Bacharach Halogen Monitor Instruction

Halogen Monitor

“Bagless” Portable Area Gas Monitor (PAGM) with

Infrared Sensor for Halogen Gases (Refrigerants)

Instruction 3015-5466

Operation & Maintenance

Rev. 6 – January 2013

Product Leadership • Training • Service • Reliability

Patent 6,590,690

Halogen Monitor (Bagless PAGM)

WARRANTY

Bacharach, Inc. warrants to Buyer that at the time of delivery this Product will be free from defects in material and manufacture
and will conform substantially to Bacharach Inc.'s applicable specifications. Bacharach's liability and Buyer's remedy under this
warranty are limited to the repair or replacement, at Bacharach's option, of this Product or parts thereof returned to Seller at the
factory of manufacture and shown to Bacharach Inc.'s reasonable satisfaction to have been defective; provided that written
notice of the defect shall have been given by Buyer to Bacharach Inc. within two (2) years after the date of delivery of this
Product by Bacharach, Inc.

Bacharach, Inc. warrants to Buyer that it will convey good title to this Product. Bacharach's liability and Buyer's remedy under
this warranty of title are limited to the removal of any title defects or, at the election of Bacharach, to the replacement of this
Product or parts thereof that are defective in title.

The warranty set forth in paragraph 1 does not apply to parts the Operating Instructions designate as having a limited shelf-life or
as being expended in normal use (e.g., filters).

THE FOREGOING WARRANTIES ARE EXCLUSIVE AND ARE GIVEN AND ACCEPTED IN LIEU OF (I) ANY AND ALL OTHER
WARRANTIES, EXPRESS OR IMPLI ED, INCLUDING WITHOUT LIMIT ATION THE IMPLIED WARRANTIES OF MERCH ANT­ABILITY AND FITNESS FOR A PARTICULAR PURPOSE: AND (II) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR
REMEDY IN CONTRACT OR TORT, WHETHER OR NOT ARISING FROM BACHARACH'S NEGLIGENCE, ACTUAL OR
IMPLIED. The remedies of the Buyer shall be limited to those provided herein to the exclusion of any and all other remedies
including, without limitation incidental or consequential damages. No agreement varying or extending the foregoing warranties,
remedies or this limitation will be binding upon Bacharach, Inc. unless in writing, signed by a duly authorized officer of
Bacharach.

Patent 6,590,690

Register your War ranty b y Visiting

www.mybacharach.com

NOTICE

Product improvements and enhancements are continuous; therefore the specifications and information
contained in this document may change without notice.

Bacharach, Inc. shall not be lia ble for errors containe d herein or for incidental or c onsequential dam ages
in connection with the furnishing, performance, or use of this material.

No part of this docum ent may be photocopie d, reproduced, or translated to a nother language without the
prior written consent of Bacharach, Inc.

Copyright © 2005-2013, Bacharach, Inc., all rights reserved.

BACHARACH

®

is a registered trademark of Bacharach, Inc. All other trademarks, trade names,

service marks and logos referenced herein belong to their respective owners.

2 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

TABLE OF CONTENTS

1 INTRODUCTION .................................................................................................................................................. 5

1.1 How to Use This Manual ................................................................................................................................... 5

1.2 Warning Statements ......................................................................................................................................... 5

1.3 Caution Statements........................................................................................................................................... 5

1.4 Hazard Symbols on Monitor.............................................................................................................................. 5

1.5 Safety Precautions ............................................................................................................................................ 6

1.5.1 Explosive Atmosphere .......................................................................................................................... 6

1.5.2 Misuse and Modifications to Monitor .................................................................................................. 6

1.5.3 Altitude Limit ........................................................................................................................................ 6

1.5.4 Cleaning ................................................................................................................................................ 6

1.6 Features and Capabilities .................................................................................................................................. 6

1.7 Unpacking and Initial Checks ............................................................................................................................ 7

1.8 Functional Overview ......................................................................................................................................... 7

2 SPECIFICATIONS ................................................................................................................................................. 8

3 OPERATION ........................................................................................................................................................ 9

3.1 Front Panel Display and Controls ...................................................................................................................... 9

3.2 Connecting the Zero Air Filter Assembly ........................................................................................................... 9

3.3 Zero Air Filter Service Life ............................................................................................................................... 10

3.4 Connecting Gas-Sample, Exhaust and Purge Lines ......................................................................................... 11

3.4.1 Overview ............................................................................................................................................. 11

3.4.2 Connecting the Gas-Sample Line or Probe (model 3015-5420) ......................................................... 11

3.4.3 Connecting the Gas-Sample Probe 3015-5694 ................................................................................... 11

3.4.4 Connecting the Exhaust Line .............................................................................................................. 11

3.4.5 Connecting Zero Air Inlet to an External Purge Line (Optional) ......................................................... 12

3.5 Gas Detector Operation .................................................................................................................................. 12

3.6 Battery Charging and Using ............................................................................................................................. 13

3.6.1 Charging the Battery ........................................................................................................................... 13

3.6.2 Using the Battery ................................................................................................................................ 13

3.7 Display Screens ............................................................................................................................................... 13

3.7.1 Initial Power ON .................................................................................................................................. 13

3.7.2 Data Display Screen ............................................................................................................................ 13

3.7.3 Function Screens ................................................................................................................................ 14

3.8 Working with System Faults ............................................................................................................................ 17

3.8.1 Functional Overview ........................................................................................................................... 17

3.8.2 Clearing / Silencing a Fault Alarm ....................................................................................................... 17

3.8.3 Viewing the Faults Log ........................................................................................................................ 17

3.8.4 Fault Codes ......................................................................................................................................... 18

3.9 Working with the Gas Alarm (Area Monitoring) ............................................................................................. 18

3.9.1 Gas-Alarm Light .................................................................................................................................. 18

3.9.2 Silencing a Gas Alarm ......................................................................................................................... 18

3.10 Working with the Gas Alarm (Leak Detector Option) ..................................................................................... 19

3.10.1 Gas-Alarm Light Plus Audio Feedback ................................................................................................ 19

3.11 Clearing the PPM & Faults Data ...................................................................................................................... 19

3.12 Working with the DIAGNOS Function ............................................................................................................. 19

3.12.1 Overview ............................................................................................................................................. 19

3.12.2 Keypad Functions................................................................................................................................ 19

3.12.3 First Diagnostic Screen ....................................................................................................................... 19

3.12.4 Second Diagnostic Screen ................................................................................................................... 20

Instruction 3015-5466 (Rev 6) 3

Halogen Monitor (Bagless PAGM)

3.13 Working with the P-CHK Function ................................................................................................................... 21

3.13.1 Overview ............................................................................................................................................. 21

