-2DU-Y 208-230/3/60 25.5 215 1 3.5 35.4 60
BESB080L6-* T3 4C1761SL-2NU-Y 208-230/3/60 31.0 180 2 7 45.8 70
BESB100L6-* T3 4C2067SL-2NU-Y 208-230/3/60 38.0 222 2 7 54.5 90
BESB120L6-* T3 4C2397SL-2NU-Y 208-230/3/60 44.2 252 2 7 62.3 100

S2 2C0484SH-2EU-Y 208-230/1/60 26.0 103 1 3.5 36.0 60
T3 2C0484SH-2DU-Y 208-230/3/60 14.2 97 1 3.5 21.3 35
S2 2C0572SH-2EU-Y 208-230/1/60 25.0 113 1 3.5 34.8 50
T3 2C0572SH-2DU-Y 208-230/3/60 15.5 97 1 3.5 22.9 35

S2 2C0692SL-2EU-Y 208-230/1/60 22.0 115 1 3.5 31.0 50
T3 2C0692SL-2DU-Y 208-230/3/60 13.8 97 1 3.5 20.8 30

COMPRESSOR

MODEL NO.

POWER
SUPPLY

COMPRESSOR

RLA LRA QTY FLA

CONDENSER FAN

MOTOR

MCA MOP

* I = Indoor, H = Outdoor. Above listed RLA value is based on UL rating method and may differ from published compressor RLA data.

BES

10/22/12

B40-BES-PDS-60-9

- 48 -

TYPICAL SYSTEM WIRING DIAGRAM

208-230/1/60 Unit with EC Motor

EC MOTORS

60Hz

BES

10/22/12

B40-BES-PDS-60-9

- 49 -

TYPICAL SYSTEM WIRING DIAGRAM

208-230/3/60 Unit with EC Motor

EC MOTORS

60Hz

BESA

10/22/12

B40-BES-PDS-60-9

- 50 -

COPELAND

GENERIC SERVICE PARTS LIST

COPELAND COMPRESSOR MODELS

MODEL CONDENSER

BESA008H2 1081652 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA010H2 1081653 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA015H2 1081643 N/A N/A 1084927 1079563 1084928 1079563 N/A N/A
BESA020H2 1081644 N/A N/A 1084927 1079563 1084928 1079563 N/A N/A
BESA030H2 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA050H8 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA051H8 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA075H8 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA076H8 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESA080H8 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESA100H8 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESA120H8 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESA150H8 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116

BESA200H8 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESA008M2 1081652 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA010M2 1081653 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA021M2 1081644 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESA010M6 1081653 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA020M6 1081643 N/A N/A 1084927 1079563 1084928 1079563 N/A N/A
BESA021M6 1081644 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESA030M6 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754

BESA005L6 1081652 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA008L6 1081652 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA010L6 1081652 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESA015L6 1081643 N/A N/A 1084927 1079563 1084928 1079563 N/A N/A
BESA020L6 1081643 N/A N/A 1084927 1079563 N/A N/A N/A N/A
BESA021L6 1081643 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESA030L6 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA032L6 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA035L6 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA040L6 1076236 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA060L6 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA061L6 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA075L6 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESA090L6 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESA100L6 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESA130L6 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESA150L6 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESA220L6 1088420 N/A N/A 1088430 1088116 1087070 10881

115/1/60

MOTORS BLADES MOTORS BLADES MOTORS BLADES MOTORS BLADES

208-230/1/60, 208-230/3/60,

200-220/1/50, 200-220/3/50

460/1/60, 460/3/60,

380-400/1/50, 380-400/3/50

16 1087071 1088116

575/3/60

BESB

10/22/12

B40-BES-PDS-60-9

- 51 -

BITZER

GENERIC SERVICE PARTS LIST

BITZER COMPRESSOR MODELS

MODEL CONDENSER

BESB010H8 1079523 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESB015H8 1081643 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESB020H8 1081643 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESB025H8 1081644 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESB029H8 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB030H8 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB035H8 1076236 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB040H8 1076236 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB050H8 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB060H8 1076238 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB076H8 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESB090H8 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESB100H8 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESB120H8 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESB150H8 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESB200H8 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116

