ACCPAC N0. NAME QTY.
73-D001 1 #1 KEY NA
73-D002 2 #2 SHAFT SPROCKET NA
73-D003 3 #3 DEEP GROOVE BALL BEARING 6004ZZ NA
73-D004 4 #4 BEARING BLOCK NA
73-D005 5 #5 SHAFT SPROCKET NA
73-D006 6 #6 CHAIN NA
73-D007 7 #7 CHAIN NA
73-D008 8 #8 PIN BEARING FC-20 NA
73-D009 9 #9 DEEP GROOVE BALL BEARING 6003ZZ NA
73-D010 10 #10 C. RETAINER RING S-17 NA
73-D011 11 #11 STAY NA
73-D012 12 #12 CHAIN NA
73-D013 13 #13 SHAFT SPROCKET NA
73-D014 14 #14 CHAIN NA
73-D015 15 #15 CHAIN NA
73-D016 16 #16 SPACERS NA
73-D017 17 #17 WASHER, FLAT NA
73-D018 18 #18 BOLT NA
73-D019 19 #19 SUPPORT BRACKET NA
73-D020 20 #20 REAR PANEL NA
73-D021 21 #21 REAR CASING NA
73-D022 22 #22 DEEP GROOVE BALL BEARING 6205ZZ NA
73-D023 23 #23 C. RETAINER RING R-52 NA
73-D024 24 #24 CHAIN NA
73-D025 25 #25 C. RETAINER RING S-70 NA
73-D026 26 #26 EXPANSION SPRING NA
73-D027 27 #27 CONNECTING BOARD NA
73-D028 28 #28 LEVER RING NA
73-D029 29 #29 CHAIN NA
73-D030 30 #30 CHAIN NA
73-D031 31 #31 DEEP GROOVE BALL BEARING 6205ZZ NA
73-D032 32 #32 CHAIN NA
73-8345 33 #33 MOTOR NA
73-8344 34 #34 CONVEYOR BELT NA
73-D035 35 #35 BOLT, ADJUSTABLE NA
73-D036 36 #36 LEFT SUPPORT BRACKET NA
73-D037 37 #37 RIGHT SUPPORT BRACKET NA
73-D038 38 #38 EXTENSION CATCH PAN NA
73-D039 39 #39 SHAFT, DRIVEN NA
73-D040 40 #40 C. RETAINER RING S-17 NA
73-D041 41 #41 DEEP GROOVE BALL BEARING 6203ZZ NA
73-D042 42 #42 ROLLER NA
73-D043 43 #43 BASE NA
73-D044 44 #44 CONNECTING ROD NA
73-D045 45 #45 LEFT SUPPORT BRACKET NA
73-D046 46 #46 RIGHT SUPPORT BRACKET NA
73-D047 47 #47 BASE NA
73-D048 48 #48 BEARING BLOCK NA
73-D049 49 #49 DEEP GROOVE BALL BEARING 6003ZZ NA
73-D050 50 #50 THRUST BALL BEARING 5 12 03 NA
73-D051 51 #51 SHAFT, ROLL NA
73-D052 52 #52 BEARING BLOCK NA
73-D053 53 #53 AXLE, SUPPORTING NA
73-D054 54 #54 NUT NA
73-D055 55 #55 SEAT, SLIDING NA
73-D056 56 #56 DEEP GROOVE BALL BEARING 6205ZZ NA
73-D057 57 #57 UP ROLLER NA
73-D058 58 #58 BOLT, ADJUSTABLE NA
73-D059 59 #59 LEVER, DEAD NA
73-D060 60 #60 LINK MASS NA
73-D061 61 #61 TORSIONAL SPRING NA
73-D062 62 #62 BAR, FULCRUM NA
73-D063 63 #63 STRICKLE SWEEP NA
73-D064 64 #64 BAR, FULCRUM NA
73-D065 65 #65 FRONT CASING NA
73-D066 66 #66 ROLLER HEAD HOUSING NA
73-D067 67 #67 STOP PIN NA
73-D068 68 #68 SAFETY GUARD NA
73-D069 69 #69 DEEP GROOVE BALL BEARING 6205ZZ NA
73-D070 70 #70 DOWN ROLLER NA
73-D071 71 #71 STRICKLE SWEEP NA
73-D072 72 #72 BOLT, SUPPORT NA
73-D073 73 #73 BOLT, ANCHOR BLOCK NA
73-D074 74 #74 SET SCREW NA
73-D075 75 #75 EXPANSION SPRING NA
73-D076 76 #76 RINGS NA
73-D077 77 #77 TRIGGER NA
73-D078 78 #78 MICRO SWITCH NA
73-D083 83 #83 MICRO SWITCH NA
73-D084 84 #84 BOLT NA
73-D085 85 #85 COMPRESSION SPRING NA
73-D086 86 #86 BALL NA
73-D088 88 #88 LOCATING MASS NA
73-D089 89 #89 MOVEMENT CONTROL LEVER NA
73-D090 90 #90 BOLT, SHAFT NA
73-D091 91 #91 C. RETAINER RING S-25 NA
73-D092 92 #92 CONNECTING BOARD NA
73-D093 93 #93 GRADUATED SCALE NA
73-D094 94 #94 FINGER NA
73-D095 95 #95 HANDLE BASE NA
73-D096 96 #96 FRONT PANEL NA
73-D097 97 #97 WASHER, FLAT NA
73-D098 98 #98 HANDLE NA
73-D099 99 #99 SPACERS NA
73-D100 100 #100 SPACERS NA
73-D101 101 #101 BOLT COVER NA
73-D102 102 #102 PIN NA
73-D103 103 #103 COMPRESSION SPRING NA
73-D104 104 #104 TRIGGER, LOCKING PIN NA
73-D105 105 #105 LOCKING MASS NA
73-D106 106 #106 RAIL REST NA
73-D107 107 #107 BOLT, CHEESE HEAD NA
73-D108 108 #108 NUT NA
73-D109 109 #109 DEEP GROOVE BALL BEARING 6003ZZ NA
73-D110 110 #110 IDLER WHEEL NA
73-D111 111 #111 FIXED BASE NA
73-D112 112 #112 FIXED BOARD NA
73-D113 113 #113 LOCATING MASS NA
73-D114 N/A #CR-2-1-6 CONTACTOR NA