3.13.2 Keypad Functions................................................................................................................................ 21

3.13.3 Screen Display..................................................................................................................................... 21

3.14 Print/Plot Logged Gas Levels ........................................................................................................................... 21

3.15 Downloading Stored Data to a Personal Computer ........................................................................................ 22

3.16 Importing Saved Data Into a Spreadsheet ...................................................................................................... 24

4 MAINTENANCE ................................................................................................................................................. 25

4.1 Disassembly ..................................................................................................................................................... 25

4.2 Internal Particulate / Hydrophobic Filter Replacement .................................................................................. 26

4.3 Updating Firmware ......................................................................................................................................... 27

4.4 Probe Filter Replacement ............................................................................................................................... 27

5 PARTS AND SERVICE ......................................................................................................................................... 28

5.1 Replacement Parts & Optional Items .............................................................................................................. 28

5.2 Service Centers ................................................................................................................................................ 28

4 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

1 Introduction

1.1 How to Use This Manual

This manual provides important information on how to operate and service Bacharach’s Refrigerant Monitor. To
assure operator safety and the proper use of the monitor, please read, understand, and follow the contents of this
manual.

If you have a working knowledge of gas monitors, you will find this manual useful as a reference tool. If you are
new to the use of gas monitors, you can educate yourself about the principles of gas detection and the proper
operation of this device by reading this manual thoroughly.

1.2 Warning Statements

The use of the word WARNING in this manual denotes a potential hazard associated with the use of this
equipment. It calls attention to a procedure, practice, or condition, or the like, which if not correctly performed or
adhered to, could result in personal injury or death.

1.3 Caution Statements

The use of the word CAUTION in this manual denotes a potential hazard associated with the use of this
equipment. It calls attention to a procedure, practice, condition, or the like, which if not correctly performed or
adhered to, could result in damage to the equipment.

1.4 Hazard Symbols on Monitor

The following symbol indicates the need to consult this operating instruction manual when opening the enclosure.

WARNING: A potential risk exists if the operating instructions are not followed.

The following symbol indicates the presence of electric shock hazards when the enclosure is opened.

WARNING: To avoid risk of injury from electric shock, do not open the enclosure when power is
applied.

Instruction 3015-5466 (Rev 6) 5

Halogen Monitor (Bagless PAGM)

1.5 Safety Precautions

1.5.1 Explosive Atmosphere

Do not operate this equipment in the presence of flammable liquids, vapors or aerosols. Operation of any electrical
equipment in such an environment constitutes a safety hazard.

HAZARDOUS AREA WARNING: This instrument has not been designed to be intrinsically safe for
use in areas classified as hazardous locations. For your safety, DO NOT

(classified) locations.

COMBUSTIBLE/FLAMMABLE GAS WARNING: This is NOT a safety device. Some gases which this
instrument can detect may be combustible/flammable. When properly configured, this instrument
is designed to alarm at concentrations that are lower than the explosive limit of the gas. As such, it
is the buyer’s responsibility to initiate an immediate planned response to any gas leaks as soon as
they are detected. This equipment should NEVER be used to measure or sample gases at or above

their respective lower explosive limits.

1.5.2 Misuse and Modifications t o Monitor

The protection provided by the monitor may be impaired if the monitor is used in a manner not specified by
these instructions. Changes or modifications to this monitor will void the warranty.

use it in hazardous

WARNING: A gas monitor is not to be used in any application that is beyond its intended purpose

or beyond the scope of its specifications. For details on appropriate use, refer to the general
description, application, and operation discussions in this manual. Before risking equipment
damage or personal injury, contact Bacharach if you are unsure of the validity of a particular gas

monitor application.

1.5.3 Altitude Limit

6,562 ft (2,000 m)

1.5.4 Cleaning

Clean the outside of the monitor’s case using a dry cloth — DO NOT use soap and water

1.6 Features and Capabilities

• Detects, measures, and displays the level of refrigerant gas in the area being monitored

• Measures all gases up to 10,000 ppm with a sensitivity of 1 ppm

• Automatically logs up to 200 gas readings that can be printed / plotted for analysis

• Eliminates false alarms with use of non-dispersive IR source and sample draw system

• Visual and audible gas alarm indictors that are turned ON when the detected gas level exceeds a user

defined trip-point

• Extensive self diagnostics, providing both visual and audible indications when a fault occurs

• Battery powered, providing 8–12 hours of operation

6 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

1.7 Unpacking and Initial Checks

Your Refrigerant Monitor was carefully inspected at the factory before shipment, and packed so as to be highly
resistant to damage while in transport. When you receive the instrument, however, please unpack it promptly
and make a visual inspection to make sure that no damage has occurred during shipment. Also check that all
the following items have been received.

Included with

Item Part No.

External Filter Assembly (gas sample) 3015-5324 2 -

Soft Carrying Case with Shoulder Strap 3015-5700 1 1

Battery Pack and Charger Kit 3015-5739 1 1

Probe Assembly 3015-5694 - 1

Stainless Steel Tube 3015-5326 1 -

Instruction Manual 3015-5466 1 1

Elbow 3015-3234 1

Tubing 0003-6182 3 ft.

Coalescing Filter 3015-3071 -

3015-5722 1 -

Filter Assembly (zero air sample)

3015-5714 - 1

If damage was found, immediately file a claim with the carrier. If an item is missing, please contact the Service
Department for assistance (refer to Service Centers on page 28).

Refrigerant Monitor

3015-5420

Included with

Refrigerant Monitor

3015-5696

Part of probe

3015-5694, above

1.8 Functional Overview

The Bacharach Refrigerant Monitor is designed to detect, measure, and display the concentration of refrigerant
gas in the area being monitored. To ensure accurate gas measurements, the monitor self-zeros every 4 minutes
using an external supply of fresh air provided by activated carbon filtering.

During normal operation the Refrigerant Monitor displays both the current gas level and the peak gas level
detected on its front panel LCD. The monitor retains a log of previous readings that can be easily accessed at a
later time for analysis.

Front panel indicators and an audible alarm are provided to signal gas alarm and instrument fault conditions.
The audible alarm can temporarily be silenced by a push of a button, but will reactivate if the gas level is still
above the alarm trip point after a user-defined time period has elapsed.

The Refrigerant Monitor requires only minor periodic maintenance such as the occasional replacement of filters.
The monitor incorporates active diagnostics that continuously check the system for proper operation. A front
panel indicator is provided to alert an operator of system malfunctions, and fault codes are generated that
enable the operator to quickly identify the cause of the fault.

