Bacharach Pur-Chek Operating Manual
Instruction 2100-9000
Operation and Maintenance
Rev. 0 — June 2010
Product Leadership • Training • Service • Reliability
WARRANTY
Bacharach, Inc. warrants to Buyer that at the time of delivery this Product will be free from defects in material and manufacture and will conform substantially to Bacharach Inc.’s applicable specifi cations. Bacharach’s
liability and Buyer’s remedy under this warranty are limited to the repair or replacement, at Bacharach’s option,
of this Product or parts thereof returned to Seller at the factory of manufacture and shown to Bacharach Inc.’s
reasonable satisfaction to have been defective; provided that written notice of the defect shall have been given
by Buyer to Bacharach Inc. within one (1) years after the date of delivery of this Product by Bacharach, Inc.
Bacharach, Inc. warrants to Buyer that it will convey good title to this Product. Bacharach’s liability and Buyer’s
remedy under this warranty of title are limited to the removal of any title defects or, at the election of Bacharach,
to the replacement of this Product or parts thereof that are defective in title.
The warranty set forth in paragraph 1 does not apply to parts the Operating Instructions designate as having a
limited shelf-life or as being expended in normal use (e.g., fi lters).
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND ARE GIVEN AND ACCEPTED IN LIEU OF (I) ANY
AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE: AND (II) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR REMEDY IN CONTRACT OR TORT, WHETHER OR NOT ARISING
FROM BACHARACH’S NEGLIGENCE, ACTUAL OR IMPLIED. The remedies of the Buyer shall be limited to
those provided herein to the exclusion of any and all other remedies including, without limitation incidental or
consequential damages. No agreement varying or extending the foregoing warranties, remedies or this limitation will be binding upon Bacharach, Inc. unless in writing, signed by a duly authorized offi cer of Bacharach.
Register Your Warranty by Visiting
www.mybacharach.com
Notice:
Product improvements and enhancements are continuous; therefore the specifi cations and information contained in this document may
change without notice.
Bacharach, Inc. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing,
performance, or use of this material.
No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Bacharach,
Inc.
Copyright © 2010, Bacharach, Inc., all rights reserved.
BACHARACH® is a registered trademark of Bacharach, Inc. All other trademarks, trade names, service marks and logos referenced herein
belong to their respective owners.
Pur•Chek
™
Contents
1 Introduction ...............................................................................1
1.1 How to Use This Manual ............................................1
1.2 Warnings & Cautions ..................................................1
1.2.1 Analyzer Warnings ......................................1
1.2.2 General Warnings & Cautions ....................2
1.3 Features and Capabilities ...........................................2
1.4 Pur•Chek™ Models and Contents ..............................2
1.5 Functional Overview ...................................................3
2 Specifi cations ...........................................................................4
3 Components ..............................................................................5
3.1 Base Unit ....................................................................5
3.2 R12 Sample Hose ......................................................5
3.3 AC Power Adapter ......................................................5
3.4 Control Panel ..............................................................6
3.5 Back Panel Connections ............................................6
3.6 Hard Shell Storage/Carrying Case .............................7
4 Operation...................................................................................8
4.1 Battery Installation ......................................................8
4.2 Turning On the Unit ....................................................9
4.3 Calibration ..................................................................9
4.4 Viewing the Test Results ............................................10
4.5 Blend Refrigerants ......................................................10
4.6 Printing the Test Results .............................................11
5 Maintenance & Troubleshooting .............................................12
5.1 Setting the Elevation ...................................................12
5.2 Setting the LCD Contrast ............................................12
5.3 Changing the Sample Filter ........................................13
5.4 Cleaning the Sample Hoses .......................................13
5.5 Changing the Printer Paper ........................................13
5.6 Low Battery Warning ..................................................14
5.7 Error Messages ..........................................................14
6 Replacement Parts ...................................................................15
7 Service Centers ........................................................................15
Instruction 2100-9000 i
Pur•Chek
™
Instruction 2100-9000ii
Pur•Chek
™
1 Introduction
1.1 How to Use This Manual
This manual provides important information on how to operate and maintain Bacharach’s Pur•Chek™ HVAC
Advanced Refrigerant Identifi er.
To assure operator safety and proper use of the Pur•Chek
this manual.
™
, please read, understand, and follow the contents of
1.2 Warnings & Cautions
When used in this manual or as labeled on the Pur•Chek™, the following hazard symbols and/or associated
words are defi ned as follows:
WARNING: This symbol and/or the use of the word WARNING indicates a potential hazard
associated with the use of this equipment. It calls attention to a procedure, practice, condition,
or the like, which if not correctly performed or adhered to, could result in death or serious injury.
WARNING: This symbol and/or the use of the word WARNING indicates a potential hazard
from electrical shock. It calls attention to a procedure, practice, condition, or the like, which if
not correctly performed or adhered to, could result in death or serious injury.
CAUTION: This symbol and/or the use of the word CAUTION indicates a potential hazard
associated with the use of this equipment. It calls attention to a procedure, practice, condition,
or the like, which if not correctly performed or adhered to, could result in minor or moderate
injury.
IMPORTANT: The use of the word IMPORTANT in this manual calls attention to a procedure,
practice, condition, or the like, which if not correctly performed or adhered to, could result in
incorrect performance of or damage to the equipment and may void the warranty.
1.2.1 Analyzer Warnings
Refrigerant Blend Warning: The HVAC industry is continually introducing new refrigerants.
Many of these new blends can be profi led using the Pur•Chek™.
Sample Filter Warning: Replace the sample fi lter of the instrument AS SOON AS RED
SPOTS OR DISCOLORATION BEGIN TO APPEAR ON THE OUTSIDE DIAMETER OF THE
WHITE ELEMENT. Failure to properly maintain and replace the sample fi lter will result in
severe damage.