BESB010L6 1079523 N/A N/A 1078535 1077321 N/A N/A N/A N/A
BESB015L6 1081643 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESB020L6 1081643 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESB025L6 1081644 N/A N/A 1084927 1079563 1084928 1079563 1084929 1079563
BESB030L6 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESB031L6 1088420 N/A N/A 1088430 1088116 1087070 1088116 1087071 1088116
BESB039L6 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB050L6 1076235 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB060L6 1076236 N/A N/A 1084930 1076754 1084930 1076754 1084931 1076754
BESB080L6 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESB100L6 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754
BESB120L6 1085368 N/A N/A 1087002 1076754 1087002 1076754 1087003 1076754

115/1/60

MOTORS BLADES MOTORS BLADES MOTORS BLADES MOTORS BLADES

208-230/1/60, 208-230/3/60,

200-220/1/50, 200-220/3/50

460/1/60, 460/3/60,

380-400/1/50, 380-400/3/50

575/3/60

NOTES

10/22/12

B40-BES-PDS-60-9

- 52 -

Finished Goods Warranty

10/22/12

B40-BES-PDS-60-9

- 53 -

The terms and conditions as described below in the General Warranty Policy cover all products
manufactured by National Refrigeration.

GeneraL Warranty PoLiCy

Subject to the terms and conditions hereof, the Company warrants all Products, including Service
Parts, manufactured by the Company to be free of defects in material or workmanship, under nor­mal use and application for a period of one (1) year from the original date of installation, or eighteen

(18) months from the date of shipment from the Company, whichever occurs rst. Any replacement

part(s) so supplied will be warranted for the balance of the product’s original warranty. The part(s) to
be replaced must be made available in exchange for the replacement part(s) and reasonable proof
of the original installation date of the product must be presented in order to establish the effective
date of the warranty, failing which, the effective date will be based upon the date of manufacture plus
thirty (30) days. Any labour, material, refrigerant, transportation, freight or other charges incurred in
connection with the performance of this warranty will be the responsibility of the owner at the cur­rent rates and prices then in effect. This warranty may be transferred to a subsequent owner of the
product.

this Warranty does not CoVer

(a) Damages caused by accident, abuse, negligence, misuse, riot, re, ood, or Acts of God (b) damages

caused by operating the product in a corrosive atmosphere (c) damages caused by any unauthorized
alteration or repair of the system affecting the product’s reliability or performance (d) damages caused
by improper matching or application of the product or the product’s components (e) damages caused by
failing to provide routine and proper maintenance or service to the product (f) expenses incurred for the
erecting, disconnecting, or dismantling the product (g) parts used in connection with normal maintenance,

such as lters or belts (h) products no longer at the site of the original installation (i) products installed

or operated other than in accordance with the printed instructions, with the local installation or building
codes and with good trade practices (j) products lost or stolen.

No one is authorized to change this WARRANTY or to create for or on behalf of the Company any
other obligation or liability in connection with the Product(s). There is no other representation, warranty
or condition in any respect, expressed or implied, made by or binding upon the Company other than
the above or as provided by provincial or state law and which cannot be limited or excluded by such
law, nor will we be liable in any way for incidental, consequential, or special damages however caused.

The provisions of this additional written warranty are in addition to and not a modication of or subtraction

from the statutory warranties and other rights and remedies provided by Federal, Provincial or State laws.

PROJECT INFORMATION

System
Model Number Date of Start-Up
Serial Number Service Contractor
Refrigerant Phone
Electrical Supply Fax

10/22/12

DISTRIBUTED BY:

General Sales, Parts & Service Manufacturing & Engineering

135 Little Nine Drive, Morehead City, NC 28557

252-240-2829 • 1-800-24-BALLY • FAX: [phone]
e-mail: [e-mail] • www.ballyrefboxes.com

Due to Manufacturer’s policy of continuous product improvement,

the Manufacturer reserves the right to make changes without notice.