Instruction 3015-5466 (Rev 6) 7

Halogen Monitor (Bagless PAGM)

2 Specifications

Product Type ........................... Portable refrigerant gas monitor

Gas Library:

HALON: H1301, H2402, H1211

Other: FA188, FC72, N1230

Measuring Range ..................... All gases 0 to 10,000 ppm

Warm-Up Time ........................ 5 minutes

Detector Type ......................... Infrared, Non-Dispersive

Sensitivity ................................ 1 ppm

Accuracy ................................. ±1 ppm ± 10% of reading from 0-1000 ppm

Response Time ........................ 90% of response within 5 seconds; 100% in 7 seconds

Temperature Drift ................... 1.5 ppm per degree C between purge cycles

System Noise ........................... Less than 40dB(A) at 10 ft (3 m)

Operating Temp ...................... 32 to 122°F (0 to 50°C)

Ambient Humidity ................... 5 to 90% RH (non-condensing)

Altitude Limit .......................... 6,562 ft (2,000 m)

Power ..................................... DC power pack, provides 8–12 hours of operation

Power Consumption ................ 15 Watts

Front Panel 3 Indicator lights:

ON: Green LED flashes during warm-up, and then glows steady

FAULT: Yellow LED flashes when there is a system fault.

ALARM: Red LED flashes when the gas level is above its alarm setting.

Audible Alarm ......................... Internal audible alarm programmable for any of the following conditions:

Dimensions ............................. 9D x 14.5L x 5W inches (229 x 368 x 127 mm)

Weight .................................... Less than 9 lbs (4 kg) including battery

Valid Calibration Period

to Specifications ...................... 12 months

Warranty ................................. 2 years from date of shipment

CFC: R-11, R-12, R-113, R-114, R-502, HFP

HFC: R-404a (HP62), R-407a, R-407c (AC9000), R-134a, R-410a (AZ20), R-507 (AZ50),

R-508b (SUVA95), R236FA, R125, R245Fa, R422a, R422d, R427a, R424a, R426a,
R438a

HCFC: R-22, R-123, R-124, R-500, R-503, R-401a (MP39), R-402a (HP80), R-402b (HP81), R-408a,

R-409a, R-23, R21, R227

R11, R22 and R113 are ±10ppm ±15% of reading from 0-1000ppm

during normal operation.

OFF, FAULT/ALARM, ALARM

8 Instruction 3015-5466 (Rev 6)

3 Operation

3.1 Front Panel Display and Controls

Halogen Monitor (Bagless PAGM)

3.2 Connecting the Zero Air Filter Assembly

A Zero Air Filter Assembly must be installed to properly use the Bacharach Refrigerant Portable Monitor. The
following steps should be taken to install the filter.

1. Unfasten the Velcro on the front of the monitor soft case.

2. Slide the zero air filter into the front pocket. Route the tubing through the hole in the back of the

pocket, along the side of the housing.

3. Insert the elbow connector extending from the Charcoal Filter Assembly into the Zero Air Inlet on

the monitor.

4. Refasten the Velcro.

Instruction 3015-5466 (Rev 6) 9

Halogen Monitor (Bagless PAGM)

To connect the elbow connector to the zero air
filter PTC fitting, firmly push the elbow into the
hole in the center of the connector until it seats in
the connector. Refer to the figures at the left.

To remove the elbow from a PTC connector, push
and hold the spring-loaded collar inwards, then
simultaneously withdraw the tubing/elbow. Refer
to the figures at the right.

3.3 Zero Air Filter Service Life

The monitor will periodically (up to 4 minute intervals) draw clean air from an intake port on the side of the
chassis. The external zero air (charcoal) filter (P/N 3015-5722) must be connected to this purge port per Section

3.2 in order to scrub any ambient refrigerant present in the area of operation. When the filter is saturated and can
no longer absorb refrigerant, refrigerant can pass thru and create an offset on subsequent measurements, so
proper filter maintenance is important. The purge intake filter can operate continuously in a 10 ppm ambient for
up to 10 hours before measurement accuracy will be affected. For higher ambient levels the run time is reduced
proportionally. To avoid measurement errors Bacharach recommends the following purge filter replacement
intervals.

Approximate Ambient Refrigerant Level Filter Replacement Interval

0 ppm 6 months

5 ppm 250 hrs
10 ppm 200 hrs
20 ppm 150 hrs

100 ppm 100 hrs

The refrigerant monitor can detect a saturated filter during operation by sampling clean (0 ppm) air after the unit
has been purged in the presence of ambient refrigerant. A fault will occur (0100) if refrigerant is detected on the
purge port.

10 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

3.4 Connecting Gas-Sample, Exhaust and Purge Lines

3.4.1 Overview

A single gas-sample line needs to be run from the Refrigerant Monitor to the area to be monitored. If desired,
an optional exhaust line can be installed to vent refrigerant gas away from the monitor.

3.4.2 Connecting the Gas-Sampl e Line or P robe (Model 3015-5420)

To connect the gas-sample line to the monitor, simply push the tubing onto the elbow connector and attach the
elbow to the Gas Sample Port on the front of the monitor as shown in the illustration below.

The gas-sample line can be up to 50 ft (15.2 m) in length. All tubing bends should have a radius of no less than
5" to insure proper airflow. If kinks or obstructions occur in the line the monitor may not function properly.

NOTE: Every foot of tubing added to the sample probe increases the instrument response time by 1 second.
For best performance use the tubing provided with the instrument when possible.

The end of this line should be placed near the potential leak source and positioned to reduce the possibility of
mists, aerosols, oil, water, dust, or other contaminates being drawn into the monitor.

An external filter (P/N 3015-5324) should be attached to the end of this line. See figure on page 11 for details.

3.4.3 Connecting the Gas-Sample Probe 3015-5694

If refrigerant monitor 3015-5696 was ordered the probe assembly is provided pre-assembled. Simply connect
the elbow to the gas sample port. See figure on page 11 for details.

3.4.4 Connecting the Exhaust Line

The optional exhaust line carries the exhausted gas sample away from the monitor. The exhaust line can be up
to 50 ft (15.2 m) in length. Ideally this line should terminate outdoors in a location that is not exposed to the
elements.

Instruction 3015-5466 (Rev 6) 11

Connecting the Gas Sample Line or Probe

Halogen Monitor (Bagless PAGM)

Connect the exhaust line to the monitor by firmly pushing the tubing into the Exhaust Port’s push-to-connect
(PTC) fitting. See below. If the exhaust line terminates outside the building, position the tubing so that no water
or moisture can enter the line. Note that this line does not require a termination filter.

To connect the exhaust line to the exhaust port’s
PTC fitting, firmly push the appropriate tubing into
the hole in the center of the connector until it seats
in the connector. Refer to the figures at the left.

