Badger Meter ModMAG M1000 Installation And Operation Manual

®

Badger Meter Europa GmbH

ModMAG® M1000

HART® protocol

INSTALLATION AND OPERATION MANUAL

April 2017

MID_M1000_BA_HART_02_1704

Contents Page

1. Basic safety recommendations ..................................................................................... 5

2. Dynamic variables .......................................................................................................... 5

Volumetric flow unit codes ....................................................................................... 5

Volume unit code .................................................................................................... 6

3. Device variables .............................................................................................................. 6

4. Field device status .......................................................................................................... 8

5. Universal commands ...................................................................................................... 9

Command 0 Read Transmitter Unique Identifier ...................................................... 9

Command 1 Read primary variable ........................................................................10

Command 2 Read Loop Current and Percent of Range .........................................10

Command 3 Read Dynamic Variables and Loop Current .......................................11

Command 3 Read Dynamic Variables and Loop Current .......................................12

Command 6 Write Polling Address .........................................................................13

Backward compatibility TEST .................................................................................14

Command 7 Read Loop Configuration ...................................................................15

Command 8 Read Dynamic Variable Classification ................................................15

Command 9 Read Device Variable with Status ......................................................16

Command 11 Read Unique Identifier Associated With Tag ....................................18

Command 12 Read message .................................................................................18

Command 13 Read tag descriptor, and date ..........................................................19

Command 14 Read PV sensor information ............................................................20

Command 15 Read PV output sensor information ..................................................21

Command 16 Read Assembly Number ..................................................................22

Command 17 Write Message .................................................................................22

Command 18 Write Tag, Description, Date ............................................................23

Command 19 Write Assembly number ...................................................................24

Command 20 Read Long tag .................................................................................25

Command 21 Read Unique Identifier Associated With Long Tag ...........................26

Command 22 Write Long tag ..................................................................................26

Command 38 Reset Configuration Changed Flag ..................................................27

Command 48 Read Additional Device Status .........................................................28

6. Additional features ........................................................................................................30

Command 40 Enter/Exit Fixed Current Mode .........................................................30

Command 42 Perform Device Reset ......................................................................31

Command 44 Write Primary Variable Units ............................................................32

Command 59 Write Number of Response Preambles ............................................32

7. Device specific commands ...........................................................................................34

Command 130 Read Product Code ........................................................................34

Command 131 Read Product Name .......................................................................34

Command 132 Read Firmware Name ....................................................................35

Command 133 Read Application Version ...............................................................36

MID_M1000_BA_HART_02_1704

Contents Page

Command 134 Read Compile Date ........................................................................36

Command 135 Read OTP Boot Checksum ............................................................37

Command 136 Read Flash OS Checksum .............................................................37

Command 141 Read Serial Number .......................................................................38

Command 150 Read Detector Diameter .................................................................39

Command 154 Read Detector Factor .....................................................................40

Command 156 Read Detector Offset .....................................................................41

Command 158 Read Amplifier Factor ....................................................................41

Command 160 Read Detector Current ...................................................................42

Command 162 Read Power Line Frequency ..........................................................43

Command 163 Write Power Line Frequency ..........................................................43

Command 164 Read Excitation Frequency ............................................................44

Command 165 Write Excitation Frequency ............................................................45

Command 166 Read Scale Factor .........................................................................45

Command 167 Write Scale Factor ..........................................................................46

Command 172 Read Polarization Voltage ..............................................................47

Command 173 Read Full Scale Flow .....................................................................47

Command 174 Write Full Scale Flow .....................................................................48

Command 175 Read Flow Unit ..............................................................................48

Command 176 Write Flow Unit ...............................................................................49

Command 177 Read Volume Unit ..........................................................................50

Command 178 Write Volume Unit ..........................................................................50

Command 181 Read Full Scale Velocity ................................................................51

Command 182 Write Full Scale Velocity .................................................................51

Command 183 Read Low Flow Cut Off ..................................................................52

Command 184 Write Low Flow Cut Off ..................................................................53

Command 185 Read Flow Direction .......................................................................53

Command 186 Write Flow Direction .......................................................................54

Command 189 Read Coil Settling Time..................................................................54

Command 190 Read Digital Input Operation ..........................................................55

Command 191 Write Flow Direction .......................................................................56

Command 192 Read Digital Input Status ................................................................57

Command 197 Write Alarm Mode ..........................................................................58

Command 200 Read Pulses per Unit .....................................................................58

Command 201 Write Pulses per Unit .....................................................................59

Command 202 Read Pulse Width ..........................................................................60

Command 203 Write Pulse Width...........................................................................60

Command 204 Read Flow Alarm Min .....................................................................61

Command 205 Write Flow Alarm Min .....................................................................62

Command 206 Read Flow Alarm Max ....................................................................63

Command 207 Write Flow Alarm Max ....................................................................64

Command 208 Read Digital Output Mode ..............................................................64

Command 209 Write Digital Output Mode ..............................................................65

MID_M1000_BA_HART_02_1704

Contents Page

Command 210 Read Digital Output Operation .......................................................66

Command 211 Write Digital Output Operation........................................................67

Command 212 Read Full Scale Frequency ............................................................68

Command 213 Write Full Scale Frequency ............................................................68

Command 214 Read Median ..................................................................................69

Command 215 Write Median ..................................................................................69

Command 216 Read Moving Average ....................................................................70

Command 217 Write Moving Average ....................................................................71

Command 229 Read Menu Language Code ..........................................................71

Command 231 Read Empty Pipe Mode .................................................................73

Command 232 Write Empty Pipe Mode..................................................................73

Command 233 Read Empty Pipe Threshold Resistance ........................................74

Command 234 Write Empty Pipe Threshold Resistance ........................................74

Command 238 Read Empty Pipe Actual Resistance ..............................................75

Command 240 Read Flow Simulation ....................................................................76

Command 241 Write Flow Simulation ....................................................................77

Command 242 Remote Login .................................................................................79

Command 243 Read Rights ...................................................................................79

Command 244 Command Action Request .............................................................80

Command 247 Read Random ................................................................................81

8. Rights – summary ..........................................................................................................82

9. Return of goods for repair/Harmless declaration ........................................................83

MID_M1000_BA_HART_02_1704

Basic safety recommendations / Dynamic variables Page 5/83

15

Cubic Feet per Minute

16

Gallons per Minute

17

Liters per Minute

18

Imperial Gallons per Minute

19

Cubic Meter per Hour

22

Gallons per Second

23

Million Gallons per Day

24

Liters per Second

25

Million Liters per Day

26

Cubic Feet per Second

27

Cubic Feet per Day

28

Cubic Meters per Second

29

Cubic Meters per Day

30

Imperial Gallons per Hour

31

Imperial Gallons per Day

130

Cubic Feet per Hour

131

Cubic Meters per Minute

132

Barrels per Second

133

Barrels per Minute

134

Barrels per Hour

136

Gallons per Hour

137

Imperial Gallons per Second

138

Liters per Hour

242

US Fluid ounces per minute

1. Basic safety recommendations

Please see “Basic safety recommendations” in installation and operation manual ModMAG

®

M1000.

2. Dynamic variables

Primary Variable Volumetric Flow rate

Secondary Variable T1+

Tertiary Variable T1-

Quaternary Variable T1NET

Volumetric flow unit codes

MID_M1000_BA_HART_02_1704

Dynamic variables / Device variables Page 6/83

40

Gallons

41

Liters

42

Imperial gallons

43

Cubic meters

46

Barrels

112

Cubic feet

236

Hectoliters

240

Mega gallons

241

Acre-feet

Code

Classification

Units

Value

Status

Response code

0

Volumetric flow

Selected flow unit

Actual flow rate

α

0

1

Velocity

m/s

Actual flow velocity

α

0

2

Volume

Selected volume unit

Totalizer T1+

β 0 3

Volume

Selected volume unit

Totalizer T1-

β

0

4

Volume

Selected volume unit

Totalizer T1Net

β

0

5

Analytical

%

Relative flow rate

α 0 6

Volumetric flow

m3/s

Actual flow rate

α

0

7

Volume

m3

Totalizer T1+

β

0

8

Volume

m

3

Totalizer T1-

β 0 9

Volume

m3

Totalizer T1Net

β

0

10

Volume

m3

Totalizer T2+

β

0

11

Volume

m3

Totalizer T2-

β 0 12

Volume

m3

Totalizer T2Net

β

0

13

Analytical

%

Relative flow rate

α

14

Current

mA

Output current

α

14

15

Volumetric flow

Selected flow unit

Actual flow rate

α

14

16

Volume

Selected volume unit

Totalizer T1+

β

14

17

Volume

Selected volume unit

Totalizer T1-

β

14

18

Volume

Selected volume unit

Totalizer T1Net

β

14

Volume unit code

3. Device variables

MID_M1000_BA_HART_02_1704

Dynamic variables / Device variables Page 7/83

Flow meter status

Device variable status

Flow simulation active

Manual fixed; Not limited

Bad

Bad; Not limited

Good

Good; Not limited

Flow meter status

Device variable status

Bad

Bad; Not limited

Good

Good; Not limited

Status α

Status β

MID_M1000_BA_HART_02_1704

Field device status Page 8/83

Bit

Status indication

Meaning

7

Field device malfunction

Some fault occurred, except pulse output overload

6

Configuration changed

Set whenever a configuration change is

operator interface

5

Cold start

Set, for one transaction only to each master, when a field device is powered up

4

More status available

Some fault occurred. Use command #48 to retrieve further information

3

Analog output fixed

The device is in multidrop mode, or the flow simulation is active (command #241)