Sample Input Warning: The instrument requires connection of the supplied sample hose to
the LOW SIDE OR VAPOR port of refrigerant storage cylinders or air conditioning systems.
DO NOT attempt to introduce liquid or samples heavily laden with oil into the low side sampling
hose. DO NOT connect the sample hose to the HIGH SIDE or LIQUID port!
Damage caused to the instrument due to the use of the wrong hose on the wrong port will void
the warranty.
Battery Charger Warning: When charging the optional battery with the 1000 mA charger,
the charger will become warm. If the charger becomes hot, unplug the charger immediately!
When charging multiple battery packs, allow the charger to cool between each battery.
Instruction 2100-9000 1
Pur•Chek
™
1.2.2 General Warnings & Cautions
• Always inspect the sample hose before each use. Replace the hose if it appears cracked,
frayed, obstructed or fouled with oil.
• ALWAYS turn the compressor off before connecting the instrument to an air conditioning
system.
• Always wear eye and skin protection when working with refrigerants. Escaping refrigerant
vapors will present a freezing danger.
• To reduce the risk of electrical shock, do not disassemble the instrument; do not use the instrument in wet or damp areas.
• DO NOT direct refrigerant vapors venting from hoses towards the skin.
• DO NOT disassemble the instrument. There are no serviceable components internal to the
instrument and disassembly will void the warranty.
• ALWAYS place the Identifi er on a fl at and sturdy surface.
• DO NOT utilize any other hose other than those supplied with the instrument. The use of other
hose types will introduce errors into the refrigerant analysis and instrument calibration.
• ALWAYS verify that the refrigerant to be tested does not contain or will not emit heavy loads of
oil or liquid.
• NEVER admit any sample into the instrument at pressures in excess of 500 psig.
1.3 Features and Capabilities
The Pur•Chek™ HVAC Advanced Refrigerant Identifi er is the most advanced portable instrument ever manu-
factured for determining the purity of gaseous refrigerants for the HVAC-R market. Features of the Pur•Chek™
include:
• Stable 4-gas infrared sensor technology
• Advanced ergonomic design
• Rugged rubberized hand grips
• Large graphic display with on-screen instructions
• Ultra fast 60-second test time
• ‘Blend-Chek’ software to identify the presence of R410A
• Built in printer option for instant analysis report
• Internal, rechargeable batter option for cordless operation in any location
• Hard shell carry/storage case
1.4 Pur•Chek™ Models and Contents
Model Name Part Number Contents
Pur•Chek™ 2100-8001 Pur•Chek™ ............................................ 2100-8001
1/4” Flare Sampling Hose Assembly ...... 2100-0005
AC Adapter .............................................2100-0004
Instruction Manual .................................. 2100-9000
All contained in a hard shell storage/carrying case.
Pur•Chek w/ Printer 2100-8002 Pur•Chek™ w/ Printer ............................2100-8002
1/4” Flare Sampling Hose Assembly ...... 2100-0005
AC Adapter .............................................2100-0004
Printer Paper (1 Roll) .............................. 2100-0003
Instruction Manual .................................. 2100-9000
All contained in a hard shell storage/carrying case.
Instruction 2100-90002
Pur•Chek
™
1.5 Functional Overview
Contamination of refrigerants either in storage cylinders or air conditioning systems can lead to component
corrosion, elevated head pressures and system failures when utilized by unsuspecting technicians. The ability
of the technician to determine refrigerant type and purity is severely hampered by the presence of air when
attempting to utilize temperature-pressure relations. The development of various substitute refrigerants further
complicates the ability of a technician to identify refrigerant purity based upon temperature-pressure relationships. The substitute refrigerant blends can also introduce a fl ammability hazard to the technician and the
ultimate end user of the air conditioning system.
The Bacharach Pur•Chek™ Advanced Refrigerant Identifi er provides a fast, easy and accurate means to deter-
mine refrigerant purity in refrigerant storage cylinders or directly in air conditioning systems. The instrument utilizes non-dispersive infrared (NDIR) technology to determine the weight concentrations of refrigerant types R12,
R134A, R22, as well as hydrocarbons. In addition, the unit will indicate the presence of R410A if the refrigerant
tested matches the internal profi le established for virgin R410A. Refrigerant purity is displayed on the LCD
Screen. The user must determine acceptable levels of purity based on their recovery or use standards.
Sample gas is admitted into the instrument through the supplied sample hose and presented to the sensing
device. The instrument provides the user with direct percent by weight concentrations of R12, R134A, R22 and
hydrocarbons. If the sample is determined to be pure R134A, the instrument will provide a direct readout of the
weight percentage of air within the sample. Note that the instrument does not consider air to be a contaminant
since it can be removed by most refrigerant recycling equipment. Since air is not considered to be a contaminant, it is possible to read 100% R134A plus 5% air. The instrument only considers the weights of the refrigerant and contaminants in the total mixture for R134A as air contamination in R12 and R22 systems causes only
minor performance degradation.
The instrument interfaces with the user with an LCD graphic display, status indicator lamps, push button communication switches and an alarm horn. Alarm indications are provided to alert of instrument fault conditions or
contaminated refrigerant presence. Direct percent by weight concentrations of the sample refrigerant is provided on the display as well as user directions and prompts. An optional factory-installed printer (Model 2100-
8002) is available to print an on-the-spot analysis report.
The Bacharach Pur•Chek™ Advanced Refrigerant Identifi er provides the refrigerant technician with excellent
knowledge of refrigerant purity and protection against refrigerant contamination and potential fl ammability.
Instruction 2100-9000 3