To remove tubing from a PTC connector, push and
hold the spring-loaded collar inwards, then
simultaneously withdraw the tubing. Refer to the
figures at the right.

3.4.5 Connecting Zero Air Inlet to an External Purge Line (Optional)

If using the charcoal filter assembly a purge line is not required.

The purge line provides the same function as the charcoal filter, supplying clean air (0 ppm target gas
concentration) into the monitor for the purpose of purging the monitor and setting its baseline reading.

The zero air inlet can be up to 50 ft (15.2 m) in length. This line should terminate in an area known to contain
clean (0 ppm) air. To connect the purge line to the monitor, simply push the tubing into the Purge Air Inlet Port.
If the purge line terminates outside the building, position the tubing so that no water or moisture can enter the
line.

3.5 Gas Detector Operation

CAUTION: Operate the monitor in its horizontal position (handle facing upwards). Tilting the
monitor to a vertical position while in operation may cause inaccurate measurements to occur.

Turn ON the monitor as follows:

1. Lift up the shield located in front of the handle

2. Press the green power ON/OFF toggle switch.

3. Observe monitor’s firmware version is briefly displayed.

4. Observe the monitor starts counting down its warm-up period of

300 seconds (5 minutes).

Observe the following as the monitor makes gas measurements in the area being sampled:

• MEASURE indicates when the monitor is actively measuring the level of refrigerant gas at the sampling

point. The measurement cycle runs for 4 minutes.

A log of up to 200 previous measurements can be viewed using the PPM LOG function as described on
page 14.

• PURGE indicates when the monitor is resetting its infrared detector to a baseline of 0 ppm. The purge

cycle runs for 10 seconds.

Work with gas alarms and system faults as follows:

12 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

VERSION x.xx

ALARM (red) light turns ON if the detected gas level exceeds a programmed alarm point.
An audible alarm also sounds if the AUDALRM function is activated. Pressing the front panel
SILENCE button turns OFF the audible alarm, but the ALARM light will continue to flash for as long
as the detected gas level is above the alarm point. The audible alarm will reactivate if the gas-alarm
condition is not cleared within the time period set by the SILENCE function (refer to text starting on
page 14).

FAULT (yellow) light turns ON if a fault occurs (see Fault Code list on page 18). An audible alarm also
sounds if the AUDALRM function is activated. Pressing the front panel SILENCE button turns OFF the
audible alarm, but the FAULT light continues to flash for as long as the fault is present. The audible
alarm will reactivate if the fault condition is not cleared within the time period set by the SILENCE
function (refer to page 14). Both the FAULT light and audible alarm will automatically turn OFF after
the cause of the fault has been eliminated. A log of the last 30 fault events can be viewed using the
monitor’s FAULTS function (page 16).

3.6 Battery Charging and Using

3.6.1 Charging the Battery

The monitor is powered by a rechargeable battery pack located in a pouch on the side of the monitor’s soft
carrying case. The battery pack can be recharged at any time, regardless of the battery’s current charge state.

The AC adapter provided accepts voltage inputs of 100 to 240 VAC. Plug the adapter into the wall, then into the
battery. Disconnect the adapter when the battery is fully charged. A fully charged battery pack will power the
monitor for approximately 8-12 hours.

3.6.2 Using the Battery

The PAGM is designed for a 16VDC input. Following the instructions for the particular battery in use, set the
output voltage to 16V. Plug the battery into the instrument's battery input port and the instrument is ready for
use.

3.7 Display Screens

3.7.1 Initial Power ON

When the monitor is first powered ON, all front panel lights turn ON and a splash screen appears showing the
monitor’s current firmware revision level. After a brief moment the Warm Up screen is displayed along with the
front panel ON light (green) blinking.

The monitor requires 5 minutes to warm up from a cold start; after which, the ON light glows steady and the
Data Display screen appears.

3.7.2 Data Display Screen

During normal operation the Data Display screen shows when the monitor is performing the following functions:

ME

ASURE

indicates that the monitor is actively measuring the refrigerant gas level at the

sample point. To reset the peak value to zero, press the

PURGE is displayed when the monitor is resetting its infrared detector to a baseline ppm value
using fresh air that is being drawn in through the Purge Air Inlet Port. This purging process is
performed on an “as needed” basis, which is normally once every 6 to 8 minutes.

WARM UP

EN

TER

button.

Instruction 3015-5466 (Rev 6) 13

Halogen Monitor (Bagless PAGM)

– Contains records of the last 200 measurements. Each record

shows the measurement’s date, time, and ppm level. Measurements are

function. After all 200

buttons to change the record number by a

buttons to change the record number by a

.

.

,

FAULTS –

>)

07/11/05 12:37

07/11/05 15:35

>LOG INT AUDALRM
LOOP CLOCK

>GASTYPE SPILLVL
ALARMS DIAGNOS

PRES CHK

is displayed when the monitor is performing an atmospheric pressure check, which is
done to ensure the accuracy of the gas measurement under varying atmospheric conditions. This
pressure check is performed every 30 minutes.

3.7.3 Function Screens

The Function screens are used to set up the monitor and display stored data. From the Data Display screen,
press both the Keypad Left and Right buttons at the same time to display the first Function Menu screen. Next,
use the Keypad buttons to move the arrow (>) until it points to the desired function, and then press the ENTER
button to select that function.

>PPM LOG FAULTS

LEAKLVL EVACLVL

>SILENCE
ZONETEMP

Once a function has been selected, use the Keypad to scroll through the displayed data or to change a
parameter associated with that function. Press ENTER to save any newly entered parameters. Press the ESC
button to return to the previous screen without saving.

Note that if no buttons are pressed within 90 seconds after selecting a function, the unit returns to the Data
Display screen.

PPM LOG

>P-CHK CUST
K2

#025 7PPM @

logged at an interval determined by the LOG INT
locations are filled the newest entries overwrite the oldest entries.

Use the Keypad Up and Down
factor of 1. Use the Right and Left
factor of 10. Press ESC to return to the previous screen.

The PPM Log can be cleared per the Section “Clearing the PPM & Faults Data”
on page 19.

ALARMS – Contains

records of the last 30 alarm events, with the monitor’s

most recent alarm being shown when the Alarm screen is first displayed
After 30 events have been recorded, the newest record overwrites the
oldest. Each record displays either LEAK, SPILL, or EVAC including the date
and time the alarm occurred. Use any of the Keypad buttons to scroll
through the other alarm records. Press ESC to return to the previous screen

The ppm levels at which alarms occur are set using the LEAKLVL, SPILLLVL
and EVACLVL functions.