2

Analog output saturated

Analog output is out of range

1

Primary variable out of limits

Relative flow rate <0% or relative flow rate >100%

0

Non-primary variable out of limits

Not implemented, always 0

4. Field device status

made by any host, or through a local

MID_M1000_BA_HART_02_1704

Universal commands Page 9/83

Byte

Description

None

Byte

Description

#0

Device Type Code for Expansion

254

#1

Manufacturer Identification Mode

189 = Badger Meter

#2

Manufacturer Device Type

3 = M1000R

#3

Number of Requested Preambles

5

#4

Revision Level of Universal Command

7

#5

Revision Level of Transmitter Document

1

#6

Software Revision Level

14

#7

(Most Significant 5 Bits) Hardware Revision Level

1

(Least Significant 3 Bits) Physical Signaling Code

0

#8

Flags, none defined at this time

0

#9

Device Identification Number, 24Bit, MSB

#10

Device Identification Number, 24Bit

#11

Device Identification Number, 24Bit, LSB

#12

Number of Preambles to be sent

5 (5…20)*

#13

Maximum Number of Device Variables

13

#14

Configuration Change Counter, MSB

#15

Configuration Change Counter, LSB

#16

Extended Field Device Status

0

#17

Manufacturer Identification Code, MSB

0

#18

Manufacturer Identification Code, LSB

189 = Badger Meter

#19

Private Distributor Identification Code, MSB

0

#20

Private Distributor Identification Code, LSB

189 = Badger Meter

#21

Device Profile

1

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

02

80

00

82

5. Universal commands

Command 0 Read Transmitter Unique Identifier

Request Data Bytes

Response data bytes

* Configurable

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Universal commands Page 10/83

Preamble

Start delimiter

Address Command Byte count Status

Data

Checksum

FF FF FF FF FF

06

80

00

18

00 42

FE BD 03 05 07 01 0E 08 00 0A E1 39 05 0D 00 01 00 00 BD 00 BD 01

43

Byte

Description

None

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

01

00

EF

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

01

07

00 42

18 40 A0 C9 48

D7

Byte

Description

None

Byte

Description

#0..#3

Primary Variable Loop Current (units of mA) , IEEE754

#4..#7

Primary Variable Percent of Range (units of percent) , IEEE754

Code

Description

0

No Command Specific Error

Response example:

Command 1 Read primary variable

Request Data Bytes

Response Codes

Request example:

Response example:

Command 2 Read Loop Current and Percent of Range

Request Data Bytes

Response Data Bytes

Long frame from slave

Response Codes

MID_M1000_BA_HART_02_1704

Universal commands Page 11/83

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

02

00

EC

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

02

0A

00 00

41 61 78 9B 42 7C 4C 71

22

Byte

Description

None

Byte

Description

#0..#3

Primary Variable Loop Current (units of mA) , IEEE754

#4

Primary Variable Unit Code

#5..#8

Primary Variable, IEEE754

#9

Secondary Variable Unit Code

#10..#13

Secondary Variable, IEEE754

#14

Tertiary Variable Unit Code

#15..#18

Tertiary Variable, IEEE754

#19

Quaternary Variable Unit Code

#20..#23

Quaternary Variable, IEEE754

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

03

00

ED

Request example:

Response example:

Long frame from

slave

Data:

14.09194 mA

63.0746 %

Command 3 Read Dynamic Variables and Loop Current

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Universal commands Page 12/83

Preamble

Start delimiter

Address

Command

Byte count Status

Data

Checksum

FF FF FF FF FF 86

BD 03 0A E1 39 03

1A

00 42

41 A0 00 00 18 40 A0 E0 91 29 49 4C EF 7C 29 42 7D F6 14 29 49 4C EB 84

D1

Byte

Description

None

Byte

Description

#0..#3

Primary Variable Loop Current (units of mA) , IEEE754

#4

Primary Variable Unit Code

Volumetric Flow Unit Codes

#5..#8

Primary Variable, IEEE754

#9

Secondary Variable Unit Code

Volume Unit Code

#10..#13

Secondary Variable, IEEE754

#14

Tertiary Variable Unit Code

Volume Unit Code

#15..#18

Tertiary Variable, IEEE754

#19

Quaternary Variable Unit Code

Volume Unit Code

#20..#23

Quaternary Variable, IEEE754

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

03

00

ED

Response example:

Long frame

from slave

Data: 20mA

5.0274128913879395 L/S

839415.75 L

63.49031066894531 L

839352.25 L

Command 3 Read Dynamic Variables and Loop Current

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Universal commands Page 13/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF

86

BD 03 0A E1

03

1A

00

41 A0 00 00 18 40 A0 E0 91 29 49 4C EF 7C 29

D

Byte

Description

#0

Polling Address

0..63

#1

Loop Current Mode

0 = signaling disabled; 1 = signaling enabled

Byte

Description

#0

Polling Address

0 (0..63)

#1

Loop Current Mode

0 = signaling disabled; 1 = signaling enabled

Code

Description

0

No Command Specific Error

2

Invalid Polling Address Selection

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

06

02

00 00

EA

Response example:

Long frame

from slave

FF

39

Data: 20mA

5.0274128913879395 L/S

839415.75 L

63.49031066894531 L

839352.25 L

Command 6 Write Polling Address

Request Data Bytes

Response Data Bytes

Response Codes

42

42 7D F6 14 29 49 4C EB 84

1

Request example:

MID_M1000_BA_HART_02_1704

Long frame

from slave

Universal commands Page 14/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

06

04

00 48

00 00

A0

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

06

01

00

E9

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

06

04

00 40

00 01

A0

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

06

01

3F

D6

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

06

04

00 48

3F 00

9F

Response example:

Long frame

from slave

Data: Polling address = 0 Loop Current Mode = 0 (signaling disabled)

Backward compatibility TEST

Request example:

Long frame

from slave

Response example:

Long frame

from slave

Data: Polling address = 0 Loop Current Mode = 1 (signaling enabled)

Request example:

Long frame

from slave

Response example:

Long frame

from slave

Data: Polling address = 63

MID_M1000_BA_HART_02_1704

Universal commands Page 15/83

Byte

Description

None

Byte

Description

#0

Polling Address

0 (0..63)

#1

Loop Current Mode

0=disabled; 1=enabled

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

07

00

E9

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

07

04

00 42

00 01

AA

Byte

Description

None

Byte

Description

#0

Primary Variable Classification

66 = Volumetric Flow

#1

Secondary Variable Classification

68 = Volume

#2

Tertiary Variable Classification

68 = Volume

#3

Quaternary Variable Classification

68 = Volume

Command 7 Read Loop Configuration

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Command 8 Read Dynamic Variable Classification

Request Data Bytes

Response Data Bytes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Universal commands Page 16/83

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

08

00

E6

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

08

06

00 42

42 44 44 44

A0

Byte

Description

#0

Slot 0: Device Variable Code

#1

Slot 1: Device Variable Code

#2

Slot 2: Device Variable Code

#3

Slot 3: Device Variable Code

#4

Slot 4: Device Variable Code

#5

Slot 5: Device Variable Code

#6

Slot 6: Device Variable Code

#7

Slot 7: Device Variable Code

Byte

Description

#0

Extended Field Device Status

0

#1

Slot 0: Device Variable Code

#2

Slot 0: Device Variable Classification

#3

Slot 0: Units Code

#4..#7

Slot 0: Device Variable Value

#8

Slot 0: Device Variable Status

#9..#16

Slot 1

#17..#24

Slot 2

#25..#32

Slot 3

#33..#40

Slot 4

#41..#48

Slot 5

#49..#56

Slot 6

#57..#64

Slot 7

#65..#68

Time stamp

Response Codes

Request example:

Response example:

Command 9 Read Device Variable with Status

Request Data Bytes

Response Data Bytes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Universal commands Page 17/83

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

14

Device Variables Returned for Device Variables

30

Command Response Truncated

Preamble

Start delimiter

Address

Command

Byte count

Data

Check sum

FF FF FF FF FF

82

BD 03 0A E1 39

09

08

00 00 00 00 00 00 00 00

EF

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

09

47

00 42

00

0E 8C 95 80

92

Response Codes

Request example:

Response example:

Long frame

from slave

Data: 0 .. Extended Field Device Status Slot 0: Volumetric Flow; 5.029623031616211 L/s; Good Slot1: Velocity; 2.561566114425659 m/s; Good Slot2: Volume; 853399.1875 L; Good Slot3: Volume; 63.49031066894531 L; Good Slot4: Volume; 853335.6875 L; Good Slot 5: Analytical; 102.462646484375 %; Good Slot 6: Volumetric Flow; 0.00502962339669466 m Slot7: Volume; 853.399169921875 m

3

; Good

3

/s; Good

Time Stamp

00 42 18 40 A0 F2 AC C0 01 43 15 40 23 F0 B3 C0 02 44 29 49 50 59 73 C0 03 44 29 42 7D F6 14 C0 04 44 29 49 50 55 7B C0 05 51 39 42 CC EC E0 C0 06 42 1C 3B A4 CF 8A C0 07 44 2B 44 55 59 8C C0

MID_M1000_BA_HART_02_1704

Universal commands Page 18/83

Byte

Description

#0..#5

Tag (Packed ASCII)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Data

Check sum

FF FF FF FF FF

82

00 00 00 00 00

0B

06

37 1C 30 C2 08 20

7E

Preamble

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

00 00 00 00 00

0B

18

00 42

FE BD 03 05 07 01 0E 08 00 0A E1 39 05 0D 00 01 00 00 BD 00 BD 01

48

Byte

Description

None

Byte

Description

#0..#23

Message (Packed ASCII)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

0C

00

E2

Command 11 Read Unique Identifier Associated With Tag

Request Data Bytes

Response Data Bytes Same as Command 0 Read Unique Identifier

Response Codes

Request example:

Data:

“M1000 ”

Response example:

Start delimiter

Command 12 Read message

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Universal commands Page 19/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1

0C

1A

00 42

08 11 07 15 28 0D 15 41 52 80 93

20

29

Byte

Description

None

Byte

Description

#0..#5

Tag (Packed ASCII)

#6..#17

Descriptor (Packed ASCII)

#18..#20

Date Code (Day, Month, Year)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

0D

00

E3

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

0D

17

00 42

37 1C 30 C2 08 20 82 08 20 82 08 20 82 08 20 82 08 20 01 01 00

43

Response example:

Long frame

from slave

39

Data: “BADGER METER INC, M1000

Command 13 Read tag descriptor, and date

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

83 B2 03 71 C3 0C 20 82 08 20 82 08

Response example:

Data: Tag: “M1000 ” Descriptor: “ ” Day:1 Month: 1 Year: 1900

Long frame

from slave

MID_M1000_BA_HART_02_1704

Universal commands Page 20/83

Byte

Description

None

Byte

Description

#0..#2

Transducer Serial Number

#3

Transducer Limits and Minimum Span Units Code

Volumetric Flow Unit Codes

#4..#7

Upper Transducer Limit

12 m/s

#8..#11

Lower Transducer Limit

0.03m/s

#12..#15

Minimum Span

0.1*(Upper-Lower)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

0E

00

E0

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

0E

12

00 42

0A E1 39 18 41 BC 7E DE 3D 71 46 3A 40 16 6B 62

4C

Command 14 Read PV sensor information

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

Data: Transducer Serial Number: 0AE139 Transducer Limits and Minimum Span Units Code: L/s Upper Transducer Limit: 23.561946868896484 Lower Transducer Limit: 0.05890486389398575 Minimum Span: 2.350304126739502

MID_M1000_BA_HART_02_1704

Universal commands Page 21/83

Byte

Description

None

Byte

Description

#0

PV Alarm Selection Code

0 .. High

252 … Unknown

#1

PV Transfer Function Code

0 = linear

#2

PV Upper and Lower Range Values Units Code

Volumetric Flow Unit Codes

#3..#6

PV Upper Range Value

Full Scale Flow

#7..#10

PV Lower Range Value

0 (always zero)

#11..#14

PV Damping Value

0 (always zero)

#15

Write Protect Code

251 = Not Implemented

#16

Reserved

250

#17

PV Analog Channel Flags

0 (always zero)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

0F

00

E1

Preamble

Start delimiter

Address

Command Byte

Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

0F

14

00 42

FB 00 18 40 9D 14 63 00 00 00 00 00 00 00 00 FB FA 00

FB

Command 15 Read PV output sensor information

Request Data Bytes

Response Data Bytes

1 … Low 251 … None

Response Codes

Request example:

Response example:

Long frame

from slave

Data: Alarm Selection: None Transfer Function: Linear Upper Range: 4.908738613128662L/s Lower Range: 0 L/s Damping Value: 0 s Write Protect Code: None Reserved: 250 Analog Channel Flags: 0

count

MID_M1000_BA_HART_02_1704

Universal commands Page 22/83

Byte

Description

None

Byte

Description

#0..#2

Final Assembly Number

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

10

00

FE

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

10

05

00 42

0A 1B 2C

80

Byte

Description

#0..#23

Message (Packed ASCII)

Byte

Description

#0..#23

Message (Packed ASCII)

Code

Description

0

No Command Specific Error

5

Too Few Data Bytes Received

Command 16 Read Assembly Number

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

Data: Final Assembly Number: 0A 1B 2C

Command 17 Write Message

Request Data Bytes

Response Data Bytes

Response Codes

MID_M1000_BA_HART_02_1704

Universal commands Page 23/83

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

11

18

08 11 07 15 28 0D 15 41 52 80 93 83 B2 03 71 C3 0C 20 82 08 20 82 08 2D

7D

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF

86

BD 03 0A E1

11

1A

00 40

08 11 07 15 28 0D 15 41 52 80 93 83

2D

3B

Byte

Description

#0..#5

Tag (Packed ASCII)

#6..#17

Descriptor (Packed ASCII)

#18..#20

Date Code (Day, Month, Year)

Byte

Description

#0..#5

Tag (Packed ASCII)

#6..#17

Descriptor (Packed ASCII)

#18..#20

Date Code (Day, Month, Year)

Code

Description

0

No Command Specific Error

5

Too Few Data Bytes Received

9

Invalid Date Code Detected

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

12

15

37 1C 30 C2 08 20 82 08 20 82 08 20 82 08 20 82 08 20 1B 08 72

79

Request example:

Long frame

from slave

Response example:

Long frame

from slave

FF

39

Data: “BADGER METER INC, M1000 -”

Command 18 Write Tag, Description, Date

Request Data Bytes

B2 03 71 C3 0C 20 82 08 20 82 08

Response Data Bytes

Response Codes

Request example:

Long frame from slave

MID_M1000_BA_HART_02_1704

Universal commands Page 24/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

12

17

00 42

37 1C 30 C2 08 20 82 08 20 82 08 20 82 08 20 82 08 20 1B 08 72

3D

Byte

Description

#0..#2

Final Assembly Number

Byte

Description

#0..#2

Final Assembly Number

Code

Description

0

No Command Specific Error

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

13

03

2C 1B 0A

C3

Response example:

Long frame from slave

Data: Tag: “M1000 ” Descriptor: “ ” Day:27 Month: 8 Year: 2014

Command 19 Write Assembly number

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Universal commands Page 25/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

13

05

00 42

2C 1B 0A

83

Byte

Description

None

Byte

Description

#0..#31

Long tag (Latin-1)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

14

00

FA

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF

86

BD 03 0A E1

14

22

00

00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

00

9

Response example:

Long frame

from slave

Data: Final Assembly Number: 2C 1B 0A

Command 20 Read Long tag

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

F

Long frame

from slave

39

42

00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

E

MID_M1000_BA_HART_02_1704

Universal commands Page 26/83

Byte

Description

#0..#31

Long tag (Latin-1)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command Byte count

Data

Checksum

FF FF FF FF FF

82

00 00 00 00 00

15

20

00 00 00 00 00 00 00 00 00 00 00 00 00 00

00 00 00 00

B7

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86 00 00 00 00 00

15 18 00 42

FE BD 03 05 07 01 0E 08 00 0A E1 39 05 0D 00 02 00 00 BD 00 BD 01

55

Byte

Description

#0..#31

Long tag (Latin-1)

Byte

Description

#0..#31

Long tag (Latin-1)

Code

Description

0

No Command Specific Error

5

Too Few Data Bytes Received

Command 21 Read Unique Identifier Associated With Long Tag

Request Data Bytes

Response Data Bytes Same as Command 0 Read Unique Identifier

Response Codes

Request example:

Response example:

Command 22 Write Long tag

Request Data Bytes

Response Data Bytes

00 00 00 00 00 00 00 00 00 00 00 00 00 00

Response Codes

MID_M1000_BA_HART_02_1704

Universal commands Page 27/83

Preamble

Start delimiter

Address

Command Byte

Data

Checksum

FF FF FF FF

82

BD 03 0A

16

20

00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

00 00

D8

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF

86

BD 03 0A E1

16

22

00 42

00 00 00 00 00 00 00 00 00 00 00 00 00 00

00 00 00 00

9C

Byte

Description

#0..#1

Configuration Change Counter

Byte

Description

#0..#1

Configuration Change Counter

Code

Description

0

No Command Specific Error

5

Too Few Data Bytes

9

Configuration Change Counter Mismatch

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

26

00

C8

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

26

02

00 02

C8

Request example:

count

FF

E1 39

Response example:

FF

39

Command 38 Reset Configuration Changed Flag

Request Data Bytes

Response Data Bytes

Long frame

from slave

00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

00 00 00 00 00 00 00 00 00 00 00 00 00 00

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Universal commands Page 28/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

26

04

00 02

C8

Byte

Description

Byte

Description

#0

Device Specific Status

Bit 7 EEPROM Error

#1

Device Specific Status

Bit 4 Excitation Frequency Error

#2 Always 0

#3 Always 0

#4 Always 0

#5 Always 0

#6 Always 0

#7 Always 0

#8 Always 0

Response example:

Command 48 Read Additional Device Status

Request Data Bytes

Response Data Bytes

Bit 0 Low Power Warning Bit 1Measure Timeout Bit 2 Empty Pipe Bit 3 Common Mode Voltage Overload Bit 4 ∑∆ADC Over range Bit 5 Coil Current Error Bit 6 Flow Overload

Long frame

from slave

Bit 0 Config Error Bit 1Pulse Overload Bit 2 Coil Disconnected Bit 3 Coil Shorted

MID_M1000_BA_HART_02_1704

Universal commands Page 29/83

Code

Description

0

No Command Specific Error

5

Too Few Data Bytes

14

Dynamic Variables Returned For Device Variables

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

30

00

DE

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

30

0B

00 42

00 00 00 00 00 00 00 00 00

93

Response Codes

Request example:

Response example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Additional features Page 30/83

Byte

Description

#0..#3

Primary Variable Fixed Current Level (units of mA) , IEEE754

Byte

Description

#0..#3

Actual Primary Variable Current Level (units of mA) , IEEE754

Code

Description

0

No Command Specific Error

3

Passed Parameter Too Large

4

Passed Parameter Too Small

5

Too Few Data Bytes Received

11

Loop Current Not Active (Device in Multidrop Mode)

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

28

04

40 80 00 00

02

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

28

06

00 08

40 80 00 00

0C

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

28

04

00 00 00 00

C2

6. Additional features

Command 40 Enter/Exit Fixed Current Mode

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Data: 4mAFixed

Request example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Additional features Page 31/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

28

06

00 00

41 61 8B FC

93

Byte

Description

None

Byte

Description

None

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

2A

00

C4

Preamble

Start delimiter

Address

Command Byte count Status Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

2A

02

00 4A

88

Response example:

Data:

14.09667 mA Actual

Command 42 Perform Device Reset

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

Response example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Additional features Page 32/83

Byte

Description

#0

Primary Variable Units Code

Volumetric Flow Unit Codes

Byte

Description

#0

Primary Variable Units Code

Volumetric Flow Unit Codes

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

2C

01

11

D2

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

2C

03

00 42

11

96

Byte

Description

#0

Number of preambles to be sent with the response message from the Slave to the Master

5 .. 20

Byte

Description

#0

Number of preambles to be sent with the response message from the Slave to the Master

5 .. 20

Code

Description

0

No Command Specific Error

3

Passed Parameter Too Large

4

Passed Parameter Too Small

5

Too Few Data Bytes Received

Command 44 Write Primary Variable Units

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Command 59 Write Number of Response Preambles

Request Data Bytes

Response Data Bytes

Long frame

from slave

Response Codes

MID_M1000_BA_HART_02_1704

Additional features Page 33/83

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

3B

01

05

D1

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

3B

03

00 40

05

97

Request example:

Response example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 34/83

Byte

Description

None

Byte

Description

#0..#1

Product Code

4 .. M1000R

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

82

00

6C

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

82

04

00 42

00 04

2A

Byte

Description

None

Byte

Description

#0..#15

Product Name, Latin-1

“M1000R”

Code

Description

0

No Command Specific Error

7. Device specific commands

Command 130 Read Product Code

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Command 131 Read Product Name

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 35/83

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

83

00

6D

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

83

12

00 42

4D 31 30 30 30 52 00 00 00 00 00 00 00 00 00 00

27

Byte

Description

None

Byte

Description

#0..#31

Firmware Name, Latin-1

“M1000R_E_STM32F107RC”

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

84

00

6A

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

84

22

00 42

4D 31 30 30 30 52 5F 45 5F 53 54 4D 33 32 46 31 30 37 52 43 00 00 00 00 00 00 00 00 00 00 00 00

7F

Request example:

Response example:

Long frame

from slave

Command 132 Read Firmware Name

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 36/83

Byte

Description

None

Byte

Description

#0..#19

Application Version, Latin-1

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

85

00

6B

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

85

16

00 42

31 2E 30 2E 31 36 62 30 37 00 00 00 00 00 00 00 00 00 00 00

58

Byte

Description

None

Byte

Description

#0

Day

#1

Month

#2

Year

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

86

00

68

Command 133 Read Application Version

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

Application Version = “1.0.16b07”

Command 134 Read Compile Date

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 37/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

86

05

00 00

10 0A 72

01

Byte

Description

None

Byte

Description

#0..#4

OTP Boot Checksum, Latin-1

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

87

00

69

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

87

07

00 42

36 62 34 37 00

7F

Byte

Description

None

Byte

Description

#0..#4

Flash OS Checksum, Latin-1

Response example:

Day = 16 Month = 10 (October) Year =2014

Command 135 Read OTP Boot Checksum

Request Data Bytes

Response Data Bytes

Response Codes

Long frame from slave

Request example:

Response example:

OTP Boot Checksum = “6b47”

Command 136 Read Flash OS Checksum

Request Data Bytes

Response Data Bytes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 38/83

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

88

00

66

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

88

07

00 42

33 63 66 34 00

25

Byte

Description

None

Byte

Description

#0..#8

Serial Number, Latin-1

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

8D

00

63

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

8D

0B

00 42

30 37 31 33 32 30 31 37 00

2F

Response Codes

Request example:

Response example:

Flash OS Checksum = “2a53”

Command 141 Read Serial Number

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

Response example:

Long frame

from slave

Serial Number = “07132017” Format: WWYYMSSS, where WW – week, YY – year, M – PCB manufacturer, SSS – serial number in given week and year

MID_M1000_BA_HART_02_1704

Device specific commands Page 39/83

Byte

Description

None

Byte

Description

#0..#1

Detector Diameter

1 DN6

35 DN1500

Request Data Bytes

Response Data Bytes

Command 150 Read Detector Diameter

2 DN8 3 DN10 4 DN15 5 DN20 6 DN25 7 DN32 8 DN40 9 DN50 10 DN65 11 DN80 12 DN100 13 DN125 14 DN150 15 DN200 16 DN250 17 DN300 18 DN350 19 DN400 20 DN450 21 DN500 22 DN550 23 DN600 24 DN700 25 DN750 26 DN800 27 DN900 28 DN1000 29 DN1050 30 DN1200 31 DN1400 32 DN1600 33 DN1800 34 DN2000

