Product Information Packet
RL625A
1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Part Detail
Revision: W Status: NLA/A Change #: Proprietary: No Type: AC Elec. Spec: 19WGW049 CD Diagram: CD0052 Mfg Plant: Mech. Spec: 19K015 Layout: 19LYK015 Poles: 02 Created Date: 06-26-2007 Base: RS Eff. Date: 11-08-2019 Leads: 5#14 A&J,2#18 B PH
Specs
Catalog Number: RL625A Frame: 56H Frame Material: Steel Output @ Frequency: 1.500 HP @ 60 HZ Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ Voltage @ Frequency: 115.0 V @ 60 HZ
230.0 V @ 60 HZ
Agency Approvals: CE
CSA
UR Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Resilient Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None Current @ Voltage: 18.000 A @ 115.0 V
9.000 A @ 230.0 V
KVA Code: H Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: No Locked Bearing Motor Lead Quantity/Wire Size: 5 @ 14 AWG, A&J Motor Lead Exit: Terminal Panel Motor Lead Termination: None Motor Type: 1924L Mounting Arrangement: F1 Power Factor: 75 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: Standard Pulley Shaft Indicator: Standard Rodent Screen: None Shaft Extension Location: Pulley End Shaft Ground Indicator: No Shaft Grounding Shaft Rotation: Reversible
Design Code: L
Shaft Slinger Indicator: No Slinger
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Terminal Panel Front Shaft Indicator: None Heater Indicator: No Heater Insulation Class: B Inverter Code: Not Inverter
Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: Automatic Thermal Overload Winding Thermal 1 Location: SB Winding Thermal 2: None
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Nameplate NP1986A
CAT.NO. ENCL OPEN
SPEC. 19K015W049G1 FRAME 56H
HP 1.5
VOLTS 115/230
AMPS 18/9
RPM 3450
HZ 60 PH 1 CL B SER.F. 1.15 DES L CODE H FL EFF 72 PF 75
RATING 40C AMB-CONT SF AMP - USABLE AT 208V 8.9
SER.
MANUAL N AUTO Y NONE N
BLANK
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Parts List
Part Number Description Quantity SA088209 SA 19K015W049G1 1.000 EA RA081137 RA 19K015W049G1 1.000 EA TPCRJ38CS THERMAL 1PH 1.00 AUT 135C 1.000 EA EC1645A06SP ELEC CAP, 645-774 MFD, 125V, 2.06D X 4. 1.000 EA 11XW0832G06 #8-32 X 3/8, TAPTITE II, HEX WSHR SLTD 1.000 EA 19EP3200BT02 MACHINING 19 FRAME 203 BRG ENC W/HUB 1.000 EA RM1000A04 CUSHION RING, MDL 34 1.000 EA HA6005A01A CLAMP CUSHION RING ASSY 35 FRAME 1.000 EA LD5000A01 LEAD ASSY, ML1400DF14 7" RING TRM EA END 1.000 EA 51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 2.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA 35CB4802A02SP CAPACITOR COVER, STAMPED X 1.000 EA 35GS3001A02 GASKET, CA.COVER, 5.38 LONG .06 CS301 1.000 EA HW5100A03 WAVY WASHER (W1543-017) 1.000 EA 19EP3201BT02 PU ENDPLATE, MACH OPEN 203 BRG 1.000 EA RM1000A04 CUSHION RING, MDL 34 1.000 EA HA6005A01A CLAMP CUSHION RING ASSY 35 FRAME 1.000 EA XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA 19CB4501 TERMINAL BOX LID, STAMPED 1.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 2.000 EA HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA WD4100A49 CAPLUG,BP-13/16,PLUG W/RECESSED HEAD 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Parts List (continued)
Part Number Description Quantity 34GS5003 FOAM SLEEVE, ID = 2 1/16" X 3 3/8" 1.000 EA WD1000A15 3-520132-2 AMP FLAG (4M/RL) 16-14AWG 2.000 EA SP5174A02 MDL 19L TERM PANEL SWITCH W/TABS & 1" TH 1.000 EA 35BA4002H01A RESILIENT BASE, STAMPED-BLACK PRIMER 1.000 EA HA3100A64 THRUBOLT 10-32 X 9.875 4.000 EA LB1118 LABEL,WARNING (ROLL LABEL) 1.000 EA LB1172A01 CUSTOM MTR CARTON LABEL LASER PRINTER 1.000 EA LC0052 CONNECTION LABEL 1.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA NP1986A CM NAMEPLATE, BOXES, UL & CSA 1.000 EA 35PA1088 PALLET PACK KIT, 10 PK 1.000 EA LB1417 LABEL CARTON 6X4 PERFORATED BLANK ROLLS 1.000 EA
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
AC Induction Motor Performance Data
Record # 6152 - Typical performance - not guaranteed values
Winding: 19WGW049-R001 Type: 1924L Enclosure: OPEN
Nameplate Data
230 V, 60 Hz:
High Voltage Connection Rated Output (HP) 1.5 Full Load Torque 2.25 LB-FT Volts 115/230 Start Configuration direct on line Full Load Amps 18/9 Breakdown Torque 6.4 LB-FT R.P.M. 3450 Pull-up Torque 5.4 LB-FT Hz 60 Phase 1 Locked-rotor Torque 6.8 LB-FT NEMA Design Code L KVA Code H Starting Current 46.3 A Service Factor (S.F.) 1.3 No-load Current 6 A
NEMA Nom. Eff. 72 Power Factor 75 LinelineRes.@25ºC
1.25ΩAPh
0.954ΩBPh
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 57°C S.F. Amps 21/10.5 Temp. Rise @ S.F. Load 84°C
Load Characteristics 230 V, 60 Hz, 1.5 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 41 56 70 75 83 84 0 Efficiency 47.5 63 68.5 72 72.3 71 0 Speed 3568 3546 3523 3497 3468 3435 0 Line amperes 6.3 7 7.7 9 10 12 10.5
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Performance Graph at 230V, 60Hz, 1.5HP Typical performance - Not guaranteed values
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
AC Induction Motor Performance Data
Record # 23844 - Typical performance - not guaranteed values
Winding: 19WGW049-R002 Type: 1924L Enclosure: OPEN
Nameplate Data
230 V, 60 Hz:
High Voltage Connection Rated Output (HP) 1.5 Full Load Torque 2.28 LB-FT Volts 115/230 Start Configuration direct on line Full Load Amps 18/9 Breakdown Torque 6.34 LB-FT R.P.M. 3450 Pull-up Torque 4.74 LB-FT Hz 60 Phase 1 Locked-rotor Torque 6.03 LB-FT NEMA Design Code L KVA Code H Starting Current 53.2 A Service Factor (S.F.) 1.3 No-load Current 5.41 A
NEMA Nom. Eff. 72 Power Factor 75 LinelineRes.@25ºC
1.31ΩAPh
0.993ΩBPh
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 50°C S.F. Amps 21/10.5 Temp. Rise @ S.F. Load 56°C
Load Characteristics 230 V, 60 Hz, 1.5 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 46 61 73 80 83 86 84 Efficiency 47.5 63.8 67.7 69.1 72.4 70.3 72 Speed 3570 3549 3525 3501 3474 3436 3466 Line amperes 5.8 6.51 7.63 8.94 10.2 12.1 10.6
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Performance Graph at 230V, 60Hz, 1.5HP Typical performance - Not guaranteed values
Page 10 of 12
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Page 11 of 12
Product Information Packet: RL625A - 1.5HP,3450RPM,1PH,60HZ,56h,1924L,OPEN,F1
Page 12 of 12