Contains records of the last 30 fault events. The most recent

event is displayed when the Fault screen is first displayed. After 30 events
have been recorded, the newest record overwrites the oldest. Each record
lists an event’s numeric fault code (refer to Section 3.8) plus the date and
time at which the event occurred. Use any of the Keypad buttons to scroll
through the other fault events. Press ESC to return to the previous screen.

To the right, record #15 shows that a Purge Flow Fault (fault code <1000
occurred on 07/11/2005 at 12:37 PM.

14 Instruction 3015-5466 (Rev 6)

#15 <1000> @

DIAGNOS –

Enters the diagnostic function. Refer to Section 3.12

.

–

–

SPILLLVL –

–

LOG INT –

–

–

,

AUDIBLE ALARM IS
OFF

0.016 mA

0001 min

1000 PPM

EDIT SPILL LEVEL
700 PPM

500 PPM

REFRIGERANT

Halogen Monitor (Bagless PAGM)

GAS TYPE

Displays refrigerant gas as the gas being monitored. No other

gas types are available for selection.

LEAKLVL/RANGE

Sets the Leak Alarm level, adjustable from 1 to 1999

ppm. Factory default is 500 ppm. The Leak Alarm level cannot be set higher
than either the Spill or Evacuate Alarm levels. Use the Keypad to set the
desired Leak Alarm level, and then press ENTER to save that level and return
to the previous screen.

When the LEAK DETECTOR option is set in AUDALRM the user menu will
display the word RANGE in place of the word LEAKLVL. Adjust the value to
correspond to the maximum concentration to be detected. The instrument
will beep and blink the ALARM light proportional to the gas concentration
present.

Sets the Spill Alarm level, adjustable from no lower than the

Leak Alarm level to a maximum value of 1999 ppm, but not higher than the
Evacuate Alarm level. Factory default is 700 ppm. Use the Keypad to set
the desired Spill Alarm level, and then press ENTER to save that level and
return to the previous screen.

EVACLVL

Sets the Evacuate Alarm level, adjustable from no lower than

the Spill Alarm level to 1999 ppm. Factory default is 1000 ppm. Use the
Keypad to set the desired spill level alarm level, and then press ENTER to
save that level and return to the previous screen.

SELECT GAS TYPE

EDIT LEAK LEVEL

EDIT EVAC LEVEL

Sets the interval at which measurements are logged to

memory from 1 to 9999 minutes. Factory default is 1 minute. The logged
measurements can be viewed using the PPM LOG function. Use the Keypad
to enter the desired value, and then press ENTER to save that value and
return to the previous screen.

LOOP

Adjusts the loop factor of the 4-20 mA current loop. Factory
default is 0.016 mA per ppm, which provides an output range of 0 ppm
(4 mA) to 1,000 ppm (20 mA). Use the Keypad to set the desired loop
factor, and then press ENTER to save that value and return to the previous
screen.

To facilitate loop zero and span checking, note that when the LOOP function
is selected the loop output is set to 20 mA, and upon exiting this function
the loop output is set to 4 mA.

AUDALRM

Allows the monitor’s internal audible alarm to be associated

with any function of the monitoring system. Factory default is OFF. Use the
Keypad to select the desired audible alarm function, and then press ENTER
to save that value and return to the previous screen.

Audible Alarm Settings: OFF, ANY ALARM, SYSTEM FAULT, LEAK ALARM
SPILL ALARM, EVAC ALARM, MONITOR STOPPED, LEAK DETECTOR.

NOTE: MONITOR STOPPED indicates there is a critical system fault, and the
monitor is no longer functioning correctly.

Instruction 3015-5466 (Rev 6) 15

LOG INTERVAL IS

EDIT LOOP FACTOR

Halogen Monitor (Bagless PAGM)

CLOCK –

SILENCE –

a

to

P-CHK –

-0.02dif <1000>

CALFACTOR

1.000

25 degC

5 PPM

0030 sec

07/11/05 15:30

Sets the monitor’s date and time. Use the Keypad to enter the

correct date and time, and then press ENTER to save those values and
return to the previous screen. Note that time is displayed in a 24 hour
format, while the date is displayed as mm/dd/yy.

Sets the length of time the internal audible alarm is turned

OFF when the front panel SILENCE button is pressed. The factory default is
30 seconds. If the cause of the gas-alarm has not been cleared at the end
of this time period, the internal audible alarm will reactivate. Use the
Keypad to enter the desired time period, and then press ENTER to save
that value and return to the previous screen.

SQUELCH - Sets

value of between 0.0 and 100 ppm that prevents the

display of measurements below that value. Factory default is 0 ppm. For
example, if the squelch setting is set to 5 ppm, then the monitor will not
display measurements that are below that value. Use the Keypad to enter
the desired value, and then press ENTER to save that value and return to
the previous screen.

ZONETEMP - Used

enter the temperature of the area being monitored

in °C, thus giving a more accurate ppm reading. The factory default is 25°C.
Use the

K

eypad

to enter the desired temperature, and then press

ENTER

to save that value and return to the previous screen.

CAL -

Used to change the monitor’s calibration factor. This function is to

be used ONLY with instructions from a Bacharach Service Center. Factory
default is 1.000.

The Pressure Check function displays the current manifold

pressure and the stored ambient pressure in psia, along with the difference
between these two pressures and the current fault code. Refer to
Section

3.13.

SET DATE & TIME

SILENCE TIMEOUT

SQUELCH BELOW

TEMP AT ZONE =

14.07 * AMB14.05

16 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

. To

13 PURGE FLOW

12 SAMPLE FLOW

07/11/05 09:00

07/11/05 08:17

3.8 Working with System Faults

3.8.1 Functional Overview

If a system malfunction occurs (see Fault Code list, Page 18), the front panel FAULT light will flash and the audible
alarm, if activated (see AUDALRM function), will start beeping.

3.8.2 Clearing / Silencing a Fault Alarm

The FAULT light and audible alarm will automatically turn OFF after the cause of the fault has been eliminated.

Pressing the SILENCE button while a fault condition still exists causes the internal audible alarm to turn OFF for a
period of time as set by the SILENCE function (refer to Function Screens on page 16). The front panel FAULT light
will continue to flash as a reminder that a fault condition still exists. At the end of the silence period if the cause
of the fault has not been corrected the audible-alarm circuit will reactivate.

3.8.3 Viewing the Faults Log

From the Data Display screen, press any of the Keypad buttons to display the first Function Menu screen. Next,
use the Keypad buttons to move the arrow (>) until it points to the FAULTS function, and then press the ENTER
button to display the Faults Log screen.