MID_M1000_BA_HART_02_1704

Device specific commands Page 40/83

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

96

00

78

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

96

04

00 42

00 09

33

Byte

Description

None

Byte

Description

#0..#4



 





 



⋅

V

s

m

A

Adjusted by manufacturer during wet

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

9A

00

74

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

9A

06

00 42

43 82 00 00

F5

Response Codes

Request example:

Response example:

Detector Diameter = DN50

Command 154 Read Detector Factor

Request Data Bytes

Response Data Bytes

Detector Factor

Response Codes

Long frame

from slave

, IEEE754

calibration

Request example:

Response example:

Detector Factor = 260.0

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 41/83

Byte

Description

None

Byte

Description

#0..#4

Detector Offset [m/s], IEEE754

Adjusted by manufacturer during wet calibration

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

9C

00

72

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

9C

06

00 42

80 00 00 00

B2

Byte

Description

None

Byte

Description

#0..#4

Amplifier Factor [div/V], IEEE754

Adjusted by manufacturer during dry calibration

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

9E

00

70

Command 156 Read Detector Offset

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Detector Offset = 0.0

Command 158 Read Amplifier Factor

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 42/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

9E

06

00 42

4B 81 64 42

DC

Byte

Description

None

Byte

Description

#0..#4

Detector Current [A], IEEE754

Adjusted by manufacturer during dry calibration

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A0

00

4E

Preamble

Start delimiter

Address

Command Byte

Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A0

06

00 42

3D 8B 9F 72

55

Response example:

Amplifier Factor = 16959620.0

Command 160 Read Detector Current

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

Response example:

Detector Current = 0.06817521

Long frame

from slave

count

MID_M1000_BA_HART_02_1704

Device specific commands Page 43/83

Byte

Description

None

Byte

Description

#0..#1

Power Line Frequency

0 50Hz 1 60Hz

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A2

00

4C

Preamble

Start

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A2

04

00 42

00 00

0E

Byte

Description

#0..#1

Power Line Frequency

0 50Hz 1 60Hz

Byte

Description

#0..#1

Power Line Frequency

0 50Hz 1 60Hz

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A3

02

00 01

4E

Command 162 Read Power Line Frequency

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

delimiter

Power Line Frequency = 50Hz

Command 163 Write Power Line Frequency

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 44/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A3

04

00 42

00 01

0E

Byte

Description

None

Byte

Description

#0..#1

Excitation Frequency

See Excitation Frequency Enumeration

Power Line Frequency

50 Hz

60 Hz

1

3.125 Hz

3.75 Hz

2

6.25 Hz

7.5 Hz

3

12.5 Hz

15 Hz

4

2.083 Hz

2.5 Hz

5

1.0417 Hz

1.25 Hz

6

0.833 Hz

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A4

00

4A

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A4

04

00 42

00 03

0B

Response example:

Power Line Frequency = 60Hz

Command 164 Read Excitation Frequency

Request Data Bytes

Response Data Bytes

Excitation Frequency Enumeration

Long frame

from slave

Response Codes

Request example:

Response example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 45/83

Byte

Description

#0..#1

Excitation Frequency

See Excitation Frequency Enumeration

Byte

Description

#0..#1

Excitation Frequency

See Excitation Frequency Enumeration

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A5

02

00 01

48

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A5

04

00 42

00 01

08

Byte

Description

None

Byte

Description

#0..#3

Scale Factor, IEEE754

Typically 1.0 (0.95 … 1.05)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A6

00

48

Command 165 Write Excitation Frequency

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Command 166 Read Scale Factor

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 46/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A6

06

00 42

3F 80 00 00

B7

Byte

Description

#0..#3

Scale Factor, IEEE754

Typically 1.0 (0.95 … 1.05)

Byte

Description

#0..#3

Scale Factor, IEEE754

Typically 1.0 (0.95 … 1.05)

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

A7

04

3F 80 00 00

F2

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

A7

06

00 42

3F 80 00 00

B6

Response example:

Scale Factor = 1.0

Command 167 Write Scale Factor

Request Data Bytes

Response Data Bytes

Response Codes

Long frame from slave

Request example:

Response example:

Scale Factor = 1.0

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 47/83

Byte

Description

None

Byte

Description

#0..#3

Polarization Voltage [V], IEEE754

For debugging purposes

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

AC

00

42

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

AC

06

00 00

3A 80 4A ED

5D

Byte

Description

None

Byte

Description

#0..#3

Full Scale Flow [Actual Flow Rate Unit], IEEE754

Full Scale Flow is identical with PV Upper Range Value

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

AD

00

43

Command 172 Read Polarization Voltage

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

Polarization Voltage = 0.000978795 V

Command 173 Read Full Scale Flow

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 48/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

AD

06

00 42

43 93 43 1D

8D

Byte

Description

#0..#3

Full Scale Flow [Actual Flow Rate Unit], IEEE754

Full Scale Flow is identical with PV Upper Range Value

Byte

Description

#0..#3

Full Scale Flow [Actual Flow Rate Unit], IEEE754

Full Scale Flow is identical with PV Upper Range Value

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Check sum

FF FF FF FF FF

82

BD 03 0A E1 39

AE

04

43 93 43 1D

CA

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

AE

06

00 42

43 93 43 1D

8E

Byte

Description

None

Byte

Description

#0

Volumetric Flow Unit

Volumetric Flow Unit Codes

Response example:

Full Scale Flow = 294.5243

Command 174 Write Full Scale Flow

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

Response example:

Full Scale Flow = 294.5243

Command 175 Read Flow Unit

Request Data Bytes

Response Data Bytes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 49/83

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

AF

00

41

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

AF

03

00 42

11

15

Byte

Description

#0

Volumetric Flow Unit

Volumetric Flow Unit Codes

Byte

Description

#0

Volumetric Flow Unit

Volumetric Flow Unit Codes

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Start delimiter

Address

Command

Byte count

Data

Check sum

82

BD 03 0A E1 39

B0

01

11

4E

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B0

03

00 42

11

0A

Response Codes

Request example:

Response example:

Long frame from slave

Flow Unit = Liters per Minute

Command 176 Write Flow Unit

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

Flow Unit = Liters per Minute

MID_M1000_BA_HART_02_1704

Device specific commands Page 50/83

Byte

Description

None

Byte

Description

#0

Volumetric Volume Unit

Volume Unit Codes

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

B1

00

5F

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B1

03

00 42

2B

31

Byte

Description

#0

Volumetric Volume Unit

Volume Unit Codes

Byte

Description

#0

Volumetric Volume Unit

Volume Unit Codes

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

B2

01

29

74

Command 177 Read Volume Unit

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Volume Unit = Cubic Meters (m3)

Command 178 Write Volume Unit

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 51/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B2

03

00 42

29

30

Byte

Description

None

Byte

Description

#0…#3

Full Scale Velocity [m/s], IEEE754

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

B5

00

5B

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B5

06

00 42

40 20 00 00

7B

Byte

Description

#0…#3

Full Scale Velocity [m/s], IEEE754

Byte

Description

#0…#3

Full Scale Velocity [m/s], IEEE754

Response example:

Volume Unit = Liters

Command 181 Read Full Scale Velocity

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Long frame

from slave

Response example:

Full Scale Velocity = 2.5 m/s

Command 182 Write Full Scale Velocity

Request Data Bytes

Response Data Bytes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 52/83

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

B6

04

41 20 00 00

3D

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B6

06

00 40

41 20 00 00

7B

Byte

Description

None

Byte

Description

#0…#3

Low Flow Cut Off [%], IEEE754

Percent of Full Scale Flow

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

B7

00

59

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B7

06

00 00

40 00 00 00

1B

Response Codes

Request example:

Response example:

Full Scale Velocity = 10 m/s

Command 183 Read Low Flow Cut Off

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Long frame

from slave

Response example:

Low Flow Cut Off = 2.0 %

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 53/83

Byte

Description

#0…#3

Low Flow Cut Off [%], IEEE754

Percent of Full Scale Flow (0.0 … 10.0)