The Faults Log screen shows the monitor’s current fault status. If the fault
is still present when the FAULTS function is selected, then the current
cause of the fault is displayed along with the date and time it occurred. If
the cause of the fault has been cleared, then the Faults Log screen will
show <0000> along with the date and time the fault was cleared. Use the
Keypad buttons to scroll through the fault log. In the screens shown to the
left, record #03 shows that a Sample Flow Fault (fault code <0800>)
occurred on 07/11/2005 at 08:17 AM, while record #04 shows that the fault
was cleared on 07/11/2005 at 9:00 AM.

The cause of the fault is identified by a numeric fault code
fault code into a text description of the fault, first press the ENTER button
and then use the Keypad buttons to scroll through the display until the text
description of the fault appears. If the fault code is a combination of two or
more faults, then continue to use the Keypad buttons until all fault text
descriptions have been displayed. For example, the fault code <1800>
represents the combination of both a Sample Flow <0800> and a Purge
Flow <1000> fault as shown to the left.

The Fault Log can be cleared as described under the heading Clearing the
PPM and Faults Data (Section 3.11).

convert the

#03 <0800> @

#04 <0000> @

FAULT CODE<1800>

FAULT CODE<1800>

Instruction 3015-5466 (Rev 6) 17

Halogen Monitor (Bagless PAGM)

3.8.4 Fault Codes

Fault codes are additive. For example, a fault code of <0003> indicates that both a Box Temperature Fault
<0001> and a Bench Temperature Fault <0002> have occurred.

Code Type Description

<0001>

<0002>

<0004>

<0080>

<0200>

<0400> A/D Fault

<0800>

<1000>

<4000>

Box Temperature
Fault

Bench Temperature
Fault

Manifold Pressure
Fault

Over Range Fault

Gain Set Fault

Sample Flow Fault

Purge Flow Fault

Zero Range Fault

Enclosure temperature is outside normal range (or IR detector has failed).
Check that the monitor is not being subjected to extreme temperatures.
Use the

Optical sensor is outside normal operating range (or IR detector has failed).
Check that the monitor is not being subjected to extreme temperatures.

The manifold pressure is outside its normal operating range (or IR detector
has failed). Enter the
with this information for further instructions.

Monitor exposed to a gas level that exceeded 65,000 ppm.

The digipot autotune sequence has failed. This fault will only occur on first
boot up or after a firmware upgrade. Call the factory for further
instructions.

A fault has occurred in the analog-to-digital circuitry. Contact the factory
with this information for further instructions.

Check for a restriction in the gas-sample inlet or exhaust; a blocked internal
filter; or a failed pump.

Check for a restriction in the gas-sample exhaust; a blocked internal filter;
or a failed pump. Once the purge air stream has been restored, the
monitor will return to normal operation after it completes a purge cycle.

The IR detector’s output voltage is out of tolerance. Enter the
and record all data. Call the factory with this information for further
instructions.

DIAG function to check the Box Temperature.

DIAG function and record ALL data. Call the factory

DIAG function

DIAG function to

<8000>

Clipping Fault

The detector voltage may be out of tolerance. Use the
check the IR detector voltage. Call the factory with this information for
further instructions.

3.9 Working with the Gas Alarm (Area Monitoring)

3.9.1 Gas-Alarm Light

If the detected gas level reaches the gas-alarm level as set by the ALRMLVL function, the front panel ALARM
(red) light will flash and the audible alarm, if activated (refer to AUDALRM function in the Function Screens

section on page 15), will start beeping. The ALARM light and audible alarm will automatically turn OFF once the
detected gas level drops below the gas-alarm level.

3.9.2 Silencing a Gas Alarm

Pressing the SILENCE button while the alarm circuit is activated causes the audible alarm to turn OFF for a period
of time as set by the SILENCE function. The front panel ALARM light will continue to flash as an indication that
an alarm condition still exists. At the end of the silence period if the detected gas level is still above the gas­alarm level the audible alarm will reactivate.

18 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

29.05cD 14.58psi

Detector Temperature °C ∗ Pressure Reading

0.00075n <0000>

35.40cB 14.59psi

Noise Fault Code
Box Temperature °C ∗ Pressure Reading

3.10 Working with the Gas Alarm (Leak Detector Option)

3.10.1 Gas-Alarm Light Plus Audio Feedback

When the LEAK DETECTOR option is selected in the AUDALRM menu, the instrument provides a ticking sound via
the internal beeper and flashes the red ALARM LED at a rate proportional to the displayed reading. At 0 ppm the
rate is approximately 1 per second. The range over which the tick sound is scaled is set using the “RANGE” menu
(taking the place of the LEAKLVL menu option).

During a purge cycle the tic sound is suspended to let the operator know that the instrument is not sampling.
Purging typically completes in approximately four seconds.

If power is removed or the product turned off, “Leak Detector Mode” remains set.

It is not possible to silence the Gas Alarm when LEAK DETECTOR operation is selected.

3.11 Clearing the PPM & Faults Data

Up to 200 gas measurements and 30 fault events are stored by the monitor.

To clear stored data, first display the data to be cleared by selecting the PPM LOG or FAULTS function per
Section 3.7.3 on page 14. Next, press both the ENTER and Keypad Right buttons at the same time. A single, long
tone should be heard when the data has been successfully cleared.

3.12 Working with the DIAG Function

3.12.1 Overview

The DIAG function displays sensor data and status information useful to a service technician for troubleshooting
various fault conditions. Explanations of the data shown in these screens are given below.

3.12.2 Keypad Functions

From the Data Display screen, press any one of the Keypad buttons to display the first Function Menu screen.
Next, use the Keypad buttons to move the arrow (>) until it is next to the DIAG function, and then press ENTER
to display the first of two Diagnostic screens.

Press the Keypad Up button to toggle between the First and Second Diagnostic screen.

3.12.3 First Diagnostic Screen

4.20885v <0000>

In the First Diagnostic screen, the user can toggle between displaying Sensor Voltage / Detector Temperature,
and Noise / Box Temperature by pressing the Keypad Right button.

Bench Voltage Fault Cod e

Instruction 3015-5466 (Rev 6) 19

Halogen Monitor (Bagless PAGM)

0.00004au 4.210v

PPM Level µMole/Liter
Avg. Absorption Unit ∗ Detector Voltage

Screen Item Description

Sensor Voltage This is the current peak-to-peak output of the IR detector. In the absence of gas

this value can range from 3.90000V to 4.50000V.

Noise The Noise value is a 16 point running average of the noise portion of the IR

detector’s output. This reading is valuable mainly when gas is NOT present.

Detector Temperature This is the current detector temperature in °C.

Box Temperature This is the current internal enclosure temperature in °C.

Fault Code Current fault code. A value of <0000> indicates that no faults are being detected.

Pressure Reading This is the pressure as measured every purge cycle with the sample pump off and

the gas-sample inlet open. Its value is weather and altitude dependent and can
range from 10.0 to 15.5 PSIA.

Purge Valve Asterisk (∗)

The purge valve can be opened and closed by pressing the Keypad Left button. An
asterisk appears on the display when the purge valve is open causing the monitor
to draw air from its purge-air port.

3.12.4 Second Diagnostic Scr e e n

0.1ppm 0.01

Screen Item Description

PPM Level

Average Absorption Unit

µMoles/Liter This is the absolute concentration in micro-moles per liter of gas.

Detector Voltage

Purge Valve Asterisk (∗)

Parts Per Million Level is the current detected gas level, and is the volume
concentration referenced to standard temperature and pressure.

This is the optical absorbency. In the absence of gas the absorbency is

0.00000 au. When sampling gas, its value varies proportionally with the gas
concentration.

This is a running average of the IR detector’s sensor voltage.

The purge valve can be opened and closed by pressing the Keypad Left button.
An asterisk appears on the display when the purge valve is open causing the
monitor to draw air from its purge-air port.

20 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

-0.16dif <0000>

3.13 Working with the P-CHK Function

3.13.1 Overview

The P-CHK function (Pressure Check function) (see section 3.7.3 on page 16) is useful to a service technician for
troubleshooting a flow-fault problem. The monitor will trigger a flow fault if the pressure drop from ambient is
less than 0.2 psi during a purge cycle, and 0.5 psi during a measurement cycle.

3.13.2 Keypad Functions

From the Data Display screen, press both the Keypad Left and Right buttons at the same time to display the
first Function Menu screen. Next, use the Keypad buttons to move the arrow (>) until it points to the P-CHK
function, and then press ENTER to display the Pressure screen.

The Keypad Left button toggles the purge valve open and closed. Note that an asterisk (*) appears when the
purge valve is open causing the monitor to draw air from the purge-air bag.

The Keypad Down button toggles the pump ON and OFF.

Pressing the ENTER button stores the current manifold pressure shown on the left to the ambient pressure
shown on the right (must be done with the pump OFF).

3.13.3 Screen Display

14.59 AMB14.75

Current Manifold Pressure ∗ Stored Ambient Pressure
Pressure Difference Fault Code

Screen Item Description

Current Manifold Pressure

Stored Ambient Pressure

Pressure Difference

Fault Code

Purge Valve Asterisk (∗)

Current manifold pressure in psia.

Stored ambient pressure in psia.

Difference between the current manifold pressure and the stored ambient pressure.

Current fault code (Page 18).

The purge valve can be opened and closed by pressing the Keypad Left button.
An asterisk appears on the display when the purge valve is open causing the
monitor to draw air from the purge-air bag.

3.14 Print/Plot Logged Gas Levels

A printout or plot of the last 200 ppm measurements can be made by connecting the optional Bacharach printer
and printer cable to the monitor as follows. (Refer to Replacement Parts section on page 28 for printer and cable
part numbers).

1. For a printout or plot to be made, the monitor must have been set up to record gas measurements using

the LOG INT function.

2. Interconnect the RS-232 connectors located on the printer and monitor.

3. If not already done, refer to the printer manual and set the printer’s communication parameters to:

• Data bit = 8

• Parity = None

• Baud rate = 19200

• Handshaking = DTR

Instruction 3015-5466 (Rev 6) 21

Halogen Monitor (Bagless PAGM)

4. From the Data Display screen, press both the Keypad Left and Right

buttons at the same time to display the first Function Menu screen.
Next, use the Keypad buttons to move the arrow (>) until it points to
either PRINT to produce a printout, or PLOT to generate a plot.

5. Press ENTER to start the print/plot process.

2ndUNIT >PRINT
PLOT PC-DUMP

3.15 Downloading Stored Data to a Personal Computer

Using the monitor’s PC DUMP feature, the last 200 refrigerant gas readings that were stored in memory can be
downloaded to a personal computer in ASCII text, comma-delimited format, which can then be imported into
most spreadsheet programs for analysis.

22 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

The following describes how to download data to a computer using Windows HyperTerminal as the
communications program. If a different operating system and/or communications program is being used, then
consult the appropriate instruction manuals for those products.

1. Install serial data cable P/N 104-4027 (straight through, 6 foot, DB9 male to DB9 female) between the

computer’s COM port and the analyzer’s RS-232 connector. (For computers having a 25-pin COM port,
either use a 25-pin to 9-pin adapter, or use a serial cable with appropriate connectors on each end.)

2. At the computer, start HyperTerminal by doing one of the following:

• If HyperTerminal has already been set up to communicate with the Refrigerant Monitor, then click Start,

point to Programs, point to Accessories, point to Communications, click HyperTerminal, and double-click
the file name or icon that has been associated with the Refrigerant Monitor.

• If HyperTerminal has never been run in association with the Refrigerant Monitor, then a new

HyperTerminal connection needs to be made as follows:

a) Click Start; click Run. In the Run box type “hypertrm.exe” and click OK. The New Connection

dialog box should appear.

b) Type in a New Connection Name such as “C

”. Click OK to select the default icon (if desired,

2N2

select a different icon before clicking OK). The Connect To dialog box should appear.

c) Click the Connect using drop-down menu and choose the COM port to which the analyzer is

connected. Then click OK to display the COM Properties dialog box for that COM port.

d) Set Port Settings to:

- Bits per second: 19200

- Data bits: 8

- Parity: None

- Stop bits: 1

- Flow control: None

Then click OK to display HyperTerminal’s main window.

e) Click File; click Save. This creates a file with an .ht extension in the folder C:\Program

Files\Accessories\Hyper Terminal, using the name that was entered in Step b.

3. After HyperTerminal is running: click Transfer, click Capture Text, and then click Start to accept the default

drive\directory\filename to which all received data will be stored as an ASCII text file.

Note: By default, the captured text file will be stored on the hard drive at C:\Program
Files\Accessories\HyperTerminal\CAPTURE.TXT. If desired, click Browse to select a different drive,
directory and filename. The next time data is captured, it will be stored under the same location and
filename.

Tip: Changing the filename extension to “CSV” (comma separated variable) will allow the file to be directly
opened in the spreadsheet program. For example, double clicking the filename CAPTURE.CSV in Windows
Explorer will automatically start Microsoft Excel and load the file.

4. From the Data Display screen, press both the Keypad Left and Right buttons at the same time to display

the first Function Menu screen. Next, use the Keypad buttons to move the arrow (>) until it points to PC­DUMP, and then press the ENTER button to begin the download process.

Instruction 3015-5466 (Rev 6) 23

Halogen Monitor (Bagless PAGM)

5. Observe that the Refrigerant Monitor’s screen goes blank and that HyperTerminal displays the data as it is

being received. After all data has been transmitted, the Refrigerant Monitor re-displays the Function
Menu screen.