Byte

Description

#0…#3

Low Flow Cut Off [%], IEEE754

Percent of Full Scale Flow

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Check sum

FF FF FF FF FF

82

BD 03 0A E1 39

B8

04

00 00 00 00

52

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B8

06

00 40

00 00 00 00

14

Byte

Description

None

Byte

Description

#0

Flow Direction

0 … Unidirectional (meter ignores negative flow rate) 1 … Bidirectional

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

B9

00

57

Command 184 Write Low Flow Cut Off

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Low Flow Cut Off = 0.0 %

Command 185 Read Flow Direction

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 54/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

B9

03

00 00

00

50

Byte

Description

#0

Flow Direction

0 … Unidirectional (meter ignores negative flow rate) 1 … Bidirectional

Byte

Description

#0

Flow Direction

0 … Unidirectional (meter ignores negative flow rate) 1 … Bidirectional

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

BA

01

54

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

BA

03

00 40

01

12

Byte

Description

None

Response example:

Flow Direction = Unidirectional

Command 186 Write Flow Direction

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

Response example:

Flow Direction = Bidirectional

Command 189 Read Coil Settling Time

Request Data Bytes

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 55/83

Byte

Description

#0…#3

Coil Settling Time [s], IEEE754

For debugging purposes

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

BD

00

53

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

BD

06

00 00

3A 91 A2 B4

EC

Byte

Description

None

Byte

Description

#0

Digital Input Operation

0 … None

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

BE

00

50

Response Data Bytes

Response Codes

Request example:

Response example:

Coil Settling Time = 0.00111111 s

Command 190 Read Digital Input Operation

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

1 … Totalizer Reset (Active input resets totalizers) 2 … Zero Flow(Active input zeroes actual flow rate) 4 … ADE (Digital input is assigned to ADE communication)

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 56/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

BE

03

00 00

00

57

Byte

Description

#0

Digital Input Operation

0 … None

Byte

Description

#0

Digital Input Operation

0 … None

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Check sum

FF FF FF FF FF

82

BD 03 0A E1 39

BF

01

51

Response example:

Digital Input Operation = None

Command 191 Write Flow Direction

Request Data Bytes

Response Data Bytes

Long frame

from slave

1 … Totalizer Reset (Active input resets totalizers) 2 … Zero Flow(Active input zeroes actual flow rate) 4 … ADE (Digital input is assigned to ADE communication)

Response Codes

Request example:

1 … Totalizer Reset (Active input resets totalizers) 2 … Zero Flow(Active input zeroes actual flow rate) 4 … ADE (Digital input is assigned to ADE communication)

MID_M1000_BA_HART_02_1704

Device specific commands Page 57/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

BF

03

00 40

01

17

Byte

Description

None

Byte

Description

#0

Digital Input Status

0 … Not Active (Unpowered) 1 … Active (Powered)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

C0

00

2E

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

C0

03

00 00

00

29

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

C0

03

00 00

01

28

Response example

:

Long frame

from slave

Digital Input Operation = Totalizer Reset

Command 192 Read Digital Input Status

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

Digital Input Status = Not Active (Unpowered)

Response example:

Long frame

from slave

Digital Input Status = Active (Powered)

MID_M1000_BA_HART_02_1704

Device specific commands Page 58/83

Byte

Description

#0

Alarm Mode

0 .. High

Byte

Description

#0

Alarm Mode

0 .. High

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Check

FF FF FF FF FF

82

BD 03 0A E1 39

C5

01

00

2A

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

C5

03

00 40

00

6C

Byte

Description

None

Byte

Description

#0…#3

Pulses per Unit, IEEE754

Refers to Actual Volume Unit

Command 197 Write Alarm Mode

Request Data Bytes

1 … Low 251 … None

Response Data Bytes

1 … Low 251 … None 252 … Unknown

Response Codes

Request example:

Response example:

Alarm Mode = High

Command 200 Read Pulses per Unit

Request Data Bytes

Response Data Bytes

sum

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 59/83

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

C8

00

26

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

C8

06

00 00

3F 80 00 00

9B

Byte

Description

#0…#3

Pulses per Unit, IEEE754

Refers to Actual Volume Unit

Byte

Description

#0…#3

Pulses per Unit, IEEE754

Refers to Actual Volume Unit

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

C9

04

41 20 00 00

42

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

C9

06

00 40

41 20 00 00

04

Response Codes

Request example:

Response example:

Pulses per Unit = 1.0

Command 201 Write Pulses per Unit

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

Request example:

Response example:

Pulses per Unit = 10.0

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 60/83

Byte

Description

None

Byte

Description

#0…#1

Pulse Width [ms]

5 … 2000 ms 0 ms (means 50% duty cycle)

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

CA

00

24

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

CA

04

00 00

24

Byte

Description

#0…#1

Pulse Width [ms]

5 … 2000 ms

Byte

Description

#0…#1

Pulse Width [ms]

5 … 2000 ms

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Command 202 Read Pulse Width

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Pulse Width = 0 ms (50% duty cycle)

Command 203 Write Pulse Width

Request Data Bytes

Response Data Bytes

Response Codes

Long frame

from slave

0 ms (means 50% duty cycle)

MID_M1000_BA_HART_02_1704

Device specific commands Page 61/83

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

CB

02

00 32

15

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

CB

04

00 40

00 32

57

Byte

Description

#0

Digital Output Number

1 … OUT1

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Flow Alarm Min [%]

0 … 100 %; Percent of Full Scale Flow

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

CC

01

22

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

CC

04

00 00

01 00

23

Request example:

Response example:

Long frame

from slave

Pulse Width = 50 ms

Command 204 Read Flow Alarm Min

If actual flow is outside the limit (lower than Min or higher than Max) corresponding output is activated. Request Data Bytes

2 … OUT2

Response Data Bytes

Response Codes

Request example:

Response example:

Digital Output Number = OUT1 Flow Alarm Min = 0 %

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 62/83

Byte

Description

#0

Digital Output Number

1 … OUT1 #1

Flow Alarm Min [%]

0 … 100 %; Percent of Full Scale Flow

Byte

Description

#0

Digital Output Number

1 … OUT1 #1

Flow Alarm Min [%]

0 … 100 %; Percent of Full Scale Flow

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

CD

02

01 01

21

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

CD

04

00 40

01 01

63

Command 205 Write Flow Alarm Min

If actual flow is outside the limit (lower than Min or higher than Max) corresponding output is activated. Request Data Bytes

2 … OUT2

Response Data Bytes

2 … OUT2

Response Codes

Request example:

Response example:

Digital Output Number = OUT1 Flow Alarm Min = 1 %

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 63/83

Byte

Description

#0

Digital Output Number

1 … OUT1

Byte

Description

#0

Digital Output Number

1 … OUT1 #1

Flow Alarm Max [%]

0 … 100 %; Percent of Full Scale Flow

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

CE

01

20

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

CE

04

00 00

01 64

45

Command 206 Read Flow Alarm Max

If actual flow is outside the limit (lower than Min or higher than Max) corresponding output is activated. Request Data Bytes

2 … OUT2

Response Data Bytes

2 … OUT2

Response Codes

Request example:

Response example:

Digital Output Number = OUT1 Flow Alarm Max = 100 %

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 64/83

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Flow Alarm Max [%]

0 … 100 %; Percent of Full Scale Flow

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Flow Alarm Max [%]

0 … 100 %; Percent of Full Scale Flow

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

CF

02

01 60

42

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

CF

04

00 40

01 60

00

Byte

Description

#0

Digital Output Number

1 … OUT1

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Digital Output Mode

0 … Normally Open 1 … Normally Closed

Command 207 Write Flow Alarm Max

If actual flow is outside the limit (lower than Min or higher than Max) corresponding output is activated. Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Digital Output Number = OUT1 Flow Alarm Max = 96 %

Command 208 Read Digital Output Mode

Request Data Bytes

Response Data Bytes

Long frame from slave

2 … OUT2

MID_M1000_BA_HART_02_1704

Device specific commands Page 65/83

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D0

01

3E

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D0

04

00 00

01 00

3F

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Digital Output Mode

0 … Normally Open 1 … Normally Closed

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Digital Output Mode

0 … Normally Open 1 … Normally Closed

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D1

02

01 01

3D

Response Codes

Request example:

Response example:

Long frame from slave

Digital Output Number = OUT1 Digital Output Mode

= Normally Open

Command 209 Write Digital Output Mode

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 66/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D1

04

00 40

01 01

7F

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Digital Output Operation

See Digital Output Operation Enumeration

0

Off

1

Comparator

2

Empty Pipe

3

Error Alarm

4

Forward

6

Reverse

7

Frequency

8

Preset

9

Direction

10

Test

11

Ade

12

Loopback

13

Quadrature

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D2

01

3C

Response example:

Long frame from slave

Digital Output Number = OUT1 Digital Output Mode

= Normally Closed

Command 210 Read Digital Output Operation

Request Data Bytes

Response Data Bytes

Digital Output Operation Enumeration

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 67/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D2

04

00 00

01 01

3C

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Digital Output Operation

See Digital Output Operation Enumeration

Byte

Description

#0

Digital Output Number

1 … OUT1 2 … OUT2

#1

Digital Output Operation

See Digital Output Operation Enumeration

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D3

02

01 09

37

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D3

04

00 40

01 09

75

Response example:

Long frame from slave

Digital Output Number = OUT1 Digital Output Operation

= Comparator

Command 211 Write Digital Output Operation

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

Digital Output Number = OUT1 Digital Output Operation = Direction

MID_M1000_BA_HART_02_1704

Device specific commands Page 68/83

Byte

Description

None

Byte

Description

#0…#3

Full Scale Frequency [Hz], IEEE754

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D4

00

3A

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D4

06

00 40

43 44 59 7C

5A

Byte

Description

#0…#3

Full Scale Frequency [Hz], IEEE754

Max. 10 000 Hz

Byte

Description

#0…#3

Full Scale Frequency [Hz], IEEE754

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D5

04

42 C8 00 00

B5

Command 212 Read Full Scale Frequency

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

Full Scale Frequency = 196.3495 Hz

Command 213 Write Full Scale Frequency

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 69/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D5

06

00 40

42 C8 00 00

F3

Byte

Description

None

Byte

Description

#0..#1

Median Filter

1 ... 13 Length of filter

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D6

00

38

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D6

04

00 00

00 01

39

Byte

Description

#0..#1

Median Filter

1 ... 13 Length of filter

Byte

Description

#0..#1

Median Filter

1 ... 13 Length of filter

Response example:

Long frame from slave

Full Scale Frequency = 100.0 Hz

Command 214 Read Median

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Median = 1

Command 215 Write Median

Request Data Bytes

Response Data Bytes

Long frame from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 70/83

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D7

02

00 01

3A

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D7

04

00 40

00 01

78

Byte

Description

None

Byte

Description

#0..#1

Moving Average Filter

1 ... 200 Length of filter

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D8

00

36

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D8

04

00 00

00 01

37

Response Codes

Request example:

Response example:

Long frame from slave

Median = 1

Command 216 Read Moving Average

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Median = 1

Long frame from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 71/83

Byte

Description

#0..#1

Moving Average Filter

1 ... 200 Length of filter

Byte

Description

#0..#1

Moving Average Filter

1 ... 200 Length of filter

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

D9

02

00 01

34

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

D9

04

00 40

00 01

76

Byte

Description

None

Byte

Description

#0

Menu Language Code

0 … English

6 … Italian

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

E5

00

0B

Command 217 Write Moving Average

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Moving Average = 1

Command 229 Read Menu Language Code

Request Data Bytes

Response Data Bytes

Long frame from slave

1 … German 2 … Czech 3 … Spanish 4 … French 5 … Russian

Response Codes

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 72/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

E5

03

00 00

00

0C

Byte

Description

#0

Menu Language Code

0 … English

6 … Italian

Byte

Description

#0

Menu Language Code

0 … English

6 … Italian

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

E6

01

08

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

E6

03

00 40

01

4E

Response example:

Long frame from slave

Menu Language Code = English Command 230 Write Menu Language Code

Request Data Bytes

1 … German 2 … Czech 3 … Spanish 4 … French 5 … Russian

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

1 … German 2 … Czech 3 … Spanish 4 … French 5 … Russian

Menu Language Code = German

MID_M1000_BA_HART_02_1704

Device specific commands Page 73/83

Byte

Description

None

Byte

Description

#0

Empty Pipe Mode

0 … Empty Pipe Detection Off 1 … Empty Pipe Detection On

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

E7

00

09

Preamble

Start delimiter

Address

Command Byte

Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

E7

03

00 00

01

0F

Byte

Description

#0

Empty Pipe Mode

0 … Empty Pipe Detection Off 1 … Empty Pipe Detection On

Byte

Description

#0

Empty Pipe Mode

0 … Empty Pipe Detection Off 1 … Empty Pipe Detection On

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

E8

01

00

07

Command 231 Read Empty Pipe Mode

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

Empty Pipe Mode = Empty Pipe Detection On

Command 232 Write Empty Pipe Mode

Request Data Bytes

Response Data Bytes

Response Codes

count

Request example:

MID_M1000_BA_HART_02_1704

Device specific commands Page 74/83

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

E8

03

00 40

00

41

Byte

Description

None

Byte

Description

#0…#3

Empty Pipe Threshold Resistance [Ω], IEEE754

60 000 Ω typ.

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

E9

00

07

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

E9

06

00 00

47 6A 60 00

48

Byte

Description

#0…#3

Empty Pipe Threshold Resistance [Ω], IEEE754

60 000 Ω typ.

Byte

Description

#0…#3

Empty Pipe Threshold Resistance [Ω], IEEE754

60 000 Ω typ.

Response example:

Long frame from slave

Empty Pipe Mode = Empty Pipe Detection Off

Command 233 Read Empty Pipe Threshold Resistance

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

Empty Pipe Threshold Resistance = 60 000 Ω

Command 234 Write Empty Pipe Threshold Resistance

Request Data Bytes

Response Data Bytes

MID_M1000_BA_HART_02_1704

Device specific commands Page 75/83

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

EA

04

47 6A 60 00

4D

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

EA

06

00 40

47 6A 60 00

0B

Byte

Description

None

Byte

Description

#0…#3

Empty Pipe Actual Resistance [Ω], IEEE754

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

EE

00

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

EE

06

00 40

42 A9 26 D4

5B

Response Codes

Request example:

Response example:

Long frame from slave

Empty Pipe Threshold Resistance = 60 000 Ω

Command 238 Read Empty Pipe Actual Resistance

Request Data Bytes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame from slave

Empty Pipe Actual Resistance = 84.5758 Ω

MID_M1000_BA_HART_02_1704

Device specific commands Page 76/83

Byte

Description

None

Byte

Description

#0

Flow Simulation [%]

-128 … OFF

-100 … -100%

Code

Description

0

No Command Specific Error

Preamble

Start delimiter

Address

Command

Byte count

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

F0

00

1E

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

F0

03

00 00

80

99

Command 240 Read Flow Simulation

Request Data Bytes

Response Data Bytes

+ 0 … 0% +10 … +10% +20 … +20% +30 … +30% +40 … +40% +50 … +50% +60 … +60% +70 … +70% +80 … +80% +90 … +90% +100 … +100%

-10 … -10%

-20 … -20%

-30 … -30%

-40 … -40%

-50 … -50%

-60 … -60%

-70 … -70%

-80 … -80%

-90 … -90%

Response Codes

Request example:

Response example:

Flow Simulation = Off

Long frame from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 77/83

Byte

Description

#0

Flow Simulation [%], not stored to non-volatile memory

-128 … OFF

-100 … -100%

Command 241 Write Flow Simulation

Request Data Bytes

+ 0 … 0% +10 … +10% +20 … +20% +30 … +30% +40 … +40% +50 … +50% +60 … +60% +70 … +70% +80 … +80% +90 … +90% +100 … +100%

-10 … -10%

-20 … -20%

-30 … -30%

-40 … -40%

-50 … -50%

-60 … -60%

-70 … -70%

-80 … -80%

-90 … -90%

MID_M1000_BA_HART_02_1704

Device specific commands Page 78/83

Byte

Description

#0

Flow Simulation [%]

-128 … OFF

-100 … -100%

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

F1

01

64

7A

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

F1

03

00 00

64

7C

Response Data Bytes

+ 0 … 0% +10 … +10% +20 … +20% +30 … +30% +40 … +40% +50 … +50% +60 … +60% +70 … +70% +80 … +80% +90 … +90% +100 … +100%

-10 … -10%

-20 … -20%

-30 … -30%

-40 … -40%

-50 … -50%

-60 … -60%

-70 … -70%

-80 … -80%

-90 … -90%

Response Codes

Request example:

Response example:

Flow Simulation = 100%

Long frame

from slave

MID_M1000_BA_HART_02_1704

Device specific commands Page 79/83

Byte

Description

#0..#3

Login

Ask manufacturer for details.