6. To stop capturing data and save it, click Transfer, click Capture Text, click Stop.

7. HyperTerminal and the connection to the Refrigerant Monitor can now be closed.

3.16 Importing Saved Data Into a Spreadsheet

A text file that was created as described in Section 3.15 Downloading Stored Data to a Personal Computer can be
imported into spreadsheet programs that are capable of importing comma-delimited files.

The following describes how to generate a spreadsheet from a comma-delimited text file using Microsoft Excel.
If you are using a different spreadsheet program, then please refer to its instruction manual for information on
how to import comma-delimited text files.

Tip: If the text file was saved with the filename extension “CSV” a spreadsheet will automatically be created

when that file is opened in Microsoft Excel.

1. Start Microsoft Excel.

2. Click File, and then click Open to display the Open dialog box.

3. Change the “Files of type:” to Text Files. Then navigate to the directory containing the text file to be

imported.

4. Double-click the desired filename to display the Text Import Wizard – Step 1 of 3 dialog box.

5. Select the Delimited radio button; then click Next to display the Text Import Wizard – Step 2 of 3 dialog

box.

6. Under Delimiters, select the Comma check box. Then click Next to display the Text Import Wizard – Step 3

of 3 dialog box.

a. Click Finish to create the spreadsheet.

7. The following is a sample spreadsheet showing the Date (month/day/year) and Time (24 hr format) the data was

recorded, and the recorded PPM refrigerant gas Level:

5/30/2007 8:00 0

5/30/2007 8:01 74

5/30/2007 8:02 74

5/30/2007 11:17 300

5/30/2007 11:18 300

5/30/2007 11:19 305

24 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

4 Maintenance

4.1 Disassembly

When servicing the parts inside the Refrigerant Monitor, disassemble the monitor’s metal chassis as follows:

Items Required:

• Medium Phillips head screwdriver

Procedure:

1. Remove monitor and its battery pack from the soft carrying case.

2. Unplug battery pack from monitor.

3. Remove a total of 10 screws from the locations shown in the illustrations below.

4. Carefully separate the metal chassis.

Instruction 3015-5466 (Rev 6) 25

Halogen Monitor (Bagless PAGM)

PARTICULATE/HYDROPHOBIC FILTERS

4.2 Internal Particulate / Hydrophobic Filter

Replacement

Items Required:

• Replacement filter (P/N 07-1654)

• Medium Phillips head screwdriver

Procedure:

1. Disassemble the monitor’s metal chassis per Section 4.1.

2. See illustration below and locate the internal particulate/hydrophobic filters.

NOTE: The third filter at the pump exhaust does not require periodic replacement.

3. Pull off tubing from both ends of filter and remove filter from instrument.

4. Attach tubing to new filter.

5. Reassemble monitor.

26 Instruction 3015-5466 (Rev 6)

Halogen Monitor (Bagless PAGM)

4.3 Updat ing Fir mware

An RS-232 connector, located on the top panel, is used to upgrade the monitor’s firmware. This flash memory
programming connector is for factory and service technician use only.

4.4 Probe Filter Replacement

Probe assembly 3015-5694 includes an inline coalescing filter 3015-3071. This filter should be replaced after
every 50 hours of use, or anytime liquid is drawn into the probe. The filter includes an arrow that indicates the
direction of flow. Replace the filter by gently pulling the tubing from each end. Orient the arrow so that it
points toward the elbow connected to the refrigerant monitor.

IMPORTANT: If liquid has entered the coalescing filter 3015-3071 to the point where it has soaked it,
the internal filters must also be changed. Disconnect the probe and dry it out with clean compressed
air. Failure to properly clean and dry the probe, along with changing the internal filter could result in
instrument damage and void the warranty.

For refrigerant monitor 3015-5420, replace the external filter 3015-5324 every 50 hours or anytime it becomes
contaminated with liquid.

Instruction 3015-5466 (Rev 6) 27

Halogen Monitor (Bagless PAGM)

5 Parts and Service

5.1 Replacement Parts & Optional Accessories

Replacement Parts

Part Number Item Description

3015-5420
3015-5696

3015-2906 External Filter
0007-1654 Hydrophobic Filter
3015-5324 External Filter Assembly
3015-5722 Replacement Input Charcoal Filter Assembly for 3015-5420 Units
3015-5714 Replacement Input Charcoal Filter Assembly for 3015-5696 Units
3015-3071 Replacement Coalescing Filter (for probe 3015-5694)
0003-6182 Tubing (order by the foot)
3015-4239 Replacement Pump
0204-0020 Battery (for main PCB board)
3015-4721 Replacement IR Sensor Kit
3015-5739 Replacement Battery Pack and Charger Kit
3015-5326 Stainless Steel Tube

Refrigerant Monitors

Optional Accessories

Part Number Item Description

0304-2743 Tubing 0.250” O.D. (25 ft.)
0104-4027 Computer Communications Cable (DB9 male to DB9 female)
0024-1229 IrDA Printer Kit, 120 VAC (printer, 120 VAC adapter, 12V in car charger, belt clip, instruction manual)
0024-1230 IrDA Printer Kit, 230 VAC (printer, 230 VAC adapter, 12V in car charger, belt clip, instruction manual)
0006-8733 Thermal Paper Roll for IrDA printer
0024-1244 Battery Pack, rechargeable, 7.2V, Li-ion
3015-4214 Cable (DB9 to RJ45)
0024-1243 AC adapter: 120 VAC
0024-1245 AC adapter: 230 VAC
0024-1250 12V in car charger
3015-5753 Manifold replacement fitting

5.2 Service Centers

Service and replacement parts can be obtained by contacting any of the following Bacharach Service Centers.

United States

Bacharach, Inc.
621 Hunt Valley Circle
New Kensington, PA 15068
Phone: [phone]
Fax: [phone]
Email: [e-mail]

28 Instruction 3015-5466 (Rev 6)

Canada

Bacharach of Canada, Inc.
20 Amber St. Unit# 7
Markham, Ontario L3R SP4
Canada
Phone: [phone]
Fax: [phone]
Email: [e-mail]

Halogen Monitor (Bagless PAGM)

Instruction 3015-5466 (Rev 6) 29

Halogen Monitor (Bagless PAGM)

World Headquarters: 621 Hunt Valley Circle, New Kensington, PA 15068-7074

PHONE: [phone] FAX: [phone] WEBSITE:

Printed in U.S. A. ® Registered Trademark of Bacharach Inc.

30 Instruction 3015-5466 (Rev 6)

www.MyBacharach.com E-MAIL: [e-mail]