Byte

Description

#0

Rights

0 ... RIGHTS_UNKNOWN,

4 ... RIGHTS_FACTORY

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

F2

04

00 00 00 00

18

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

F2

03

00 60

04

7F

Byte

Description

Byte

Description

#0

Rights

0 ... RIGHTS_UNKNOWN,

4 ... RIGHTS_FACTORY

Command 242 Remote Login

Request Data Bytes

Response Data Bytes

1 ... RIGHTS_USER, 2 ... RIGHTS_SERVICE, 3 ... RIGHTS_ADMIN,

Response Codes

Request example:

Response example:

Long frame

from slave

Rights = RIGHTS_FACTORY(Even Factory variables can be modified)

Command 243 Read Rights

Request Data Bytes

Response Data Bytes

1 ... RIGHTS_USER, 2 ... RIGHTS_SERVICE, 3 ... RIGHTS_ADMIN,

MID_M1000_BA_HART_02_1704

Device specific commands Page 80/83

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

F3

00 1D

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

F3

03

00 40

04

5E

Byte

Description

#0..#1

Command

8 … Clear Totalizers T2

only

Byte

Description

#0..#1

Reserved

0

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

F4

02

00 08

10

Preamble

Start delimiter

Address

Command Byte

Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

F4

04

00 00

1A

Response Codes

Request example:

Response example:

Long frame

from slave

Rights = RIGHTS_FACTORY(Even Factory variables can be modified)

Command 244 Command Action Request

Request Data Bytes

23 … Restart of device Others … reserved for manufacturer purposes

Response Data Bytes

Response Codes

Request example:

Response example:

Long frame

from slave

MID_M1000_BA_HART_02_1704

count

Device specific commands Page 81/83

Byte

Description

Byte

Description

#0

Rights

0 ... RIGHTS_UNKNOWN,

4 ... RIGHTS_FACTORY

Code

Description

0

No Command Specific Error

2

Invalid Selection

5

Too Few Data Bytes Received

16

Access Restricted

Preamble

Start delimiter

Address

Command

Byte count

Data

Checksum

FF FF FF FF FF

82

BD 03 0A E1 39

F3

00 1D

Preamble

Start delimiter

Address

Command Byte count Status

Data

Checksum

FF FF FF FF FF

86

BD 03 0A E1 39

F3

03

00 40

04

5E

Command 247 Read Random

Generates Random Number necessary for login calculation. Request Data Bytes

Response Data Bytes

1 ... RIGHTS_USER, 2 ... RIGHTS_SERVICE, 3 ... RIGHTS_ADMIN,

Response Codes

Request example:

Response example:

Long frame

from slave

Rights = RIGHTS_FACTORY(Even Factory variables can be modified)

MID_M1000_BA_HART_02_1704

‘Rights summary Page 82/83

COMMAND_163_WRITE_POWER_LINE_FREQUENCY

Rights_User

COMMAND_165_WRITE_EXCITATION_FREQUENCY

Rights_Service

COMMAND_167_WRITE_SCALE_FACTOR

Rights_Service

COMMAND_174_WRITE_FULL_SCALE_FLOW

Rights_Factory

COMMAND_176_WRITE_FLOW_UNIT

Rights_User

COMMAND_178_WRITE_VOLUME_UNIT

Rights_User

COMMAND_182_WRITE_FULL_SCALE_VELOCITY

Rights_Factory

COMMAND_184_WRITE_LOW_FLOW_CUT_OFF

Rights_Admin

COMMAND_186_WRITE_FLOW_DIRECTION

Rights_Factory

COMMAND_191_WRITE_DIGITAL_INPUT_OPERATION

Rights_Service

COMMAND_197_WRITE_ALARM_MODE

Rights_Service

COMMAND_201_WRITE_PULSES_PER_UNIT

Rights_Service

COMMAND_203_WRITE_PULSES_WIDTH

Rights_Service

COMMAND_205_WRITE_FLOW_ALARM_MIN

Rights_Service

COMMAND_207_WRITE_FLOW_ALARM_MAX

Rights_Service

COMMAND_209_WRITE_DO_OUTPUT_MODE

Rights_Service

COMMAND_211_WRITE_DO_OUTPUT_OPERATION

Rights_Service

COMMAND_213_WRITE_FULL_SCALE_FREQUENCY

Rights_Service

COMMAND_215_WRITE_MEDIAN

Rights_Service

COMMAND_217_WRITE_MOVING_AVERAGE

Rights_Service

COMMAND_230_WRITE_MENU_LANGUAGE_CODE

Rights_User

COMMAND_232_WRITE_EMPTY_PIPE_MODE

Rights_Admin

COMMAND_234_WRITE_EMPTY_PIPE_THRESHOLD_RESISTANCE

Rights_Admin

COMMAND_241_WRITE_FLOW_SIMULATION

Rights_Service

COMMAND_244_ACTION_REQUEST

Rights_Admin

8. Rights – summary

MID_M1000_BA_HART_02_1704

Return of goods for repair/Hamless declarat Page 83/83

9. Return of goods for repair/Harmless declaration

Please refer to our claims return form/harmlessness declaration under www.badgermeter.de/service/return

of goods.

MID_M1000_BA_HART_02_1704

®

Hotline

Phone +49-7025-9208-0 or -30 Fax +49-7025-9208-15

Badger Meter Europa GmbH

Subsidiary of Badger Meter, Inc., USA

Nürtinger Strasse 76 72639 Neuffen (Germany) E-mail: badger@badgermeter.de www.badgermeter.de

Badger Meter ModMAG M1000 Installation And Operation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Basic safety recommendations

2. Dynamic variables

Volumetric flow unit codes

Volume unit code

3. Device variables

4. Field device status

5. Universal commands

Command 0 Read Transmitter Unique Identifier

Command 1 Read primary variable

Command 2 Read Loop Current and Percent of Range

Command 3 Read Dynamic Variables and Loop Current

Command 3 Read Dynamic Variables and Loop Current

Command 6 Write Polling Address

Backward compatibility TEST

Command 7 Read Loop Configuration

Command 8 Read Dynamic Variable Classification

Command 9 Read Device Variable with Status

Command 11 Read Unique Identifier Associated With Tag

Command 12 Read message

Command 13 Read tag descriptor, and date

Command 14 Read PV sensor information

Command 15 Read PV output sensor information

Command 16 Read Assembly Number

Command 17 Write Message

Command 18 Write Tag, Description, Date

Command 19 Write Assembly number

Command 20 Read Long tag

Command 21 Read Unique Identifier Associated With Long Tag

Command 22 Write Long tag

Command 38 Reset Configuration Changed Flag

Command 48 Read Additional Device Status

6. Additional features

Command 40 Enter/Exit Fixed Current Mode

Command 42 Perform Device Reset

Command 44 Write Primary Variable Units

Command 59 Write Number of Response Preambles

7. Device specific commands

Command 130 Read Product Code

Command 131 Read Product Name

Command 132 Read Firmware Name

Command 133 Read Application Version

Command 134 Read Compile Date

Command 135 Read OTP Boot Checksum

Command 136 Read Flash OS Checksum

Command 141 Read Serial Number

Command 150 Read Detector Diameter

Command 154 Read Detector Factor

Command 156 Read Detector Offset

Command 158 Read Amplifier Factor

Command 160 Read Detector Current

Command 162 Read Power Line Frequency

Command 163 Write Power Line Frequency

Command 164 Read Excitation Frequency

Command 165 Write Excitation Frequency

Command 166 Read Scale Factor

Command 167 Write Scale Factor

Command 172 Read Polarization Voltage

Command 173 Read Full Scale Flow

Command 174 Write Full Scale Flow

Command 175 Read Flow Unit

Command 176 Write Flow Unit

Command 177 Read Volume Unit

Command 178 Write Volume Unit

Command 181 Read Full Scale Velocity

Command 182 Write Full Scale Velocity

Command 183 Read Low Flow Cut Off

Command 184 Write Low Flow Cut Off

Command 185 Read Flow Direction

Command 186 Write Flow Direction

Command 189 Read Coil Settling Time

Command 190 Read Digital Input Operation

Command 191 Write Flow Direction

Command 192 Read Digital Input Status

Command 197 Write Alarm Mode

Command 200 Read Pulses per Unit

Command 201 Write Pulses per Unit
